Table of Contents Service and Maintenance Procedures 129359-452, Volume 1
A WORD FROM STERIS CORPORATION
Thismanualcontainsimportantinformationonproperuseandmaintenanceof
thissterilizer.Alloperatorsanddepartmentheadsareurgedtocarefullyreview
and become familiar with the warnings, cautions and instructions contained
herein. Thissterilizerisspecificallydesignedtoprocessgoodsusingonlythe
cycles as specified in this manual. If there is any doubt about a specific
material or product, contact the manufacturer of the product for the recom-
mended sterilization technique.
A thorough preventive maintenance program is essential to safe and proper
sterilizer operation. You are encouraged to contact STERIS concerning our
PreventiveMaintenanceAgreement.Undertermsofthisagreement,preven-
tivemaintenance, adjustments, and replacementofworn parts aredoneon a
scheduled basis to assure equipment performance at peak capability and to
helpavoiduntimelyorcostlyinterruptions. STERISmaintainsanationwidestaff
ofwell-equipped,factory-trainedtechnicianstoprovidethisservice,aswellas
expert repair services. Contact your STERIS representative for details.
STERIScarriesacompletelineofaccessoriesforthisunittosimplify,organize
andassuresterilityofthesterilizationprocess. Instrumenttrays,Vantageand
DEXTEX wraps and biological/chemical monitoring systems are all available
to fulfill your facility’s processing needs. A STERIS representative will gladly
review these with you.
This sterilizer is not designed to process flammable liquids nor liquids inThis sterilizer is not designed to process flammable liquids nor liquids in
This sterilizer is not designed to process flammable liquids nor liquids inThis sterilizer is not designed to process flammable liquids nor liquids in
This sterilizer is not designed to process flammable liquids nor liquids in
containersthatarenotdesignedforsterilization.containersthatarenotdesignedforsterilization.
containersthatarenotdesignedforsterilization.containersthatarenotdesignedforsterilization.
containersthatarenotdesignedforsterilization. Anyalterationofthesterilizer
which affects its operation will void the warranty and could violate state and
local regulations and jeopardize insurance coverage.
IMPORTANT: A SUMMARY OF THE SAFETY PRECAUTIONS TO BE OB-
SERVED WHEN OPERATING THIS EQUIPMENT CAN BE FOUND ON PAGE
1 OF EACH VOLUME OF THIS MANUAL AND BEHIND THE UPPER ACCESS
PANELOFTHEUNIT. DONOTOPERATETHESTERILIZERUNTILYOUHAVE
BECOME FAMILIAR WITH THIS INFORMATION.
SERIES 3011 SERIES 3013
16x16x26" Gravity 16x16x26"Vacamatic
(406x406x660 mm) (406x406x660 mm)
SERIES 3021 SERIES 3023
20x20x38" Gravity 20x20x38"Vacamatic
(508x508x965 mm) (508x508x965 mm)
SERIES 3031 SERIES 3033
24x36x36" Gravity 24x36x36"Vacamatic
(610x914x914 mm) (610x914x914 mm)
SERIES 3041 SERIES 3043
24x36x48" Gravity 24x36x48"Vacamatic
(610x914x1219 mm) (610x914x1219 mm)
SERIES 3051 SERIES 3053
24x36x60" Gravity 24x36x60"Vacamatic
(610x914x1524 mm) (610x914x1524 mm)
© 1988-1991, STERIS Corporation. All rights reserved.

iii
Table of Contents Service and Maintenance Procedures 129359-452, Volume 1
TABLE OF CONTENTS
Section Description Page
1 SUMMARY OF SAFETY PRECAUTIONS.........................................1-1
2 INSTALLATION VERIFICATION.......................................................2-1
2.1 Installation Checklist ..................................................................2-1
2.2 Filling/Starting Optional Electric Steam Generator
Boiler (If Equipped) ....................................................................2-3
3 SERVICE ADJUSTMENTS AND SPECIAL FEATURES ..................3-1
3.1 Automatic Duplicate Print ...........................................................3-2
3.2 Intermittent BuzzerWhen Cycle Complete.................................3-2
3.3 Access Code To Set CycleValues..............................................3-2
3.4 LanguageOption........................................................................3-4
3.5 Sterilizer Number .......................................................................3-5
3.6 Set Sterilizer Clock/CalendarTime and Date .............................3-5
3.7 Set Automatic Utilities ControlTimes..........................................3-6
3.8 Laboratory Option Description ...................................................3-7
3.8.1 Set SterilizeTemperature Overdrive ..............................3-7
3.8.2 Undertemperature Recovery Function ..........................3-8
3.8.3 Steam Pressure Regulator (Sterilization At
Temperatures Below 250 F) ..........................................3-8
4 ROUTINE MAINTENANCE ...............................................................4-1
4.1 Daily...........................................................................................4-2
4.2 Weekly .......................................................................................4-2
4.3 Monthly ......................................................................................4-3
4.4 Quarterly....................................................................................4-3
4.5 Optional Steam Generator .........................................................4-3
4.6 As Necessary.............................................................................4-3
4.6.1 Change Paper Roll ........................................................4-3
4.6.2 Install Chamber Door Gasket ........................................4-5
5 OPERATOR TROUBLESHOOTING .................................................5-1
6 REPLACEMENT PARTS...................................................................6-1
6.1 Spare Parts List (Series 3011, 3021, 3013 And 3023) ...............6-1
6.2 Spare Parts List (Series 3031, 3041, 3051, 3033, 3043
And 3053) ..................................................................................6-4
7 ASSOCIATED PUBLICATIONS........................................................7-1

iv
129359-452, Volume 1 Service and Maintenance Procedures Table of Contents
Amsco Eagle®3000 Series Sterilizers

1-1
Summary of Safety Precautions Service and Maintenance Procedures 129359-452, Volume 1
SUMMARY OF SAFETY PRECAUTIONS 1
The following is a summary of safety precautions to be observed when operating or servicing this unit. WARNINGS
indicate the potential for danger to personnel, and CAUTIONS indicate the potential for damage to equipment.
The precautions are repeated (in whole, or in part) where applicable throughout the manual. This is a listing of
all safety precautions appearing in the manual. Carefully read them before proceeding to use or service the unit.
WARNING – BURN AND SHOCK HAZARD:
Repairsandadjustments should beattemptedonlyby authorized personsfullyacquainted
with this equipment. Use of inexperienced, unqualified persons to work on the equipment or the
installation of unauthorized parts could cause personal injury or result in costly damage.
Allow sterilizer, generator (if applicable) and accessories to cool to room temperature
before performing any cleaning or maintenance procedures.
Sterilizer and rack/shelves will be HOT after cycle is run. Always wear protective gloves and
apron (also face shield if processing liquids) when removing a processed load. Protective gloves and
apron should also be worn when reloading sterilizer following previous operation.
When sterilizing liquids, to prevent personal injury or property damage resulting from
bursting bottles and hot fluid, you must observe the following procedure:
•Use LIQUIDS cycle only. No other cycle is safe for processing liquids.
•Use only vented closures —do not use screw caps or rubber stoppers with crimped seal.
•Use only Type I borosilicate glass bottles —do not use ordinary glass bottles or any container not
designed for sterilization.
•Avoid sudden full opening of door at end of cycle. Open sterilizer door no more than one inch and wait
at least 10 minutes before unloading sterilizer.
•Do not allow hot bottles to be jolted. This can cause hot-bottle explosions! Do not move bottles if any
boiling or bubbling is present.
•Allow bottles to cool to touch before attempting to move them from sterilizer shelf or tray(s) to the storage
area.
A steam supply malfunction may cause the sterilizer-chamber to fill with scalding water.
Do not open chamber door if the unit fails to complete an automatic cycle or if water leaks past the door
gasket upon unlocking the door.
WARNING – SLIPPING HAZARD:
To avoid slippery floor conditions, immediately wipe up any spillage or condensation in sterilizer
loading area.
WARNING – EXPLOSION HAZARD:
This sterilizer is not designed to process flammable liquids.

1-2
129359-452, Volume 1 Service and Maintenance Procedures Summary of Safety Precautions
CAUTION – POSSIBLE EQUIPMENT DAMAGE:
Never use a wire brush, abrasives or steel wool on door and chamber assembly.
After installation it is mandatory to brace piping so that it will not move vertically. Failure to do so may allow
p-trap to separate from the funnel.

2-1
InstallationVerification Service and Maintenance Procedures 129359-452, Volume 1
INSTALLATION VERIFICATION 2
An EQUIPMENT DRAWING showing all utility and space requirements was
senttopurchaserafterorder forthis sterilizerwasreceived.Clearancespace
shownonthedrawingisnecessaryforeaseofinstallationandtoassureproper
operation and maintenance of equipment. INSTALLATION and UNCRATING
INSTRUCTIONSwere alsofurnished withsterilizer. Ifanyofthesedocuments
are missing or misplaced, contact STERIS giving the Serial, Equipment and
Model numbers. Replacement copies will be sent to you promptly.
2.1 Installation Checklist (See Figure 2-1)
After installing this unit according to instructions provided, complete the
followingchecklisttoassurethatyourinstallationiscompleteandcorrect. Or,
if you desire, contact your STERIS representative for a technician to be
scheduledtotestyour installationanddemonstrateproper equipmentopera-
tion.
Shut-off valves, for maintenance purposes, installed in steam and water
lines at a point near the equipment.
Disconnectswitch(withOFFpositionlockout)installedinelectricsupplyline
near the sterilizer.
NOTE:Iftheequipmentisinstallednexttootherequipment,shutoffvalvesand
disconnectswitchesshouldbeplacedsothatservicecanbeshutofftoanyone
unit.
Service clearance is as shown on the EQUIPMENT DRAWING.
Levelingscrewsarecorrectlyadjustedsothatsterilizerislevelandisatthe
heightshownontheEQUIPMENTDRAWING.Tocheck,proceedasfollows:
a. Place a spirit level on sterilizer end ring in door opening (side to side).
b. SmallSterilizers-Placelevelonrightsideofstandonundersideofangle
supporting shell (running front to back).
Medium Sterilizers - Place level on sterilizer end ring in door opening
(top to bottom).
If a recessed machine, panel trim fits tightly against curtain-wall opening.
Building steam line (direct steam units) provides condensate-free steam
between97and100%saturatedvaporandthatpressureisasspecifiedon
the EQUIPMENT DRAWING.
Buildingcoldwaterlinesupplieswatertosterilizeratthepressurespecified
on the EQUIPMENT DRAWING.
Drain funnel is placed in the building waste line outlet (stubbing).
Electrical supply for sterilizer controls is as specified on the EQUIPMENT
DRAWING.
Iffurnished, rack is secureand shelves move freelyinand out ofchamber.
If applicable, building hot water line supplies water to electric generator of
sterilizer at the pressure specified on the EQUIPMENT DRAWING.
If applicable, electric supply for optional steam generator heaters is as
specified on the EQUIPMENT DRAWING. Circuit protection by others, not
supplied as part of the generator.
If applicable, disconnect switch for optional steam generator heaters is
installed in electric supply line near the sterilizer.

2-2
129359-452, Volume 1 Service and Maintenance Procedures InstallationVerification
Figure 2-1. Installation Verification

2-3
InstallationVerification Service and Maintenance Procedures 129359-452, Volume 1
2.2 Filling/Starting Optional Electric Steam Generator Boiler
(If Equipped) (See Figure 2-2)
1. Verify that the steam-to-jacket valve is closed.
NOTE: Water to sterilizer must also be turned on.
2. Open the drain valve on the side of the unit.
3. Open the water-level sight glass valves and water supply valve if they are
closed.
NOTE:Watersupplyisthreepositionvalve.Rotatequickly180°counterclock-
wise.
4. Position the main electric power disconnect switch to ON. (The main
disconnect switch is not part of the generator.)
5. PositionthesterilizerpowerswitchtotheONposition.Waterwillflowintothe
generator and out of the drain valve, flushing out the boiler.
6. Allow the unit to flush for at least 3 minutes; then close the drain valve. The
generator will fill to the proper working level and then start to heat.
7. Open the steam-to-jacket valve slowly when the generator has reached
proper operating pressure (within 10 minutes after flushing).
Figure 2-2. Optional Steam Generator

3-1
Service Adjustments and Special Features Service andMaintenance Procedures 129359-452, Volume 1
SERVICE ADJUSTMENTS AND
SPECIAL FEATURES 3
BURN AND SHOCK HAZ-
ARD: Repairs and adjust-
ments should be attempted
only by authorized persons
fully acquainted with this
equipment. Useofinexperi-
enced, unqualified persons
toworkontheequipmentor
the installation of unautho-
rizedpartscouldcauseper-
sonal injury or result in
costly damage.
Factorysettingsofcertainsterilizercontrolfunctionsareserviceadjustableto
best adapt sterilizer to your operation. See Tables 3-1 and 3-2 for a listing of
these features.
NOTE: These adjustments must be made by a qualified service technician.
ProceduresformakingtheseadjustmentsareincludedintheMAINTENANCE
MANUAL (see Section 7 for ordering information).
TABLE 3-1. SERVICE ADJUSTMENTS
(Dip Switch)
Function Factory Setting Optional
Temperature Display
and Printout Units* Degrees F Degrees C
Pressure Display
and Printout Units PSIG Bar
Time Display and
Printout Units Std. AM/PM Military
AutomaticDuplicate
Printout No Yes
AutomaticUtilities
Control** No Yes
Intermittent Buzzer
for Cycle Complete Yes No
Access Code
For Cycle Values No Yes
Point of Use
Laboratory or Hospital Hospital Lab***
Undertemperature Restart Resume
Recovery Timer Timer***
* For both Fahrenheit and Centigrade temperatures (in hospital or laboratory mode),
temperature is set and displayed to the nearest degree; however, temperature
control and printout is to the nearest 1/10 degree.
**Requires optional Utilities Shutdown Valve Kit.
***These adjustments are only for use in a laboratory. See VOLUME 3, STERILIZER
OPERATING PROCEDURES —LABORATORY USAGE

3-2
129359-452, Volume 1 Serviceand Maintenance Procedures Service Adjustments and Special Features
TABLE 3-2 SERVICE ADJUSTMENTS
(Field Test Mode)*
Function Factory Setting Optional
SterilizeTemperature
Overdrive* 3.0 F 0-9.9 F
Overtemperature Point 20.0 F 0-99.9 F
UndertemperaturePoint 2.0 F 0-9.9 F
Pressure Points
P1, P2, P3 26, 1, 3 psig 0-36 psig
Vacuum Point (Express,
Prevac Cycles) 26, 26.5 in Hg 0-36 in Hg
Number of EXPRESS - 2 0-99
Vacuum Pulses PREVAC - 4 0-99
Print Intervals 1 min./FLASH 0-99 min.
(Each Cycle) 5 min./others 0-99 min.
* These values are all operator settable in the laboratory mode.
** SterilizeTemperatureOverdrive,OvertemperatureandUndertemperaturearesettable
in 1/10 degree increments.
3.1 Automatic Duplicate Print
Sterilizercanbe settoautomaticallyfurnisha duplicateprintoutofeachcycle
attheendofthecycle.Firstlinewillalwaysread...DUPLICATEPRINT...and
complete printout of cycle data will be furnished.
3.2 Intermittent Buzzer When Cycle Complete
Sterilizer can be set so that the interim buzzer does not sound when cycle is
complete.Alladditionalwarningbuzzeralarmswillstillsoundevenifcomplete
buzzer is set to OFF.
3.3 Access Code To Set Cycle Values
NOTE: When Access Code function is set to OFF (service adjustment), no
printouts or displays will indicate the feature exists.
1. Open the printer door and position the power switch to ON.
•Display panel lights up.
•The printer records the time and date that the power is turned ON.
NOTE:Whenpowertoprevacuumsterilizersisswitchedon,displaywillshow
the following messages:
•First Message: PERFORM LEAK TEST? Press cycle selector touch pad
number 2 for NO.
•Second Message: PERFORM DART TEST? (BOWIE-DICK) Press cycle
selector touch pad number 2 for NO.
2. Close the printer door and raise the sliding door over the touch pad panel
to access the VALUES touch pads.

3-3
Service Adjustments and Special Features Service andMaintenance Procedures 129359-452, Volume 1
NOTE: When Access Code function is enabled, the following message is
displayed every time the CHANGE VALUES touch pad is pressed (even if no
cycles are locked-out):
DO YOU KNOW ACCESS CODE?
NO
(NO will be blinking on and off.)
Press CHANGE VALUES touch pad while “NO”is blinking to automatically
advance control to first cycle which is not locked-out and cycle and cycle
valuesmaybechangedperParagraph3.3ofVOLUMES2or3ofthismanual.
3. PressVALUES“UP”directionarrowtouchpadtochange“NO”to“YES”and
press CHANGE VALUES touch pad while “YES”is blinking to advance
control to the following display message:
ENTER ACCESS CODE
CODE IS 0000
(Cursor position [first digit] will be blinking on and off.)
4. Enter access code as follows:
a.PressVALUES“UP”directionarrowtouchpadthenumberoftimesequal
to the first digit.
b. PressCURSOR“RIGHT”directionarrowtouchpadtomovecursortothe
second digit.
c. PressVALUES“UP”directionarrowtouchpadthenumberoftimesequal
to the second digit.
d. PressCURSOR“RIGHT”directionarrowtouchpadtomovecursortothe
third digit.
e. PressVALUES“UP”directionarrowtouchpadthenumberoftimesequal
to the third digit.
f. PressCURSOR“RIGHT”directionarrowtouchpadtomovecursortothe
fourth digit.
g. PressVALUES“UP”directionarrowtouchpadthenumberoftimesequal
to the fourth digit.
h. Press CHANGE VALUES touch pad to input the entered access code.
•Ifincorrect accesscodeisentered,controlwilladvancetofirstcycle
whichisnotlocked-outandcycleandcyclevaluesmaybechangedper
Paragraph 3.3 or 3.5 of VOLUMES 2 or 3, STERILIZER OPERATING
PROCEDURES. If all four cycles are locked out, control will advance to
CHANGE TIME AND DATE display. Press SAVE VALUES touch pad to
advance control to READY mode, then repeat the procedure and enter
correct access code.
. . . or . . .
Figure 3-1. Turn Power On

3-4
129359-452, Volume 1 Serviceand Maintenance Procedures Service Adjustments and Special Features
•Ifcorrectaccesscodeisentered,thefollowingmessageisdisplayed:
CHANGE ACCESS CODE?
NEW CODE = 0000
(Cursor position (first digit) will be blinking on and off.)
NOTE: Maintain a written record of the currently set access code. If access
code is lost or forgotten, have a qualified service technician reset the access
code function.
5. Change access code if desired by repeating step 1a through 1h.
. . . or . . .
•Press CHANGE VALUES touch pad if not changing access code to
advance control.
NOTE: If a number of cycles are currently locked-out, that number will appear
in the following message instead of “0”. The following message is displayed:
CYCLES TO LOCK OUT = 0
(Cursor position [0] will be blinking on and off.)
NOTE: Locked-out cycles will always be in order; i.e., if one cycle locked-out,
it will be #1; if two cycles locked-out, they will be #1 and #2; etc.
6. If changing the number of locked-out cycles, press VALUES “UP”
direction touch pad the number of times equal to the desired number of
locked-outcycles (1,2,3 or4),then pressCHANGEVALUES touchpad to
advance control to cycle #1.
. . . or . . .
If not changing the number of locked-out cycles, press CHANGE
VALUES touch pad to advance control to cycle #1.
7. Changecycles and cyclevaluesper Paragraph 3.3 ofVOLUMES2, or 3 of
this manual.
3.4 Language Option
Sterilizer can be set to print and display in English, French or Spanish.
1. WithpowerswitchOFF,set DipSwitch#4onDisplayBoardtoONposition.
Turn power switch ON. Screen should display:
1 ENGLISH 3 ESPANOL
2 FRANCAIS
2. Press appropriate PB to select desired language.
3. Set dip switch to OFF position to retain selected language.
NOTE:Ifitisdesiredtooperatetheunitinmultiplelanguagesatvarioustimes,
leave the dip switch ON. Each time the unit is powered up, the display will ask
for language choice.
Figure 3-2. Access Code
Sequence

3-5
Service Adjustments and Special Features Service andMaintenance Procedures 129359-452, Volume 1
NOTE:WhetherswitchisONorOFF,anytimeaburn-inoccurs,thedisplaywill
ask for a language choice.
3.5 Sterilizer Number
Sterilizer can be set to print a specific sterilizer identification number from 00
to 99.
1. While in service test mode (Dip Switch #4 on Display Board), screen
displays:
STERILIZER = VAC00
OR
STERILIZER = GRA00
2. Use arrows to change 00 to desired number. Press SAVE VALUES PB to
save.
3.6 Set Sterilizer Clock/Calendar Time and Date
NOTE:Whenpowertoprevacuumsterilizersisswitchedon,displaywillshow
the following messages:
•First Message: PERFORM LEAK TEST? Press cycle selector touch pad
number 2 for NO.
•Second Message: PERFORM DART TEST? (BOWIE-DICK) Press cycle
selector touch pad number 2 for NO.
When the sterilizer is set for laboratory use the operator selects all values
showninTABLE 3-2inaddition toallthenormalhospitalvalues.Also,sterilize
anddrytimevaluesareinhours,minutesandsecondsinsteadofonlyminutes.
Values are set using the same procedure as hospital values. Printouts will
indicate LABORATORY STERILIZER when unit is set for laboratory. (See
printout example.)
1. Open the printer door and position the power switch to ON.
•Display panel lights up.
•The printer records the time and date that the power is turned ON.
2. Close the printer door and raise the sliding door over the touch pad panel
to access the VALUES touch pads.
NOTE: If access code feature is enabled, bypass code by pressing CHANGE
VALUES touch pad when NO is blinking.
3. Check display for correct time and date. To change either:
a. Press and release the CHANGE VALUES touch pad until the time and
date are displayed.
b. Movecursor(theblinkingdisplayposition)tothedigityouwishtochange
by pressing CURSOR direction pad (left or right).

3-6
129359-452, Volume 1 Serviceand Maintenance Procedures Service Adjustments and Special Features
c. Increaseordecreasethevalue(ofblinkingdigit)bypressingtheVALUE
direction pad (up or down).
d. Repeat steps b. and c. until correct time and date is set.
e. PressSAVEVALUESpadtorecordthenewtimeanddateandtoadvance
controltoreadymode.Printoutofcyclevaluesandnewtimeanddatewill
also be furnished.
3.7 Set Automatic Utilities Control Times (if
feature activated)
NOTE: When Automatic Utilities Control feature is set to OFF (service adjust-
ment), no printouts or displays will indicate that the feature exists.
Sterilizer can be set to automatically control utilities shutdown and restart
times.ThecontrolwillautomaticallyshutoffutilitieswhentheSHUTDOWNset
timeisreachedandturnthembackonwhentheRESTARTsettimeisreached.
IfacycleisinprogresswhentheSHUTDOWNtimeisreached,theutilities
will not be shut off until the cycle is complete.
The following conditions apply when the Automatic Utilities Control feature is
in use:
•If the SHUTDOWN and RESTART times are identical or if SHUTDOWN time
is set to zero, then no shutdown will occur.
•If the RESTART time is set to zero, then no restart will occur until a CYCLE
touch pad (numbered 1, 2, 3 and 4) or RESET touch pad is pressed.
•RESTART can be activated manually by pressing a CYCLE touch pad
(numbered 1, 2, 3 and 4) or pressing RESET touch pad when in the
SHUTDOWN phase.
•If a power failure occurs during SHUTDOWN, the control will return to
SHUTDOWN phase upon return of power.
When the control is in the SHUTDOWN phase the display will show:
UTILITIES SHUTDOWN
RESTART AT (SET TIME)
1. Open the printer door and position the power switch to ON.
•Display panel lights up.
•The printer records the time and date that the power is turned ON.
NOTE:Whenpowertoprevacuumsterilizersisswitchedon,displaywillshow
the following messages:
•FIRST MESSAGE: PERFORM LEAK TEST? Press cycle selector touch
pad number 2 for NO.
•SECOND MESSAGE: PERFORM DART TEST? (BOWIE-DICK) Press
cycle selector touch pad number two for NO.
2. Close the printer door and raise the sliding door over the touch pad panel
to access the VALUES touch pads.
NOTE: If access code feature is enabled, bypass code by pressing CHANGE
VALUES touch pad when NO is blinking.
Figure 3-3. Turn Power On

3-7
Service Adjustments and Special Features Service andMaintenance Procedures 129359-452, Volume 1
3. Set or change utilities control times as follows:
a. Press and release the CHANGE VALUES touch pad six times to
advance display to...
DAYS IN WEEK
DAY OF WEEK
b. Enter the number of days in week utilities control is desired (i.e., 5 for
Monday - Friday week; 7 for entire week, etc.).
c. Enter the number of day of the above entered week that it is (i.e.,
Wednesday of a 5 day week would be 3, Friday would be 5, etc.).
d. PressandreleasetheCHANGEVALUEStouchpadoncemore(seventh
time) to advance display to...
SHUTDOWN AT (TIME) A
RESTART AT (TIME) P
e. Movecursor(theblinkingdisplayposition)tothedigityouwishtochange
by pressing CURSOR direction pad (left or right).
f. Increaseordecreasethevalue(ofblinkingdigit)bypressingtheVALUE
direction pad (up or down).
g. Press SAVE VALUES pad to record the utility control times and to
advance control to READY mode. Printout of cycle values with utility
control times will also be furnished.
3.8 Laboratory Option Description
When the sterilizer is set for laboratory use the operator selects all values
showninTABLE 3-2inaddition toallthenormalhospitalvalues.Also,sterilize
anddrytimevaluesareinhours,minutesandsecondsinsteadofonlyminutes.
Values are set using the same procedure as hospital values. Printouts will
indicate LABORATORY STERILIZER when unit is set for laboratory. (See
printout example.)
Laboratory processes may require additional special sterilizer adjustments
described in Paragraphs 3.6.1, 3.8.2 and 3.8.3.
Refer to VOLUME 3, STERILIZER OPERATING PROCEDURES –LABORA-
TORYUSAGEwhensterilizerisbeingusedinthelaboratorymodeofoperation.
3.8.1 Set Sterilize Temperature Overdrive
Controlsare factorycalibratedto controlchamber temperature at3.0 F*(2C)
above the set temperature. This overdrive setting assures effective load
temperature control and provides for the shortest possible cycle time. For
special sterilizer applications this can be adjusted from 0-9.9 F.

3-8
129359-452, Volume 1 Serviceand Maintenance Procedures Service Adjustments and Special Features
3.8.2 Undertemperature Recovery Function
NOTE:Resume-timeoptionisonlyforuseintheLaboratoryenvironment.Itis
not to be used in a hospital application.
Sterilizer is factory set so that if chamber temperature drops more than 2.0 F*
belowsetsterilizetemperature,andthensettemperatureisreattained,sterilize
timer will reset to full sterilize time.
Sterilizer can be adjusted so that if chamber temperature drops more than
2.0 F* below set sterilize temperature and then set temperature is reattained,
sterilize timer will resume counting down remaining sterilize time.
3.8.3 Steam Pressure Regulator (Sterilization At Temperatures
Below 250 F)
The steam pressure regulator (HI-LO Valve) is factory set for 250 and 270 F
(121and132C)sterilizationcycles.Forsterilizationtemperaturecontrolbelow
250F(121C),suchaslaboratoryprocesses,theLOsettingofsteampressure
regulator must be changed by a qualified service technician.
Printout Example
* This value is operator adjustable in the
laboratory mode of operation.

4-1
RoutineMaintenance Service and Maintenance Procedures 129359-452, Volume 1
ROUTINE MAINTENANCE 4
WARNING –BURN AND
SHOCK HAZARD: Repairs
and adjustments should
be attempted only by expe-
rienced persons fully
acquainted with this
equipment. Use of inexperi-
enced, unqualified persons
toworkontheequipmentor
the installation of unautho-
rized parts could cause
personal injury or result in
costly damage.
WARNING –BURN HAZ-
ARD: Allow sterilizer,
generator(ifapplicable)and
accessoriestocooltoroom
temperaturebeforeperform-
ing any cleaning or mainte-
nance procedures.
CAUTION–Neveruseawire
brush, abrasives or steel
wool on door and chamber
assembly.
IMPORTANT::
::
:Paragraph4.4,step3callsforperiodiccheckingofsafetyvalve
operationinaccordancewiththe NationalBoardInspectionCode.Aperiodic
boilerinspectionbyaqualifiedinspectortochecktheintegrityofthepressure
vessel of units equipped with integral steam generator is also advisable. Be
sure to check state and local requirements for such inspections.
The following procedures should be performed at regular intervals, as indi-
cated.Thisfrequencyistheminimumandshouldbeincreasedifusageofthe
sterilizer demands. Should a problem occur, refer to Section 5, “Operator
Troubleshooting”.
Figure 4-1. Routine Maintenance
