Quick Installation Guide
Version 1.1
ITX-i67M0
Mini-ITX Industrial Motherboard
Form Factor
Mini-ITX
CPU
Soldered onboard Intel®
Core™i7/i5/i3,Celeron®
in rPGA988 (Socket G2)
Chipset
Intel® QM67
I/O
PCIe/ SATA/ USB/ COM/
DIO/ Mini-card
LAN
1 x Intel ® 82579LM PCIe
GbE PHY w/ iAMT,
1 x Intel ® 82583V GbE
Controllers
Audio
Realtek ALC886 codec
(Line-in/ Line-out/ Mic-in)
Video
Dual Channel 18/24-bit
LVDS/ DVI-I
If you have any technical difculties, please consult the user’s manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
nd out the answer.
http://www.arbor.com.tw
E-mail: [e-mail]
♦ Technical Support
Copyright®2012 All Rights Reserved. 4041670000110P
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE

- 2 -
Ordering Information
Before you begin installing your single board, please make sure that the following
materials have been shipped:
Packing List
Recommended CPU List
i7-2710QE 2.1GHz Core™Processor
i5-2510E 2.5GHz Core™Processor
i3-2330E 2.2GHz Core™Processor
B810 1.6GHz Celeron® Processor
ITX-i67M0 Intel® Huron River rPGA988 socket embedded Mini-ITX
motherboard
CBK-10-67M0-00
Cable kit
2 x Two ports COM cables
1 x COM Flat cable
1 x USB cable
6 x ATA cables
1 x ITX-i67M0 Mini-ITX industrial motherboard
1 x Driver CD
1 x Quick Installation Guide
1 x CPU Cooler
1 x I/O Bracket
If any of the above items is damaged or missing, contact your vendor immediately.

- 3 -
The Installation Paths of CD Driver (V4.1A)
Windows XP
Driver Path
CHIPSET \CHIPSET\INTEL\INF 9.2.0.1021
NET Framework \NET Framework\NET Framework 3.5
ME \ME\AMT_INTEL_V7.0.0.1109
GRAPHICS \GRAPHICS\INTEL\Winxp_14464
LAN \ETHERNET\WIN_allos_Ver16.3
AUDIO \AUDIO\Realtek_HD\XP_2000 WDM_R261 32_64 bit
Windows 7
Driver Path
CHIPSET \CHIPSET\INTEL\INF 9.2.0.1021
ME \ME\AMT_INTEL_V7.0.0.1109
GRAPHICS \GRAPHICS\INTEL_Win7_32\2291
\GRAPHICS\INTEL_Win7_64\2291
LAN \ETHERNET\WIN_allos_Ver16.3
AUDIO \AUDIO\Realtek_HD\Vista_Win7_R261-32_64 bit

- 4 -
Specications
Form Factor Mini-ITX Industrial Motherboard
CPU Soldered onboard Intel® Core™ i7/i5/i3, Celeron® processor in
rPGA988 (Socket G2)
Chipset Intel® QM67
System Memory 2 x 204-pin DDR3 SO-DIMM sockets supporting 1066/1333 MHz
SDRAM up to 8GB
Graphics Controller Integrated Intel® HD Graphics 3000
DVI-I/ Dual Channels 18/24-bit LVDS
I/O Chip Fintek F71869ED + Fintek 81216
BIOS AMI BIOS 64Mb SPI ROM
Audio Realtek ALC886 HD Audio Codec (Line-in/ Line-out/ Mic-in)
Storage
6 x SATA ports:
2 x Serial ATA 3.0 ports with 600MB/s HDD transfer rate
4 x Serial ATA 2.0 ports with 300MB/s HDD transfer rate
Support RAID 0, 1 , 5, 10
Ethernet 1 x Intel® 82579LM PCIe GbE PHY w/ iAMT
1 x Intel® 82583V GbE controller
USB Port
12 x USB 2.0 ports:
6 ports with double stacked USB type A connector
4 ports with four stacked USB type A connector
2 ports by internal pin headers
Serial Port
6 x COM ports:
5 x RS-232 ports
1 x RS-232/422/485 selectable port w/ auto-ow control
KB/MS One 6-pin mini-DIN connector for PS/2 Keyboard & Mouse via Y-Cable
Digital I/O 16-bit programmable Digital Input/Output
Expansion Bus 1 x Mini-card slot
1 x PCIe x16 slot
Watchdog Timer 1~255 levels reset
Power Consumption 3.5A@12V (Max.) with i7-2710QE
Power Requirement DC 12V input only
Certication CE, FCC class B
Operation Temp. -20°C ~ 70°C (-4°F ~ 158°F)
Storage Temp. -20°C ~ 80°C (-4°F ~ 176°F)
Humidity 0% ~ 95% (non-condensing)
Dimension (L x W) 170 x 170 mm (6.7" x 6.7")

- 5 -
Board Dimensions
10.28
42.4
75.05
96.91
137.38
118.38
USB COM/DVI-I LAN/USB LAN/USB Line in/out/Mic
Unit: mm
USB*4
162.28
33.02
165.1
KB/MS
170
169.98
A1
A6
I1
I9
I17
I8
I16
I24
A9
C1
C2
C3C4
C5
C6
A5
11
41
14
44
5 4 3 21
25 24 23 22
35 34 33 32
A14
A13
A12
A11
A10
A2
A9
A1
B5B8
B4 B1
H7
H8
H4
H2
H6 H5
H1
H3
A14
A13
A12
A11
A10
A2
A9
A1
B5B8
B4 B1
H7H8
H4
H2
H6 H5
H1
H3
B2 B1 B81
B82 A81 A82
14
13
12
9
85
41
NO COMPONENT
NO COMPONENT
NO COMPONENT
NO COMPONENT
SG
76 5 4321 7 6 5 43217 6 5 4321
76 5 43217 6 5 4321 7 6 5 4321
1
2
9
10
1
2
9
10
9
10
1 3
1
14 4
1
1
9
1
2
13
14
8
7
2
1
1
1

- 6 -
Jumpers/ Connectors Quick Reference
Jumpers
Label Description
JPWR1 AT/ATX Power Mode Selection
JBAT1 CMOS Keep Up Selection
JRS1 COM2 RS-232 / 422 / 485 Selection
CON1 COM2/3 Power Source Select on Pin 9
JME1 ME Function Select
Connectors
Label Description
JSPI1 SPI Flash for External SPI Programming Tools
USB1 4 x USB Port Connector
USB2 USB Port Connector
LVDS1 LVDS Connector
MC1 PCI Express Mini-Card Slot
INV1 LVDS Inverter Connector
LPC1 Low Pin Count Connector
AUDIO1 Audio Interface Port
LAN1, 2 Ethernet Connectors (include USB0/1/2/3 Connector)
DVI1 COM1 (only supports RS-232) & DVI-I (29 PIN)
COM2 RS-232 / 422 / 485 Connector
COM3~6 Serial Port Connectors (only support RS-232)
DIO1 Digital IO Connector
12VIN1 ATX12V Connector
FAN1, 2 Fan Connectors
JFRT1 Switches and Indicators
SATA1~6 Serial ATA Connectors
PWROUT1 SATA Power Connector

- 7 -
Jumpers & Connectors Location
SATA1
SATA2
SATA3
SATA4
SATA5
SATA6
JPWR1
JBAT1
USB2
INV1
AUDIO1LAN2LAN1USB1
DVI1
COM1
KBUSB1
DIO1
JRS1
COM2
COM3
COM4
CON1
12VIN1
rPGA-988
DIMM2
DIMM1
5
FAN2
25
PWROUT1
35
LVDS1
26
27 29
28
31
30
1
JSPI1
3
4
6
7
8
910
12
11
13
14
19
15
16
17
COM5
20
18
22
FAN1
23
JFRT1
24
COM6
21
2
34
LPC1
33
MC1
JME1
32

- 8 -
Jumpers
Jumper Settings
The jumper is “short” (closed) when the jumper cap is
placed on pins. If not, that means the jumper is “open.”
Pin open Pin short
(closed)
Pin 2-3 short
(closed)
Pin 1-2 short
(closed)
JBAT1: Clear CMOS Setting (3)
Connector type: 2.00mm pitch 1x3-pin header
Pin Mode
1-2 Keep CMOS data (Default)
23 1
2-3 Clear CMOS data
23 1
JPWR1: AT/ATX Power Mode Selection (1)
Connector type: 2.00mm pitch 1x3-pin header
Pin Power Mode Selection
1-2 ATX Mode (Default)
23 1
2-3 AT Mode
23 1
JRS1: COM2 RS-232 / 422 / 485 Selection (14)
Connector type: 2.00mm pitch 2x4-pin header
Assignment
1 2
7 8
Pin RS-232
(Default) RS-422 RS-485
1-2 Short Open Open
3-4 Open Short Open
5-6 Open Open Short
7-8 ** Short Short Open/Short
** 485 Auto-Flow selection, OFF: Enable, ON: Disable
Connectors
12
7 8
JSPI1: SPI Flash for External SPI Programming
Tools (2)
Connector type: 2.54mm pitch 2x4-pin header
Pin Desc. Pin Desc.
1 V_3P3_SPI 2 GND
3 SPI_CS0_R 4 SPI_CLK_R
5 SPI_SO_R 6 SPI_SI_R
7 NC 8 NC
USB2: USB Port Connector (4)
Connector type: 2.54mm pitch 2x5-pin header
Pin Desc. Pin Desc.
1 2
109
1+5V 2+5V
3 USBD2- 4 USBD3-
5USBD2+ 6USBD3+
7 GND 8 GND
9 GND 10 NC (Key)
JME1: ME Function Select (32)
Connector type: 2.00mm pitch 1x3-pin header
Pin Power Mode Selection
1-2 ME Enable/ME Flash
disable (Default)
23 1
2-3 ME Disable/ME Flash
enable
23 1
CON1: COM3/4 Power Source Select on Pin 9 (18)
Connector type: 2.00mm pitch 2x5-pin header
Default setting: Standard
Pin 9 Power
Source Special
Support
COM3
CON1
COM4
CON1
1 2
9 10
Standard (RI)
(Default)
7-9 8-10
POS: 12V/1A on
Pin 9
1-3 2-4
POS: 5V/1A on
Pin 9
3-5 4-6
INV1: LCD Inverter Connector (5)
Connector type: 2.00mm pitch 1x5 box wafer connector
Pin Description
1
2
3
4
5
1+12V
2 GND
3Backlight on/off
4 Brightness control
5 GND

- 9 -
LVDS1: LVDS Connector (6)
Connector type: DF-13-40DP-1.25V connector
Pin Desc. Pin Desc.
1
3940
2
2 VCC3 1 VCC3
4 GND 3 GND
6 VCC5 5 VCC5
8 GND 7 GND
10 LVDSA_DATA1- 9LVDSA_DATA0-
12 LVDSA_DATA1 11 LVDSA_DATA0
14 GND 13 GND
16 LVDSA_DATA3- 15 LVDSA_DATA2-
18 LVDSA_DATA3 17 LVDSA_DATA2
20 GND 19 GND
22 LVDSB_CLK- 21 LVDSA_CLK-
24 LVDSB_CLK 23 LVDSA_CLK
26 GND 25 GND
28 LVDSB_DATA1- 27 LVDSB_DATA0-
30 LVDSB_DATA1 29 LVDSB_DATA0
32 GND 31 GND
34 LVDSB_DATA3- 33 LVDSB_DATA2-
36 LVDSB_DATA3 35 LVDSB_DATA2
38 GND 37 GND
40 NC 39 GPIO
AUDIO1: Audio Interface Port (7)
Connector type: triple stacked audio jacks (Stereo
ø3.50)
Blue: Line In
Green: Line Out
Pink: MIC In
LAN1, 2: Ethernet Connectors (include
USB0/1/2/3 Connector) (9, 8)
Connector type: RJ-45 + double stacked USB type
A connector.
LAN (RJ-45)
LED LED
LAN
USB
USB
8 7 6 5 4 3 2 1
1 2 3 4
1 2 3 4
Pin Desc.
1MDI0+
2 MDI0-
3MDI1+
4 MDI1-
5MDI2+
6 MDI2-
7MDI3+
8 MDI3-
USB (USB type A connector)
Pin Desc.
1+5V
2 USB-
3USB+
4 GND
USB1: 4 x USB Port Connector (10)
Connector type: 4-stack USB type A connector
Pin Desc. Pin Desc.
11 5V 21 5V
12 USBD1- 22 USBD2-
13 USBD1+ 23 USBD2+
14 GND 24 GND
31 5V 41 5V
32 USBD3- 42 USBD4-
33 USBD3+ 43 USBD4+
34 GND 44 GND
G1 GND G4 GND
G2 GND G5 GND
G3 GND G6 GND
COM1: RS-232 Connector (11)
Connector type: D-sub 9-pin male connector
Pin Desc. Pin Desc.
1 5
6 9
1 DCD 6 DSR
2 RX 7 RTS
3 TX 8 CTS
4 DTR 9 RI
5 GND 10 NC
PWROUT1: SATA Power Connector (35)
Connector type: 2.50mm pitch 1x4-pin wafer connector
Pin Description
1
2
4
3
1 5V
2 GND
3 GND
4 12V_FAN2

- 10 -
12VIN1: ATX12V Connector (22)
12INV1 supplies the CPU operation ATX +12V (Vcore).
Pin Desc. Pin Desc.
2
4
1
3
2 GND 1 GND
4+12V 3+12V
COM3~6: Serial Port Connectors (15, 17,
20, 21)
Connector type: 2.00mm pitch 2x5-pin box header
Pin Desc. Pin Desc.
1 2
9 10
1 DCD1 2 RXD1
3 TXD1 4 DTR1
5 GND 6 DSR1
7 RTS1 8 CTS1
9 RI1 10 NC
COM2: Serial Port Connector (16)
Connector type: 2.00mm pitch 2x7-pin box header
Pin Desc. Pin Desc.
1 2
1314
1 DCD2 2 RXD2
3 TXD2 4 DTR2
5 GND 6 DSR2
7 RTS2 8 CTS2
9 RI2 10 NC
11 422TX+_485+ 12 422TX-_485-
13 422RX+ 14 422RX-
DIO1: DIO Port (19)
Connector type: 2.00mm pitch 2x10-pin header
Pin Desc. Pin Desc.
1 2
23 24
1 DIO0 2 DIO1
3 DIO2 4 DIO3
5 DIO4 6 DIO5
7 DIO6 8 DIO7
9 DIO8 10 DIO9
11 DIO10 12 DIO11
13 DIO12 14 DIO13
15 DIO14 16 DIO15
17 5V 18 GND
19 5V 20 GND
KBUSB1: PS/2 Keyboard and USB x 2 (13)
Connector type: PS/2 Keyboard+USB connector
DVI1: DVI-I Connector (12)
18
916
17 24
C1 C2
C3 C4
C5
Pin Desc. Pin Desc.
1 TX2- 13 TX3+
2TX2+ 14 +5V/50mA
3 TX2/4GND 15 GND
4 TX4- 16 HTPLG
5TX4+ 17 TX0-
6 DDC_CLK 18 TX0+
7 DDC_DATA 19 TX0/5GND
8 CRT_Vsync 20 TX5-
9 TX1- 21 TX5+
10 TX1+ 22 TXC_GND
11 TX1/3GND 23 TXC+
12 TX3- 24 TXC-
C1 Analog RED
C2 Analog Green
C3 Analog Blue
C4 Analog V_SYNC
C5 Analog R, G, B Return
Keyboard
(Purple)
KB_CLK
KB_GND
KB_DAT
KB_VCC
MS_CLK
MS_DAT

- 11 -
FAN1, 2: Fan Connectors (23, 25)
Connector type: 2.54mm pitch 1x4-pin wafer connector
Pin Description
1
2
4
3
1 GND
2+12V
3 FAN_Detect
4 Control
SATA1~6: Serial ATA Connectors (26~31)
Pin Description
7
1
1 GND
2TX+
3 TX-
4 GND
5 RX-
6RX+
7 GND
JFRT1: Switches and Indicators (24)
It provides connectors for system indicators that
provides light indication of the computer activities
and switches to change the computer status.
Connector type: 2.54mm pitch 2x5-pin header
Pin Description Pin Description
109
1 2
1RESET+ 2RESET-
3POWER_LED+ 4 POWER_LED-
5HDD_LED+ 6 HDD_LED-
7SPEAKER+ 8 SPEAKER-
9PSON+ 10 PSON-
LPC1: Low Pin Count Connector (34)
Connector type: CVILUX 0.5mm CF20141U0*0-LF
connector
Pin Desc. Pin Desc.
14
1
1 LPC_D0 8 LPC_RST#
2 LPC_D1 9 GND
3 LPC_D2 10 LPC_CLK_33Mhz
4 LPC_D3 11 GND
5 GND 12 GND
6 LPC_FRAME# 13 +3.3V
7 SERIRQ 14 +3.3V
MC1: Mini-card Slot (33)
52
51
16
18
15
17
2
1
Pin Desc. Pin Desc.
1Wake 2+3.3V
3 COEX1 4 GND
5 COEX2 6 +1.5V
7 CLKREQ# 8 UIM_PWR
9 GND 10 UIM_DATA
11 REFCLK- 12 UIM_CLK
13 REFCLK+ 14 UIM_RESET
15 GND 16 UIM_VPP
17 UIM_C8/Reserved 18 GND
19 UIM_C4/Reserved 20 W_Disable#
21 GND 22 PERST#
23 PERn0 24 +3.3V
25 PERp0 26 GND
27 GND 28 +1.5V
29 GND 30 SMB_CLK
31 PETn0 32 SMB_DATA
33 PETp0 34 GND
35 GND 36 USB_D-
37 GND 38 USB_D+
39 +3.3V 40 GND
41 +3.3V 42 LED_WWAN#
43 GND 44 LED_WLAN#
45 Reserved 46 LED_WPAN#
47 Reserved 48 +1.5V
49 Reserved 50 GND
51 Reserved 52 +3.3V
