Aplisens APCE-2000G User manual

DTR.APCE.APRE.02(ENG)
APLISENS
MANUFACTURE OF PRESSURE TRANSMITTERS
AND CONTROL INSTRUMENTS
USER’S MANUAL
SMART PRESSURE TRANSMITTER
type: APCE-2000, APCE-2000G
SMART DIFFERENTIAL PRESSURE TRANSMITTER
type:
APRE-2000, APRE-2000G
Edition D5
WARSAW MARCH 2020
APLISENS S.A. 03-192 Warszawa, ul. Morelowa 7
tel. [phone]; fax [phone]
www.aplisens.pl, e-mail: [e-mail]

Symbols used
BASIC REQUIREMENTS AND SAFE USE
- The manufacturer will not be liable for damage resulting from incorrect installation,
failure to maintain the device in a suitable technical condition, or use of the device
other than for its intended purpose.
- Installation should be carried out by qualified staff having the required authorizations to install
electrical and pressure-measuring devices. The installer is responsible for performing the
installation in accordance with these instructions and with the electromagnetic compatibility
and safety regulations and standards applicable to the type of installation.
- The device should be configured appropriately for the purpose for which it is to be used.
Incorrect configuration may cause erroneous functioning, leading to damage to the device or
an accident.
- In systems with pressure transmitters there exists, in case of leakage, a danger to staff on the
side where the medium is under pressure. All safety and protection requirements must be
observed during installation, operation and inspections.
- If a device is not functioning correctly, disconnect it and send it for repair to the manufacturer
or to a firm authorized by the manufacturer.
In order to minimize the risk of malfunction and associated risks to staff, the device is not to be
installed or used in particularly unfavourable conditions, where the following dangers occur:
- possibility of mechanical impacts, excessive shocks and vibration;
- excessive temperature fluctuation, exposure to direct sunlight;
- condensation of water vapour, dust, icing.
Installation of intrinsic safety versions should be performed with particular care, in accordance
with the regulations and standards applicable to that type of installation.
Changes to the products manufacturing documentation may forestall a paper user updating.
Current Instruction Manual is available at Producer http. on www.aplisens.pl
Symbol
Description
Warning to proceed strictly in accordance with the information contained in the
documentation in order to ensure the safety and full functionality of the device.
i
Information particularly useful during installation and operation of the device.
Information particularly useful during installation and operation of a type Ex device.
Information on disposal of used equipment.

D5 1 DTR.APCE.APRE.02(ENG)
CONTENTS
I. APPENDIX Ex.02................................................................................................................................... 2
1. INTRODUCTION.................................................................................................................................... 5
2. USER MATERIALS................................................................................................................................ 5
3. APPLICATIONS AND MAIN FEATURES............................................................................................... 5
4. IDENTIFYING MARKS. ORDERING PROCEDURE............................................................................... 5
5. TECHNICAL DATA................................................................................................................................ 6
5.1. APCE..., APRE... -COMMON PARAMETERS.................................................................................................................. 6
5.2. APCE-2000 -MEASUREMENT RANGES AND METROLOGICAL PARAMETERS...................................................................... 8
5.3. APRE-2000 -MEASUREMENT RANGES AND METROLOGICAL PARAMETERS...................................................................... 9
5.4. APRE-2000 WITH TWO DIAPHRAGM SEALS.MEASUREMENT RANGES AND METROLOGICAL PARAMETERS ......................... 10
5.5. APCE–2000G, APRE–2000G, MEASUREMENT RANGES AND METROLOGICAL PARAMETERS. ....................................... 10
6. CONSTRUCTION,PRESSURECONNECTORS,ELECTRICALCONNECTORS...........................................................11
6.1. MEASUREMENT PRINCIPLES,ELECTRONIC SYSTEM ..................................................................................................... 11
6.2. CONSTRUCTION ......................................................................................................................................................... 11
6.3. CASING,ELECTRICAL CONNECTIONS........................................................................................................................... 12
7. PLACE OF INSTALLATION OF TRANSMITTERS ...............................................................................12
7.1. GENERAL RECOMMENDATIONS .................................................................................................................................... 12
7.2. LOW AMBIENT TEMPERATURE..................................................................................................................................... 12
7.3. HIGH MEDIUM TEMPERATURE ..................................................................................................................................... 12
7.4 ELECTROSTATIC HAZARDS ........................................................................................................................................... 13
7.5. MECHANICAL VIBRATION,CORROSIVE MEDIA .............................................................................................................. 13
8. INSTALLATION AND MECHANICAL CONNECTIONS.........................................................................13
8.1. APCE... INSTALLATION AND CONNECTIONS.................................................................................................................. 13
8.2. APRE... INSTALLATION AND CONNECTIONS.................................................................................................................. 13
8.3. APRE-2000G. INSTALLATION AND CONNECTIONS ....................................................................................................... 14
9. ELECTRICAL CONNECTION ...............................................................................................................15
9.1. GENERAL RECOMMENDATIONS .................................................................................................................................... 15
9.2. CONNECTIONS FOR TRANSMITTERS WITH PD-TYPE CONNECTOR ................................................................................... 15
9.3. CONNECTIONS FOR TRANSMITTERS WITH TERMINAL BOX (PZ-TYPE CONNECTOR)........................................................... 15
9.4. PROTECTION FROM EXCESS VOLTAGE ......................................................................................................................... 15
9.5. EARTHING ................................................................................................................................................................. 15
10. SETTING AND REGULATION..............................................................................................................16
10.1. TRANSMITTER RANGE,DEFINITIONS.......................................................................................................................... 16
10.2. CONFIGURATION AND CALIBRATION........................................................................................................................... 16
11. SERVICES AND SPARE PARTS..........................................................................................................19
11.1. PERIODIC SERVICE ................................................................................................................................................... 19
11.2. UNSCHEDULED INSPECTIONS .................................................................................................................................... 19
11.3. CLEANING THE DIAPHRAGM SEAL,OVERLOADING DAMAGE ........................................................................................ 19
11.4. SPARE PARTS. ......................................................................................................................................................... 19
12. PACKING, STORAGE AND TRANSPORT ...........................................................................................19
13.GUARANTEE .......................................................................................................................................20
14. SCRAPPING, DISPOSAL .....................................................................................................................20
15. ADDITIONAL INFORMATION...............................................................................................................20
16. FIGURES..............................................................................................................................................20
FIG.1. APCE...,APRE... TRANSMITTERS –BLOCK DIAGRAM. .............................................................................................. 20
FIG.2. ELECTRICAL CONNECTIONS FOR APCE..., APRE... TRANSMITTERS. ......................................................................... 21
FIG.3. APCE-2000 TRANSMITTER WITH PD CONNECTOR. .................................................................................................. 22
FIG.4. APCE-2000 TRANSMITTER WITH PZ CONNECTOR. .................................................................................................. 23
FIG.5. M-TYPE CONNECTOR WITH M20X1.5 THREAD. ......................................................................................................... 24
FIG.6. P-TYPE CONNECTOR WITH M20X1.5 THREAD........................................................................................................... 24
FIG.7. CM30X2-TYPE CONNECTOR WITH FLUSH DIAPHRAGM WITH M30X2THREAD. ............................................................. 24
FIG.8. G1/2” AND G1” PROCESS CONNECTIONS................................................................................................................. 25
FIG.9. APRE-2000 DIFFERENTIAL PRESSURE TRANSMITTER WITH P-TYPE CONNECTOR. ...................................................... 26
FIG.10. APRE-2000 DIFFERENTIAL PRESSURE TRANSMITTER WITH CTYPE VENTED COVERS. .............................................. 27
FIG.11. APRE-2000 DIFFERENTIAL PRESSURE TRANSMITTER WITH A SINGLE DIRECT DIAPHRAGM SEAL (EXAMPLES).............. 27
FIG.12. APRE-2000 DIFFERENTIAL PRESSURE TRANSMITTER WITH TWO REMOTE DIAPHRAGM SEALS (EXAMPLES). .............. 28
FIG.13. APRE-2000 DIFFERENTIAL PRESSURE TRANSMITTER WITH DIRECT DIAPHRAGM SEAL AND REMOTE DIAPHRAGM SEAL 28
FIG.14. APCE-2000G PRESSURE TRANSMITTER AND APRE-2000G DIFFERENTIAL PRESSURE TRANSMITTER FOR LOW
RANGES............................................................................................................................................................. 29
FIG.15. ADDITIONAL EQUIPMENT FOR FITTING OF PRESSURE TRANSMITTERS........................................................................ 30
FIG.16. EXAMPLE:HOW TO INSTALL THE APRE-2000 TRANSMITTERS WITH REMOTE DIAPHRAGM.......................................... 31
FIG.17. EXAMPLE:HOW TO INSTALL THE APRE-2000 TRANSMITTER ON A VERTICAL OR HORIZONTAL PIPE. ........................... 31
FIG.18. EXAMPLE:HOW TO INSTALL THE APRE-2000 TRANSMITTER WITH A VALVE MANIFOLD TO A WALL. ............................. 32

D5 2 DTR.APCE.APRE.02(ENG)
I. APPENDIX Ex.02
SMART PRESSURE TRANSMITTER type APCE–2000, APCE-2000G
SMART DIFFERENTIAL PRESSURE TRANSMITTERS
type APRE-2000, APRE-2000G
Ex VERSIONS
1. Introduction
1.1. This “Appendix Ex.02” applies only to the APCE-2000, APCE-2000G, APRE-2000, APRE-2000G,
intrinsically safe (Exi) transmitters designed in accordance with ATEX Directive, provided with the
rating plate as specified in section and information about Exi design in the Product Certificate.
1.2. The appendix contains supplementary information relating intrinsically safe versions of transmitters.
During installation and use of Ex transmitters, reference should be made to DTR.APC.APR.02(ENG)
in conjunction with “Appendix Ex.02”.
2. Use of APCE-2000, APCE-2000G, APRE-2000, and APRE-2000G
transmitters in hazardous areas
2.1. The transmitters are designed and manufactured in accordance with the requirements of the following
standards:
EN 60079-0:2012+A11:2013, EN 60079-11:2012, EN 50303:2000.
2.2. The transmitters may operate in potentially explosive areas in accordance with the rating of the explosion
protection design:
I M1 Ex ia I Ma
II 1/2G Ex ia IIC T4/T5/T6 Ga/Gb
II 1D Ex ia IIIC T110ºC Da
KDB 12ATEX 0077X
3. Identifying marks
Intrinsically safe transmitters are provided with a rating plate containing the information specified in paragraph
4 of DTR.APCE.APRE.02(ENG) and also at least the following:
- CE mark and number of notified body: 1453 in the case of GIG KDB;
- “Ex” mark, designation of explosion protection design, certificate number;
- Values of parameters such as. Ui, Ii, Pi, Ci, Li;
- Marking of electrical and process connections;
- Year of manufacture.
4. User information
Together with the ordered intrinsically safe transmitters, user receives:
a. Product Certificate, which is also a warranty card;
b. Declaration of Conformity;
c. Copy of certificate –on request;
d. User Manual numbered: DTR.APCE.APRE.02(ENG) with Appendix Ex.02
Items b, c and d are accessed at www.aplisens.pl
5. Permitted input parameters (based on data from the KDB 12ATEX 0077X
and certificates and certification documentation)
- Permissible input parameters for power supply with linear output characteristic
Ui = 30V; Ii = 0.1A; Pi - according to Table 1
- Permissible input parameters for power supply with trapezoidal and rectangular output characteristic
Ui = 24V; Ii = 0.1A;Pi - according to Table 1
Input inductance and capacity: Ci = 11nF; Li = 0,611mH
The dependence of transmitter temperature class from temperature Ta[ºC] and delivered power Pi[W] for all
kinds of power supplies was introduced in Table No 1, where:
Ta –ambient temperature of mounted transmitter (for example at tank).
1453

D5 3 DTR.APCE.APRE.02(ENG)
Appendix Ex.02
Table 1
- Version of transmitter with surge arrester, marked on the plate “Version SA”, does not meet the
requirements of Section 10,3 of the EN 60079-11 (500Vrms). This must be taken into account when
installing the equipment.
- Transmitters with a plastic rating plate and transmitters with teflon coated diaphragm seals, for group
III, should be installed in a place and in a way that prevents electrostatic charging see p.7.4.
Supply examples:
- Power supply with a linear output characteristic may be e.g. a typical barrier with parameters
Uo = 28V; Io = 0.093A; Rw = 300 Ω, Po= 0,65W
Uo
Rw ID
Ui
Fig.1. Power supply from a source with linear characteristic.
- Power supply with a trapezial output characteristic
Example of power supply from a source with trapezial characteristic (see Fig. 2).
UQ = 48V; Uo = 24V; Io = 0,1A; Po = 1,2W
Uo
RwIz
Uq
Rw1 Rw2 ID
Uo
ID
UqUi Ui
Fig. 2. Power supply from a source with trapezial characteristic.
If Uo < then
UQ= , Rw = , Pi =
- Power supply with rectangular output characteristic
The supply of power from a source with a rectangular output characteristic means that the voltage of the Ex
power supply remains constant until current limitation activates.
The protection level of power supplies with a rectangular output characteristic is normally “ib”. Transmitters
powered from such a supply are also an Ex devices with protection level “ib”.
Example of practical provision of power supply for case a):
–use a stabilized power supply with Uo=24V with protection level “ib” and current limited to Io=25mA or
50mA, Po = 1,2W.
transmitter
transmitter
UQ
Ii
4Pi
Ii
UQ
2
Uo(UQ-Uo)
Rw`
Pi [W]
Ta [ºC]
Temperature class
0.75
50
T6
70
T5
80
T4, group I
1.2
40
T6
60
T5
80
T4, group I
i
24V
UQ
48V

D5 4 DTR.APCE.APRE.02(ENG)
Appendix Ex.02
6. How to connect Ex transmitters
Connection between transmitter and other devices in the measuring loop should be made in
accordance with the requirements of intrinsically safe standards and instructions for use in
hazard areas.
Non-compliance with the intrinsic safety requirements may cause the transmitter to explode
and hazard to human safety and health.
At hazardous areas,connections
to the transmitter terminals should
be made using instruments with
Ex certificate.
In the absence of a such
instruments the transmitter
should be configured and
calibrated within a safe zone.
Control
terminal
Hazardous area

M20x1,5
Terminal 2 - "-"
Terminal 1 - "+"
Terminals 1, 2 of the box correspond to terminals 1, 2 of the PD connector.
PZ electrical connector (terminal box),
Earthing terminal
internal
1 "+" 2 "-"
cable
external
Earthing terminal
PG-11 cable gland,
PD electrical connector
cable 8...10 mm
DIN 43650

3
2
+
Ex power supply
F4F1 F2 F3
ABC
1
4
7
STU
JKL
DEF GHI @%&
.
32
VWX
MNO
YZ#
5 6
PQR * +/
98 0
REPF PV F4
_
Ro Z
Safe area
1
+
_
To measure the transmitter output
current without disconnecting
the measuring circuit,
connect a milliammeter
to control terminals 1 and 3.
Ex communicator
cable gland
PG-9 cable gland,
cable 6...8 mm

7. Basic requirements according to EN 60079-25 for type A and B leads used
to connect the transmitter to the power supply and measurement circuit.
7.1. Thickness of insulation according to type of material, but not less than 0.2 mm.
7.2. Insulation strength:
- 2UNbut not less than 500VAC for the wire;
- 500VAC between the cable screen and the connected wires;
- 1000VAC between two groups of wires, each of which contains half the connected wires of the cable.
7.3. Multiwire cable must not carry any circuit which is not an intrinsically safe circuit.
7.4. The cable must not carry circuits with a maximum voltage exceeding 60V.
7.5. The cables should be protected from damage, for example using channels, shielding pipes, cable racks,
durable fastenings etc.
Under no circumstances may the electrical system of the transmitter be repaired or otherwise
handled by the user. Damage assessments and repairs may only be carried out by the
manufacturer or its authorized dealer
i

D5 5 DTR.APCE.APRE.02(ENG)
1. INTRODUCTION
1.1. This User Manual is intended for users of APCE–2000, APCE-2000G smart pressure transmitters,
APRE–2000, APRE–2000G smart differential pressure transmitters. The instruction contains the data and
guidelines necessary to understand the functioning of the transmitters and how to operate them.
It includes essential recommendations concerning installation and use, as well as emergency procedures.
1.2. Technical data for the diaphragm seals for the APCE-2000,APRE-2000, transmitters are contained in the
catalogue cards “DIAPHRAGM SEALS”.
1.3. The transmitters comply with the requirements of EU directives as shown on the plate and with the relevant
Declaration of Conformity.
1.4. Additional information for APCE–2000, APCE-2000G, APRE–2000 and APRE–2000G
transmitters in Ex versions covered by the EU-type test certificate number KDB 12ATEX 0077X is
contained in the appendix designated DTR.APCE.APRE.02(ENG)Appendix Ex.02.
During installation and use of the transmitters in Ex version, reference should be made to
DTR.APCE.APRE.02(ENG) in conjunction with Appendix Ex.02.
1.5. The APCE-2000, APRE-2000 (excluding versions with diaphragm seals) transmitters, with overpressure
limit greater than 200 bar, ordered as a special PED version, made in a version compliant with 2014/68/EU PED
directive category I, module A have the values of parameters PS, PT, TS specified on the rating plate.
The APCE-2000, APRE-2000 (excluding versions with diaphragm seals) transmitters, with overpressure limit
200 bar and lower, are manufactured in accordance with the sound engineering practice according to article 4
point 3 of the PED directive.
1.6. Parameters and information given for APCE..., APRE... transmitters apply to the APCE–2000,
APCE-2000G, APRE-2000, APRE–2000G transmitters and to the explosion-proof versions as well as
all variants with different types of electrical and process connections.
1.7. The APCE..., APRE... transmitters in all versions are complied with the RoHS Directive requirements in
accordance with PN-EN 50581:2013-03 standard.
2. USER MATERIALS
Transmitters are delivered in single and/or multiple packs. Every transmitter is delivered together with:
a. Product Certificate, which is also a warranty card;
b. Declaration of Conformity; for PED according to p. 5.1.5.
c. Copy of certificate –on request;
d. User Manual numbered: DTR.APCE.APRE.02(ENG).
Documents b, c and d are accessed at www.aplisens.pl
3. APPLICATIONS AND MAIN FEATURES
3.1. The APCE... pressure transmitter series are designed to measure gauge pressure, vacuum pressure and
absolute pressure of gases, vapours and liquids including corrosive substances.
3.2. Differential pressure transmitters APRE–2000 series are used to measure liquid levels in closed tanks, with
static pressure up to 250bar or 320bar and 413bar for special versions, and to measure differential pressure
liquid and gases at elements such as filters, orifices, etc.
3.3. The transmitters may be fitted with a range of types of process connectors, which enables them to be
used in a variety of conditions such as thick or highly reactive media, high and low temperatures, etc.
3.4. APRE–2000G transmitters are designed to measure absolute, gauge, and differential pressure of non-
reactive gases. Typical applications are low pressure measurement include the measurement of air blasts,
chimney draughts, or pressure and overpressure in combustion chambers.
The transmitters are constructed up to 350mbar or 1bar overpressures.
3.5. APCE..., APRE... transmitters generate a 4...20mA output signal and a digital communication signal in
a two-wire system. The use of smart electronics enables regulation of the zero point, the measurement range,
damping, radical conversion characteristic and other functions using an Aplisens KAP communicator or
a HART/RS232 converter, Aplisens “RAPORT 2” configuration software and a PC computer.
4. IDENTIFYING MARKS. ORDERING PROCEDURE
4.1. Every transmitter carries a rating plate containing at least the following information: name of manufacturer,
CE mark, numbers of notified institutions and designations of certificates obtained, product type, basic range,
min. set range, static pressure limit, output signal, series number, power supply voltage.
Version types and the method of specifying of the desired product by ordering are described in the current
“Information Cards” and the Catalogue.
i
i

D5 6 DTR.APCE.APRE.02(ENG)
4.2. APCE..., APRE... transmitters in Ex approval have additional markings as are described in
DTR.APCE.APRE.02(ENG) Appendix Ex.02.
4.3. The rating plates of APCE-2000, APRE-2000 (excluding versions with diaphragm seals)
transmitters in versions compliant with the PED pressure directive module A contain maximum
allowable pressure PS, test pressure PT, minimum/maximum allowable temperature TS –see fig.
below. The maximum allowable pressure PS is greater than 200 bar.
where:
C –process connection of APRE-2000 transmitter
XX –process connection of APCE-2000 transmitter
YY –electrical connection
5. TECHNICAL DATA.
5.1. APCE..., APRE... - Common parameters
5.1.1. APCE..., APRE... Electrical parameters
Power supply
- normal versions 7.5 ÷ 55V DC, rated 24V DC
- intrinsic-safe versions 7,5 30V DC”
Output signal 4÷20mA (or 20÷4mA) with HART
Communication via HART transmission protocol and signal 4…20 mA.
For this purpose KAP-03, KAP-03Ex communicator or APLISENS converters: HART/RS232 or HART/USB
Converter, or other HART converter and your PC with Report 2 program (see p.10.2.4).
Resistance required for HART communication min.240
Load resistance RLmax[Ω]=
Constant response time 22 ms (cannot be set by software)
Additional electronic damping 0…30s
Error due to supply voltage changes ± 0.002% (FSO) / 1V
Voltage for insulation testing 500 VAC or 750 VDC, see 9.4.
Excess voltage protection see 9.4.
i
Usup [V] –7.5V
0.0225A

D5 7 DTR.APCE.APRE.02(ENG)
5.1.2. APCE..., APRE.... Permitted environmental conditions
Operating temperature range -40ºC ÷ 85ºC (ambient temperature) –for APCE...
Exi version -40ºC ÷ 80ºC (ambient temperature) –for APCE...
-25ºC ÷ 85ºC (ambient temperature) –for APRE...
Exi version -25ºC ÷ 80ºC (ambient temperature) – for APRE...
-30ºC ÷ 85ºC (ambient temperature) –for APRE-2000G
Operating temperature range for intrinsic-safe versions in accordance with Appendix Ex.02.
Medium temperature range -40ºC ÷ 120ºC –direct measurement –for APCE...
-25ºC ÷ 120ºC –direct measurement –for APRE...,
over 120ºC measurement with the use of a transmission
tube or diaphragm seal.
Medium temperature range -40ºC ÷ 100ºC –for APCE...
for transmitters compliant with PED directive -25ºC ÷ 100ºC – for APRE…
Thermal compensation range -25ºC ÷ 80ºC
-40ºC ÷ 80ºC for special version APCE…
-10ºC ÷ 70ºC for APRE-2000G
Relative humidity 0% ÷ 98%
Vibration during operation max 4g
Exposure to direct sunlight not recommended causing strong transmitter warming
5.1.3. APCE..., APRE... Construction materials
Diaphragm seal for APCE... steel 1.4404/1.4435 (316L) or Hastelloy C276
Diaphragm seal for APRE... steel 1.4404/1.4435 (316L) (PED) or Hastelloy C276
Sensing module steel 1.4404 (316L)
Casing for electronic parts steel1.4301 (304)
Connectors for APCE... steel 1.4404 (316L) or
Hastelloy C276 only for P, GP, CM30x2
C-type vented covers and connectors for APRE... steel 1.4404 (316L)
Liquid filling of the interior the sensing module Silicone oil, chemically inactive liquid for measurement
of oxygen.
5.1.4. APCE..., APRE... Ingress Protection Rating of Case according to EN 60529
IP65 - PD type connector; IP66 - PZ type connector.
5.1.5. APCE-2000, APRE-2000 for PED version
The APCE-2000, APRE-2000 (excluding versions with diaphragm seals) transmitters with an
acceptable overload exceeding 200 bar ordered as special PED designs are supplied with the
manufacturer's declaration of compliance with the pressure directive 2014/68/EU cat. I, module A.
The conformity assessment procedures provided for Module A have been applied. The process is
based on internal control covering the design phase as well as the production phase.
These transmitters are designed as pressure accessories for measuring group 1 media pressures
(hazardous) and for acceptable overloads higher than 1000 bar for measuring group 1 and 2 media
pressures.
The APCE-2000, APRE-2000 (excluding versions with diaphragm seals) transmitters with an
acceptable 200 bar overload and a lower one are manufactured in accordance with Article 4 para. 3 of
directive 2014/68/EU. Design and manufacture is in accordance with the sound engineering practice to
ensure safe use.
The manufacturer does not issue a declaration of conformity with the pressure directive 2014/68/EU for
these transmitters.
i

D5 8 DTR.APCE.APRE.02(ENG)
5.2. APCE-2000 - Measurement ranges and metrological parameters.
5.2.1. APCE-2000, Measurement ranges
N
Nominal measuring range
(FSO*)
Minimum set range
Rangeability
Overpressure limit
(without hysteresis)
1.
0...1000bar (0...100MPa)
10bar (1MPa)
100:1
1200bar (120MPa)
2.
0...600bar (0...60MPa)
6bar (600kPa)
100:1
1200bar (120MPa)
3.
0...300bar** (0...30MPa)
3bar (300kPa)
100:1
450bar (45MPa)
4.
0...160bar** (0...16MPa)
1.6bar (160kPa)
100:1
450bar (45MPa)
5.
0...70bar** (0...7MPa)
0.7bar (70kPa)
100:1
140bar (14MPa)
6.
-1...70bar** (-0,1...7MPa)
0.71bar (71kPa)
100:1
140bar (14MPa)
7.
0...25bar** (0...2.5MPa)
0.25bar (25kPa)
100:1
50bar (5MPa)
8.
0...7bar** (0...0.7MPa)
0.07bar (7kPa)
100:1
14bar (1.4MPa)
9.
-1...25bar** (-0,1...2.5MPa)
0.26bar (26kPa)
100:1
50bar (5MPa)
10.
-1...7bar** (-100...700kPa)
0.08bar (8kPa)
100:1
14bar (1.4MPa)
11.
-1…1.5bar** (-100…150kPa)
0.12bar (12kPa)
20:1
4bar (400kPa)
12.
0...2bar** (0...200kPa)
100mbar (10kPa)
20:1
4bar (400kPa)
13.
0...1bar** (0...100kPa)
50mbar (5kPa)
20:1
2bar (200kPa)
14.
-0.5...0.5bar** (-50...50kPa)
50mbar (5kPa)
20:1
2bar (200kPa)
15.
0...0.25bar** (0...25kPa)
25mbar (2,5kPa)
10:1
1bar (100kPa)
16.
-100...100mbar** (-10...10kPa)
20mbar (2kPa)
10:1
1bar (100kPa)
17.
-15...70mbar*/** (-1.5...7kPa)
5mbar (0.5kPa)
17:1
0.5bar (50kPa)
18.
-25...25mbar*/*** (-2.5...2.5kPa)
2mbar (0.2kPa)
25:1
1bar (100kPa)
19.
-7...7mbar*/*** (-7...7kPa)
1mbar (0.1kPa)
14:1
1bar (100kPa)
20.
0...1,3bar abs (0...130kPa abs)
100mbar abs (10kPa abs)
13:1
2bar (200kPa)
21.
0...7bar abs (0...7MPa abs)
100mbar abs (10kPa abs)
70:1
14bar (1.4MPa)
22.
0...25bar abs (0...2.5MPa abs)
0.25bar abs (25kPa abs)
100:1
50bar (5MPa)
23.
0...70bar abs (0...7MPa abs)
0.7bar abs (70kPa abs)
100:1
140bar (14MPa)
24.
0...300bar abs (0...30MPa abs)
3bar abs (300kPa abs)
100:1
450bar (45MPa)
* - transmitters not available with diaphragm seal; ** - transmitters available in HS version;
***- transmitters available only in HS version.
**** overpressure limit can be different for version according to pressure directive 2014/68/EU PED
5.2.2. APCE-2000, Metrological parameters
Accuracy ± 0.1% of calibrated range
Long term stability accuracy for 3 years
(for the nominal measuring range) 2 x accuracy for 5 years
HS version accuracy for 6 years
HS version 2 x accuracy for 10 years
Thermal error ± 0.08% (FSO) / 10ºC
(± 0.1% for ranges n16, 17, 18, 19).
Thermal error for the whole thermal ± 0.25% (FSO)
compensation range (± 0.4% for ranges n16, 17, 18, 19).

D5 9 DTR.APCE.APRE.02(ENG)
5.2.3. APCE-2000, Pressure Connectors
- M-type connector with M20x1.5 thread –see figure 5a;
- P-type connector with M20x1.5 thread –see figure 6a;
- CM30x2-type connector with flush diaphragm –see figure 7a;
- G1/2 -type connector with G1/2” thread – see figure 8a;
- GP -type connector with G1/2” thread;
- CG1-type connector with G1” thread and flush diaphragm;
- RM –type connector with M20x1.5 thread with radiator;
- RP –type connector with M20x1.5 thread with hole Φ12 with radiator;
- G1/4 –type connector with G1/4” thread with hole Φ4;
- 1/2NPT M type connector with 1/2NPT tread;
- 1/2NPT F type connector with 1/2NPT tread;
- R1/2-type connector with R1/2 tread;
- CG1/2-type connector with G1/2 tread and flush diaphragm;
- Other connection types by arrangement.
5.3. APRE-2000 - Measurement ranges and metrological parameters
5.3.1. APRE-2000, Measurement ranges
N
Nominal measuring range
(FSO)
Minimum set
range
Rangeability
Overpressure
limit
Static
pressure limit
1
0...70bar (0...7MPa)
7bar (700kPa)
10:1
exception: 70bar for P-type
2
0...16bar* (0...1,6MPa)
1,6bar (160kPa)
10:1
C-type: 250 / 320 / 413 bar
P-type: 40 bar (for range no.1)
3
0...2,5bar (0...250kPa)
0,2bar (20kPa)
12,5:1
4
0...1bar* (0...100kPa)
50mbar (5kPa)
20:1
5
0...0,25bar* (0...25kPa)
10mbar (1kPa)
25:1
6
-0,5...0,5bar* (-50...50kPa)
0,1bar (10kPa)
10:1
7
-100...100mbar* (-10...10kPa)
10mbar (1kPa))
20:1
8
-5...70mbar* (-0,5...7kPa)
4mbar (0,4kPa)
18:1
9
-25...25mbar* (-2,5...2,5kPa)
2mbar (0,2kPa)
25:1
C-type: 200bar
P-type: 40bar
10
-7...7mbar** (-700...700Pa)
1mbar (0,1kPa)
14:1
20bar
* - available also in HS version;
** - available only in HS version.
5.3.2. APRE-2000, Metrological parameters
Accuracy ± 0.1% for the basic range
Long term stability accuracy for 3 years
(for the nominal measuring range) 2 x accuracy for 5 years
HS version accuracy for 6 years
HS version 2 x accuracy for 10 years
Thermal error ± 0.08% (FSO) / 10ºC
Thermal error for the whole thermal
compensation range ± 0.3% (FSO)
Zero shift error for static pressure* ± 0.01 % (FSO) / 10 bar (for ranges n3, 4, 5, 6, 7, 9)
± 0.03 % (FSO) / 10 bar (for range n8)
± 0.06 % (FSO) / 10 bar (for ranges n1, 2)
± 0.01 % (FSO) / 10 bar (for ranges n2, 8) in HS version
± 0.02 % (FSO) / 10 bar (for range n10)
Cut-off on radical characteristic curve of up to10%
* Error can be eliminated by the transmitter zeroing in static pressure conditions with zero differential pressure.
5.3.3. APRE-2000, Pressure Connectors
APRE-2000 without diaphragm seals - P-type connector with M20x1.5 thread –see fig.9 or C-type connector to
mount together with a valve manifold see fig.10.
APRE-2000 with single direct diaphragm seal –as in the example (figure 11) or with other diaphragm seals in
accordance with catalogue cards “DIAPHRAGM SEALS”.

D5 10 DTR.APCE.APRE.02(ENG)
5.4. APRE-2000 with two diaphragm seals. Measurement ranges and
metrological parameters
5.4.1. APRE-2000 with two diaphragm seals. Measurement ranges
Nominal range
(FSO)
Minimum set
range
Vertical
spacing of
diaphragm
seals.
Maximum configurable range dependent
on the actual vertical spacing of
diaphragm seals. (m)
Static
pressure limit
-160...160 mbar
0.1 mH2O
1.7m
[1,6+( vertical spacing of sealsx94)]mH2O
40bar
-0.5...0.5 bar
0.5 mH2O
6m
[5+(vertical spacing of sealsx1.04)]mH2O
40bar
-1.6...2 bar
1.5 mH2O
15m
[20+(vertical spacing of sealsx1.04)]mH2O
40bar
-1.6...16 bar
1bar
15m
16bar
40bar
5.4.2. APRE-2000 with two diaphragm seals. Metrological parameters
Accuracy
0.1% (FSO)
Thermal error
0.08 % (FSO) / 10ºC
Thermal error for the whole thermal compensation range
0.3 % (FSO)
Zero shift error for static pressure
see p. 5.3.2.
Additional errors due to effects of sealing
see catalogue cards “DIAPHRAGM SEALS”.
The maximum vertical diaphragm seal spacing shown in the table applies to level measurement,
ensuring that it is possible to set the zero point of the transmitter when the tank is empty.
For measurements of density or phase boundaries (in the sugar and chemical industries and in
refineries) the vertical spacing of the diaphragm seals can be larger.
5.4.3. APRE-2000 with two diaphragm seals. Permitted Environmental Conditions.
Vibration during operation: vibration of the transmitter is not recommended, but vibration is permissible at the
place where the seals are installed. Permitted temperature and corrosive properties of medium are dependent
on the diaphragm seal type (see catalogue cards “DIAPHRAGM SEALS”).
Other parameters as given in 5.1.
5.4.4. APRE-2000 with two diaphragm seals. Pressure Connectors
See fig. 12, 13 and for other remote diaphragm seals - see catalogue cards “DIAPHRAGM SEALS”.
5.5. APCE–2000G, APRE–2000G, Measurement ranges and metrological
parameters.
5.5.1 APCE–2000G, APRE–2000G. Measurement ranges
N
Nominal range
(FSO)
Minimum set range
Overpressure
limit
Static pressure limit
1
0...25mbar (0...2500Pa)
1mbar (100Pa)
1bar
350mbar
2
-2.5...2.5mbar (-250...250Pa)
0,2mbar (20Pa)
350mbar
350mbar
3
-7...7mbar (-700...700Pa)
1mbar (100Pa)
350mbar
350mbar
4
-25...25mbar (-2500...2500Pa)
5mbar (500Pa)
1bar
1bar
5
-100...100mbar (-10...10Pa)
20mbar (2kPa)
1bar
1bar
5.5.2. APCE–2000G, APRE–2000G. Metrological parameters
Nominal range
0...25mbar
-2,5...2,5mbar
-7...7mbar
-25...25mbar
-100...100mbar
Accuracy
0.075 %
0.25 %
0.1 %
0.1 %
0.075 %
Thermal error
0.1 % (FSO)/ 10ºC,
max 0.4 % (FSO) for the whole thermal compensation range
Thermal
compensation
range
-10 … 70ºC
i

D5 11 DTR.APCE.APRE.02(ENG)
5.5.3. APCE–2000G, APRE–2000G. Construction Materials
Adapter M20x1.5/6x1 brass
Valve manifold Stainless steel 1.4404 (316L)
Adapter for valve manifold Stainless steel 1.4404 (316L)
Connector ¼ NPT brass, steel 1.4404 (316L) or St3S+ (galvanized)
(Other materials as given in 5.1.3 for APRE..., APRE-2000).
5.5.4. APCE–2000G, APRE–2000G. Pressure Connectors
- The terminals fit ø 6x1 plastic tubes;
- Adapter to a valve manifold or ¼ NPT connector - (see. 8.3. and fig.14).
6. CONSTRUCTION,PRESSURECONNECTORS,ELECTRICAL CONNECTORS
6.1. Measurement Principles, Electronic System
APCE... electronic pressure transmitters and APRE... electronic differential pressure transmitters work by
converting changes in the resistance of a piezoresistance bridge, which are proportional to the pressure
difference being measured, into a standard current signal.
The active sensing element is a silicon diaphragm with four (bridge) piezoresistors, separated from the medium
by a sealing diaphragm and manometric fluid.
The electronic system digitally processes the measurement signal and generates output signals: an analogue:
4÷20 mA signal, and a digital HART communication signal.
A transmitter electrical block diagram is presented in Figure 1. On the input circuit two analogue signals are
formed, reflecting the measured pressure and the sensing module temperature. These signals are digitized and
imputed to a microprocessor. Using data input during the production process adjusts for thermal errors and
carries out linearization.
After processing, the digital signal is converted into an analogue 4÷20mA current signal, with a superimposed
digital communication signal.
For communication with the transmitter via analog signal line the Aplisens KAP communicator, or a PC
computer meeting the requirements given in 10.2.4, is used.
The transmitter’s input point is fitted with a noise filter and elements protecting against excess voltage.
Plasma surge arrester is installed in the special Exi version on request. The transmitter then has got, on rating
plate, marking "Version SA".
6.2. Construction
The main components of the smart pressure transmitter is the sensing module, in which the pressure signal is
converted into an electrical signal, and the electronic system, which converts the signal from the sensing
module into a 4...20mA output analog signal and produces a digital HART signal.
6.2.1. To the APCE-2000, sensing module transmitters may be installed the pressure connectors as in figures
5a, 6a, 7a, 8 or other. They are equipped with a diaphragm separating the internal part of the head from the
medium.
6.2.2. In the APRE–2000 transmitters, the sensing module has two kind of process connectors: P-type
connectors (figure 9), or C-type with covers connecting for installation on a valve manifold (figure 10).
6.2.3. The APRE–2000 transmitters may be fitted with a single direct diaphragm seal, mounted on the “+”
pressure input of the sensing module, while the “–” input is a ¼NPT socket (figure 11).
The APRE–2000 transmitter is fitted with two diaphragm seals and can be produced in two versions:
- with one direct diaphragm seal and one remote diaphragm seal (figure 13);
- with two remote diaphragm seals (figure 12).
The diaphragm seal transmits the pressure obtained from the medium. The pressure is transmitted via a
manometric fluid which fills the space between the diaphragm of the seal and the diaphragm of the sensing
module. In the case of remote diaphragm seals, pressure is transmitted via a capillary linking the transmitter’s
sensing module to the diaphragm seal.
The construction of the seals depends on the medium properties and operating conditions for which they are
intended.
Technical data relating to the diaphragm seals’ dimensions and operating conditions can be found in catalogue
cards “DIAPHRAGM SEALS”.
6.2.4. The APRE-2000G are designed to the low pressures measurement of non-aggressive gases, with
a permitted overpressure of 350mbar or 1bar. The basic (economy) version of this transmitter has terminals
fitting ø6x1 elastic tubes, while the industrial version has adapters as shown in figure 14.

D5 12 DTR.APCE.APRE.02(ENG)
6.3. Casing, Electrical Connections
APCE..., APRE... transmitters are cased in an Ø51 pipe with a PD (DIN 43650) or PZ type connector.
6.3.1. The PD type connector (figure 3) is located on the top of the casing (Ø51 pipe) and sealed with a rubber
washer.
6.3.2. Transmitters with a PZ type connector (figure 4) have a terminal box connected permanently to the
casing. The box is closed with a lid and has an external and internal earthing terminal. Mounted on the inside
a terminal block is equipped with additional control terminals, galvanically connected to terminals 1, 2 and 3.
7. PLACE OF INSTALLATION OF TRANSMITTERS
7.1. General recommendations
7.1.1. The pressure transmitters and differential pressure transmitter can be installed both indoors and
outdoors. It is recommended that transmitters installed outdoor should be placed in a box or under cover. There
is no need for a cover in the case of transmitters with PZ type electrical connector.
7.1.2. The place of installation should be chosen in such a way as to allow access to the device and to protect it
from mechanical damage. In planning the transmitter installation and the pulse lines configuration, should be
paid attention to the following requirements:
- The impulse lines should be as short as possible, with a sufficiently large cross-section, and free of
sharp bends, in order to prevent blockages.
- Where the medium is a gas, the transmitters should be installed above the measuring point, so that
condensation flows down towards the site of the pressure measurement; where the medium is a
liquid or where a protective liquid is used, the transmitters should be installed below the place where
the pressure measurement is taken.
- The impulse lines should be inclined at a gradient of at least 10cm/m.
- The levels of filling liquid in the impulse lines should be equal or kept constant difference.
- The configuration of the impulse lines and the valve connection system should be chosen with regard
to the measurement conditions and to requirements such as the need to reset the transmitters in
position and the need for access to the impulse lines during water or gas removal and flushing.
7.1.3. Where there is a risk of heavy objects hitting the instrument (resulting, in extreme cases,
in a part of the system with transducers being torn off and medium leakage), appropriate means
of protection should be applied for safety reasons and to avoid the possibility of sparkling or
other, more appropriate location should be selected for the transmitter.
7.1.4. Attention should also be paid to possible installation faults which may lead to measurement errors, such
as connections which are not tight, sediment blockage in lines which are too narrow, gas bubbles in a liquid line
or liquid column in a gas line etc.
7.2. Low Ambient Temperature
When the solidification point of the liquid whose pressure is being measured is greater than the
ambient temperature, steps should be taken to protect the measurement apparatus from
freezing effects.
This is particularly important in the case open-air installations.
Protection is obtained by filling the impulse lines with a mixture of ethylene glycol and water, or another liquid
whose solidification point does not exceed the ambient temperature. Thermal insulation can protect the casing
of the transmitter and lines only from brief exposure to low temperatures. Where the temperature is very low,
the transmitter and impulse lines are should be heated.
7.3. High Medium Temperature
The APCE..., APRE... transmitters may be used to measure media with temperatures of up to 120ºC.
To protect the sensing module from temperatures in excess of 120ºC, suitably long impulse lines are used to
disperse the heat and to lower the temperature of the module.
Where it is not possible to use impulse lines of the required length, APCE..., APRE... transmitters with remote
diaphragm seals should be used (see catalogue cards “DIAPHRAGM SEALS”).
Temperature applications for Ex versions in accordance with Appendix Ex.02.
i

D5 13 DTR.APCE.APRE.02(ENG)
7.4 Electrostatic hazards
Plastic rating plate and teflon on the diaphragm seals are non-conductive layer applied on conductive surface.
Transmitters in this version should be installed in locations with no possibility of electrostatic charging.
In particular through contact with electrified dust falling or exhaled from devices operating nearby.
For Exi version are valid data by Appendix Ex.02.
7.5. Mechanical Vibration, Corrosive Media
7.5.1. Transmitters should correctly work with vibrations with amplitudes to 1.6 mm and accelerations to 4g.
If strong vibrations are carried via the pressure line and disturb of measuring, use should be made of elastic
pulse lines or transmitters with a remote diaphragm seal.
7.5.2. Transmitters should not be installed in places where the diaphragm, made of 1.4404/1.4435
(316L) steel, would be subject to corrosion by the medium being measured.
If possible, transmitters with diaphragms made of Hastelloy C276 should be used, or other means of
protection applied (e.g. in the form of a separating liquid) or transmitters with diaphragm seals adapted
for measuring aggressive mediums according to catalogue cards “DIAPHRAGM SEALS”) should be used.
8. INSTALLATION AND MECHANICAL CONNECTIONS
APCE-2000 pressure transmitter with measuring ranges -7÷7 mbar and -25÷25 mbar
and APRE-2000G differential pressure transmitters should be mounted in a vertical position
with the process connectors downwards.
Others APCE..., APRE... transmitters can operate in any position.
When installed on an object with a high-temperature medium, it is advantageous to mount the transmitter in a
horizontal position with the packing gland pointing downwards or to the side, in such a way that the transmitter
is kept away from the stream of rising hot air.
When the measurement range is small, the reading can be affected by the position of the transmitter and by the
configuration of the impulse lines and the way in which they are filled with liquid.
This error can be corrected using the zero-setting function after transmitter installation.
8.1. APCE... Installation and connections
8.1.1. The APCE... transmitters can be installed directly on rigid impulse lines.
Where connectors are used as in figures 5a, 6a and 7a, it is recommended that connection sockets be used as
shown in figure 5b, 6b, 7b or 7c.
It is recommended that sockets labelled “Socket CG1” and “Socket CG1/2” Fig. 8 are used for CG1 and CG1/2
connections, respectively.
Besides, there are adapters for standard DIN50, (DIN40, DIN25, Clamp2”, Clamp1.5”, Clamp1”) type connections
provided for readouts carried out in aseptic conditions using transmitters with CM30x2 connection.
There are seals provided for every transmitter with P, CM30x2, CG1, CG1/2 and GP type connections.
The seal material is selected based on the pressure value and the type and temperature of the medium.
8.1.2. If the pressure is applied via a flexible plastic tube, the transmitter should be mounted on a support with
Red Ø6-M reduction. In case of metal pipes, the used connections should comply with PN-82/M-42306.
The types of the impulse tubes (Fig. 15) are to be selected depending on the measured value of the pressure
and the medium temperature.
8.1.3. Tighten the transmitter in the socket with a torque appropriate for the type of the used seal and the
measured pressure.
8.2. APRE... Installation and connections
8.2.1. The APRE 2000 transmitters can be mounted directly on rigid impulse lines.
To connect the transmitters basic versions, with two M20x1.5 stubs (P-type connector), can be use straight
connecting elements with nuts (type C). If elastic impulse lines are used for connection purposes, the
transmitter should be additionally fastened to a pipe, panel or supporting construction.
8.2.2. The APRE-2000 can be installed using the fastener ø25 (figure 16.) on an ø25 pipe or on a flat surface
using an angle bracket.

D5 14 DTR.APCE.APRE.02(ENG)
8.2.3. The APRE-2000 with connecting cover (C-type connector) (figure 10) are designed for installation on
3-valve or 5-valve manifolds to a 2” pipe or to a flat surface using an fastener C-2” (fig.17) or “U” (fig.18).
It is not permitted to unscrew the screws fixing the C type connection covers.
Interference will result in loss of warranty.
8.3. APRE-2000G. Installation and connections
8.3.1. The “economy” version of the APRE-2000G transmitter can be mounted on a wall, panel or other stable
construction, using a clamp with Ø9 holes (Figure 14).
The transmitter is fitted with stubs which fits an Ø6x1 elastic impulse tube.
When the measured impulse is transmitted via a metal terminal with M20x1.5 opening, an adapter is used
between the M20x1.5 thread and the Ø6x1 terminal.
Transmitters should be installed in a vertical position.
Where there is a significant difference between the height at which the transmitter is mounted and the height of
the impulse source, particularly if the measurement range is small, the reading may fluctuate depending on the
temperature difference between the impulse lines.
This effect can be reduced by ensuring that the lines run side by side.
The APRE-2000G transmitter can also be fitted with an adapter (Figure 14) creating a C-type connector,
designed for installation on a 3-valve or 5-valve manifold. Aplisens can also supply transmitters ready mounted
on valves.
Pressure may be transmitted to the installed device only after checking that it has a
measurement range which properly corresponds to the value of the measured pressure, that
gaskets have been properly selected and fitted, and the connector has been properly screwed
tight.
Attempts to undo the screws or fixing connector pipes on a transmitter under pressure may
cause the medium to leak and create hazards for the personnel.
When disassembling the transmitter, it is necessary to disconnect it from the process pressure
or bring the pressure to atmospheric level, and to take particular care and precautions in case
of media which are highly reactive, caustic, explosive or otherwise hazardous to personnel.
If necessary, rinse out this part of the system.
Transmitters with flange diaphragm seals are to be installed on the corresponding counter flanges on
the facility.
It is recommended that the user matches the screw joints material to the pressure, temperature, flange
material and seal to ensure tightness of the flange joint in the expected operating conditions.
Coarse-threaded screws complying with ISO 261 are to be used for flanges used in the APCE...,
APRE... transmitters.
Additional data concerning the diaphragm seals are specified in the catalogue cards “DIAPHRAGM SEALS”.
i

D5 15 DTR.APCE.APRE.02(ENG)
9. ELECTRICAL CONNECTION
9.1. General recommendations
It is recommended that twisted pair cabling be used for the signal lines. If the transmitter and signal line are
subject to a large amount of electromagnetic interference, then screened twisted pair cable should be used.
The signal wires should not run alongside network power supply cables or near to large electrically-powered
devices.
The devices used together with the transmitters should be resistant to electromagnetic interference from the
transmission line in accordance with compatibility requirements.
It is also beneficial to use anti-interference filters on the primary side of the transformers, the power supplies
used for the transmitters and apparatus used in conjunction with them.
9.2. Connections for transmitters with PD-type connector
The transmitters with PD type connectors are to be connected as shown in figure 2a.
To make the connections, remove the terminal block from the contact pins together with its cover.
Then remove the block from its cover, levering it off with the end of a screwdriver inserted into the slot provided
for this purpose. Connect the wires to the block.
Where the isolation of the wires in the cable gland is ineffective (for example, when single wires are used)
the opening of the gland should be carefully sealed with an elastic sealing compound to obtain IP65
ingress protection. It is useful to form the segment of the signal wire leading to the PG-11, PG-9 cable
gland into a protective loop to prevent condensation from running down in the direction of the gland.
9.3. Connections for transmitters with terminal box (PZ-type connector)
The transmitters with PZ-type connectors should be connected by linking the signal wires to a terminal block, as
shown in figure 2a and 2b. Carefully screw in the cover and cork of the packing gland, making sure that the wire
is tightly packed. Where necessary, the packing gland should be further sealed as described in 9.2.
9.4. Protection from excess voltage
9.4.1. The transmitters may be in danger from excess voltage caused by connection faults or atmospheric
electrical discharge. Protection from excess voltage between the wires of the transmission line is provided by
TVS diodes installed in all types of transmitter (see the table, column 2).
9.4.2. In order to protect against excess voltage between the transmission line and the casing or earth (not
prevented by the diodes connected between the transmission wires), additional protection is provided in the
form of plasma surge arresters or TVS diodes (see the table, column 3).
In the case of unprotected transmitters, external protective devices may be used, e.g. the UZ-2 system
produced by Aplisens, or others. When the transmission lines are long, it is advantageous to use one
protective device near the transmitter (or inside it), and another near entry points to other devices used in
conjunction with it.
Internal protection of transmitters:
9.4.3. The voltage in the protective elements must not exceed the maximum permitted values given in columns
2 and 3 of the table.
The insulation test voltages (500V AC or 750V DC) given in 5.1.1 refer to transmitters without plasma
surge arresters - such protection is not used in Ex versions of transmitters.
9.5. Earthing
The transmitters are fitted with internal and external earth terminals.
i
1
2
3
Type of
transmitter
Protection between wires (transil
diodes) –permitted voltage
Protection between wires and earth and/or casing –
type of protection, permitted voltage
APCE...,
APRE...
39V DC
Plasma surge arresters - 100V DC
(for normal and SA version)
i

D5 16 DTR.APCE.APRE.02(ENG)
10. SETTING AND REGULATION
APCE..., APRE... transmitters are factory calibrated to the range stated in the order or to the basic range.
After installation, the transmitter’s zero-point may drift and require adjustment.
This applies particularly in cases where the measurement range is small, where the impulse lines are filled with
a separating liquid or where APCE..., APRE... transmitters are used with remote diaphragm seals.
10.1. Transmitter Range, Definitions
10.1.1. The maximum range of absolute or differential pressure which the transmitter can measure is called
the “basic range” (for specifications of basic ranges see 5.2.1, 5.3.1, 5.4.1 and 5.5.1 and 5.6.1).
The width of the basic range is the difference between the upper and lower limits of the basic range.
The internal characteristic conversion curve for the basic range is coded in the transmitter’s memory.
This is the reference curve used when making any adjustments which affect the transmitter’s output signal.
10.1.2. When the transmitter is in use the term “set range” is used. The set range is the range whose lower
end-point corresponds to an output current of 4mA and whose upper end-point corresponds to a current of
20mA (or 20mA and 4mA respectively when the conversion curve is inverted).
The set range may cover the whole of the basic range or only a part of it.
The width of the set range is the difference between its upper and lower end-points.
The transmitter may be set to any range within the basic range of pressure values, subject to the restrictions set
out in the table in 5.2.1, 5.3.1, 5.4.1, 5.5.1 and 5.6.1.
10.2. Configuration and Calibration
10.2.1. The transmitter has features which enable metrological and identification parameters to be set and
altered. The configurable metrological parameters affecting the transmitter’s output current include the
following:
a) unit in which the measured pressure is expressed on the display;
b) upper end-point of the set range;
c) lower end-point of the set range;
d) time constant;
e) type of characteristic curve: linear or radical.
Parameters of an informational nature which cannot be altered include the following:
f) upper limit of the maximum range;
g) lower limit of the maximum range;
h) minimum range.
10.2.2. Other identification parameters, not affecting the output signal, include: device address, device type
code, factory identification code, factory device code, number of preambles (3÷20), UCS, TSD, program
version, electronics version, flags, factory number, label tag, description tag, date tag, message, record number,
sensing module number.
The process of setting the parameters listed in 10.2.1 and 10.2.2 is called “Configuration”.
10.2.3. It is possible to carry out a “pressure zeroing” procedure, for example in order to compensate for
measurement deviation caused by a change in position when the transmitter is installed.
The transmitter may also be calibrated, by taking readings with the input pressure controlled using a standard
device. This process and zero-point adjustments are called “Calibration”.
10.2.4. Configuration and Calibration of the transmitter are carried out using an Aplisens KAP-03
communicator, certain HART communicators or a PC with HART/RS232 or HART/USB Converter and Aplisens
Raport 2 software.
Together with the “RAPORT 2” configuration software there is “INTERVAL LINEARIZATION” software supplied
to enable the input of 21-point nonlinear functional characteristics to the transmitter.
A description of the functions of the KAP communicator is contained in the KAP Communicator Operating
Manual.
After configuration it is important to protect the transducers using command HART [247].
During work transmitter should be safe prior to entries. This prevents accidental or intentional
changes configurational data. The protection function is accessible in KAP-03 communicator,
“Raport's 2” software, as well as, in applying DD or DMT programs libraries.

D5 17 DTR.APCE.APRE.02(ENG)
10.2.5. Configuration of the APRE-2000 transmitters to measure the level, density of
liquid and phase boundary

D5 18 DTR.APCE.APRE.02(ENG)
KAP-03
an APRE-2000
the APRE-2000
