Aprilaire 6000 Series Setup guide

SAFETY INSTRUCTIONS
Read this entire installation manual before beginning installation of the Aprilaire 6000 Series Zone Control System. For questions call Aprilaire
customer support at [phone] or visit AprilairePartners.com.
WARNING
1. 120 volts may cause serious injury from electrical shock. Leave power disconnected until installation is complete.
2. The system is designed for indoor use only. Do not expose any of the components to moisture.
WARNING
1. Turn o the system power before removing or installing any wires into the terminals of any component of the system. Wiring with a live
circuit can lead to electrical shorts that can damage components.
2. Installation must be done in accordance with all applicable codes.
3. Installer should touch a grounded metal object before handling the components of the system. This will prevent any static discharge that
may cause damage.
4. A 6000 Series Zone Control System may not control temperature properly unless the heating and cooling system is properly sized and
balanced.
5. Insucient air flow or excessive temperatures through the heating and cooling system could result in equipment damage. Refer to the
manufacturer’s recommendations for minimum safe airflow and temperature requirements.
6. Do not mount the 6000 Series Control or Sensors on any exterior wall or equipment supply ductwork.
7. Do not install the system components where temperatures exceed 158°F (70°C) or are below 32°F (0°C), non-condensing.
8. Improper system installation could cause water damage from frozen pipes. Check system operation after installation.
READ AND SAVE THESE INSTRUCTIONS
6000 Series Zone Control System
For models 6010, 6015, 6020, 6025, 6030, 6035,
6040, 6045, 6045M
Safety & Installation Instructions
1

TABLE OF CONTENTS
SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
APPLICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
6000 Series Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
6000 Series Control Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6000 Series Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6000 SERIES HUB INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
6000 SERIES HUB WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Transformer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Damper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Outdoor Temperature Sensor (Included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Discharge Air Temperature Sensor (Included) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Return Air Temperature Sensor (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
HVAC Equipment Wiring Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Indoor Air Quality Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
6000 SERIES CONTROL AND SENSORS INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Location Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
INSTALLER SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6000 Series Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Installer Setup Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
INSTALLER TOOLS AND TEST TABLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 2: Installer Tools and Test Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
INSTALLER SETTINGS TABLES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Table 3: General System Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Table 4: Thermostat System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Table 5: Zone System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Indoor Air Quality (IAQ). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Table 6: Humidifier System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Table 7: Dehumidifier System Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 8: Air Cleaning System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Table 9: Fresh Air System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
WI-FI SETUP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
For Aprilaire App Connected Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
For Home Automation Connected Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Connect to a Network using the 6000 Series Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Connect to a Network using a Browser. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6000 SERIES SENSOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Zone Number Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
INSTALLER TEST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6000 Series Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6000 Series Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SEQUENCE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
2

SPECIFICATIONS
INPUT RATINGS (6000 SERIES HUB)
Voltage: 18-30VAC 50/60 Hz
MAXIMUM CURRENT
Damper output per zone (fused): 18VA at 158°F, 30VA at 90°F
Note: Use 18 or 20 AWG solid (non-stranded) wire
ENVIRONMENT
6000 Series Hub Temperature (operating): 32°F – 158°F
6000 Series Control and Sensors (operating): 32°F – 120°F
Temperature (shipping): -30°F – 150°F
Humidity: 5% – 90%, non-condensing
DIMENSIONS
8.63 (219) 1.86
(47)
11.19 (284)
3.07 (78)
0.82
(21)
4.99 (127)
7.11 (181)
6000 SERIES HUB
6000 SERIES SENSOR
6000 SERIES CONTROL
4.38 (111)
1.06
(27)
FIGURE 1 – DIMENSIONS IN INCHES (mm)
90-2405
3

APPLICATIONS
The Aprilaire 6000 Series Zone Control System is available in these configurations:
Model 6010 2 Zone Hub Black Control 1 Black Sensor Model 6030 2 Zone Hub Black Control
Model 6015 2 Zone Hub White Control 1 White Sensor Model 6035 2 Zone Hub White Control
Model 6020 3 Zone Hub Black Control 2 Black Sensors Model 6040 3 Zone Hub Black Control
Model 6025 3 Zone Hub White Control 2 White Sensors Model 6045 3 Zone Hub White Control
Model 6045M 3 Zone Hub White Control
FEATURES
• Remote access using a downloadable app from the iOS App Store and from Google Play Store
• Indoor air quality control
• Humidification with automatic or manual control
• Dehumidification
• Event-Based™ air cleaning
• Ventilation with temperature and humidity limits
• Temperature control
• Heat Blast® raising the room temperature 3°F to 5°F
• One touch Away
• Large touch screen with adjustable backlight
• 7 day programmability
• Displays room temperature, room humidity, temperature setting, and outdoor temperature
• Air filter, humidifier, dehumidifier, and HVAC service reminders
• Programmable fan control with fan circulation mode
• Easy to use temperature control that can override program schedule at any time
• Progressive recovery that ensures proper temperature at the start of a program event
• Built in compressor protection that prevents damage to your equipment
• Two heating and two cooling stages (conventional)
• Four heating and two cooling stages (heat pump)
• Integrated balance point control
• System test mode
4

LAYOUT
6000 SERIES HUB
TERMINALS
1. HVAC – HVAC connection.
2. JUMPER – RH/RC Jumper.
3. ZONE 1 CONTROL – 6000 Series Control connection.
4. ZONE 2 CONTROL – 6000 Series Sensor 2 connection.
5. ZONE 3 CONTROL – 6000 Series Sensor 3 connection (3Zone
models only).
6. DAMPER 1 – Zone 1 damper connection.
7. DAMPER 2 – Zone 2 damper connection.
8. DAMPER 3 – Zone 3 damper connection (3 Zone models only).
9. REMOTE SENSORS DAT (Discharge Air Temperature).
10. REMOTE SENSORS ODT (Outdoor Air Temperature).
11. REMOTE SENSORS RAT (Returning Air Temperature).
12. POWER – System power connection 24VAC.
13. HUM/AUX – Humidifier (AUX is for future upgrades).
14. DEHUM – Dehumidifier.
15. VENT – Ventilation.
LEDS
16. POWER – Green: 24VAC present. Flashing: Not connected to 6000
Series Control.
17. EM HEAT – Yellow: Emergency heating is active.
18. HEATING – Green: Heating is active.
19. COOLING – Green: Cooling is active.
20. FAN – Green: Fan output is active.
21. HUM/AUX – Green: Humidification output is active (AUX is for future
upgrades).
22. DEHUMIDIFIER – Green: Dehumidification output is active.
23. VENTILATION – Green: Humidification output is active.
24. ZONE 1 – Green: Damper is open. Red: Damper is closed.
25. ZONE 2 – Green: Damper is open. Red: Damper is closed.
26. ZONE 3 – Green: Damper is open. Red: Damper is closed. (3 Zone
models only)
BUTTON
27. INSTALLER TEST BUTTON – See page 24.
16
17
18
19
20
21
22
23
24
25
26
8
7
6
27
10
11
9
1
2
12
3
4
5
13
14
15
90-2406
5

NOTE: SCREEN BRIGHTENS AFTER FIRST TOUCH.
OUTDOOR
TEMPERATURE
HEATING AND COOLING
EQUIPMENT STATUS
HOLD MENU
& STATUS
FAN MODE
SELECTION
DETAILED
EQUIPMENT STATUS
HEAT BLAST MODE
& STATUS
WEATHER FORECAST
& ALLERGY REPORT
ACTIVE ALERTS &
ALERT SETTINGS
CURRENT SCREEN
RELATED HELP
MAIN MENU
HUMIDIFIER AND
OR DEHUMIDIFIER
INDOOR AIR QUALITY
SCREEN & SIMPLE
STATUS
ROOM TEMPERATURE
TEMPERATURE SETTINGHEATING AND COOLING STATUS
TEMPERATURE ADJUSTMENT
AIR CLEANING
INDOOR AIR QUALITY
SCREEN & SIMPLE
STATUS
COOL SETTING ZONE SELECTIONWI-FI INDICATOR
(STROBES IN SETUP MODE)
FRESH AIR INDOOR
AIR QUALITY SCREEN
& SIMPLE STATUS
AWAY MODE
& STATUS
SYSTEM MODE
SELECTION
ROOM TEMPERATURE
& HUMIDITY
HEAT SETTINGCURRENT DATE AND TIME
(AUTOMATICALLY UPDATED
IF CONNECTED TO INTERNET)
6000 SERIES CONTROL HOME SCREEN
6000 SERIES SENSOR
6

6000 SERIES HUB INSTALLATION
LOCATION
1. Mount the 6000 Series Hub near the HVAC equipment, on an
interior wall, stud or return duct. See FIGURE 2.
2. Locate the Discharge Air Temperature (DAT) in the supply trunk,
downstream of the heat exchanger and cooling coils, and before
the zone dampers (refer to the shaded areas of FIGURE 2).
Note: Do not mount the sensor in direct line-of-sight of the heat
exchanger, cooling coils or UV lights as this may cause the sensor
to report false temperature readings. Do not route wires along
120VAC lines.
3. Before wiring the sensor to the 6000 Series Hub, measure
the resistance across the sensor. The resistance corresponds
(approximately) to the sensed temperature according to TABLE 1.
TABLE 1 – DAT SENSOR RESISTANCE
Temperature (°F) 30 40 50 60 70 80 90 100
Resistance (k )34.6 26.1 19.9 15.3 11.9 9.4 7.4 5.9
MOUNTING
1. Separate the 6000 Series Hub cover from the base. See FIGURE 3.
2. Use the base as a template to drill mounting holes. See FIGURE 4 for mounting hole locations.
3. Attach the base to an interior wall, stud or return duct.
LOCATE DAT
SENSOR IN
SHADED AREA
(SUPPLY DUCT)
HUB MOUNTED ON
WALL OR STUD
HUB MOUNTED ON
RETURN DUCT
USE TWO SCREWS WHEN
ATTACHING TO A WALL STUD
USE FOUR SCREWS
WHEN ATTACHING TO
DRYWALL/PLASTER
1
2
FIGURE 2 – 6000 SERIES HUB MOUNTING LOCATION
FIGURE 4 – 6000 SERIES HUB MOUNTING LOCATIONFIGURE 3
90-2407
90-240990-2408
7

6000 SERIES HUB WIRING
WARNING
120 volts may cause serious injury from electrical shock. Sudden
operation may cause serious injury from moving parts. Leave
power disconnected until installation is complete.
Follow these steps for all system connections. Wiring will vary
depending on equipment. Wiring of the system must comply with
applicable codes, ordinances and regulations.
• Use only 18 or 20 gauge solid (non-stranded) wire.
• Strip off 7/16" of insulation from the wire.
• Push wire into the terminal of the 6000 Series Hub.
• To release the wire, press down on the top of the terminal and pull
the wire out.
• The 6000 Series Hub supports multiple options to route and anchor
wires to the housing. See FIGURE 5.
WIRE TIE MOUNTS
FIGURE 5 – WIRE TIE MOUNTS
90-2073
TRANSFORMER
Note: The HVAC equipment transformer cannot be used for power. A
separate transformer should be used to power the system.
1. Wire 24VAC from transformer to the POWER, R and C terminals (see
FIGURE 6).
2. Sizing of transformer to accommodate the number of dampers:
a. Select your damper type.
OPTION 1: Normally Open/Power Close Dampers (2-Wire)
i. Add up all the zone dampers that are in the system.
ii. Subtract the number of dampers in the zone with the least number of dampers. This is the greatest number of dampers that could be
energized at one time.
iii. Multiply this number by 10 to determine the damper VA requirement. Add an additional 10VA for the 6000 Series System.
Example: If you have a 3-zone system, and there are two dampers per zone, then the total number of dampers that could be energized at
one time is,
6 dampers – 2 dampers = 4 dampers
4 dampers x 10VA per damper + 10VA for 6000 Series System = 50VA required
OPTION 2: Power Open/Power Close Dampers (3-Wire)
i. Add up all the zone dampers that are in the system.
ii. Multiply this number by 2.5 to determine the transformer size. Add an additional 10VA for the 6000 Series System.
Example: If you have a 3-zone system, and there are two dampers per zone, then the total number of dampers that could be energized at
one time is,
6 dampers x 2.5VA per damper + 10VA for 6000 Series System = 25VA required
b. Select a transformer that meets or exceeds the value calculated.
TRANSFORMER
24 VAC
120 VAC
FIGURE 6 – TRANSFORMER
90-2412
8

DAMPER
• Run 2-conductor thermostat wire for spring
return dampers (normally open or normally
closed).
• Run 3-conductor thermostat wire for power
open/power close dampers.
• Multiple dampers for the same zone can be
wired in parallel as shown in FIGURES 7 & 8.
• Wire the dampers to the 6000 Series Hub:
NC – This terminal is used to power open
a normally closed damper. For power open
and power close dampers this terminal is
used to power open the damper.
NO – This terminal is used to power close a
normally open damper. For power open and
power close dampers this terminal is used to
power close the damper.
COM – This terminal provides a common
connection for the NC and NO terminals.
• If multiple transformers will be required,
wire them in parallel as shown. Before
wiring the transformers together, ensure
that they are connected in phase by
observing polarity marks or terminal
orientation on each transformer. See
FIGURE 9.OPEN
CLOSE
COMMON
OPEN
CLOSE
COMMON
IMPORTANT: CHECK PHASE OF TRANSFORMERS BEFORE WIRING TOGETHER
90-2415
FIGURE 7 – NORMALLY OPEN / POWER CLOSE DAMPERS
FIGURE 8 – POWER OPEN / POWER CLOSE DAMPERS
FIGURE 9 – MULTIPLE TRANSFORMERS
90-2413
90-2414
9

OUTDOOR TEMPERATURE SENSOR (INCLUDED)
• Wire the outdoor temperature sensor Model
8052 to the “ODT” terminals as shown. See
FIGURE 10.
• Maximum distance of the ODT sensor from
the 6000 Series is 300 feet.
• Do not wire along 120VAC lines.
• Outdoor temperature sensor should be
mounted:
– On side of building out of direct sunlight.
– Above snow line.
– At least 3 feet away from exhaust vents
and condensing lines.
MODEL 8052 TEMP SENSOR
MODEL 8057 TEMP SENSOR
90-2088
90-2427
FIGURE 10 – OUTDOOR TEMPERATURE SENSOR
FIGURE 11 – DISCHARGE AIR TEMPERATURE SENSOR
MODEL 8052 TEMP SENSOR
90-2416
FIGURE 12 – RETURN AIR TEMPERATURE SENSOR
DISCHARGE AIR TEMPERATURE SENSOR (INCLUDED)
• Wire the discharge air temperature sensor
Model 8057 to the “DAT” terminals as
shown. See FIGURE 11.
• Maximum distance of the DAT sensor from
the 6000 Series Hub is 300 feet.
• Do not wire along 120VAC lines.
• Refer to FIGURE 2 on page 7 for the proper
mounting location of the discharge air
temperature sensor.
RETURN AIR TEMPERATURE SENSOR (OPTIONAL)
• Wire the return air temperature sensor
Model 8052 to the “RAT” terminals as
shown. See FIGURE 12.
• Maximum distance of the RAT sensor from
the 6000 Series Hub is 300 feet.
• Do not wire along 120VAC lines.
• Mount the sensor according to the
installation instructions provided with the
sensor.
10

HVAC EQUIPMENT WIRING DIAGRAMS
JUMPER
INSTALLED
FURNACE AND A/C
Y
RH
RC
Y2
HVAC
W2
W
C
G
O
L
B
Y1
G
R
BOILER AND A/C
NOTE:
REMOVE RH/RC JUMPER
R
C
W
BOILER
INDOOR
AIR HANDLER
AND A/C
JUMPER
REMOVED
Y
RH
RC
Y2
HVAC
W2
W
C
G
O
L
B
Y2
R
W1
Y1
TWO STAGE
HEAT PUMP
W2
O
L
C
G
JUMPER
INSTALLED
Y
RH
RC
Y2
HVAC
W2
W
C
G
O
L
B
G
C
R
Y1
FURNACE
AND A/C W1
R
C
W1
24V SPST
NO RELAY
RADIANT
FLOOR
HEAT
JUMPER
INSTALLED
Y
RH
RC
Y2
HVAC
W2
W
C
G
O
L
B
90-2417
90-2419
90-2418
90-2420
FIGURE 13 – TWO-STAGE FURNACE AND A/C
FIGURE 15 – BOILER AND A/C
FIGURE 14 – TWO-STAGE HEAT PUMP
FIGURE 16 – RADIANT FLOOR FIRST-STAGE HEAT,
FURNACE SECOND-STAGE HEAT AND A/C
11

INDOOR AIR QUALITY WIRING DIAGRAMS
TRANSFORMER
TRANSFORMER
HUMIDIFIER
DEHUMIDIFIER
NORMALLY
CLOSED DAMPER
TRANSFORMER
HUMIDIFIER
DEHUMIDIFIER
NORMALLY
CLOSED DAMPER
90-2425 90-2426
FIGURE 17 – INDOOR AIR QUALITY WIRING
WITH SEPARATE TRANSFORMERS
FIGURE 18 – INDOOR AIR QUALITY WIRING
WITH A SINGLE TRANSFORMER
Note: Outputs are 24VAC dry contact. Refer to individual product
installation instructions for more details.
Note: Outputs are 24VAC dry contact. Refer to individual product
installation instructions for more details.
12

6000 SERIES CONTROL AND SENSORS INSTALLATION
LOCATION RECOMMENDATIONS
6000 Series Control and Sensors should be mounted:
• On an interior wall, in a frequently occupied space.
• Approximately 5 feet above floor.
• At least 18" from outside wall.
• Displays can be mounted to a vertical junction box.
Do not mount:
• Behind doors, in corners, or other dead air spaces.
• In direct sunlight, near lighting fixtures, or other appliances that give off heat.
• On an outside or unconditioned area wall.
• In the flow of a supply register, in stairwells, or near outside doors.
• On a wall with concealed pipes or ductwork.
MOUNTING
1. Remove the rear mounting plate.
2. Pull wires through the opening on the rear mounting plate.
3. Position and level the mounting plate of the display on the wall and mark the hole locations with a pencil.
4. Drill 1/4" holes and insert supplied anchors (drywall only).
5. Place mounting plate over anchors, insert and tighten screws.
6. Seal wire entry holes to prevent drafts affecting temperature readings.
90-2421 90-2422
FIGURE 19 – 6000 SERIES CONTROL MOUNTING PLATE FIGURE 20 – 6000 SERIES SENSOR MOUNTING PLATE
13

WIRING
WIRE SPECIFICATIONS:
18-24 gauge thermostat wire
INSTALLATION NOTES:
Control to Hub
• Ensure power at the 6000 Series Hub is off.
• Insert stripped wire (Hub).
• Loosen screw terminals (Control), insert stripped wire and re-tighten.
• Push the excess wire at Control, back into the opening and plug the
wall opening to prevent drafts.
1– Connect Control terminal 1 to Hub terminal 1
2– Connect Control terminal 2 to Hub terminal 2
3– Connect Control terminal 3 to Hub terminal 3
4– Connect Control terminal 4 to Hub terminal 4
Sensor to Hub
• Ensure power at the 6000 Series Hub is off.
• Insert stripped wire (Sensor & Hub).
• Push the excess wire at Sensor, back into the opening and plug the
wall opening to prevent drafts.
1– Connect Sensor terminal 1 to Hub terminal 1
2– Connect Sensor terminal 2 to Hub terminal 2
3– Connect Sensor terminal 3 to Hub terminal 3
4– Connect Sensor terminal 4 to Hub terminal 4
90-2423
90-2424
FIGURE 21 – 4-WIRE CONNECTION, 6000 SERIES CONTROL
FIGURE 22 – 4-WIRE CONNECTION, 6000 SERIES SENSOR
14

INSTALLER SETUP
6000 SERIES CONTROL
The 6000 Series Hub is powered by 24VAC. The 6000 Series Control is powered by the 6000 Series Hub. In the case of power loss, the system will
maintain the clock for 24 hours. The system has a memory backup that saves the system settings in case of power interruption. The factory reset is
located in the Installer Tools option of the Installer Menu. See Installer System Settings section for details.
INSTALLER SETUP MENU
The first time the system is powered up (or after
a factory reset) it will enter the Installer Setup
Menu. All installer settings can be set here. The
installer settings are also accessible in the MENU
by pressing the Contractor Info button for 10
seconds. Installer settings can be imported and
exported via USB drive. This feature can be
found by selecting the Installer Tools button on
the Installer Settings Menu Screen.
INSTALLER TOOLS AND TEST TABLE
TABLE 2: INSTALLER TOOLS AND TEST MENU
Function Description
Import USB Settings Import installer settings from another 6000 Series Control. USB drive required.
Export USB Settings Export installer settings to use on another 6000 Series Control. USB drive required.
Factory Reset Reset the control back to factory defaults.
Connection Type Select whether the control will connect to the Aprilaire App (default) or to an home automation system.
Installer Test Test equipment outputs. See page 23.
INSTALLER SETTINGS TABLES
The following tables contain the system settings and their details. Default settings are shown in bold. The availability of some settings is dependent
upon the value of other settings.
TABLE 3: GENERAL SYSTEM SETTINGS
System Setting Description
Factory Default Settings (bold)
and Settings Range
Installer Temperature Scale This selection only effects the installer setup menus. Fahrenheit
Celsius
Contractor Information Input Enter contractor’s contact information. Company, Phone, Email, Web.
15

TABLE 4: THERMOSTAT SYSTEM SETTINGS
System Setting Description
Factory Default Settings (bold)
and Settings Range
Equipment Type Note: Equipment Type related settings will return to defaults if this is changed. Heat/Cool
Heat Pump
Control Setup Used to lockout heating or cooling outputs. (Heat/Cool mode only.)
Heat & Cool
Heat Only
Cool Only
Heat Pump Auxiliary Type Selects auxiliary type. (Heat Pump mode only.) Gas/Oil Heat
Electric Heat
Fan Control In Heating Selects thermostat or equipment to control the fan in heating. (Heat/Cool mode
only.)
Gas/Oil Heat
Electric Heat
Number of Compressor Stages Select number of compressor stages. (Heat Pump mode only.) One
Two
Number of Auxiliary Heat Stages Select number of auxiliary heat stages. (Heat Pump mode only.) One
Two
Number of Stages of Heat Select number of heat stages. (Heat/Cool mode only.) One
Two
Number of Stages of Cool Select number of cool stages. (Heat/Cool mode only.) One
Two
Return Air Temperature Sensor Installed? Select whether return air temperature sensor is attached or not. No
Yes
Outdoor Temperature Sensor Installed? Select whether outdoor sensor is attached or not.
Yes
No
Automation
Schedule Zone 1 Enables or disables programmable schedule. Note: Disabled if Automation. Enabled
Disabled
Schedule Zone 2 Enables or disables programmable schedule. Note: Disabled if Automation. Enabled
Disabled
Schedule Zone 3 Enables or disables programmable schedule. Note: Disabled if Automation. Enabled
Disabled
Progressive Recovery Enables or disables progressive recovery. Enabled
Disabled
Display Away Button?
Away allows the user to set the thermostat to a predefined setpoint using
a single button press. The predefined setpoints can be selected in the User
Settings.
Yes
No
Display Heat Blast Button? Select whether the Heat Blast button is displayed. Yes
No
Blast Offset Amount of heating when Heat Blast is initiated.
3°F (1.5°C)
4°F (2°C)
5°F (2.5°C)
Extended Fan – Heat Extends fan operation after heat call ends. Disabled
Enabled
Extended Fan – Cool Extends fan operation after cool call ends. Disabled
Enabled
Auto Changeover Enable or disable Auto Changeover mode. Enabled
Disabled
DeadBand Auto Changeover mode deadband. 3°F (1.5°C)
2 to 9°F (1 to 4.5°C)
Auto Changeover Time Minimum time between heating and cooling calls. 4 Minutes
1 to 5 Minutes
Temp Sensor Offset Zone 1 Field adjustment of controlling temperature sensors. 0°F (0°C)
-4 to 4°F (-2 to +2°C)
16

TABLE 4: THERMOSTAT SYSTEM SETTINGS
System Setting Description
Factory Default Settings (bold)
and Settings Range
RH Sensor Offset Zone 1 Field adjustment of internal RH sensor. 0
-5 to 5
Temp Sensor Offset Zone 2 Field adjustment of controlling temperature sensors. 0°F (0°C)
-4 to 4°F (-2 to +2°C)
RH Sensor Offset Zone 2 Field adjustment of internal RH sensor. 0
-5 to 5
Temp Sensor Offset Zone 3 Field adjustment of controlling temperature sensors. 0°F (0°C)
-4 to 4°F (-2 to +2°C)
RH Sensor Offset Zone 3 Field adjustment of internal RH sensor. 0
-5 to 5
Equipment Minimum On Time Minimum on time for heating and cooling. 2 Minutes
1 to 5 Minutes
Heating Minimum Off Time Minimum off time for heating. 2 Minutes
1 to 5 Minutes
Compressor Minimum Off Time Minimum off time for compressor protection. 5 Minutes
1 to 5 Minutes
Outdoor Temperature High Balance Point Enable or disable high balance point. (Available if ODT is installed.) Enabled
Disabled
Select Temperature If outside temperature is above the high balance point, the aux heat operation is
not allowed. (Available if high balance point is enabled.)
65°F (14.5°C)
0 to 80°F (-18 to 22°C)
Outdoor Temperature Low Balance Point Enable or disable low balance point. (Available if ODT is installed.) Enabled
Disabled
Select Temperature If outside temperature is below the low balance point, the compressor operation
is not allowed. (Available if low balance point is enabled.)
20°F (-8°C)
0 to 60°F (-18 to 12°C)
Stage Rate Accumulation of equipment run time in staging determination. Enabled
Disabled
Factor 1 = more rapid staging of equipment (comfort).
5 = slower staging of equipment (economy).
2
1 to 5
First Stage Differential First stage differential. 1°F (0.5°C)
1 to 9°F (0.5 to 4.5°C)
Second Stage Differential Second stage differential. 1°F (0.5°C)
1 to 9°F (0.5 to 4.5°C)
Third Stage Differential Third stage differential. 1°F (0.5°C)
1 to 9°F (0.5 to 4.5°C)
Forth Stage Differential Fourth stage differential. 1°F (0.5°C)
1 to 9°F (0.5 to 4.5°C)
Service HVAC Reminder The period for displaying the HVAC Service reminder message. Disabled
Enabled
Recurrence Select number of months for displaying reminder. 12 Months
1 to 12 Months
17

TABLE 5: ZONE SYSTEM SETTINGS
System Setting Description
Factory Default Settings (bold)
and Settings Range
Number of Zones Number of zones detected.
1
2
3
Staging Based On Staging based on Zones. Zone
Number of Zones
Zones to Stage Selects how many Zones are required to stage up. Note: Only option if ZONES is
enabled.
2
1-9
Zone 1 Weighting The amount of precedence each zone has.
1
2
3
Zone 2 Weighting The amount of precedence each zone has.
1
2
3
Zone 3 Weighting The amount of precedence each zone has.
1
2
3
DAT Sensor Enables or disables the DAT sensor. Yes
No
DAT Low Limit Low Temperature Limit. Safety limit at which the HVAC equipment will turn off.
Note: Only option if DAT Sensor is enabled.
30°F to 45°F
(2.5°F steps / 35°F)
DAT High Limit High Temperature Limit. Safety limit at which the HVAC equipment will turn off.
Note: Only option if DAT Sensor is enabled.
110°F to 170°F
(5°F steps / 160°F)
Downstage on DAT Allows panel to downstage multistage equipment when DAT temperature comes
within 5°F high or low limit. Note: Only option if DAT Sensor is enabled.
Yes
No
18

INDOOR AIR QUALITY (IAQ)
The following tables contain the Indoor Air Quality system settings and their details. Default settings are shown in bold. Some settings are only
present dependent upon the value of other settings. The use of an outdoor temperature sensor (recommended) enables additional Indoor Air Quality
functionality. Please refer to the Owner’s Manual for further information about control features.
Note: Refer to manuals for humidifier, dehumidifier, air cleaner, and ventilation products for recommended installation and operation.
TABLE 6: HUMIDIFIER SYSTEM SETTINGS
System Setting Description
Factory Default Settings (bold)
and Settings Range
Humidifier Installed? No: Humidifier is not installed. Yes/On HVAC: Humidifier is installed on the HVAC
duct. Yes/Standalone: Humidifier is independent of the HVAC system.
No
Yes/On HVAC
Yes/Standalone
Display Button? Note: Only available if Humidifier Installed is set to No. Yes
No
Outdoor Temperature Sensor Installed? Select if outdoor sensor is attached or not.
Yes
No
Automation
Humidifier Mode
Auto: Controls based on setting and outdoor temperature. Manual: Controls
based on RH% setpoint. (Auto mode is only available if Outdoor sensor is set to
Yes.)
Auto
Manual
Allowed Humidifier Operation
Selects when humidification is allowed to occur relative to heating and fan
operation. Without Fan allows humidification to occur without the HVAC fan.
This option should only be used when the humidifier is independent of the HVAC
system. Note: Without Fan is only available when Humidifier Installed is set to
Yes/Standalone.
Forces Fan
Heat Only
Heat or Fan
Without Fan
CAUTION: When Humidifier Operation is set to Without Fan, the control will turn on humidification without energizing the HVAC fan. Do not select this option
when the humidifier is installed on the HVAC duct. Without airflow, moisture can accumulate in the duct resulting in significant damage. Humidity Deadband
Select the minimum difference between the humidifier and dehumidifier setpoints. (Only available if both a humidifier and dehumidifier are installed.)
Humidity Deadband Select the minimum difference between the humidifier and dehumidifier
setpoints. (Only available if both a humidifier and dehumidifier are installed.)
10%
10 to 20%
Humidifier Reminder Selects when the Change Water Panel message is displayed.
Off
300h Valve
600h Valve
1 per season
2 per season
Single or First Reminder Appears Determines the month the first (or only) Change Water Panel message is
displayed.
October
November
December
January
February
March
April
May
June
July
August
September
Second Reminder Appears Determines the month the second Change Water Panel message is displayed.
October
November
December
January
February
March
April
May
June
July
August
September
19

TABLE 7: DEHUMIDIFIER SYSTEM SETTINGS
System Setting Description
Factory Default Settings (bold)
and Settings Range
Dehumidifier Type Installed? Selects whether a dehumidifier is installed. (If set to None, no other dehumidifier
settings will be available.)
None
Whole Home
Air Conditioner Overcooling
Display Button? Note: Only available if Dehumidifier Installed is set to None Yes
No
Disable Dehumidification During Cooling? Selects whether a dehumidifier is disabled during a cooling call. Yes
No
Dehumidifier Forces Fan? Selects whether dehumidification can turn on the fan. Yes
No
Dehumidifier Overcooling Limit Selects the amount of overcooling that can occur for dehumidification. (Only
available if dehumidifier type is set to Air Conditioning.)
1°F (0.5°C)
2°F (1°C)
3°F (1.5°C)
Dehumidifier Reminder The period for displaying the Dehumidification Service Reminder message. Disabled
Enabled
Recurrence Select number of months for displaying reminder. 12 Months
1 to 12 Months
Humidity Deadband Select the minimum difference between the humidifier and dehumidifier
setpoints. (Only available if both a humidifier and dehumidifier are installed.)
10%
10 to 20%
TABLE 8: AIR CLEANING SYSTEM SETTINGS
System Setting Description
Factory Default Settings (bold)
and Settings Range
Air Cleaner Installed? Selects whether an air cleaner is installed. (If set to No, no other air cleaner
settings will be available.)
No
Yes
Display Button? Note: Only available if Air Cleaning Installed is set to No. Yes
No
Air Cleaner Reminder The period for displaying the Change Air Filter message. Disabled
Enabled
Recurrence Select number of months for displaying reminder. 12 Months
1 to 12 Months
20
