AN-826
APPLICATION NOTE
One Technology Way •P. O . Box 9106 •Norwood, MA 02062-9106, U.S.A. •Tel: [phone] •Fax: [phone] •www.analog.com
A 2.4 GHz WiMAX Direct Conversion Transmitter
by Cecile Masse and Qui Luu
Rev. B | Page 1 of 16
FEATURES
Direct conversion transmit chain
Tx radio using 5 chips
Dual AD9862 MxFE, 14-bit DAC, 128 MSPS, with
programmable full-scale current
3 GHz quadrature modulator ADL5373
2.7 GHz VGA ADL5330 with 50 dB of power control range
4 GHz fractional-N synthesizer ADF4153
3 GHz RMS power detector AD8362
Supports 10 MHz channel bandwidth with 1024-subcarriers
OFDM
Supports QPSK, 16 QAM, and 64 QAM OFDMA
Transmitter output power: 13 dBm maximum, CW
EVM 64 QAM OFDM: 1.2% @ −3 dBm output
Transmitter noise at 20 MHz offset: −142.5 dBm/Hz @ −1 dBm
Precise output rms power control
Dual-supply operation: 5 V @ 380 mA, 3.3 V @ 165 mA
APPLICATIONS
WiBro/WiMAX 5 V CPE and base stations
DAC
DAC
ADC
ADC
AD8362
0°90°
FRACTIONAL-N
SYNTHESIZER
ADF4153
A
D9860/AD9862
MxFE
RMS POWER
DETECTOR
RF VGA
ADL5330
IQ MODULATOR
ADL5373
05790-001
Figure 1. Direct Conversion Transmitter

AN-826
Rev. B | Page 2 of 16
TABLE OF CONTENTS
Features .............................................................................................. 1
Applications....................................................................................... 1
Introduction ...................................................................................... 3
Architecture................................................................................... 3
Analog Baseband Signal Generation ......................................... 4
IQ Modulator ................................................................................ 5
The LO Synthesizer ...................................................................... 8
The VGA and the Interface to the IQ Modulator .....................9
RMS Power Detection ............................................................... 10
Overall System Performance .................................................... 12
Typical Performance Characteristics ........................................... 13
Summary of Measured Performance ........................................... 15
Bill of Materials for Major Components ..................................... 16

AN-826
Rev. B | Page 3 of 16
INTRODUCTION
The purpose of this application note is to demonstrate the
Analog Devices, Inc. WiMAX 5 V transmit signal chain for
applications extending up to 2.7 GHz.
As the wireless communication industry moves toward higher
RF frequencies, and higher data rates through wider modula-
tion bandwidths, high performance linear transmit chains are
required. WiMAX wireless broadband networks reflect such a
trend. Deployment has started in the 2.5 GHz and 3.5 GHz bands
for point-to-point and point-to-multipoint fixed applications.
Data rates of up to 80 Mbps are achieved using wideband
orthogonal frequency division multiplexing (OFDM) modu-
lations.
802.16 WiMAX fixed or mobile standards are based on
2N-carrier OFDM modulation: 256 for 802.16d and 512 to
2048 for 802.16e. Each of the 2Nsubcarriers can be modulated
with either a QPSK, a 16 QAM, or a 64 QAM data sequence.
The standards also support different signal bandwidths, from
1.25 MHz to 20 MHz to accommodate variable rates, although
the current profiles define channel bandwidths from 5 MHz to
10 MHz. The OFDM composite signal envelope amplitude can
exhibit significant peaks and valleys, with a modulation depth
close to 100% and peak-to-average ratio of about 10 dB. This
imposes severe linearity requirements on the transmit chain.
To address these challenges, direct conversion architecture has
been chosen. For this particular analysis, a full Tx signal chain,
starting from the baseband signal generation, up to the voltage
controlled amplifier and power detector functions (but excluding
the power amplifier) was evaluated. The primary focus is the
wireless broadband (WiBro) frequency band, 2.3 GHz to
2.4 GHz, used in Korea for the deployment of the 802.16d
(fixed) and 802.16e (mobile) standards. However, this signal
chain may also be used up to 2.7 GHz (see the AD9862,
ADL5373, ADL5330, ADF4153, and AD8362 data sheets
for performance details).
ARCHITECTURE
The radio architecture is a direct upconversion, having the
following benefits: low number of parts, less mixing product
spurs, fewer filters, and lower current consumption.
In addition, the architecture requires only a single upconversion
operation, and thus one synthesizer. The large number of sub-
carriers within the WiMAX OFDM or orthogonal frequency
division multiple access (OFDMA) signal actually makes this
modulation quite sensitive to phase noise, as each of the N
subcarriers is modulated by the phase noise of the local
oscillator (LO). For this reason, it is important to minimize
the amount of phase error added onto the modulation.
DAC
DAC
ADC
ADC
AD8362
0°90°
FRACTIONAL-N
SYNTHESIZER
ADF4153
A
D9860/AD9862
MxFE
RMS POWER
DETECTOR
RF VGA
ADL5330
IQ MODULATOR
ADL5373
05790-002
Figure 2. Direct Conversion Tx Chain
This architecture includes a transmit DAC, a fixed gain IQ
modulator, an LO fractional-N synthesizer, an RF VGA, and an
rms power detector. Off-chip, low-pass filters are also required
at the DAC outputs to filter the images that lie at multiples of
the sampling frequency. The DAC and the synthesizer need a
3.3 V supply, but all other parts run off a 5 V single supply.
The specific parts used for the Tx signal chain are as follows:
•AD9860/AD9862, 12-bit/14-bit, 128 MSPS sampling DAC,
SNR ≥ 70 dB
•ADL5373, 3 GHz IQ modulator
•ADF4153, 4 GHz LO fractional-N synthesizer
•ADL5330, 2.7 GHz voltage controlled amplifier/
attenuator VGA
•AD8362, 2.7 GHz rms power detector
Given the nature of the OFDM signal and the stringent error
vector magnitude (EVM) requirements imposed by the very
high data rates, these parts have been selected for their linearity
and noise performance of up to 2.7 GHz.
The following sections address each of the major functions
within this Tx signal chain, with a focus on the system design
rationales, implementation, and interfaces.

AN-826
Rev. B | Page 4 of 16
ANALOG BASEBAND SIGNAL GENERATION
The Tx DAC is one of the most critical components in this
signal chain because it needs to provide the closest to ideal
analog signal to be upconverted and amplified. The DAC
signal-to-noise ratio (SNR) and sampling rate define the
spectral purity and signal quality of the modulated signal
driving the IQ modulator.
SNR and SFDR
The chosen Tx DACs for this application are part of the
AD9860/AD9862 mixed signal front-end family (MxFE®) and
are 12 bits and 14 bits, respectively. They have a maximum
sampling rate of 128 MHz. The output of the Tx DACs is a
current source, with a programmable peak current between
2 mA and 20 mA. Programming the full-scale current through
register writes provides the flexibility of adjusting the peak-to-
peak input voltage to the IQ modulator while maintaining the
12-bit/14-bit resolution.
Recommended SNR for this application should be at least
60 dB to be able to meet the spectral mask at maximum power
levels and EVM at the lowest power levels (for instance, an SNR
of 31.4 dB plus margin is required for a 64 QAM three-quarter
OFDM even at the minimum output power at the antenna). Both
the 12-bit AD9860 and the 14-bit AD9862 provide better than
70 dB SNR. In some BTS applications, higher SNR is required
to meet stringent spectral masks. It is then recommended to use
a 16-bit DAC like the AD9779.
In addition, the spurious-free dynamic range (SFDR) within
the first Nyquist zone stays constant at −76 dBc whether the
signal frequency is at 1 MHz or 6 MHz. This is important, for
instance, when dealing with large signal bandwidths like an
OFDM 10 MHz WiMAX signal centered at dc.
Sampling Frequency
Depending on the maximum modulation bandwidth, the sampling
frequency can be appropriately chosen. For example, a WiBro
complex OFDM signal with an 8.75 MHz bandwidth would require
a DAC sampling rate , fSAMPLING, of at least 2 × 10 MHz or twice the
Nyquist minimum (OFDM modulation sampling frequency = n×
bandwidth = 8/7 × 8.75e6 = 10 MHz). But all sampling alias would
be at n × 20 MHz, which would fall in band for RF frequency band-
widths higher than 20 MHz. These images can only be filtered by
the off-chip reconstruction filter at the DAC output.
Good filtering of the DAC images at multiples of the sampling
frequency then requires higher order filters. This can be
avoided using the interpolation filters, available within the
DAC. While the input data rate to the DAC remains the same,
the interpolation filters increase the sampling frequency of the
DACs. As a result, the images appear further away from the
main input signal. Figure 3 and Figure 4 show the effect of
enabling the 4× interpolation filters on the AD9860/AD9862.
–120
–100
–80
–60
–40
–20
0
MAGNITUDE (dB
m
)
0 20 40 60 80 100 120 140
FREQUENCY (MHz)
05790-003
Figure 3. AD9860/AD9862 Tx DAC Generating an OFDM Signal with
1× Interpolation (fSAMPLE = 32 MSPS, 1× Interpolation)
–120
–100
–80
–60
–40
–20
0
MAGNITUDE (dB
m
)
0 20 40 60 80 100 120 140
FREQUENCY (MHz)
05790-004
Figure 4. AD9860/AD9862 TxDAC Generating an OFDM Signal with
4× Interpolation (fSAMPLE = 32 MSPS, 4× Interpolation)
Therefore, while the Tx digital data are updated at a rate of
20 MHz only, the 4× interpolation filter effectively increases the
overall sampling rate to 80 MHz. This allows a simple third-
order Bessel LPF at the DAC output (see the IQ Modulator
section).

AN-826
Rev. B | Page 5 of 16
IQ MODULATOR
Modulator AC Drive Level
The I and Q inputs of the modulator should be driven
differentially. For a modulation like WiMAX OFDM with
peak-to-average ratios of 10 dB and higher, the peak drive
level should be such that there is at least a 10 dB backoff from
compression to minimize the distortions. The optimum level is
actually determined by minimizing the spectral distortion at the
modulator output while maintaining sufficient SNR.
DAC1
R1
R2
R
L
DAC2
I INPUT
Q INPUT
ADL5373
05790-005
AD9862
Figure 5. DAC to IQ Modulator Interface
The interface between the AD9862 DAC and the ADL5373
modulator is shown in Figure 5.
Resistors R1 and R2 set the dc bias level while Resistor RLsets
the level of the baseband I and Q voltages to the modulator.
The modulator differential input voltage can be calculated from
Equation 1 and is both a function of the Resistor RLand the DAC
full-scale current, IDAC.
R2R1R
RgIf
RR
RRI
V
DC
L
DAC
L
DC
L
DCDAC
diff
==
==
+×
×××
=)()(
2
2
(1)
The ADL5373 has a fixed voltage gain. The output level of the
modulator can be set by choosing the appropriate input load
resistor. As an alternative, a larger resistor can be chosen and
the full-scale output current of the DAC can be scaled to the
desired drive level.
Optimum drive level to the ADL5373 IQ modulator for an
OFDM modulation like WiMAX is 0.650 V p-p ± 10% (see the
Finding the IQ Modulator Optimum Operating Point section
for more details). At this level, the rms power level out of the
modulator is about −12 dBm, providing an optimum trade-off
between output power level and spectral quality.
This input voltage can be obtained by using a 50 Ω RLresistor
while driving the modulator with 20 mA of full-scale current.
However, it is common to operate at a given back-off from
full scale. As an example, this optimum ac level can also be set
by choosing RLfor a high enough peak voltage (200 Ω for
1.3 V p-p, for instance) and by adjusting the DAC output
current to about 10 mA (or −6 dBFS). A dc offset then needs
to be applied at the connecting point of R1 and R2 to maintain
the 500 mV of dc bias level. Note that with this lower full-scale
current, the ac dynamic performance of the DAC degrades by
about 2 dB.
DC Bias Level
Resistors R1 and R2 set the dc bias level. The recommended
level of common-mode voltage is 500 mV.
A value of 50 Ω generates the required 500 mV dc bias for
20 mA of DAC full-scale current, independently of the RLvalue.
Baseband Filtering
With the signal being sampled at 80 MHz (20 MHz + 4×
interpolation), the requirement for image rejection can be
defined. The sample-and-hold action of the DAC is equivalent
to a convolution of the sampled waveform by a sin(x) function
in the frequency domain.
⎟
⎟
⎠
⎞
⎜
⎜
⎝
⎛
π
π
×= fT
fT
fVfV sampled
out
)sin(
)()( (2)
Figure 3 is a good example of this sampling image shaping
effect. As a result, the highest image is usually at 1 × fS, or
80 MHz here.
The level of these sampling images can be calculated using the
sin(x)/x function.
Calculated levels are −31.6 dBc and −37.6 dBc at 1 × fSand
2 × fSrespectively, at a sampling frequency of 80 MHz. The
measured levels of these images were actually not very different
from these calculated values: −33 dBc and −40 dBc for the first
and second images.
The reconstruction filter at the DAC modulator interface is
there to provide the modulator with a clean baseband signal,
free from images that fall inside the RF bandwidth by
up-conversion. Low-pass Bessel structures are ideal for their
flat in-band group delay (see Figure 8). A third-order filter with
a 3 dB cutoff frequency at 8 MHz provides 50 dB of rejection at
80 MHz, bringing the sampling images down to 80 dBc.
The details of the baseband filter are shown in Figure 6 to
Figure 8.
R3
R = 50Ω
R4
R = 50Ω
R5
R = 200Ω
L6
L = 820nH
L7
L = 820nH
PORT
P1
PORT
P2
C8
C = 47pF
C9
C = 330pF
PORT
P3
PORT
P4
05790-006
Figure 6. Baseband Filter Schematic Including Source Resistor
and Termination Resistor

AN-826
Rev. B | Page 6 of 16
–50
–40
–30
–20
–10
–60
0
dB (H(f))
10k 100k 1M 10M 100M
FREQUENCY (Hz)
05790-007
Figure 7. Baseband Filter Gain Response in Decibels
10
20
30
40
0
DELAY (H(f)) (ns)
10k 100k 1M 10M 100M
FREQUENCY (Hz)
05790-008
Figure 8. Baseband Filter Group Delay Response in Seconds
It is important to consider passive components with the lowest
tolerance for this filter, to minimize mismatches between I and
Q signal paths.
LO Feedthrough and Sideband Nulling
LO leakage at the output of the modulator comes from different
sources:
•DC offsets between I and Q
•DC offsets causing imbalance between the differential
signals I and Ior Q and Q
•Imperfect LO-to-RF isolation
Usually the most important sources of LO leakage are the
unwanted cumulated dc offsets on the baseband signals,
between the signal generation and the modulator mixers input.
On the other hand, amplitude and phase mismatches between
the I and Q signals and an inaccurate 90°LO phase shifter
result in an unwanted upper sideband image. When the Tx
DACs are configured for complex outputs, good image rejection
at the modulator output is critical because this spur falls inside
the channel and cannot be filtered. Phase mismatches cannot be
compensated for in this design, but amplitude matching may be
achieved through independent gain correction at the DAC level.
Similarly, the AD9862 DACs allow dc offset correction voltages
to achieve LO leakage suppression.
I and Q amplitude mismatch correction is achieved by current
scaling. There is both a fine and coarse gain control (Register 14
and Register 15) to adjust the full-scale output current of either Tx
channel independently. The coarse gain control can be bypassed
where no current scaling is done or it can be scaled by 1/2 or 1/11
of the full-scale current. This translates to a −6 dB or −20 dB
change in the current. For finer resolution, the fine gain control
scales the full-scale currents individually on each leg by ±4%.
For LO suppression, a positive or negative offset can be applied
on either the I channel or the Q channel. With a 10-bit accuracy
(Register 10 to Register 13), an offset current of up to ±12% or
±2.4 mA for 20 mA full scale can be applied to either differential
channel. This is far more than what is usually required for LO
nulling.
The gain and offset mismatches are corrected after the analog
conversion, therefore maintaining the signal resolution. LO
leakage can be suppressed down to 75 dBc at the modulator
output and unwanted sideband can be reduced to −60 dBc at
room temperature.
Although the WiMAX OFDM signal has no subcarrier at dc, it
is important to achieve good dc offset correction to help the
demodulator distinguish between the on and off times of the
WiMAX burst and to make sure it does not saturate the receiver
ADC at low transmitted power.
Figure 9 shows the single sideband spectral characteristic at
the IQ modulator output once dc offset and gain calibration
have been applied. The unwanted sideband is at −60 dBc and
LO leakage at −70 dBc.
10
0
–10
–20
–30
–40
–50
–60
–70
–80
–90
CENTER 2.4GHz SPAN 6.5MHz650kHz/
REF 10dBm ATT 15dBm
RBW 50kHz
VBW 200kHz
SWT 5ms
MARKER 1 [T1]
–1.59dBm
2.399000000GHz
10 OFFSET 3.5dB
MARKER 3 [T1]
–69.84dBm
2.400000000GHz
1
2
3
05790-009
DELTA 2 [T1]
–59.81dB
2.000000000MHz
*
*
1 SA
AVG
A
Figure 9. Single Sideband Spectrum at 2.4 GHz,
After DC/Gain Calibration (DAC+IQ Modulator Output)

AN-826
Rev. B | Page 7 of 16
Finding the IQ Modulator Optimum Operating Point
Optimum output level for the modulator can be determined by
measuring the upconverted signal distortion in the frequency
domain. Input voltage at the modulator input is swept such that
the output power level varies from −6 dBm to −20 dBm.
The spectral masks are currently being defined but are typically
imposed by local regulations for out-of-band emissions. As of
today, the Korean WiBro standard provides a specific spectral
mask that applies in the 2.3 GHz to 2.4 GHz band, as shown in
Figure 10. Other masks have been defined for fixed and mobile
radio systems like in the U.S. for deployments in the 2.5 GHz to
2.69 GHz (FCC 04-258).
As an example, Figure 10 shows the characteristics of the WiBro
BTS mask, the modulated signal bandwidth being 8.75 MHz.
f 1
f 2
05790-010
P1
P2
d
Br
FREQUENCY
OFFSET
Figure 10. BTS WiBro Spectral Mask (RBW = 100 kHz)
The WiBro standard specifies different ACPR requirements
depending on the transmitted power at the antenna. Here the
requirements are derived for a power level at the antenna of
+33 dBm:
•P1 ≤−34.5 dBr at f1 = 4.77 MHz (edge of the main
channel)
•P2 ≤−52.4 dBr at f2 = 9.23 MHz (center of the adjacent
channel)
Figure 11 shows the modulator spectral performance with a
16 QAM, 256-OFDM signal according to this mask, with the
offsets scaled for a 10 MHz OFDM signal. An input drive level
has been varied such that the IQ modulator output power
ranges from −20 dBm to −6 dBm. An optimum operating point
is obtained at about −12 dBm output rms, where the mask is
met with more than 20 dB margin.
Figure 12 displays a more generic ACPR characteristic, again for
a 10 MHz OFDM signal, where adjacent and alternate powers
are compared to the main channel power level. All channel
power levels are integrated in a 9 MHz bandwidth and ACP1
and ACP2 are respectively calculated at 10 MHz and 20 MHz
offsets from the carrier.
At the first frequency offset (ACP1), as the power level drops,
more backoff from the compression and third-order intercept
point helps reduce the signal distortion and improve ACPR
performance. As the output power drops further, degradation
of SNR (due to less signal energy compared to modulator noise
floor) is the reason for the dB-per-dB ACPR degradation. At the
second frequency offset given by ACP2, there is no spectral
regrowth and ACPR basically degrades with decreasing SNR.
–
50
–55
–60
–65
–70
–75
–80
WiBro MASK (dBm)
–22 –20 –18 –16 –14 –12 –10 –8 –6 –4
IQ MODULATOR OUTPUT POWER (dBm)
05790-011
CHANNEL EDGE @ 5.45MHz
ADJ CHANNEL @ 10.5MHz
Figure 11. Modulator Performance According to WiBro Mask, with 16 QAM
OFDM Modulation, Function of I and Q Input Voltage (or IQ Modulator
Output Power), at 2400 MHz
–
50
–55
–60
–65
–70
–75
–80
ACPR 16 QAM OFDM (dB)
–22 –20 –18 –16 –14 –12 –10 –8 –6 –4
IQ MODULATOR OUTPUT POWER (dBm)
05790-012
ACP1
ACP2
Figure 12. Modulator Output ACPR with 16 QAM OFDM Modulation,
Function of I and Q Input Voltage (or IQ Modulator Output Power), at
2400 MHz
The EVM performance with a WiMAX OFDM waveform,
for the IQ modulator itself, is also quite good at 0.6% rms. Most
of it is due to finite upper sideband cancellation as well as
second- and third-order intermodulation for each subcarrier
that falls within the main channel.

AN-826
Rev. B | Page 8 of 16
THE LO SYNTHESIZER
One local oscillator (LO) is required for this direct conversion
architecture. The up-conversion from dc to the wanted RF
frequency is directly achieved by the IQ modulator. Perform-
ances like phase noise, frequency resolution, and settling time
dictate the choice of a fractional-N synthesizer for the LO
generation.
Phase Noise
With the upconversion, phase noise is superimposed on each of
the N subcarriers of the WiMAX OFDM signal when mixed to
the local oscillator.
LO phase noise has two effects:
•Random phase rotation for all subcarriers
•Intercarrier interference resulting from the corruption of
a given subcarrier by its N-1 noisy adjacent subcarriers.
To help correct for these phase errors that contribute greatly
to the degradation of EVM, the OFDM symbol contains eight
subcarriers that are modulated with a known training sequence
of data. These training subcarriers are called pilot tones and
help the receiver track and remove most of the close-in phase
noise generated by the LO. However, this only allows the removal
of phase changes that are slower than a symbol period, while
phase changes that are faster than a symbol period are not
tracked and, therefore, affect EVM.
For a 64 QAM modulated OFDM, EVM requirements at the
transmitter output are very stringent at 3.1% rms. This is why the
PLL loop bandwidth, as well as the total integrated phase error,
is critical for the design of this PLL. A total phase error lower
than 1°rms has been used as a criteria for choosing a synthesizer.
With integer-N synthesizers, the N divider can be quite high
to synthesize >2.3 GHz RF frequencies while allowing for fine
resolution. Within the PLL loop bandwidth, both the reference
and phase frequency detector (PFD) noise levels are increased
by 20 × log(N). It directly degrades the PLL total phase error,
which can often be higher than 1°rms.
Fractional-N synthesizers are preferred for their inherent good
phase noise. Very small frequency resolution can be achieved
while using a higher comparison frequency, therefore helping
to reduce the total phase noise. The typical phase noise errors
for these fractional-N synthesizers can be <0.5°rms; which is
appropriate for this application.
The ADF4153 is a 4 GHz fractional-N synthesizer with three
modes available: low noise mode, low noise/low spur mode,
and low spur mode. The low noise mode is recommended for
narrow-loop filter bandwidths because the loop filter response
already attenuates the spurs. This is the case for WiMAX duplex
modes that do not require fast locking loops.
For fast loops, spurs are less attenuated because they fall inside
the loop bandwidth. In low spur mode, dither is enabled. This
randomizes the fractional quantization noise so it looks like
white noise, not spurious noise.
Synthesizer Frequency Resolution
The minimum required frequency resolution for the IQ
modulator LO is derived from the required channel raster
imposed by the 802.16 standard. As of today, the channel raster
requirement should be 250 kHz in most cases, and 200 kHz for
some specific profiles. This means that the carrier frequency
generated by the PLL should be at least a multiple of 250 kHz.
Reference Frequency
The following equations govern how a fractional-N synthesizer
is programmed:
RFout = [INT + K/MOD] × [fREF] (3)
RES
REF
f
f
MOD =(4)
where:
RFout is the PLL synthesized frequency.
fREF is the reference frequency, also equal to the PFD
comparison frequency in this case.
INT is the integer division factor.
Ksets the value of the synthesized frequency fractionality.
MOD is the modulus.
fRES is the PLL frequency resolution.
In fractional-N synthesizers, spurs appear at intervals of the chan-
nel spacing (fractional spurs) and possibly also at fractions of
the channel spacing (subfractional spurs). Table 1 shows how
the value of the modulus affects the location of subfractional spurs.
Table 1.
Conditions Spur Interval
If MOD is divisible by 2, not by 3 Channel step/2
If MOD is divisible by 3, not by 2 Channel step/3
If MOD is divisible by 6 Channel step/6
Otherwise Channel step
From Equation 4, the modulus value (MOD) depends on the
PFD frequency and channel spacing. The channel spacing is
fixed, so if possible the PFD should be chosen such that the
modulus value does not produce subfractional spurs.
In addition, the reference frequency should be chosen high
enough to reduce the integer INT division ratio (see Equation 3).
A reference frequency greater than 10 MHz contributes to the
improvement of the PLL phase noise beyond that achievable
with an integer-N synthesizer.

AN-826
Rev. B | Page 9 of 16
Lock Time Figure 14 shows the closed-loop phase noise performance of
this PLL.
PLL lock time can be critical in the following scenarios:
The VCO is a Sirenza VCO190-2350T(Y), with a tuning sensi-
tivity of 35 MHz/V typical. PLL closed-loop in-band phase
noise is −95 dBc/Hz.
•In HFDD systems where both frequency duplex and time
duplex are used.
•During frequency hopping used to achieve better signal
quality, to increase data security, to avoid multipath fading,
or to avoid interference.
The equivalent rms phase error for this design is only 0.35°rms,
equivalent to an EVM contribution of 0.6%. The contribution of
this fractional-N PLL to the overall EVM performance is given
in the Overall System Performance section.
PLL lock time can be optimized by increasing the reference or
comparison frequency, and, if necessary, by increasing the loop
bandwidth.
–140
–130
–120
–110
–100
–90
–
80
PHASE NOISE (dBc/Hz)
1M100k10k1k100
PHASE NOISE AT 2.35GHz
FREQUENCY (Hz)
05790-014
With the ADF4153, a reference frequency or PFD frequency up
to 32 MHz can be chosen, or the available frequency doubler
can be used to increase the PFD frequency while using a lower
frequency reference clock.
The definition of the PLL loop bandwidth is a trade-off between
the required settling time, the acceptable phase error, and the
spurs level. The larger the loop bandwidth is the faster the lock
time, at the expense of higher phase error and spurs level. But if
the lock time is not critical, using a narrow-loop bandwidth is
recommended for the reasons described in the Phase Noise
section.
Performance Figure 14. Closed-Loop Phase Noise Simulation at 2.35 GHz
In this particular characterization, the PLL has been designed
for a closed-loop bandwidth of about 20 kHz. For a 10 MHz
256 OFDM signal, the symbol duration is 25.6 μs, which
corresponds to a subcarrier spacing of 39 kHz. Therefore, the
PLL loop has voluntarily been designed slower than the symbol
duration such that most of its phase noise can be tracked and
removed by the pilot-tracking algorithm. Figure 13 shows the
PLL schematic, including the loop filter.
THE VGA AND THE INTERFACE TO THE IQ
MODULATOR
Because WiMAX systems can be used for nonline-of-sight
applications, gain control of the transmitter is necessary to
adjust the output Tx level depending on the channel quality.
The ADL5330 is a high performance VGA, 50 Ω I/O, which
provides close to 50 dB of gain control at 2.3 GHz, with a gain
control slope of about 60 dB/V. A positive control voltage from
0.5 V to 1.4 V is required to control the gain of the VGA. At
VGAIN = 1.4 V, a maximum gain close to 15 dB is achieved. The
basic connections for interfacing the ADL5373 IQ modulator
with the ADL5330 are shown in Figure 15.
6
5
8
13
12
11
10
715 16
AV
DD
DV
DD
V
P
CPGND AGND DGND
RF
IN
A
RF
IN
B
REF
IN
LE
DATA
CLK
SDV
DD
2
1
14
MUXOUT
R
SET
CP
F
OUT
V+
GND
V SUPPLY
REFERENCE
TCXO10
C1
4.70nF
R1
750Ω
C2
56.0nF
C3
2.20nF
R2
1.50kΩ
LOCK DETECT
OUT
VCO
35.0MHz/V
349
NOTES
1. AV
DD
ANALOG POWER SUPPLY.
2. DV
DD
DIGITAL POWER SUPPLY.
3. V
P
CHARGE PUMP POWER SUPPLY.
4. AV
DD
= DV
DD
, VP ≥DV
DD
,AV
DD
.
5. CONSULT MANUFACTURER’S DATA
SHEET FOR FULL DETAILS.
ADF4153
05790-013
R
SET
5.10kΩ
Figure 13. PLL Loop Schematic

AN-826
Rev. B | Page 10 of 16
IBBP
DAC
IBBN
QBBP
DAC
QBBN
VOUT
ADL5373
IQ MOD
100pF
100pF
ETC1-1-13
LO OUTPUT
VPS COM
INLO
INHI
ADL5330
RF VGA
VPS COM
100pF
100pF
OPHI
OPLO
+5V +5V
100pF
100pF
ETC1-1-13
RF OUTPUT
120nH 120nH
+5
V
DIFFERENTIAL I/Q
BASEBAND INPUTS
05790-015
GAIN CONTROL
LOIP LOIN
Figure 15. IQ Modulator and RF VGA Interfaces
The ADL5373 is designed to drive a 50 Ω load and easily
interfaces with the VGA.
If less power is required from the VGA, adding a pad in
between the modulator and the VGA is recommended.
This helps maintain optimum linearity performance while
improving the output noise floor.
For operation in the 2 GHz to 3 GHz bandwidth, using
differential-to-single-ended baluns specifically matched in
this bandwidth is also recommended. The ADL5330 provides
differential input and output. For a single-ended interface, using
a balun like the Murata SP-LDZ-49_LDB182G5005G helps to
improve the RF gain by at least 1 dB.
RMS POWER DETECTION
For accurate and fast power control, the AD8362 rms power
detector can be used at the output of the power amplifier. This
is a high accuracy, wideband rms-to-dc square law detector.
The output of this square law function is a positive current that
is integrated by both an on-chip capacitance and an external
capacitance, CLPF. The resulting voltage is then buffered by a
dc-coupled amplifier, which provides output that can be used
for measurement and control purposes.
Figure 16 shows an rms power measurement technique through
a directional coupler. For practical reasons, it has been placed at
the VGA output, but can also be used to detect power levels at
the power amplifier (PA) output.
ADL5330
VOUT
VSET
CLPF
INHI
INLO
VTGT
AD8362
V
OUT
47nF
VREF
1nF
1nF
100Ω
OPHI
OPLO
120nH 120nH
100pF
100pF
10dB
+5V
P
OUT
= –1dBm MAX
T2
ETC1-1-13
0
5790-016
Figure 16. Power Detection Using the AD8362
The AD8362 takes either a differential input (for best detection
range) or a single-ended input. Because the coupled port
of a coupler is unbalanced, the AD8362 has been characterized
with a single-ended drive, for all the potential modulations in
the 802.16 standard.
An externsal filtering shunt capacitor is required at the output
of the square law detector to remove the residual of the signal
envelope. For WiMAX signals, a capacitor of 0.1 μF provides a
good trade-off between the detection accuracy and settling
time. But a smaller capacitor along with a fast sampling ADC
can be used for a faster response.
Table 2.
CLPF Accuracy Within 40 dB Settling Time
0.1 μF +0.3 dB/−0.5 dB 160 μs
47 nF +0.3 dB/−0.75 dB 78 μs
The expected measured performance of the power detector is
shown in Figure 29 and Figure 30.

AN-826
Rev. B | Page 11 of 16
Figure 17 shows the power detection error with CLPF = 1 μF
and VTG = 0.625 V.
3
2
1
0
–1
–2
–3
ERROR (dB)
–60 –55 –50 –45 –40 –35 –30 –25 –20 –15 –10 –5 0 5 10
INPUT POWER (dBm)
05790-017
CW
QPSK 1/2
16QAM 3/4
64QAM 2/3
BPSK
QPSK 3/4
16QAM 1/2
64QAM 3/4
Figure 17. RMS Power Detector Detection Range and
Accuracy for CLPF = 1 μF
With VTG = 0.625 V (connecting VREF to VTG through a
resistive divider) and a smaller CFLT capacitor, similar perform-
ances can be achieved with a fast averaging ADC. In such
configuration, the RMS detector is completely insensitive to
the type of OFDM modulation applied to it. Therefore, no
calibration is required, whether a QPSK or a 64 QAM modulates
the OFDM subcarriers. Figure 18 shows the power detector
settling time for CLPF = 47 nF.
05790-018
CH1 500mV M1.00ms A CH1 1.33V
CH1 RISE
77.93µs
1
T2.97200ms
Figure 18. Power Detector Time Response to a WiMAX Downlink Burst
(TSYMB = 25.6 μs), CLPF = 47 nF
Temperature Compensation
To improve the measurement accuracy of the AD8362 over
temperature at 2.35 GHz, a simple temperature compensation
scheme can be used. It helps correct for the drift of the detector
intercept point of the VDET = f(Pin) characteristic. The whole
transfer function tends to drop with increasing temperature,
while the slope remains quite stable. Therefore, compensating the
drift at a particular input level (for example, −15 dBm) holds up
well over the dynamic range (see Figure 20).
The compensation is simple and relies on the TMP36 precision
temperature sensor. At 25°C, the TMP36 has an output voltage
of 750 mV and a temperature coefficient of 10 mV/°C. The
positive temperature coefficient of the TMP36 can directly
compensate for the negative temperature coefficient of the
detector. The implemented circuit is given in Figure 19. (Note
that the VOUT pin of AD8362 is depicted as VDET_OUT to
avoid confusion within this figure.) The resistor ratio of R1
and R2 can be calculated so that the corrected VOUT_Comp
voltage remains steady over temperature.
The temperature drift of the AD8362 at 2.35 GHz is −0.03 dB/°.
It has been measured at a detector input power of −15 dBm.
The following equation shows how of the resistor ratio is
calculated:
C)(mV/8362
C/mV10
o
o
DriftAD
T
V
T
P
V
R1
R2
DET
TM
−=
Δ
Δ
Δ
Δ
−
=
The temperature drift of the AD8362 in dB/°C is converted to
mV/°C through multiplication by the logarithmic slope of the
detector (49.79 mV/dB at 2.35 GHz). In this application, the
drift of −0.03 dB/°C is equivalent to −1.51 mV/°C.
Figure 20 shows the measured performance over temperature
for the compensated circuit at 2.35 GHz. Note that the compen-
sation factor was chosen to optimize temperature drift in the
0°C to 85°C range. This is consistent with end equipment where
performance at low temperatures is less critical.
VDET_OUT
VSET
CLPF
INHI
INLO
VTGT
AD8362
VOUT_Comp
47nF
0.1µF
VREF
1nF
1nF
5V
R1
4.99kΩ
R2
33.2kΩ
TMP36F
4.7nH
2.7nH
10dB
4dB
P
OUT
= –1dBm MAXRF INPUT
05790-019
Figure 19. Power Detection and Temperature Compensation of the AD8362 at 2.35 GHz

AN-826
Rev. B | Page 12 of 16
+25°C
–4
–3
–2
–1
0
1
2
3
4
ERROR (dB)
0
4.0
PIN MEASURE (dBm)
V
OUT
(V)
0–60
05790-020
3.5
3.0
2.5
2.0
1.5
1.0
0.5
–55 –50 –45 –40 –35 –30 –25 –20 –15 –10 –5
+25°C
+85°C
–40°C
–40°C
+85°C
Figure 20. Output Voltage and Temperature Drift of the AD8362 at 2.35 GHz
with External Temperature Compensation
OVERALL SYSTEM PERFORMANCE
Table 3 gives a summary of the whole Tx chain performance.
The following system performances have been characterized:
•Power control range
•Maximum linear output power
•Gain flatness
•Noise floor
•OP1dB and OIP3
•Power detector accuracy and detection range
•EVM with a WiMAX OFDM signal
•Spectral quality with a WiMAX OFDM signal
The OFDM signal is generated by extracting I and Q vectors off
of a WiMAX signal generator. EVM performance was measured
using the Agilent 89600 demodulating software.
For an OFDM signal, most of the EVM degradation is caused
by the imperfections of the IQ modulator and the phase noise
or phase error of the local oscillator. Some of the close-in phase
noise modulating the subcarriers after upconversion can be
removed by the phase tracking algorithm implemented within
the receiver or demodulator.
The contribution of each building block of this transmit chain
to EVM at −3 dBm of output power is as follows:
•DAC and IQMOD with ideal LO: EVM = 0.6%
•DAC and IQMOD + VGA with ideal LO: EVM = 1.02%
•DAC and IQMOD + VGA with Frac-N PLL: EVM = 1.21%
The fractional-N PLL used for this reference design has a phase
error due to phase noise of 0.35° and only degrades the overall
system EVM by 0.2%.
For these characterizations, the IQ modulator output power
level was set around its optimum power level at −14 dBm. Then
a 3 dB pad was added to drive the Tx VGA.
1.0
0.9
0.8
0.7
0.6
0.5
0.4
IQ MODULATOR EVM (% RMS)
–22 –18 –14 –10 –6
OUTPUT POWER LEVEL (dBm)
05790-021
Figure 21. IQ Modulator EVM in %rms vs. Output Power, 64 QAM OFDM
3.5
3.0
2.5
2.0
1.5
1.0
0.5
TOTAL EVM (% RMS)
–50 –40 –30 –20 –10 0
TRANSMITTER OUTPUT POWER LEVEL (dBm)
05790-022
Figure 22. Signal Chain Total EVM as a Function of the Tx VGA Gain
With −17 dBm of input power, the VGA can deliver about
−3 dBm with a very good EVM performance of 1.2%, as shown
in Figure 22.
Figure 22 highlights the exceptional EVM performance of the
ADL5373 IQ modulator over a good range of output power
levels. Its contribution to the cascaded EVM performance is
quite small.
At midpower, the EVM is basically driven by the IQ modulator
and the LO synthesizer. As the output power reaches the lowest
part of the dynamic range, EVM performance starts to degrade
as the signal-to-noise ratio drops.

AN-826
Rev. B | Page 13 of 16
TYPICAL PERFORMANCE CHARACTERISTICS
VPS1 = 5 V for the ADL5373, ADL5330, and AD8362 components. VPS2 = 3.3 V for ADF4153 and AD9860/AD9862. Radio frequency
band: 2.3 GHz to 2.4 GHz.
–45
–35
–25
–15
–5
5
15
GAIN (dB)
–15
–10
–5
0
5
10
15
GAIN LAW CONFORMANCE (dB)
V
GAIN
(V)
0.2 0.4 0.6 0.8 1.0 1.2 1.4
05790-023
Figure 23. Power Gain Range for −10 dBm Out of the IQ Modulator, and Gain
Law Conformance vs. VGAIN at 2350 MHz
–6
–5
–4
–3
–2
–1
0
MODULATED POWER LEVEL (dBm)
RF FREQUENCY (GHz)
2.28 2.30 2.32 2.34 2.36 2.38 2.40 2.42
05790-024
Figure 24. Modulated Power Level vs. RF Frequency, with a Modulated OFDM
Signal
–70
–60
–50
–40
–30
–20
–
10
WiBro MASK (dBm)
OUTPUT POWER LEVEL (dBm)
–50 –40 –30 –20 –10 0
05790-025
CHANNEL EDGE @ 5.45MHz
ADJ CHANNEL @ 10.5MHz
Figure 25. Transmitter Spectral Quality According to WiBro Mask (64 QAM
WiMAX OFDM, 10 MHz BW) Function of Output Power or VGAIN Voltage
–20
–30
–40
–50
–60
–70
–80
–90
–
100
–
110
CENTER 2.35GHz SPAN 40MHz4MHz/
REF –11.7dBm ATT 0dB
RBW 30kHz
VBW 300kHz
SWT 1s
05790-026
*
*
**
A
LVL
EXT
Figure 26. Transmitter Output Spectrum @ 2.35 GHz (64 QAM WiMAX OFDM,
Bandwidth = 10 MHz) at −5 dBm Output Power

AN-826
Rev. B | Page 14 of 16
0.5
1.0
1.5
2.0
2.5
3.0
3.5
TOTAL EVM (% RMS)
TRANSMITTER OUTPUT POWER LEVEL (dBm)
–50 –40 –30 –20 –10 0
05790-027
Figure 27. Transmitter Total EVM for an 802.16 64 QAM OFDM Signal,
10 MHz Signal Bandwidth
–60 –50 –40 –30 –20 –10 0
05790-028
–
130
–135
–140
–145
–150
–155
–160
NOISE FLOOR (dBm/Hz)
TOTAL OUTPUT POWER LEVEL (dBm)
Figure 28. Transmitter Output Noise Floor vs. Output Power (QPSK, 16 QAM,
64 QAM OFDM Modulated Signal)
3
2
1
0
–1
–2
–3
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0
ERROR (dB)
OUTPUT VOLTAGE (V)
–60 –55 –50 –45 –40 –35 –30 –25 –20 –15 –10 –5 0 5 10
INPUT POWER (dBm)
05790-029
CW
BPSK
QPSK 1/2
QPSK 3/4
16QAM 3/4
64QAM 1/2
Figure 29. RMS Power Detector Response and Detection Error vs. Tx Signal
Chain Output Power Level for QPSK, 16 QAM, 64 QAM OFDM Modulations
05790-030
CH2 20.0mVΩCH1 500mV M1.00ms A CH4 174mV
2
T3.15200ms
1
Figure 30. Power Detector Time Response for a WiMAX Downlink Burst
(Long Preamble, FCH, 64 QAM OFDM Data Sequence), TSYMB = 25.6 μs

AN-826
Rev. B | Page 15 of 16
SUMMARY OF MEASURED PERFORMANCE
VPS1 = 5 V (ADL5373, ADL5330, and AD8362). VPS2 = 3.3 V (ADF4153, AD9860/AD9862 DAC). Radio frequency band: 2.3 GHz to
2.4 GHz. Signal bandwidth = 10 MHz. QPSK, 16 QAM, and 64 QAM, 256-subcarriers OFDM modulation.
Table 3.
Parameter Conditions Typ Unit
Maximum Linear Output Power Level 64 QAM OFDM, EVM = 1.2 % −3 dBm
Output Power Control Range @ 2.35 GHz, ±3 dB gain law conformance, VGA input power <−10 dBm 51 dB
Gain Flatness vs. Frequency 2.3 GHz to 2.4 GHz band 0.005 dB/MHz
Worst case for any BW = 20 MHz 0.25 dB
OIP3 @ 2.35 GHz, VGAIN1= 1.4 V 19 dBm
OP1dB @ 2.35 GHz, VGAIN = 1.4 V 12.4 dBm
Spectral Mask/ACP RBW = 100 kHz, VBW = 30 kHz
64 QAM OFDM − POUT = −5 dBm, 10 MHz signal
Adjacent channel at 10MHz offset −55 dB
WiBro mask first offset @ channel edge −48.5 dBr
WiBro mask second offset @ center of adjacent channel −59 dBr
EVM vs. Gain Control 64 QAM OFDM, 2.35 GHz
P
OUT = −3 dBm, VGAIN = high −38.4 dB
1.2 %
P
OUT = −30 dBm, VGAIN = low −39.1 dB
1.1 %
Broadband Noise Floor Offset frequency = 20 MHz, POUT = −1 dBm or VGAIN = 1.4 V −142.5 dBm/Hz
Offset frequency = 20 MHz, POUT ≤−20 dBm or VGAIN ≤1 V −155 dBm/Hz
RMS Power Detection Range All modulation types, error < ±0.5 dB 60 dB
1VGAIN is the ADL5330 gain control voltage.
Table 4. Power Supply
Parameter Conditions Typ Unit
Positive Supply Voltage 1 5 V
Quiescent Current Total current for the ADL5373, ADL5330, and AD8362 380 mA
Positive Supply Voltage 2 3.3 V
Quiescent Current Total current for the ADF4153, AD9860/AD9862 Tx paths at 80 MSPS 165 mA

AN-826
Rev. B | Page 16 of 16
BILL OF MATERIALS FOR MAJOR COMPONENTS
Table 5. Components Description (Excludes Passives)
Component Function Vendor Evaluation Board Part No.
AD9860/AD9862 Mixed signal front end (ADC and DAC) Analog Devices, Inc. AD9860-EB, AD9862-EB
ADL5373 Direct conversion IQ modulator Analog Devices, Inc. ADL5373-EVALZ
ADL5330 Voltage-controlled amplifier/attenuator Analog Devices, Inc. ADL5330-EVAL
ADF4153 Fractional-N PLL Analog Devices, Inc. EVAL-ADF4153EB1
AD8362 RMS responding power detector Analog Devices, Inc. AD8362- EVALZ
©2005–2007 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
AN05790-0-9/07(B)
