ANTAIRA LNP-C500G User manual

Antaira Technologies
LNP-C500G Series
Compact 5-Port Industrial Gigabit PoE+ Unmanaged Ethernet
Switch, w/4*10/100/1000Tx (PSE: 30W/Port) + 1*10/100/1000Tx
Quick Installation Guide
Version 1.1
(July 2021)
Tel: [phone]
Fax: [phone]
www.antaira.com
19020000000011
Package Check List
The package contains the following items:
⚫1 - Quick Installation Guide
⚫1 - LNP-C500G(-T)
⚫1 - Wall mounting bracket set with screws
⚫1 - DC cable –18 AWG & DC jack 5.5 x 2.1mm
⚫1 - Dust cover set
Front Panel Layout
Top Panel View
LNP-C500G series top panel is equipped with one 4-pin removal
terminal block connector for dual DC power inputs (48~55 VDC).
Product Overview
System Interface/Performance
All RJ-45 ports support the auto MDI/MDI-X function
Ethernet connectivity 4*10/100/1000Tx (PSE: 30W/Port)
RJ45 ports + 1*10/100/1000Tx RJ45 port
Store-and-forward switching architecture
8K MAC address table
Jumbo frame supports up to 10Kbytes
1Mbits memory buffer
Power Input & Connection
DC 48~55V redundant power with a 4-pin removal terminal
block
It is recommended to use a UL listed Industrial Power
Supply
Operating Temperature
Standard operating temperature model: -10°C to 70°C
Extended operating temperature model: -40°C to 75°C
Case/Installation
IP30 protection
DIN-rail and wall mount design
LED Indicators
LED
Color
Description
Power
Green
On
Power input 1 or 2 is active
Off
Power input 1 and 2 are inactive
PoE
(Port 1-4)
Green
On
The port is supplying power to the
powered-device
Off
No powered-device attached or power
supply fails
LAN Port 1~5
(Upper LED)
Green
On
Connected to network, 1000Mbps
Flashing
Networking is active
Off
Not connected to network
LAN Port 1~5
(Lower LED)
Green
On
Connected to network, 10/100Mbps
Flashing
Networking is active
Off
Not connected to network
Quick Installation
Ethernet Port
RJ45 Ports (Auto MDI/MDIX)
All RJ-45 ports are auto-sensing for 10Base-T, 100Base-TX, or
1000Base-T device connections. Please follow the below wiring
pin assignment table for Ethernet port installation.
RJ45 Ethernet Port Pin Outs
Pins
T568A Color
T568B Color
10Base-T,
100Base-TX
1000
Base-T(X)
Pin 1
white/green stripe
white/orange stripe
Rx+
TP0+
Pin 2
green solid
orange solid
Rx-
TP0-
Pin 3
white/orange stripe
white/green stripe
Tx+
TP1+
Pin 4
blue solid
blue solid
unused
TP2+
Pin 5
white/blue stripe
white/blue stripe
unused
TP2-
Pin 6
orange solid
green solid
Tx-
TP1-
Pin 7
white/brown stripe
white/brown stripe
unused
TP3+
Pin 8
brown solid
brown solid
unused
TP3-
Grounding Screw
4-Pin Removal Terminal Block
(Power Input)
LED for Power
LAN# 1~5 –LED for
1000Mbps
LAN# 1~4 –10/100/1000Tx
RJ45 w/ PoE+
LAN# 1~5 –LED for
10/100Mbps
LAN# 5 –10/100/1000Tx RJ45
LED for PoE

Power Inputs Wiring
Please follow the below steps to insert the power wire:
1. Insert the positive and negative wires into the PWR1
(V1+, V1-) and PWR2 (V2+, V2-) contacts on the
terminal block connector as shown below in Figure 1.
2. Tighten the wire-clamp screws to prevent the wires from
loosening, as shown below in Figure 2.
V1-V1+ V2-V2+
Figure 1 Figure 2
Industrial Switch Mounting
DIN-Rail Mounting
The DIN-Rail bracket is pre-installed on the
industrial Ethernet switch from the factory.
Please refer to Figure 3 for DIN-Rail bracket
installation reference.
Follow below steps for installing the
industrial switch on the DIN-Rail track:
1. Insert the top of the DIN-Rail on to the
track as shown below in Figure 4.
2. Lightly pull down the bracket on to the
rail as shown below in Figure 5.
3. Check if the bracket is mounted tightly on the rail.
4. To remove the industrial
Ethernet
switch from the rail, do the
opposite from the above steps.
Figure 4 Figure 5
Wall Mounting
Follow the steps below to mount the industrial Ethernet switch
using the wall mounting bracket as shown below in Figure 6.
1. Remove the DIN-Rail bracket from the industrial Ethernet
switch by loosening the screws.
2. Place the wall mounting brackets on the top and bottom of
the industrial Ethernet switch.
3. Use the screws to screw the wall mounting bracket onto the
industrial Ethernet switch.
4. Use the hook holes at the corners of the wall mounting
bracket to hang the industrial Ethernet switch on the wall.
5. To remove the wall mount bracket, do the opposite from the
steps above.
Figure 6
Field Maintenance and Service
⚫If the device requires servicing of any kind, the user is
required to disconnect and remove it from its mounting. The
initial installation should be done in a way that makes this as
convenient as possible.
⚫Voltage/Power lines should be properly insulated as well as
other cables. Be careful when handling them so as to not trip
over.
⚫Do not under any circumstance insert foreign objects of any
kind into the heat dissipation holes located in the different
faces of the device. This may not only harm the internal
layout, but might cause harm to user as well.
⚫Do not under any circumstance open the device for any
reason. Please contact your dealer for any repair needed or
follow the instructions within the manual.
Warranty Policy
Warranty Conditions
Products supplied by Antaira Technologies are covered in this
warranty for sub-standard performance or defective
workmanship. The warranty is not, however, extended to goods
damaged in the following circumstances:
(a) Excessive forces or impacts
(b) War or an Act of God: wind storm, fire, flood, electric shock,
earthquake
(c) Use of unqualified power supply, connectors, or
unauthorized parts/kits
(d) Replacement with unauthorized parts
RMA and Shipping Costs Reimbursement
Customers shall always obtain an authorized "RMA" number
from Antaira before shipping the goods for repair or
replacement.
•Within the warranty period (based on the invoice date), all
parts and labor are free of charge to the customers.
•Customers are responsible for the cost of parts and labor, if
the products are out of warranty.
•For RMA service, customers are responsible for the shipping
expense for shipping the RMA unit(s) to Antaira. Antaira is
responsible for the shipping expense via a ground service
for the return repair/replace unit(s) back to customers.
Limited Liability
Antaira would not be held responsible for any consequential
losses from using Antaira’s product.
Warranty Period
5-Year Warranty
Antaira’s Customer Service and Support
•Antaira’s Technical Service & Support Centers:
+ 844-268-2472 (Antaira US Headquarter)
+ 48-22-862-88-81 (Antaira Europe Office)
+ 886-2-2218-9733 (Antaira Asia Office)
•Antaira’s Web Sites & Repair/Support Emails:
www.antaira.com / [email protected]
www.antaira.eu / [email protected]
www.antaira.com.tw / [email protected]
*Any changes will be announced on the Antaira website.
Figure 3
