AMX Endeleo Multi-Format Receiver UDM-RX02 User manual

Installation Guide
UDM-RX02 Multi-Format Receiver
Overview
Installed at the display device, the UDM-RX02 converts the signal received from the
UDM-1604 or UDM-0102 Multi-Format Distribution Hub to standard audio/video signals. With
intelligent receiver technology, each UDM-RX02 is powered remotely from the Multi-Format
Distribution Hub via Cat 5/5e/6 cable.
The receiver supports an embedded control function to allow detection of a change in signal
from the hub and automatic switch of the Plasma or LCD screen to its new video format.
The UDM-RX02 also allows an optional local power supply to be added for long cable runs.
Common Application
Perfect for the receiving end of sources to be displayed in classrooms, conference rooms or
other presentation rooms.
Features
• Video Support for 1600 x 1200 (UXGA), 1920 x 1080 (HDTV), Component YPbPr,
S-Video, Composite PAL/NTSC
• S/PDIF, Digital and analog stereo audio support
• IR blaster and receiver ports
Compatibility
The UDM-RX02 is compatible for use with the following UDM Hubs:
• UDM-0102 (FG-UDM-0102) - supports Common Synch Mode.
• UDM-0404 (FG-UDM-0404) - supports Common Synch Mode.
• UDM-1604 (FG-UDM-1604C) - supports Common Synch Mode.
• UDM-1604 (FG-UDM-1604) - does not support Common Synch Mode. In this case,
the UDM-RX02 will function, but without Common Synch Mode.
Product Specifications
Configuration
The UDM-RX02 is configured via the UDM Hub’s WebConsole. Refer to the UDM Hub’s
Operation/Reference Guide for details.
Audio & Video Formats/Resolutions/Distance
Note: The maximum distances indicated above are not absolute, but are recommended
distances that have been tested to deliver video at the specified resolutions, without
significant signal degradation. In particular, lower resolutions (640 x 480, 720 x 480 and
800 x 600) can often be delivered significantly further than what is indicated in the table.
Refer to the UDM Hub’s Operation/Reference Guide for additional details on maximum cable
distances.
Wiring and Connections
All of the connectors and ports are located on the rear panel (FIG. 2):
UDM Hub Port (RJ45)
The UDM-RX02 connects to a UDM Hub through a Cat 5/Cat 6 connection. Refer to the
UDM Hub’s Operation/Reference Guide for details.
Serial Port (RJ12)
The SERIAL (RJ12) port allows administrators to control the various functions to the
UDM-RX02 from a command line prompt and terminal connection.
• Requires a DB9-to-RJ12 adapter cable (FG-RS01) to connect to a PC.
• Default settings = 9600, 8 bit, No Parity, 1 Stop Bit.
FIG. 1 UDM-RX02
UDM-RX02 Specifications
Power Requirements: 24VDC @ .75A
Note: In most cases the UDM-RX02 is remotely powered by
the UDM Multi-Format Distribution Hub (see Powering on the
UDM-RX02).
Rear Panel Connectors:
Power Socket: 2.1mm barrel-style DC power socket (female)
UDM Hub (RJ45) Port: Provides audio/video transport as well as control via Cat5,
Cat5e or Cat6 to an UDM Hub.
Serial (RJ12) port: Provides serial RS232 control of remote devices.
It also allows administrators to control the various functions to
the UDM-RX02 from a command line prompt and terminal
connection.
• See the Serial Port (RJ12) section for more details.
• Requires a DB9-to-RJ12 adapter cable (FG-RS01) to
connect to a PC.
IR Rx Port: 3.5mm stereo input port, for connection of an IR receiver to
allow setup of the UDM-RX02, local compensation
controls, and remote control of centrally located IR devices.
IR Tx Port: 3.5mm stereo IR Transmitter output port allows one IR-con-
trolled device (such as a DVD or VCR player) to be controlled
via optional wired IR emitter.
Audio Connectors: • Black RCA connector - Digital audio
• White / Red RCA connectors - Analog audio L/R
Video Connectors: • Yellow RCA female connector - CVBS (supports composite
video)
• S-Video - S-video female connector
• VGA - HD15 female connector (supports VGA video)
• Green RCA female connector - Component output: Y
• Blue RCA female connector - Component output: Pb
• Red RCA female connector - Component output: Pr
Operating Environment: • 35°F - 95°F (5°C - 35°C)
• Max. relative humidity - 85% (non-condensing)
• Heat Dissipation (Typical): 30.7 BTU/hr
Dimensions (HWD): 1" x 8 15/16” x 3 3/8” (25 mm x 227 mm x 85 mm)
Weight: 1.45 lb. (658 g)
UDM-RX02 Specifications (Cont.)
Certifications: • CE
• FCC part 15 Class A
Included Accessories: UDM-PS 24VDC, 30W Power Supply (57-0102-01)
Other AMX Equipment: • RS232 DB9/RJ12 Connection Cable (FG-RS01)
• UDM-RC02 Multi-Format IR Remote Control
(FG-UDM-RC02)
• UDM-RC05 Multi-Format IR Remote Control
(FG1402-70)
• IR01 IR Emitter Module (FG-IR01)
• IR03 External IR Receiver Module (FG-IR03)
Audio & Video Formats/Resolutions/Distance
Class Format Name Distance
Composite 720x480 NTSC 300 m / 1000’
720x576 PAL 300 m / 1000’
Component 720x480 480p 300 m / 1000’
720x576 576p 300 m / 1000’
1280x720 720p 300 m / 1000’
1920x1080 1080i 300 m / 1000’
1920x1080 1080p 300 m / 1000’
VGA 640x480 VGA 300 m / 1000’ *
800x600 SVGA 300 m / 1000’ *
1024x768 XGA 300 m / 1000’ *
1280x1024 SXGA 300 m / 1000’ *
1600x1200 UXGA 300 m / 1000’ *
* When using VGA modes with audio enabled, the maximum cable
distance is approximately 200 m / 650’.
FIG. 2 UDM-RX02 - rear panel components
Serial port (RJ12)
IR Rx port
SPDIF female Digital Audio port
RCA audio
(left/right)
CVBS port
S-Video port
Power connector
UDM HUB port (RJ45) - from an
IR Tx port
VGA (HD15) port
Component (Y) port
Component (Pb) port
Component (Pr) port
“OUTPUT” port on the UDM Hub
