Arbor Technology ITX-i92QA User manual

ITX-i92QA
10th Gen Intel®Xeon W/ Core™ Processor
Mini-ITX motherboard
User Manual
Version 1.0
2023.03

Revision History
Version Date Description
1.0 2023.03 Initial release

- i -
Preface iii
Copyright Notice................................................................iii
Declaration of Conformity ................................................iii
CE..........................................................................................iii
FCC Class B.........................................................................iii
About This User’s Manual ...........................................v
Warning .........................................................................v
Replacing the Lithium Battery.....................................v
Technical Support ........................................................v
Warranty .............................................................................vi
Environmental Protection Announcement................vi
Chapter 1 - Introduction 1
1.1 The Product..................................................................2
1.2 About This Manual.......................................................2
1.3 Specifications ..............................................................3
1.4 Inside the Package ......................................................4
Chapter 2 - Board Overview 7
2.1 Motherboard Internal Diagram - Top Side .................8
2.2 Jumper and Connector ................................................9
2.3 Dimensions .................................................................10
Chapter 3 - Installation & Maintenance 11
3.1 Jumpers & Connectors Quick Reference.................12
3.2 Jumpers & Connectors Location ..............................13
3.2 Connectors and Headers ...........................................14
Contents

- ii -
Chapter 4 - BIOS 20
4. Introducing BIOS ..........................................................21
4.1 Entering Setup ...........................................................21
4.2 BIOS Menu Screen .....................................................22
4.3 Function Keys.............................................................22
4.4 Menu Bars ...................................................................22
4.6 Main Menu ...................................................................23
4.7 Advanced Menu ..........................................................24
4.8 Chipset .......................................................................38
4.8.1 PCI Express Conguration ...............................41
4.8.2 SATA Conguration ..........................................41
4.8.3 USB Conguration ............................................41
4.9 Security ......................................................................42
4.10 Boot ..........................................................................43
4.11 Save & Exit ................................................................44
Content

- iii -
Preface
Copyright Notice
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
This product has passed the CE test for environmental specications. Test
conditions for passing included the equipment being operated within an
industrial enclosure. In order to protect the product from being damaged by
ESD (Electrostatic Discharge) and EMI leakage, we strongly recommend the
use of CE-compliant industrial enclosure products.
Warning
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
FCC Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:

- iv -
Preface
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including interference
that may cause undesired operation.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
ARBOR Technology Corp. certies that all components in its products are
in compliance and conform to the European Union’s Restriction of Use of
Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive
2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main
purpose of the directive is to prohibit the use of lead, mercury, cadmium,
hexavalent chromium, polybrominated biphenyls (PBB), and polybrominated
diphenyl ethers (PBDE) in electrical and electronic products. Member states of
the EU are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not
contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that
exceed a maximum concentration value of 0.1% by weight or for cadmium
exceed 0.01% by weight, per homogenous material. Homogenous
material is dened as a substance or mixture of substances with uniform
composition (such as solders, resins, plating, etc.). Lead-free solder is used for all
terminations (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
To minimize the environmental impact and take more responsibility to the
earth we live, Arbor hereby conrms all products comply with the restriction

- v -
Preface
of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH
--Registration, Evaluation, Authorization, and Restriction of Chemicals)
regulated by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)
About This User’s Manual
This user’s manual provides general information and installation instructions
about the product. This User’s Manual is intended for experienced users and
integrators with hardware knowledge of personal computers. If you are not
sure about any description in this booklet. Please consult your vendor before
further handling.
Warning
Single Board Computers and their components contain very delicate
Integrated Circuits (IC). To protect the Single Board Computer and its
components against damage from static electricity, you should always follow
the following precautions when handling it :
1. Disconnect your Single Board Computer from the power source when you
want to work on the inside.
2. Hold the board by the edges and try not to touch the IC chips, leads or
circuitry.
3. Use a grounded wrist strap when handling computer components.
4. Place components on a grounded antistatic pad or on the bag that comes
with the Single Board Computer, whenever components are separated
from the system.
Replacing the Lithium Battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery type
recommended by the manufacturer.
Do not throw lithium batteries into the trash-can. It must be disposed of in
accordance with local regulations concerning special waste.
Technical Support
If you have any technical di󰀩culties, please do not hesitate to call or e-mail our
customer service.
https://www.arbor-technology.com
E-mail:[e-mail]

Preface
Warranty
This product is warranted to be in good working order for a period of two years
from the date of purchase. Should this product fail to be in good working order
at any time during this period, we will, at our option, replace or repair it at no
additional charge except as set forth in the following terms. This warranty does
not apply to products damaged by misuse, modications, accident or disaster.
Vendor assumes no liability for any damages, lost prots, lost savings or any
other incidental or consequential damage resulting from the use, misuse of,
or inability to use this product. Vendor will not be liable for any claim made by
any other related party.
Vendors disclaim all other warranties, either expressed or implied, including
but not limited to implied warranties of merchantability and tness for a
particular purpose, with respect to the hardware, the accompanying product’s
manual(s) and written materials, and any accompanying hardware. This limited
warranty gives you specic legal rights.
Return authorization must be obtained from the vendor before returned
merchandise will be accepted. Authorization can be obtained by calling or
faxing the vendor and requesting a Return Merchandise Authorization (RMA)
number. Returned goods should always be accompanied by a clear problem
description.
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize
pollution and ensure environment protection of mother earth, please recycle.

- 1 -
Introduction
1Chapter 1
Introduction

- 2 -
Introduction
1.2 About This Manual
This user’s manual provides general information and installation instructions
about the product. This user’s manual is intended for experienced users and
integrators with hardware knowledge of personal computers. If you are not
sure about any description in this booklet. Please consult your vendor before
further handling.
1.1 The Product
The ITX-i92QA is a ITX form factor board of 170 mm x 210 mm to o󰀨er fast-
to-market solutions with a full lineup of di󰀨erent form factors. Support Intel®
10th Generation Xeon W/ Core i3/ i5/ i7/ i9 processors and integrated Intel®
Graphics chipset, bringing dual HDMI for dual monitors.
For system conguration, the board is supported by AMI UEFI BIOS. ITX-
i92QA is an ideal choice for some demanding industrial control and data com-
munications by its signicant processing performance, Intel Xeon W Server
Processors and these features:
• Supports Intel®LGA1200 10th Gen. Xeon W/ Core i3/ i5/ i7/ i9
Processor
• 6 x Gigabit Ethernet ports
• 4 x Serial ATA ports and 2 x M.2 M key sockets
• 2 x HDMI port
• 3 x RS-232 ports and two RS-232/422/485 ports
• 4 x USB 3.0 and two USB 2.0

- 3 -
Introduction
1.3 Specifications
System
CPU Support Intel®10th Generation Xeon W/
Core i3/ i5/ i7/ i9 processors in LGA1200 socket
Chipset Intel PCH W480E
Form Factor Wide Mini-ITX mother board
Memory 2 x DDR4 DIMM sockets; support ECC
BIOS AMI BIOS
Watchdog Timer 1~255 levels reset
I/O
USB Port 4 x USB 3.0/2.0 ports;
2 x USB 2.0 ports
Serial Port 3 x RS-232 ports;
2 x RS-232/422/485 ports
Expansion 1 x PCIex16 slot, support SCDB-3297;
1 x PCIex8 + 2x PCIex4 lanes Riser Card
Storage
4 x Serial ATA port with 600MB/s,
(supports RAID 0,1,5,10)
2 x M.2 2280 M-key
(Gen3x4, supports NVMe SSD)
LAN 5 x Intel i210AT GbE controllers,
1 x Intel i219LM PHY with iAMT
Display
Graphic Chipset Integrated Intel®UHD Graphics
Graphic Interface 2 x HDMI 2.0 port
OS Support
Windows 10 64-bit
Linex Ubuntu

- 4 -
Introduction
Mechanical & Environmental
Power Requirement Wide range DC input 9 ~ 36V, supports ATX 4-pin
Power Consumption 2.98A@12V (w/ i5-10500TE)
Operating Temp. 0 ~ 60°C (32 ~ 140ºF)
Operating Humidity 10 ~ 95% @ 60°C (non-condensing)
Dimensions (L x W) 170 x 210 mm (6.7” x 8.3”)
1.4 Inside the Package
Before you begin installing your single board, please make sure that the
following materials have been shipped:
1 x ITX-i92QA Mini-ITX industrial motherboard
1 x Quick Installation Guide
If any of the above items is damaged or missing, contact your vendor
immediately.
Driver Installation
To install the drivers, please visit our website at www.arbor-technology.com
and download the driver pack from the product page. If you need login access,
please contact your local ARBOR sales representative.

- 5 -
Introduction
1.5 Rear IO Diagram
USB 3.0 Ports LAN Ports
HDMI Ports

- 6 -
This page is intentionally left blank.

- 7 -
Board Overview
2Chapter 2
Board Overview

- 8 -
Board Overview
2.1 Motherboard Internal Diagram - Top Side
JBIOS1
DGP1
JFRT1
DIMM2
DIMM1
HDMIUSB2
HDMIUSB1
PWR1PWR2
BZ1 USB1
JBIOSROM1
JATMODE1
COM1 COM2 COM3 COM4 COM5
PWROUT1
PWROUT3 PWROUT2
PWROUT4
FNPWR1
SYSFAN1
CPUFAN1
SATA1
SATA3
SATA2SATA4
NGFF2
NGFF1
⑲SATAPWR 1
⑳SATAPWR 2
①SYSFAN1
②CPUFAN1
③PWR1
④PWR2
⑥FNPWR1
⑩COM4
⑪COM5
➋JATMODE1
⑤JFRT1
➊JME1
⑮SATA 1
⑰SATA 3
⑭PCIE1
⑬NGFF1
⑫NGFF2
⑯SATA2
⑱SATA4
⑦COM1~5
⑧COM1~5
⑨COM1~5
SATAPWR 3
21
SATAPWR 4
22
USB1
23

- 9 -
Board Overview
2.2 Jumper and Connector
Jumper
P/N Name Description
➊JME Clear CMOS Jumper 2-pin Block
➋JATMODE1 AT/ATX Type Selection 2-pin Block
Connector
P/N Name
①SYSFAN System Fan Connector
②CPUFAN CPU Fan Connector
③PWR1 DCIN 9~36V Power input Connector
④PWR2 DCIN 9~36V Power input Connector
⑤JFRT1 Switches and Indicators
⑥FNPWR1 FRONT PANEL power connector
⑦COM1~5 RS232/RS422/RS485 Serial Port: COM1, 2
RS232 Serial Port: COM3-5
⑧NGFF2 M.2 M KEY PCI-E CONNECTOR 2
⑨NGFF1 M.2 M KEY PCI-E CONNECTOR 1
⑩PCIE1 PCI-E x16 SLOT
⑪SATA 1/2/3/4 Serial ATA connector Channel 0~3
⑫SATAPWR 1~4 Serial ATA power connector 1~4
⑬USB1 USB2.0 HUB port 1-2

- 10 -
Board Overview
2.3 Dimensions
170
210
6
44.9
176.98
6.35
19
46
72
94
116
163.83
Unit: mm

- 11 -
Installation & Maintenance
3Chapter 3
Hardware
Installation

- 12 -
Installation & Maintenance
3.1 Jumpers & Connectors Quick Reference
Jumper
P/N Name Description
➊JME Clear CMOS Jumper 2-pin Block
➋JATMODE1 AT/ATX Type Selection 2-pin Block
Connector
P/N Name
①SYSFAN System Fan Connector
②CPUFAN CPU Fan Connector
③PWR1 DCIN 9~36V Power input Connector
④PWR2 DCIN 9~36V Power input Connector
⑤JFRT1 Switches and Indicators
⑥FNPWR1 FRONT PANEL power connector
⑦~⑪COM1~5 RS232/RS422/RS485 Serial Port: COM1, 2
RS232 Serial Port: COM3-5
⑫NGFF2 M.2 M KEY PCI-E CONNECTOR 2
⑬NGFF1 M.2 M KEY PCI-E CONNECTOR 1
⑭PCIE1 PCI-E x16 SLOT
⑮⑯⑰⑱SATA
1/2/3/4
Serial ATA connector Channel 0~3
⑲⑳
21 22
SATA-
PWR 1~4
Serial ATA power connector 1~4
23
USB1 USB2.0 HUB port 1-2
