Anritsu MS2690A User manual

Document No.: M-W2914AE-9.0
ANRITSU CORPORATION
MS2690A/MS2691A/MS2692A
and MS2830A Signal Analyzer
Vector Signal Generator
Operation Manual
IQproducerTM
Ninth Edition
•For safety and warning information, please read this
manual before attempting to use the equipment.
•
Additional safety and warning information is provided
within the “MS2690A/MS2691A/MS2692A Signal
Analyzer Operation Manual (Mainframe Operation)”,
“MS2830A Signal Analyzer Operation Manual
(Mainframe Operation)”,
“MS2690A/MS2691A/MS2692A Option 020 Vector
Signal Generator (Operation)” and “MS2830A Vector
Signal Generator (Operation)” Please also refer to
either of these documents before using the
equipment.
•
Keep this manual with the equipment.

ii
Safety Symbols
To prevent the risk of personal injury or loss related to equipment malfunction, Anritsu Corporation uses the
following safety symbols to indicate safety-related information. Ensure that you clearly understand the meanings
of the symbols BEFORE using the equipment. Some or all of the following symbols may be used on all Anritsu
equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this
manual.
Symbols used in manual
This indicates a very dangerous procedure that could result in serious injury or
death if not performed properly.
This indicates a hazardous procedure that could result in serious injury or death if
not performed properly.
This indicates a hazardous procedure or danger that could result in light-to-severe
injury, or loss related to equipment malfunction, if proper precautions are not taken.
Safety Symbols Used on Equipment and in Manual
The following safety symbols are used inside or on the equipment near operation locations to provide information
about safety items and operation precautions. Ensure that you clearly understand the meanings of the symbols
and take the necessary precautions BEFORE using the equipment.
This indicates a prohibited operation. The prohibited operation is indicated
symbolically in or near the barred circle.
This indicates an obligatory safety precaution. The obligatory operation is
indicated symbolically in or near the circle.
This indicates a warning or caution. The contents are indicated symbolically in or
near the triangle.
This indicates a note. The contents are described in the box.
These indicate that the marked part should be recycled.
MS2690A/MS2691A/MS2692A and MS2830A Signal Analyzer
Vector Signal Generator
Operation Manual (IQproducerTM)
25 April 2007 (First Edition)
25 November 2014 (Ninth Edition)
Copyright © 2007-2014, ANRITSU CORPORATION.
All rights reserved. No part of this manual may be reproduced without the prior written permission of the
publisher.
The contents of this manual may be changed without prior notice.
Printed in Japan
DANGER
WARNING
CAUTION

iii
Notes On Export Management
This product and its manuals may require an Export License/Approval by
the Government of the product's
country of origin for re-
export from your
country.
Before re
-
exporting the product or manuals, please contact us to confirm
whet
her they are export-controlled items or not.
When you dispose of export
-
controlled items, the products/manuals need
to be broken/shredded so as not to be unlawfully used for military purpose.
Trademark and Registered Trademark
IQproducer
TM
is a registered trademark of Anritsu Corporation.

iv
Protection Against Computer Virus Infections
Prior to the software installation
Before installing this software or any other software recommended or
approved by Anritsu,
run
a virus scan on your computer, including
removable media (e.g. USB memory stick and CF memory card) you
want to connect to your computer.
When using this softwar
e and connecting with the measuring instrument
•Copying files and data
On your computer, do not save any copies other than the following:
•Files and data provided by Anritsu
•Files created by this software
•Files specified in this document
Before copying these files and/or data, run a virus
scan, including
removable media (e.g. USB memory stick and CF memory card).
•Connecting to network
Connect your computer to the network that provides adequate
protection against computer viruses.
Cautions on Proper Operation of Software
This software may not operate normally if any of the following operations
are performed
on your computer:
•Simultaneously
running any software other than that recommended or
approved by Anritsu
•Closing the lid (Laptop computer)
•Turning on the screen saver function
•Turning on the battery-power saving function (Laptop computer)
For how to turn off the functions, refer to the
operation manual
that came
with your computer.

I
About This Manual
Composition of Operation Manuals
The operation manuals for the MS2690A/MS2691A/MS2692A or
MS2830A Signal Analyzer are comprised as shown in the figure below.
Vector Signal Generator Operation Manual (IQproducerTM)
Vector Signal Generator Operation Manual (Standard Waveform Pattern)
Communication System Supporting IQproducerTM Operation Manual
MS2690A/MS2691A/MS2692A
Signal Analyzer Operation Manual
(Main Frame Operation)
MS2690A/MS2691A/MS2692A and MS2830A
Signal Analyzer Operation Manual (Main Frame Remote Control)
MS2830A Signal Analyzer
Operation Manual
(Main Frame Operation)Or
MS2690A/MS2691A/MS2692A
Signal Analyzer
Option 020: Vector Signal
Generator Operation Manual
(Operation)
MS2830A
Signal Analyzer Vector Signal
Generator Operation Manual
(Operation)
Or
MS2690A/MS2691A/MS2692A
Signal Analyzer
Option 020: Vector Signal
Generator Operation Manual
(Remote Control)
MS2830A
Signal Analyzer Vector Signal
Generator Operation Manual
(Remote Control)
Or

II
Signal Analyzer Operation Manual (Mainframe Operation)
Signal Analyzer Operation Manual (Mainframe Remote Control)
These manuals describe basic operating methods, maintenance
procedures, common functions, and common remote control of the signal
analyzer mainframe.
Vector Signal Generator Operation Manual (Operation)
This manual describes functions, operating methods, and so on of the
vector signal generator (option).
Vector Signal Generator Operation Manual (Remote Control)
This manual describes remote control of the vector signal generator
(option).
Vector Signal Generator Operation Manual (IQproducerTM) (This
manual)
This manual describes functions, operating methods, and so on of the
IQproducer, which is application software used with the vector signal
generator (option).
Vector Signal Generator Operation Manual (Standard Waveform
Pattern)
This manual describes details on the standard waveform pattern data
used with the vector signal generator (option).

III
2
3
4
5
1
Appendix Index
Table of Contents
About This Manual........................................ I
Chapter 1 Overview.................................... 1-1
1.1 Overview .................................................................... 1-2
1.2 Functions ................................................................... 1-3
Chapter 2 Installation/Uninstallation ........ 2-1
2.1 Operating Environment.............................................. 2-2
2.2 Installation/Uninstallation Procedure ......................... 2-3
Chapter 3 Basic Operations ...................... 3-1
3.1 Operations for Menu .................................................. 3-2
3.2 Operations for Dialog Box.......................................... 3-4
Chapter 4 Operations for Each Function . 4-1
4.1 Starting/Exiting IQproducerTM .................................... 4-4
4.2 Common Platform Screen ......................................... 4-6
4.3 CCDF Graph Display ................................................. 4-10
4.4 FFT Graph Display .................................................... 4-24
4.5 File Conversion on Convert Screen........................... 4-38
4.6 W-CDMA Downlink Waveform Pattern Generation
Function ..................................................................... 4-64
4.7 W-CDMA Uplink Waveform Pattern Generation
Function ..................................................................... 4-91
4.8 Help Screen ............................................................... 4-114
4.9 Time Domain Graph Display...................................... 4-115
4.10 Clipping Function ....................................................... 4-134
Chapter 5 Waveform Pattern Generation . 5-1
5.1 Generating Waveform Pattern ................................... 5-2

IV.
Appendix A Error Messages....................... A-1
Index .......................................................... Index-1

Chapter 1 Overview
1-1
1
Overview
This chapter provides an overview of the IQproducerTM for the
MS2690A/MS2691A/MS2692A or MS2830A Signal Analyzer Vector
Signal Generator option.
1.1 Overview .................................................................... 1-2
1.2 Functions ................................................................... 1-3
1.2.1 Signal generation application corresponding to
communications system ................................ 1-3
1.2.2 CCDF graph display function ........................ 1-3
1.2.3 FFT graph display function............................ 1-3
1.2.4 File conversion function................................. 1-3
1.2.5 Time domain graph display function.............. 1-4
1.2.6 Clipping function ............................................ 1-4

Chapter 1 Overview
1-2
1.1 Overview
The IQproducerTM is Windows application software used to generate a
modulated waveform pattern to be used by the
MS2690A/MS2691A/MS2692A or MS2830A Signal Analyzer Vector
Signal Generator option.
Note that purchase of a license key corresponding to the serial number of
your Vector Signal Generator option is required when actually using a
waveform file with the Vector Signal Generator option, a file generated
by the modulated waveform pattern generator IQproducerTM (hereinafter,
referred to as “signal generation application”) corresponding to each
communication system.
The IQproducerTM also enables the Complimentary Cumulative
Distribution Function (CCDF) results and Fast Fourier Transform (FFT)
results of a generated modulated waveform pattern to be displayed in a
graph. In addition, it can convert an ASCII-format waveform pattern
generated by your signal generation application tool to a binary-format
waveform pattern that can be used in the Vector Signal Generator option.
This operation manual describes the functions of the IQproducerTM,
except for the signal generation application.

1.2 Functions
1-3
1
Overview
1.2 Functions
1.2.1 Signal generation application corresponding to communications
system
Signal generation applications that generate modulation waveform
patterns are provided for each communications system. For detailed
information on the operations and functions of these applications, refer to
the operation manual of each signal generation application.
1.2.2 CCDF graph display function
The IQproducerTM can read a modulation waveform pattern generated by
each signal generation application and display it in the CCDF graph with
up to eight traces.
The CCDF graph displayed on the screen can be printed out and saved
into a CSV-format file.
1.2.3 FFT graph display function
The IQproducerTM can read a modulation waveform pattern generated by
each signal generation application and display it in the FFT graph with
up to four traces.
The FFT graph displayed on the screen can be printed out and saved into
a CSV-format file.
1.2.4 File conversion function
The IQproducerTM can convert an ASCII-format waveform pattern
generated by simulation software or other external software to a
binary-format modulation waveform pattern file that can be used in the
Vector Signal Generator option.
In addition, it can convert a digitized file that is created by the
MS2690A/MS2691A/MS2692A or MS2830A Signal Analyzer using the
digitize function, and convert a waveform pattern for the
MG3700A/MG3710A Vector Signal Generator (hereinafter, referred to as
“MG3700A/MG3710A”) into a binary-format modulation waveform
pattern that can be used in the Vector Signal Generator. Conversely, a
waveform pattern for the MS269x/MS2830 can also be converted into a
file that can be used in the MG3700A/MG3710A.

Chapter 1 Overview
1-4.
1.2.5 Time domain graph display function
The IQproducerTM can read a modulation waveform pattern generated by
each signal generation application and display it in the time domain
graph with up to four traces.
1.2.6 Clipping function
This function performs clipping processing for a waveform pattern
generated by each signal generation application.

Chapter 2 Installation/Uninstallation
2-1
2
Installation/Uninstallation
This chapter describes how to install/uninstall the IQproducerTM to a PC.
2.1 Operating Environment.............................................. 2-2
2.2 Installation/Uninstallation Procedure ......................... 2-3
2.2.1 Installation procedure .................................... 2-4
2.2.2 Upgrade procedure........................................ 2-6
2.2.3 Uninstallation procedure................................ 2-7

Chapter 2 Installation/Uninstallation
2-2
2.1 Operating Environment
The IQproducerTM requires the following environment.
Table 2.1-1 Operating Environment
PC
OS Windows XP/Windows Vista/Windows 7
CPU At least 1 GHz or faster Pentium III or
equivalent
Memory 512 MB or more
Hard disk 5 GB or more free space in the drive where
this software is to be installed.
Peripheral device
Display Displays with a resolution of 1024 × 768 pixels
are best viewed using a small font setting.
Although the IQproducerTM can be installed and operated in the
MS2690A/MS2691A/MS2692A or MS2830A, operations of the
measurement functions are not guaranteed when the IQproducerTM is
running on the MS2690A/MS2691A/MS2692A or MS2830A.

2.2 Installation/Uninstallation Procedure
2-3
2
Installation/Uninstallation
2.2 Installation/Uninstallation Procedure
The IQproducerTM can be installed interactively by activating the setup
program.
If resident virus check programs are running on your PC, exit them
before activating the IQproducerTM setup program, as well as other
Windows applications in progress.
Note:
If you upgrade the IQproducerTM after the version 3.00 (hereafter
referred to as “new software”) in PC in which the IQproducerTM
before version 2.01 (hereafter referred to as “old software”) is
installed, please execute the setup file of the old software and
uninstall it before executing the setup file of new software.
However, if the short file name support was disabled on your
Windows, old software cannot be uninstalled. In this case,
instead of uninstalling the old software, execute the setup file of
the new software and specify the installation folder of the old
software for the Destination Folder, thereby installing the new
software, while overwriting the old one.
Note:
This software of version 13.00 or later requires you to have
installed Microsoft Visual C++ 2010 Redistributable Package (x86).
In addition, this software of version 13.00 or later does not work on
Windows2000.
Note:
When you run the setup program for IQproducerTM version 14.02
or later (hereafter referred to as “new software”) on the PC to
which IQproducerTM version 14.01 or earlier (hereafter referred to
as “old software”) has been installed, the automatic uninstallation
of the old software starts.
When the old software has been successfully uninstalled, the
installation of the new software starts.
Note:
To downgrade from IQproducerTM version 14.02 or later (hereafter
referred to as “new software”) to IQproducerTM version 14.01 or
earlier (hereafter referred to as “old software”), uninstall the new
software before installing the old software.

Chapter 2 Installation/Uninstallation
2-4
2.2.1 Installation procedure
Follow the procedure below to install the IQproducerTM on the hard disk
of your PC.
<Procedure>
1. Double-click the SETUP.EXE file in the folder where the files of the
IQproducerTM are stored.
When installing the IQproducerTM using the setup disk, double-click
the SETUP.EXE file in the \IQproducer directory of the setup disk.
2. If Microsoft Visual C++ 2010 Redistributable Package (x86) is not
installed to your PC, start the installation of the package.
Figure 2.2.1-1 Installation of the Microsoft Visual C++2010
Redistributable Package
3. When Microsoft Visual C++ 2010 Redistributable Package (x86)
version 10.0.30319 or later has been already installed, the following
confirmation message may appear. If you see the confirmation
message, continue the installation.
Figure 2.2.1-2 Confirmation Message That Appears When the New Version
of Microsoft Visual C++2010 Redistributable Package Is Installed
To check the version information of Microsoft Visual C++ 2010
Redistributable Package (x86), click Control Panel, and then click
Uninstall a program.

2.2 Installation/Uninstallation Procedure
2-5
2
Installation/Uninstallation
4. The IQproducerTM setup program starts. When “Welcome to the
InstallShield Wizard for IQproducer” is displayed on the screen,
click the Next> button.
5. The License Agreement screen is displayed. Read the license
agreement terms, and click the Yes button if you agree with the
contents.
Note that the installation procedure will not continue unless you
agree with the license agreement terms.
6. The directory path in which the software will be installed is
displayed in the Destination Folder field.
When changing the installation folder, click the Browse… button to
open the directory change dialog box, and specify the desired folder.
In this event, be sure to confirm that there is enough free space in
the drive where the target folder belongs to. For free space, refer to
Section 2.1 “Operating Environment.”
The IQproducerTM generates temporary data under the installation
folder.
7. After specifying the installation folder, click the Next> button to
display the folder for storing the program icon in the program folder
selection window. It is also possible to change from this window the
folder for storing the program icon. Click the Next> button to start
installation.
8. When “InstallShield Wizard Complete” is displayed, click the Finish
button.

Chapter 2 Installation/Uninstallation
2-6
2.2.2 Upgrade procedure
Follow the procedure below to upgrade the IQproducerTM.
The upgrade process is run by double-clicking the SETUP.EXE file for
the later version than the version currently installed on your PC.
<Procedure>
1, Double-click the SETUP.EXE file in the folder where the
IQproducerTM is stored. To install using the setup disk for the
IQproducerTM, double-click the SETUP.EXE file stored in the
\IQproducer folder on the setup disk.
2. The installation of Microsoft Visual C++ 2010 Redistributable
Package (x86) begins in the same way as described in step 2 of 2.2.1
“Installation procedure”. Follow step 2 of 2.2.1 “Installation
procedure”.
3. Follow step 3 of 2.2.1 “Installation procedure”.
4. When you see the following message after the IQproducerTM setup
program starts, click the Yes button:
“The setup will perform an upgrade of ‘IQproducer’. Do you want to
continue?”
5. When you see the following message, click the Next button to start
upgrade:
“Resuming the InstallShield Wizard for IQproducer”
6. When you see the following message, click the Finish button:
“Update Complete”
Note:
If you double-click the SETUP.EXE file for the older version than
the version currently installed on your PC, the setup process is
cancelled and you will see the following message:
“A later version of ‘IQproducer’ is already installed on this machine.
The setup cannot continue.”

2.2 Installation/Uninstallation Procedure
2-7
2
Installation/Uninstallation
2.2.3 Uninstallation procedure
Follow the procedure below to uninstall the IQproducerTM from the hard
disk of your PC.
<Procedure>
1. Click the
Start button on the Windows task bar, point Setting, and
click Control Panel.
2. Double-click the
Add or Remove Programs icon.
3. On the
Change or Remove Programs tab, click the IQproducer item
in the Currently Installed Programs list to display it highlighted.
4. Click the
Change/Remove button.
5. When the uninstall program starts, read the message, and click the
OK button.
6. A confirmation message may be displayed during uninstallation,
asking whether to remove a shared file. Select NO unless it is not
certain whether the indicated file is shared by any other programs.
Some programs may not function correctly if a necessary shared file
is removed inadvertently.
7. When “Uninstallation Complete” is displayed, click the Finish
button.
Note:
If a shared file is removed, there is a possibility that other
application programs may not function. Do not remove the shared
file unless it is not certain whether the indicated file is shared or
not.
Even if a shared file is removed inadvertently, it may be restored
by installing the IQproducerTM again.
If the short file name support was disabled on your Windows,
IQproducerTM before version 1.02 cannot be uninstalled.

Chapter 2 Installation/Uninstallation
2-8.
