MODEL 1205D SETUP GUIDE
Unpacking
Carefully check the packing material for these accessories: GNSS antenna, standard antenna cable
assembly, and one DIN rail clip with mounting screws. Handle the GNSS antenna carefully, as it may
be damaged if dropped.
Installing GNSS Antenna
The GNSS antenna included with the clock is designed to be threaded onto a 3/4 inch diameter pipe (not
included). The optional Antenna Mounting Kit (part number: AS0044600) includes a 3/4 inch diameter pipe
nipple and makes installation easier. The antenna works best with a clear view of the sky in all directions.
GNSS Antenna
3/4 inch Pipe (not included)
Operate LED Antenna Cable
Figure 1: Antenna Mounting Example
1. Pass the antenna cable through the pipe and attach the cable to the antenna. Tighten by hand,
spinning the cable connector. DO NOT spin the antenna onto the cable or DAMAGE may occur.
2. Thread the 3/4 inch diameter pipe (not included) into the base of the antenna and snug by hand.
3. Mount the pipe to a fixture, such as our Antenna Mounting Kit.
4. Install GNSS Surge Protector or In-Line Preamplifier if needed. Reference their own instructions.
5. Connect the antenna cable to the clock.
Connecting Power Cables
• VERIFY that the voltage level is in the correct range.
• VERIFY that the polarity is as specified on the label.
• Strip the insulation 1/4 inch and DO NOT tin.
• A fuse is located to the left of each installed power inlet connector.
Connecting Signal Cables
Strip the insulation 1/4 inch and DO NOT tin.
Installing DIN Rail Clip
The Model 1205D may be mounted with a DIN rail clip that can be attached to one of three sides.
Arbiter Systems, Inc. ·1324 Vendels Circle, Suite 121 ·Paso Robles, CA 93446 ·USA ·Tel: [phone]
Fax: [phone] ·E-mail: [e-mail] ·Internet: http://www.arbiter.com PD0054500C 1

MODEL 1205D SETUP GUIDE
PORT 1
PORT 2
100 – 350 Vdc
85 – 264 Vac / 47 – 440 Hz
100VA MAX.
3.15 AT
400 Vdc
500 Vac
GND L2
DC–
L1
DC+
1205D GNSS SYNCHRONIZED CLOCK
ANTENNA
STATUS
RS–485
PROGRAMMABLE PULSE
341 2 5 6
IRIG
B
OPEN
DRAIN
ANALOG
IN
EVENT
IN
RS–232
PORT 1
RS–232
PORT 2
RELAY
GNSS
FAULT
OPERATE NORMAL LEARN
UNLOCKED ALARM
0 – 5 Vdc
PORT 3
Figure 2: 1205D Connections Figure 3: 1205D DIN Rail Mounting Clip
Figure 4: Input/Output Connector showing Locking Retention Hardware
Configuring with Web Interface
1. Connect one of the ports to the network or computer.
• NET 1 is set to the static address 192.168.0.232
• NET 2 and NET 3 are set for DHCP. Find assigned IP address:
–Press SYSTEM until view NETWORK STATUS?
–Press ENTER
–Press UP or DOWN to review the IP and MAC address of each port.
2. Use a web browser (Firefox or Chrome work best). Use the IP address of the port
(http://192.168.0.232). The UI will provide a login screen for entering the username and password.
3. The default username is admin and the default password is password.
Additional Help
The operation manual is available as a free download from www.arbiter.com or to purchase.
