Programmer’s Guide
For PLS300

2
A1: Introduction
If you need to use your own Software Control program from a PC or WORKSTATION with an RS-232 or LAN port, the device allows communication
through an ASCII code protocol.
The device treats any character that it receives on the RS-232 or LAN as a possible command but only accepts legal commands.
There is no starting/ending code needed in a command string.
A command can be a single character typed on a keyboard and does not require any special character before or after it.
(It is not necessary to press "ENTER" on the keyboard). A command can be preceded by a value (See chapter A-2).
When the device receives a valid command, it will execute the command. Then it will send back the status of the parameters that have changed due
to this command.
If the command cannot be executed (value out of range, no signal on the selected input),etc. The device will just sends back the current status of
the corresponding parameters.
If the command is invalid, an error response will be returned to the control device. All responses returned to the control device end with
a carriage return <CR> and a line feed <LF> signaling the end of the response character string (see chapter A-3).
A2: Commands structure
The above listed devices share the same code structure.
Commands are made of numerical values for arguments followed by the command characters (one or Two case-sensitive alphabetical letters). Usually the same
characters (letters) are used for the [read Command] as well as the [write command].
The indexes are defined numbers indicating the how the arguments for the command apply. For example a layer number, an input number, a preset number, etc.
They are separated with a comma.
There are commands without index and others with up to 3 indexes. Each index is followed by a comma character. The final argument, also refered to as the “value”
does not have a comma between it and the command.

3
A [write command] is made of indexes followed by the numerical value followed by the command characters.
Write command = [[index,] ...] + Value + Character (s) code (s)
For example: “1,2,0IN” or “4YB”
A [read command] is made of indexes followed immediately by the command characters. (no numerical value)
Read command = [[index,] ...] Character (s) code (s)
For example: “1,2,IN” or “YB”
A3: Examples
Document notation:
1) Command with 1 index : OFORMAT
Command to set the Main output format to XGA: 0,12OF
Answer: OF0,12<CR><LF> which mean that the main output format is now 1024x768
2) Command with 2 indexes : PE_INPUTNUM
Command to set the input 4 displayed in background layer of Next Preset: 1,2,4IN
Answer: IN1,1,4<CR><LF> which mean that the background layer of the next preset will display the input 4 signal
3) Read command without index : TAKEAVA
Read command to know if the TAKE command is available: TA
Answer: TA1<CR><LF> which mean that the device is ready to accept the TAKE command.
4) Read command with 2 indexes : SET_ASPECT_RATIO_OUT
Read command to know how is displayed a signal plugged on the input 4: 3,so
Answer: so3,2<CR><LF> which mean that the input 4 is displayed cropped

4
A4: Error codes
Answer: E10<CR><LF> which mean invalid command
Answer: E11<CR><LF> which mean index value error (index value out of range)
Answer: E12<CR><LF> which mean index number error (too or few indexes)
Some commands are only available as [Read command], they are status and are colored in blue as this line.
Some commands are colored in yellow as this line to indicate they were added or modified in this version.
A5 COMMUNICATION PORTS

5
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
SYSTEM
DIESE # # Request the retrieval of all the
variables Rd/Wr
0 1 0
READY * * Ready Device Flag Rd 0 1 0 0= Initialization in progress
1 = Ready
DEV ? DEV MMS device type Rd 78 78 78 78 = PLS-300
CONTROLS
UPDATER yU yU Device reboot for update Rd/Wr
0 255 0 1 then 254 => Reboot
FACTORYRESET YR YR
Apply factory settings to the
device( except image settings ) Rd/Wr
0 1 0
Auto reset
POSMEMORYRESET YE YE Erase stored image settings Rd/Wr
0 1 0
Auto reset
CSTORE YS YS
FLASH memory writing in progess.
Do not power off Rd 0 1 0 0 = Free 1 = Flash writing in progress
LOCK YK YK Device locking Rd/Wr
0 2 0 0 = No lock 1 = Locked menu
2 = Locked front panel
LCDBRIGHTNESS YB YB Front panel display brightness Rd/Wr
1 8 8 1, …, 8 = Brightness level, 12,5%
step
KEYBRIGHTNESS Yb Yb Front panel keys brightness Rd/Wr
10 100 100 1, …, 100 = Brightness level, 1%
step
TBAR_ENABLE YD YD Enable disable T-BAR Rd/Wr
0 1 1
COPKIND CK CK Kind of slow in-progress operation
Rd 0 6 0
0 = None
1 = Auto centering
2 = Auto setting
3 = StandBy
4 = Picture recording
5 = Reset to default factory
setting
6 = Reset User settings
COPPROGRESS CP CP Progress percent of the slow
operation Rd 0 100 0 Percent : 0 to 100%
AXION
yA yA Device is driven by Orchestra Rd/Wr
0 1 0 0 = Device is not driven by ORC- 50
1 = Device is driven by Orc-50
AUTO_LOCK
YL YL Forbide the use of a signal-less
input Rd/Wr
0 1 1
0 = Signal less input can be
selected
1 = Signal less input can not be
selected
AUTO_TAKE
YT YT
Automatic Take after an input
change Rd/Wr
0 1 0 0 = AUTO-TAKE Disable
1 = AUTO-TAKE Enable
AUTO_STEPBACK
Ys Ys
Automatic preset toggle after a
TAKE Rd/Wr
0 1 0
0 = AUTO- PRESET-TOGGLE
Disable
1 = AUTO- PRESET-TOGGLE
Enable
FREEZE_MODE Ym Ym Input freeze mode Rd/Wr
0 1 0 0 = Freeze by input
1 = Freeze all inputs

6
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
FRAME_ALERT Yf Yf Back-up input when an input loose
its signal Rd/Wr
0 12 0
0 = No input
1 = Input1
2 = Input2
3 = Input3
4 = Input4
5 = Input5
6 = Input6
9 = Input9
10 = Input10
11 = Input11
12 = Input12
TRANSPARENT_BACKGROUND Yt Yt Disable the the black fiilng of the
bakgrounfd live layer Rd/Wr
0 1 1 0 = use BLACK_FILL 1 = Disable black filling only for
background
BLACK_FILL bF bF Fill PIP with black depending on
the aspect ratio Rd/Wr
0 1 0 0 = Disable black filling
1 = Enable black filling
DISABLE_ID bI bI Disable Frame and Ids on the
preview output Rd/Wr
0 1 0
STANDBY
STDBYSTATUS
wS
wS
Standby mode Rd/Wr
0 1 0 0 = Normal mode
1 = Standby mode
STDBYREQUEST
wQ
wQ
Request for standby or wake up Rd/Wr
0 1 0 0 = Wake up
1 = Standby
STDBYPROJ_ON
wN
wN
Message to wake-up an output
display device ( 50 characters) Rd/Wr
0 255 0 min = 0 max = 49
STDBYPROJ_OFF
wF
wF
Message to send an output display
device to sleep ( 50 characters) Rd/Wr
0 255 0 min = 0 max = 49
STDBYPROJ_RATE
wR
wR
Output display device UART speed
Rd/Wr
0 3 2
0 = 1200bauds
1 = 2400bauds
2 = 9600bauds
3 = 19200bauds
STDBYPROJ_CTRL
wC
wC
Rd/Wr
0 4 0
0 = No request
1 = Wake up request
2 = Standby request
3 = Clear Wake up message
4 = Clear standby message
VERSION
VERI1 xi xi Byte 0 and 1 of the device ID Rd 0 65535 0 ex : AAAA
VERI2 xj xj Byte 2 and 3 of the device ID Rd 0 65535 0 ex : AAAA
VERI3 xk xk Byte 4 and 5 of the device ID Rd 0 65535 0 ex : AAAA
VERI4 xl xl Byte 6 and 7 of the device ID Rd 0 65535 0 ex : AAAA

7
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
VERK xK xK Checksum/version of the
programmable components Rd/Wr
0 65535 0
0 = Number of
programmables
components
1 = Main micro-
controler
2 = Front panel
micro-controler
3 = FPGA
Caecina
4 = FPGA Fannia
5 = FPGA
Thrasea
6 = Synchro
CPLD
VERV xV xV Variable set version Rd 0 65535 42
VERUPD xU xU Updater version Rd 0 65535 0
OPT yo yo Detected options Rd 0 65535 0
bit 0 = Lan Module
bit 1 = SDI In 1 board (SDI 1 and
2)
bit 2 = Recording board
bit 3 = CF Caecina
bit 4 = CF Fannia
bit 5 = CF Thrasea
bit 6 = SDI In 2 board (SDI 3 and
4)
bit 7 = Audio Evolution
bit 8 = HDCP DVI In Evolution
REV xR xR Moher board revision Rd 0 255 0
INPUT
IN_AUTOSET_ALL Ia Ia
Auto
-setting request for all the
inputs Rd/Wr
0 1 0
IN_AUTOSET Ii Ii
Auto
-setting request for the
specified input Rd/Wr
0 1 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

8
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
IN_USR_FORMAT iU iU
Format/standard of the input signal
corrected by user Rd/Wr
0 42 0
0 = None
1 = Invalid
2 = Unknown
3 = SDTV NTSC
4 = SDTV PAL
5 = SDTV SECAM
6 = SDTV BW
7 = SDTV 480i
8 = SDTV 576i
9 = EDTV 480p
10 = EDTV 576p
11 = HDTV 720p
12 = HDTV 1035i
13 = HDTV 1080i
14 = HDTV 1080p
15 = HDTV 1080sF
16 = CPU VGA
17 = CPU 800x480
18 = CPU WVGA
19 = CPU SVGA
20 = CPU 1280x600
21 = CPU 720p RGB
22 = CPU XGA
23 = CPU WXGA
24 = CPU SWXGA
25 = CPU 800p RGB
26 = CPU SWXGA+
27 = CPU 1152x864
28 = CPU 900p RGB
29 = CPU 1600x900
30 = CPU 960p RGB
31 = CPU SXGA
32 = CPU 1360x1024
33 = CPU DILA4/3
34 = CPU SXGA+
35 = CPU WSXGA+
36 = CPU 1080p RGB
37 = CPU 2K
38 = CPU UXGA
39 = CPU WUXGA
40 = CPU 1920x1440
41 = CPU QXGA
42 = CPU 1366x768
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

9
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
IN_TYPE iK iK Input signal type Rd/Wr
0 17 13
0 = SDTV Composite
1 = SDTV Y/C
2 = SDTV/EDTV/HDTV RGBS
TTL/Analog
3 = SDTV/EDTV/HDTV RGB
SOG
4 = SDTV/EDTV/HDTV YUV
5 = Computer SOG
6 = Computer H&V or Composite
(TTL/Analog)
7 = Computer B&W
8 = DVI-D EDTV/HDTV RGB 16-
235
9 = DVI-D EDTV/HDTV YUV
10 = DVI-D Computer RGB 0-255
11 = DVI-D Computer RGB 16-
235
12 = SDI SDTV/HDTV
13 = Analog Computer, separated
H&V synchro
14 = Analog Computer,
composite TTL synchro
15 = Analog Computer,
composite analog synchro
16 = Analog RGB video,
composite TTL synchro
17 = Analog RGB video,
composite analog synchro
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_SYNC_LOAD il il
Analog H sync load
Rd/Wr
0 1 0 0 = Hi-Z
1 = 75 ohm loaded
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

10
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
IN_USED iu iu Input is enabled Rd/Wr
0 1 1
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_SD_STD iS iS Decoded video standard Rd/Wr
0 7 0
0 = Auto
1 = NTSC (M,J)
2 = PAL (BDGHIN)
3 = PAL (M)
4 = PAL (N-Combination)
5 = NTSC 4.43
6 = SECAM
7 = PAL 60
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_SD_STA iV iV Video Signal stability Rd/Wr
0 1 1 0 = Stable Source ( DVD ) 1 = VCR Source ( Video cassette
recorder )
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_SYNCHRONIZED iY iY VIS Synchronisation group Rd/Wr
0 3 0
0 = Does not belong to any VIS
Group
1 = Groupe VIS 1 group for
analog input
2 = Groupe VIS 2 group for
analog input
3 = Groupe VIS 3 group for
analog input
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_HDCP_ENABLE iH iH Enable/disable the HDCP support
of a DVI input Rd/Wr
0 1 1 10 = Input11
11 = Input12

11
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
IN_HDCP_CABLE_LEN iC iC Lenght of an DVI input cable Rd/Wr
0 2 0
0 = Less than 10 meter cable
length
1 = 5 to 20 meters cable length
2 = More than 15 meters cable
length
10 = Input11
11 = Input12
KEYING
IN_KEYING_TYPE KT KT Keying type Rd/Wr
0 4 0
0 = No keying
1 = Luma Key Keying
2 = ChromaKey Keying
3 = Luma Key Keying + DSK
4 = ChromaKey Keying + DSK
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_KEYING_R_LEVEL KR KR Keying level (Red ) Rd/Wr
0 255 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_KEYING_G_LEVEL KG KG Keying level (Green) Rd/Wr
0 255 255
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_KEYING_B_LEVEL KB KB Keying level (Bule) Rd/Wr
0 255 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

12
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
IN_KEYING_TOLER KH KH Keying Tolerance (for chroma and
luma key) Rd/Wr
0 255 10
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_KEYING_LUMA_LOW_LEVEL KL KL Minimum luma level Rd/Wr
0 255 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_KEYING_LUMA_HIGH_LEVEL KM KM Maximum luma level Rd/Wr
0 255 255
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_KEYING_DSK_ALPHA KA KA Brightness of DSK background Rd/Wr
0 255 64
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

13
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
IN_KEYING_INVERT KI KI Invert keying area Rd/Wr
0 1 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
IN_KEYING_GRAB_ENABLE Kg Kg Enable/disable the keying color
grabber mode Rd/Wr
0 1 0 0 = Disable the grabber
1 = Enable the grabber
IN_KEYING_GRAB_GET Kc Kc Capture the coolor selected by the
grabber and apply the settings Rd/Wr
0 1 0 Percent of OSCREEN_UTIL_H
IN_KEYING_GRAB_H Kh Kh Horizontal position of the grabber Rd/Wr
0 65535 32768 Precent of OSCREEN_UTIL_V
IN_KEYING_GRAB_V Kv Kv Vertical position of the grabber Rd/Wr
0 65535 32768
Auto reset
INPUT
STATUS
SIG_HPOL sh sh Input H sync polarity Rd 0 1 0 0 = Negative Synchro
1 = Positive Synchro
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_VPOL sv sv Input V sync polarity Rd 0 1 0 0 = Negative Synchro
1 = Positive Synchro
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_SYNC_TYPE sK sK Input sync type Rd 0 3 0
0 = Séparated Synchros H&V
1 = Composite TTL Synchro
2 = Composite Analog Synchro
3 = Synchro on Green (SOG)
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

14
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
SIG_FREQ_FIELD sf sf Input frame frequency Rd 0 65535 0 Unit = 1/100Hz
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_FREQ_LINE sl sl Input line frequency Rd 0 65535 0 Unit = 1/100Hz
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_COMPLETE sc sc Input scan completed Rd 0 1 0 0 = scan in progress or failed
1 = scan completed
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

15
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
SIG_DETECTED_FORMAT sD sD Input detected format name Rd 0 42 0
0 = None
1 = Invalid
2 = Unknown
3 = SDTV NTSC
4 = SDTV PAL
5 = SDTV SECAM
6 = SDTV BW
7 = SDTV 480i
8 = SDTV 576i
9 = EDTV 480p
10 = EDTV 576p
11 = HDTV 720p
12 = HDTV 1035i
13 = HDTV 1080i
14 = HDTV 1080p
15 = HDTV 1080sF
16 = CPU VGA
17 = CPU 800x480
18 = CPU WVGA
19 = CPU SVGA
20 = CPU 1280x600
21 = CPU 720p RGB
22 = CPU XGA
23 = CPU WXGA
24 = CPU SWXGA
25 = CPU 800p RGB
26 = CPU SWXGA+
27 = CPU 1152x864
28 = CPU 900p RGB
29 = CPU 1600x900
30 = CPU 960p RGB
31 = CPU SXGA
32 = CPU 1360x1024
33 = CPU DILA4/3
34 = CPU SXGA+
35 = CPU WSXGA+
36 = CPU 1080p RGB
37 = CPU 2K
38 = CPU UXGA
39 = CPU WUXGA
40 = CPU 1920x1440
41 = CPU QXGA
42 = CPU 1366x768
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

16
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
SIG_CURRENT_FORMAT sF sF Input current format name Rd 0 42 0
0 = None
1 = Invalid
2 = Unknown
3 = SDTV NTSC
4 = SDTV PAL
5 = SDTV SECAM
6 = SDTV BW
7 = SDTV 480i
8 = SDTV 576i
9 = EDTV 480p
10 = EDTV 576p
11 = HDTV 720p
12 = HDTV 1035i
13 = HDTV 1080i
14 = HDTV 1080p
15 = HDTV 1080sF
16 = CPU VGA
17 = CPU 800x480
18 = CPU WVGA
19 = CPU SVGA
20 = CPU 1280x600
21 = CPU 720p RGB
22 = CPU XGA
23 = CPU WXGA
24 = CPU SWXGA
25 = CPU 800p RGB
26 = CPU SWXGA+
27 = CPU 1152x864
28 = CPU 900p RGB
29 = CPU 1600x900
30 = CPU 960p RGB
31 = CPU SXGA
32 = CPU 1360x1024
33 = CPU DILA4/3
34 = CPU SXGA+
35 = CPU WSXGA+
36 = CPU 1080p RGB
37 = CPU 2K
38 = CPU UXGA
39 = CPU WUXGA
40 = CPU 1920x1440
41 = CPU QXGA
42 = CPU 1366x768
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

17
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
SIG_FORMAT_LIST sL sL Bit field of the fomats compatible
with the detected format
Rd 0 255 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
0 = Bits 0 to 7
Slice
1 = Bits 8 to 15
Slice
2 = Bits 16 to 23
Slice
3 = Bits 24 to 31
Slice
4 = Bits 32 to 39
Slice
5 = Bits 40 to 47
Slice
SIG_SCANTYPE ss ss Input scan type Rd 0 3 0
0 = Progressive
1 = Interleaved, Top field first
2 = Interleaved, Bottom field first
3 = Segmented frame
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HTOTAL_THEORIC sH sH Total number of pixels per line Rd 0 65535 0 Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HTOTAL_MAXI sM sM
Maximal number of pixels per input
line Rd 0 65535 0 Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

18
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
SIG_WIDTH sw sw Input displayed pixel count Rd 0 65535 0 Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HEIGHT st st Input displayed line count Rd 0 65535 0 Unit = pixels
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_HDCP sn sn Input HDCP status Rd 0 1 0
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SIG_MEM_SLOT sS sS Memory slot index Rd 0 255 255
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

19
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
INPUT
SETTINGS
SET_HPOS SH SH Input horizontal position Rd/Wr
0 2048 1024 1024 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_VPOS SV SV Input vertical position Rd/Wr
0 2048 1024 1024 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_HSIZE Sw Sw Input horizontal size Rd/Wr
0 4096 2048 2048 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_VSIZE Sh Sh Input vertical size Rd/Wr
0 4096 2048 2048 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12

20
Group Name CmdResp
Description
Read /
Write
Min
Value
Max
value
Default
value Values Index #1 Index #2
SET_BRIGHTNESS Sg Sg Input brightness Rd/Wr
0 255 128 128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_CONTRAST Sc Sc Input Contrast Rd/Wr
0 255 128 128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_COLOR Sr Sr Input color level Rd/Wr
0 255 128 128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
SET_HUE Su Su Input hue (NTSC only) Rd/Wr
0 255 128 128 = neutral
0 = Input1
1 = Input2
2 = Input3
3 = Input4
4 = Input5
5 = Input6
8 = Input9
9 = Input10
10 = Input11
11 = Input12
