am-4671 UPPER HUB Replica for RAPID REACT (SM) Assembly Guide v1.0
UPPER HUB Replica for RAPID REACTSM (am-4671) Assembly Guide
v1.1 1/21/2022
1 ip-4671_uhb Upper Hub Baseplate 1
2 am-4675 Hub Angle Bracket 24
3 ip-4671_uhvr Upper Hub Vertical Rib 4
4 Ip-4671_uhsr Upper Hub Small Rib 4
5 ip-4671_uhlr Upper Hub Large Rib 4
6 ip-4671_uhp Upper Hub Panel 4
7 ip-4671_uhvp
Upper Hub Vision
Plastic
4
Included Parts & Hardware
Part Item Item Description Quantity

2
am-4671 UPPER HUB Replica for RAPID REACT (SM) Assembly Guide v1.0
8 am-4676 Upper Hub Vision
Angle 12
9 am-1189 or
similar Cable Tie 30
10 am-1015 ¼-20 Nylock Nut 100
11 am-1027 ¼” id washer 12
12 am-1602 Hex Head Screw, 1/4-
20 x 5/8 long 32
13 am-1603 Hex Head Screw, 1/4-
20 x 1.0 long 68
Optional – Not Included in Kit
14
am-2934 OR
FIRST Choice
3M Vision Tape, 5”
long x 2” wide
16 (not included in kit)
Assembly Instructions
1. Attach Hub Angle Brackets (item 2, qty. 4) to the Baseplate (item 1, qty. 1), using 5/8” long screws (item 12, qty.
16) and ¼-20 nuts (item 10, qty. 16).
2. Attach qty. 2 Hub Angle Brackets (item 2) to each of the Plastic Ribs (Small and Large) using the 1” screws
(item 13, qty. 4 per Rib) and ¼-20 nuts (item 10, qty. 4 per Rib).
1
2
12
10
4 & 5
2
10
13

3
am-4671 UPPER HUB Replica for RAPID REACT (SM) Assembly Guide v1.0
3. Attach the Upper Hub Vertical Rib (item 3, qty. 4) to the Baseplate, using the 1” screws (item 13, qty. 4 per Rib)
and ¼-20 nuts (item 10, qty. 4 per Rib).
4. Attach the Large Ribs (item 5, w/ Brackets, qty. 4) to the Upper Hub Vertical Ribs (item 3, qty. 4) using the 1”
screws (item 13, qty. 4 per Rib) and ¼-20 nuts (item 10, qty. 4 per Rib).
5. Repeat previous step with the Small Ribs (item 4, w/ Brackets, qty. 4), using the 1” screws (item 13, qty. 4 per
Rib) and ¼-20 nuts (item 10, qty. 4 per Rib).
2
13
10
13
10
5
4
10
13

4
am-4671 UPPER HUB Replica for RAPID REACT (SM) Assembly Guide v1.0
6. Insert plastic Upper Hub Panels (item 6, qty. 4), one piece at a time, bending and ensuring it lands on all 6
hooks on the Vertical Ribs. Pieces will need to be pressed down firmly to seat where they overlap the adjacent
Panel piece. The last piece of Panel plastic will tight to get in place. Use cable ties to hold plastic into position.
7. Attach Upper Hub Vision Angles (item 8, qty. 3 per Plastic piece) to the Upper Hub Vision Plastic (item 7, qty.
1), using the 5/8” screws (item 12, qty. 3 per Plastic piece) and ¼-20 nuts (item 10, qty. 3 per Plastic piece).
Attach 5” x 2” Vision Tape as shown (Item 14, qty 4 per Plastic piece). Vision tape is not included.
8. Attach assembled Upper Hub Vision Angles (qty. 4 assemblies) to the Large Ribs at the top of the Hub using
the 1” screws (item 13, qty. 12) with nuts (item 10, qty. 12) and washers (item 11, qty. 12) on the bottom of the
plastic. Use cable ties at each Plastic joint, shown at item 9 below (qty. 8). Ensure the Vision Plastic is not
upside down. Extra screws and nuts are for attaching agitator, (am-4674, sold separately, not included in
Upper Hub)
6
10
7
12
8
14
13
10
9
