Aquila AT01-200 User manual

MAINTENANCE MANUAL
AQUILA AT01-100
AMAINTENANCE MANUAL
AQUILA AT01-100
A
MAINTENANCE MANUAL
AQUILA AT01-100 (A211)
AQUILA AT01-200 (A212)
Doc.-No. MM-AT01-1020-110
This document is protected by copyright. All associated rights, in particular those of translation, reprinting, reproduction
by photo mechanical or similar means and storing in data processing facilities in whole or part are reserved.
The technical content of this document is approved under the authority of the DOA ref. EASA.21J.025.
AQUILA Aviation International GmbH Phone:++49 33 731 707 - 0
Flugplatz Fax: ++49 33 731 707 - 11
14959 Schönhagen e-mail: [email protected]
AQUILA Aviation International GmbH

MAINTENANCE MANUAL
AQUILA AT01-100
AMAINTENANCE MANUAL
AQUILA AT01-100
A

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
TABLE OF CONTENTS
Cha/Sec/Sub Title Pages
TABLE OF CONTENTS 1-6
INTRODUCTION 1-8
LIST OF EFFECTIVE CHAPTERS 1-2
04 AIRWORTHINESS LIMITATIONS
04-00-00 Airworthiness Limitations - General 1-2
05 TIME LIMITS / MAINTENANCE CHECKS
05-00-00 Time Limits / Maintenance Checks - General 1
05-10-00 Component Time Limits 1-4
05-20-00 Scheduled Maintenance Checks 1-31
05-30-00 Daily Inspections 1
05-50-00 Unscheduled Maintenance Checks 1-2
06 DIMENSIONS AND AREAS
06-00-00 Dimensions and Areas - General 1
06-10-00 Aircraft Dimensions and Areas 1-3
06-20-00 Aircraft Zoning 1-2
06-30-00 Access/Inspection Plates 1-2
07 LIFTING AND SHORING
07-00-00 Lifting and Shoring - General 1
07-10-00 Jacking 201-202
08 LEVELING AND WEIGHING
08-00-00 Leveling and Weighing - General 1
08-10-00 Weighing 201-203
08-20-00 Leveling 201-202
09 TOWING AND TAXIING
09-00-00 Towing and Taxiing - General 1
09-10-00 Towing 201
09-20-00 Taxiing 201
10 PARKING, MOORING, STORAGE AND RETURN TO SERVICE
10-00-00 Parking, Mooring, Storage and Return to Service - General 1
10-10-00 Parking 201
10-11-00 Storage 201
10-20-00 Mooring 201
10-30-00 Return to Service 201
10-40-00 Transport 201-202
TOC Page 1
Table of Contents
28.02.20

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
11 PLACARDS AND MARKINGS
11-00-00 Placards and Markings - General 1
11-20-00 Exterior Placards and Markings 201-207
11-30-00 Interior Placards and Markings 201-207
12 SERVICING
12-00-00 Servicing - General 1
12-10-00 Replenishing - Description 1-2
12-11-00 Fuel - Servicing 301-302
12-12-00 Engine Oil - Servicing 301-302
12-13-00 Induction Air Filter - Servicing 301
12-14-00 Cooling System - Servicing 301-302
12-15-00 Brake System - Servicing 301
12-16-00 Tires - Servicing 301
12-17-00 Battery - Servicing 301
12-20-00 Scheduled Servicing - Description 1
12-21-00 Lubricants - Description 1-2
12-22-00 Lubrication - Servicing 301-303
12-23-00 Aircraft Exterior - Cleaning and Care 701-704
12-24-00 Aircraft Interior - Cleaning and Care 701-702
12-30-00 Unscheduled Servicing 301
20 STANDARD PRACTICES AIRFRAME
20-00-00 Standard Practices Airframe - General 1
20-10-00 Fastener Identification and Torque Data 1-4
20-11-00 Conversion Data 1-3
21 VENTILATION AND HEATING
21-00-00 Ventilation and Heating - General 1
21-20-00 Fresh Air Distribution - Maintenance 201-203
21-40-00 Heating - Maintenance 201
23 COMMUNICATIONS
23-00-00 Communications - General 1 1)
23-10-00 Speech Communications - Description 1-2/2 1)
23-10-00 Speech Communications - Maintenance 201-202/2021)
23-50-00 Audio Integrating - Maintenance 201-202/202
24 ELECTRICAL POWER
24-00-00 Electrical Power - General 1
24-00-00 Electrical Power - Troubleshooting 101-102
1)
24-20-00 Alternator System - Description 1-3/3 1)
24-20-00 Alternator System - Maintenance 201-204/205
24-30-00 Main Battery System - Description 1-2
TOC Page 2
Table of Contents
28.02.20
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
24-30-00 Main Battery System - Maintenance 201-203
24-40-00 External Power - Maintenance 201-203
24-60-00 Electrical Load Distribution - Description 1
24-61-00 Circuit Breaker - Maintenance 201-203
24-97-00 Electrical System Wiring - Maintenance 201
25 EQUIPMENT / FURNISHINGS
25-00-00 Equipment / Furnishings - General 1
25-10-00 Seats - Maintenance 201-203
25-11-00 Restraint System - Maintenance 201
25-12-00 Cabin Interior - Maintenance 201-203
25-50-00 Cargo Tie Downs - Maintenance 201
25-60-00 Emergency Equipment - Description 1-2
25-62-00 Emergency Locater Transmitter - Maintenance 201-202 1)
25-66-00 Fire Extinguisher - Maintenance 201/201-202
27 FLIGHT CONTROLS
27-00-00 Flight Controls - General 1
27-10-00 Aileron Control System - Description 1-2
27-10-00 Aileron Control System - Maintenance 201-207
27-20-00 Rudder Control System - Description 1-2
27-20-00 Rudder Control System - Maintenance 201-205
27-30-00 Elevator Control System - Description 1-2
27-30-00 Elevator Control System - Maintenance Practices 201-205
27-31-00 Elevator Trim Control System - Description 1-2
27-31-00 Elevator Trim Control System - Maintenance 201-202
27-50-00 Flap Control System - Description 1-2
27-50-00 Flap Control System - Maintenance 201-205
28 FUEL 1)
28-00-00 Fuel - General 1-2/2
28-10-00 Fuel Storage - Maintenance 201
28-20-00 Fuel Distribution - Maintenance 201-207 1)
28-41-00 Fuel Quantity Indication - Maintenance 201-203/203
28-44-00 Fuel Pressure Indication - Maintenance 201
28-45-00 Fuel Flow Indication - Maintenance 201-202
31 INDICATING / RECORDING SYSTEMS 1)
31-00 00 Indicating / Recording Systems - General 1-2/2/2
31-10-00 Instrument Panel - Maintenance 201-202
32 LANDING GEAR
32-00-00 Landing Gear - General 1
32-10-00 Main Landing Gear - Description 1
TOC Page 3
Table of Contents
28.02.20
1) Depending on effectivity. 1) Depending on effectivity.

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
11 PLACARDS AND MARKINGS
11-00-00 Placards and Markings - General 1
11-20-00 Exterior Placards and Markings 201-207
11-30-00 Interior Placards and Markings 201-207
12 SERVICING
12-00-00 Servicing - General 1
12-10-00 Replenishing - Description 1-2
12-11-00 Fuel - Servicing 301-302
12-12-00 Engine Oil - Servicing 301-302
12-13-00 Induction Air Filter - Servicing 301
12-14-00 Cooling System - Servicing 301-302
12-15-00 Brake System - Servicing 301
12-16-00 Tires - Servicing 301
12-17-00 Battery - Servicing 301
12-20-00 Scheduled Servicing - Description 1
12-21-00 Lubricants - Description 1-2
12-22-00 Lubrication - Servicing 301-303
12-23-00 Aircraft Exterior - Cleaning and Care 701-704
12-24-00 Aircraft Interior - Cleaning and Care 701-702
12-30-00 Unscheduled Servicing 301
20 STANDARD PRACTICES AIRFRAME
20-00-00 Standard Practices Airframe - General 1
20-10-00 Fastener Identification and Torque Data 1-4
20-11-00 Conversion Data 1-3
21 VENTILATION AND HEATING
21-00-00 Ventilation and Heating - General 1
21-20-00 Fresh Air Distribution - Maintenance 201-203
21-40-00 Heating - Maintenance 201
23 COMMUNICATIONS
23-00-00 Communications - General 1 1)
23-10-00 Speech Communications - Description 1-2/2 1)
23-10-00 Speech Communications - Maintenance 201-202/2021)
23-50-00 Audio Integrating - Maintenance 201-202/202
24 ELECTRICAL POWER
24-00-00 Electrical Power - General 1
24-00-00 Electrical Power - Troubleshooting 101-102
1)
24-20-00 Alternator System - Description 1-3/3 1)
24-20-00 Alternator System - Maintenance 201-204/205
24-30-00 Main Battery System - Description 1-2
TOC Page 2
Table of Contents
28.02.20
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
24-30-00 Main Battery System - Maintenance 201-203
24-40-00 External Power - Maintenance 201-203
24-60-00 Electrical Load Distribution - Description 1
24-61-00 Circuit Breaker - Maintenance 201-203
24-97-00 Electrical System Wiring - Maintenance 201
25 EQUIPMENT / FURNISHINGS
25-00-00 Equipment / Furnishings - General 1
25-10-00 Seats - Maintenance 201-203
25-11-00 Restraint System - Maintenance 201
25-12-00 Cabin Interior - Maintenance 201-203
25-50-00 Cargo Tie Downs - Maintenance 201
25-60-00 Emergency Equipment - Description 1-2
25-62-00 Emergency Locater Transmitter - Maintenance 201-202 1)
25-66-00 Fire Extinguisher - Maintenance 201/201-202
27 FLIGHT CONTROLS
27-00-00 Flight Controls - General 1
27-10-00 Aileron Control System - Description 1-2
27-10-00 Aileron Control System - Maintenance 201-207
27-20-00 Rudder Control System - Description 1-2
27-20-00 Rudder Control System - Maintenance 201-205
27-30-00 Elevator Control System - Description 1-2
27-30-00 Elevator Control System - Maintenance Practices 201-205
27-31-00 Elevator Trim Control System - Description 1-2
27-31-00 Elevator Trim Control System - Maintenance 201-202
27-50-00 Flap Control System - Description 1-2
27-50-00 Flap Control System - Maintenance 201-205
28 FUEL 1)
28-00-00 Fuel - General 1-2/2
28-10-00 Fuel Storage - Maintenance 201
28-20-00 Fuel Distribution - Maintenance 201-207 1)
28-41-00 Fuel Quantity Indication - Maintenance 201-203/203
28-44-00 Fuel Pressure Indication - Maintenance 201
28-45-00 Fuel Flow Indication - Maintenance 201-202
31 INDICATING / RECORDING SYSTEMS 1)
31-00 00 Indicating / Recording Systems - General 1-2/2/2
31-10-00 Instrument Panel - Maintenance 201-202
32 LANDING GEAR
32-00-00 Landing Gear - General 1
32-10-00 Main Landing Gear - Description 1
TOC Page 3
Table of Contents
28.02.20
1) Depending on effectivity. 1) Depending on effectivity.

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
32-10-00 Main Landing Gear - Maintenance 201-202
32-20-00 Nose Landing Gear - Description 1
32-20-00 Nose Landing Gear - Maintenance 201-204
1)
32-40-00 Wheels and Brakes - Description 1/1 1)
32-40-00 Wheels and Brakes - Maintenance 201-223/208
33 LIGHTS
33-00-00 Lights - General 1
33-10-00 Interior Lights - Maintenance 201-202
33-40-00 Exterior Lights - Maintenance 201-202
34 NAVIGATION
34-00-00 Navigation - General 1
34-11-00 Pitot / Static System - Description 1-2
34-11-00 Pitot / Static System - Maintenance 201-204
34-18-00 Stall Warning System - Description 1
34-18-00 Stall Warning System - Maintenance 201
34-20-00 Attitude and Direction - Maintenance 201-203 1)
34-25-00 Integrated Flight System - Maintenance 201-204/2021)
34-40-00 Independent Position Determining - Maintenance 201-201/204
34-50-00 Dependent Position Determining - Maintenance 201-203
51 STRUCTURES
51-00-00 Structures - General 1-2
51-10-00 Composite Damage Investigation 201-203
51-20-00 Composite Repair 201-223
52 DOORS
52-00-00 Doors - General 1
52-10-00 Canopy - Maintenance 201-204
52-30-00 Baggage Door - Maintenance 201
53 FUSELAGE
53-00-00 Fuselage - General 1
53-10-00 Fuselage Main Frame - Description 1-4
53-10-00 Fuselage Main Frame - Maintenance 201
53-20-00 Auxiliary Structure - Description 1
55 STABILIZERS
55-00-00 Stabilizers - General 1
55-10-00 Horizontal Stabilizer - Maintenance 201
55-20-00 Elevator - Maintenance 201-203
55-30-00 Vertical Stabilizer - Maintenance 201
55-40-00 Rudder - Maintenance 201-202
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
TOC Page 4
Table of Contents
28.02.20
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
56 WINDOWS
56-00-00 Windows - General 1
56-10-00 Flight Compartment Windows - Maintenance 201-203
57 WINGS
57-00-00 Wings - General 1
57-00-00 Wings - Maintenance 201-206
57-50-00 Control Surfaces - Maintenance 201-207
61 PROPELLER
61-00-00 Propeller - General 1
61-00-00 Propeller - Troubleshooting 101-103
61-10-00 Propeller Assembly - Maintenance 201-204
61-20-00 Propeller Control - Maintenance 201-205
71 POWER PLANT 1)
71-00-00 Power Plant - General 1-2/2
71-00-00 Power Plant - Troubleshooting 101-104
71-00-00 Power Plant - Maintenance 201-202
71-10-00 Cowling - Maintenance 201-202
71-20-00 Engine Mount - Maintenance 201 1)
71-60-00 Air Induction System - Maintenance 201/201
74 IGNITION SYSTEM
74-00-00 Ignition System - General 1-2
74-00-00 Ignition System - Maintenance 201-203
75 COOLING SYSTEM
75-00-00 Cooling System - General 1-2 1)
75-00-00 Cooling System - Maintenance 201-203/203
76 ENGINE CONTROLS
76-00-00 Engine Controls - General 1-2
76-00-00 Engine Controls - Maintenance 201-208
77 ENGINE INDICATING
77-00-00 Engine Indicating - General 1 1)
77-10-00 Power Indication - Maintenance 201/201 1)
77-20-00 Temperature Indication - Maintenance 201-202/202
77-40-00 Engine Monitoring System - Maintenance 201-202
78 EXHAUST
78-00-00 Exhaust System - General 1 1)
78-00-00 Exhaust System - Maintenance 201-204/203
TOC Page 5
Table of Contents
28.02.20
1) Depending on effectivity. 1) Depending on effectivity.

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
32-10-00 Main Landing Gear - Maintenance 201-202
32-20-00 Nose Landing Gear - Description 1
32-20-00 Nose Landing Gear - Maintenance 201-204
1)
32-40-00 Wheels and Brakes - Description 1/1 1)
32-40-00 Wheels and Brakes - Maintenance 201-223/208
33 LIGHTS
33-00-00 Lights - General 1
33-10-00 Interior Lights - Maintenance 201-202
33-40-00 Exterior Lights - Maintenance 201-202
34 NAVIGATION
34-00-00 Navigation - General 1
34-11-00 Pitot / Static System - Description 1-2
34-11-00 Pitot / Static System - Maintenance 201-204
34-18-00 Stall Warning System - Description 1
34-18-00 Stall Warning System - Maintenance 201
34-20-00 Attitude and Direction - Maintenance 201-203 1)
34-25-00 Integrated Flight System - Maintenance 201-204/2021)
34-40-00 Independent Position Determining - Maintenance 201-201/204
34-50-00 Dependent Position Determining - Maintenance 201-203
51 STRUCTURES
51-00-00 Structures - General 1-2
51-10-00 Composite Damage Investigation 201-203
51-20-00 Composite Repair 201-223
52 DOORS
52-00-00 Doors - General 1
52-10-00 Canopy - Maintenance 201-204
52-30-00 Baggage Door - Maintenance 201
53 FUSELAGE
53-00-00 Fuselage - General 1
53-10-00 Fuselage Main Frame - Description 1-4
53-10-00 Fuselage Main Frame - Maintenance 201
53-20-00 Auxiliary Structure - Description 1
55 STABILIZERS
55-00-00 Stabilizers - General 1
55-10-00 Horizontal Stabilizer - Maintenance 201
55-20-00 Elevator - Maintenance 201-203
55-30-00 Vertical Stabilizer - Maintenance 201
55-40-00 Rudder - Maintenance 201-202
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
TOC Page 4
Table of Contents
28.02.20
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
56 WINDOWS
56-00-00 Windows - General 1
56-10-00 Flight Compartment Windows - Maintenance 201-203
57 WINGS
57-00-00 Wings - General 1
57-00-00 Wings - Maintenance 201-206
57-50-00 Control Surfaces - Maintenance 201-207
61 PROPELLER
61-00-00 Propeller - General 1
61-00-00 Propeller - Troubleshooting 101-103
61-10-00 Propeller Assembly - Maintenance 201-204
61-20-00 Propeller Control - Maintenance 201-205
71 POWER PLANT 1)
71-00-00 Power Plant - General 1-2/2
71-00-00 Power Plant - Troubleshooting 101-104
71-00-00 Power Plant - Maintenance 201-202
71-10-00 Cowling - Maintenance 201-202
71-20-00 Engine Mount - Maintenance 201 1)
71-60-00 Air Induction System - Maintenance 201/201
74 IGNITION SYSTEM
74-00-00 Ignition System - General 1-2
74-00-00 Ignition System - Maintenance 201-203
75 COOLING SYSTEM
75-00-00 Cooling System - General 1-2 1)
75-00-00 Cooling System - Maintenance 201-203/203
76 ENGINE CONTROLS
76-00-00 Engine Controls - General 1-2
76-00-00 Engine Controls - Maintenance 201-208
77 ENGINE INDICATING
77-00-00 Engine Indicating - General 1 1)
77-10-00 Power Indication - Maintenance 201/201 1)
77-20-00 Temperature Indication - Maintenance 201-202/202
77-40-00 Engine Monitoring System - Maintenance 201-202
78 EXHAUST
78-00-00 Exhaust System - General 1 1)
78-00-00 Exhaust System - Maintenance 201-204/203
TOC Page 5
Table of Contents
28.02.20
1) Depending on effectivity. 1) Depending on effectivity.

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
TABLE OF CONTENTS (Cont.)
Cha/Sec/Sub Title Pages
79 OIL 1)
79-00-00 Oil - General 1-2/2
79-10-00 Oil Tank - Maintenance 201-202
79-20-00 Oil Cooler - Maintenance 201-202 1)
79-31-00 Oil Pressure Indication - Maintenance 201-202/201
1)
79-33-00 Oil Temperature Indication - Maintenance 201/201
80 STARTING
80-00-00 Starting - General 1
80-11-00 Starter - Maintenance 201
91 CHARTS AND DIAGRAMS
91-00-00 Charts and Diagrams - General 1-40
TOC Page 6
Table of Contents
28.02.20
1) Depending on effectivity.

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
Revision
Number
Revision
Number
Date of
Revision
Date of
Revision
Date
Inserted
Date
Inserted
By By
RECORD OF REVISIONS
Record of Revisions
A.01 30.04.13
A.02 26.08.13
A.03 24.10.13
A.04 02.03.15
A.05 20.08.15
A.06 29.02.16
A.07 10.06.16
A.08 09.10.18
A.09 28.02.20

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
Temp. Revision
Number
Page Date of
Revision By By
Date
Removed
RECORD OF TEMPORARY REVISIONS
Record of Temp. Revisions
01 05-10-00 p.1 & 3 11.06.14 20.08.15
02 05-20-00 p.7 14.08.14 20.08.15
76-00-00 p.203
& 204

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
Temp. Revision
Number
Page Date of
Revision By By
Date
Removed
RECORD OF TEMPORARY REVISIONS
Record of Temp. Revisions
01 05-10-00 p.1 & 3 11.06.14 20.08.15
02 05-20-00 p.7 14.08.14 20.08.15
76-00-00 p.203
& 204

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
Revision
Number
Revision
Number
Date of
Revision
Date of
Revision
HIGHLIGHTS OF REVISIONS
Highlights of Revisions
Reason for Revision Reason for Revision
A.01 30.04.13 Initial issue.
A.02 26.08.13 SB-AT01-027
A.03 24.10.13 FAA validation
(airworthiness limitations,
wire routing diagrams);
lubrication revised;
standard torque ROTAX
engine mount revised
A.04 02.03.15 Life time limit,
6000 hour inspection
A.05 20.08.15 Fuel quantity indicating
system calibration
procedures added;
TBO’s and maintenance
checklist revised;
Temporary revisons 1
& 2 incorporated
A.06 29.02.16 Control surface ply
lay-up added; repair
procedures revised
A.07 10.06.16 6000h check & TBOs
added; battery check;
wing bolts safetying
A.08 09.10.18 Beringer: new axle
and new wheels;
Rotax: new spark plugs
A.09 28.02.20 New model AT01-200

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
Revision
Number
Revision
Number
Date of
Revision
Date of
Revision
HIGHLIGHTS OF REVISIONS
Highlights of Revisions
Reason for Revision Reason for Revision
A.01 30.04.13 Initial issue.
A.02 26.08.13 SB-AT01-027
A.03 24.10.13 FAA validation
(airworthiness limitations,
wire routing diagrams);
lubrication revised;
standard torque ROTAX
engine mount revised
A.04 02.03.15 Life time limit,
6000 hour inspection
A.05 20.08.15 Fuel quantity indicating
system calibration
procedures added;
TBO’s and maintenance
checklist revised;
Temporary revisons 1
& 2 incorporated
A.06 29.02.16 Control surface ply
lay-up added; repair
procedures revised
A.07 10.06.16 6000h check & TBOs
added; battery check;
wing bolts safetying
A.08 09.10.18 Beringer: new axle
and new wheels;
Rotax: new spark plugs
A.09 28.02.20 New model AT01-200

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
INTRODUCTION
Introduction
Table 1 - List of Technical Publications
28.02.20
INTRODUCTION
1. General
This maintenance manual provides to maintenance personnel all information necessary for the
maintenance of the aircraft. It contains detailed descriptions of the systems, troubleshooting and
maintenance practices. This handbook only contains maintenance practices to be carried out on the
aircraft, e.g. removal and installation of components.
Maintenance, repairs and inspections must be accomplished in accordance with the instructions given
in this maintenance manual (MM).
2. List of Technical Publications
A. Use the MM in conjunction with the latest revisions of the technical publications listed in table 1.
NOTE: Due to the multiplicity of equipment coming onto the market the following list may be
incomplete. If there is no information given on a certain component, use the
documentation provided by the manufacturer of this component.
Page 1
1. AQUILA AT01-100A/B/C FM-AT01-1010-101/102/103 AQUILA Aviation
Airplane Flight Manual International GmbH
2. AQUILA AT01-200C FM-AT01-1010-106 AQUILA Aviation
Airplane Flight Manual International GmbH
3. AQUILA AT01-100/200 PC-AT01-1030-110 AQUILA Aviation
Illustrated Parts Catalog International GmbH
4. Maintenance Manual (Line) for MML-912 BRP-Powertrain GmbH & Co KG
ROTAX 912 Series 899191
5. Maintenance Manual (Line) for MML-914 BRP-Powertrain GmbH & Co KG
ROTAX 914 Series 899608
6. Maintenance Manual (Heavy) for MMH-912 / MMH-914 BRP-Powertrain GmbH & Co KG
ROTAX 912 and 914 Series 899603
7. Operator’s Manual for OM-912 BRP-Powertrain GmbH & Co KG
ROTAX 912 Series 899649
8. Operator’s Manual for OM-914 BRP-Powertrain GmbH & Co KG
ROTAX 914 Series 899645
9. Illustrated Parts Catalog for IPC-912 / IPC-914 BRP-Powertrain GmbH & Co KG
ROTAX 912 and 914 Series 899472
10. Hydraulically Controlled Variable Pitch Prop. E-124 MT-Propeller Entwicklung GmbH
Operation & Installation Manual
No. Title Manual No. / Part No. Supplier

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
INTRODUCTION Page 2
Introduction
28.02.20
Table 1 - List of Technical Publications (Cont.)
No. Title Manual No. / Part No. Supplier
11. Operation & Installation Manual E-1048 MT-Propeller Entwicklung GmbH
Hydraulic Constant Speed Governor P-8()()-()
12. 5.00-5” Wheels and Brakes Beringer Aero
RA-002 / RF-005 User Manual UM-ETSO-002
RA-014 / RF-018 User Manual UM-ETSO-007
13. Cleveland Wheels and Brakes AWBCMM0001 Parker Hannifin Corp.
Maintenance Manual
14. Garmin G500 PFD/MFD System Garmin International Inc.
AML STC Installation Manual 190-01102-06
Instructions for Continued Airworthiness 190-01102-00
15. Garmin G500/G600 TXi Garmin International Inc.
Part 23 AML STC Maintenance Manual
16. EFD1000 and EFD500 Aspen Avionics Inc.
Installation Manual 900-00003-001
Instructions for Continued Airworthiness 900-00012-001
17. Garmin GMA 340 Audio Panel Garmin International Inc.
Installation Manual 190-00149-01
Pilot’s Guide 190-00149-10
18. Garmin GMA 350/350H Garmin International Inc.
Installation Manual 190-01134-11
Pilot’s Guide 190-01134-12
19. Garmin GTX 328 Transponder 190-00420-04 Garmin International Inc.
Installation Manual
20. Garmin GTX 330 Transponder 190-00207-02 Garmin International Inc.
Installation Manual
21. Garmin 400W Series 190-00356-02 Garmin International Inc.
Installation Manual
22. Garmin GTN 6xx/7xx 190-01007 Garmin International Inc.
AML STC Installation Manual
23. Flymap L 500-301 Stauff Systec GmbH
Installation Manual
24. Model SL30 NAV/COMM Garmin AT Inc.
Installation Manual 560-0404-03
Pilot’s Guide 560-0403-01
25. Model SL40 VHF COMM Garmin AT Inc.
Installation Manual 560-0956-03
Pilot’s Guide 560-0954-02
26. Kannad 406 AF Compact DOC 08038 Kannad Aviation Enquiries
Installation Manual / Operation Manual Ref. 0145599 Orolia SAS
Part 23 AML STC Installation Manual 190-01717-B3
190-01717-B1
INTRODUCTION
Page 3
Introduction
28.02.20
Table 1 - List of Technical Publications (Cont.)
No. Title Manual No. / Part No. Supplier
27. Kannad AF Integra DOC 09078 Kannad Aviation Enquiries
Operation Manual Ref. 0146257 Orolia SAS
28. VT-01 Transponder 01.0200.11E Garrecht Avionik GmbH
Installation Manual
29. VT-02 Transponder 02.0200.11E Garrecht Avionik GmbH
Installation Manual
30. Glass Panel Engine Monitor MVP-50P-AQ Electronics International Inc.
Operating Instructions OI 06031301
Component Replacement Considerations 06201301
31. Acceptable Methods, Techniques and AC 43.13-1B Federal Aviation Administration
Practices - Aircraft Inspection and Repair (FAA)
32. Garmin GTR 225 / GNC 255 190-01182-02 Garmin International Inc.
TSO Installation Manual
33. Garmin GTR 225/225A/225B 190-01182-00 Garmin International Inc.
Pilot’s Guide
34. Garmin GNC 255A/255B 190-01182-01 Garmin International Inc.
Pilot’s Guide
35. Restraint Systems Model 1-10-() CMM 25-22-13 Schroth Safety Products GmbH
Component Maintenance Manual
36. Garmin G5 Garmin International Inc.
Pilot's Guide 190-01112-12
Part 23 AML STC Maintenance Manual 190-01112-11
37. Garmin G3X Touch Garmin International Inc.
Pilot's Guide 190-02472-00
Part 23 AML STC Maintenance Manual 190-02472-02
38. Sandia SAI-340 306181-00 Sandia Aerospace Inc.
Installation Manual
39. Bendix King KI 300 Electronic Attitude 89000004-101 Bendix King
Indicator Installation Manual Honeywell International Inc.
40. Andromeda Aurora Aveo Engineering
Installation Manual
41. Ultra Galactica AVE-WPST-54G-IM Aveo Engineering
Installation Manual
42. Parmetheus PAR-36 Plus LED Landing Light 14793 Whelen Engineering Company
STC Manual
43. Garmin GFC500 Autopilot 190-02291-01 Garmin International Inc.
Part 23 AML STC Maintenance Manual
44. Garmin GTX 33X and GTX 3X5 ADS-B 190-00734-11
Maintenance Manual
Garmin International Inc.

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
INTRODUCTION Page 2
Introduction
28.02.20
Table 1 - List of Technical Publications (Cont.)
No. Title Manual No. / Part No. Supplier
11. Operation & Installation Manual E-1048 MT-Propeller Entwicklung GmbH
Hydraulic Constant Speed Governor P-8()()-()
12. 5.00-5” Wheels and Brakes Beringer Aero
RA-002 / RF-005 User Manual UM-ETSO-002
RA-014 / RF-018 User Manual UM-ETSO-007
13. Cleveland Wheels and Brakes AWBCMM0001 Parker Hannifin Corp.
Maintenance Manual
14. Garmin G500 PFD/MFD System Garmin International Inc.
AML STC Installation Manual 190-01102-06
Instructions for Continued Airworthiness 190-01102-00
15. Garmin G500/G600 TXi Garmin International Inc.
Part 23 AML STC Maintenance Manual
16. EFD1000 and EFD500 Aspen Avionics Inc.
Installation Manual 900-00003-001
Instructions for Continued Airworthiness 900-00012-001
17. Garmin GMA 340 Audio Panel Garmin International Inc.
Installation Manual 190-00149-01
Pilot’s Guide 190-00149-10
18. Garmin GMA 350/350H Garmin International Inc.
Installation Manual 190-01134-11
Pilot’s Guide 190-01134-12
19. Garmin GTX 328 Transponder 190-00420-04 Garmin International Inc.
Installation Manual
20. Garmin GTX 330 Transponder 190-00207-02 Garmin International Inc.
Installation Manual
21. Garmin 400W Series 190-00356-02 Garmin International Inc.
Installation Manual
22. Garmin GTN 6xx/7xx 190-01007 Garmin International Inc.
AML STC Installation Manual
23. Flymap L 500-301 Stauff Systec GmbH
Installation Manual
24. Model SL30 NAV/COMM Garmin AT Inc.
Installation Manual 560-0404-03
Pilot’s Guide 560-0403-01
25. Model SL40 VHF COMM Garmin AT Inc.
Installation Manual 560-0956-03
Pilot’s Guide 560-0954-02
26. Kannad 406 AF Compact DOC 08038 Kannad Aviation Enquiries
Installation Manual / Operation Manual Ref. 0145599 Orolia SAS
Part 23 AML STC Installation Manual 190-01717-B3
190-01717-B1
INTRODUCTION
Page 3
Introduction
28.02.20
Table 1 - List of Technical Publications (Cont.)
No. Title Manual No. / Part No. Supplier
27. Kannad AF Integra DOC 09078 Kannad Aviation Enquiries
Operation Manual Ref. 0146257 Orolia SAS
28. VT-01 Transponder 01.0200.11E Garrecht Avionik GmbH
Installation Manual
29. VT-02 Transponder 02.0200.11E Garrecht Avionik GmbH
Installation Manual
30. Glass Panel Engine Monitor MVP-50P-AQ Electronics International Inc.
Operating Instructions OI 06031301
Component Replacement Considerations 06201301
31. Acceptable Methods, Techniques and AC 43.13-1B Federal Aviation Administration
Practices - Aircraft Inspection and Repair (FAA)
32. Garmin GTR 225 / GNC 255 190-01182-02 Garmin International Inc.
TSO Installation Manual
33. Garmin GTR 225/225A/225B 190-01182-00 Garmin International Inc.
Pilot’s Guide
34. Garmin GNC 255A/255B 190-01182-01 Garmin International Inc.
Pilot’s Guide
35. Restraint Systems Model 1-10-() CMM 25-22-13 Schroth Safety Products GmbH
Component Maintenance Manual
36. Garmin G5 Garmin International Inc.
Pilot's Guide 190-01112-12
Part 23 AML STC Maintenance Manual 190-01112-11
37. Garmin G3X Touch Garmin International Inc.
Pilot's Guide 190-02472-00
Part 23 AML STC Maintenance Manual 190-02472-02
38. Sandia SAI-340 306181-00 Sandia Aerospace Inc.
Installation Manual
39. Bendix King KI 300 Electronic Attitude 89000004-101 Bendix King
Indicator Installation Manual Honeywell International Inc.
40. Andromeda Aurora Aveo Engineering
Installation Manual
41. Ultra Galactica AVE-WPST-54G-IM Aveo Engineering
Installation Manual
42. Parmetheus PAR-36 Plus LED Landing Light 14793 Whelen Engineering Company
STC Manual
43. Garmin GFC500 Autopilot 190-02291-01 Garmin International Inc.
Part 23 AML STC Maintenance Manual
44. Garmin GTX 33X and GTX 3X5 ADS-B 190-00734-11
Maintenance Manual
Garmin International Inc.

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
3. Structure of the Maintenance Manual
The MM has been prepared in accordance with the Air Transport Association (ATA) Specification
Number 100 for Manufacturer’s Technical Data.
A. Classification of Subject Matter
The MM is divided into 5 major sections. Each of these sections is sub-divided into chapters.
A table of contents is provided at the beginning of each MM chapter.
(1) General Ch. 05 - 12
(2) Airframe Systems Ch. 20 - 37
(3) Structures Ch. 51 - 57
(4) Propeller Ch. 61
(5) Power Plant Ch. 71 - 80
Each chapter is identified by a separator sheet with the chapter number and the title.
B. Page Numbering System
(1) The page numbering system consists of three-element numbers separated by dashes.
The first element identifies a system:
e.g. 27 Flight Controls (a chapter)
The second element identifis a subsystem in the system:
e.g. 27-30 Elevator (a section)
If the system comprises several subsystems, further sections are added:
e.g. 27 - 31 Elevator Trim Control (a further section)
The last number permits the identification of the individual units in a system or subsystem.
However, this number is only used when detailed description of such individual units is
required.
Example
27 - 10 - 00
Chapter/ Section/ Subject/
System Subsystem Unit
(here Flight- (here
Controls) Ailerons)
:
Page 5
INTRODUCTION
Introduction
28.02.20
Page 4
INTRODUCTION
Introduction
(2) When the chapter/system element number is followed by zeros in the section/subsystem and
subject/unit element number (28-00-00), the information is applicable to the entire system.
(3) When the section/subsystem element number is followed by zeros in the subject/unit element
number (28-20-00), the information is applicable to subsystem within the system.
(4) The subject/unit element number is used to identify information applicable to units within
the subsystems.
This breakdown of the chapters provides a good overview and facilitates the exchange of
revised pages. Since most of the systems are relatively simple, the third element is used only
in the more complex systems, i.e. if it appears necessary to describe a unit or device in greater
detail.
(5) All maintenance data given in the MM is divided into specific types of information.
This facilitates work with the manual. For this purpose, page number blocks are reserved
depending on type of information.
Page 1 - 99 Description and Operation
Page 101 - 199 Troubleshooting
Page 201 - 299 Maintenance Practices
Page 301 - 399 Servicing
Page 401 - 499 Removal/Installation
Page 501 - 599 Adjustment/Test
Page 601 - 699 Inspection/Check
Page 701 - 799 Cleaning/Painting
Page 801 - 899 Repairs
Example page number:
Page 301 First page with service instructions
12 - 17 - 00
15.11.04 Publication date
Servicing Battery
(6) Figures are numbered consecutively within each topic.
Example: Fig. 201 1. Illustration for maintenance
Fig. 202 2. Illustration for maintenance etc.
C. Page Order
(1) In the front of the manual:
Title
Table of Contents
Record of Revisions
28.02.20

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
3. Structure of the Maintenance Manual
The MM has been prepared in accordance with the Air Transport Association (ATA) Specification
Number 100 for Manufacturer’s Technical Data.
A. Classification of Subject Matter
The MM is divided into 5 major sections. Each of these sections is sub-divided into chapters.
A table of contents is provided at the beginning of each MM chapter.
(1) General Ch. 05 - 12
(2) Airframe Systems Ch. 20 - 37
(3) Structures Ch. 51 - 57
(4) Propeller Ch. 61
(5) Power Plant Ch. 71 - 80
Each chapter is identified by a separator sheet with the chapter number and the title.
B. Page Numbering System
(1) The page numbering system consists of three-element numbers separated by dashes.
The first element identifies a system:
e.g. 27 Flight Controls (a chapter)
The second element identifis a subsystem in the system:
e.g. 27-30 Elevator (a section)
If the system comprises several subsystems, further sections are added:
e.g. 27 - 31 Elevator Trim Control (a further section)
The last number permits the identification of the individual units in a system or subsystem.
However, this number is only used when detailed description of such individual units is
required.
Example
27 - 10 - 00
Chapter/ Section/ Subject/
System Subsystem Unit
(here Flight- (here
Controls) Ailerons)
:
Page 5
INTRODUCTION
Introduction
28.02.20
Page 4
INTRODUCTION
Introduction
(2) When the chapter/system element number is followed by zeros in the section/subsystem and
subject/unit element number (28-00-00), the information is applicable to the entire system.
(3) When the section/subsystem element number is followed by zeros in the subject/unit element
number (28-20-00), the information is applicable to subsystem within the system.
(4) The subject/unit element number is used to identify information applicable to units within
the subsystems.
This breakdown of the chapters provides a good overview and facilitates the exchange of
revised pages. Since most of the systems are relatively simple, the third element is used only
in the more complex systems, i.e. if it appears necessary to describe a unit or device in greater
detail.
(5) All maintenance data given in the MM is divided into specific types of information.
This facilitates work with the manual. For this purpose, page number blocks are reserved
depending on type of information.
Page 1 - 99 Description and Operation
Page 101 - 199 Troubleshooting
Page 201 - 299 Maintenance Practices
Page 301 - 399 Servicing
Page 401 - 499 Removal/Installation
Page 501 - 599 Adjustment/Test
Page 601 - 699 Inspection/Check
Page 701 - 799 Cleaning/Painting
Page 801 - 899 Repairs
Example page number:
Page 301 First page with service instructions
12 - 17 - 00
15.11.04 Publication date
Servicing Battery
(6) Figures are numbered consecutively within each topic.
Example: Fig. 201 1. Illustration for maintenance
Fig. 202 2. Illustration for maintenance etc.
C. Page Order
(1) In the front of the manual:
Title
Table of Contents
Record of Revisions
28.02.20

MAINTENANCE MANUAL
AQUILA AT01-100/200
AMAINTENANCE MANUAL
AQUILA AT01-100/200
A
INTRODUCTION Page 6
Introduction
Page 7
INTRODUCTION
Introduction
Meter
Common Meter Plus PSI Desired Value (VDC) Unit under test
Pin 2 (blk) Pin 4 (red) 0 4.95 to 5.0 3010016,17,18
Pin 2 (blk) Pin 1 (wht) 0 1.70 to 2.10 3010016,17,18
Pin 2 (bik) Pin 3 (grn) 0 1.70 to 2.10 3010016,17,18
Pin 3 (grn) Pin 1 (wht) 0 -0.003 to +0.003 3010016,17,18
Pin 3 (grn) Pin 1 (wht) 10 0.031 to +0.034 3010016
Pin 3 (grn) Pin 1 (wht) 30 0.028 to +0.032 3010017
Pin 3 (grn) Pin 1 (wht) 60 0.028 to +0.032 3010018
77-40-00 Page 101
13.07.01
EFFECTIVITY
Aircraft equipped with VM 1000 Engine Management
System
effectivity block
Effectivity Block
Figure 1
Record of Temporary Revisions
Highlights of Revisions
Introduction
List of Effective Chapters
(2) Each chapter begins with:
Title
Table of Contents
D. Figures
The figures within the sections of a chapter are numbered in accordance with the appropriate
page number block. Numbering begins with one (1) and is continuous.
4. Using the Maintenance Manual
A. To obtain information about a specific system, refer to the list of effective chapters in the front of
the manual to find the corresponding chapter number.
In the table of contents of the respective chapter, one then finds more detailed information about
the arrangement of material.
28.02.20
B. Effectivity
This maintenance manual is "customized". It includes the following effectivity identification
system to show modification and/or configuration differences.
(1) The MM starts with a list of effective chapters. Each chapter is listed with date of issue or
revision.
(2) To identify the aircraft an effectivity statement (i.e. Garmin Avionics) or a six-digit numeric
indicator is shown in the effectivity column in the table of contents if applicable.
(a) The six-digit numeric indicator begins with the last three digits of the lowest assigned
number, to indicate first effectivity, and ends with the last three digits of the highest
assigned number, to indicate last effectivity, of an unbroken sequence of assigned
numbers. A hyphen is shown between the numbers. Open ended effectivity is
indicated by "999" in the last effectivity if applicable. For example: 023-999 indicates
aircraft 023 and subsequent.
(3) Effectivity Block
The system provides further direct annotation of applicability on the pages. On pages not
applicable for all aircraft, an effectivity block appears at the bottom left-hand corner.
Effectivity identification may be a six-digit numeric indicator (ref. to (2)(a)) or an effectivity
statement (refer to figure 1).
The information on that page applies only to the aircraft noted in the effectivity block.
NOTE: Pages with no effectivity block may be followed by pages with effectivity blocks
and vice versa and have identical page numbers.
C. Revisions
(1) Maintenance manual revisions, caused by variety of reasons (regulation changes, technical
changes, typographical errors, etc.), will be published regularly.
Revision notification contains a note explaining the revision along with:
- the revised manual chapters
- the reason of revision
- the affected aircraft serial numbers
(2) Should a revision be urgently required between regular updating, a temporary revision will
be issued. The relevant pages are yellow and will usually be incorporated in the next
scheduled revision of the maintenance manual.
(3) Identifying revised material
(a) Revisions and/or additions will be identified by a vertical black line (revision bar) in the
outer margin of the page opposite the text/illustration that has been changed.
(b) When technical changes result in unaltered texts slipping on to a different page, a
revision bar will be placed in the outside margin, opposite the chapter/section/subject,
page number and date of all affected pages, providing no other revision bar appears on
the page.
28.02.20
