Arbor Technology HiCORE-i67Q1 User manual

- 1 -
Quick Installation Guide
Version 1.2
If you have any technical difculties, please consult the user's manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
nd out the answer.
http://www.arbor.com.tw
E-mail: [e-mail]
♦ Technical Support
HiCORE-i67Q1
HiCORE-i67Q2
PICMG 1.3 Full-size SBC
Form Factor
PICMG 1.3 Full-size
SBC
I/O
PCI/ PEG/ SATA/ USB/
LPT/ COM
CPU
Socket LGA1155 for
Intel®Sandy Bridge or Ivy
Bridge processors
LAN
2 x Intel
®
82583V PCIe
GbE
Chipset
Intel®PCH Q67
Video
Analog RGB
Copyright® All Rights Reserved. 4041670100120P
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Audio
Realtek ALC886 HD
AUDIO CODEC, Line-in/
Line-out/ Mic-in

- 2 -
Ordering Information
HiCORE-i67Q1 Socket LGA1155 for Intel® Ivy/ Sandy Bridge processor
Full-size SBC with BIOS to support 1 x PCIe x4
HiCORE-i67Q2 Socket LGA1155 for Intel® Ivy/ Sandy Bridge processor
Full-size SBC with BIOS to support 4 x PCIe x1
Before starting with the installation, make sure the following items are
shipped:
1 x HiCORE-i67Q1 or HiCORE-i67Q2
PICMG 1.3 Full-size SBC
1 x Driver CD
1 x Quick Installation Guide
CBK-06-67Q1-00
Cable Kit
1 x RS-232 cable
1 x RS-232/422/485 cable
1 x SATA cable
1 x USB cable w/ bracket
1 x Keyboard & Mouse cable
1 x Audio cable
If any of the above items is missing or appears damaged, contact your
vendor immediately.
Packing List
Optional Accessories
HS-67Q1-C1 Aluminium CPU cooler for Pentium® G850
HS-67Q1-C2 Copper CPU cooler for Core-i series
PBPE-10SA 10 slots PICMG 1.3 backplane
PBPE-13SA 13 slots PICMG 1.3 backplane

- 3 -
Specifications
Form Factor PICMG 1.3 Full-size SBC
Processor Support 2nd and 3rd Generation Intel® Core™ i7/i5/i3/
Pentium®/Celeron® processors in LGA1155 socket
System Memory 2 x 240-pin DDR3 Long-DIMM sockets, supporting
1066/1333MHz SDRAM up to 16GB
Chipset Intel® PCH Q67
BIOS AMI PnP Flash BIOS
Watchdog Timer 1~255 levels reset
Super I/O Fintek F71869ED
Note:
HiCORE-i67Q1 supports 1 x PCIe x4. HiCORE-i67Q2 supports 4 x PCIe x1.
Since PCIe x4 slot and PCIe x1 slot. Because they cannot work at the same
time under the same BIOS conguration, there should be two BIOS versions.
If you want to change BIOS setting for desired PCIe, download its BIOS at
ftp://ftp.arbor.com.tw/pub/driver/01slot_computing/HiCORE-i67Q1/BIOS/
Update BIOS in DOS:
- PCIex1.bat: BIOS set as PCIe x1 enabled.
- PCIex4.bat: BIOS set as PCIe x4 enabled.
Intel® 3rd Generation
i7-3770 3.4GHz Core™ Processor
i5-3550S 3.0GHz Core™ Processor
i3-3220 3.3GHz Core™ Processor
G2120 3.1GHz Pentium® Dual Core Processor
Intel® 2nd Generation
i7-2600 3.4GHz Core™ Processor
i5-2400 3.1GHz Core™ Processor
i3-2120 3.3GHz Core™ Processor
G850 2.9GHz Pentium® Dual Core Processor
G540 2.5GHz Celeron® Dual Core Processor
Recommended CPU List

- 4 -
Serial Port 2 x COM ports
(COM1 RS-232, COM2 RS-232/422/485 selectable)
Parallel Port SPP/EPP/ECP mode selectable
USB 2.0
14 x USB 2.0 ports
(10 ports on CPU board, 4 ports through gold nger
to backplane)
Keyboard/ Mouse One 6-pin Mini-DIN connector for keyboard and
mouse (PS/2 standard via Y-cable)
Digital I/O 8-bit programmable Digital Input/Output
Expansion Bus
4 x PCI Masters
1 x PCIe x16 lanes
1 x PCIe x4 lane (HiCORE-i67Q1)
4 x PCIe x1 lanes (HiCORE-i67Q2)
Storage
2 x SATA 600MB/s ports
4 x SATA 300MB/s ports (2 x SATA ports on SBC, 2 x
SATA ports through GF to Backplane)
Support RAID 0, 1, 5, 10
Ethernet Chipset 2 x Intel® 82583V PCIe GbE controllers
Audio Interface Realtek ALC886 HD Audio CODEC, Line-in/ Line-out/
MIC via audio cable
Graphics Chipset Integrated Intel® HD Graphics 200
Graphics Interface Analog RGB supports resolution up to 2048 x 1536
@75Hz
Power Connector ATX +12V input
Certication CE/FCC
Operation Temp. 0oC ~ 60oC (32oF ~ 140oF)
Operating Humidity 0 ~ 95% (non-condensing)
Dimension (LxW) 338 x 126mm (13.3" x 4.96")

- 5 -
The Installation Paths of CD Driver
The CPU board supports Windows XP and Windows 7. Find the necessary
drivers by the following paths on the CD that comes with your purchase.
Windows XP
Chipset \HiCORE-i67Q1\CHIPSET
Audio \HiCORE-i67Q1\AUDIO\WinXP
LAN \HiCORE-i67Q1\ETHERNET\32
\HiCORE-i67Q1\ETHERNET\64
Graphic \HiCORE-i67Q1\GRAPHIC\Win XP
ME \HiCORE-i67Q1\ME
AHCI \HiCORE-i67Q1\RAID
Windows 7
Chipset \HiCORE-i67Q1\CHIPSET
Audio \HiCORE-i67Q1\AUDIO\Win7
LAN \HiCORE-i67Q1\ETHERNET\32
\HiCORE-i67Q1\ETHERNET\64
Graphic \HiCORE-i67Q1\GRAPHIC\Win7
ME \HiCORE-i67Q1\ME
AHCI \HiCORE-i67Q1\RAID

- 6 -
Board Dimensions
1
2
9
10
1
2
9
10
12 11
2
1
16 15
2
20
19
2
1
41
2
9
10
9
10
10
9
1
10
9
2
10
9
2 1
10
6
15 11
5 1
6 5
4 3 2 1
26 25
2 1
1
1
1
6
5
2
+ +
3
4
3.44 92.2
4.00
329.58
338.60
4.12 108.77
126.4
118.00
Ø3.2 x Ø8.0
Unit:mm

- 7 -
Jumpers/ Connectors Quick Reference
Connectors
Label Description
AUDIO1 AUDIO Connector
COM1 RS-232 Connector
COM2 RS-232/422/485 Connector
DIO1 Digital I/O Connector
IR1 Infrared Connector
J2, J3, J5, J6 SATA Connectors
J4 LPT Connector
J7 ATX1 2V power Connector
JFAN1~2 Fan Connectors
JFRT1 Switches and indicators
JUSB1~5 USB Port Connectors
KBM1 Keyboard and Mouse Connector
LAN1~2 Ethernet Connectors
VGA1 Analog RGB Connector
Jumpers
Label Description
JBAT1 Protected RTC Setting
JBAT2 Clear CMOS Setting
JRS1 COM2 RS-232/422/485 Selection

- 8 -
Jumpers & Connectors location
2
9
10
9
10
10
9
1
10
9
2
10
9
2 1
1
1
6
5
2
3
J7
10
4
1 2
1
1
11
2
12
25 26
21
21
1615
1
1
1
1
1
Socket
LGA1155
JFAN2
9
JUSB3
8
JUSB1
7
JUSB2
6
JUSB5
5
JUSB4
4
JFRT1
3
JBAT2
2
JBAT1
1
JFAN1
11
J5
12
J2
13
J6
14
J3
15
DIO1
16
COM2
17
JRS1
18
COM1
19
IR1
20
J4
21
AUDIO1
22
LAN1
23
LAN2
24
VGA1
25
KBM1
26

- 9 -
Jumper
JBAT1: Protected RTC Setting (1)
Connector type: 2.54mm pitch 1x3-pin headers.
Pin Mode
1-2 Keep Protected (Default)
2 31
2-3 Clear RTC
2 31
Connectors
JBAT2: Clear CMOS Setting (2)
Connector type: 2.54mm pitch 1x3-pin headers.
Pin Mode
1-2 Keep CMOS (Default)
2 31
2-3 Clear CMOS
2 31
JRS1: COM2 RS-232 / 422 / 485
Selection (18)
Connector type: 2.00mm pitch 2x3-pin headers.
Mode RS-232
(Default) RS-422 RS-485
1-2 Short Open Open
3-4 Open Short Open
5-6 Open Open Short
65
21
65
21
65
21
JFAN1, 2: Fan Connectors (9), (11)
Connector type: 2.54mm pitch 1x4-pin wafer
connector.
Pin Description
1
2
4
3
1GND
2 +12V
3 RPM
4FAN_CTL
J7: ATX +12V Connector (10)
J7 supplies the CPU operation ATX +12V (Vcore).
Pin Desc. Pin Desc.
2
4
1
3
1GND 2GND
3 +12V 4 +12V
J2, J3, J5, J6: Serial ATA Connectors
(12, 13, 14, 15)
Connector type: SATA connectors.
Pin Description
1
7
1GND
2 TX+
3 TX-
4GND
5RX-
6 RX+
7GND
JUSB1~5: USB Ports (4, 5, 6, 7, 8)
Connector type: 2.54mm pitch 2x5 pin-header, pin-
10 is eliminated.
Pin Desc. Pin Desc.
109
1 2
1+5V 2+5V
3USBD1- 4USBD2-
5 USBD+ 6USBD2+
7GND 8 GND
9 N/C (Key) 10 N/C
JFRT1: Switches and Indicators (3)
Connector type: 2.54 mm pitch 2x8-pin headers.
Pin Desc. Pin Desc.
1Power LED+ 2PWRBTN+
3Power LED- 4PWRBTN-
5 Power LED- 6 RESET+
7HD LED+ 8 RESET-
9 HD LED- 10 SPEAKER+
11 SMB CLK 12 SPEAKER+
13 SMB DAT 14 SPEAKER-
15 SMB GND 16 SPEAKER-
1 2
15 16

- 10 -
DIO1: Digital I/O Connector (16)
Connector type: 2.54mm pitch 2x5-pin headers.
Pin Desc. Pin Desc.
109
1 2
1DIO0 2DIO1
3DIO2 4DIO3
5 DIO4 6DIO5
7DIO6 8DIO7
9 +5V 10 GND
COM1: RS-232 Port (17)
Connector type: 2.54mm pitch 2x5-pin box headers.
Pin Desc. Pin Desc.
1 2
9 10
1DCD# 2DSR#
3RXD 4RTS#
5 TXD 6CTS#
7DTR# 8 RI#
9 GND 10 N/C
COM2: RS-232/422/485 Port (19)
Connector type: 2.54mm pitch 2x7-pin box headers.
Pin Desc. Pin Desc.
1 2
13 14
1DCD# 2DSR#
3RXD 4RTS#
5 TXD 6CTS#
7DTR# 8 RI#
9 GND 10 GND
11 442TX+/ 485+ 12 422TX-/ 485-
13 422RX+ 14 422RX-
AUDIO1: AUDIO Connector (22)
Connector type: 2.00mm pitch 2x6-pin headers.
Pin Desc. Pin Desc.
1211
1 2
1 LIN-L 2 LIN-R
3LINE-JD 4GND_AU
5MICL 6 MICR
7MIC-JD 8 GND_AU
9 LOUT-L 10 LOUT-R
11 FRONT-JD 12 GND_AU
LAN1, 2: GbE Connectors (23), (24)
Connector type: RJ-45 with LED indicators.
IR1: Infrared Connector (20)
Connector type: 2.54mm pitch 1x5-pin headers.
Pin Description
1
2
3
4
5
1+5V
2N/C
3 IRRX
4GND
5IRTX
J4: Parallel Port Connector (21)
Connector type: 2.54mm pitch 2x13 box headers.
Pin Description Pin Description
1
13
14
26
1STB# 14 AFD#
2PTD0 15 ERROR#
3PTD1 16 INIT#
4PTD2 17 SLIN#
5 PTD3 18 GND
6PTD4 19 GND
7PTD5 20 GND
8 PTD6 21 GND
9 PTD7 22 GND
10 ACK# 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SELECT 26 N/C

- 11 -
KBM1: Keyboard & Mouse Connector (26)
Connector type: 6-pin Mini-DIN connector.
Pin Description
12
3
56
4
1KB Data
2MS Data
3GND
4 VCC PS2
5 KB Clock
6 MS Clock
VGA1: Analog RBG Connector (25)
Connector type: D-Sub 15-pin female.
Pin Desc. Pin Desc.
1
515
11
1RED 9 VCC
2 GREEN 10 GND
3BLUE 11 N/C
4N/C 12 DDC_DATA
5 GND 13 HSYNC
6GND 14 VSYNC
7GND 15 DDC-CLK
8 GND
