ANT-6000X
Specification & User Manual
Version 1.5

Details subject to change and Firmware version
2
ANT-6000X (ANT-6000E & ANT-6000D)
ANT-6000E
Front view!
ANT-6000E
Rear view!
ANT-6000D
Front view!
ANT-6000D
Rear view!

Details subject to change and Firmware version
ANT-6000X - Connection
3
Multimedia
Player
TV or Monitor
ANT-6000E ANT-6000D
HD-SDI
or
HDMI
or
D-sub Ethernet
HD-SDI
or
HDMI
or
D-sub

Details subject to change and Firmware version
4
ANT-6000X (ANT-6000E/ANT-6000D) Main Highlights
 1080p60 full HD encode/decode with H.264 Baseline Profile (Level 4.2)
• Supports both interlacing and progressive input streams
 Very low encode/decode latency
• Latency of encode-decode in 1080p60 HD: 90 ms
 PC2TV: Supports both DTV & VESA Standards
• DTV: 1920x1080i60/p60, 1280x720p60, 720x480i60/p60
• VESA:HD 1080 (1920x1080), WSXGA+(1680x1050), SXGA(1280x1024), WXGA(1280x800), XGA(1024x768), SVGA
(800x600), VGA(640x480)
 High-end solution of the Ethernet full HD with 40Mbit/s of video encoding rate
 Full HD real-time streaming server over Internet (RTSP/RTP/UDP or MPEG-2 TS/UDP)
• Maximum video encoding rate of RTSP/RTP/UDP streaming: 30 ~ 40Mbps
• Maximum video encoding rate of MPEG-2 TS/UDP streaming: ~ 15Mbps
 HD-SDI & 3G-SDI Interface
 Supports either high quality 16-bit 48kHz audio or bandwidth efficient G.711 audio (64kbps or 128
kbps)
 Back channel audio
 Video out with video scaler
• Support various video outputs on the ANT-6000D

Details subject to change and Firmware version
5
Encoder (ANT-6000E)
 Video Input
• HDMI(DVI): up to 1080p60, HDMI v1.3 compatible
• RGB (D-Sub): VESA formats up to 1280 x 1024 and 1920 x 1080p60
• HD-SDI & 3G-SDI: up to 1080i60/p60
 Audio Input
• HDMI : HDMI compatible audio, Compressed or Uncompressed
• HD-SDI & 3G-SDI: SDI compatible audio
• Stereo Audio : Analog, 44.1kHz/48kHz 16-bit ADC
- Stereo Phone Jack
 Back Channel Audio Output
• Stereo Audio : Analog, 44.1kHz/48kHz 16-bit DAC
- Stereo Phone Jack
 Encoding of Moving Pictures
• H.264 (MPEG-4 Parts10: AVC)
• Baseline Profile with Level 4.2 (up to 1920 x 1080p60)
 Ethernet Output for Audio/Video
• 10/100 BASE-Encoder, Cat.5 UTP cable
• Power Of Ethernet (Max. 13W): Option
 USB for Engineering use
 Serial port for bi-directional remote operation

Details subject to change and Firmware version
6
Decoder (ANT-6000D)
 Video Output
• HDMI: up to 1080p60, HDMI v1.3 compatible
• RGB (D-Sub): VESA formats up to 1280 x 1024 and 1920 x 1080p60
• HD-SDI & 3G-SDI: up to 1080i60/p60
• COMPONENT (YPbPr) (using gender): All HDTV formats up to 1080i60
 Audio Output
• HDMI: HDMI compatible audio
• Stereo Audio : Analog, 44.1kHz/48kHz 16-bit DAC
- Stereo Phone Jack & Stereo RCA Jack
 Back Channel Audio Input
• Stereo Audio : Analog, 44.1kHz/48kHz 16-bit ADC
- Stereo Phone Jack
 Decoding of Moving Pictures
• H.264 (MPEG-4 Parts10: AVC)
• Baseline Profile with Level 4.2 (up to 1920 x 1080p60)
 Ethernet Input for Audio/Video
• 10/100 BASE-Encoder, Cat.5 UTP cable (150m)
• Power Over Ethernet (Max. 13W): Option
 USB for Engineering use.
 Serial port for bi-directional remote operation

Details subject to change and Firmware version
7
Video Format Supported: VESA & DTV
Video Standard Resolutions HDMI D-SUB COMP SDI
PC Format
(VESA or Industrial)
640 x 480P 60/70/72/75/85 O O X X
800 x 600P 56/60/72/70/75/85 O O X X
1024 x 768P 60/70/72/75/85 O O X X
1152 x 864P 60/70/75/85 O O X X
1280 x 800P 60 O O X X
1280 x 960P 60/70/72/75/85 O O X X
1280 x 1024P 60/70/75/85 O O X X
1360 x 768P 60 O X X X
1366 x 768P 60 O X X X
1440 x 900P 60 O X X X
1440 x 1050P 60 O X X X
1600 x 1200P 60/R60 O O X X
1600 x 900P 60 O X X X
1680 x 1050P 60/R60 O x X X
1920 x 1080P R60 O O X O
TV Format
(DTV or SMPTE)
720 x 480I60(NTSC) O O O O
720 x 576I50(PAL) O O O O
720 x 480P60 O O O X
720 x 576P50 O O O X
1280 x 720P50 O O O O
1280 x 720P60 O O O O
1920 x 1080I50 O O O O
1920 x 1080I60 O O O O
1920 x 1080P24 O O X O
1920 x 1080P25 O X X O
1920 x 1080P30 O X X O
1920 x 1080P50 O O O O
1920 x 1080P60 O O O O

Details subject to change and Firmware version
8
Common Specifications
Video Compression
H.264 Baseline Profile Level 4.2
Video Resolutions (partial list)
480i/p, 720p, 1080i and 1080p (24fps/30fps/60fps)
System Latency
Less than 90 millisecond Delay between Transmitter and Receiver
Ethernet LAN
10/100 BASE-Encoder, car.5e UTP cable
Optional: PoE (Max. power 13W)
USB
Upgrade SW firmware
Optional: 3G/LTE wirless network
Power Supply
6 - 12V/1.5A DC
Dimensions (H x W x D, mm)
Board: 28 x 175 x 100, Enclosure: 30 x 184 x 101
Weight (g)
Encoder
400g (with case), 140g (without case)
Decoder
400g (with case), 140g (without case)
Operating Temperature
Operating from 0°C ~ 40°C
Storage Temperature
Storage from -20°C ~ 60°C

Details subject to change and Firmware version
ANT-6000E/D specification
9
ANT-6000E spec
Digital Video IN Interface
1 x HDMI
HDMI-v1.3 compatible, Up to 24 bit RGB or YUV (4:2:2)
1 x HD-SDI
Female BNC, 3G-SDI(2.970Gb/s), HD-SDI(1.485Gb/s), SD-SDI(270Mb/s)
Analog Video IN Interface
1 x D-Sub (15pin)
RGB Video with D-Sub, YPbPr with D-Sub to component gender
Digital Audio IN Interface
HDMI, HD-SDI
2 Ch Linear PCM, DTS 5.1 Ch., AC3 5.1 Ch.
Analog Audio IN Interface
Mini Stereo headphone Jack
48 kHz sampling with 16bits resolution
Back channel Audio OUT Interface
Mini Stereo headphone Jack
48 kHz sampling with 16bits resolution
ANT-6000D spec
Digital Video OUT Interface
1 x HDMI
HDMI-v1.3 compatible, Up to 24 bit RGB or YUV (4:2:2)
1 x HD-SDI
Female BNC, 3G-SDI(2.970Gb/s), HD-SDI(1.485Gb/s), SD-SDI(270Mb/s)
Analog Video OUT Interface
1 x D-Sub (15pin)
RGB Video with D-Sub, YPbPr with D-Sub to component gender
Digital Audio OUT Interface
HDMI, HD-SDI
2 Ch Linear PCM, DTS 5.1 Ch., AC3 5.1 Ch.
Analog Audio OUT Interface
Mini Stereo headphone Jack
48 kHz sampling with 16bits resolution
Back channel Audio IN Interface
Mini Stereo headphone Jack
48 kHz sampling with 16bits resolution
SDI signal Formats
SMPTE-425M-A/B
1080p (60/59.94/50/30/29.97/25/24/23.98)
SMPTE-274M
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/23.98)
SMPTE-296M
720p (60/59.94/50)
SMPTE-259M-C
576i (50) / 487i (59.94)
ITU-R BT.656
SD format
ITU-R BT.709 and BT.1120-6
1125 line format

Details subject to change and Firmware version
ANT-6000E/D Video Outputs
10
Output Mode (HDMI Colour space)
SDI
HDMI
RGB
YPbPr
Analog
Audio
Video
Audio (1)
Video
Audio
HDMI (RGB)
Colour
mismatch
OK
OK
OK
OK
No Out
OK
HDMI (YPbPr)
OK
OK
OK
OK
Colour
mismatch
OK
OK
DSUB
No Out
No Out
OK
OK
OK
No Out
OK
Component
OK
OK
OK
OK
Colour
mismatch
OK
OK
HDSDI
OK
OK
OK
OK
Colour
mismatch
OK
OK

Details subject to change and Firmware version 11
Boards of Encoder (ANT-6000E)/Decoder (ANT-6000D)
Encoder!Decoder!
LAN +12.0V
POWER
Back Ch.
Audio
RS-2
32C
USB
HD-SDI
HDMI
D-Sub
Audio
out
LAN +12.0V
POWER
Back Ch.
Audio
RS-2
32C
USB
HD-SDI
HDMI
D-Sub
Audio
In

Details subject to change and Firmware version
ANT-6000X Front LED & Rear Connector
12

Details subject to change and Firmware version
LED Description
13
ANT-6000E
ON
OFF
Blinking
Power
RED
Power on
Power off
-
Link
YEL
-
-
Link up status and data transmit
HD-SDI
GRN
Selected and input normal
Not Selected
Selected and No input
HDMI
GRN
Selected and input normal
Not Selected
Selected and No input
RGB
GRN
Selected and input normal
Not Selected
Selected and No input
ANT-6000D
ON
OFF
Blinking
Power
RED
Power on
Power off
-
Link
YEL
Link up status and data transmit
-
-
HD-SDI
GRN
Selected and output normal
Not Selected
Selected and No output
HDMI
GRN
Selected and output normal
Not Selected
Selected and No output
RGB
GRN
Selected and output normal
Not Selected
Selected and No output

Details subject to change and Firmware version
LED operation at booting
14
ANT-6000E
Link LED
Video Port LED (HD-SDI, HDMI, RGB)
Time
Power LED ON
Blinking
3 x LED Blinking
4~5sec
Booting
Blinking
LED Off
40~45sec
Blinking
Blinking
60~65sec
Normal operation
Fast Blinking
LED On
90~95sec
ANT-6000D
Link LED
Video Port LED (HD-SDI, HDMI, RGB)
Time
Power LED ON
Blinking
3 x LED Blinking
4~5sec
Booting
Blinking
LED Off
40~45sec
Normal operation
LED On
LED On
90~95sec

Details subject to change and Firmware version
Factory Reset
15
 Factory reset will be started by pushing SEL button more than 20 seconds.
 All LEDs except power LED will blink fast, then you can release the button.
 It will reboot after 2~3 minutes.
 The IP address will be set to default value of 192.168.0.161 for ANT-6000E, and 192.168.0.162
for ANT-6000D.

Details subject to change and Firmware version
Web Based Interface
16
 System Configuration
 Serial port Configuration
 FW Images
 Streaming Control
 Save changes
 Reboot System

Details subject to change and Firmware version
System Configuration
17

Details subject to change and Firmware version
Changing IP address of the ANT-6000E or ANT-6000D
18
 Default IP address of the ANT-6000E and ANT-6000D were set to 192.168.0.161 for ANT-6000E
(Encoder) and 192.168.0.162 for ANT-6000D (Decoder). So, if this IP address is used by other IP devices
on the same network, then you have to change the IP address to another one through the web interface of
the Encoder and Decoder. You can connect to the embedded web page of the Encoder/Decoder with
Encoder/Decoder’s IP address via Internet Explorer. Please connect a laptop or PC to the Encoder
(Decoder) with a CAT5e Ethernet cable directly. And enter the below IP address on the URL of Internet
Explorer/Chrome.
Example of the Encoder) http://192.168.0.161
Example of the Decoder) http://192.168.0.162
1. Change the IP address using “Ethernet IP”, “Ethernet NetMask” & “Gateway” to correct values, page 18 of this user guide.
2. Save the changed IP address, page 39.
3. Enter the new IP address of the ANT-6000E on the URL of Internet Explorer.
4. Same changes should be repeated to the ANT-6000D.
 And, if you did change the Encoder or Decoder IP address, you have to input the “Peer IP (lan)” in the “Syst
em Configuration” page. New IP address of the Decoder must be entered in to the Encoder’s
“Peer IP(lan)” field, and the new IP address of Encoder must be entered on to the Decoder’s
“Peer IP(lan)” value.

Details subject to change and Firmware version
System Configuration (Encoder)
19
Streaming Mode : P2P/Multicast!
Multicast address when Multicast
mode!
Peer address when P2P mode!
Ethernet Configurations!
Click ‘Submit’ to activate the
changes of Configuration!
Click ‘Refresh’ to display
current status!
Count value for Multicast Time To
Live!
ANT-6000X

Details subject to change and Firmware version
System Configuration (Encoder) – P2P mode
20
Select P2P!
Enter Peer address!
ANT-6000X
