ANTAIRA IMP-C1000-SFP-bt-24 Series User manual

Antaira Technologies
IMP-C1000-SFP-bt-24 Series
Industrial Gigabit IEEE 802.3bt Ethernet-to-Fiber Media
Converter, 1*10/100/1000Tx RJ45 (90W/Port) to 1*100/1000 SFP
Slot; 12~55VDC Power Input
Quick Installation Guide
Version 1.0
(April 2020)
Tel: [phone]
Fax: [phone]
www.antaira.com
19020000000131
Package Check List
The package contains the following items:
Quick Installation Guide
IMP-C1000-SFP-bt-24(-T)
Wall mounting bracket set with screws
DC cable –18 AWG & DC jack 5.5x2.1mm
Front Panel Layout
Top Panel View
IMP-C1000-SFP-bt-24 series top panel is equipped with one
4-pin removal terminal block connector for dual DC power inputs
(12~55VDC).
Product Overview
System Interface/Performance
RJ45 port support the auto MDI/MDI-X function
Ethernet RJ45 port connectivity 1*10/100/1000Tx (w/PSE:
90W/port)
Fiber connectivity with 1*100/1000Fx SFP slot
Store-and-forward switching architecture
Supports 10Kbytes Jumbo Frame
Power Input & Connection
DC 12~55VDC redundant power, with a 4-pin removal
terminal block
Max. current: 7A
Max. PoE output: 90W
It is recommended to using UL listed Industrial Power
Supply
Operating Temperature
Standard operating temperature model: -10°C ~ 65°C
Extended operating temperature model (–T): -40°C ~ 75°C
Case/Installation
IP30 protection
DIN-Rail and wall mount design
Safety Precaution
If the DC voltage is supplied by an external circuit, please use a
protection device on the power supply input.
LED Indicators
LED
Color
Description
Power
Green
On
Power input 1 or 2 is active
Off
Power input 1 and 2 are inactive
AT PoE
Green
On
IEEE 802.3af/at connection
Off
No powered-device attached or power supplying fails
BT PoE
Blue
On
IEEE 802.3bt connection
Flashing
1. PoE over current or cable short
2. Invalid connection check signature or connection-
check error is detected
Off
No powered-device attached or power supplying fails
RJ45 Port
(Upper LED)
Green
On
Linked to network at 1000Mbps
Flashing
Networking is active
Off
Not connected to network
RJ45 Port
(Lower LED)
Green
On
Linked to network at 10/100Mbps
Flashing
Networking is active
Off
Not connected to network
SFP Port
Link/Act
Green
On
Connected to network, 100/1000Mbps
Flashing
Networking is active
Off
Not connected to network
DIP-Switching Setting
There are 3 sets of DIP‐switches on the front panel that are
responsible for the settings of PRRT (PD Remote Reset
Technology) function, LFP (Link Fault Pass) function, and SFP
transmission rate.
DIP-Switch Number
ON
OFF
1
PRRT Enabled
PRRT Disabled
2
LFP Enabled
LFP Disabled
3
SFP 100Fx
SFP 1000Fx
Note: After any DIP switch changes have been made, it is
required to power cycle the unit for the changes to take
effect.
Quick Installation
Ethernet RJ45 Port (Auto MDI/MDIX)
RJ-45 port is auto-sensing for 10Base-T, 100Base-TX or
1000Base-TX devices connections. Please follow the wiring pin
assignment table below for Ethernet port installation.
RJ45 Ethernet Port Pin Outs
Pins
T568A Color
T568B Color
10/100
Base-T(X)
1000
Base-T
PoE
1
White/Green
White/Orange
Rx+
TP0+
DC+
2
Green
Orange
Rx-
TP0-
DC+
3
White/Orange
White/Green
Tx+
TP1+
DC-
4
Blue
Blue
unused
TP2+
5
White/Blue
White/Blue
unused
TP2-
4-Pin Removal Terminal Block (Power Input)
100/1000Fx SFP slot
Grounding Screw
DIP Switch
LED for RJ45 Link/Activity
1000Mbps
LED for Power, at PoE, and bt PoE
10/100/1000TX RJ45 port
LED for SFP Link/Activity
LED for RJ45 Link/Activity
10/100Mbps

6
Orange
Green
Tx-
TP1-
DC-
7
White/Brown
White/Brown
unused
TP3+
8
Brown
Brown
unused
TP3-
SFP Slots
The small form-factor pluggable (SFP) is a compact optical
transceiver used in optical communications.
Please follow steps below for connecting the SFP and LC cable:
1. Insert the SFP transceiver module into the SFP slot as
shown below in Figure 1 (Notice that the triangle mark is at
the bottom of the SFP slot). Figure 2 shows SFP transceiver
module was inserted.
Figure 1 Figure 2
2. Insert the fiber cable of the LC connector into the transceiver
as shown below in Figure 3.
Figure 3
Power Inputs Wiring
Please follow the steps below to insert the power wire:
1. Insert the positive and negative wires into the PWR1
(V1+, V1-) and PWR2 (V2+, V2-) contacts on the
terminal block connector as shown below in Figure 4.
2. Tighten the wire-clamp screws to prevent the wires from
loosening, as shown below in Figure 5.
V1-V1+ V2-V2+
Figure 4 Figure 5
Industrial Switch Mounting
DIN-Rail Mounting
The DIN-Rail bracket is pre-installed on the industrial Ethernet
switch from the factory. Please refer to Figure 6 for DIN-Rail
bracket installation reference.
Follow below steps for installing the industrial switch on the
DIN-Rail track:
1. Insert the top of the DIN-Rail onto the track as shown below
in Figure 7.
2. Lightly pull down the bracket onto the rail as shown below in
Figure 8.
3. Check if the bracket is mounted tightly on the rail.
4. To remove the industrial
Ethernet
switch from the rail, do the
opposite from the above steps.
Figure 7 Figure 8
Wall Mounting
Follow the steps below to mount the industrial Ethernet switch
using the wall mounting bracket as shown below in Figure 9.
1. Remove the DIN-Rail bracket from the industrial Ethernet
switch by loosening the screws.
2. Place the wall mounting
brackets on the top and bottom
of the industrial Ethernet
switch.
3. Use the screws to screw the
wall mounting bracket on the
industrial Ethernet switch.
4. Use the hook holes at the
corners of the wall mounting
bracket to hang the industrial
Ethernet switch on the wall.
5. To remove the wall mount
bracket, do the opposite from
the steps above. Figure 9
Field Maintenance and Service
If the device requires servicing of any kind, the user is
required to disconnect and remove it from its mounting. The
initial installation should be done in a way that makes this as
convenient as possible.
Voltage/power lines should be properly insulated as well as
other cables. Be careful when handling them so as to not trip
over.
Do not under any circumstance insert foreign objects of any
kind into the heat dissipation holes located in the different
faces of the device. This may not only harm the internal
layout, but might cause harm to user as well.
Do not under any circumstance open the device for any
reason. Please contact your dealer for any repair needed or
follow the instructions within the manual.
Warranty Policy
Warranty Conditions
Products supplied by Antaira Technologies are covered in this
warranty for sub-standard performance or defective
workmanship. The warranty is not, however, extended to goods
damaged in the following circumstances:
(a) Excessive forces or impacts
(b) War or an Act of God: wind storm, fire, flood, electric shock,
earthquake
(c) Use of unqualified power supply, connectors, or
unauthorized parts/kits
(d) Replacement with unauthorized parts
RMA and Shipping Costs Reimbursement
Customers shall always obtain an authorized "RMA" number
from Antaira before shipping the goods for repair or
replacement.
Within the warranty period (based on the invoice date), all
parts and labor are free of charge to the customers.
Customers are required to be responsible for the cost of
parts and labor if the products are out of warranty.
For RMA service, customers are required to be responsible
for the shipping expense for shipping the RMA unit(s) to
Antaira; and Antaira will be responsible for the shipping
expense by ground service for the return repair/replace
unit(s) back to customers.
Limited Liability
Antaira would not be held responsible for any consequential
losses from using Antaira’s product.
Warranty Period
5-Year Warranty
Antaira’s Customer Service and Support
Antaira’s Technical Service & Support Centers:
+ 844-268-2472 (Antaira US Headquarter)
+ 48-22-862-88-81 (Antaira Europe Office)
+ 886-2-2218-9733 (Antaira Asia Office)
Antaira’s Web Sites & Repair/Support Emails:
www.antaira.com / [email protected]
www.antaira.eu / i[email protected]
www.antaira.com.tw / [email protected]
*Any changes will be announced on the Antaira website.
