Anritsu VNA Master MS2024B User manual

VNA Master
User Guide
MS2024B, MS2025B, MS2034B, and MS2035B
Handheld Compact Vector Network Analyzer

User Guide
VNA Master™ Model MS20xxB
Vector Network Analyzer with
Spectrum Analyzer
MS2024B
VNA Frequency: 500 kHz to 4 GHz
MS2025B
VNA Frequency: 500 kHz to 6 GHz
MS2034B
VNA Frequency: 500 kHz to 4 GHz,
Spectrum Analyzer, 100 kHz to 4 GHz
MS2035B
VNA Frequency: 500 kHz to 6 GHz,
Spectrum Analyzer, 100 kHz to 6 GHz
Anritsu Company
490 Jarvis Drive
Morgan Hill, CA 95037-2809
USA
Part Number: 10580-00301
Revision: D
Published: March 2013
Copyright 2010 - 2013 Anritsu Company

MS20xxB UG PN: 10580-00301 Rev. D Title-3
