User instructions
ArcSource Outdoor 24 MC
The product generates colored light by means of high power LEDs.The product was designed for exterior use
and it is ideal for locations where signaling,directional or e󰀨ect lighting is required.
1.Attention
Consider the respective national norms during the installation!
Do not install the unit near naked ames.
Avoid using the unit in locations subject to possible impacts.
Do not attempt to dismantle or modify the unit.
Do not install the module in badly ventilated location
Avoid looking directly into the LED light beam at close range.
2.Installation
The ArcSource Outdoor unit can be connected to the ArcPower Rack Unit, ArcPower 24 Outdoor, ArcPower
48 Outdoor, ArcPower 192 Outdoor, DRS. See their user manuals for full details of mains power requirements
and DMX operation.
Example of installation:
Number of connected ArcSource Outdoor 24 MC to the one LED output of the LED driver:
1 unit for ArcPower 24 Outdoor
2 units for ArPower 48 Outdoor, ArcPower 192 Outdoor, ArcZone DRS, ArcPower Rack Unit
Note: Use the T-connector Chogori 8-pin (optional accessories) for multiply units installation.
Connections:
1. ArcSource Outdoor 24 MC

2
2. Adapter cable Chogori -RJ45 (it is not a standard part of delivery), for indoor use only
3. Adapter cable Chogori -Chogori (it is not a standard part of delivery)
The ArcSource Outdoor unit can be arranged in any position orientation. LED module body is mounted on a
steel “U” bracket for “ tilt” adjustment, after adjusting desired inclination, secure the LED module bode by means
of the Allen key 6. For fastening the unit on the wall (truss etc) serves 3 apertures in the U-bracket .
Top hat (half top hat) installation:
3.Technical specications
Max input current (per colour ): 700 mA
Maximum power consumption: 60 Watts
Comp. power supplies : ArcPower 192 Outdoor, ArcPower 24 Outdoor,
ArcPower 48 Outdoor, ArcZoneDRS, ArcPower Rack Unit,
Max. surface temperature: 75°C@+40°C
Operating ambient temp.range: -20°C/+40°C
Cooling system: convection
LED device: Cree MC-E
Number of RGBW multichips: 6
Beam angle: 11°, 26°, 36°
Typical Lumen maintenance: 70%@ 60,000 hours
LED life expectancy: minimum 60,000 hours
Ingress Protection: IP 67
Construction: Body+ "U" bracket High-pressure die cast aluminium
transparent cover tempered glass
Weight: 4.3 kg
LED connection plug: Chogori 08BMMA-SL8001 (male)
LED connection cable: LiYY 8xAWG22 UL Style 2517/CSA O.D. 6,70mm; L=0.5m
Unscrew the four socket head screws 6x10 (1) in Arc-
Source Outdoor 24 MC housing and slide the top hat
(2) onto ArcSource outdoor 24 MC and secure it with
four socket head screws 6x10 through holes (3) in the
top head.

3
Dimensions (mm)
Top hat
Half top hat

4
Version 2.1
July 26, 2018
Specications are subject to change without notice
Made in ROBE Lighting s.r.o., Palackého 416, 757 01 Valašské Meziříčí, Czech Republic
Floor stand
4. Accessories
1x Connector Chogori CGRBDU-08BFFA (female), IP67
5. Optional Accessories
(P/N 13051960) Adapter cable CGRBDU-08BFFA/ CGRBDU-08BMMA, L=3m, IP67
(P/N 13051966) Adapter cable CGRBDU-08BFFA/RJ45, L=0.25m, for indoor use only
(P/N 13051938) T-connector Chogori 8-pin, IP67
(P/N 10980171) Top Hat ArcSource Outdoor 24 MC
(P/N 10980172) Half Top Hat ArcSource Outdoor 24 MC
(P/N 1098 0175) Floor stand for ArcSource Outdoor 24 MC
(P/N 10980327) Pole Clamp for ASO 16/24/48MC, 63-80mm
(P/N 10980328) Pole Clamp for ASO 16/24/48MC, 80-105mm
(P/N 10980325) Pole Clamp for ASO 16/24MC, 63-80mm
(P/N 10980326) Pole Clamp for ASO 16/24MC, 80-105mm
(P/N 10980331) Tenon Adaptor for ASO 16/24/48MC 64-80mm
(P/N 10980332) Tenon Adaptor for ASO 16/24/48MC 80-106mm
(P/N 10980329) Tenon Adaptor for ASO 16/24MC 64-80mm
(P/N 10980330) Tenon Adaptor for ASO 16/24MC 80-106mm
(P/N 10980334) Land Spike for ASO 16/24/48MC
