Arbor Technology M1922 User manual

M1922
19” Fanless Intel®Medical Station
User's Manual
Version 1.2
2019.01
P/N: 4012192200120P

- 2 -
This page is intentionally left blank.

- i -
Revision History
Version Release
Time Description
1.0 2015.02 Initial release
1.1 2015.08 XRemove CPU i5-4422E information
XModied BIOS version information
1.2 2019.01
XFeatures and specications: Updated the regulation
compliance version information:
IEC & EN 60601-1 (Edition 3.1), IEC & EN 60601-1-2
(Edition 4th) and UL60601-1 certied
X2.1.1 Front View: Revise power LED descriptions /
volume & brightness control buttons
XAdded ‘2.2 Conneting to AC Power” section
XDeleted “Appendix B. Optional Medical Arms” section

Copyright
Copyright © 2019 ARBOR Technology Corp. All Rights Reserved.
This document contains proprietary information protected by copyright. No
part of this manual may be reproduced by any mechanical, electronic, or other
means in any form without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
About This Manual
This user’s manual provides the general information and installation
instructions for the product. The manual is meant for the experienced users
and integrators with hardware knowledge of personal computers. If you are not
sure about any description in this manual, consult your vendor before further
handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing ARBOR
products.

- iii -
Contents
Preface..........................................................................................................vi
Declaration of Conformity .....................................................................................vi
CE..................................................................................................................vi
FCC................................................................................................................vi
IEC 60601-1/EN60601-1/EN60601-1-2 ........................................................ vii
RoHS ............................................................................................................ vii
SVHC / REACH ........................................................................................... viii
Intended Use ...................................................................................................... viii
Symbol Descriptions........................................................................................... viii
Important Safety Instructions.............................................................................. viii
General Cleaning Tips ...........................................................................................x
Cleaning Tools ...............................................................................................xi
Recommended Cleaning Procedures........................................................... xii
Disposing of the Equipment................................................................................. xii
Additional Information & Technical Support ........................................................ xiii
Warranty ............................................................................................................. xiv
Chapter 1 Introduction................................................................................1
1.1 Product Highlights............................................................................................2
1.2 Package Contents ...........................................................................................3
1.3 Ordering Information........................................................................................4
1.3.1 Optional Accessories .............................................................................4
1.3.2 Optional Conguration (Congure-to-Order Service).............................4
1.4 Dimensions......................................................................................................5
1.5 Specications...................................................................................................6
Chapter 2 Getting Started...........................................................................9
2.1 Getting to Know the Computer ......................................................................10
2.1.1 Front View............................................................................................10
2.1.2 Rear Side.............................................................................................12
2.1.3 Bottom Side .........................................................................................13
2.1.4 Top Side ...............................................................................................14
2.1.5 Side View.............................................................................................14
2.2 Conneting to AC Power .................................................................................15
2.3 Periodic Cleaning & Disinfection....................................................................15
2.4 Drivers and Utilities Installation......................................................................17
2.4.1 DVD Contents......................................................................................18
2.4.2 Installing the Drivers & Utilities ............................................................19
Chapter 3 Using the Computer.................................................................23
3.1 Calibrating the Touch Screen.........................................................................24

- iv -
Contents
3.2 Touch Screen Settings...................................................................................27
3.2.1 Edge Compensation Settings ..............................................................27
3.2.2 Gesture Settings ..................................................................................28
3.3 Using the Touch Screen.................................................................................30
3.3.1 Text Input .............................................................................................31
3.4 Function Keys................................................................................................33
3.4.1 Using Function Keys............................................................................33
3.4.2 Customizing Function Keys .................................................................34
3.5 Using the Wi-Fi Feature.................................................................................36
3.6 Using the Bluetooth Feature..........................................................................38
3.6.1 Pairing/Connecting with Other Bluetooth Devices ...............................38
3.6.2 Bluetooth Device Name .......................................................................40
3.6.3 Hiding/Exposing the Computer ............................................................40
3.7 Using the Smart Card Reader .......................................................................42
3.8 Using the Camera Feature (Congure-to-Order)...........................................44
3.8.1 Taking a Picture ...................................................................................44
3.8.2 Recording a Video ...............................................................................45
3.8.3 Conguring Video Recording...............................................................45
3.9 Using the RFID&NFC Reader (Congure-to-Order)......................................46
Chapter 4 BIOS ..........................................................................................49
4.1 Accessing the BIOS Setup Utility...................................................................50
4.2 Main Setup.....................................................................................................51
4.3 Advanced Settings .........................................................................................52
4.3.1 ACPI Settings.......................................................................................53
4.3.2 CPU Conguration...............................................................................55
4.3.3 SATA Conguration..............................................................................56
4.3.4 AMT Conguration ...............................................................................58
4.3.5 USB Conguration ...............................................................................60
4.3.6 F81216 Secondary Super IO Conguration.........................................63
4.4 Chipset...........................................................................................................64
4.4.1 PCH IO Conguration ..........................................................................65
4.4.2 System Agent (SA) Conguration ........................................................66
4.5 Boot ...............................................................................................................69
4.6 Security..........................................................................................................70
4.7 Save & Exit ....................................................................................................71

- v -
Preface
Appendix .....................................................................................................73
A. Maintaining the the Battery Pack (CTOS) .......................................................74

- vi -
Preface
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
FCC
This device complies with Part 18 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference
that may cause undesired operation.
Any changes or modications not expressly approved by the guarantee of this
device could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 18 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
Preface

- vii -
Preface
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
IEC 60601-1/EN60601-1/EN60601-1-2
•This product complies with the system standard IEC 60601-1 Medical
Electrical Equipment Part 1: General Requirements for Safety. And
therefore, the product is exclusively interconnected with IEC 60601-1
certied equipment in the patient environment.
•Equipment connected to the analog or digital interfaces of the unit must
comply with the respective IEC standards (e.g. IEC 60601-1 for medical
equipment). Furthermore all congurations shall comply with the current
version of the standard for SYSTEMS IEC 60601-1-1.
•Everybody who connects additional equipment to the signal input part or
signal output part congures a medical system, and is therefore responsible
that the system complies with current version of the requirements of the
system standard IEC 60601-1-1. If in doubt, consult the technical service
department or your local representative.
RoHS
ARBOR Technology Corp. certies that all components in its products are
in compliance and conform to the European Union’s Restriction of Use
of Hazardous Substances in Electrical and Electronic Equipment (RoHS)
Directive 2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that
exceed a maximum concentration value of 0.1% by weight or for cadmium
exceed 0.01% by weight, per homogenous material. Homogenous material
is dened as a substance or mixture of substances with uniform composition
(such as solders, resins, plating, etc.). Lead-free solder is used for all
terminations (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).

- viii -
Preface
SVHC / REACH
To minimize the environmental impact and take more responsibility to the
earth we live, ARBOR hereby conrms all products comply with the restriction
of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH
--Registration, Evaluation, Authorization, and Restriction of Chemicals)
regulated by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)
Intended Use
This product is intended for use in a medical system.
Symbol Descriptions
This “CAUTION” symbol indicates that there is a danger
of injury to the user or a risk of damage to the product,
should warning notices be disregarded.
Battery Recycle (for models with battery)
This symbol of “Electrical Safety” indicates electrical
warning of specic electrical hazards.
Refer to the user manual for more information.
Important Safety Instructions
Read these safety instructions carefully:
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or
letting it fall may cause damage
3. Make sure the correct voltage is connected to the equipment.
