Aquila AT01 User manual

MAINTENANCE MANUAL
AQUILA AT01
A
Revision
Number
Revision
Number
Date of
Revision
Date of
Revision
Date
Inserted
Date
Inserted
By By
RECORD OF REVISIONS
Record of Revisions
1 01.10.01
2 29.10.01
3 05.11.01
4 07.11.01
5 26.11.01
6 01.03.02
7 15.03.02
8 22.03.02
9 14.05.02
10 18.05.02
11 08.07.02
12 26.04.05
13 28.10.05
14 18.01.06
15 30.04.08
16 15.09.09
17 02.03.10
18 21.06.10
19 25.11.10
20 24.02.11
21 05.11.12
22 19.03.13
23 19.07.13
24 15.08.13
25 30.10.13
26 02.03.15
27 21.07.15
28 28.08.15
29 29.02.16
30 10.06.16
31 09.10.18
32 16.09.19

MAINTENANCE MANUAL
AQUILA AT01
A

MAINTENANCE MANUAL
AQUILA AT01
A
Temp. Revision
Number
Page Date of
Revision By By
Date
Removed
RECORD OF TEMPORARY REVISIONS
Record of Temp. Revisions
01 05-20-00 p.4 24.01.13 19.03.13
02 05-10-00 p.1 & 2 11.06.14 28.08.15
03 05-20-00 p.7 14.08.14 28.08.15
76-10-00 p.203
& 204
04 12-14-00 p.301 27.04.15
& 302
75-10-00 p.201
79-20-00 p.201

MAINTENANCE MANUAL
AQUILA AT01
A

MAINTENANCE MANUAL
AQUILA AT01
A
Revision
Number
Revision
Number
Date of
Revision
Date of
Revision
HIGHLIGHTS OF REVISIONS
Highlights of Revisions
Reason for Revision Reason for Revision
25 30.10.13 FAA validation:
description/maintenance
of electrical system,
avionics and structures
revised; airworthiness
limitations;
26 02.03.15 Life time limit,
6000 hour inspection
27 21.07.15 “Fuel” revision;
fuel indicating system
calibration procedures
28 28.08.15 TBO’s and maintenance
checklist revised; Temp.
rev. 2 & 3 incorporated
29 29.02.16 Control surface ply
lay-up added; repair
procedures revised
30 10.06.16 6000h check & TBOs
added; battery check
procedure added
31 09.10.18 Rotax: new spark plugs
32 16.09.19 TBO’s and maintenance
checklist revised

MAINTENANCE MANUAL
AQUILA AT01
A

MAINTENANCE MANUAL
AQUILA AT01
A
LIST OF EFFECTIVE CHAPTERS
LIST OF EFFECTIVE CHAPTERS
Chapter Title Date*
GENERAL
Table of Contents 10.06.16
Introduction 30.10.13
04 Airworthiness Limitations 02.03.15
05 Time Limits / Maintenance Checks 16.09.19
06 Dimensions and Areas 26.04.05
07 Lifting & Shoring 30.10.13
08 Leveling and Weighing 27.09.01
09 Towing and Taxiing 02.03.10
10 Parking, Mooring, Storage & Return to Service 02.03.10
11 Placards and Markings 05.11.12
12 Servicing 30.10.13
AIRFRAME SYSTEMS
20 Standard Practices Airframe 09.10.18
21 Ventilation and Heating 08.07.02
23 Communications 30.10.13
24 Electrical Power 10.06.16
25 Equipment and Furnishings 30.10.13
27 Flight Controls 30.10.13
28 Fuel 21.07.15
31 Indicating/Recording Systems 30.10.13
32 Landing Gear 15.03.02
33 Lights 30.10.13
34 Navigation 30.10.13
STRUCTURES
51 Structures 29.02.16
52 Doors 30.10.13
53 Fuselage 30.10.13
55 Stabilizers 14.05.02
56 Windows 19.07.13
57 Wings 18.01.06
PROPELLER
61 Propeller 19.03.13
List of Chapters
16.09.19
Page 1

MAINTENANCE MANUAL
AQUILA AT01
A
LIST OF EFFECTIVE CHAPTERS
POWER PLANT
71 Power Plant 26.04.05
74 Ignition 09.10.18
75 Cooling System 26.04.05
76 Engine Controls 28.08.15
77 Engine Indicating 26.11.01
78 Exhaust 07.11.01
79 Oil 07.11.01
80 Starting 05.11.01
91 Charts and Wiring Diagrams 30.04.08
* The date refers to the issue / revision date of the respective chapter.
LIST OF EFFECTIVE CHAPTERS
Chapter Title Date*
List of Chapters
16.09.19
Page 2
The technical content of this document (revision 32) is approved under the authority of
DOA ref. EASA.21J.025.
Date, Signature Office of Airworthiness

MAINTENANCE MANUAL
AQUILA AT01
A
CHAPTER 5
TIME LIMITS / MAINTENANCE CHECKS

MAINTENANCE MANUAL
AQUILA AT01
A

MAINTENANCE MANUAL
AQUILA AT01
A
05 - TOC Page 1
Maintenance Checks
TABLE OF CONTENTS
Chapter
Section
Title Subject Page
TIME LIMITS / MAINTENANCE CHECKS - GENERAL ...........................05-00-00 1
Introduction 05-00-00 1
General Description 05-00-00 1
COMPONENT TIME LIMITS .........................................................................05-10-00 1
General 05-10-00 1
Component Time Limits 05-10-00 1
SCHEDULED MAINTENANCE CHECKS....................................................05-20-00 1
General 05-20-00 1
Inspection Time Intervals Chart 05-20-00 1
6000-Hour Inspection 05-20-00 17
DAILY INSPECTIONS......................................................................................05-30-00 1
General 05-30-00 1
Pre-Flight Check 05-30-00 1
Post-Flight Check 05-30-00 1
UNSCHEDULED MAINTENANCE CHECKS .............................................05-50-00 1
General 05-50-00 1
Special Checks 05-50-00 1
16.09.19

MAINTENANCE MANUAL
AQUILA AT01
A

MAINTENANCE MANUAL
AQUILA AT01
A
05-00-00
Maintenance Checks
TIME LIMITS / MAINTENANCE CHECKS - GENERAL
1. Introduction
A. This chapter provides scheduled and unscheduled maintenance checks and inspections,
recommended by the type certificate holder as well as the time limits for service life limited
components and parts.
2. General Description
In the following, a brief description and intended purpose of each section of this chapter is given.
A. Section 05-00-00 - Time limits / Maintenance Checks - General. This section provides a general
overview of the content and purpose of this chapter.
B. Section 05-10-00 – Component Time Limits. This section contains the time limits of all service life
limited components and parts and recommended time between overhaul (TBO) for components.
C. Section 05-20-00 - Scheduled Maintenance Checks. This section contains information about
recommended scheduled maintenance and inspections. The recommended maintenance and
inspection program for the systems and components as well as the relevant intervals are
embodied in a checklist included in this section.
D. Section 05-30-00 - Daily Inspections. In this section pre-flight and post-flight checks are described,
that have to be carried out every day the aircraft is in operation.
E. Section 05-50-00 - Unscheduled Maintenance Checks. This section specifies checks, which have to
be conducted after unusual events and incidences such as hard landings.
16.09.19
Page 1

MAINTENANCE MANUAL
AQUILA AT01
A

MAINTENANCE MANUAL
AQUILA AT01
A
COMPONENT TIME LIMITS
1. General
A. Different components and parts of the aircraft are certified for specific service life. When reaching
this time limit, the respective item must be replaced or overhauled.
In order to monitor permissible service life the installation or removal of each item must be
recorded in the aircraft logbook.
Where an interval is given in both flight time and calendar time, the limit which is reached first
must be applied.
2. Component Time Limits
A. Under certain circumstances the replacement or overhaul of components may be required before
the time limits listed below are reached.
B. Replacement time limits, recommended by the type certificate holder:
Chapter Component / Part Replacement Time Overhaul
24 Ignition lock 6000 h no
24 Starter relais 2000 h no
27 Elevator control rods 6000 h no
incl. rod ends
27 Rudder control cables 6000 h no
27 Control surface 6000 h no
plain bearing bushings
28 Electrical fuel pump 3000 h or 10 years no
32 Nose landing gear spring 5 years no
package rubber elements
32 Main landing gear struts no 6000 h
32 Flexible hoses 10 years no
of the brake system
55 Lower rudder hinge bracket 6000 h no
57 Wing attachment bolts 6000 h no
71 Flexible teflon hoses 2000 h or 15 years no
1)
of the oil / fuel system
05-10-00
Maintenance Checks
16.09.19
Page 1
1) Hoses that are not covered by the engine type certificate (TC).

MAINTENANCE MANUAL
AQUILA AT01
A
05-10-00 Page 2
16.09.19
Maintenance Checks
C. Vendor Established Component Time Limits
Chapter Component / Part Replacement Time Overhaul
25 ELT battery Note 1 no
25 Fire extinguisher 10 years Note 4
Air Total
25 Fire extinguisher 12 years no
H3R
31 ASPEN internal battery 800 h or 3 years no
34 KMD 150 MFD/GPS 10 years no
internal battery (recommended)
34 WINTER instruments no Note 5
61 Propeller no 2000 h or 6 years
MTV-21-A/175-05 Note 2
61 Propeller governor no 6 years, with engine
Woodward A210786 Note 6
61 Propeller governor no 2000 h or 6 years
P-410-13 Note 2
61 Propeller governor no 2000 h or 6 years
P-850-12 Note 2
71 Engine ROTAX 912S no 2000 h or 15 years,
1500 h or 12 years,
1200 h or 10 years
Note 3
71 Flexible hoses of the 5 years no
cooling system
71 AQUILA engine mount 6000 h no
and attaching bolts
71 Engine shock with engine no
mounts overhaul
76 Engine / propeller control 2000 h no
Bowden cable wires
Chapter Component / Part Replacement Time Overhaul

MAINTENANCE MANUAL
AQUILA AT01
A
05-10-00 Page 3
71 ROTAX mechanical 5 years no
fuel pump Note 3
71 ROTAX flexible teflon with engine overhaul no
hoses of the fuel system Note 3
71 ROTAX rubber parts 5 years no
of the engine Note 3
(V-belt, hoses,
carburetor parts)
71 Spark plugs 200 h no
Note 3
NOTES:
Note 1: Refer to manufacturer instructions for battery replacement time limits.
Note 2: Refer to latest issue of the mt-propeller Service Bulletin No. 1.-( ), and to the
mt-Propeller E-124 Operation and Installation Manual.
Note 3: Refer to the latest issues of BRP-Rotax, i.e. Service Bulletins, Service Information and
to the ROTAX Aircraft Engines Maintenance Manual for ROTAX Engine Type 912
Series.
Note 4: Refer to manufacturer instruction for overhauling.
Note 5: Though there is no TBO for these instruments, the manufacturer Gebr. Winter GmbH
& Co. KG recommends that airspeed indicators and altimeters are subjected to
retesting after 5 years.
Note 6: The 6 year calendar time limit applies for units not in continuous service with a
minimum of 120 hours per year. Refer to the latest issue of the Woodward Service
Bulletin S/B-33580-M.
16.09.19
Maintenance Checks

MAINTENANCE MANUAL
AQUILA AT01
AMaintenance Checks

MAINTENANCE MANUAL
AQUILA AT01
A
05-20-00
SCHEDULED MAINTENANCE CHECKS
1. General
A. The inspection time intervals chart contained in this chapter shows the recommended intervals at
which maintenance and maintenance checks should be carried out on the aircraft.
Annual inspections and 100 hour inspections on the AQUILA AT01 must include all inspection
items as required by FAR 43, Appendix D, “Scope and detail of annual/100h inspections”.
Chapter 4 “Airworthiness Limitations“ of this manual defines the inspection intervals for
continued airworthiness.
B. If an aircraft is being operated under unusual environmental conditions, maintenance intervals
may be reduced.
2. Inspection Time Intervals Chart
A. The maintenance and checks listed are to be carried out at the specified intervals and documented
appropriately.
NOTE: For new aircraft and new engines the first check is carried out after 25 hours and should
be of the extent of a 100-hour inspection. For new engines only an engine ground run
and the checks listed in the “Engine” section have to be carried out.
NOTE: If more than 30% of operation hours have been flown with leaded fuel (e.g. AVGAS
100LL), an additional 50-hour inspection is necessary (refer to ROTAX Aircraft Engines
SI-912-016).
NOTE: Where an interval is given in both flight time and calendar time, the limit which is
reached first must be applied. The next interval starts with the flight time and calendar
time of the latest performed maintenance check.
B. For intervals between maintenance work, the following tolerances must not be exceeded:
Interval Tolerance
up to and including 100 h 10% of interval
>100 h up to and including 1000 h 5% of interval
>1000 h 50 h
calendar time limits 30 days
These tolerances must not me added up. For example: if the 100-hour inspection was done at
107 h, the next inspection must be done at 200±10 h, not 207 10 h.
If an inspection is carried out earlier than allowed by the specified tolerance, all subsequent
inspection intervals are counted from that inspection. For example: If the 100 h inspection was
done at 87 h, the next inspection must be done at 187±10 h.
±
Maintenance Checks
16.09.19
Page 1

MAINTENANCE MANUAL
AQUILA AT01
A
05-20-00 Page 2
Maintenance Checks
1. Check that the following documents are AT01 X
up-to-date and available upon request: Maintenance
- AT01 Maintenance Manual Manual,
- AT01 Airplane Flight Manual AT01
- Aircraft Log Book and required certificates Airplane
- Engine and Propeller Log Books Flight Manual
- Equipment List and Weight and Balance Record
- Airworthiness Directives
- Service Bulletins and Service Information
- Services Time Record
2. Airworthiness Directives - Verify all Airworthiness Directives X
have been complied with.
3. Service Letters, Service Bulletins, and Service Information - X
Verify all AQUILA GmbH and suppliers Service Letters, Service
Bulletins and Service Information have been complied with.
4. Service time records, equipment list and weight and balance X
records - Check. Update if necessary.
5. Aircraft file and technical documentation - Verify X
complete and in proper order.
No. Pre-Inspection / Engine Ground Test Reference Interval Initials
100h other
Aircraft S/N Operating Hours Registration
Number
Engine S/N Operating Hours Date
TTSN / TTSO:
Propeller S/N Operating Hours Type of
TTSN / TTSO: Inspection
16.09.19
C. Due to recent ROTAX publications the maintenance checks given for the ROTAX engine may not
be up to date. Refer to the latest revisions of ROTAX Engine Type 912 Series Maintenance Manual
and Service Bulletins.
D. Due to the multiplicity of equipment coming onto the market, no maintenance instructions are
given for electronic equipment. For information on a certain component use the documentation
provided by the manufacturer of this component.
NOTES:
E. Inspection Time Intervals Chart:
R912* Maintenance Manual for ROTAX Engine Type 912 Series
MT* mt-Propeller E-124 Operation and Installation Manual
TTSN Total Time Since New
TTSO Total Time Since Overhaul
