ITX-i89H0
Mini-ITX Industrial Motherboard
Quick Installation Guide
Version 1.0
CPU
Soldered onboard
6th Generation
Intel®Core™/Xeon®
Processor
Form Factor
Mini-ITX
I/O
SATA/ USB 2.0/
USB3.0/ UART/ PCIe/
NGFF
Video
HDMI/ DisplayPort
LAN
Intel i219LM GbE PHY
Audio
Realtek
®
ALC662
MIC-in/ Line-out
Copyright ©All Rights Reserved. 4041890001100P
♦ Technical Support
If you have any technical difculties, please consult the user’s manual rst at:
http://www.arbor-technology.com/
Contact our customer service at the following addresses if your problem persists.
http://www.arbor-technology.com/
E-mail: [e-mail]
♦ Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions : (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

- 2 -
Packing List
Before you begin to install your single board, please make sure that the following
materials have been shipped:
1 x ITX-i89H0 Mini-ITX industrial motherboard
1 x Cooler
1 x Driver CD
1 x Quick Installation Guide
If any of the above items is damaged or missing, contact your vendor immediately.
Ordering Information
ITX-i89H0-A-6100E Intel® Core™ Processor i3-6100E/CM236 PCH Mini-ITX
motherboard
ITX-i89H0 (BTO) Intel® Xeon® Processor E3-1505L/CM236 PCH Mini-ITX
motherboard
CBK-06-89H0
2 x SATA cables
1 x SATA Power cable
1 x COM cable
1 x USB cable
1 x USB 3.0 cable
The Installation Paths of CD Driver
Windows 8.1&10 (64-bit)
Driver Path
CHIPSET \i89X\Chipset\Chipset_10.1.1.13_Public
GRAPHIC \i89X\Graphic\IntelR Graphics Driver Production Version 15.40.16.64.4364
ETHERNET \i89X\Ethernet
AUDIO \i89X\Audio\7687_PG436_Win10_Win8.1_Win8_Win7_WHQLx64
ME \i89X\ME\Intel(R)_ME_11.0_Corporate_11.0.0.1202
USB3.0 \i89X\USB3.0\win8.1 64bit\Intel_USB_3.0_xHC_Adaptation_Driver_MR1_Re-
lease_1.0.1.45_PV
RAID \i89X\RAID\Intel Rapid Storage Technology Driver 14.8.0.1042

- 3 -
Specications
Form Factor Mini-ITX industrial motherboard
Processor
Soldered onboard Intel® Core™ i3-6100E Dual-core 2.7GHz
(Base)
Intel® Xeon® Processor E3-1505L V5 Quad-core 2.0GHz (Base) /
2.8GHz (Trubo)
Intel® Xeon® Processor E3-1515M V5 Quad-core 2.8GHz (Base) /
3.7GHz (Trubo)(Optional)
Chipset Intel® CM236
Memory 2 x DDR4 SO-DIMM sockets w/ ECC, supporting up to 32GB
SDRAM
BIOS AMI BIOS
Super I/O Nuvoton NCT6776D
Serial Port 1 x UART connector
Keyboard & Mouse USB interface Keyboard/ Mouse
USB 2.0 4 x USB 2.0 ports
USB 3.0/2.0 6 x USB 3.0/2.0 ports
Expansion
1 x PCIe x16 Gen 3.0 slot
1 x NGFF M.2 E-Key socket for Wireless
1 x LPC interface
Storage 2 x Serial ATA ports with 600MB/s HDD transfer rate
1 x NGFF M.2 M-Key socket for SSD
Ethernet Chipset 1 x Intel® i219LM GbE PHY
Audio Interface Realtek® ALC662 5.1 Channel HD Audio CODEC, Mic-in/Line-
out
Graphic Chipset Integrated Intel® HD Graphics
Graphic Interface 1 x HDMI port
2 x DisplayPort ports
OS Support Windows 8.1 64-bit
Windows 10 64-bit
Power Input DC 12V DC jack
Power Consumption 4.17A@12V (w/ E3-1505L)
Operating Temp. -20 ~ 70ºC (-4 ~ 158ºF)
Operating Humidity 10 ~ 95% @ 70ºC (non-condensing)
Dimension (L x W) 170 x 170 mm (6.7” x 6.7”)

- 4 -
Board Dimensions
156.5
135.65
111.76
85.8
57.9
33.1
170
Unit: mm
163.65
6.17
10.16
Ø3.96x4PCS
33.02
170
165.1

- 5 -
Jumpers/Connectors Quick Reference
Jumpers
Label Function
JPCH1 Clear CMOS Selection
JME1 ME Selection
Connectors
Label Function
USB2 USB3.0/2.0 connector
SATA1~2 SATA Connectors
AUDIO1 Audio Connector
USB1 USB3.0/2.0 connector
LAN1 RJ-45 LAN and USB 2.0
Stack port
HDMI1 HDMI Connector
DP1 Displayport Connector
DCIN1 12V DC Jack
Label Function
CPUFAN1 Fan Power Connector
X16PCEG1 PCIex16 Gen 3.0 slot
FP1 Front panel LED & audio
header
SYSFAN1 FAN Connector
PWROUT1 Connector for SATA Power
USB3 USB 2.0 connector
LPC1 Low Pin Count Connector
JCOM1 UART Connector
WIFI1 M.2 E-Key Socket
SSD1 M.2 M-Key Socket
JME1
➋
JME2
➌
➊JPCH1
JLCD1
➍
⑰JCOM1
⑩CPUFAN1
⑪X16PCEG1
①USB2
④AUDIO1
⑤USB1
⑥LAN1 ⑦HDMI1 ⑧DP1
②SATA1
③SATA2
⑨DCIN1
⑫FP1
⑬SYSFAN1
⑭PWROUT1
⑲SSD1
⑯LPC1 ⑮USB3
⑱WIFI1
Label Function
JME2 SRTC Rest Selection
JLCD1 LCD Panel Voltage Selection

- 6 -
Jumpers
❶ JPCH1: Clear CMOS Selection
Connector type: 2.54mm pitch 1×2-pin headers
Pin Mode
Short Clear CMOS 1 2
Open Keep CMOS (default) 1 2
❷ JME1: ME Selection
Connector type: 2.54mm pitch 1×2-pin headers
Pin Mode
Short ME Disable 1 2
Open ME Enable (default) 1 2
❸JME2 : SRTC Reset Selection
Connector type: 2.54mm pitch 1×2-pin headers
Pin Mode
Short Clear ME RTC 1 2
Open Normal (default) 1 2
❹ JLCD1: LCD Panel Voltage Selection
Connector type: 2.54mm pitch 1x3-pin headers
Pin Mode
1-2 +5V
23 1
2-3 +3.3V (Default)
23 1
Connectors
①USB2 : USB3.0/2.0 Connector
Connector Type: 2x10 pin box header
Pin Desc. Pin Desc. 1
11 01
19
20 N/C 1 +V5S
19 +V5S 2 USB3_RXN5_C
18 USB3_RXN6_C 3USB3_RXP5_C
17 USB3_RXP6_C 4GND
16 GND 5 USB3_TXN5_C
15 USB3_TXN6_C 6 USB3_TXP5_C
14 USB3_TXP6_C 7 GND
13 GND 8USBP5N
12 USBP6N 9USBP5P
11 USBP6P 10 N/C
②③SATA1~2 : Serial ATA Connectors
The pin assignments conform
to the industry standard.
④AUDIO1: Audio Connector
Connector type: Double-stacked ø3.5mm stereo audio jacks
Description
Line out
Mic
Line-out
Mic-in
⑤USB1 : USB 3.0/2.0 Stack Connectors
Connector type: Quadruple-stacked USB connectors
The pin assignments conform to the
industry standard.
⑥ LAN1: RJ-45 LAN and USB 2.0 Stack
Connectors
Connector type: RJ-45 and double-stacked USB
connectors
The pin assignments conform to the
industry standard.

- 7 -
⑦ HDMI1: HDMI Connector
Connector Type: 19-pin HDMI connector
The pin assignments conform to
the industry standard.
18
1
2
19
⑧ DP1: DisplayPort Stack Connectors
Connector Type: Double-stacked DisplayPort connectors
The pin assignments conform to the
industry standard.
⑨ DCIN1: DC IN Jack
Connector type: 4-pin DC in Jack
Pin Desc. Pin Desc. 1
2
43
2VCC1 1 GND1
4VCC2 3GND2
⑩⑬ CPUFAN1&SYSFAN1: Fan Power
Connector
Connector Type: 2.54mm pitch 1x4-pin one-wall connector
Pin Description
1
4
1GND
2 +12V
3RPM
4 Control
⑪ X16PCEG1: PCIex16 Gen 3.0 slot
The pin assignments conform to the industry standard.
B2 B1 A1 A2
B81B82 A81A82
⑫FP1: Front panel LED & audio
header
Connector Type: 2.54mm pitch 2x5-pin headers
Pin Desc. Pin Desc.
1
9
2
10
1HLED+ 2 PLED+
3HLED- 4PLED-
5 RESET+ 6 PSON+
7 RESET- 8PSON-
9+5V 10 N/C
⑭PWROUT1: SATA Power Connector
Connector Type: Onboard 4-pin box connector
Pin Desc.
1
4
1 5V
2 GND
3 GND
4 12V
⑮USB3: USB 2.0 Connector
Connector Type: 2.54mm pitch 2x5-pin headers
Pin Desc. Pin Desc.
1
9
2
10
1+5VS 2 +5VS
3USBP7N 4USBP8N
5 USBP7P 6 USBP8P
7 GND 8GND
9 N/C 10 GND

- 8 -
⑯ LPC1: Low Pin Count Connector
Connector Type: 2x10-pin 2.54mm pitch male pin
header
Pin Desc. Pin Desc.
1
19
2
20
1CLK_PC_24M 2GND
3L_FRAME# 4N/C
5PLTRST# 6+V5S
7L_AD3 8L_AD2
9+V3.3S 10 L_AD1
11 L_AD0 12 GND
13 SMBCLK_M 14 SMBDATA_M
15 +V3.3A 16 SER_IRQ
17 GND 18 TPM_CLKRUN#
19 LPCPD#_LPC 20 L_DRQ_N
⑰JCOM1: UART Connector
Connector Type: 2.54mm pitch 2x5 pin box header
Pin Desc. Pin Desc.
1 2
9 10
1N/C 6N/C
2RXD 7RTS
3TXD 8CTS
4N/C 9N/C
5GND 10 N/C
⑱ WIFI1: NGFF M.2 E-Key Socket
The pin assignments conform to the industry standard.
75
2
74
1
⑲SSD1:NGFF M.2 M-Key Socket
The pin assignments conform to the industry standard.
M
75
2
74
1
