Aolait AL4410 User manual

LED Outdoor Wash Light
44X10W RGBW 4in1 LED
USER MANUAL
Thank you very much for choosing our product. For safety purpose,
please read this manual carefully before your operation. This
manual included installation and using information. Please install
and operate it according to this manual.

1
Part 1 PRODUCT
1.1 Product introduction
This product is designed for indoor/outdoor use. Suitable
applications include wash or effect lighting for architectural, stage
or nightclub applications. This product can also be installed for use
in signage and advertising using the dynamic functions available
with DMX512 control. Direct input of DMX512 signal allows the
units to be controlled from any DMX512 controller. This product
can be operated as a single unit or in multiple units for large
applications.
1.2 Technical Specifications
Voltage: AC100-240V, 50/60Hz
Power: 600W
Light Source: 44X10W RGBW 4in1 LED
IP Rating: IP65
Lifespan: Around 100,000 hours
Housing: Die-casting aluminum, powder-coated finish
Control: DMX 512, 4/6/9CH
Control Mode: DMX, Auto, Master/Slave mode
Dimmer: 0-100%
Strobe: 0-20Hz
Beam angle: 45º
N.W: 10KG
1.3 Safety Warning
IMPORTANT:
ALWAYS READ THE USER MANUAL BEFORE OPERATION. PLEASE
CONFIRM THAT THE POWER SUPPLY STATED ON THE PRODUCT IS
THE SAME AS THE MAINS POWER SUPPLY IN YOUR AREA.
●This product must be installed by a qualified professional.
●Always operate the equipment as described in the user
manual.

2
●A minimum distance of 0.5m must be maintained between the
equipment and combustible surface.
●The product must always be placed in a well ventilated area.
●Always make sure that the equipment is installed securely.
●DO NOT stand close to the equipment and stare directly into
the LED light source.
●Always disconnect the power supply before attempting and
maintenance.
●Always make sure that the supporting structure is solid and can
support the combined weight of the products.
●The earth wire must always be connected to the ground.
●Do not touch the power cables if your hands are wet.
ATTENTION:
●This product left the place of manufacture in perfect condition.
In order to maintain this condition and for safe operation, the
user must always follow the instructions and safety warnings
described in this user manual.
●Avoid shaking or strong impacts to any part of the equipment.
●Make sure that all parts of the equipment are kept clean and
free of dust.
●Always make sure that the power connections are connected
correct and secure.
●If there is any malfunction of the equipment, contact your
distributor immediately.
●When transferring the product, it is advisable to use the original
packaging in which the product left the factory.
●Shields, lenses or ultraviolet screens shall be changed if they
have become damaged to such an extent that their
effectiveness is impaired.
●The lamp (LED) shall be changed if it has become damaged or
thermally deformed.

3
PART 2 INSTALLATION
2.1 Mounting:
2.1-1 Hanging
The product can be mounted in a hanging position using the
supporting bracket. The bracket should be secured to the
mounting truss or structure using a standard mounting clamp.
Please note that when hanging the unit a safety cable should also
be used
.
2.1-2 Upright
The product can be mounted in an upright or sitting position using
the supporting brackets.
NOTE:
The product can be mounted at any angle and in any position. It is
possible to further adjust the angle of the product using the two
adjustment knobs located on the side of the fixture.
2.2 DMX Channel instruction
4/6/9 Channel Mode
4CH
6CH
9CH
Function
Value
Instruction
1
1
Dimmer
0-255
Dimmer, from dark to bright
2
2
Strobe
0-3
No function
4-255
Strobe from slow to fast
1
3
3
Red
Dimming
0-255
Red Dimming, from dark to
bright
2
4
4
Green
Dimming
0-255
Green Dimming, from dark to
bright
3
5
5
Blue
Dimming
0-255
Blue Dimming, from dark to
bright
4
6
6
White
Dimming
0-255
White Dimming, from dark to
bright
7
Color
Selection
0-31
No function
32-63
Red

4
2.3 Special construction for DMX connection
☆At last fixture, the DMX cable has to be terminated with a
terminator to reduce signal errors. Solder a 120-ohm 1/4W
resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin
XLR-plug and plug it in the DMX-output of the last fixture.
☆If the controller is 5-pin output, it’s necessary to use an adaptor
to transfer signal from 5-pin output to 3-pin XLR-plug or you
can connect cables as following:
64-95
Green
96-127
Blue
128-159
White
160-191
Red+Green
192-223
Red+Blue
224-255
Green+Blue
8
Macro
Function
0-50
No function
101-150
Color Change
151-200
Color Gradual
201-255
Color Pulse
9
Speed
0-255
Speed from slow to fast

5
PART 3 Display Panel Operation
3.1 Display panel menu instruction
[MENU]menu selection or return to previous menu.
[ENTER] confirm & quit out current function setting.
[UP] press [UP] through the menu list to increase/change the value
of the current function.
[DOWN] press [DOWN] through the menu list to decrease/change
the value of the current function.
3.2 Displa y M enu instruction (general)
Show
Function
Item 1
DMX
Address
001~512
Channel Mode
4 Channel
6 Channel
9 Channel
Manual
1.Dimmer
0-255
2.Strobe
0-255
3.Red
0-255
4.Green
0-255
5.Blue
0-255
6.White
0-255
Macro
Run Mode
Stop

6
Flash
Fade
Pulse
Speed
0-255
System
Host Mode
OFF/ON
Language
English/Chinese
Backlight setting
Auto/Keep on
Cuve
Cuve 1
Cuve 2
Cuve 3
Cuve 4
Blackout Time(ms)
0-200
Information
Devide Tou(min)
About
Soft version
Part 4 Maintenance
The cleaning of internal must be carried out periodically to
optimize light output. Cleaning frequency depends on the
environment in which the fixture operates: damp, smoky or
particularly dirty surrounding can cause greater accumulation of
dirt on the fixture’s optics.
●Clean with soft cloth using normal glass cleaning fluid.
●Always dry the parts carefully.
●Clean the external optics at least every 20 days.
●Clean the internal optics at least every 30/60 days –Up to vary
products.
Please ask professional technical to clean waterproof products
and make sure the fixture will be reassembled well for waterproof.
