AMX IS-SPX-1000 - SCHEMA Parts list manual

Operation/Reference Guide
Inspired Signage
IS-SPX-1000
InspiredSignage XPress Player
Last Revised: 5/31/2012

AMX Limited Warranty and Disclaimer
This Limited Warranty and Disclaimer extends only to products purchased directly from AMX or an AMX Authorized Partner which
include AMX Dealers, Distributors, VIP’s or other AMX authorized entity.
AMX warrants its products to be free of defects in material and workmanship under normal use for three (3) years from the date of
purchase, with the following exceptions:
• Electroluminescent and LCD Control Panels are warranted for three (3) years, except for the display and touch overlay compo-
nents are warranted for a period of one (1) year.
• Disk drive mechanisms, pan/tilt heads, power supplies, and MX Series products are warranted for a period of one (1) year.
• AMX lighting products are guaranteed to switch on and off any load that is properly connected to our lighting products, as long
as the AMX lighting products are under warranty. AMX also guarantees the control of dimmable loads that are properly con-
nected to our lighting products. The dimming performance or quality there of is not guaranteed, impart due to the random combi-
nations of dimmers, lamps and ballasts or transformers.
• AMX software is warranted for a period of ninety (90) days.
• Batteries and incandescent lamps are not covered under the warranty.
• AMX AutoPatch Epica, Modula, Modula Series4, Modula CatPro Series and 8Y-3000 product models will be free of defects in
materials and manufacture at the time of sale and will remain in good working order for a period of three (3) years following the
date of the original sales invoice from AMX. The three-year warranty period will be extended to the life of the product (Limited
Lifetime Warranty) if the warranty card is filled out by the dealer and/or end user and returned to AMX so that AMX receives it
within thirty (30) days of the installation of equipment but no later than six (6) months from original AMX sales invoice date. The
life of the product extends until five (5) years after AMX ceases manufacturing the product model. The Limited Lifetime Warranty
applies to products in their original installation only. If a product is moved to a different installation, the Limited Lifetime Warranty
will no longer apply, and the product warranty will instead be the three (3) year Limited Warranty.
All products returned to AMX require a Return Material Authorization (RMA) number. The RMA number is obtained from the AMX
RMA Department. The RMA number must be clearly marked on the outside of each box. The RMA is valid for a 30-day period. After
the 30-day period the RMA will be cancelled. Any shipments received not consistent with the RMA, or after the RMA is cancelled, will
be refused. AMX is not responsible for products returned without a valid RMA number.
AMX is not liable for any damages caused by its products or for the failure of its products to perform. This includes any lost profits, lost
savings, incidental damages, or consequential damages. AMX is not liable for any claim made by a third party or by an AMX Autho-
rized Partner for a third party.
This Limited Warranty does not apply to (a) any AMX product that has been modified, altered or repaired by an unauthorized agent or
improperly transported, stored, installed, used, or maintained; (b) damage caused by acts of nature, including flood, erosion, or earth-
quake; (c) damage caused by a sustained low or high voltage situation or by a low or high voltage disturbance, including brownouts,
sags, spikes, or power outages; or (d) damage caused by war, vandalism, theft, depletion, or obsolescence.
This limitation of liability applies whether damages are sought, or a claim is made, under this warranty or as a tort claim (including
negligence and strict product liability), a contract claim, or any other claim. This limitation of liability cannot be waived or amended by
any person. This limitation of liability will be effective even if AMX or an authorized representative of AMX has been advised of the
possibility of any such damages. This limitation of liability, however, will not apply to claims for personal injury.
Some states do not allow a limitation of how long an implied warranty last. Some states do not allow the limitation or exclusion of inci-
dental or consequential damages for consumer products. In such states, the limitation or exclusion of the Limited Warranty may not
apply. This Limited Warranty gives the owner specific legal rights. The owner may also have other rights that vary from state to state.
The owner is advised to consult applicable state laws for full determination of rights.
EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO OTHER WARRANTIES, EXPRESSED OR
IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. AMX
EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT
MAY BE IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS LIMITED WARRANTY. EXCEPT AS OTHERWISE LIMITED
BY APPLICABLE LAW, AMX RESERVES THE RIGHT TO MODIFY OR DISCONTINUE DESIGNS, SPECIFICATIONS, WARRAN-
TIES, PRICES, AND POLICIES WITHOUT NOTICE.

AMX Software License and Warranty Agreement
By opening the attached file or installing the software, you ("Licensee") agree to be bound by, and AMX LLC ("AMX") shall
be entitled to enforce, this AMX License Agreement ("Agreement"). By not opening the attached, Licensee (i) does not
agree to be bound by this Agreement; (ii) shall not be permitted access to the software accompanying, or obtained through,
this media; and (iii) if applicable, shall promptly return this media or copies in any media, at Licensee's expense, to AMX at
3000 Research Drive, Richardson, Texas 75082, USA.
1.LICENSE GRANT. The Software consists of programming and development software, product documentation, sample
applications, tools and utilities, technical information, associated media, printed materials, audiovisual content, and
"online" or electronic documentation (collectively, the "Product"). Please refer to the README.TXT file for further informa-
tion regarding the components of the Product. AMX grants to Licensee the non-exclusive, non-sublicensable right to use
the Product in the manner described in this License on a single computer. The Product is licensed, not sold. The Product is
subject to restrictions on distribution described in this License Agreement. You may not reverse engineer, decompile, dis-
assemble, or otherwise decipher any portion of the Product. Reproduction and/or redistribution of any portion of the Prod-
uct is specifically prohibited. YOU MAY NOT LICENSE, RENT, OR LEASE THE PRODUCT.
2.INTELLECTUAL PROPERTY. This Software is protected by United States copyright laws, patent laws, international treaty
provisions, and/or state of Texas trade secret laws. Licensee may make copies of the Product solely for backup or archival
purposes. Licensee may not copy the written materials accompanying the Product. This license does not impart or imply
any ownership or intellectual property rights in and to the Product. You agree to abide by the copyright law and all other
applicable US and International laws including those relating to export controls. You agree not to ship or re-export any por-
tion of the Product to any destination to which it could not lawfully have been exported originally under those export con-
trols.
3.CONTENT CREATION AND DISTRIBUTION. All video, audio, and other content accessed through the Product is the prop-
erty of the applicable content owner and may be protected by applicable copyright law. This Agreement gives you no rights
to such content. If you use the Product to create or distribute audio, video, or other content, AMX is not responsible for
such content, and you are solely responsible, for the property rights, legality, and regulation of all such content, including
but not limited to issues of copyright ownership and obscenity regulation worldwide.
4.TERMINATION. AMX RESERVES THE RIGHT, IN ITS SOLE DISCRETION, TO TERMINATE THIS LICENSE FOR ANY REA-
SON AND UPON WRITTEN NOTICE TO LICENSEE. In the event that AMX terminates this License, then Licensee shall return
all copies of the Product to AMX and certify in writing that all copies have been destroyed.
5.LIMITED WARRANTY. AMX warrants that the Product will perform substantially in accordance with the accompanying
written materials for a period of 90 days from the date of receipt. AMX DISCLAIMS ALL OTHER WARRANTIES, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, WITH REGARD TO THE PRODUCT. THIS LIMITED WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS.
6.LICENSEE REMEDIES. AMX's entire liability and your exclusive remedy shall be repair or replacement of the Product that
does not meet AMX's Limited Warranty and which is returned to AMX. This Limited Warranty is void if failure of the Product
has resulted from accident, abuse, or misapplication. Any replacement Product will be warranted for the remainder of the
original warranty period or 30 days, whichever is longer. Outside the United States, these remedies may not be available.
7.NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL AMX BE LIABLE FOR ANY DAMAGES WHATSO-
EVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION,
LOSS OF BUSINESS INFORMATION, OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO
USE THIS AMX PRODUCT, EVEN IF AMX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME
STATES/COUNTRIES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDEN-
TAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
8.U.S. GOVERNMENT RESTRICTED RIGHTS. The Product is provided with RESTRICTED RIGHTS. Use, duplication, or dis-
closure by the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of The Rights in Technical Data
and Computer Software clause at DFARS 252.227-7013 or subparagraphs (c)(1) and (2) of the Commercial Computer Soft-
ware Restricted Rights at 48 CFR 52.227-19, as applicable.
This Agreement is governed by the laws of the State of Texas, and all disputes will be resolved in the courts in Collin
County, Texas, USA.
NOTICE:
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”)
AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-
COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO
LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED
FROM MPEG LA, L.L.C SEE HTTP://WWW.MPEGLA.COM

i
IS-SPX-1000 InspiredSignage XPress Player
Table of Contents
Overview ............................................................................................................ 1
IS-SPX-1000 Overview .............................................................................................. 1
Specifications............................................................................................................ 1
Remote Monitoring................................................................................................... 2
Storage ..................................................................................................................... 3
Configuration............................................................................................................ 3
Connectivity.............................................................................................................. 3
Programming ............................................................................................................ 3
Supported Video File Types ..................................................................................... 3
Standard and Pro Licenses........................................................................................ 4
IS-SPX-1000 Installation...................................................................................... 5
Powering up the IS-SPX-1000 ................................................................................... 5
Resetting the IS-SPX-1000 to Factory Default Settings ............................................ 6
Updating Firmware ................................................................................................... 6
Automatic update ........................................................................................................... 7
Getting Connected ................................................................................................... 7
Accessing and Changing the IS-SPX-1000 IP Address .............................................. 7
Installing the IS-SPX-MNT Mount Adapter................................................................ 9
Installing the NXA-AVB Breakout Box Mounting Bracket ......................................... 9
Troubleshooting ..................................................................................................... 10
Configuring A PC Network Connection......................................................................... 10
IS-SPX-1000 Web-Based Configuration Pages.................................................. 13
Overview ................................................................................................................ 13
Navigation Bar........................................................................................................ 13
Information ............................................................................................................. 14
Status ............................................................................................................................ 14
Snapshot ....................................................................................................................... 15
Display Info ................................................................................................................... 16
Storage ......................................................................................................................... 17
Logs .............................................................................................................................. 18
Administration ........................................................................................................ 19
Display Settings - Basic ................................................................................................. 19
Display Settings - Advanced.......................................................................................... 20
Network Settings - Basic ............................................................................................... 22
Automatic DHCP Configuration .................................................................................... 23
Fixed IP Configuration .................................................................................................. 23

ii IS-SPX-1000 InspiredSignage XPress Player
Network Settings - Advanced ....................................................................................... 24
Media Sources - Basic.................................................................................................... 25
Using a USB drive with the IS-SPX-1000 ....................................................................... 26
Media Sources - Advanced ............................................................................................ 27
Configuring Network Credentials For Remote Servers ................................................. 27
Security ......................................................................................................................... 28
Controlling User Rights and Permissions ....................................................................... 29
Date/Time ..................................................................................................................... 30
RS232/USB IO ............................................................................................................... 32
Uploading Protocol Files ............................................................................................... 32
Pull Mode ...................................................................................................................... 33
Accessing a Remote iCalendar File on an IS-SPX-1000.................................................. 34
Firmware Update .......................................................................................................... 35
Maintenance - Basic....................................................................................................... 36
Maintenance - Advanced ............................................................................................... 37

1
IS-SPX-1000 Inspired Signage Xpress Player
Overview
IS-SPX-1000 Overview
The IS-SPX-1000 InspiredSignage Xpress Player (FG1231-01) offers a simple way to deliver digital signage
solutions. The rich set of functionalities offered by the SPX-1000 simplifies the implementation, management
and maintenance of a range of audio/visual communication solutions. The SPX-1000 is designed to satisfy the
reliability needs of nonstop 24/7 service and minimize maintenance costs. The SPX-1000 contains no moving
parts and is engineered to be used wherever digital signage displays are utilized.
Whether integrated behind displays, beneath a technical floor, or in a custom enclosure, the IS-SPX-1000 is
ready to deliver with a small form factor and a low power draw. The USB interface can be used to extend the
internal storage through memory sticks or hard drives. The same interface can support external devices such as
touch screen controllers or keyboards.
Specifications
FIG. 1 IS-SPX InspiredSignage Xpress Player
IS-SPX-100 Specifications (FG1231-01)
Dimensions (HWD) 1.0” x 6.27” x 3.24” (25.4mm x 158.75mm x 82.80mm).
Weight 0.60 lbs (272.16 g).
Enclosure: Metal with black matte finish.
Power Supply: • 5V DC, typ. 0.4A
• 2 watts
Power Supply Input: • 100-240V 50-60 Hz, max input current 0.6A.
Real time clock: • Min. accuracy 1 minute/month free running, battery backed.
Storage: • Internal storage: 2GB solid state.
• External storage: Flash drives and hard disks via USB 2.0 port.
Supported Video File Types:
Supported video codecs Up to SD resolution: MPEG-4 ASP, MPEG-2, MPEG-1, H.264, MJPEG, 
Microsoft VC-1 (Windows Media Video 9)
Supported audio codecs MPEG audio layer 1/2/3 (MP3), ITU G.711, G.722, PCM, Microsoft WMA, Real
Audio
Media container formats AVI, WMV/WMA, VOB, AIFF, OGG, WAV
front
rear
5V-DC Input
RS232 Interface
Ethernet
RJ45 USB 2.0
Connector Reset Button
Analog Video
Out (VGA)
Analog
Audio
Out
Digital Video Out (HDMI)
Status LED

2IS-SPX-1000 Inspired Signage Xpress Player
Remote Monitoring
The IS-SPX-1000 implements an intuitive on-board web interface. By connecting to the IP address of a unit
with any web browser, the user can monitor the status of the unit and even configure specific parameters. To
support the management of a large distributed network of IS-SPX-1000 devices, native support for the SNMP
protocol is provided. Through this standard protocol, the devices can publish all their vital parameters,
including storage level and CPU status. Via this protocol, the IS-SPX-1000 can interface with any SNMP
network management tool. These tools can provide graphical frameworks for remote monitoring the status of
an individual IS-SPX-1000 unit or a complex network of units.
IS-SPX-1000 Specifications (Cont.)
Supported Video File Types (Cont.):
Streaming media protocol MMS, RTSP, RTP, SDP, HTTP; Uni- & multicast
Front Panel Components:
• Ethernet RJ45 Ethernet 10/100 Mbit/s (RJ-45), IEEE 802.3u, 802.3x.
• USB 2.0 Connector Used with Flash drives and hard disks for additional external storage; interac-
tivity events via touch screen, keyboard and mouse.
• Status LED LED displays status of device:
• Green LED flashing once per second (regular operation)
• Green LED flashing 4 times per second (recovery mode)
• Green LED on and flashing occasionally (booting up)
• Orange LED blinks steadily (Zeroconf link-local IP address is assigned to
device)
• LED alternates between red and orange (failure)
• Reset Reset button for rebooting device.
• RS232 Interface RS232, up to 115200 bauds, mini-jack 3.5mm.
Rear Panel Components:
• DC Power Input 5V DC, typ. 0.4A (2W)
• HDMI HDMI (incl. digital audio), DVI via adapter.
• Analog Audio Out Supported audio codecs: MPEG audio layer 1/2/3 (MP3), ITU G.711, G.722,
G.729,PCM, Microsoft WMA, Real Audio.
• Analog Video Out VGA (DB15 HD connector).
Digital Display Compatibility:
• Aspect ratio • 16:9, 16:10, 4:3 (horizontal & vertical)
• Maximum resolution • 1280x720 (16:9), 1024x640 (16:10), 1024x768 (4:3)
• Video output • 720p (HD-Ready), 576p, 480p, VGA; 50 or 60 fps
• Video connectors • HDMI (incl. digital audio), DVI via adapter. VGA (DB15 HD connector).
Simultaneous use of HDMI and VGA possible.
Certifications: • FCC
•CE
•RoHS
Operating Temperature: HDMI: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% relative humidity
VGA: 32ºF to 104ºF (0ºC to 40ºC); 10% to 90% relative humidity
Storage Temperature: -13ºF to 113ºF (-25ºC to 45ºC); 10% to 90% relative humidity
Included Accessories • Power Source (3A-161WP05)
• IS-SPX-1000 Installation Guide (93-1231-01)
Other AMX Equipment • AC-SMB Surface Mount Bracket Accessory (FG525)
• IS-SPX-MNT Mount adapter (FG1231-71)
• AMX InspiredSignage Xpress Standard License (FG1231-20)
• AMX InspiredSignage Xpress Pro License (FG1231-21)

3
IS-SPX-1000 Inspired Signage Xpress Player
Storage
The IS-SPX-1000 comes with 2 gigabytes of internal memory, but this may be expanded by connecting to
external hard drives, thumb drives, or other storage options via the USB port on the front of the device. The
USB port also allows connection to external control devices such as touch panels.
Configuration
The IS-SPX-1000 is configured via an intuitive web interface that can be accessed through any web browser.
This interface allows the configuration of display modes, network settings, time zone settings, firmware
updates and other operational parameters. For more information, please refer to the IS-SPX-1000 Web-Based
Configuration Pages section on page 13.
Connectivity
The IS-SPX-1000 connects to displays through onboard HDMI and VGA connectors. Through the HDMI
output, it is possible to support DVI displays via an adapter cable, but in this case the digital audio is lost. Both
connectors are simultaneously active so that two displays can be supported without the need of additional
splitters or distribution amplifiers. Where analog audio is needed an analog audio connector is provided.
The IS-SPX-1000 is a high-definition ready device: it can render content on digital displays with resolution up
to 1280x720 at 60Hz (720p resolution). The maximum resolution supported by the IS-SPX-1000 is
1920x1080 for semi static images.
The IS-SPX-1000 connects to the network through a standard RJ-45 connector. Each device has a unique
MAC address that allows to identify the unit and thus the associated display.
The IS-SPX-1000 supports 10/100BASE-T Ethernet via a standard RJ-45 connector. Each unit has a unique
MAC address and supports all the required protocols to connect to network file systems and retrieve media
elements. These include:
Ethernet 10/100 Mbit/s,
IPv4, DHCP or fixed address
HTTP configuration server, password protected
HTTP client for web content retrieval
WebDAV server, password protected
SNMPv1/v2c,
NTP
The IS-SPX-1000 supports USB2.0 Hi-Speed with a bandwidth up to 10 Mbyte/second.
Programming
Information on creating content for the IS-SPX-1000 using the AMX InspiredSignage XPress software is
available in the AMX InspiredSignage XPress Programming Guide, available from www.amx.com.
Supported Video File Types
The following codecs, formats, and protocols are supported by the IS-SPX-1000:
The IS-SPX-1000 can play files as indicated above if they were created with supported codecs and are within
the video size specifications. If your IS-SPX-1000 is not successfully importing an SD video of the supported
file type, it was likely created with an unsupported codec or the file size is too large. If this is the case, try to
convert the video to a supported codec, using one of the many available tools for video conversion. The best
target format is the MPEG4 codec in the mov or avi file format.
Supported Video File Types
Supported video codecs Up to SD resolution: MPEG-4 ASP, MPEG-2, MPEG-1, H.264, MJPEG, Microsoft
VC-1 (Windows Media Video 9)
Supported audio codecs MPEG audio layer 1/2/3 (MP3), ITU G.711, G.722, G.729,PCM, Microsoft WMA,
Real Audio
Media container formats AVI, WMV/WMA, VOB, AIFF, OGG, WAV
Streaming media protocol MMS, RTSP, RTP, SDP, HTTP; Uni- & multicast

4IS-SPX-1000 Inspired Signage Xpress Player
Standard and Pro Licenses
The software for the IS-SPX-1000 comes in two packages, depending upon the number of software licenses to
be used. The Standard License (FG1231-20) includes one device and one single-node, multi-user license for
the accompanying software. The Pro License (FG1231-21) includes ten devices and one single-node, multi-
user license for the software.
Both the Standard and the Pro Licenses only apply to one computer installation of the
software at a time. If the software is installed on a second computer, a new license
must be purchased for that computer.

5
IS-SPX-1000 Inspired Signage Xpress Player
IS-SPX-1000 Installation
The installation of an IS-SPX-1000 starts by plugging in two cables: the power cable and the video cable
(HDMI and/or VGA) to the display. As soon as it is connected to the power line, the device will boot in a few
seconds and automatically select the resolution supported by the associated digital display. Content rendering
will begin in less than 1 minute. When connected to a local network through the RJ45 connector, the 
IS-SPX-1000 supports both DHCP for automatic configuration of the network and manual configuration by
specifying a static IP address and network properties. A hook and loop strip can be used to secure the IS-SPX-
1000 to any desired position on a wall or behind a display. The unit can be easily located near the display, as it
does not put off significant heat nor does it contain any moving mechanical parts.
Once installed, getting started with the IS-SPX-1000 is a matter of a few simple steps. The following sections
show how to connect one or more units to a network and how to publish content from the XPRESS software to
specific displays.
Powering up the IS-SPX-1000
To power up the IS-SPX-1000:
1. Check your digital display. The IS-SPX-1000 can drive a digital display through HDMI or VGA
connections. Make sure that your display supports at least one of the two.
2. Get the correct video cable for the display. Older displays may require a VGA cable.
3. Connect the IS-SPX-1000 to the display. Simply plug the HDMI or the VGA cable between the
corresponding video connector on the IS-SPX-1000 and the corresponding video input connector of your
display.
4. Power up the display. Make sure to select the right video input.
5. Power up the IS-SPX-1000. Use the cables and the power converter provided in the IS-SPX-1000
package. Plug the power converter on one side to a 110-220V outlet and on the other to the back panel DC
jack. Shortly after power up, the screen displays the AMX splash screen.
The first time the IS-SPX-1000 boots, the automatic configuration procedure takes about 2 minutes. The
process will be reduced to less than 50 seconds when you reboot the IS-SPX-1000 again. During this booting
process, the front panel LED shows green and red activity. At the end of the boot process, the screen will start
displaying the animated AMX logo. This is the default content. At this time, the green LED blinks regularly on
and off every second to indicate that the IS-SPX-1000 in operating normally. If your system does not behave as
described above make sure that the digital displays are functional and that the right input has been selected
(some displays have multiple inputs and you may need to manually select the right one). Also check that the
reset push button is not being pressed by some other system component. If the set-up appears correct, try to
power cycling the IS-SPX-1000 unit by unplugging and plugging the power.
In order to facilitate the best transmission of data, including EDID information,
standard pinouts for VGA cables should be used.
When installing the IS-SPX-1000, be careful to avoid any water or high humidity
exposure.

6IS-SPX-1000 Inspired Signage Xpress Player
Resetting the IS-SPX-1000 to Factory Default Settings
To reinitialize the IS-SPX-1000 unit to its factory default settings:
1. Unplug the unit from the power.
2. Push the reset button and keep it pressed.
3. Power up the IS-SPX-1000 unit.
4. Wait with the reset button pressed for at least 8 seconds.
5. Release the reset button.
6. The IS-SPX-1000 unit will now boot in the factory default mode.
Updating Firmware
To check if a new version of the firmware is available for your unit:
1. With your preferred web browser, connect to the HTTP server of your unit by entering the device’s IP
address into the browser.
2. Click on Firmware Update under the Administration menu on your left.
3. Check that the field Server URI is equal to: "http://webservices.amx.com/InspiredSignage/IS-SPX-1000/
updates/". (If this is not the case, click the Reset to Default button)
4. In the section Manual Update, select the update source "From server" and click the Check for Update
button.
A new page will open. At the end of the check, the page reports the current update status of your IS-SPX-1000
unit. Three cases are possible:
No updates are available.
Updates are ready to install. See the section 'Updating IS-SPX-1000 firmware' section to learn how
to proceed with the update.
The update failed.
The most probable source of this error is that your IS-SPX-1000 couldn't contact the update server. It is
recommended to check your internet connection and your network configuration. Make sure that a Gateway
and a DNS server are configured. If the IS-SPX-1000 is not connected to the internet, you need to contact
AMX Technical Support to check which update procedure is best suited to your configuration. Please specify
in your message if your IS-SPX-1000 unit(s) are in a location where you can easily plug an USB key or if they
have local network connectivity.
If the check for updates procedure reported that updates are available for your IS-SPX-1000, click the Update
Now button to start the update process.
The IS-SPX-1000 will restart automatically once the update process is over. It is possible that the web page
displays a time-out error during the update. However, this has no influence on the update process itself. At the
end of this process, refresh your web browser to display the new firmware version under the Current Versions
section. If you click the Check for Update button again, the page will report that no updates are available.
It is possible that the IS-SPX-1000 performed only a partial update of the firmware. In this case, the firmware
will need to be updated a second time.
The following procedure will delete all previously saved content and configurations on
the IS-SPX-1000 device.
Fatal Error: If the update process reports a fatal error, please contact AMX Technical
Support to find how to restore the firmware of your IS-SPX-1000.
Do not power down the device at any time during the update process.

7
IS-SPX-1000 Inspired Signage Xpress Player
Automatic update
If your IS-SPX-1000 is configured to use automatic update and has direct access to the Internet, it will update
its firmware automatically as soon as a firmware update is available. The update will take place at 3:00 AM
and will not modify the content played by the IS-SPX-1000. This update will also not affect the device’s
display and networks settings.
To enable the automatic update feature:
1. Check the Enable automatic updates check box.
2. Select the update time.
3. Press Apply to validate your changes.
Getting Connected
The IS-SPX-1000 has a special procedure for connection for the first time to a PC using the RJ-45 Ethernet
interface. This step is required to remote publish content on an IS-SPX-1000. This procedure requires an IS-
SPX-1000 device and one of the following configurations:
PC with RJ-45 10/100/1000 Ethernet interface and an Ethernet cable.
PC with RJ-45 10/100 Ethernet interface and an Ethernet crossover cable.
PC with RJ-45 10/100 Ethernet interface, a switch and 2 Ethernet cables.
To make a remote connection for the first time:
1. Connect the PC, through the switch if using one in the particular configuration, to the IS-SPX-1000
following one of the above schemes.
2. Power up the PC (and switch, if applicable).
3. Power up the IS-SPX-1000.
4. Make sure that the IS-SPX-1000 has completed the booting phase: allow about 1 minute from the start of
the powerup. If the device is connected to a display, you should see the default animated logo.
5. Check that the LED is blinking green once per second.
6. Open a web browser and enter the IP address of the device in the location bar at the top to open the Web-
Based Configuration Pages (for more information, please refer to the IS-SPX-1000 Web-Based
Configuration Pages section on page 13).
Accessing and Changing the IS-SPX-1000 IP Address
The IS-SPX-1000 automatically uses DHCP to assign an IP address to the device when first configured, but
this may be changed to a preassigned IP address. To access the IP address for the IS-SPX-1000:
1. In a Zero-Configuration-enabled application, such as NetLinx Studio or in a ZeroConfiguration-enabled
browser, look for the entry for the IS-SPX-1000 and its assigned serial number. (This serial number may
be found on the underside of the device.)
2. Click on the entry to open the device’s Web-Based Configuration Pages. (For more information, please
refer to the IS-SPX-1000 Web-Based Configuration Pages section on page 13.)
3. In the Status page of the Information section, the IP address is displayed below the serial number and
firmware version.
To change the IP address of the IS-SPX-1000:
1. From the Web-Based Configuration Pages, click the Network Settings listing in the Administration menu.
This procedure applies only if you have not modified the default network configuration
of the IS-SPX-1000. See the Resetting the IS-SPX-1000 to Factory Default
Settings section on page 6 to make sure that your IS-SPX-1000 is in the default
network configuration.
Note that the device does not need to be connected to a display. Allow about one
minute to the device to boot up, with the green light blinking once per second.

8IS-SPX-1000 Inspired Signage Xpress Player
2. In the Basic tab of the Network Settings page, click the Static radio button to switch the settings from
DHCP to Static.
3. In the fields below the Static radio button, enter the desired IP address in the Address field.
4. Add the subnet mask, gateway, and DNS information into the appropriate fields and press Apply.
If the IS-SPX-1000 is accidentally configured with an incorrect IP address, you need
to reset the unit to its factory default and restart the configuration procedure.

9
IS-SPX-1000 Inspired Signage Xpress Player
Installing the IS-SPX-MNT Mount Adapter
The optional IS-SPX-MNT Mount Adapter Kit (FG1231-17) is intended to allow attachment of the IS-SPX-
1000 to Vesa display wall mounts, thereby keeping it within easy reach for firmware uploads and other basic
maintenance.
To install the IS-SPX-MNT Mount Adapter:
1. Select the side of the IS-SPX-1000 to which the adapter is to be installed. The IS-SPX-MNT may be
installed to either side of the device.
2. Using the supplied pan-head screws, attach the IS-SPX-MNT to the side of the device.
3. Use the appropriate mounting holes to attach the assembly to the display wall mount.
Installing the NXA-AVB Breakout Box Mounting Bracket
The optional NXA-AVB Breakout Box Mounting Bracket Kit (FG1231-17) is intended to allow attachment of
the IS-SPX-1000 to solid surfaces such as desk tops, thereby keeping it within easy reach for firmware uploads
and other basic maintenance.
To install the NXA-AVB Breakout Box Mounting Bracket:
1. Select the side of the IS-SPX-1000 to which the adapter is to be installed. The mounting bracket may be
installed to either side of the device.
2. Using the supplied pan-head screws, attach the mounting bracket to the side of the device.
3. Use the mounting holes to attach the assembly to a fixed surface.
FIG. 2 Installation of the IS-SPX-MNT Mount Adapter (62-1231-03)
FIG. 3 Installation of the NXA-AVB Breakout Box Mounting Bracket (62-1231-03)
IS-SPX-1000
IS-SPX-MNT Mount Adapter
Pan head screws
Mounting holes
IS-SPX-1000
Mounting Bracket
Pan Head Screws
Mounting holes

10 IS-SPX-1000 Inspired Signage Xpress Player
Troubleshooting
If you are unable to connect to your IS-SPX-1000, check the following items:
1. Double check that you have correctly entered the correct IP address in your web browser.
2. Check the LED on your device. If the LED is blinking from orange to red once per second: the IP address
of your device has already been assigned on the network. Check your network configuration and make
sure that it is not taken by another device. If the LED is blinking fast (several times per second) from
green to red, the device is in recovery mode. In this case, unplug the device, power it up again, and wait
about 1 minute. If the IS-SPX-1000 remains in recovery mode, contact AMX Technical Support.
3. If the device has already been configured and does not have a default IP address, it may be returned to its
factory default. Note that all the content stored on the device will be deleted. For more information, refer
to the Resetting the IS-SPX-1000 to Factory Default Settings section on page 6.
4. Double-check the connectivity of cables, connectors, and switches in your setup.
5. Check the network configuration of your PC.
6. Verify that the web browser does not have a proxy configured.
Configuring A PC Network Connection
To configure the network connection of your PC via Windows XP Professional in order to connect to n IS-
SPX-1000 in its default configuration:
1. Open the Control Panel (Start>Control Panel) and then double click Network Connections (FIG. 4).
2. Select the local connection corresponding to the RJ-45 Ethernet connection used for the IS-SPX-1000.
Right-click on the icon and choose Properties (FIG. 5).
FIG. 4 Windows XP Professional Control Panel
FIG. 5 Local Area Connection Properties

11
IS-SPX-1000 Inspired Signage Xpress Player
3. Select Internet Protocol (TCP/IP) from the list and press the Properties button to open the Internet
Protocol (TCP/IP) Properties tab (FIG. 6).Configure the Protocol properties and click OK.
FIG. 6 Internet Protocol (TCP/IP Properties)

12 IS-SPX-1000 Inspired Signage Xpress Player

13
IS-SPX-1000 Inspired Signage Xpress Player
IS-SPX-1000 Web-Based
Configuration Pages
Overview
To access the IS-SPX-1000 Web-Based Configuration pages, enter the IP address of the IS-SPX-1000 into
your web browser. This advertisement may be viewed with any Zeroconf-enabled browser, such as NetLinx
Studio, or via the Bonjour plug-in for Internet Explorer and Safari.
Navigation Bar
The navigation bar (FIG. 7) appears on the left side of each IS-SPX-1000 Web-Based Configuration page.
Each page may be accessed from any other page. The Serial Number for the device always appears at the
bottom of the navigation bar.
Bonjour, Bonjour for Windows, the Bonjour logo, and the Bonjour symbol are
copyright 2010 Apple, and are used under license.
The "Software copyrights and licenses" text at the bottom of each page is an active
link to the Copyrights and Licenses page. This page contains all of the copyrights
reserved on the IS-SPX-1000, as well as all software licenses used by the device.
FIG. 7 IS-SPX-1000 Web-Based Configuration Page navigation bar
Navigation Bar
Information: This section contains the links for all of the Information pages. These pages are generally
read-only.
Administration: This section contains the links for all of the Administration pages. These pages generally
may be modified or edited.
Serial Number: This number is the IS-SPX-1000’s unique serial number.

14 IS-SPX-1000 Inspired Signage Xpress Player
Information
The Information pages contain all of the basic schematics of the IS-SPX-1000. This information cannot be
edited.
Status
The Status page lists the current basic information on the IS-SPX-1000, including the latest firmware version.
FIG. 8 Information - Status page
Information - Status Page
Serial Number: This number is the serial number of the device. The revision number lists the 
daughterboard and motherboard type used in the device.
Firmware: This number lists the current firmware version loaded on the device.
MAC: This number is the device’s MAC address number.
Device name: This number is the individual device name, used for multi-device applications. This 
number generally is the same as the Serial Number.
Multiscreen ID: This number is the ID number for the device when used for multiscreen applications. This
number generally is the same as the Serial Number.
