Digital Gas Controller System CGD-05
1 Application Intended for Use
CGD-05, Gas Controller is used for monitoring and warning of toxic and combustible gases and vapours in the
ambient air.The CGD-05 Gas Controller fulfils the requirements according to VDI 2053 (January 04),
ÖNORM and NVN 2443 for the stationary monitoring of carbon monoxide (CO), nitrogen dioxide (NO2)
and combustible gases in underground garages, tunnels, go-cart race courses etc. The CGD-05 Gas
Controller also meets the requirements according to EN 378, VBG 20 and the guidelines "Safety
requirements for ammonia refrigeration systems". The Gas Controller can be used as well for monitoring
lots of other gases.
The intended sites are all areas being directly connected to the public low voltage supply, e.g. residential,
commercial and industrial ranges as well as small enterprises (according to EN55 02). The Gas Controller
may only be used in ambient conditions as specified in the Technical Data.
The Gas Controller CGD-05 must not be used in potentially explosive atmospheres.
2 Description
The Gas Controller is a measuring and warning controller for the continuous monitoring of different toxic or
combustible gases and vapours as well as of Freons. The CG-05 is suitable for the connection of up to 98
digital transmitters via the 2-wire bus. In the 48/48 MP addressing mode you can connect 48 transmitters with 4
to 20 mA input for the connection of an analog transmitter. There are 4 analog inputs available at each PE-05
module in addition. The controller can be employed as analog, as analog/digital or as digital controller. The
total number of connected transmitters, however, may not exceed 96 respectively 98 transmitters.
Up to five free programmable alarm thresholds are available for each transmitter. For transmitting the alarms
there are up to 30 relays with potential-free change-over contact.
Comfortable and easy operation of the Gas Controller is done via the logical menu structure. A number of
integrated parameters enables the realisation of various requirements in the gas measuring technique.
Configuration is menu-driven via the keypad. For fast and easy configuration, you can use the configuration
software CGD-EasyConf.
Prior to commissioning please consider the guidelines for wiring and commissioning of the hardware.
2.1 Normal Mode
In normal mode, the gas concentrations of the active transmitters are continuously polled and displayed at the
LCD display in a scrolling way. The controller also monitors the communication to all active transmitters and
modules.
2.2 Alarm Mode
If the gas concentration reaches the programmed alarm threshold, the alarm is started, the assigned alarm
relay activated and the alarm LED (orange for alarm1, red for alarm 2 + n) starts to flash. The set alarm can be
read from the menu Alarm Status. When the gas concentration falls below the alarm threshold plus hysteresis,
the alarm is automatically reset. In latching mode, the alarm has to be reset manually in the menu Relay Status
or via a digital input.
2.3 Fault Mode
If the controller detects an incorrect communication at an active transmitter or module, or if a signal is outside
the admissible range (< 3 mA - > 22 mA), the assigned fault relay is set and the error LED starts to flash. The
error is displayed in the menu Error Status in clear text. After removal of the cause, the error message has to
be acknowledged manually in the menu Error Status.

5
June 2012
Gas Controller
AUTOMATIKPRODUKTER
3 Operating Instruction
The complete configuration, parameterization and service are made via keypad user interface in combination
with the display screen. Security is provided via four password levels.
3.1 Description Keypad User Interface
Exits programming, returns to the previous menu level.
Enters sub menus, and saves parameter settings.
Scrolls down & up within a menu, changes a value.
Moves the cursor position.
LED orange: Flashes when alarm one or more alarms are active.
Permanently on, when at least one relay is manually operated.
LED red: Flashes when alarm two or more alarms are active.
Permanently on, when at least one relay is manually operated.
LED yellow: Flashes at system or sensor failure or when maintenance needed.
LED green: Power LED
3.2 Setting / Change Parameters or Set points
Open desired menu window.
Code input field opens automatically, if no code is approved.
After input of valid code the cursor jumps onto the first position segment to be changed.
Push the cursor onto the position segment, which has to be changed.
Set the desired parameter / set point.
Save the changed value.
Input finished.

6
June 2012
Gas Controller
AUTOMATIKPRODUKTER
3.3 Code Levels
According to the regulations of all national and international standards for gas warning systems, all inputs and
changes are protected by a four-digit numeric code (= password) against unauthorised intervention. All menu
windows are visible without entering a code.
The release of a code level is cancelled if no button is pushed within 15 minutes.
The code levels are classified in order of priority: Priority 1 has top priority.
Priority 1: (fixed value – not changeable)
Code level priority 1 is intended for the service technician of the installer to change parameters and set-points.
All settings can be edited with this password.
Priority 2: (fixed value – not changeable)
With code level 2, it is possible to lock/ unlock transmitters temporarily.
This password is only given to the end user by the installer in problem situations.
Priority 3: (settable)
It is only intended to update the maintenance date, as well as to turn on and off the service mode.
Normally the code is only known by the service technician.
It can be changed individually via priority 1.
Priority 4: (password 1234) (fixed value – not changeable)
Code level priority 4 allows the operator:
- to acknowledge faults
- to manually operate the alarm relays
- to set date and time
- to configure the data logger.

7
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4 Menu Overview
The Gas Controller CGD-05 is operated via a simple and logical menu structure which is easy to learn. The
operating menu contains the following levels:
•Starting menu with date and time if no MP is registered, otherwise scrolling display of the gas
concentrations of all registered transmitters in 5-second intervals. If alarms are active, only the values
of the transmitters currently in alarm status are displayed.
•Main menu
•Submenu 1 and 2
Starting menu Main menu Sub menu
After 30 sec.
or
Reading and reset of errors
See from point 4.1
Display of the status of actual alarms
See point 4.2
Display of the relay status
Manual operation of the relays
Reset function of the relays
See from point 4.3
Display of the measuring values
See point 4.4
Reading and change of the relay parameters
See from point 4.5
Reading and change of measuring point parameters
Activate or Deactivate MP
Assignment of the alarms to the alarm relay
See from point 4.6
Reading and change of the data logger parameters
See from point 4.8 (available from version 9.02)
Reading and change of the system parameters
See from point 4.7
Display of
Gas concentration
System Errors
Status Alarm
Status Relay
Measuring Values
Relay Parameter
MP Parameter
System Parameter
Power On time
AP
02.04.12 12:53
Data Logger

8
June 2012
Gas Controller
AUTOMATIKPRODUKTER
MP01.1 Error
Erased
Error still
exists
4.1 Fault Management
The integrated fault management records the first 20 faults with date and time stamps in the menu „System
Errors“. Additionally a record of the faults occurs in the “Error memory”, which can only be read and cancelled
by the service technician.
An actual fault activates the fault indication relay which is defined in the system parameter “Fault relay” after an
internal fault delay time of 2 minutes. The yellow LED (Fault) starts to flash and the fault is displayed in plain
text with date and time in the starting menu.
In case of the fault of a connected transmitter the alarms defined in the menu “MP Parameter” are activated in
addition.
4.1.1 Acknowledge a Fault
Attention:
According to the directives of the gas measuring technique, accumulated errors aren’t allowed to be
acknowledged automatically. Therefore, acknowledgment of a fault is only possible after having removed the
cause!
Select menu “System Errors”
Example: Communication error MP01.1
Acknowledge the fault message?
Fault message acknowledged.
or
Fault acknowledged Cause not eliminated
Reset not possible
4.1.2 Error Memory
The menu „Error Memory“ in the main menu “System Error” can only be opened via the code level priority 1.
In the error memory, the 20 first faults already acknowledged in the menu “System Error” are listed for the
service technician in a power failure safe way.
This memory should always be emptied during maintenance.
The deletion of each individual message is effected in the same way as the reset of a fault.
System Errors
MP01.1 Error
05.02 10.38
MP01.1 Error
Reset?

9
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4.1.3 System Errors
The following system error messages are recorded:
MP XX.1 Error Communication error to MPXX.1.
Cause: Bus line interrupted or short circuit, MPXX.1 registered at the controller,
but not addressed, Transmitter defective.
Solution: Check line to transmitter, check transmitter address, replace transmitter.
MPXX.1 > 22 mA
MPXX.1 < 3 mA Sensor signal at transmitter out of the measuring range.
Cause: Transmitter not calibrated, defective.
Solution: Calibrate transmitter, replace transmitter.
MPXX.2 > 22 mA Current signal at analog input MPXX.2 > 22 mA.
Cause: Short-circuit at analog input, analog transmitter not calibrated, or defective.
Solution: Check cable to analog transmitter, make calibration, replace the analog
transmitter.
MPXX.2 < 3 mA Current signal to analog input MPXX.2 < 3 mA.
Cause: Wire break at analog input, analog transmitter not calibrated, or defective.
Solution: Check cable to analog transmitter, make calibration, replace the analog
transmitter.
PE00 Error: Internal communication error I/O Board to LCD Board.
Cause: Internal error. RS 485 field bus at X10 pin 11- 12 not correct
Solution: Check RS 485 field bus at X10 pin 11 and 12.
Disconnect RS 485 bus at X10 pin 11 and 12, check function again.
Replace the Gas Controller.
PE 0X Error Communication error to extension module PE 0X.
(Only active, if PE 0X is registered).
Cause: PE module address not correct. (See Commissioning.)
Bus line to PE 0X module interrupted.
No power supply at the PE 0X module.
PE module defective.
Solution: Check and correct the PE module address.
Check the bus cable and the power supply.
Replace the PE 0X module.
Maintenance: System maintenance is necessary.
Cause: Maintenance date exceeded.
Solution: Perform the maintenance.
MPXX locked: This MP input is locked (MP is physically present, but cancelled by the
operator)
Cause: Operator intervention.
Solution: Eliminate the cause of a possible fault and then unlock the MP.

10
June 2012
Gas Controller
AUTOMATIKPRODUKTER
MP02.1
A1 A2
R 01
OFF
4.2 Status Alarm
Display of the actual alarms in plain text in the order of their arrival. Only those measuring points are displayed,
where at least one alarm is active. Changes are not possible in this menu.
Symbol Description Function
MP02.1 Measuring (MP) Point No.
AX Status alarm
A1 = Alarm 1 ON
A2 = Alarm 2 ON
A3 = Alarm 3 ON
A4 = Alarm 4 ON
A5 = Alarm 5 ON
4.3 Status Relay
Reading of the actual status of alarm relays, manual operation of the alarm relays.
Symbol Description Setting
Status Function
R 01 Relay No. 01
OFF Status Relay OFF
OFF
ON
Manual OFF
Manual ON
Latching mode
= Relay OFF (no gas alarm)
= Relay ON (gas alarm)
= Relay manual OFF
= Relay manual ON
= Relay in latching mode
4.3.1 Manual Operation of the Relays
The manual operation of the alarm relays is managed in the menu “Status Relay” or externally via an assigned
digital input. In the manual ON or OFF status, the alarm LEDs at the Gas Controller are lit continuously.
The external operation of the alarm relay via an assigned digital input has priority to the manual operation in
the menu "Status Relay" and to gas alarm.
Relays manually operated in the menu “Status Relay” are cancelled again by selection of the automatic
function.
Acknowledging the relays in latching mode is also effected in this menu or by a digital input.
Select the relay
Select the function manual operation
Manual ON = Relay ON
Select the function Manual OFF = Relay OFF
Automatic = Cancel manual operation.
Reset ? = Reset of a latching mode.
Take over the function
R 01
OFF
Manual ON
Manual OFF
R 01
Manual OFF

11
June 2012
Gas Controller
AUTOMATIKPRODUKTER
MP01 CO ppm
50 *MW 33 IW
MP01.2 Ex %LEL
13*IW
MP01.1 CO ppm
50 *MW 33 IW
4.4 Menu Measuring Values
In this menu, the display shows the current value (CV), the gas type and the defined control mode (CV or AV
mode) for each active measuring point.
In the control mode Average Value (AV), both values (CV and AV) are displayed.
MP01.1= Measuring value of the bus transmitter with MP address 01.
MP01.2= Measuring value of the analog transmitter connected to the bus transmitter via MP address 01.
The MP address and the display depend on the system parameter settings for the MP addressing mode (see
4.8.3).
In the version without analog transmitters at the 4 to 20 mA input of the bus transmitter, the addresses MP01 to
MP98 are listed.
In the version with analog transmitters at the bus transmitter, the addresses MP01 to MP48 are listed with the
index XX.1for the measured value of the bus transmitter and with XX.2for the measured value of the analog
transmitter.
MP addressing mode: 98 bus transmitters
--------------------------------------------------------------------------------------------------------------------------------------------
MP addressing mode: 48 bus transmitters and 48 analog transmitters
--------------------------------------------------------------------------------------------------------------------------------------------
Symbol Description Setting
Status Function
MPXX.1Measured value Measured value from bus transmitter with MP address XX
MPXX.2Measured value
Measured value from analog transmitter at bus transmitter with
MP address XX
CO Gas type See 4.6.3
ppm Gas unit See 4.6.3
CV Current value Current value of gas concentration
AV Average value Average value (10 measured values within the time unit)
* Control mode Display of active control mode (CV or AV evaluation) without
active alarms
! Control mode Display of active control mode (CV or AV evaluation) with
occurred active alarm of the transmitter
Not active Status MP MP not active
Error Malfunction MP Communication error, or signal out of the measuring range
Locked MP locked MP was temporarily locked by the operator.

12
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4.5 Menu Relay Parameter
Reading and changes of the parameter for each single alarm relay.
(Main menu)
(Selection relay No. – only possible for registered modules)
Relay mode
See 4.5.1
Relay function
See 4.5.2
Activation of latching mode
See 4.5.3
Definition horn function
See 4.5.4
Definition external operation
See 4.5.5
Delay time for relay ON
See 4.5.6
Delay time for relay OFF
See 4.5.6
4.5.1 Relay Mode
Definition of the relay mode
Symbol Description Setting Status Function
R 01 Relay No. Selection of relay
De-energized Relay Mode De- energized Relay de-energized
Relay energized = Alarm OFF = Relay OFF = Alarm ON = Relay OFF
4.5.2 Relay Function Static / Flash
Definition of the relay function
Symbol Description Setting Status Function
R 01 Relay No. Selection of relay
0 Function 0
0 = Relay function static
> 0 = Relay function flashing (= time interval in sec.)
Impulse / Break = 1:1
Relay Mode
De- energized
Static / Flash
0 s
Relay Parameter
R 01
Latching mode
No
Time Recurr. DI
0s 0 0
External mode
DI: ON = 0: OFF = 0
ON-Delay time
0 s
OFF-Delay time
0 s

13
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4.5.3 Latching Mode
Definition of the latching function:
The combination of latching function and automatic reset of the horn function cancels the effect of each other
and therefore is not admitted.
Symbol Description Setting Status Function
R 01 Relay No. Selection Relay
No Latching
Mode No No
Yes
= No latching function
= Latching function
Acknowledging a latching relay in the menu “Status Relay” is only possible if the gas concentration is again
lower than the alarm threshold including hysteresis. In this case the status latching occurs in the display.
The respective switch-off delay is without effect when the latching mode is activated.
Example: Alarm relay R2 with latching mode
Alarm 2
Display in the Menu
Status Relay
Relay 2
Reset in the Menu
Status Relay
or Digital Input
On
Off
On
Off
On
Off
R2
Off R2 On R2 On R2 On R2 Latching R2 Off
Gas concentration higher lower than threshold
4.5.4 Horn Function
The horn function is only activated if at least one of the two parameters (time or digital input) is set. This
function has priority to the latching mode function.
The following possibilities to reset are available for the alarm relay as horn relay:
•By pressing any of the 6 pushbuttons. (Only possible in the starting menu).
•Automatic reset at the end of the preset time (active, if value >0).
•By an external pushbutton. (Assignment of the appropriate digital input DI: 1-4).
After acknowledgment the horn remains permanently reset until all assigned alarms for this relay function are
inactive again. Not till then it is triggered anew in case of an alarm.
Special function Recurrence
After acknowledgment of the relay (by pushbutton or externally), the time starts. When this time has run out
and the alarm is still acting, the relay is set again.
Symbol Description Setting
Status Function
R 04 Relay No.
Selection relay
Recurrence Reset Mode 0
0 = Reset of the relay after time having run out, via DI (external) or
by pushbuttons
1 = After reset of the relay, time starts. At the end of the set time,
the relay is activated again (recurrence function).
Time 120 Enter time for function automatic reset or recurrence function in sec.
0 = no reset function
DI 0 Assignment, which digital input resets the relay.

14
June 2012
Gas Controller
AUTOMATIKPRODUKTER
Acknowledge the horn relay
Alarm 4
Relay 4
Gas concentration higher lower than threshold
Acknowledging
signal
On
Of
On
Off
On
Off
Time
Reset command by external push-button or one of the operating keys.
Special function Recurrence of the horn relay
Alarm 4
Relay 4
Gas concentration higher lower than threshold
Acknowledging-
signal
On
Off
On
Off
On
Off
Time Time
Reset command by external push-button or one of the operating keys.
4.5.5 External Operation of Alarm Relay
Assignment of a digital input (DI) for external switching of the alarm relay (ON and/or OFF).
This function has priority to a gas alarm and/or manual switching in the menu “Status Relay”.
The relays also work in this mode according to the parameter settings “static/ flashing and “energized/ de-
energized”. If external ON and OFF are parameterised on the same relay simultaneously, and the both are
active at the same time, then only the signal arrived first is carried out in this situation.
Symbol Description Setting
Status Function
R 01
Relay No.
Selection relay
DI-ON External ON 0 As long as digital input closed, relay switches to ON
DI-OFF External OFF 0 As long as digital input closed, relay switches to OFF
4.5.6 Delay Mode of Alarm Relay
Definition of the switch-on and switch-off delay of the relays
If the latching mode is set for this relay, the respective switch-off delay is without effect.
Symbol Description Setting
Status Function
R 01 Relay No. Selection relay
0 s Switch-ON
Delay Time 0 Relay is only activated at the end of the defined time (sec.) 0 sec. = No delay
0 s Switch-OFF
Delay Time 0 Rel
ay is only deactivated at the end of the defined time (sec.) 0
sec. = No delay

15
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4.6 Menu MP Parameter
For reading and changing measuring point parameters for each bus and analog transmitter including
registration of MP and assignment of the alarm relays.
The presentation of the MP parameters depends on the system parameter settings for the CG mode (see
4.8.3).
(Main menu)
MP01.1= Parameter
bus transmitter
(Selection MP No.)
MP01.2= Parameter analog
transmitter
Activate or deactivate MP
See 4.6.1
Lock or unlock MP
See 4.6.2
Definition of gas type, unit and number
of alarms at falling concentrations (AF)
See 4.6.3
Definition measuring range
See 4.6.4
Adjust signal form of the transmitter
See 4.6.5
Define threshold 1
See 4.6.6
Define threshold 2
See 4.6.6
Define threshold 3
See 4.6.6
Define threshold 4
See 4.6.6
MP Mode
active
MP Parameter
Measuring range
300 ppm
MP Signal
Linear
Threshold 1
80 ppm
Threshold 2
100 ppm
Threshold 3
120 ppm
Threshold 4
120 ppm
MP01.1
active
MP01.2
active
Gas unit AF
CO ppm 0
Lock
No

16
June 2012
Gas Controller
AUTOMATIKPRODUKTER
Define threshold 5
See 4.6.6
Hysteresis
See 4.6.6
Set delay time for alarm ON
See 4.6.7
Set delay time for alarm OFF
See 4.6.7
Define control mode
See 4.6.8
Assign MP fault to alarm
See 4.6.9
Assign alarm to alarm relay
See 4.6.10
Assign MP signal to analog output
See 4.6.11
4.6.1 Activate – Deactivate MP
Symbol Description Setting
Status
Function
MP01.1 Measuring point
Selection MP No./ bus or analog transmitter
Active MP Status not
active
active = Measuring point activated at the controller
not active = Measuring point not activated at the controller
4.6.2 Lock or Unlock MP
This functionality is available from version 9.02
In the Lock Mode, the function of the existing transmitter is put out of service, which means there is no alarm or
fault message at this measuring point. Existing alarms are cancelled with the locking; the associated faults can
be acknowledged. If at least one transmitter is blocked in its functionality, the collective fault message is
activated after the internal fault delay time, the yellow fault LED is flashing and there is a message in the menu
System Errors.
Symbol Description Setting
Status Function
MP01.1 MP No. Selection Lock Yes/ No
No No No = MP free, normal operation
Yes = MP locked, SSM (collective error message) active
Threshold 5
120 ppm
Hysteresis
15 ppm
ON-Delay time
0 s
OFF-Delay time
0 s
C/A Mode
CV
Alarm - 1 2 3 4 5
Fault - 0 0 0 0 0
A1 A2 A3 A4 A5
1 2 3 4 0
Analog Output
0

17
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4.6.3 Selection Gas Type
Assign gas type of the attached gas transmitter.
Symbol Description
Setting
Status
Gas type Unit1
Measuring
range
1
MP 01 Measuring point
CO Gas type CO
CO
Ex
NO
NO2
NH3
O2
CO2
SO2
H2S
CL2
ETO
VOC
R4XX
R5XX
R11
R123
R134
R22
TEM
RH
TOX
CH4
VAP
ExIr
NF3
PTC
Carbon monoxide
Combustible gases
Nitrogen oxide
Nitrogen dioxide
Ammonia
Oxygen2
Carbon dioxide3,4
Sulphur dioxide
Hydrogen sulphide
Chlorine
Ethylene oxides
Air quality
Refrigerant gas
Refrigerant gas
Refrigerant gas
Refrigerant gas
Refrigerant gas
Refrigerant gas
Temperature
Humidity
Toxic gas
Methane
Vapours
Ex infrared
Nitrogen trifluoride
Percentage
Empty
ppm
% LEL
ppm
ppm
ppm
Vol%
ppm
ppm
ppm
ppm
ppm
Vol%
ppm
ppm
ppm
ppm
ppm
ppm
°F/ °C
%RH
ppm
% LEL
% LEL
% LEL
ppm
%
0 – 300
0 – 100
0 – 50
0 – 25
0 – 300
0 – 25
0 – 2000
0 – 100
0 – 200
0 – 100
0 – 20
0 – 100
0 – 300 / 2000
0 – 300
0 – 300
0 – 300
0 – 300 / 2000
0 – 300
XXXX
0 – 100
0 – XXX
0 – 100
0 – 100
0 – 100
0 – 100
XXXX
Symbol Description Setting
Status Function
ppm Unit ppm
ppm
%LEL
Vol%
°F
%RH
%
ppk
°C
AF Direction of the
alarm release 0
Alarm release
0 = at increasing concentration for all alarms
1 = Alarm 1 at falling, Alarm 2- 5 at increasing conc.
2 = Alarm 1 + 2 at falling, Alarm 3-5 at increasing c.
5 = Alarm 1-5 at falling concentration
1Recommendation without obligation
2Oxygen measurements: Alarm at falling concentration
3Carbon dioxide measurements with unit ppk (1 vol% = 10 ppk)
4Carbon dioxide measurements with unit ppm (1 vol% = 10.000 ppm)

18
June 2012
Gas Controller
AUTOMATIKPRODUKTER
Direction of the alarm release
In the gas measuring technique, most of the gases are monitored for their increasing concentration. For
example oxygen, however, is monitored for its falling concentration. In this menu there is the definition how
many of the 5 alarm thresholds monitor a falling concentration.
4.6.4 Measuring Range Definition
The measuring range can be adapted to the working range of the connected gas transmitter within 1 to 9999.
This also influences the display of the measured values, the alarm threshold as well as the hysteresis. Two
decimal places are displayed for measuring ranges <= 10, one decimal place for measuring ranges > 10 and
<= 100 and no decimal place for measuring ranges > 100.
4.6.5 MP Signal Definition
Gas transmitter using electro-chemical or catalytic beat gas sensors normally produce a linear signal,
proportional to the gas concentration.
Semiconductor gas sensors produce a non-linear (exponential) signal due to the measuring function. This
signal leads again to a non-linear 4 to 20 mA signal of the gas transmitter.
The Gas Controller CG-05 is prepared for both types of gas transmitters. The classification of signals is defined
in this menu.
Symbol Description
Setting
Status
Function
MP01.1 Measuring Point Selection MP No. bus or analog transmitter
Linear MP Signal linear Linear = Transmitter with linear output signal Non-linear = Transmitter with non-linear output signal
(semiconductor)
4.6.6 Threshold/ Hysteresis
For each measuring point five alarm thresholds are available for free definition. If the gas concentration is
higher than the set alarm threshold, the associated alarm is activated. If the gas concentration falls below the
alarm threshold inclusive hysteresis the alarm is again reset. In the mode “Alarm at falling” the corresponding
alarm is set in case of falling below the set alarm threshold. The display depends on the set measuring range:
see 4.6.4. Unused alarm thresholds have to be defined at measuring range end point, in order to avoid false
alarms.
Symbol Description
Default
Status
Function
MP01.1 Measuring Point Selection MP No. / Bus or analog transmitter
80 ppm Threshold
80
100
120
120
300
15
Threshold 1
Threshold 2
Threshold 3
Threshold 4
Threshold 5
Hysteresis
Gas concentration > Threshold 1 = Alarm 1
Gas concentration > Threshold 2 = Alarm 2
Gas concentration > Threshold 3 = Alarm 3
Gas concentration > Threshold 4 = Alarm 4
Gas concentration > Threshold 5 = Alarm 5
Gas concentration < (Threshold X –Hysteresis)
= Alarm X OFF
4.6.7 Delay for Alarm ON and/or OFF
Definition of delay time for alarm ON and/or alarm OFF. The delay applies to all alarms of an MP, not with
average value overlay, see 4.8.6.
Symbol Description
Default
Status
Function
MP01.1
Measuring Point
Selection MP No./ bus or analog transmitter
0 s Delay Time ON 0 Gas concentration > Threshold: Alarm is only activated at the end
of the fixed time (sec.). 0 sec. = No delay
0 s Delay Time OFF 0 Gas concentration < Threshold: Alarm is only deactivated at the
end of the fixed time (sec.). 0 sec. = No delay

19
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4.6.8 Control Mode Current or Average Value
Definition of the alarm evaluation by current value CV) or average value (AV).
Symbol Description
Default
Status
Function
MP01.1 Measuring Point Selection MP No./ bus or analog transmitter
CV Evaluation CV CV = Control by the current gas value
AV = Control by the average gas value
Current/ average value function see also 4.8.6
4.6.9 MP Fault Assigned to Alarm
In this menu you can define, which alarms are activated by a fault at the measuring point.
Symbol Description
Default
Status
Function
MP01.1
Measuring Point
Selection MP No./ bus or analog transmitter
Alarm - 1 2 3 4 5
Fault - 1 1 0 0 0 Failure MP 1 1 0 0 0 0 = Alarm not ON at MP failure 1 = Alarm ON at MP failure
4.6.10 Alarm Assigned to Alarm Relay
Each of the 5 alarms can be assigned to any physically existing alarm relay. Unused alarms are not
assigned to an alarm relay. See also 4.8.16 Relay Multiplication.
Symbol Description
Default
Status
Function
MP01.1
Measuring Point
Selection MP No./ bus or analog transmitter
01
A1
A2
A3
A4
A5
01
02
03
04
00
01 = Alarm 1 activates alarm relay R 01
02 = Alarm 2 activates alarm relay R 02
03 = Alarm 3 activates alarm relay R 03
04 = Alarm 4 activates alarm relay R 04
00 = Alarm 5 doesn’t activate any alarm relay
4.6.11 MP Signal Assigned to Analog Output
The measuring point signal can be assigned to one of the max. twelve analog outputs. The signal defined in
the control mode (current or average value) is transmitted.
Analog output, see also 4.8.15.
Symbol Description
Default
Status
Function
MP01 Measuring Point Selection MP No./ bus or analog transmitter
0 AX 0 0 = MP Signal not assigned to any analog output 1 = MP Signal assigned to analog output 1
X = MP Signal assigned to analog output X

20
June 2012
Gas Controller
AUTOMATIKPRODUKTER
4.7 Menu Data Logger
This function is available from software version 9.02.
But only if the CG-05 controller is equipped with a mini USB interface incl. USB special cable at the bottom side
of the module. This option can’t be retrofit.
Connect an USB device at the USB cable to use the data logger function.
This USB device may be for example an USB stick version 2.0 (not all types have been tested).
In this menu, the parameters for the long-term recording of the USB device are set.
(Main menu)
See 4.7.1
See 4.7.2
See 4.7.3
See 4.7.4
See 4.7.5
4.7.1 Data Logger Switch On/Off
Starting the logger function.
Symbol Description Setting
Status Function
OFF Turned off OFF OFF = Data Logger function is turned off
ON = Data Logger function is turned on
Note:
This function only works with an USB device.
If this function is active, the USB device mustn’t be removed, otherwise data may be lost!! (Like with Windows
– safe removal of USB devices)
Current value
Off
IW Log Rate
10s
Data Logger
Data Logger
Off
Alarm status
Off
Error status
Off
