Aplisens APRE-2000GN User manual

USER’S MANUAL
SMART DIFFERENTIAL PRESSURE TRANSMITTER
for low ranges
APRE-2000GN
EN.IO.APREGN
SEPTEMBER 2020
APLISENS S.A., 03-192 Warsaw, Morelowa 7 St.
tel. [phone]; fax [phone]
www.aplisens.com, e-mail: [e-mail]
Revision 02.A.002

Symbols used
Symbol
Description
Warning to proceed strictly in accordance with the information contained in the
documentation in order to ensure the safety and full functionality of the device.
Information particularly useful during installation and operation of the device.
Information on disposal of used equipment.
BASIC REQUIREMENTS AND SAFE USE
The manufacturer will not be liable for damage resulting from incorrect installation,
failure to maintain suitable technical condition of the device, or use of the device
other than for its intended purpose.
Installation should be carried out by qualified staff having the required authoriza-
tions to install electrical and I&C equipment. The installer is responsible for perform-
ing the installation in accordance with manual as well as with the electromagnetic
compatibility and safety regulations and standards applicable to the type of installa-
tion.
In systems with I&C equipment, in case of leakage, there is a danger to staff due to
the medium under pressure. All safety and protection requirements must be ob-
served during installation, operation and inspections.
If a malfunction occurs, the device should be disconnected and handed over to the
manufacturer for repair.
In order to minimize the risk of malfunction and associated risks to staff, the device
is not to be installed or used in particularly unfavourable conditions, where the fol-
lowing hazards occur:
possible mechanical impacts, excessive shocks and vibration;
excessive temperature fluctuation;
water vapour condensation, dusting, icing.
Changes made to the manufacturing of products may be introduced before the paper version of the
manual is updated. The up-to-date manuals are available on the manufacturer's website:
www.aplisens.com.

EN.IO.APREGN
Revision.02.A.002 3
TABLE OF CONTENTS
1. INTRODUCTION ......................................................................................... 5
1.1. Purpose of the document....................................................................................................... 5
1.2. Trademarks ........................................................................................................................... 5
1.3. Definitions and abbreviations ................................................................................................. 5
1.4. Transmitter set range............................................................................................................. 6
2. SAFETY ...................................................................................................... 7
3. TRANSPORT AND STORAGE ................................................................... 8
3.1. Delivery check ....................................................................................................................... 8
3.2. Transport ............................................................................................................................... 8
3.3. Storage.................................................................................................................................. 8
4. GUARANTEE .............................................................................................. 8
5. IDENTIFICATION ........................................................................................ 9
5.1. Manufacturer's address ......................................................................................................... 9
5.2. Transmitter identification........................................................................................................ 9
5.3. CE mark, declaration of conformity ........................................................................................ 9
6. CONSTRUCTION...................................................................................... 10
6.1. Transmitter housing and dimensions ................................................................................... 10
7. INSTALLATION ........................................................................................ 11
7.1. General recommendations................................................................................................... 11
7.2. Installation and pressure connection.................................................................................... 11
8. ELECTRICAL CONNECTION ................................................................... 12
8.1. Electrical connection of transmitter ...................................................................................... 12
8.2. Transmitter power supply..................................................................................................... 13
8.2.1. Transmitter supply voltage ........................................................................................... 13
8.2.2. Resistance load in power supply line............................................................................ 13
8.2.3. Shielding, equipotential bonding................................................................................... 13
9. OPERATION ............................................................................................. 14
9.1. Local LCD display................................................................................................................ 14
9.2. Local buttons ....................................................................................................................... 17
9.3. Local configuration of setpoint ............................................................................................. 17
9.5. Acceptance of local setpoints............................................................................................... 17
9.6. Structure of local setpoints MENU ....................................................................................... 17
9.7. Remote configuration of setpoints (HART 5/HART 7) .......................................................... 19
9.7.1. Compatible devices ...................................................................................................... 19
9.7.2. Compatible configuration software ............................................................................... 19
10. START-UP ................................................................................................ 20
10.1. Alarm configuration.............................................................................................................. 20
10.2. Configuration of operating mode.......................................................................................... 21
10.3. Correction of impact of transmitter mounting position on site –pressure reset..................... 22
11. MAINTENANCE ........................................................................................ 23
11.1. Periodic inspections............................................................................................................. 23
11.2. Non-periodic inspections...................................................................................................... 23
11.3. Cleaning / washing .............................................................................................................. 23
11.4. Spare parts .......................................................................................................................... 23
11.5. Repair.................................................................................................................................. 23

PL.IO.APREGN
4 Revision.02.A.002
11.6. Returns ................................................................................................................................23
12. SCRAPPING, DISPOSAL.......................................................................... 23
13. HISTORY OF REVISIONS......................................................................... 23
LIST OF DRAWINGS
Figure 1. Set range and measurement limits. ......................................................................................6
Figure 2. APRE-2000GN transmitter nameplate..................................................................................9
Figure 3. APRE-2000GN differential pressure transmitter –dimensions. ..........................................10
Figure 4. APRE-2000GN differential pressure transmitter –mounting method..................................11
Figure 5. Connection of the APRE-2000GN transmitter and communicator or modem. ....................12
Figure 6. Display information fields....................................................................................................14
Figure 7. Set range current, saturation currents, alarm currents........................................................20
LIST OF TABLES
Table 1. Definitions and abbreviations. ................................................................................................5
Table 2. Permissible transmitter supply voltages. ..............................................................................13

EN.IO.APREGN
Revision.02.A.002 5
1. INTRODUCTION
1.1. Purpose of the document
The subject of manual is smart differential pressure transmitters APRE-2000GN in standard version.
The manual contains data, tips and general recommendations for safe installation and operation of
the transmitters, as well as troubleshooting in case of possible failure.
1.2. Trademarks
HART®is a registered trademark of FieldComm Group.
Windows®–is a registered trademark of Microsoft Corporation.
Google Play®–is a service registered and managed by Google®Inc
1.3. Definitions and abbreviations
Table 1. Definitions and abbreviations.
Item
no.
Abbr.
Meaning
1
LRV
“Lower Range Value” – the value of the set range expressed in physical units corresponding to
the current of 4.000 mA, i.e. 0% of the output setpoint. The set range cannot exceed the set
range limits. The minimum width of the set range |(URV-LRV)| is limited to 10 % of the base
range (URL-LRL).
2
URV
“Upper Range Value” — the value of the set range expressed in physical units corresponding to
the current of 20.000mA, i.e. 100% of the output setpoint. The set range cannot exceed the set
range limits. The minimum width of the set range(URV-LRV)| is limited to 10 % of the base range
(URL-LRL).
3
LRL
LSL
“Lower Range Limit” or “Lower Sensor Limit” – lower limit of set range expressed in physical units.
Value (URL-LRL) or (USL-LSL) is referred to as the base transmitter range.
4
URL
USL
“Upper Range Limit” or “Upper Sensor Limit” – upper limit of set range expressed in physical units.
Value (URL-LRL) or (USL-LSL) is referred to as the base transmitter range.
5
LPL
“Lower Processing Limit” – lower limit of digital processing of measured value. The transmitter
processes a digital measurement up to 50 % of the base range width below the lower limit of set
range LRL (LSL). After reaching the LPL and when below this value up to LSAL, the transmitter
freezes the refreshing of digital value of the measurement. In this situation, message “UndEr” will
be displayed on the display and diagnostic alarm mode will be activated depending on the set-
tings I_AL < 3.650 mA or I_AL > 21.500 mA. Additionally, collective status PV_OUT_OF LIMITS
and status PV_LOW_LIMITED in the Transducer Block will be set, which can be read out in the
diagnostic tab via HART communication.
6
UPL
“Upper Processing Limit” – upper limit of digital processing of measured value. The transmitter
processes a digital measurement up to 50% of the base range width above the upper limit of set
range URL (USL). After reaching the UPL and when above this value up to USAL, the transmit-
ter freezes the refreshing of digital value of the measurement. In this situation, message "OvEr"
will be displayed on the display and diagnostic alarm mode will be activated depending on the
settings I_AL< 3.650 mA or I_AL > 21.500 mA. Additionally, collective status PV_OUT_OF LIM-
ITS and status PV_HIGH_LIMITED in the Transducer Block will be set, which can be read out in
the diagnostic tab via HART communication.
7
LSAL
“Lower Saturation Limit” – lower limit of the A/D transmitter processing range. The lower limit of
the A/D transmitter saturation is on the pressure/differential pressure scale below the LPL point
and is associated with the minimum pressure, at which the analogue-digital pressure measure-
ment transmitter reaches the lower limit of the processing capacity. The exact determination of
this pressure is not possible, however usually the pressure does not exceed the pressure corre-
sponding to 200 % of the base range width (URL-LRL) below the lower limit of the digital pro-
cessing of measured LPL value. After reaching LSAL and when below this value, error number
E0256 will be displayed and the diagnostic alarm mode will be activated depending on the set-
tings I_AL < 3.650 mA or I_AL > 21.500 mA. Additionally, collective status SENSOR_FAULT,
PV_OUT_OF LIMITS, status NOREF+ERR@AIN1_AD7794 in the Sensor Block and
PV_LOW_LIMITED in the Transducer Block will be set, which can be read out in the diagnostic
tab via HART communication.

PL.IO.APREGN
6 Revision.02.A.002
8
USAL
“Upper Saturation Limit” – upper limit of the A/D transmitter processing range. The upper limit
saturation point of A/D transmitter is on the pressure/differential pressure scale above the UPL
point and is associated with the maximum pressure at which the analogue-digital pressure
measurement transmitter reaches the upper limit of the processing capacity. The exact determi-
nation of this pressure is not possible, however usually the pressure does not exceed the pres-
sure corresponding to 200% of the base range width (URL-LRL) above the upper limit of the
digital processing of measured UPL value. After reaching USAL and when above this value,
error number E0256 will be displayed and the diagnostic alarm mode will be activated depending
on the settings I_AL < 3.650 mA or I_AL > 21.500 mA. Additionally, collective status SEN-
SOR_FAULT, PV_OUT_OF LIMITS, status NOREF+ERR@AIN1_AD7794 in the Sensor Block
and PV_HIGH_LIMITED in the Transducer Block will be set, which can be read out in the diag-
nostic tab via HART communication.
9
AL_L
Low current alarm (I < 3.650 mA).
10
AL_H
High current alarm (I > 21.500 mA).
11
I_AL
The alarm current set by the transmitter controller in the current loop.
1.4. Transmitter set range
The figure below shows the transmitter set range and limits related to allowable set range, digital pro-
cessing range and saturation limits of A/D pressure measurement transducer. As standard, values of
4 mA/20 mA currents are assigned to LRV/URV points. In order to obtain reverse characteristics, it is
possible to reverse the assignment so that the LRV/URV points are assigned to 20 mA/4 mA currents.
Figure 1. Set range and measurement limits.

EN.IO.APREGN
Revision.02.A.002 7
2. SAFETY
The installation and start-up of the device and any activities related to operation shall be
carried out after thorough examination of the contents of user’s manual and the instruc-
tions related thereto;
installation and maintenance should be carried out by qualified staff having the required
authorizations to install electrical and measuring devices;
the device shall be used according to its intended purpose in line with the permissible
parameters specified on the nameplate (Transmitter identification);
the protecting elements used by the manufacturer to ensure transmitter safety may be
less effective if the device is operated in a manner not consistent with its intended pur-
pose;
before installing or disassembling the device, it is absolutely necessary to disconnect it
from the power source;
no repairs or alterations to the transmitter electronic system are permitted. Assessment
of damages and possible repair may only be performed by the manufacturer or author-
ized representative;
do not use instruments if damaged. In case of malfunction, the device must be put out of
operation.

EN.IO.APREGN
8 Revision.02.A.002
3. TRANSPORT AND STORAGE
3.1. Delivery check
After receiving the delivery of the equipment, it is necessary to:
make sure that the packaging and its contents were not damaged during transport;
check the completeness and correctness of the received order, and make sure no parts are
missing.
3.2. Transport
Transport of transmitters shall be carried out with the use of covered means of transport, in original
packages. The packaging shall be protected against movement and direct impact of atmospheric fac-
tors.
3.3. Storage
Transmitters shall be stored in a factory packaging, in a room, without vapours and aggressive sub-
stances, protected against mechanical impact.
Allowable range of storage temperature:
-25 … 70 °C (-13 ... 158 °F).
4. GUARANTEE
General terms and conditions of guarantee are available on the manufacturer's website:
www.aplisens.com/ogolne_warunki_gwarancji
The guarantee shall be repealed if the device is used against its intended use, failure to
comply with user’s manual or interference with the structure of the device.

EN.IO.APREGN
Revision.02.A.002 9
5. IDENTIFICATION
5.1. Manufacturer's address
APLISENS S.A.
03-192 Warsaw
Morelowa 7 St.
Poland
5.2. Transmitter identification
Each transmitter APRE-2000GN is equipped with a nameplate showing the following data.
Figure 2. APRE-2000GN transmitter nameplate.
1. Logo and name of manufacturer.
2. CE mark.
3. Product code.
4. Transmitter type.
5. Transmitter serial number.
6. Base measuring range.
7. Supply voltage values.
8. Output signal.
9. Maximum static pressure.
10. Type of process connector.
5.3. CE mark, declaration of conformity
The device has been designed to meet the highest safety standards, has been tested and has left the
factory in a condition that is safe for operation. The device complies with the applicable standards and
regulations listed in the EU Declaration of Conformity and has CE marking on nameplate.

EN.IO.APREGN
10 Revision.02.A.002
6. CONSTRUCTION
The basic transmitter assemblies are: housing, processing unit (with pressure sensor and electronic
unit), in which the pressure signal is converted into an electric signal and transformed into a unified
output signal.
6.1. Transmitter housing and dimensions
The APRE-2000GN transmitter housing is made of polycarbonate –PC or ABS and consists of a
housing body and a transparent cover to ensure the readability of the LCD display.
The housing body is equipped with pressure connections for plastic tubes Ø6x1 and electrical con-
nection.
On the inner side surface of the housing body there is an anti-interference filter unit electrically con-
nected to the processing unit and to the base of the electrical connection of the transmitter.
Figure 3. APRE-2000GN differential pressure transmitter –dimensions.

EN.IO.APREGN
Revision.02.A.002 11
7. INSTALLATION
7.1. General recommendations
It is recommended that in case of a gaseous medium, the transmitters should be installed
above the measuring point so that condensate may flow to the point from which the
measured pressure is collected. The configuration of impulse tubes and valve connection
system should be selected taking into account the measurement conditions.
Differential pressure transmitters for gases APRE-2000GN should be obligatorily installed
vertically.
7.2. Installation and pressure connection
The APRE-2000GN transmitters can be mounted on a wall or on a control panel.
The installation method is shown in Fig. 4.
The transmitter is fitted with connectors which fit to a Ø6x1 elastic impulse tube.
In case of significant level differences between the transmitter location and the pulse point, a ‘’floating’’
effect of the measurement may occur when the temperature difference of the impulse tubes changes.
This effect can be reduced by leading the impulse tubes side by side.
When assembling transmitter mounting accessories, information about connecting pressure elements
such as: reductive, nests, valves, reducer clamps, signal tubes –offered by APLISENS –may be help-
ful. Data on this subject are contained in catalogue.
Figure 4. APRE-2000GN differential pressure transmitter –mounting method.

EN.IO.APREGN
12 Revision.02.A.002
8. ELECTRICAL CONNECTION
8.1. Electrical connection of transmitter
All connection and installation operations shall be performed with disconnected supply
voltage and disconnected input signal.
Failure to provide proper connection of the transmitter may result in danger.
Connect the differential pressure transmitter APRE-2000GN according to fig. 5.
Figure 5. Connection of the APRE-2000GN transmitter and communicator or modem.
Communicator or modem electrical connections.
In order to enable communication by connecting a communicator, modem or converter to the trans-
mitter’s terminals, make sure that the resistance Ro seen from the transmitter’s terminals towards the
power supply source lies within the range of 240≤Ro≤1100 . If necessary, an additional resistor can
be installed in the line. The communicator or modem connection must be in accordance with Fig.5.

EN.IO.APREGN
Revision.02.A.002 13
8.2. Transmitter power supply
8.2.1. Transmitter supply voltage
Power cables may be live.
There is a risk of electric shock.
Table 2. Permissible transmitter supply voltages.
Version
Minimum supply voltage
Maximum supply voltage
Standard
10 V DC
55 V DC
8.2.2. Resistance load in power supply line
The power line resistance, power source resistance and other additional serial resistances increase
the voltage drops between the power source and the transmitter terminals. The maximum transmitter
current under normal operation conditions is 20.500 mA but during high alarm the value of current
I_max is 22.000 mA.
The maximum resistance value in the power circuit (along with the power cables resistance) is de-
fined by the formula:
RL_MAX [Ω] ≤=
where:
U –voltage of 4…20 mA current loop power supply unit in [V];
RL_MAX –maximum power supply line resistance in [Ω].
8.2.3. Shielding, equipotential bonding
When using a cable in the screen, connect the screen on one side at the transmitter’s power supply
point.
(U−10)[V]
0,022 [A]

EN.IO.APREGN
14 Revision.02.A.002
9. OPERATION
9.1. Local LCD display
The LCD has three primary information fields identified in the figure below as LCD1, LCD2, LCD3.
Figure 6. Display information fields.
LCD1 field:
[mA] - value (milliamperes) of process current in line 4...20 mA, proportional to the measured pres-
sure.
[%] - value (percentage) of the setpoint of current controller in current loop 4...20 mA. This value
is the ratio of the process current to the current range width according to the following formula:
% =
LCD2 field:
The LCD2 field is used mainly to display floating point decimal values in a unit displayed on LCD3. In
some cases, other messages may be displayed:
ERROR in case of some operating errors or failure diagnosed in the transmitter, error/failure
number Exxxx will appear on LCD2, the ERROR message will be displayed on LCD3. The
image will blink to attract the operator’s attention. The transmitter will set the current output to
alarm status depending on the configuration I_AL < 3.650 mA or I_AL > 21.500 mA.
In order to identify the cause, please refer to the chapter “Troubleshooting” placed in Tech-
nical Information;
undEr the message will appear when 50% of the base range below the lower limit range of the
set LRL (LSL) is exceeded. After reaching the LPL and when below this value up to LSAL, the
transmitter freezes the refreshing of digital value of the measurement. In this situation, mes-
sage “UndEr” will be displayed. The image will blink to attract the operator’s attention. The di-
agnostic alarm mode will be enabled depending on the settings I_AL < 3.650 mA or
I_AL > 21.500 mA. Additionally, common status PV_OUT_OF LIMITS and status
PV_LOW_LIMITED in the Sensor Block will be set, which can be read out in the diagnostic tab
via HART communication;
ouEr the message will appear when 50 % of the base range below the lower limit range of the
set URL (USL) is exceeded. After reaching the UPL and when above this value up to USAL,
the transmitter freezes the refreshing of digital value of the measurement. In this situation, the

EN.IO.APREGN
Revision.02.A.002 15
message “ovEr” will be displayed. The image will blink to attract the operator’s attention. The
diagnostic alarm mode will be enabled depending on the settings I_AL < 3.650 mA or
I_AL > 21.500 mA. Additionally, common status PV_OUT_OF LIMITS and status
PV_HIGH_LIMITED in the Sensor Block will be set, which can be read out via HART commu-
nication;
● ● ● ● when the set position of comma (point) on LCD2 does not allow for the correct dis-
play of the process variable, four dots ● ● ● ● will appear on LCD. The image will blink to at-
tract the operator’s attention. In this situation, change the decimal point position in the local
setpoint change MENU or via HART communications.
LCD3 field:
Abbreviations of physical units of pressures and levels and their description:
INH2O
inches of water column with temperature of 0°C.
INHG
inches of mercury column with temperature of 0°C.
FTH2O
feet of water column with temperature of 20°C (68°F).
MMH2O
millimeters of water column with temperature of 20°C (68°F).
MMHG
millimeters of mercury column with temperature of 0°C.
PSI
pounds per square inch.
BAR
bars.
MBAR
millibars.
GSQCM
grams per square centimeter.
KGSQCM
kilograms per square centimeter.
PA
pascals.
KPA
kilopascals.
TORR
torrs.
ATM
atmosphere.
MH2O4
metres of water column with temperature of 4°C.
MPA
megapascals.
INH2O4
inches of water column with temperature of 4°C.
MMH2O4
millimeters of water column with temperature of 4°C.
NOUNIT
the shortcut displayed when a unit not implemented in the transmitter is configured via HART com-
munication.
Abbreviations of temperature measurement point name:
SENS °C
temperature of pressure/differential pressure sensor measurement structure
in degrees Celsius.
CPU °C
temperature of the main CPU structure in degrees Celsius.
Abbreviations displayed during configuration via local MENU and their descriptions:
<-BACK
return to one level above in local MENU.
EXIT
going out of the local MENU.
UNIT
pressure and level unit selection menu.
SENS_T
option of measuring the temperature of pressure/differential pressure sensor measurement structure.
CPU_T
option of measuring the main CPU structure temperature.
DAMPIN
menu of selecting damping time constant of process variable.
TRANSF
menu of selecting the current output linearization function.
%SQRT
menu of selecting the deadband percentage of the root characteristics of the current output lineariza-
tion.
PVZERO
pressure transmitter resetting menu and option.
SETURV
URV setting menu (upper pressure of the set range).
SETLRV
LRV setting menu (lower pressure of the set range).
BYPRES
option of setting the range according to pressure.
BYVALU
option of setting the set range by entering a value.
RESET
transmitter hot restart software menu.
LCD1VR
menu for selection of the type of measurement displayed on LCD1.

EN.IO.APREGN
16 Revision.02.A.002
LCD2VR
menu for selection of the type of measurement displayed on LCD2.
LCD2DP
menu for selecting position of comma / decimal point.
FACTOR
return to factory values menu.
RECALL
option of return to factory settings. Factory pressure/differential pressure calibrations, zero setpoints of
pressure and current will be restored.
LINEAR
option of linear function of current output setpoint linearization.
SQRT
option of root function of current output setpoint linearization.
SPECIA
option of the user’s special characteristics of current output setpoint linearization.
SQUARE
option of square function of current output setpoint linearization.
CURREN
option of selecting the display of set current on LCD1.
PERCEN
option of selecting the display of set percentage on LCD1.
PRESS
option of selecting the display of pressure/differential pressure on LCD1.
USER
option of selecting user’s units and scaling to be displayed on LCD1.
MID_WP
MID mode setting menu. In this mode, the option of changing the setpoints related to the transmitter
metrology is disabled. Exceeding of LRV and URV limits results in displaying the undEr or ouEr mes-
sage, blinking of the display and setting of the process output to the current alarm mode depending on
the configuration I_AL<3.650 mA or I_AL>21.500 mA.
ON
MID mode activation option.
OFF
MID mode deactivation option.
X.XXXX
option of selecting position of comma / decimal point.
XX.XXX
option of selecting position of comma / decimal point.
XXX.XX
option of selecting position of comma / decimal point.
XXXX.X
option of selecting position of comma / decimal point.
XXXXX.
option of selecting position of comma / decimal point.
0 [S]
option of selecting damping time constant.
2 [S]
option of selecting damping time constant.
5 [S]
option of selecting damping time constant.
10 [S]
option of selecting damping time constant.
30 [S]
option of selecting damping time constant.
60 [S]
option of selecting damping time constant. The 60-second damping constant is only available from the
local keypad; the configuration via HART in Revision 5 does not allow a damping value greater than 30
seconds. Other damping values are possible to be set via HART communication.
0.0%
option of selecting root characteristics deadband point.
0.2%
option of selecting root characteristics deadband point.
0.4%
option of selecting root characteristics deadband point.
0.6%
option of selecting root characteristics deadband point.
0.8%
option of selecting root characteristics deadband point.
1.0 %
option of selecting root characteristics deadband point.
other deadband values are possible to be set via HART communication.
DONE
message about the acceptance and implementation of the set-point change.
Abbreviations of local configuration errors and description of abbreviations:
ER_L07
message displayed on LCD3. It is displayed if a user tries to change the setpoint in the transmitter pro-
tected against entry (change of setpoints).
ER_L09
message displayed on LCD3. It is displayed if:
a user tries to change the set range by set pressure which is not within the allowable upper
URL pressure.
A user tries to reset pressure when the pressure exceeds the allowable upper limit.
ER_L10
message displayed on LCD3. It is displayed if:
a user tries to change the set range by set pressure which is not within the allowable lower LRL
pressure.
A user tries to reset pressure when the pressure exceeds the allowable lower limit.
ER_L14
message displayed on LCD3. It is displayed if:
the adopted URV value through the set pressure or entry of a value cannot be accepted be-
cause it causes a reduction of the set pressure range set below the allowable limit.
ER_L16
message displayed on LCD3. It is displayed if:
a user tried to perform an operation that is disabled or unavailable. It may be caused by:
attempting to access the local setpoint change MENU when
the access to the local MENU is disabled;
attempting to reset pressure in the absolute pressure measurement transducer.

EN.IO.APREGN
Revision.02.A.002 17
WG_L14
the message will appear if the assumed LRV value through the set pressure or entry of a value causes
a decrease of the current set range. Entry of LRV automatically results in the transmitter’s attempt to set
URV in such a way that the current width of the set range is maintained. If this is not possible due to
exceeded URL, the transmitter automatically adopts the URV = URL and a new LRV. Since the set
range width and URV deviate from previous values, a message is displayed.
ASCII characters displayed on LCD3 in user’s unit:
using HART communication, the user can configure its own 6-character unit displayed on
LCD3. It is possible to display ASCII characters from the range (32 ... 96 dec) or
(20 … 60 hex), i.e.:
!"#$%&'()*+,-./0123456789:;<>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`
9.2. Local buttons
Local buttons are used to enable the configuration mode of some transmitter parameters and to navi-
gate through MENU and accept MENU options. The MENU can be accessed by pressing and holding
any of the buttons for at least 4 seconds. After this time, the LCD3 field of the local display will show
an EXIT message. This signals entering into the MENU navigation mode.
9.3. Local configuration of setpoint
APRE-2000GN transmitter enables local configuration of some of the most common setpoints via
local buttons and local LCD display.
9.4. Navigation in local setpoints MENU
The MENU can be accessed by pressing and holding any of the buttons for at least 4 seconds. After
this time, the LCD3 field of the local display will show an EXIT message. This signals entering into the
local configuration MENU. By pressing the buttons with arrows [↑] [↓] for at least 1 second you can
move up or down MENU.
9.5. Acceptance of local setpoints
The key marked with symbol [●] is used to accept the selection. The acceptance of setpoint change is
confirmed by a DONE message displayed on LCD3. After changing the setpoint, the transmitter
leaves the local configuration change MENU. If no selection is made in the MENU mode, after 2
minutes the transmitter automatically returns to display of standard messages. The MENU can also
be left by selecting and accepting the EXIT option.
9.6. Structure of local setpoints MENU
Press and hold any of 3 buttons for 4 seconds.
When navigating in the area of the active local MENU, holding the button required to trigger the action
is minimum 1 second. Continuous pressing of the ↑ or ↓ button results in scrolling of the MENU posi-
tions every 1 second. If the local MENU remains inactive for more than 2 minutes, after this time the
transmitter will automatically leave the local MENU and will display the process variable.

EN.IO.APREGN
18 Revision.02.A.002

EN.IO.APREGN
Revision.02.A.002 19
9.7. Remote configuration of setpoints (HART 5/HART 7)
The transmitter allows to read out and configure the parameters via HART communication using
4...20 mA loop as a physical layer for FSK BELL 202 modulation.
9.7.1. Compatible devices
The following devices may be used to communicate with the transmitter:
Aplisens S.A. KAP-03, KAP-03Ex communicator (HART 5 only);
communicators from other companies, including those using DDL and DTM libraries;
PC computers equipped with HART modem (e.g. HART/USB converter by Aplisens S.A.) with
Windows7 or Windows10 operating system with installed Raport 2;
PC computers equipped with HART modem using software from other companies, accepting
DDL and DTM libraries;
smartphones with Android system, using a converter providing wireless communication (e.g.
HART/USB converter by Aplisens S.A.) using Aplisens Mobile Configurator. The software is
available on Google Play under the link:
https://play.google.com/store/apps/details?id=com.aplisens.mobile.amc
9.7.2. Compatible configuration software
Raport 2 Aplisens under control of Windows 7 or Windows 10;
Aplisens Mobile Configurator under control of the Android system;
every software from other companies accepting DDL and DTM libraries.

EN.IO.APREGN
20 Revision.02.A.002
10. START-UP
As standard, the transmitter is adjusted to a set range equal to the base range, unless a specific set
range is provided in the order. The base range and the basic unit of the transmitter can be read out
from its nameplate (Transmitter identification).
Use the transmitter within the allowable pressure limits. Risk of injury due to component
breakage after exceeding the maximum permitted operating pressure.
10.1. Alarm configuration
Transmitter APRE-2000GN has a developed internal diagnostics, which monitors the work of elec-
tronic circuits, process and environmental parameters. Diagnosed dangerous states or malfunctions
of the internal transmitter systems result in setting the alarm current depending on the configuration
I_AL < 3.650 mA or I_AL > 21.500 mA. The user has an option of enabling/disabling of the current
alarms. Current alarms are disabled by default.
The figure below shows the normal operation ranges of the transmitter process output and the ranges
of saturation and alarm currents
Figure 7. Set range current, saturation currents, alarm currents.
1 –Set 4...20 mA current area is corresponding to setpoint 0…100% of the process output.
2 –Lower saturation current of 3.800 mA for NAMUR mode.
3 –Lower saturation current of 3.900 mA for NORMAL mode.
4 –Upper saturation current of 20.500 mA for NAMUR and NORMAL mode.
5 –Alarm current area AL_L < 3.650 mA for internal diagnostic alarms.
6 –Alarm current area AL_H > 21,500 mA for internal diagnostic alarms.
