Aolait AL350RX User manual

350Beam Spot Wash 3in1 Moving head
User manual
Thanks for choosing our goods please read this manual carefully before your operating

2
Contents
Introduction........................................................3
Dimensions.........................................................4
Safety Information..............................................5
Using for the first time........................................7
AC power............................................................8
Data link..............................................................8
Setup....................................................................9
Menu chart..........................................................10
DMX Protocol&Channel Function................ ....14
Service and maintenance....................................19
Cleaning..............................................................20

3
Introduction
350W Beam Spot Wash 3 in 1 Moving head light
Voltage:AC100V-240V 50/60Hz
Power Consumption:500W
Light source:R17 350W
Color Temperature:3200K-8000K Linear Adjustment
Beam Angle: Beam0-1.5, Spot1.5°- 20° linear fast zooming.
Focus:High precision optical lens,electronic linear control
Linear Dimmer:Mechanical dimmer 0-100%
Color Wheel:13 fixed color+open,half-tone effect, linear color conversion,
bi-directionally rotatable at variable speeds and rainbow effect
Rotating Gobo:8rotating gobos+White,bi-directional rotatable and gobo
shaking at variable speeds
Fixed gobo: 13 interchangeable gobos +white, and bi-directionally rotatable
and gobo shaking at variable speeds
Prism:8+6facet circular prism (10°-20° zooming)
Dimmer:0-100% linear dimmer
Strobe:0.3-20times/second,double lens strobe with adjustable speed
Pan and Tilt: Smoothly,automatic Pan/Tilt position correction,speed adjustable
Range:Pan540°,Tilt 280°
Frost: 8°-60° washing
Effect:Color+Gobo+Prism+Strobe automatic operation function
Cooling:Fan Cooling
Control mode:Standard DMX 512, 3 pin connector(5pin optional)
Channel mode:19/24
Display Interface:LCD screen both in Chinese and English
IP rate:IP20,Built-in overheat protection,triggered high voltage protection.
Size: 400x280x660mm
Net Weight:20KG
Gross Weight:21KG(Carton)

4
Dimensions

5
Safety Information
The following symbols are used to identify important safety information on the product and in this manual:
WARNING!
Read the safety precautions in this section before
installing, powering, operating or servicing this
product.
This product is for professional use only. It is not for household use.
!
DANGER!
Hazardous
voltage. Risk
of lethal or
severe electric
shock.
WARNING!
Burn hazard.
Hot surface.
Do not touch.
WARNING!
Refer to user
manual.
WARNING!
High brightness
light source,
With risk of
burned eyes.
Protection
from burn
and fire.
DANGER!
Safety hazard.
Risk of severe
injury or death.
WARNING!
Wear
protective
Eye wear.
Warning!
High brightness light source,don’t look at the light directly so that keep the risk of burned eyes
away.
This product is for professional use only. It is not for household use.
This product presents risks of severe injury or death due to fire and burn hazards, electric shock
and falls.
Read this manual before installing, powering or servicing the fixture, follow the safety precautions
listed below and observe all warnings in this manual and printed on the fixture.
If have any problem,please contact the supplier.

6
PROTECTION FROM ELECTRIC SHOCK
• Disconnect the fixture from AC power before removing or installing any cover or part and when not in
use.
• Always ground (earth) the fixture electrically.
• Use only a source of AC power that complies with local building and electrical codes and has both
overload and ground-fault (earth-fault) protection.
• Before using the fixture, check that all power distribution equipment and cables are in perfect condition
and rated for the current requirements of all connected devices.
• Power input and throughput cables must be rated 20 A minimum, have three conductors 1.5 mm²
(16 AWG) minimum conductor size and an outer cable diameter of 5 - 15 mm (0.2 - 0.6 in.). Cables must
be hard usage type (SJT or equivalent) and heat-resistant to 90° C (194° F) minimum. In the EU the
Cable must be HAR approved or equivalent.
• Use only Neutrik Powercon NAC3FCA cable connectors to connect to power input sockets. Use only
Neutrik Powercon NAC3FCB cable connectors to connect to power throughput sockets.
• Isolate the fixture from power immediately if the power plug or any seal, cover, cable, or other
Component is damaged, defective, deformed, wet or showing signs of overheating. Do not reapply
power until repairs have been completed.
• Do not expose the fixture to rain or moisture.
PROTECTION FROM BURNS AND FIRE
• Do not operate the fixture if the ambient temperature (Ta) exceeds 40° C (104° F).
• The exterior of the fixture becomes hot during use. Avoid contact by persons and materials. Allow
the fixture to cool for at least 10 minutes before handling.
• Keep all combustible materials (e.g. fabric, wood, paper) at least 100 mm (3.9 in.) away from the
fixture.
• Keep flammable materials well away from the fixture.
• Ensure that there is free and unobstructed airflow around the fixture.
• Do not expose the front glass to sunlight or other strong light sources from any angle.
•
Do not illuminate surfaces within 200 mm (7.9 ins.) of this light.
• Do not attempt to bypass thermostatic switches or fuses.
• Do not stick filters, masks or other materials onto any optical component.
• Do not modify the fixture in any way not described in this manual

7
Using for the first time
PROTECTION FROM INJURY
•When light up the fixture,please don’t look at the optical lens with eyes directly.Besides, don’t use the
camera light to point at the optical lens.
• Fasten the fixture securely to a fixed surface or structure when in use. The fixture is not portable when
installed.
• Ensure that any supporting structure and/or hardware used can hold at least 10 times the weight of all
the devices they support.
• Allow enough clearance around the head to ensure that it cannot collide with an object or another
fixture when it moves.
• Check that all external covers and rigging hardware are securely fastened.
• Block access below the work area and work from a stable platform whenever installing, servicing or
moving the fixture.
• Do not operate the fixture with missing or damaged covers, shields or any optical component.
Important! After unpacking,please check the goods damage or not,which due to the
transportation. If you find damage, please do not use this item, then contact the dealer or
manufacturer as soon as possible.
•Please read the “Safety Information”before using the fixture.
• Check that the local AC mains power source is within the fixture’s power voltage and
frequency ranges.
•Please make sure the fixture use in “Safety Information” term.

8
AC power
Power voltage
Data link
Warning! Read “Safety Information” starting on page 5 before connecting this light to AC
mains power.
Warning! For protection from electric shock, this light must be grounded (earthed). The
power distribution circuit must be equipped with a fuse or circuit breaker and ground-
fault (earth-fault) protection.
Warning! Socket outlets or external power switches used to supply this light with power
must be located near the fixture and easily accessible so that the fixtures can easily be
disconnected from power.
Important! Do not insert or remove live Neutrik PowerCon connectors to apply or cut
power, as this may cause arcing at the terminals and damage the connectors.
Important! Do not use an external dimming system to supply power to the 350BSW as this
may cause damage to the fixture that is not covered by the product warranty.
Warning! Check that the voltage range specified on the fixture’s serial number label matches the
local AC mains power voltage before applying power to the fixture.
This light fixtures accept AC mains power at 100-240 V nominal, 50/60 Hz. Do not apply AC
mains power to the fixture at any other voltage than that specified on the fixture’s serial number
label.
A DMX 512 data link is required in order to control a 350BSW via DMX.
This light has 5-pin XLR connectors for DMX data input and output. The pin-out on all
connectors is pin 1 = shield, pin 2 = cold (-), and pin 3 = hot (+). Pins 4 and 5 in the 5-pin XLR
connectors are not used in this light but are available for possible additional data signals as
required by the DMX512-A standard.
Standard pin-out is pin 4 = data 2 cold (-) and pin 5 = data 2 hot (+).
The number of fixtures is either limited to 256 or limited by the number of DMX channels required by
the fixtures in relation to the maximum 512 channels available in one DMX universe, whichever limit is
lower. Note that if independent control of a fixture is required, it must have its own DMX channels.
Fixtures that are required to behave identically can share the same DMX channels.
To add more fixtures or groups

9
Connecting the data link
When this light turned on , the display screen and key button get flash
in every second once the fixture without the DMX signal.When insert
DMX signal,the display screen and key button stop flashing, it stand
for run into the DMX control mode. 20 seconds later,the display will
be in power save mode and the the key button indicator turn off.
Setup
Control panel and menu navigation
This light control center to
set the DMX. When you choose a
menu press OK ,
or view menus.
After finding your menu,Press to enter OK ,quit
After out of menu,press to see the working condition.
Connecting the data link
To connect this light to data:
1.
Connect the DMX data output from the controller to the closest this light
male 5/3-pin XLR DMX input connector.
2. Connect the DMX output of the fixture closest to the controller to the DMX
input of the next fixture and
continue connecting fixtures output to input.
3. Terminate the last fixture on the link with a 120 Ohm resistor.

10
Menu chart:
Main Menu Sub Menu UP/DOWN
Setting
Run Mode
DMX
Sound
Random
DMX Address 001-512
Std. 19CH
Channel Mode
+003-- -003
Sound Regulator
ON
Invert Pan
OFF
ON
Invert Tilt
OFF
ON
Pan-Tilt Encoder
NO DMX Signal
OFF
KEEP
Display
CLEA
ON
Lamp On@Startup
OFF
ON
OFF
ScreenAutoRotation
ON
OFF
Load Default
OK
CANCEL
Ext. 24CH
Lock Remark: Lock Display
↓180
Remark:Display 180° invert
中Remark: Language 中EN

11
Manual
1. Pan 000-255
2.Pan Fine 000-255
3. Tilt 000-255
4. Tilt Fine 000-255
5. Pan-Tilt Speed 000-255
6.Lamp Control&Reset ON/OFF/RESET
7.Color 000-255
8.ColourFine 000-255
9. Gobo 000-255
000-255
10. Effect Gobo
000-255
000-255
11. Effect Gobo Rotation
000-255
12. Gobo1RtFine
000-255
13. Prism
Info
14. Prism Rotation
000-255
21. FocusFine 000-255
22. Shutter/Strobe 000-255
23. Dimmer 000-255
24. Dimmer Fine 000-255
Ver.
000-255
DMX Monitor
System Errors
Total Fixture Hours 00000:00
Partial Fixture Hours 00000:00
Total Lamp Hours 00000:00
Please Input Password
Main Menu Sub Menu UP/DOWN
15. Prism1
000-255
16. Prism1 Rotation 000-255
000-255
17. Frost
18. Zoom
19. ZoomFine
20.Focus
000-255
350-A011
►
►
System

14
DMX Protocol
19Channel 24Channel
DMX Value
Function
Channel 1 Channel 1
Pan
0 - 255
Pan
Channel 18 Channel 2
Pan fine
0 - 255
Pan fine
Channel 2 Channel 3
Tilt
0 - 255
Tilt
Channel 19 Channel 4
Tilt fine
0 - 255
Tilt fine
Channel 3 Channel 5
Pan - Tilt - (Pan fine - Tilt fine) Speed
0-255
0 → 100% Pan - Tilt - (Pan fine - Tilt fine)
Speed fast to slow
Channel 4 Channel 6
Power/Special functions
0 – 19
Reserved
20 -24
Half Power
25- 29 Full Power
30- 69Reserved
70-79 Pan/Tilt Rotate Off Light
80-89 Pan/Tilt Rotate On Light
90-129
Reserved
130-139 Lamp on
140-149 Pan/Tilt Reset
150-189 Effect Reset
190-199
Reserved
Channel 5Channel 7
210-229 Reserved
230-239
Full Reset
240-255 Reserved
Macro Color
0-127 Linear Color (Open+13colors)
128-129 White
130-134 Color 1
135-138 Color 2
139-143 Color 3
144-147 Color 4
148-152 Color 5
153-157 Color 6
200-209
Lamp Off

15
158-161 Color 7
162-166 Color 8
167-171 Color 9
172-176 Color 10
177-180 Color 11
181-185 Color 12
186-189 Color 13
190-220 Fast Rotation-Slow Rotation
221-255 Slow Rotation-Fast Rotation
0-255 Color Fine
*Channel 8
Channel 6 Channel 9
Channel 5Channel 7
0 - 3 WHITE
4 - 9GOBO1
10 - 15GOBO2
16 - 21 GOBO3
22- 27GOBO4
28 - 33 GOBO5
34 - 39GOBO6
40 - 45 GOBO7
46 - 51 GOBO8
52 - 57 GOBO9
58 - 63 GOBO10
Static gobo wheel
64 - 69 GOBO11
70 - 75 GOBO12
76 - 81 GOBO13
82 - 87 GOBO14
88 - 95 GOBO1 Shake,Slow→ Fast
96 - 103 GOBO2 Shake,Slow → Fast
104 - 111 GOBO3 Shake,Slow → Fast
112 - 119 GOBO4 Shake,Slow → Fast
120 - 127 GOBO5 Shake,Slow → Fast
128- 135 GOBO6 Shake,Slow → Fast
136 - 143 GOBO7 Shake,Slow → Fast
144- 151 GOBO8 Shake,Slow → Fast
152 - 159 GOBO9 Shake,Slow → Fast
160 - 167 GOBO10 Shake,Slow → Fast
168 - 175 GOBO11 Shake,Slow → Fast
176 - 183 GOBO12 Shake,Slow → Fast
184 - 191 GOBO13 Shake,Slow → Fast

16
Channel 8 Channel 11
GOBO14 Shake,Slow → Fast
192- 199
200- 201
202-227
White
Fast Rotation-Slow Rotation
228-229
230-255
Stop
Slow Rotation-Fast Rotation
Channel 7 Channel 10
Rotating gobo wheel
0 Small WHITE
1 - 4
GOBO2-1
5 - 8
GOBO2-2
9 - 12
GOBO2-3
13- 16
GOBO2-4
17 - 20
GOBO2-5
21 - 24
GOBO2-6
25 - 28
GOBO2-7
29 - 32
GOBO2-8
33 - 36
GOBO2-9
37 - 40
41- 48
49 - 56
57 - 64
Big WHITE
GOBO2-1 Shake, Slow to Fast
GOBO2-2 Shake, Slow to Fast
GOBO2-3 Shake, Slow to Fast
GOBO2-4 Shake, Slow to Fast
GOBO2-5 Shake, Slow to Fast
GOBO2-6 Shake, Slow to Fast
GOBO2-7 Shake, Slow to Fast
GOBO2-8 Shake, Slow to Fast
GOBO2-9 Shake, Slow to Fast
81- 88
73 - 80
65- 72
105- 112
97 - 104
89- 96
113- 119
120-185
Big White
Fast Rotation-Slow Rotation
186-189
190-255
Stop
Slow Rotation-Fast Rotation
Rot. gobo indexing and rotation
0-127 Rotation indexing and Positioning
128 - 190 Fast Rotation-Slow Rotation
191-192 No rotation (Stop)193- 255 Slow Rotation-Fast Rotation
Channel 12
*0- 255 Reserved
Channel 9 Channel 13
Prism 1
0- 127 Reserved
128-255 Prism 1

17
Shutter
0-31 Close Shutter
32-63 Open Shutter
64-95 Slow to Fast
96-127
128-143 Fast Strobe - Slow Strobe
160-191 Open Shutter
Channel 17Channel 23
Dimmer
0-255 Linear Dimmer
Channel 10 Channel 14
Prism 1-Rotation
0- 127 Rotation
128-189 Slow Rotation-Fast Rotation
190-192
193-255 Fast Rotation-Slow Rotation
Stop
Channel 11 Channel 15
Prism 2
0- 127 Reserved
128-255 Prism 2
Channel 12 Channel 16
Prism 2-Rotation
0- 127 Rotation
128-189 Slow Rotation-Fast Rotation
190-192
193-255 Fast Rotation-Slow Rotation
Stop
Channel 13 Channel 17
Frost
0- 64 Reserved
65-255 Linear Frost
Channel 14 Channel 18
Zoom
0- 255 Linear Zoom
Channel 19
*0- 255 Zoom Fine
Channel 15 Channel 20 0- 255 Focus
Channel 21
*0- 255 Focus Fine
Channel 16 Channel 22
Open Shutter
144 - 159 Slow Strobe- Fast Strobe
192-223 Random Slow to Fast
224-225 Open Shutter
*Channel 24 Reserved

19
Gobo replacement
Identification of gobo wheel
To replace a gobo:
• Disconnect the fixture from power and allow to cool.
• Position the head and apply the tilt lock.
• Remove the rear head cover located on the same side as the pan lock
(A). See figure below.
• Remove the gobo wheel cover for access to the gobo wheel.
• Turn the gobo wheel until the gobo you want to replace is accessible.
• Unhook the end of the spring and turn it upwards. Pull the gobo holder
out of the gobo wheel.
Service and maintenance
Warning! Read “Safety Information” on page 5 before servicing this light.
Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before
handling. Do not view the light output from less than 4 meters without shade 4-5 welding goggles. Be
prepared for the fixture to light suddenly if connected to power.
Warning! Refer any service operation not described in this user manual to a qualified service
technician.
Important! Excessive dust, smoke fluid, and particle buildup degrades performance, causes overheating and
will damage the fixture. Damage caused by inadequate cleaning or maintenance is
not covered by the product warranty.
Following are a few common problems that may occur during operation. Here are some suggestions
for easy troubleshooting:
A. The unit does not work, no light and the fan does not work
1. Check the connect power and main fuse.
2. Measure the mains voltage on the main connector.
3. Check the power on LED to see if it can be light up or not.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if they are linked properly.
2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the unit or the
previous one.
4. Try to use another DMX controller.
5. Check to see if the DMX cables run near or run alongside to high voltage cables that may cause damage
or interference to DMX interface circuit.
C. One of the channels is not working well
1. The stepper motor might be damaged or the cable connected to the PCB is broken.
2. The motor’s drive IC on the PCB might be out of condition.
D. The lamp is cutting out intermittently
1. The lamp is not working well. Check the mains voltage either too high or too low.
2. Internal temperature may be too high. Check if replacement of fan is needed on the head.

20
Specifications subject to change without notice.
If have questions,please contact the dealer.
Cleaning
Cleaning schedules for lighting fixtures vary greatly depending on the operating
environment. Environmental factors that may result in a
need for frequent cleaning include:
• Use of smoke or fog machines.
• High airflow rates (near air conditioning vents, for example).
• Presence of cigarette smoke.
• Airborne dust (from stage effects, building structures and fittings or the natural
environment at outdoor events, for example).
If one or more of these factors is present, inspect fixtures within their first 100
hours of operation to see whether cleaning is necessary. Check again at frequent
intervals. This procedure will allow you to assess cleaning requirements in your
particular situation. If have any question,please contact dealer.
Use gentle pressure only when cleaning, and work in a clean, well-lit area. Do
not use any product that contains solvents or abrasives, as these can cause
surface damage.
Warning! Disconnect from power and allow to cool before cleaning.
To clean the fixture:
1. Disconnect the fixture from power and allow it to cool for at least 10 minutes.
2. Vacuum or gently blow away dust and loose particles from the outside of the
fixture and the air vents at
the back and sides of the head and in the base with low-pressure compressed air.
3.Please use the professional cloth to clean the optical lens and soak with low
concentration detergent liquid.
Do not rub the surface hard: lift particles off with a soft repeated press. Dry with
a soft, clean, lint-free cloth or low-pressure compressed air. Remove stuck
particles with an unscented tissue or cotton swab moistened with glass cleaner
or distilled water.
4. Check that the fixture is dry before reapplying power.
Table of contents
Other Aolait Lighting Equipment manuals
