AOpen Digital Engine DE965 User manual

Assembly Guide for DE965
V2.0
2009/01/09

Index
1. Outlook …………..……………………………………………2
2. Open Housing ……………………………………...………...4
3. Install Key components………………………………………7
4. Assemble the Supporter & Upper Case…………………..16
5. Appendix 1 Packing List…………………………………….25
6. Appendix 2 Table of Screw and Torque..………………….26
7. Appendix 3 Watch Dog Timer Configuration…….………..27
8. Appendix 4 Outline and Holder Drawing .…………………32
1

1. Outlook
Power Button
Front USB Power Button Front USB
Front IO
2

Rear IO
COM port
VGA2
DC 19V HDMI VGA1 LAN
USB 2.0
Mic in
Line out
Antenna
hole
Kensington
lock hole
3

2. Open Housing
2-1.
Detach 2 pcs of the rear side screw ( FPH M3
screw ) by the electric screw driver .
(Screwdriver torque : 5.0±0.2 kgf. cm )
2-2.
Push the Upper case to remove it .
Front Side
Rea
r
Side
Unscrew
4

2-3. Detach 4 pcs of the supporter screw ( FPH
M3 screw )by the electric screw driver
(Screwdriver torque : 5.0 ±0.2 kgf. cm )
2-4.Remove Supporter
5

2-5.You will see the kernel of Digital Engine
6

3. Install Key components
3-1Install Memory
3-1-1.
Insert the memory on the socket as this
angle.
MB
30°
Insert DIMM as this angle
7

3-1-2.
Then press the DIMM as flat on the
Motherboard, and you will hear the click
voice.
Make sure it clicks
8

3-1-3.Unscrew the CPU cooler 3-1-5. Unscrew CPU socket
Counterclockwise direction
Unscrew
3-1-4. Remove the cooler
9

3-1-6 Put the CPU into the socket, and check
the direction. 3-1-8. Put on the cooler and screw it tightly
.clockwise direction
3-1-7. Screw the CPU socket. 3-1-9 connect the wire for cooler
10

3-2Install HDD on Supporter without ODD
3-2-1 Install Card Holder
Put the Card Holder on the supporter,
and screw it with 1pcs of M2 screw.
(Screwdriver torque : 0.7±0.1kgf.cm)
3-2-2.Insert the MPI-SATAcard into HDD
Screw internal card to Card holder with 2pcs of
M2 screws.(Screwdriver torque:0.7±0.1kgf.cm)
11

3-2-3. Put the HDD on support
Please pay attention to the direction of SATA
HDD
3-2-4. and screw HDD with 4pcs of FPH M3
screw (on both flanks)
(Screwdriver torque : 2.5 ±0.1 kgf. cm )
12

3-3 Install HDD on Supporter with slim ODD
3-3-1 Put slim ODD on the top side of supporter,
screw the position 1 and 2 with M2 screw first,
then screw position 3 and with M2 screw to fix
the slim ODD.
(Screwdriver torque : 0.7±0.1kgf.cm)
13

3-3-2.Insert the MPI-SATAcard into HDD 3-3-3 Screw MPI-SATAcard to ODD with 2
pcs of M2 screws.
(Screwdriver torque : 0.7±0.1kgf.cm)
3-3-4. Put the HDD on support
Please pay attention to the direction of SATA
HDD
and screw HDD with 4pcs of FPH M3 screw
(on both flanks)
(Screwdriver torque : 2.5 ±0.1 kgf. cm )
14

3-3-5 FPH M3xL5 Screw
FPH M2xL3 Screw
15

4. Assemble the Supporter & Upper Case
4-1.Make sure Front USB wire connect to MB
16

4-2. Install the supporter (Only HDD is on the supporter now)
4-2-1. Make sure the MPI-SATA card is correctly insert into the socket
4-2-2.Screw 4pcs of M3 screw at the
supporter.
(Screwdriver torque : 5.0 ±0.2 kgf.cm)
17

4-3. Install the supporter (HDD and ODD are on the supporter now)
4-3-1. Make sure the MPI-SATA card is correctly insert into the socket
4-3-2.Screw 4pcs of M3 screw at the
supporter.
(Screwdriver torque : 5.0 ±0.2 kgf.cm)
18

4-4. Assemble the upper case (without ODD)
4-4-1. Connect the power switch wire. 4-4-2. Connect the Front-USB wire to
upper-case.
4-4-3. Adjust the USB cable to arrange the
cable under the supporter . Accord the photo.
2
1
