Apollo Seiko SRC-3000 User manual

Sponge Roller Cleaner
SRC-3000
Operation Manual
Thank you for purchasing the SRC-3000.
Read these instructions thoroughly for proper use of this device.
Make sure to read "Safety Notes" before you use the device.
This information protects you from possible dangers during use.
Apollo Seiko Ltd.
Rev.1.00
1

Safety Notes
This manual includes the important information to use this device safely. This also includes useful information to
prevent avoiding injury or damaging property.
Please read this manual carefully prior to connecting or operating the SRC-3000.
Keep this manual nearby the device all the time.
Supply only specified voltage
Do not connect to a power supply greater than the specified voltage. If not, electrical shock and /or damage to the
device may occur.
Make sure that the electrical outlet is properly grounded. If the outlet is not properly grounded, electrical shock
and/or damage to the device may occur.
Working ambient temperature and relative humidity
This device has been designed to use between 0～40 degree、10%～90%. Do not use this device under the
condition exceeding here-in.
Handle with care
This device is designed to clean the iron tip.
Please be careful your fingers do not get caught in roller sponges.
Please make sure to turn off the power, when you replace sponges.
Please note water does not overflow from the water reservoir. It may cause electric shock or leak.
Please handle the device with care. If you drop or make a big impact/ vibration, it may cause malfunction.
If you note malfunction on unit
If the device become a malfunction, turn off the power immediately and contact a dealer you purchased the
device from.
Immunity from responsibility
We do take NO responsibility on a damage caused by misuse, mistake, accident, uses in abnormal condition or
natural disaster such as an earthquake, a fire etc.
We do take NO responsibility on contingency loss （Business loss、Business stop）caused by device stop.
We do take NO responsibility on a loss caused by the operation not mentioning on this manual.
We do take NO responsibility on a loss caused by a wrong connection with other equipment.
If for any reason the internal circuitry is tampered with altered or repaired without written consent of Apollo Seiko,
the warranty is null and void. The customer is allowed to make necessary tooling adjustment, replace solder
iron tips and make any necessary adjustments to the temperature controller.
2

Index
Safety Notes............................................................................................................... 2
1. Description .................................................................................................................... 4
2. Maintenance .................................................................................................................. 5
3. Consumables ................................................................................................................. 6
4. Specification................................................................................................................... 6
5. Dimension ..................................................................................................................... 6
3

1. Description
Power switch
(SRC-3007)
Suction Sponge B
(SRC-3005)
Pin
(SRC-3003)
Cover
(SRC-3001)
Water reservoir
(SRC-3002)
Fuse 1A
(SRC-3010)
Motor 100V / 200V
(SRC-3008)
Sponge
(SRC-3006)
Sponge screw cap
(SRC-3004)
Power cable
(SRC-3009)
4

2. Maintenance
2-1. Replacement of Sponge (SRC-3006)*Before removing,
Remove the used sponges. *Please moisten the sponges before removing.
Put the new sponges. *Please use the moistened sponges.
2-2. Replacement of Suction sponge B (SRC-3005)
Loosen the two nuts.
Please power OFF, when you work below.
After removing the two front
sponges, take the Pin off.
Remove the two back sponges.
Put new back sponges and
pins.
Put new front sponges and
tighten the two nuts.
Insert a new moistened
sponge and pick out the tip
of sponge with a pinch.
Moisten the used suction
sponge and remove it.
5

(Sponge interference dimension)
Mounting screw hole (Φ3.5) 2
3. Consumables
4. Specification
5. Dimension
Apollo Seiko Ltd.
2271-7 Jinba, Gotenba-shi,
Shizuoka, Japan
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
URL: http://www.apolloseiko.co.jp
Name Type
Pin SRC-3003
Nut SRC-3004
Suction sponge B SRC-3005
Sponge SRC-3006
Dimension 115mm(W) X90mm(D) X88mm(H)
Power supply (100V / 220V) AC-100V / AC220V
Number of Sponge Rotation Approx. 30rpm
Working Liquid Tap-water
