Aolait AL440RX User manual

1
440W Beam Spot Wash With CMY Moving Head
USER MANUAL

2
***Please carefully read this user manual in its entirety and keep it safe for future reference. It is
essential to know the information and comply with the instructions given in this manual to ensure
the fitting is installed, used and serviced or correctly and safely.
一：First, check the package:
Because the light in the purchase process must carry through the process of long-distance
transportation. To ensure that you receive the light, please when receiving goods , please
check the accessories of light.
二、Lighting packaging accessories
Power cable *1
Signal cable *1
manual *1
Certificate *1（On the light）
SAFETY INFORMATION
•Minimum distance from flammable materials
The projector must be positioned so that any flammable materials are at least 0.20 meters (8")
from every point on the surface of the fitting.
•Mounting surfaces
It is impermissible to mount the fitting on normally flammable surfaces.
•Protection against electrical shock
Connection must be made to a power supply system fitted with efficient earthing (class I
appliance according to standard EN 60598-1). It is, moreover, recommended to protect the
supply lines of the projectors from indirect contact and/or shorting to earth by using
appropriately sized residual current devices.
•Connection to mains supply
Connection to the electricity mains must be carried out by a qualified electrical
installer.
Check that the mains frequency and voltage correspond to those for which the projector is
designed as given on the electrical data label.
This label also gives the input power to which you need to refer to evaluate the maximum
number of fittings to connect to the electricity line, in order to avoid overloading.
•Temperature of the external surface
The maximum temperature that can be reached on the external surface of the fitting, in a
thermally steady state, is 100°C (212°F).

3
•Maintenance
Before starting any maintenance work or cleaning the projector, cut off power from the main
supply.
After switching off, do not remove any parts of the fitting, to avoid getting burnt for at least
35minutes. After this time the likelihood of the lamp exploding is virtually nill.
The fitting is designed to hold in any splinters produced by a lamp exploding.The lenses must
be mounted and, if visibly damaged, they have to be replaced with genuine spares.
MECHANICAL DETAILS
Specification
Input：100-240V 50HZ-60HZ
Power：700W
Light source：Yodn 440W，OSRAM470W
Working lifetime：average lifetime 1500 hours
Color temperature：7800K
Total Output (Lumen)：23600LM
Control mode：DMX512,RDM，Sound，Auto，Master-slave
LCD display：LCD color touch display + button
DMX Channel：
XY: X540°Y270°16BIT Precise control +Fast and quiet 3-phase motors＋stable and quiet
Dimmer：0-100% ,16-bit, mechanical dimming
Strobe：0.5-20 Hz ,synchronized, pulse effects
Beam angle：2.5°beam mode
Spot angle：3°-62°spot mode
Effect wheel rainbow effect＋frost
CMY/CTO：CMY color mixing system，2 CTO（3200K and 2500K）
Focus: motorized focus
Prism：8 + 16-facet prism, CW/CCW rotation（Standard，customized is availbale)Auto focusing
when zooming
Color wheel：13 colors + open
Fixed gobo wheel：14 gobos + open（Gobo customized is available）
Rotating wheel：7 interchangeable gobos + open（Gobo customized is available）
Animation wheel：3 animation wheel＋open (can make special dynamic flame or water effect)
Electronic system:Switch the light bulb through the console，Electronic automatic monitoring of
reset failure，Detection of Fan Speed
Energy saving mode：When the light is closed, the power decreases automatically.
Suitable：stage、perform，event ，culb，show etc.
DMX data input/output: Chassis 3-pin and 5-pin Neutrik XLR (in/out)
AC power: powerCon in and out.
Cooling cystem：High Speed Mute Fan with Multiple Flame Retardant Rollers
Appearance: Superalloy Resistant Plastics
IP：IP20
N.W.：23KG

4
Product size：380*300*710MM
Display Description
MainMenu
Second Menu
Third Menu
Forth Menu
Settings
Dmx Address
1 - 512
Fixture Set
Dmx Mode
STD / EXT
Run Mode
DMX / Host
Pan Inverse
Close / Open
Tilt Inverse
Close / Open
Lamp Open
Close / Open
Display
Language
CH / EN
Display Flip
Close / Open
Display Mode
Show / 60s
Reset
Reset
Cance / Run
Factory
Cance / Run
Info
Time
Current Time
xxxH
Show Time
xxxH
Power Count
xxx
Sensor
xxxxxx
Software Version
Panel
Vx.xxx
Motor_XY
Vx.xxx
Motor
Vx.xxx
Manual
Pan
0 - 255
PanFine
0 - 255
Tilt
0 - 255
TiltFine
0 - 255
.
.
.
.
.
.
Password
0 - 255
Pan
0 - 255
Tilt
0 - 255
Dim
0 - 255
Cyan
0 - 255
Magenta
0 - 255
Yellow
0 - 255
Color
0 - 255
FixGobo
0 - 255
Effect
0 - 255

5
Factory
Rot Gobo
0 - 255
Gobo Rot
0 - 255
Color7
0 - 255
Frost
0 - 255
PrismZoo
0 - 255
Prism1
0 - 255
Prism1Ro
0 - 255
Prism2
0 - 255
Prism2Ro
0 - 255
Focus
0 - 255
Zoom
0 - 255
Channel Description
Standard
mode
Simple mode
DMX Value
Function
1
1
0-255
Pan
2
2
0-255
Pan Low
3
3
0-255
Tilt
4
4
0-255
Tilt Low
5
5
0-255
P/T Speed
6
6
Function
50－99
Reset
100－149
Lamp Off
150－199
Lamp On
7
7
Shutter
0-3
Closed
4-103
SLOW STROBE -> FAST STROBE
104-107
Open
108-207
SLOW STROBE -> FAST STROBE
208-212
Open
213-251
RANDOM STROBE SLOW -> FAST
252-255
Open
8
8
Dimmer
0－255
Linear Dimmer
9
9
0-255
CMY open
10
10
0－255
CMY-C
11
11
0－255
CMY-M
12
12
0－255
CMY-Y
13
13
0－127
reserve
128－255
CTO

6
14
14
0-255
CMY color Mixed
15
15
Macro Colour
0-4
white
5-9
Colour 1
10-14
Colour 2
15-19
Colour 3
20-24
Colour 4
25-29
Colour 5
30-34
Colour 6
35-39
Colour 7
40-44
Colour 8
45-49
Colour 9
50-54
Colour 10
55-59
Colour 11
60-64
Colour 12
65-69
Colour 13
70-74
Colour 14
75-79
Colour 15
80-84
Colour 16
85-89
Colour 17
90-94
Colour 18
95-99
Colour 19
100-104
Colour 20
105-109
Colour 21
110-114
Colour 22
115-119
Colour 23
120-124
Colour 24
125-129
Colour 25
130-134
Colour 26
135-139
Colour 27
140-194
FAST ROTATION - SLOW ROTATION
195-200
STOP
201-255
SLOW ROTATION - FAST ROTATION
16
/
0-255
Color Fine--Linear
Static Gobo
0-3
white
4-9
Gobo 1
10-15
Gobo 2
16-21
Gobo 3
22-27
Gobo 4
28-33
Gobo 5
34-39
Gobo 6
40-45
Gobo 7

7
17
16
46-51
Gobo 8
52-57
Gobo 9
58-63
Gobo 10
64-69
Gobo 11
70-75
Gobo 12
76-81
Gobo 13
82-87
Gobo 14
88-95
Gobo 1 Jitter
96-103
Gobo 2 Jitter
104-111
Gobo 3 Jitter
112-119
Gobo 4 Jitter
120-127
Gobo 5 Jitter
128-135
Gobo 6 Jitter
136-143
Gobo 7 Jitter
144-151
Gobo 8 Jitter
152-159
Gobo 9 Jitter
160-167
Gobo 10 Jitter
168-175
Gobo 11 Jitter
176-183
Gobo 12 Jitter
184-191
Gobo 13 Jitter
192-201
white
202-227
FAST ROTATION - SLOW ROTATION
228-229
STOP
230-255
SLOW ROTATION - FAST ROTATION
18
17
Animation Gobo
0-4
white
5-9
white
10-39
Gobo1
40-69
Gobo2
70-99
Gobo3
100-129
FAST ROTATION - SLOW ROTATION
130-135
STOP
136-165
SLOW ROTATION - FAST ROTATION
166-195
Gobo 1 Jitter
196-225
Gobo 2 Jitter
226-255
Gobo 3 Jitter
Rotation Gobo
0-9
white
10-19
Gobo 1
20-29
Gobo 2
30-39
Gobo 3
40-49
Gobo 4
50-59
Gobo 5

8
19
18
60-69
Gobo 6
70-79
Gobo 7
80-94
Gobo 1 Jitter
95-109
Gobo 2 Jitter
110-124
Gobo 3 Jitter
125-139
Gobo 4 Jitter
140-154
Gobo 5 Jitter
155-169
Gobo 6 Jitter
170-184
Gobo 7 Jitter
185-189
white
190-222
FAST ROTATION - SLOW ROTATION
223-255
SLOW ROTATION - FAST ROTATION
20
19
Rotation Gobo Rot
0－127
Rotation
128－190
FAST ROTATION - SLOW ROTATION
191－192
STOP
193－255
SLOW ROTATION - FAST ROTATION
21
/
0-255
Gobo Rotation Fine Linear
22
20
Color7/Frost
0－127
White
128－191
Frost
192－255
Color7
23
21
0-255
Prism-zoom
24
22
Prism1
0－127
Reserve
128-255
Prism1
25
23
Prism-1 Rot
0－127
Rotation
128－190
FAST ROTATION - SLOW ROTATION
191－192
STOP
193－255
SLOW ROTATION - FAST ROTATION
26
24
Prism2
0-127
Reserve
128-255
prism2
27
25
Prism-2 Rot
0－127
Rotation
128－190
FAST ROTATION - SLOW ROTATION
191－192
STOP
193－255
SLOW ROTATION - FAST ROTATION
28
26
Foucs
0-255
Linear
29
/
0-255
Foucs Fine Linear
30
27
Zoom

9
0-255
Linear
31
/
0-255
Zoom Fine Linear
CLEANING AND MAINTENANCES
In order to ensure the fixture could work normally, it should be kept clean always. It is
recommended that the fans and ventilation inlet should be cleaned every 15 days. The lens should
be regularly cleaned and maintain an optimum light output.
