Arada LOG Series Assembly instructions

Optional Accessory Instructions
OPTIONAL
STAND & LOG STORE
FITTING GUIDE
EN13240:2011 +A2:2004
BK 748 Rev 01 ISSUE DATE : 14/09/2020

OPTIONAL STAND & LOG STORE
FITTING INSTRUCTIONS
BK 748 Specific
Applicable Part Numbers — LOG-xxx
STAND-xxx
(NOTE : xxx—Model insignia)
Fitting Instructions :
Your stove is factory fitted with the standard foot assembly, however if it is so desired, this
can be removed and an optional stand or log store can be fitted, so that the appliance
height can be raised.
STEP 1:
To remove the factory fitted feet assembly, it is suggested that the canopy assembly be
removed to avoid damage. Carefully lower the stove onto its rear, taking care not to
damage the rear air box and tertiary air inlet cover. We recommend lowering the stove onto
the packing pallet, that it was delivered on, this can be seen below.
Page 2
WARNING : Health and Safety
Please consult health and safety guidelines for advice on handling heavy and / or
large items.
When lifting the appliance we recommend you always obtain assistance when handling.

Page 3 BK 748 Specific
STEP 2:
With the stove safely resting on its back, place a wooden bock or similar suitable object to
prevent the appliance from rocking or moving, this can be seen in the image below.
Ensure the appliance is secure before progressing onto step 3.
STEP 3:
Proceed to remove the 4 off fixings; 2 no. are located in either front corners and the
remaining screws are located either side, at the rear of the stove. Remove the factory fitted
feet assembly. Keep this item safe, for future use.
Wooden
Packing Block
OPTIONAL STAND & LOG STORE
FITTING INSTRUCTIONS
View On Base
View On Side
2 no. Front
Corner Fixings
Side Fixing
(Repeat For
Other Side)

CAUTION : Only
Hand Tighten
Fixings
Page 4
BK 748 Specific
Arada Ltd,
The Fireworks, Weycroft Avenue,
Axminster, Devon,
United Kingdom,
EX13 5HU
Technical Help : [phone]
STEP 4:
Position either the log store or stand assembly, against the appliance base. Affix the 4 off
fixing screw, that were removed in step 3. Only hand tighten these fixings, otherwise
damage to the threads may occur.
OPTIONAL STAND & LOG STORE
FITTING INSTRUCTIONS
STEP 5:
Taking care, return the appliance to the upright position. Extra caution will be needed as
the centre of gravity will have moved by fitting the new accessory.
CAUTION :
TAKE CARE
WHEN
LIFTING
UPRIGHT
