Arbor Technology MB-i89Q0 User manual

- 1 -
Quick Installation Guide
Version 1.0
If you have any technical difculties, please consult the user’s manual rst at:
http://www.arbor-technology.com
Please do not hesitate to e-mail to our customer service when you still can not nd out
the answer.
E-mail: [e-mail]
♦ Technical Support
MB-i89Q0
Micro-ATX Industrial Motherboard
Form Factor
Micro-ATX Industrial
Motherboard
Video
DVI-I/ DisplayPort
I/O
PCIe/ PCI/ SATA/ COM/
USB 3.0/ USB 2.0
CPU
Socket LGA1151 for
Intel®Core i7/i5/i3
Processors
Chipset
Intel®PCH Q170
LAN
Intel®i210AT PCIe GbE
Controller
Intel®i219LM PCIe GbE
Audio
Realtek®ALC269 HD,
MIC-in/Line-out/ Line-in ,
with Amplier
Copyright 2018 All Rights Reserved. 4041890004100P
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
BIOS ACT
Anti-Crash
Technology for system
BIOS recovering

- 2 -
Specifications
Form Factor Micro-ATX Industrial Motherboard
CPU Support 6th Generation Intel® Core™ i7/i5/i3 processors in LGA1151
socket
Memory 4 x 288-pin DDR4 Long-DIMM sockets, supporting 2133/1866MHz
SDRAM up to 64GB
Chipset Intel® PCH Q170
BIOS AMI UEFI ROM
TPM Support TPM 1.2 & 2.0 daughterboard via LPC connector (optional)
Watchdog Timer 1~255 levels reset
Super IO Chipset FINTEK F81768
FINTEK F81216AD (OEM request)
Serial Port 2 x RS-232 ports,
up to 4 x RS-232 ports (OEM request)
USB Port 10 x USB 2.0 ports, 4 x USB 3.0/2.0 ports
Keyboard & Mouse 6-pin wafer connector for PS/2 keyboard/ mouse via Y-cable
Expansion Bus
1 x PCI slot
1 x PCIex16 Gen 3.0 slot
1 x PCIex4 in x8 slot
1 x PCIex1 slot
Storage
Six Serial ATA ports with 600MB/s HDD transfer rate
RAID 0, 1, 5, 10 supported
Ethernet Chipset 1 x Intel® i210AT PCIe GbE controller
1 x Intel® i219LM PCIe GbE PHY
Audio Interface Realtek® ALC269 5.1 Channel HD Audio CODEC,Mic-in/ Line-in/ Line-
out with Amplifier
Graphic Chipset Integrated Intel® HD Graphics 5x0
Graphic Interface 1 x DVI-I port, 2 x DisplayPort ports
Power Requirement 24-pin + 4-pin ATX power connector
Power Consumption 2.34A @+12V with i3-6100 (Typical)
3.83A @+12V with i7-6700 (Typical)
Operating Temp. 0 ~ 60ºC (32 ~ 140ºF)
Operating Humidity 10 ~ 95% @ 60ºC (non-condensing)
Dimension (L x W) 244 x 244 mm (9.6” x 9.6”)
Recommended CPU List:
Intel® Core™ i7-6700 quad-core 3.4 GHz processor
Intel® Core™ i5-6500 quad-core 3.6 GHz processor
Intel® Core™ i3-6100 dual-core 3.7 GHz processor

- 3 -
Before you begin installing your single board, please make sure that the
following materials have been shipped:
Packing List
1 x MB-i89Q0 Industrial Motherboard
1 x Driver CD
1 x Quick Installation Guide
1 x I/O Bracket
If any of the above items is damaged or missing, contact your vendor
immediately.
Ordering Information
MB-i89Q0 Socket LGA1151/ PCH Q170 for Intel® 6th Gen.
processor micro-ATX motherboard
CPF-67Q0-C1 CPU COOLING FAN FOR LGA1151
Optional Accessories
SCDB-3291 TPM 1.2 Daughter board with Infineon OPTIGA TPM
SLB9660
SCDB-3292 TPM 2.0 Daughter board with Infineon OPTIGA TPM
SLB9665
CBK-11-89Q0-00
Cable kit
2 x USB 2.0 cable w/ bracket (2 ports / cable)
1 x COM port cable
6 x SATA cables
2 x DP cables

- 4 -
The Installation Paths of CD Driver
The CPU board supports Windows 10 64-bit. Find the necessary drivers by
the following paths on the CD that comes with your purchase.
Windows 10 64-bit
Chipset \i89X\Chipset\Chipset_10.1.1.13_Public
Audio \i89X\Audio\7687_PG436_Win10_Win8.1_Win8_Win7_WHQLx64
LAN \i89X\Ethernet
Graphic \i89X\Graphic\IntelR Graphics Driver Production Version
15.40.16.64.4364
ME \i89X\ME\Intel(R)_ME_11.0_Corporate_11.0.0.1202
RAID \i89X\RAID\Intel Rapid Storage Technology Driver 14.8.0.1042

- 5 -
Board Dimensions
Unit:mm
9.76
42.4
75.05
96.91
137.38
118.38
1.6
KB/MS
USB
COM/DVI-I USBx4 LAN/USB LAN/USB Line in/out/Mic
33.02
165.1
237.49
243.84
6.35
163.83
229.87
209.55
10.16
243.84
4
1
NO COMPONENT
NO COMPONENT
143
1442
78
287
288
145
146 222
77
221
143
144
2
78
287
288
145
146 222
77
221
143
1442
78
287
288
145
146 222
77
221
143
1442
78
287
288
145
146 222
77
221
1 2
1
1
1 2
15 16

- 6 -
Jumpers/ Connectors Quick Reference
Jumpers
Jumper Description
➊JBAT1 CMOS Setting
➋JPIC1 ACT Function Setting
➌JPATATX1 AT/ATX Mode Selection
Connectors
Connector Description
①ATX1 ATX Power Connector
②⑪SYSFAN1, 2 Fan Power Connectors
③~⑧SATA1~6 Serial ATA Connectors
⑨JICSP1 For Internal Use Only
⑩JFRT1 Connectors for front-panel switches and LED status lamps
⑫LPC1 Low Pin Count Connector
⑬⑭USB3, 2 USB 2.0 Connectors
⑮TPM1 TPM Connector
⑯⑰⑱COM2, 3, 4 RS-232 Connectors
⑲⑳SPKR1, SPKL1 Speaker Connectors
21
AUDIO1 Audio Interface Port
22 23
LAN1, 2 RJ-45+USB 3.0 Stacked Connectors
24
USB1 USB 2.0 Stacked Connectors
25
DVI1 Stacked COM1 & DVI-I Connectors
26
KBUSB1 PS/2 Keyboard & USB 2.0 Stacked Connectors
27
JATX1 ATX 12V Connector
28 29
DP1, 2 DisplayPort Connectors
30
CPUFAN1 CPU Fan Power Connector
31
PCIE1 PCI Express x16 Gen 3.0 Slot
32
PCIE2 PCI Express x1 Slot
33
PCIE4 PCI Express x8 Slot with x4 Single
34
PCI1 PCI Slot
35
~
38
DIMM1~4 288-pin DDR4 Memory Slots

- 7 -
Jumpers & Connectors Location
4
1
NO COMPONENT
NO COMPONENT
143
1442
78
287
288
145
146 222
77
221
143
144
2
78
287
288
145
146 222
77
221
143
1442
78
287
288
145
146 222
77
221
143
1442
78
287
288
145
146 222
77
221
1 2
1
1
1 2
15 16
COM
DVI-I
LAN Line in
Line out
Mic
USB 2.0 x4
USB2
USB1
LAN
USB4
USB3
KB/MS
USB5
USB6
USB7
USB8
USB9
USB10
SYSFAN1
USB3
JICSP1
JPIC1
JFRT1
DP1
JATX1
DP2
AUDIO1DVI1
USB1 LAN1
LAN2
ATX1
JBAT1
USB2
JPATATX1
SPKL1 SPKR1
KBUSB1
SYSFAN2
PCI1
PCIE4
PCIE2
PCIE1
CPUFAN1 LPC1
2
SATA2SATA1
34
1
11
12
13
14
TPM1
15
COM2
16
COM3
17
COM4
18
20 19
212325
22
24
26
27
28
29
30
31
32
33
34
10
9
SATA4SATA3
5 6
SATA6SATA5
8
7
35
DIMM1
36
DIMM2
37
DIMM3
38DIMM4
1 2
3

- 8 -
Jumpers
➊JBAT1: CMOS Setting
Connector type: 2.54mm pitch 1x3-pin header
Pin Description
1-2 Keep CMOS (default)
23 1
2-3 Clear CMOS
23 1
➋JPIC1: ACT Function Setting
Connector type: 2.00mm pitch 1x3-pin header
Pin Mode
1-2 ACT Enabled (default)
23 1
2-3 ACT Disabled
23 1
➌JPATATX1: AT/ATX Mode Selection
Connector type: 2.54mm pitch 1x3-pin header
Pin Description
1-2 AT Mode
23 1
2-3 ATX Mode (Default)
23 1
Connectors
①ATX1: ATX Power Connector
Connector type: 24-pin ATX power supply
connector
Pin Desc. Pin Desc.
1
13
12
24
1+3.3V 13 +3.3V
2 +3.3V 14 -12V
3 COM 15 COM
4+5V 16 PS-ON
5 COM 17 COM
6 +5V 18 COM
7COM 19 COM
8 PW-OK 20 NC
9 +5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 COM
②⑪ SYSFAN1, 2: Fan Power Connectors
Connector type: 2.54mm pitch 1x4-pin wafer one
wall connector
Pin Description
1
4
1GND
2 +12V
3 RPM
4CTRL
③~⑧ SATA1~6: Serial ATA Connectors
Connector type: lockable SATA connectors with
housing
The pin assignments conform to the
industry standard.
⑨ JICSP1: For Internal Use Only
Connector type: 2.00mm pitch 2x4-pin
header
21
⑩JFRT1: Connectors for front-panel
switches and LED status lamps
Connector type: 2.54mm pitch 2x8-pin header
Pin Description Pin Description
1
15 16
2
1LED- 2 LED+
3 PWRBTN- 4PWRBTN+
5 RESET- 6 RESET+
7HDD LED+ 8 GND
9 HDD LED- 10 SPEAKER+
11 SMB_CLK 12 SPEAKER+
13 SMB_DATA 14 SPEAKER-
15 GND 16 SPEAKER-
⑫ LPC1: Low Pin Count Connector
Connector Type: 2.00mm pitch 2x5-pin header
Pin Desc. Pin Desc.
1 2
9 10
1CLK_PC_24M 2GND
3L_FRAME# 4L_ADØ
5PLTRST# 6SERIRØ
7L_AD3 8L_AD2
9+V3.3S 10 L_AD1

- 9 -
⑬ USB3: USB 2.0 Connectors
Connector Type: 2.54mm pitch 2x5-pin header
Pin Desc. Pin Desc.
1
9
2
10
1+5VS 2 +5VS
3USBP11N 4 USBP12N
5USBP11P 6 USBP12P
7GND 8 GND
9 N/C 10 GND
⑭ USB2: USB 2.0 Connectors
Connector Type: 2.54mm pitch 2x5-pin header
Pin Desc. Pin Desc.
1
9
2
10
1+5VS 2 +5VS
3 USBP13N 4 USBP14N
5 USBP13P 6 USBP14P
7GND 8 GND
9 N/C 10 GND
⑮ TPM1: TPM Connector (Optional)
Connector type: 2.54mm pitch 2x10-pin header
Pin Desc. Pin Desc.
1
19 20
2
1 CLK_LPC1_24M 2 GND
3 L_FRAME# 4N/C
5 PLT_RST 6 N/C
7L_AD3 8 L_AD2
9 +V3.3S 10 L_AD1
11 L_AD0 12 GND
13 N/C 14 N/C
15 +V3.3A 16 SER_IRQ
17 GND 18 CLKR#
19 LPCPD#_LPC 20 N/C
⑯⑰⑱COM2, 3, 4: RS-232 Connectors
(COM3 & 4 optional)
Connector type: 2.54mm pitch 2x5-pin header
Pin Desc. Pin Desc.
1 2
9 10
1DCD# 2 RXD
3 TXD 4DTR#
5 GND 6 DSR#
7RTS# 8 CTS#
9 RI# 10 N/C
⑲⑳ SPKR1, SPKL1: Speaker Connectors
Connector Type: 1.25mm pitch 1x2-pin wafer con-
nector
Pin Description
12
1INSPL/R+
2 INSPL/R-
21
AUDIO1: Audio Interface Port
Connector type: 3 x 3.5mm stacked phone jack
Audio Jack Description
Line in
Line out
Mic
Blue Line-in
Green Line-out
Pink Mic-in
22 23
LAN1, 2: RJ-45+USB 3.0 Stacked Con-
nectors
Connector type: RJ-45 connector with LED +
Double-stacked USB 3.02/2.0 type A connectors
LAN
Speed Speed
Link/Act Link/Act
USB2
USB1
USB4
USB3
LAN1 LAN2
LED Denition
Speed Amber:1000M
Green: 10/100M
Link/
Act
On: Linked
Blink: Network Activity
Off: No Link
USB
The pin assignments conform to
the industry standard.
24
USB1: USB 2.0 Stacked Connectors
Connector type: Quad-stacked USB 2.0 type A
connectors
The pin assignments conform to
the industry standard. USB7
USB8
USB9
USB10

- 10 -
30
CPUFAN1: CPU Fan Power Connector
Connector type: 2.54mm pitch 1x4 wafer one wall
connector
Pin Description
1
4
1GND
2 +12V
3 RPM
4CTRL
31
PCIE1: PCIe x16 Gen 3.0 Slot
Connector type: PCI Express x16 Gen 3.0 slot
The pin assignments conform to the industry stan-
dard.
B2 B1 A1 A2
B81B82 A81A82
32
PCIE2: PCIe x1 Slot
Connector type: PCI Express x1 slot
The pin assignments conform to the industry stan-
dard.
A1 A2
A18
B18
A17B17
B1
B2
33
PCIE4: PCIe x8 Slot w/ x4 Single
Connector type: PCI Express x8 slot with x4 single
The pin assignments conform to the industry stan-
dard.
A48 A49 B48
B49
A2 A1 B1 B2
34
PCI1: PCI Slot
Connector type: 32-bit PCI slot
The pin assignments conform to the industry stan-
dard.
A1
A2
B1
B2
A61
A62
B61
B62
35 36 37 38
DIMM1~4: 288-pin DDR4
Memory Slots
Connector type: 288-pin DDR4 DIMM slots
287
288
145
146
143
144
2
221 222
77 78
The pin assignments conform to the industry standard.
25
DVI1: Stacked COM1 & DVI-I Connectors
Connector type: Male type 9-pin D-SUB
connector+female type DVI-I connector
COM1:
Pin Desc. Pin Desc.
18
916
17 24
C1 C2
C3 C4
C5
1 5
6 9
COM1
DVI-I
1DCD# 2 RXD
3 TXD 4DTR#
5 GND 6 DSR#
7RTS# 8 CTS#
9 RI#
DVI-I: The pin assignments conform to the industry
standard.
26
KBUSB1: PS/2 Keyboard & USB 2.0
Stacked Connectors
Connector type: 6-pin Mini-DIN & Double-stacked
USB 2.0 type A connectors
Keyboard
(Purple)
KB_CLK
KB_GND
KB_DAT
KB_VCC
MS_CLK
MS_DAT
USB5
USB6
27
JATX1: ATX 12V Connector
Connector type: 8-pin power connector
Pin Desc. Pin Desc.
1 4
8
5
1GND 5 +12V
2 GND 6 +12V
3 GND 7+12V
4GND 8 +12V
28 29 DP1, 2: DisplayPort Connectors
Connect the display device to the DisplayPort
Connector
The pin assignments conform to the
industry standard.

- 11 -
Anti-Crash Technology for BIOS Recovering
Board Block Diagram
2 x USB 2.0 Ports
1 x RS-232 port COM2
Pin-header
PS/2 Keyboard/ Mouse
KBMS_USB1
Stacked PS/2
USB Type A
1 x RS-232 port
LPC I/F Fintek
F81768D
Super IO
2 x RS-232 ports COM3, 4
Pin-header
(OEM-request)
LPC I/F Fintek
F81216AD
Super IO
eDP Analog RGB
COM1_DVI1
DB9 female conn.
(up side)
DVI-I conn.
(low side)
DDI port
Chrontel
CH7517A
SATA 1, 2, 3, 4, 5, 6
SATA1 ~ 6
SATA connectors
1 x PCIex4
PCIe3
PCIex8 slot
1 x PCIex1
PCIe2
PCIex1 slot
1 x PCIex1
PCI I/F
PCI1
PCI slot
LPC I/F
4 x USB 2.0 Ports
USB2,3
Pin-header
DIMM1~4
Dual Channel
DIMM DDR4 sockets
DDR4 2133/1866MHz
PCIe1
PCIex16 slot
PCIex16 lanes
2 x USB 3.0/2.0 Ports
GbE
Intel i219LM
GbE PHY
1 x PCIex1 LAN1
RJ-45 connector
& Double Stacked
USB Type A
connector
2 x USB 3.0/2.0 Ports
GbE
Intel i210
GbE Controller
1 x PCIex1 LAN2
RJ-45 connector
& Double Stacked
USB Type A
connector
USB1
4x stacked USB 2.0
4 x USB 2.0 Ports
2 x DDI ports DP1,2
Internal connector
DMI3
FDI
Socket
LGA1151
6th/7th Gen
Intel®
Core i7/i5/i3
Processor
(Skylake-S)
Intel®
Q170 non-ECC
PCH
LPC1
Pin-header
(optional)
SCDB-3291 (TPM 1.2)
SCDB-3292 (TPM 2.0)
LPC I/F
TPM 1.2/ 2.0
Infineon SLB9660/
SLB9665
LPC1
Pin-header
PCIe to
PCI Bridge
HD Audio
ALC269
Line-out/ Line-in/MIC-in
Amplifier
AUDIO1
Phone jacks
SPKR1,SPKL2
1x2-pin wafer conn.
Realtek
Anti-Crash Technology (ACT)
•BIOS Monitoring
•BIOS Recovery Automatically
•BIOS & MCU Flash Synchronous Upgrade
ACT Block Diagram
System BIOS
Flash
BIOS ACT
RS232
UART TTL level (COM1)
SPI
SPI
Embedded
Board
External Flash
MCU
PIC32MX220F032C

- 12 -
4
1
NOCOMPONENT
NOCOMPONENT
143
1442
78
287
288
145
146 222
77
221
143
144
2
78
287
288
145
146 222
77
221
143
1442
78
287
288
145
146 222
77
221
143
1442
78
287
288
145
146 222
77
221
1 2
1
1
1 2
15 16
BIOS Flash MCU External Flash
•BIOS Flash: Master ROM for BIOS
•MCU External Flash: Slave ROM for backup BIOS
The motherboard supports Anti-Crash Technology (ACT) for automatical
system BIOS recovering. If problem is detected on the BIOS ash, then the
recovery process will automatically start to load the backup BIOS from the
MCU external ash (slave ROM) to prevent system crash.
When a new version of BIOS is available and you want to update both the
master and slave ROMs with the new BIOS, please contact ARBOR for
technical support.
