Arbor Technology EmCORE-i315 User manual

Part Number:7003150010010
Quick Installation Guide
386SX Onboard 40MHz CPU with
4MB EDO, Ethernet, 2 serial port
and DiskOnChip socket
EmCORE-i315
Version 1.0

2EmCORE-i315 Quick Installation
Copyright©2002
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequen-tial damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of
such damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
About this Quick Installation
This Quick Installation provides general information and installation instructions
about the product. This Quick Installation is intended for experienced users
and integrators with hardware knowledge of personal computers. If you are
not sure about any description in this Quick Installation, please consult your
vendor before further handling.

3EmCORE-i315 Quick Installation
Warning
Single Board Computers and their components contain very delicate
Integrated Circuits (IC). To protect the Single Board Computer and its
components against damage from static electricity, you should
always follow the following precautions when handling it :
1. Disconnect your Single Board Computer from the power source when you
want to work on the inside
2. Hold the board by the edges and try not to touch the IC chips, leads or
circuitry
3. Use a grounded wrist strap when handling computer components.
4. Place components on a grounded antistatic pad or on the bag that came
with the Single Board Computer, whenever components are separated
from the system
Technical Support
If you have any technical difficulites, please consult the user's manual first
at:
ftp://ftp.arbor.com.tw/pub/install
Please do not hesitate to call or e-mail our customer service when you still
can not find out the answer.
http://www.arbor.com.tw
E-mail:[email protected]

4EmCORE-i315 Quick Installation
Specifications
Sysem:
•CPU + Chipset: 386SX Onboard 40MHz CPU, embedded in Ali
M6117C Chipset
•System Memory: 4MB EDO RAM standard onboard
Multi I/O:
•Serial: Two RS-232C/485 ports (COM 1/COM2)
•Parallel: Supports SPP, EPP and ECP mode
•16-bit Digital I/O
LAN:
•Chipset: Realtek 8019AS single chip, 10Mbps, NE2000 compati-
ble
Flash Disk:
•DiskOnChip2000 socket : supports 16MB ~ 1GB Flash Disks
Mechanical and Environmental:
•Operating Temperature: -20 to 70°C
•Power: Single +5V @400mA

5EmCORE-i315 Quick Installation
Packing list
Before you begin installing your single board computer, please make sure that
the following materials have been shipped:
> 1 x EmCORE-i315DL
> 1 x Quick Installation Guide
> 1 x CD driver
> 1 x Warranty Card
Ordering Codes
EmCORE-i315DL 386SX Onboard 40MHz CPU with 4MB EDO, Ethernet, 2
serial port and DiskOnChip socket

6EmCORE-i315 Quick Installation
Board Layout Top View (Front)
J10

7EmCORE-i315 Quick Installation
Board Layout Top View (Back)
KBD1
J2
J1
RES1
GPIO1
COM2 COM1
J4J5
LPT1
J10
PWR1

8EmCORE-i315 Quick Installation
Board Dimension

9EmCORE-i315 Quick Installation
Jumper Quick Reference
Jumpers
Lable Function
J1 Clear CMOS
J4 RS-232& RS-485 Selection on COM1&COM2
J2 DOC, Flash and EEPROM address selection
RES1 Reset Function

10 EmCORE-i315 Quick Installation
Connector Quick Reference
Connectors
Lable Function
J10 PC104 Connector
GPIO1 GPIO Connector
COM1 RS232 Serial Port: COM1
COM2 RS232 Serial Port: COM2
KBD1 Keyboard Connector
LAN1 10/100M LAN1 Connector
J3 10/100M LAN1 Connector FOR OEM
LPT1 Parallel Port
PWR1 2P Power Connector

11EmCORE-i315 Quick Installation
CMOS Jumper Settings
CMOS Operation (J1)
Type : J1: onboard 3-pin header
If the EmCORE-i315 refuses to boot due to inappropriate CMOS settings here
is how to proceed to clear (reset) the CMOS to its default values.
CMOS Setup (J1) J1 Status
Normal Operation 1-2 ON
Clear CMOS 2-3 ON
default setting 1-2 ON
123
J1
DOC / Flash / EEPROM Selection
DOC, Flash and EEPROM Selection (J2)
Type : J2: onboard 2x3-pin header
Mode Setting (J2)
1-2 3-4 5-6
ON ON ON DOC D0000
OFF ON ON DOC D8000
ON OFF ON FLASH D0000
OFF OFF ON FLASH D8000
OFF ON ON FLASH D4000
OFF ON OFF EPROM D0000
ON OFF OFF EPROM D8000
OFF OFF OFF ALL OPEN
Deafult setting DOC D0000
1
3
5
2
4
6

12 EmCORE-i315 Quick Installation
Serial Port Selection (RS232C/485)
RS-232C/485 Mode select (J4)
Type : J4: onboard 6-pin(2*3) header
RS-422/485 Mode on COM1 & COM2
The onboard COM1 and COM2 port can be configured to operate in RS-485
modes. Jumper J4 switches between RS-232C or RS-485 mode. All of the
RS-232C/485 modes are available on COM1 or COM2.
COM2
Pin Defined: RS-232C RS-485
Pin1 : DCD RTx+
Pin2 : RXD RTx-
Pin8 : CTS x
Pin9 : RI x
J4 Selection 1-3 2-4 3-5 4-6
RS-232C ON ON OFF OFF
RS-485 OFF OFF J5(1-2) J5(3-4)
default setting RS-232C
1
3
5
2
4
6
Reset System
Reset System (RES1)
Type: Onboard 2-pin header
Pin Description
1RST
2GND
1
2RES1

13EmCORE-i315 Quick Installation
COM1 & COM2 Connector
Connector : COM1
Type : onboard 10-pin box header
Pin Description Pin Description
1DCD1(485DATA1+) 2RXD1(485DATA1-)
3TXD1 4DTR1
5GND 6DSR1
7RTS1 8CTS1
9RI 10 NC
Connector : COM2
Type : onboard 10-pin box header
Pin Description Pin Description
1DCD2(485DATA2+) 2RXD1(485DATA2-)
3TXD2 4DTR2
5GND 6DSR2
7RTS2 8CTS2
9RI 10 NC
COM1
&
COM2
9
1
210
16-Bit General Purpose I/O
Connector : GPIO1
Type : onboard 20-pin box header
Pin Description Pin Description
1GND 2VCC
3GPI0 4GPO0
5GPI1- 6GPO1
7GPI2 8GPO2
9GPI3 10 GPO3
11 GPI4 12 GPO4
13 GPI5 14 GPO5
15 GPI6 16 GPO6
17 GPI7 18 GPO7
19 VCC 20 GND
GPIO1
19
1
220

14 EmCORE-i315 Quick Installation
Keyboard Connector
Connector : KBD1
Type : onboard waver 5-pin
Pin Description Pin Description
1KB_CLK 2KB_DATA
3N/A 4GND
5Vcc
1 2 3 4 5
Fast Ethernet Connectors
LAN Port (10/100Mbps)
Connector : LAN1
Type : external RJ-45 on bracket
Pin 12345678
Desciption TX+ TX- RX+ NC NC RX- NC NC
1
2
3
4
5
6
7
8
LAN 1
Connector : LAN1 (OEM)
Type : Onboard 2x4 pin connector
Pin 1234
Desciption TCT TX- RX+ NC
Pin 5678
Description RX- NC NC NC
2 4 6 8
1 3 5 7

15EmCORE-i315 Quick Installation
LPT1
Pin Description Pin Description
1STROBE 14 AFD
2PTD0 15 ERROR
3PTD1 16 INIT
4PTD2 17 SLIN
5PTD3 18 GND
6PTD4 19 GND
7PTD5 20 GND
8PTD6 21 GND
9PTD7 22 GND
10 ACK 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SELECT 26 GND
Type : Onboard 20-pin header
20 2
19 1
Power Connector
Connector:PWR1
Type : onboard 2-pin Wafer connector
Pin Description
1GND
2Vcc
1
2
PWR2
