Operation/Reference Guide
Inspired Signage
IS-SPX-1000
IS-SPX-1300
Inspired Signage XPress Players
Last Revised: 2/06/2013

Inspired Signage XPress Players
3
IS-SPX-1000 & IS-SPX-1300 Inspired Signage XPress Players
IS-SPX-1300
The IS-SPX-1300 Inspired Signage Xpress Player (FG1231-11) offers the same functionality as the IS-SPX Player, but
offers a different set of supported video and audio codecs, and media container formats (see Specifications tables).
IS-SPX-1300 Specifications
IS-SPX-1000 Specifications (Cont.)
Digita l Displa y Compat ibility
• Aspect ratio: • 16:9, 16:10, 4:3 (horizontal & vertical)
• Maximum resolution: • 1280x720 (16:9), 1024x640 (16:10), 1024x768 (4:3)
• Video output: • 720p (HD-Ready), 576p, 480p, VGA; 50 or 60 fps
• Video connectors: • HDMI (incl. digital audio), DVI via adapter. VGA (DB15 HD connector). Simultaneous use of
HDMI and VGA possible.
Certifications: • FCC, CE, RoHS
Operating Temp: HDMI: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% RH
VGA: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% RH
Storage Temp: -13ºF to 113ºF (-25ºC to 45ºC); 10% to 90% RH
Included Accessories: • Power Source (3A-161WP05)
• IS-SPX Player Installation Guide (93-1231-01)
Other AMX Equipment: • NXA-AVB Breakout Box Mounting Kit (KA-2250-40)
• IS-SPX-MNT Mount adapter (FG1231-71)
FIG. 2 IS-SPX-1300
IS-SPX-1300 Specifications
Dimensions (HWD) 1.0” x 6.27” x 3.24” (25.4mm x 159.26mm x 82.30mm).
Weight 0.80 lbs (362.88 g).
Enclosure: Metal with black matte finish.
Power Supply: • 5V DC, typ. 0.6A
• 3 watts
Power Supply Input: • 100-240V 50-60 Hz
Real time clock: • Min. accuracy 1 minute/month free running, battery backed.
Storage: • Internal storage: 2GB solid state.
• External storage: Flash drives and hard disks via USB 2.0 port.
5V-DC Input
RS232 Interface
Ethernet RJ45 USB 2.0 Connector
Reset
Analog Video Out (VGA)
Analog Audio OutDigital Video Out (HDMI)
Status LED

Inspired Signage XPress Players
4IS-SPX-1000 & IS-SPX-1300 Inspired Signage XPress Players
IS-SPX-1300 Specifications (Cont.)
Form at s, Codecs a nd Encoding Pa ra me ters
Audio file formats: AIFF, MP3, M4A (or MP4), WAV and WMA.
Video file formats: AVI, ASF, MOV, MP4, VOB and WMV
Audio codecs: • AAC - up to 6 channels input; the following AAC profiles are supported: (MPEG-2 Part 7) Low
Complexity Profile, (MPEG-4 Part 3) AAC Profile and High-Efficiency AAC Profile version 1
(HE-AAC v1).
Note: HE-AAC v1 requires firmware 2.2.5 or later. HE-AAC v2 is not supported.
•MPEG-1/2 Layer III (MP3) - the previous versions: MPEG-1/2 Audio Layer II (MP2) and
MPEG-1 Audio Layer I (MP1) are supported as well
•Linear PCM (LPCM)
•ITU-T G.711 and G.726
•Windows Media Audio (WMA)
Video codecs: • H.264 (H.264/MPEG-4 Part 10 or AVC)
•MPEG-4 (Part 2) or MPEG-4 Visual
•MPEG-2 and MPEG-1
•Windows Media Video 9 (WMV3) - Simple and Main profiles, Low and Medium levels;
Not supported: Main Profile @ High Level (MP@HL) and the Advanced Profile (WVC1 / VC-1
Advanced Profile).
•Motion JPEG (MJPEG) - interlacing is not supported and for QuickTime formats only MJPEG-
A is supported (MJPEG-B is not supported).
Profiles and Levels: • MPEG-4 (Part 2): Simple and Advanced Simple (SP/ASP) up to level 5 (reference: MPEG-4
levels) - resolution up to 720p.
•MPEG-2: Main profile and Main level (MP@ML) (reference: MPEG-2 profiles and levels) -
resolution up to 720p.
•H.264 (aka MPEG4 Part 10): Constrained Baseline or Main profile up to level 3 (reference:
H264 levels) - resolution up to SD.
•MJPEG - resolution up to SD.
•Windows Media Video 9 (WMV3): Simple and Main profiles, Low and Medium levels -
resolution up to SD.
Note: MPEG-4 is the most optimized codec to use on IS-SPX Players.
Front Pa nel Com pone nts:
• Ethernet RJ45 Ethernet 10/100 Mbit/s (RJ-45), IEEE 802.3u, 802.3x.
• USB 2.0 Connector Used with Flash drives and hard disks for additional external storage; interactivity events via
touch screen, keyboard and mouse.
• Status LED LED displays status of device:
• Green LED flashing once per second (regular operation)
• Green LED flashing 4 times per second (recovery mode)
• Green LED on and flashing occasionally (booting up)
• Orange LED blinks steadily (Zeroconf link-local IP address is assigned to device)
• LED alternates between red and orange (failure)
• Reset Reset button for rebooting device.
Re ar Pa nel Com ponents:
• DC Power Input 5V DC, typ. 0.6A (3W).
• HDMI HDMI (incl. digital audio), DVI via adapter.
• Analog Audio Out Line level, stereo, mini-jack 3.5mm
• Analog Video Out VGA (DB15 HD connector).
• RS232 Interface RS232, up to 115200 baud, mini-jack 3.5mm.
Digit al Displa y Compat ibilit y
• Aspect ratio • 16:9, 16:10, 4:3 (horizontal & vertical)
• Max resolution • 1280x720 (16:9), 1024x640 (16:10), 1024x768 (4:3)

Inspired Signage XPress Players
5
IS-SPX-1000 & IS-SPX-1300 Inspired Signage XPress Players
Remote Monitoring
IS-SPX Players implement an intuitive on-board web interface. By connecting to the IP address of a unit with any web
browser, the user can monitor the status of the unit and even configure specific parameters. To support the management
of a large distributed network of IS-SPX Players, native support for the SNMP protocol is provided. Through this
standard protocol, the devices can publish all their vital parameters, including storage level and CPU status. Via this
protocol, the IS-SPX Players can interface with any SNMP network management tool. These tools can provide graphical
frameworks for remote monitoring the status of an individual IS-SPX Player or a complex network of Players.
Storage
IS-SPX Players come with 2 gigabytes of internal memory, but this may be expanded by connecting to external hard
drives, thumb drives, or other storage options via the USB port on the front of the device. The USB port also allows
connection to external control devices such as touch panels.
Configuration
IS-SPX Players are configured via an intuitive web interface that can be accessed through any web browser. This
interface allows the configuration of display modes, network settings, time zone settings, firmware updates and other
operational parameters. For more information, refer to the Web-Based Configuration Pages on page 13.
Connectivity
IS-SPX Players connect to displays through on-board HDMI and VGA connectors. Through the HDMI output, it is
possible to support DVI displays via an adapter cable, but in this case the digital audio is lost. Both connectors are
simultaneously active so that two displays can be supported without the need of additional splitters or distribution
amplifiers. Where analog audio is needed an analog audio connector is provided.
IS-SPX Players are high-definition ready devices: they can render content on digital displays with resolution up to
1280x720 at 60Hz (720p resolution). The maximum resolution supported by IS-SPX Players is 1920x1080 for semi
static images.
IS-SPX Players connect to the network through a standard RJ-45 connector. IS-SPX Players support 10/100BASE-T
Ethernet via a standard RJ-45 connector. Each unit has a unique MAC address and supports all the required protocols to
connect to network file systems and retrieve media elements. These include:
Ethernet 10/100 Mbit/s,
IPv4, DHCP or fixed address
HTTP configuration server, password protected
HTTP client for web content retrieval
WebDAV server, password protected
HTTPS for webservers, content stored on a WebDAV server over a secure 443 port
SNMPv1/v2c,
NTP
IS-SPX Players support USB2.0 Hi-Speed with a bandwidth up to 10 Mbyte/second.
IS-SPX-1300 Specifications (Cont.)
Digita l Displa y Compat ibility (Cont .)
• Video output • 720p (HD-Ready), 576p, 480p, VGA; 50 or 60 fps
• 1080p: 24/25 Hz
• Video connectors • HDMI (incl. digital audio), DVI via adapter. VGA (DB15 HD connector). Simultaneous use of
HDMI and VGA possible.
Certifications: • FCC, CE, RoHS
Operating Temp: • HDMI: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% RH
• VGA: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% RH
Storage Temp: -13ºF to 113ºF (-25ºC to 45ºC); 10% to 90% RH
Included Accessories • Power Source (3A-161WP05)
Other AMX Equipment • AC-SMB Surface Mount Bracket Accessory (FG525)
• IS-SPX-MNT Mount adapter (FG1231-71)
• IS-SPX-SERIAL Inspired XPress Serial Cable (FG1231-60)
