Aplisens APT-2000ALW User manual

USER’S MANUAL
TEMPERATURE TRANSMITTER
APT-2000ALW
Version in accordance with EN 12405-1:2018 Standard (MID)
EN.IO.APT.ALW.MID
JANUARY 2022
APLISENS S.A., 03-192 Warsaw, Morelowa 7 St,
tel. [phone]; fax [phone]
www.aplisens.com, e-mail: [email protected]
Revision 01.A.001

Symbols used
Symbol
Description
Warning to proceed strictly in accordance with the information contained in the
documentation in order to ensure the safety and full functionality of the device.
Information particularly useful during installation and operation of the device.
Information particularly useful during installation and operation of anExtype device.
Information on disposal of used equipment.
BASIC REQUIREMENTS AND SAFE USE
The manufacturer will not be liable for damage resulting from incorrect installation,
failure to maintain a suitable technical condition of the device or use of the device
other than for its intended purpose.
Installation should be carried out by qualified staff having the required authorizations
to install electrical and I&C equipment. The installer is responsible for performing
the installation in accordance with manual as well as with the electromagnetic
compatibility and safety regulations and standards applicable to the type of
installation.
In systems with I&C equipment, in case of leakage, there is a danger to staff due to
the medium under pressure. All safety and protection requirements must be
observed during installation, operation and inspections.
If a malfunction occurs, the device should be disconnected and handed over to the
manufacturer for repair.
In order to minimize the risk of malfunction and associated risks to staff, the device
is not to be installed or used in particularly unfavourable conditions, where the
following hazards occur:
−possible mechanical impacts, excessive shocks and vibration;
−excessive temperature fluctuation;
−water vapour condensation, dusting, icing.
Changes made to the manufacturing of products may be introduced before the paper version of the
manual is updated. The up-to-date manuals are available on the manufacturer's website:
www.aplisens.com.

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 3
TABLE OF CONTENTS
1. INTRODUCTION ......................................................................................... 5
1.1. Purpose of the document.......................................................................................................5
1.2. Trademarks ...........................................................................................................................5
1.3. Definitions and abbreviations.................................................................................................5
1.4. Transmitter set range.............................................................................................................6
2. SAFETY ...................................................................................................... 6
3. TRANSPORT AND STORAGE ................................................................... 7
3.1. Delivery check.......................................................................................................................7
3.2. Transport...............................................................................................................................7
3.3. Storage..................................................................................................................................7
4. GUARANTEE.............................................................................................. 7
5. IDENTIFICATION........................................................................................ 8
5.1. Manufacturer’s address .........................................................................................................8
5.2. Transmitter identification........................................................................................................8
5.3. CE mark, declaration of conformity........................................................................................8
6. INSTALLATION .......................................................................................... 8
6.1. General recommendations.....................................................................................................8
7. ELECTRICAL CONNECTION ..................................................................... 9
7.1. Cable connection to transmitter terminals..............................................................................9
7.1.1. Cable connection ...........................................................................................................9
7.1.2. Connection of transmitter with the option of using local HART communication...............9
7.2. Transmitter power supply.....................................................................................................11
7.2.1. Transmitter supply voltage ...........................................................................................11
7.2.2. Uninterruptible current measurement in 4…20 mA current loop ...................................11
7.2.3. Specifications of electrical switching terminals .............................................................11
7.2.4. Cabling specification ....................................................................................................11
7.2.5. Resistance load in power supply line............................................................................12
7.2.6. Shielding, equipotential bonding...................................................................................12
7.3. Overvoltage protection.........................................................................................................12
7.4. Final inspection of cabling....................................................................................................12
8. OPERATION ............................................................................................. 13
8.1. Local LCD display................................................................................................................13
8.2. Local buttons.......................................................................................................................14
8.3. Local configuration of setpoints............................................................................................14
8.4. Navigation in local setpoints MENU.....................................................................................14
8.5. Acceptance of local setpoints...............................................................................................14
8.6. Structure of local setpoints MENU .......................................................................................15
8.7. Remote configuration of setpoints (HART 5)........................................................................16
8.7.1. Compatible devices......................................................................................................16
8.7.2. Compatible configuration software ...............................................................................17
8.7.3. Local HART communication jumper.............................................................................17
9. START-UP ................................................................................................ 17
9.1. Alarm configuration..............................................................................................................17
9.2. Configuration of operating mode..........................................................................................17
9.3. Sealing of the transmitters ...................................................................................................18
9.4. Temperature measurements................................................................................................19
10.EXPLOSIONPROOF PARAMETERS ....................................................... 21
10.1. Transmitters with Exd protection..........................................................................................21
10.2. Transmitter explosion-proof marking....................................................................................21
10.3. Category of transmitter and hazard zones ...........................................................................21
10.4. Power supply and exploitation of transmitter........................................................................21
10.5. Measurement of operating temperature of transmitter..........................................................21

EN.IO.APT.ALW.MID
4 Revision 01.A.001/2023.01
10.6. Determination of the temperature class T* of the transmitter for gas....................................22
10.7. List of cable glands and plug replacements..........................................................................23
10.8. Specific conditions of use.....................................................................................................23
10.9. Transmitters with Exi protection............................................................................................24
10.10.Transmitter explosion-proof marking....................................................................................24
10.11.Ui, Ii, Pi supply parameters and temperature classes...........................................................25
11.MAINTENANCE.........................................................................................26
11.1. Periodic inspections .............................................................................................................26
11.2. Non-periodic inspections......................................................................................................26
11.3. Cleaning/washing.................................................................................................................26
11.4. Spare parts ..........................................................................................................................26
11.5. Repair ..................................................................................................................................26
11.6. Returns ................................................................................................................................26
12.SCRAPPING, DISPOSAL..........................................................................26
13.HISTORY OF REVISIONS.........................................................................26
LIST OF DRAWINGS
Figure 1. Set range and measurement limits.......................................................................................6
Figure 2. Transmitter nameplate .........................................................................................................8
Figure 3. Electrical connection to transmitter.......................................................................................9
Figure 4. Electrical connection 4…20 mA of HART to transmitter in Exd version ..............................10
Figure 5. Electrical connection 4…20 mA of HART to transmitter in Exi version................................10
Figure 6. Rotation of the housing, change of display position and access to buttons.........................13
Figure 7. Display information fields....................................................................................................13
Figure 8. Structure of local setpoints menu of the transmitter............................................................15
Figure 9. Example of the transmitter side covers sealing...................................................................18
Figure 10. Mounting the transmitter in zones.....................................................................................22
Figure 11. Flameproof joints..............................................................................................................24
Figure 12. Mounting the transmitter in zones.....................................................................................24
Figure 13. The principle of feeding from a source with a linear characteristic....................................25
Figure 14. The principle of feeding from a source with a trapezoidal characteristic ...........................25
LIST OF TABLES
Table 1. Definitions and abbreviations.................................................................................................5
Table 2. Permissible transmitter supply voltages...............................................................................11
Table 3. Example of recommended types of cable ............................................................................11
Table 4. Explanation of menu items...................................................................................................16
Table 5. Alarm currents of transmitters..............................................................................................17
Table 6. List of cable glands..............................................................................................................23
Table 7. List of blank plug replacements............................................................................................23

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 5
1. INTRODUCTION
1.1. Purpose of the document
The subject of manual are the installation and exploitation data of the APT-2000ALW MID smart
temperature transmitters with direct resistive sensor Pt100, designed to work in user’s
thermowell. Transmitters APT-2000ALW MID meet the requirements of the EN12405-1:2018
Standard, harmonized to Directive 2014/32/EU (MID) and are used for type 2 of gas conversion device.
In the following, they will be referred to as transmitters. The manual applies to intrinsically safe (Exi)
and the flameproof (Exd) versions.
Within the scope of the MID Directive, transmitters are intended for use in volume gas converters 2
type, equipped with an electric power backup source (battery, UPS) for 1 and 2 family gas fuels in
accordance with EN 437 Standard.
The Exi and Exd transmitter parameters are presented in the p. 10.
➔EXPLOSIONPROOF PARAMETERS
The manual contains data, tips and general recommendations for safe installation and operation of the
transmitters, as well as troubleshooting in case of possible failure.
The use of the equipment in hazardous zones without appropriate approvals is
forbidden.
1.2. Trademarks
HART®is a registered trademark of FieldComm Group.
Windows®is a registered trademark of Microsoft Corporation.
Google Play®is a service registered and managed by Google®Inc.
1.3. Definitions and abbreviations
Table 1. Definitions and abbreviations
Item
no.
Abbr.
Meaning
1
LRV
"Lower Range Value" –the value of the set range expressed in physical units corresponding to the current
of 4,000 mA, i.e. 0% of the output setpoint. Exceeding the LRV limit, with the MID blockade on, makes the
generation of alarm signals bythe transmitter, and on the main display the undEr inscription will be showed.
2
URV
"Upper Range Value" –the value of the set range expressed in physical units corresponding to the current
of 20,000 mA, i.e. 100% of the output setpoint. Exceeding the URV limit, with the MID blockade on, makes
the generation of alarm signals by the transmitter, and on the main display the ouEr inscription will be
showed.
3
LRL
LSL
"Lower Range Limit" or "Lower Sensor Limit" –lower limit of set range expressed in physical units. Value
(URL-LRL) or (USL-LSL) is referred to as the base transmitter range.
4
URL
USL
"Upper Range Limit" or "Upper Sensor Limit" –upper limit of set range expressed in physical units. Value
(URL-LRL) or (USL-LSL) is referred to as the base transmitter range.
5
LPL
"Lower Processing Limit" –lower limit of digital processing of measured value. The transmitter digitally
processes a measurement up to 50% of the base range width below the lower limit of set range LRL (LSL).
6
UPL
"Upper Processing Limit" –upper limit of digital processing of measured value. The transmitter digitally
processes a measurement up to 50% of the base range width above the upper limit of set range URL (USL).
7
LSAL
"Lower Saturation Limit" –lower limit of the A/D transmitter processing range. The lower limit of the A/D
transmitter saturation is on the temperature scale below the LPL point and is associated with the minimum
temperature, at which the analogue-digital temperature measurement transmitter reaches the lower limit of
the processing capacity.
8
USAL
"Upper Saturation Limit" –upper limit of the A/D transmitter processing range. The upper limit saturation
point of A/D transmitter is on the temperature scale above the UPL point and is associated with the maximum
temperature, at which the analogue-digital temperature measurement transmitter reaches the upper limit of
the processing capacity.
9
AL_L
Low current alarm.
10
AL_H
High current alarm.
11
I_AL
The alarm current set by the transmitter controller in the current loop.

EN.IO.APT.ALW.MID
6 Revision 01.A.001/2023.01
1.4. Transmitter set range
The figure below shows the transmitter set range and limits related to allowable set range, digital
processing range and saturation limits of A/D transducer of temperature measurement. As standard,
values of 4 mA/20 mA currents are assigned to LRV/URV points. In order to obtain reverse
characteristics, it is possible to reverse the assignment so that the LRV/URV points are assigned to 20
mA/4 mA currents.
Figure 1. Set range and measurement limits
2. SAFETY
−The installation and start-up of the device and any activities related to operation
shall be carried out after thorough examination of the contents of user’s manual
and the instructions related thereto.
−Installation and maintenance should be carried out by qualified staff having the
required authorizations to install electrical and measuring devices.
−The device shall be used according to its intended purpose in line with the
permissible parameters specified on the nameplate (➔Transmitter identification).
−The protectionelements used by themanufacturerto ensure transmitter safetymay
be less effective if the device is operated in a manner not consistent with its
intended purpose.
−Before installing or disassembling the device, it is absolutely necessary to
disconnect it from the power source.
−No repairs or alterations to the transmitter electronic system are permitted.
Assessment of damages and possible repair may only be performed by the
manufacturer or authorized representative.
−Do not use instruments if damaged. In case of malfunction, the device must be put
out of operation.

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 7
3. TRANSPORT AND STORAGE
3.1. Delivery check
After receiving the delivery of the equipment, it is necessary to:
−make sure that the packaging and its contents were not damaged during transport;
−check the completeness and correctness of the received order, and make sure no parts are
missing.
3.2. Transport
Transport of transmitters shall be carried out with the use of covered means of transport, in original
packages with process connection provided with protection. The packaging shall be protected against
movement and direct impact of atmospheric factors.
3.3. Storage
Transmitters shall be stored in a factory packaging, in a room without vapours and aggressive
substances, protected against mechanical impact.
Allowable range of storage temperature:
-40 ... 80 °C (-40 ... 176 °F).
4. GUARANTEE
General terms and conditions of guarantee are available on the manufacturer's website:
www.aplisens.com/ogolne_warunki_gwarancji.
The guarantee shall be repealed if the device is used against its intended use, or failure to
comply with user’s manual or interference with the structure of the device.

EN.IO.APT.ALW.MID
8 Revision 01.A.001/2023.01
5. IDENTIFICATION
5.1. Manufacturer’s address
APLISENS S.A.
03-192 Warsaw
Morelowa 7 St.
Poland
5.2. Transmitter identification
The transmitter is labelled with rating plates with data as shown below:
APLISENS SA - Produkcja Przemysłowej
Aparatury Pomiarowej i Elementów Automatyki
Rok produkcji :
03-192 WARSZAWA
ul. Morelowa 7
tel. [phone]
fax [phone]
www.aplisens.pl
Year of production
T *
Ser.-No
APLISENS S. A.
03-192 WARSZAWA
ul. Morelowa 7
T. [phone]
F. [phone]
POLAND
www.aplisens.pl
IP66
>
>
U> --- ... --- V DC
>amb, min
INTELIGENTNY PRZETWORNIK TEMPERATURY
Mat.
Numer seryjny:
ttamb, max
supl.
=oC=
=
=
output =
-25 55
4...20mA DC + HART
I
smart temperature transmitter
IP 66
TYP: APT-2000ALW
Realization in accordance with EN 12405-1:2018
Typ osłony czujnika: WGB1
Element pomiarowy: Pt 100
Wykonanie zgodne z PN- EN 12405-1:2019
---- ... ---- V DC
Sygnał wyjściowy: 4...20mA + HART
Zasilanie:
tamb, min tamb, max
=oC=oC
-25 55
TYPE: APT-2000ALW
oC
Sensor type Pt100
Sensor thermowell WGB1
-20 ... 60
Materiał osłony czujnika:
Nr certyfikatu części -- -- -- Part's Certificate No. -- -- --
adj.
oC
Zakres pomiarowy:* -20 ... 60 °C
nastawiony
Dane certyfikatu ATEX ATEX certificate data
Figure 2. Transmitter nameplate
*) transmitters are offered in one of measuring ranges below:
-20 … 40 °C
·
·
·
-20 … 60 °C
5.3. CE mark, declaration of conformity
The device has been designed to meet the highest safety standards, has been tested and has left the
factory in a condition that is safe for operation. The device complies with the applicable standards and
regulations listed in the EU Declaration of Conformity and has CE marking on nameplate.
6. INSTALLATION
6.1. General recommendations
Temperature transmitter APT-2000ALW can be mounted in any position but always in
thermowell. The housing of the transmitter should be protected against hot air streams
by appropriate location of the transmitter or by installing thermal screens so that the
transmitter does not heat up to a temperature higher than the permissible one. The
transmitter housing allows for wall and pipe mounting. For this purpose, use the AL
handle by Aplisens S.A.

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 9
7. ELECTRICAL CONNECTION
7.1. Cable connection to transmitter terminals
All connection and installation operations shall be performed with disconnected supply
voltage and other external voltages, if used.
Failure to provide proper connection of the transmitter may result in danger.
Risk of electric shock and/or ignition in potentially explosive atmospheres.
7.1.1. Cable connection
In order to perform correct connection of the cables, the following steps shall be performed:
−disconnect power supply of the supply cable line before connecting the transmitter cabling;
−unscrew the rear cover of the transmitter body to access the power connector;
−pull the cable through the cable gland;
−connect the transmitter according to the figure below, paying attention to the correct tightening
of the bolts fixing the conductor core to the terminal;
−check the correct fixing of the HART local communication jumper;
−tighten the rear cover of the transmitter body;
−leaving a small clearance of the cable inside the body, tighten the gland nut so that the gland
seal is clamped on the power cable.
Figure 3. Electrical connection to transmitter
1. Housing.
2. Jumper for local HART communication.
3. Internal ground terminal.
4. External ground terminal.
5. Transmitter power terminals, 4…20 mA current loop.
6. Ammeter connection terminals for uninterruptible current measurement in current loop(optional).
In hazardous zone, do not unscrew the housing covers after connecting the Exd
flameproof transmitter to the power source.
7.1.2. Connection of transmitter with the option of using local HART communication
The transmitter allows to use the local HART communication. To do this you can use a HART
communicator or HART modem connected to a computer or a smartphone.

EN.IO.APT.ALW.MID
10 Revision 01.A.001/2023.01
In order to establish the local communication, it is necessary to:
−remove HART communication jumper (item 2);
−connect the communicator or modem to electrical terminals (item 5).
Opening of the HART jumper results in applying resistance of 240 Ω in series in line
4...20 mA. This resistance reduces voltage on transmitter supply terminals by approximately
5 V DC for maximum current that can be set by the transmitter. To avoid the supply
voltage deficit on the transmitter terminals, the HART jumper must be dismantled
only for the time of performing the HART local communication.
Connection diagram of the communicator or modem to transmitter power supply and measurement
system is presented below:
Figure 4. Electrical connection 4…20 mA of HART to transmitter in Exd version
Figure 5. Electrical connection 4…20 mA of HART to transmitter in Exi version

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 11
It is mandatory toread p. 10. ➔EXPLOSIONPROOF PARAMETERS, containing important
information related to the installation of intrinsically safe and flameproof versions of the
transmitter.
The converter HART/USB Aplisens may also be operated using Aplisens Mobile Configurator
installed on smartphones with Android system and connected using wireless communication.
The software is available on Google Play®:
https://play.google.com/store/apps/details?id=com.aplisens.mobile.amc.
7.2. Transmitter power supply
7.2.1. Transmitter supply voltage
Power cables may be live.
There is a risk of electric shock and/or explosion.
Installation of the transmitter in explosion-risk atmospheres must comply with national
standards and regulations.
All explosion protection data is given in p. 10. ➔EXPLOSIONPROOF PARAMETERS.
Table 2. Permissible transmitter supply voltages
Version
Minimum supply voltage
Maximum supply voltage
Exi
13,5 V DC
28 V DC
Exd
13,5 V DC*
45 V DC
* Minimum supply voltage with backlight off. Switching on the backlight increases the minimum supply voltage
by 3V. The backlight is switched off by default.
7.2.2. Uninterruptible current measurement in 4…20 mA current loop
The transmitter is capable of continuous current measurement in the current loop using an ammeter. In
order to maintain the current measurement error below 0,05%, the internal resistance of the ammeter
shall be less than 10 Ω.
Ammeter connection diagram –see: ➔Cable connection
7.2.3. Specifications of electrical switching terminals
Internal electrical switching terminals are suitable for conductors with the cross-section from 0,5 to 2,5
mm2. The internal and external electrical ground terminal of the body are suitable for conductors with
cross-section from od 0,5 to 5 mm2.
7.2.4. Cabling specification
Aplisens S.A. recommends using two-wire screened twisted pair cable. The outer diameter of the cable
shell from 5 to 9 mm is recommended.
Exemplary cable types are presented in the table below.
Table 3. Example of recommended types of cable
Type
Producer
Technokabel
LAPPKABEL
shielded
IB-YSLY 2x0.75
ÖLFLEX® EB 2X1 (art. No. 0012440)
unshielded
IB-YSLCY 2x0.75
ÖLFLEX® EB CY 2X1 (art. No. 0012650)

EN.IO.APT.ALW.MID
12 Revision 01.A.001/2023.01
7.2.5. Resistance load in power supply line
The power line resistance, power source resistance and other additional serial resistances increase
the voltage drops between the power source and the transmitter terminals. The maximum current of
Exd or Exi transmitters under normal operation conditions is defined as I_max = 20,500 mA, in the
high alarm state, the I_max current rises to at least 21,5 mA.
The maximum resistance value in the power circuit (along with the power cables resistance) is
defined by the formula:
 󰇛  󰇜󰇟󰇠
󰇟󰇠
where:
RL_MAX –maximum power supply line resistance [Ω],
U –voltage at the supply terminals of the 4…20 mA current loop [V],
Umin –minimum supply voltage of transmitter [V] (➔Table 2. Permissible transmitter supply voltages).
7.2.6. Shielding, equipotential bonding
When using a cable in the screen, connect the screen on one side. The best option is to connect it in
power supply and measurement installation cabinet.
7.3. Overvoltage protection
Transmitters comply with EMC standards in terms of emission and immunity for products used in
industrial environments.
7.4. Final inspection of cabling
After completing the electrical installation of the transmitter it is necessary to check the following:
−Does the supply voltage measured at the transmitter terminals at maximum set current match
the range of supply voltage specified on the transmitter nameplate?
−Is the transmitter connected according to the information given in section ➔Cable connection
to transmitter terminals?
−Are all the screws tightened?
−Are the transmitter covers tightened?
−Are the cable gland and the gland plug tightened?

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 13
8. OPERATION
The IP 66 degree of the transmitter housing protection for applications with gaseous fuels
from 1 and 2 families in accordance with EN 437 Standard is ensured by the housing
design as well as cable entries and plugs with HNBR or NBR seals. When you intend to
use own cable inlets and plugs, you should use components dedicated to Ex zones,
guaranteeing compliance with the requirements regarding: ambient temperatures,
resistance to gaseous fuels, families 1 and 2 and IP degree.
The transmitter gives the possibility of rotating the housing and adjusting the display position to the
mounting position of the body. To rotate the housing, loosen the screw (item 1), position the transmitter
housing (item 2) as required, tighten the screw (item 1). Access to the extensions (item 4) used to rotate
the display (with 90°step) is provided after opening the front cover (item 3).
Figure 6. Rotation of the housing, change of display position and access to buttons
1. Screw blocking display rotation.
2. Transmitter housing.
3. Front cover.
4. Buttons.
5. Screw blocking display rotation.
In hazardous zone, do not unscrew the housing covers after connecting the Exd
flameproof transmitter to the power source.
8.1. Local LCD display
The LCD has three primary information fields identified in the figure below as LCD1, LCD2, LCD3.
Figure 7. Display information fields

EN.IO.APT.ALW.MID
14 Revision 01.A.001/2023.01
LCD1 field:
[mA] –value (milliamperes) of process current in line 4...20 mA, proportional to the measured
temperature.
[%] –value (percentage) of the setpoint U(t) of current controller in current loop 4...20 mA. This value
is the ratio of the process current Ip(t) to the current range width according to the following formula:
󰇛󰇜󰇛󰇜 

󰇟󰇠
󰇟󰇠󰇟󰇠
LCD2 field:
The LCD2 field is used mainly to display floating point decimal values of process variable in a unit
displayed on LCD3. In some cases, other messages may be displayed:
−ERROR in case of some operating errors or failure diagnosed in the transmitter, error/failure
number Exxxx will appear on LCD2, the ERROR message will be displayed on LCD3. The
image will blink to attract the operator’s attention. The transmitter will set the current output to
alarm status.
−undEr if the limit below LRV of the set range in MID mode is exceeded by the process, the
LCD1 display of transmitter will show the message undEr (under). The image will blink to attract
the operator’s attention. The transmitter will set the current output to alarm status.
−ouEr if the limit above URV of the set range in MID mode is exceeded by the process, the LCD1
display of transmitter will show the message ouEr (over). The image will blink to draw the
operator’s attention.
−● ● ● ● when the set position of comma (point) on LCD2 does not allow for the correct display
of the process variable, four dots ● ● ● ● will appear on LCD. The image will blink to attract
the operator’s attention. In this situation, change the decimal point position in the local setpoint
change MENU or via HART communication.
LCD3 field:
During normal operation it is designed for continuous display of the base unit or the user units. In the
MENU operation mode it displays the setting options. It is also used to display errors related to the
execution of commands in the local setup MENU.
8.2. Local buttons
Local buttons are used to enable the configuration mode of some transmitter parameters and to
navigate through MENU and accept MENU options. The MENU can be accessed by pressing and
holding any of the buttons for at least 4 seconds. After this time, the LCD3 field of the local display will
show an EXIT message. This signals entering into the MENU navigation mode.
8.3. Local configuration of setpoints
Transmitter enables local configuration of some of the most common setpoints via local buttons and
local LCD display.
8.4. Navigation in local setpoints MENU
The MENU can be accessed by pressing and holding any of the buttons for at least 4 seconds. After
this time, the LCD3 field of the local display will show an EXIT message. This signals entering into the
local configuration MENU. By pressing the buttons with arrows [↑] [↓] for at least 1 second you can
move up or down in MENU.
8.5. Acceptance of local setpoints
The button marked with symbol [●] is used to accept the selection. The acceptance of setpoint change
is confirmed by a DONE message displayed on LCD3. After changing the setpoint, the transmitter
leaves the local configuration change MENU. If no selection is made in the MENU mode, after
2 minutes the transmitter automatically returns to display of standard messages. The MENU can also
be left by selecting and accepting the EXIT option.

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 15
8.6. Structure of local setpoints MENU
When navigating in the area of the active local MENU, holding the button required to trigger the action
is minimum 1 second. Continuous pressing of the ↑ or ↓ button results in scrolling of the MENU positions
every 1 second. If the local MENU remains inactive for more than 2 minutes, after this time the
transmitter will automatically leave the MENU mode and will display the process variable.
Figure 8. Structure of local setpoints menu of the transmitter

EN.IO.APT.ALW.MID
16 Revision 01.A.001/2023.01
Table 4. Explanation of menu items
Local Menu
Submenu
Description
EXIT
Return from the Local Menu to display the process variable
SET LRV /
SET URV
Setting the start of the range set to LRV /
Setting the finish of the range set to URV
XXX.XX
The current LRV/URV value is displayed
+/-_____
Select and confirm the sign of the parameter to be entered; enter digit by digit, 5-digit
number with or without a dot; after confirming the last 5th digit of the parameter, the
transmitter will confirm acceptance of the command with "DONE" or will report an
error number; the parameter is entered in "UNIT" units".
UNIT
Setting of temperature units.
DAMPIN
Setting of the constant time damping of the process variable.
TRANSF
Setting the linearization type of current processing characteristics.
LINEAR
Linear characteristics.
SQRT
Square root function.
SQRX^3
Square root function of x3.
SQRX^5
Square root function of x5.
SPECIA
Linearization of the user board output.
SQUARE
Square function.
ALARM
Setting the transmitter alarm current value.
LOW
Low alarm current.
HIGH
High alarm current.
LAST
Last value.
CUSTOM
Alarm current value set by user.
LCD1VR
Type of process variable displayed on LCD1.
CURREN
The LCD1 displays the current value in the current loop.
PERCEN
The LCD1 displays the percentage of output control.
LCD2VR
Type of variable displayed on LCD2.
TEMPER
The LCD2 displays process variable.
USER
The LCD2 will display the scaled value in user units.
UNIT
The LCD2 displays actual unit and process variable alternately.
NOUNIT
The LCD2 does not display actual unit and process variable alternately.
LCD2DP
Position of the decimal dot of the variable displayed on LCD2.
FACTORY
Removes user’s calibration coefficients of temperature and current, returns to factory
settings.
RESET
Forced transmitter reset by software.
MID WP
Setting write lock parameters.
8.7. Remote configuration of setpoints (HART 5)
The transmitter allows to read out and configure the parameters via HART communication using 4...20
mA loop as a physical layer for FSK BELL 202 modulation.
8.7.1. Compatible devices
The following devices may be used to communicate with the transmitter:
−Aplisens S.A. KAP-03, KAP-03Ex communicator (HART 5 only);
−communicators from other companies, including those using DDL and DTM libraries;
−PC computers equipped with HART modem (e.g. HART/USB converter by Aplisens S.A.) with
Windows 7 or Windows 10 operating system with installed Raport 2;
−PC computers equipped with HART modem using software from other companies, accepting
DDL and DTM libraries;
−smartphones with Android system, using a converter providing wireless communication (e.g.
HART/USB converter by Aplisens S.A.) using Aplisens Mobile Configurator. The software is
available on Google Play under the link:
https://play.google.com/store/apps/details?id=com.aplisens.mobile.amc.

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 17
8.7.2. Compatible configuration software
−Raport 2 Aplisens under control of Windows 7 or Windows 10;
−Aplisens Mobile Configurator under control of the Android system;
−softwares from other companies accepting DDL and DTM libraries.
8.7.3. Local HART communication jumper
The transmitter allows to use the local HART communication. To do this you can use a HART
communicator unit or modem interoperating with a computer or a smartphone.
In order to establish communication, it is necessary to:
−remove the HART communication jumper (➔Figure 3. Electrical connection to transmitter);
−connect the communicator or modem to terminals (➔Connection of transmitter with the option
of using local HART communication).
9. START-UP
As standard, the transmitter is adjusted to a set range equal to the base range, unless a specific set
range is provided in the order. The base range and the basic unit of the transmitter can be read out
from its nameplate (➔Transmitter identification).
Use the transmitter within the allowable temperature limits. Risk of injury due to
component breakage after exceeding the maximum permitted operating temperature.
9.1. Alarm configuration
Transmitters has a developed internal diagnostics, which monitors the work of their electronic circuits,
process and environmental parameters.
The user has an option of enabling/disabling the current alarms. Current alarms are disabled by default.
The table below shows value of alarm currents.
Table 5. Alarm currents of transmitters
Type of alarm
Value of alarm current [mA]
NORMAL LOW
3,75
NORMAL HIGH
21,6
NAMUR LOW
3,6
NAMUR HIGH
21,0
9.2. Configuration of operating mode
Before starting the work with the transmitter, the following parameters must be configured:
−basic unit of transmitter;
−the beginning of the set range LRV;
−the end of the set range URV;
−damping time constant;
−NORMAL/NAMUR analogue output operation mode;
−alarm mode, high or low alarm;
−transmitter tag (TAG/LONG_TAG);
−LCD display configuration parameters;
−setting of the settings change lock password.

EN.IO.APT.ALW.MID
18 Revision 01.A.001/2023.01
Once the transmitter parameters have been entered and it has been reset at the workstation, it
is required to:
−Secure the device against the possibility of making changes in the local setpoint change
MENU.
−Set your own password different from default password of “00000000”. The new
password may consist of any combination of 8 hexadecimal characters 0...9, A…F. Store
the password in a safe place. If the password is lost, its restoration or resetting to factory
settings may only be performed by the manufacturer.
−Activate the setpoint change lock to secure the transmitter against
accidental/unauthorized change of parameters.
Operations described above can be done via HART communication.
For Exd type transmitters, opening the housing cover in the hazardous zone in order to
use the local setpoint change MENU is forbidden.
9.3. Sealing of the transmitters
The transmitters are sealed according to the regulations in the place / country of using.
The manufacturer seals the side covers and the sensor as well as the nameplate, if it is made of metal.
The sealing method of the transmitter by the manufacturer is shown at Fig. 9.
Figure 9. Example of the transmitter side covers sealing
Protection against changes in the settings in the transmitter can be done as follows:
–systemically, activated by a configuration program (Raport 2) andprotected by password,
with „spec lock” disabled;
–done with local buttons on the transmitter with a local menu (command MID_WP) with
„spec lock” disabled.
As a standard, the manufacturer turns on the ‘’spec lock’’ or, in agreement with the ordering
party, the transmitter may be unblocked.
Local buttons, enabling the activation of the “spec lock”, are secured with side cover which
could be sealed. With the “spec lock”on, it is possible to change only some of the
transmitter parameters, i.e. the HART address of the transmitter and the time constant,
and transmitter identification entries related to its place of work can be made, e.g. TAG.

EN.IO.APT.ALW.MID
Revision 01.A.001/2023.01 19
9.4. Temperature measurements
The transmitter version in accordance with the EN 12405-1: 2018 standard is designed to measure
temperatures of gases, vapors and liquids. The metrological parameters of the transmitter are
presented below.
Measurement ranges -20 … 60 °C *
·
·
-20 … 40 °C
*) The transmitter measurement range is setting by the manufacturer. For range -20…60 °C it is possible to lower the upper
limit of the range to 40°C. A lower measurement range can be set by manufacturer at the user’s request, or can be changed
by the user after removing the lock.
Maximum permissible error (according to EN 12405-1:2018)
(calculated in relation to the measured value)
−at the rated temperature range: (-25 ÷ 55 °C) ≤ 0,2 %
−at reference conditions ≤ 0,1 %
−long-term stability / 5 years ≤ 0,2 %
Cover type of temperature sensor WGB1
Enclosure Ingress Protection IP 66
For the clearing needs, in accordance with Directive 2014/32/EU, should be used one of
the two metrological checked transmitter output signals: digital HART signal rev 5.1 or
analogue current signal.
Other parameters
Medium temperature range -20 ÷60 °C
Ambient temperature range -25 ÷ 55 °C
Relative humidity 10 ÷ 98 % with condensation
Error due to supply voltage changes 0,002 %(FSO) / 1V
Thermal error < 0,05 %(FSO) / 10°C
Output updating time (period of calculation cycle) 150 ms
Dumping 0...60 s
Sensor length min. 150 mm
Length of the connection cable max. 1500 m

EN.IO.APT.ALW.MID
20 Revision 01.A.001/2023.01
Transmitters environmental parameters
Products for this application meet the following requirements.
Criteria by EN 12405-1:2018
Electromagnetic Compatibility,
immunity
Electrostatic Discharge (ESD):
EN 61000-4-2
Contact ±8 kV
Air ±15 kV
Conducted Radio Frequency:
EN 61000-4-6
0,15 … 80 MHz –10 V
Radiated Electromagnetic Field:
EN 61000-4-3
80 … 1 000 MHz –10 V/m
1 … 2,700 GHz –10 V/m
Magnetic Field:
EN 61000-4-8
100 A/m –direct
1000 A/m –for 3 s
Level 5
Electrical Fast Transient (Burst):
EN 61000-4-4
±2 kV, I/O
Electrical Slow Transient (Surges)
EN 61000-4-5
±2 kV
Short drops in electrical supply
EN 61000-4-29
Level 1
Climatic Immunity
The transmitters can be installed in
different climatic conditions (see p.7)
in environments of varying humidity,
also in areas of water vapour
condensation.
Environment temperature:
EN 60068-2-1, EN 60068-2-2,
EN 60068-3-1
hot: T = 55 °C, RH= max 55 %
cold: T = -25 °C
Humid Permanent Heat:
EN 60068-2-78
T = 55 °C, RH= 93 %, 96 h
Damp Heat Cycle:
EN 60068-2-30
(T = 22 ÷ 55 °C, RH= 80 ÷ 100 %,
24h)x2
Mechanical Immunity
Shocks:
EN 60068-2-31, Level 2
Vibrations in a wide band:
EN 60068-2-64, test Fh, Level 2
