MINI-VOX
PUBLIC ADDRESS SYSTEM
Anchor Audio’s MiniVox public address system is a lightweight, compact, conveniently battery operated unit widely praised by users
across all industries. The package includes wireless microphone upgrade options and a shoulder strap for mobility. The MiniVox is
great for fire fighters, law enforcement, search and rescue squads, tour guides or any person needing voice amplification.
FOR MORE INFORMATION PLEASE CALL: 800.262.4671
www.anchoraudio.com
SPECIFICATIONS
MiniVox
Rated Power Output 18 Watts
Max SPL@Rated Power 108 dB @ 1 meter
Frequency Response 100Hz - 12Hz
Speaker Type 4” Neodymium woofer
CD/Tape Input line level, 3.5 mm
Mic Input Lo-Z phantom powered, 3.5 mm jack
Mic Input Lo-Z, 1/4” phone
Battery Type Nine C-size, alkaline
Dimensions (HWD) 8 x 6.5 x 9.5” / 20 x 17.5 x 24 cm
Weight 3.75 lbs. / 1.7 Kg.
RC-25 Recharge Kit (optional)
Battery Type 9 ‘C’ size, 1.5AH rechargeable NiCad
Charger AC-25
AC-25 Input 120 VAC, 60Hz, 10 Watts max
AC-25/220 Input 220 VAC, 50Hz, 10 Watts max export
AC-25 Output DC taper charge
Shipping Weight 2.1 lbs. / 1.0 Kg.
MADE IN THE USA!
108DB of Clear Sound
Reach crowds of 150+
Lightweight and Compact
Operates on Nine “C” Cell Batteries for up to 25-35 hrs.
Built-in UHF Wireless Receiver
16 Channel UHF Diversity Wireless by Anchor Audio
4” Neodymium Woofer and 18W Amplifier
Includes Handheld Mic w/6’ coiled cord and Shoulder Strap
Line Input allows you to plug in CD player or Walkman™
Phantom-powered input for electret-type microphone
Optional Rechargeable Kit
6-YEAR WARRANTY! MINIVOX PACKAGE INCLUDES:
• MiniVoxPAspeakerUnit
• HandheldWiredMicrophone(6”coil)
• MiniVoxCarryingBag
• WB-6000BodyPack andchoiceofmic:
- LM-60 Lapel Mic, HBM-60 Headband Mic, CM-60 Collar Mic
or EM-60T UltraLite Mic
