Aquarobotman NEMO User manual

Aquarobotman Innovation Copyright
1
NEMO
User Manual

Aquarobotman Innovation Copyright
2
Reading Tips
Recommendation
Users are advised to watch the instructional videos and Disclaimer before reading this manual.
Video course
Users can watch the instructional videos through the following link, including how to use this product
correctly and safely.
https://www.youtube.com/watch?v=qo-piE7QJhY
Download Aquarobotman APP
Key in Aquarobotman in Apple App Store or Google Play and download the Aquarobotman APP
Apple Mobile Terminal: https://itunes.apple.com/cn/app/aquarobotman/id1247384464?mt=8
Android Mobile Terminal: https://play.google.com/store/apps/details?id=com.qsx.aquarobotma

Aquarobotman Innovation Copyright
3
Contents
Reading Tips................................................................................................................................................ 2
Recommendation...................................................................................................................................................................... 2
Video course.............................................................................................................................................................................. 2
Download Aquarobotman APP................................................................................................................................................2
Product Introduction.................................................................................................................................................5
Brief Introduction........................................................................................................................................................................5
Function Features......................................................................................................................................................................5
Module Composition................................................................................................................................................................. 5
Power System............................................................................................................................................................................ 8
Lighting System......................................................................................................................................................................... 8
Hosting Machine Function........................................................................................................................................................8
Smart Protection System..........................................................................................................................................................8
Smart Battery............................................................................................................................................................................. 9
Wireless Transmitter..............................................................................................................................................10
Brief Introduction......................................................................................................................................................................10
KEVLAR Tether Cable............................................................................................................................................................10
WIFI Signal............................................................................................................................................................................... 10
Protection System................................................................................................................................................................... 10
Aquarobotman APP.................................................................................................................................................. 11
Brief Introduction......................................................................................................................................................................11
Main Interface.......................................................................................................................................................................... 11
Setting Interface.......................................................................................................................................................................13
VR Interface..............................................................................................................................................................................13
Help Interface...........................................................................................................................................................................14
Preview Interface.....................................................................................................................................................................14
Handle Introduction................................................................................................................................................................. 14
Operation Guide......................................................................................................................................................15

Aquarobotman Innovation Copyright
4
Installation.................................................................................................................................................................................15
APP Application....................................................................................................................................................................... 15
PC Software............................................................................................................................................................................. 20
Sensor Calibration...................................................................................................................................................................20
Battery Charge.........................................................................................................................................................................21
Attention......................................................................................................................................................................21
Environmental requirement.................................................................................................................. 21
Check before use................................................................................................................................... 21
Maintenance after use...........................................................................................................................21
Export of the hosting machine memory data..................................................................................... 22
Appendix.....................................................................................................................................................................23
Take off upper shell.................................................................................................................................................................23
Specification and Parameter..................................................................................................................................................24
After-sales support information.......................................................................................................................... 26
Return and replacement policy..............................................................................................................................................26
Warranty policy........................................................................................................................................................................ 27

Aquarobotman Innovation Copyright
5
Product Introduction
This chapter mainly introduces the features and functions of Nemo.
Brief Introduction
The underwater drone Nemo with 4K UHD shooting system and four-ducted stability system enable
real-time, stable and high-definition shooting underwater. The maximum underway speed in water is 2m/s
and duration of running underwater reaches 3 hours. At the same time, the modular design makes the
product more convenient to carry and longer battery life.
Function Features
1. High-definition 4K lens. Support 4K video capture and shooting with 16 million pixels. 120/fps video
capture with the QAS-Balance system enables high-quality dynamic images to be snapshotted.
2. QAS-Balance system. The four-ducted structure design and the independently developed control system
enable Nemo to run stably underwater and perform stable video and photo capture.
3. Detachable battery design. The hosting machine battery is detachable, which finishes loading and
unloading steps through the rotary knob. If the battery is run out, another battery can be replaced. At the
same time, the battery of wheel on wireless transmitter is also independently replaceable.
4. Dynamic experience. Provide various operating methods such as mobile APP, handle, and VR glasses. The
APP control interface is simple and quick to get started. In VR mode, the handle works on control when it is
operated with VR glasses at the same time. The somatosensory control mode is set, which makes the
machine movement is synchronized with the head movement, bringing more real feeling to the user.
Module Composition
Mainly introduce the various modules of the whole machine, detailed parameters can be viewed in the
appendix specification parameter table.
1. Hosting machine
Front

Aquarobotman Innovation Copyright
6
Reverse
2. Wireless transmitter
3. Wireless transmitter battery
Rotary knob
Wireless transmitter
KEVLAR tether cable

Aquarobotman Innovation Copyright
7
4. Hosting machine battery
5. Charger
6. Filter
7. Protective rack

Aquarobotman Innovation Copyright
8
Power System
The power system is mainly composed of two horizontal + two vertical four-ducted thrusters. The thruster
is composed of a customized waterproof and corrosion-resistant motor. With the self-designed propeller,
the performance of the motor can be improved to the highest.
Lighting System
Adjustable matrix lower beam fill light with a maximum brightness of 1000lm.
Suggestions: It is recommended to turn off the fill light to save power in the day time. The fill light needs to
be turned on in water holes with weak light at night.
Hosting Machine Function
1. Depth-oriented: When controlling the horizontal direction, the machine maintains the current depth and
pitch angle unchanged. This mode relies on the internal sensors of the machine. If complicated situations
happen, such as strong magnetic field interference, the machine will not operate normally. Please head to
safe place.
2. Direction-oriented: The direction of the machine remains unchanged, and the snorkeling throttle
controls the machine to float or dive.
3. Open-ended operation: This mode provides a fully open control mode to complete complex dive
postures, such as the machine moving up or down at a large angle. In this mode, the machine's pitch angle
is limited to ±90°, and the pitch angle can be controlled according to different speed levels.
4. VR somatosensory operation: This operation needs to be used with VR glasses. In VR mode, it has a
somatosensory start lock. The user needs to lift the head up more than 60°, then lower the head more than
60°, finally return the head back and thus the somatosensory function can be unlocked. After unlocking,
the machine angle can be controlled by the head posture.
Smart Protection System
The machine will react to unexpected situations:
1. Temperature protection: The normal working water temperature of the machine is -2 °C-35 °C. If the
internal temperature of the machine is abnormal, it will start protection mode.
There are two situations:
a) Work in water with high temperature.
b) The machine is kept in the air after power on, and the internal temperature of the machine is too high.
2. Humidity protection: The protective measures are activated when the machine is too humid. This
problem does not occur in normal use and needs to be returned to the factory for repair when problems
occur.
3. Overcurrent protection: The main causes are as follows:
a) The propeller is entangled and cannot be rotated.
b) Internal performance failure results in short circuit.

Aquarobotman Innovation Copyright
9
4. Low voltage protection: This protection will be triggered when the battery voltage is too low. When the
voltage is lower than 10%, the APP will occur page reminder; when the voltage drops to 0%, the battery will
automatically power off. At this point, the machine can only be manually pulled out of the water through
the KAVLAR signal cable.
5. Motor protection: When the machine's pitch angle or roll angle is greater than 60°under unlocking and
without any control, the motor stops rotating and enters protection mode until the pitch angle and roll
angle are less than 60° at the same time.
Smart Battery
The hosting machine battery acts as a separate part with a built-in intelligent control panel to ensure the
safety of the battery as a connection to various states. The specific features are as follows:
1. Load detection: When it is not loaded, the battery is in sleep state and will not discharge. It only works
when the battery is connected to the machine.
2. Battery self-test: After the battery is installed on the hosting machine, it will first perform a self-test to
check whether the power meets the requirements to power on.
3. Battery short-circuit protection: When the battery detects a short circuit, it will cut off the output and
protect the battery.
4. Discharge overcurrent protection: During the discharge process, if the current is too large, the output will
be cut off to protect the battery and external circuits.
5. Battery storage: The battery can be placed in any state for a short period of time. If it needs long-term
placement, the battery will remain at 80%.

Aquarobotman Innovation Copyright
10
Wireless Transmitter
As a link of communication between the underwater drone and user terminals
Brief Introduction
The wireless transmitter has a built-in WIFI signal, and the battery of which is independently detachable.
The mobile terminal can be connected to WIFI by the Aquarobotman's APP to view the status of the
machine in real time. Please refer to the operation guide for specific operations. Users can choose a wheel
to achieve convenient cable recycling.
KEVLAR Tether Cable
The main function of the KEVLAR signal cable aims to transmit signals. The cable built-in reinforced KEVLAR
fiber can withstand a maximum tensile force of 100kg. It exhibits neutral buoyancy in fresh water, and slight
buoyance in seawater.
WIFI Signal
The WIFI signal uses the 802.11a standard, and the communication distance in a spacious place reaches
50m.
Protection System
When the battery voltage is too low, the system will automatically power off to protect the wireless
transmitter battery.

Aquarobotman Innovation Copyright
11
Aquarobotman APP
About the APP interface and instructions
Brief Introduction
The Aquarobotman APP is applied with Nemo to manipulate Nemo's movements and set basic camera
parameters, as well as share photos and videos directly to social networks.
Main Interface
1. Handle connection status
：Display the handle connection status. Red and “×” are displayed, the connection fails; white and blue “√”
are displayed, the connection succeeds; white icon is displayed, the connection is normal.
2. Hosting machine power
: The battery level is displayed as a percentage. When the battery is too low, the icon will turn red and
a pop-up prompt will appear.
3. WIFI connector battery power
: Wheel battery power. When the battery is too low, the icon will turn red and pop up on the interface
4. Machine pitch angle
: Display the machine's pitch angle data in real time.
5. Machine working temperature
: Display the value of the internal working temperature of the machine, not the temperature in water.
6. Current water depth
: Show the current water depth of the machine and measured in meters.
7. Photo shooting button

Aquarobotman Innovation Copyright
12
: start up single photo shooting
8. Long video capture button
: Start long video capture and the button turns red, then the time shows on the left side of the button.
Press the button again to end the video capture, and the button returns to white.
9. Short video capture button
: Click the button to start short video capture and it takes 20 seconds. Click the button again before
ending record, the record can be canceled. The video will be automatically stored to local album for sharing
at any time.
10. Snorkeling throttle push rod
: Click on the middle dot, slide up and down to make the machine float or dive in the water.
11. Expand/Hide Menu Bar
: Expand the secondary menu bar, including help interface, playback, VR mode, settings. Click the
button again to hide the menu bar.
12. Help interface
: Click help icon to display the function definition of each button.
13. Album preview
: Preview all videos and photos taken by the machine, you can choose to download the file to the local
file or delete the selected file.
14. VR mode
: Choose VR mode, the interface will be divided into two screens, which are put directly into the VR
glasses for use.
15. Setting
: Provides related auxiliary settings, including depth calibration, video definition selection, version
number, etc.
16. Directional control panel
: The directional control panel provides 360° omnidirectional control and the machine can move in any
horizontal direction.
17. Speed switch button
: By sliding up and down on this button, you can change the basic speed level and this can be reflected
through the direction control panel.
18. Handheld compass direction
: Real-time display of the current specific direction of the phone/tablet
19. The direction of the machine in the water
: You can see the direction of the machine under water in real time.

Aquarobotman Innovation Copyright
13
Setting Interface
1. Sensor calibration
Horizontal calibration. Place the underwater drone in the air or on the water surface, click the depth
calibration button, and it takes about 2S.
Compass calibration. After clicking on the compass calibration button, rotate the machine 360° until the
calibration is completed, and it takes about 30S.
2. Shooting setting
Video resolution information and properties of captured photos can be set. More professional shooting
settings and functions can be provided including video resolution, picture pixels, picture quality, video
quality, continuous shooting mode, time-lapse shooting, video watermarking.
Calibration interface Shooting parameter
3. Status information
View the firmware version information of the current underwater drone in real time. It also shows the
internal humidity of the machine, which is used to detect the risk of water in the machine.
4. About us
Visit the Aquarobotman website for more information.
Status information About us
VR Interface
Split screen display video interface applied with VR box. In this mode, somatosensory operation function
enables user to watch the underwater scene wearing VR glasses. The head posture is converted into a
real-time view of the machine, bringing stronger immersive experience.

Aquarobotman Innovation Copyright
14
Help Interface
Main interface button illustration.
Preview Interface
Show all taken photos and videos, download or delete files, which enables users to view taken photos and
videos.
Handle Introduction
The handle connects to the APP via Bluetooth, and the APP receives the connection of the Bluetooth
handle. After connecting, direct control and shoot can be operated on the handle.

Aquarobotman Innovation Copyright
15
Operation Guide
Detailed instructions for installation and use
Installation
1. Connect the hosting machine
a) Connect the wheel signal cable connector to the rear of the machine
b) Install the battery into the battery jar of the hosting machine, gently press the battery and turn the
butterfly knob clockwise to tighten the battery
APP Application
1. Connect APP
a) Connect the WIFI Aquarobotman
b) The interface of the APP successful connection is as shown below

Aquarobotman Innovation Copyright
16
2. Operation
Function
Diagram
Locked
The icon in the upper left corner
is gray, which shows it is locked
and the main thruster does not
rotate
Unlocked
The icon in the upper left corner
is yellow, which shows it is
unlocked and the hosting
machine enters normal running
state

Aquarobotman Innovation Copyright
17
Function
Diagram
Lighting Adjustment
Slide the middle to adjust the
brightness of the fill light
Speed Adjustment
Adjust the speed of horizontal
movement while using direction
control
Horizontal Control
Control the horizontal movement
of the machine
Snorkeling Control

Aquarobotman Innovation Copyright
18
Function
Diagram
Control the machine to float and
dive
Snorkeling Control
Simultaneous operation of the
horizontal direction and
snorkeling throttle, while
changing the pitch angle. The
maximum angle of the pitch angle
can reach 90°.
Shooting
The button will flash red and the
interface will flash once, when
taking a photo,
Long video capture

Aquarobotman Innovation Copyright
19
Function
Diagram
Start shooting long videos and
the hosting machine will record
video
Short video capture
20 seconds video capture
3. Photo album management
Function
Diagram
Photo album preview
Check and manage taken photos and
videos
Download

Aquarobotman Innovation Copyright
20
Select a video or image to download and
share on the internet
PC Software
a) PC software can download the video or photo file taken by the hosting machine, open the
Aquatobotman.exe file on the PC side, and the interface is successfully connected.
b) Open the file list and view the basic information of the video.
c) A pop-up reminder will appear when the download is completed
d) When the video is deleted, the user will be prompted to confirm again
Sensor Calibration
Machine sensor calibration must be performed when it is first used. It can be calibrated later depending on
the needs of the user. The sensors that the machine needs to calibrate include the compass and depth.
1. Depth calibration: Place the machine in the air, click on the depth calibration and wait for completion.
2. Compass calibration: Click the compass calibration, rotate the machine space 360° until the calibration is
completed. The APP operation is as shown below.
