Arbor Technology EmCORE-i55M0 User manual

- 1 -
4041055000120P
Copyright®2011 All Rights Reserved.
Quick Installation Guide
Version 1.2
If you have any technical difculties, please consult the user’s manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
nd out the answer.
http://www.arbor.com.tw
E-mail: [e-mail]
♦ Technical Support
EmCORE-i55M0
3.5" Compact Board
Form Factor
3.5"Compact Board
Video
Dual Channels 24-bit
LVDS/ Analog RGB /
DisplayPort
I/O
CFast/ SATA/ USB/ COM
CPU
Socket-G rPGA988A
supports Intel®i7-620M/
i5-520M/ Celeron P4500
Processor
LAN
Intel
®
82583V PCIe
Gigabit Ethernet
Audio
Realtek ALC662 HD Audio
CODEC, Line-in/ Line-out/
Mic-in
Chipset
Intel®HM55
Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.

- 2 -
Ordering Information
EmCORE-i55M0 Socket-G rPGA988 for Intel® i7-620M 2.66GHz/ i5-520M
2.40GHz/ Celeron P4500 1.86GHz 3.5” Compact Board
FCDB-1424 DisplayPort daughter board
FCDB-349R Digital IO daughter board
CBK-12-57M0-00
Cable Kit
2 x USB cables
1 x Audio cable
1 x PS/2 KB/MS Y-cable
2 x SATA cables
1 x VGA cable
1 x GbE Ethernet cable
4 x COM port cables
Packing List
Before you begin installing your Compact Board, please make sure that the following
materials have been shipped:
1 x EmCORE-i55M0 3.5" Compact Board with heatsink
1 x Driver CD
1 x Quick Installation Guide
If any of the above items is damaged or missing, contact your vendor immediately.

- 3 -
The Installation Paths of CD Driver
Windows XP
Driver Path
Management Engine \ME
CHIPSET \CHIPSET\INTEL\INF 9.11
NET Framework \NET Framework
VGA \GRAPHICS\WINXP_32_14425
\GRAPHICS\WINXP_64_14425
LAN \ETHERNET\INTEL\82583V\32
\ETHERNET\INTEL\82583V\64
AUDIO \AUDIO\REALTEK_HD\XP_WDM_R255
Windows 7
Driver Path
Management Engine \ME
CHIPSET \CHIPSET\INTEL\INF 9.11
VGA \GRAPHICS\Win7_32_15179
\GRAPHICS\Win7_64_15179
LAN \ETHERNET\INTEL\82583V\32
\ETHERNET\INTEL\82583V\64
AUDIO \AUDIO\REALTEK_HD\Win7_R255
Note:
Before install the Management Engine driver, please copy the
MEI_ALLOS_6.1.0.1042_PV.exe into a writable storage device and then
execute the driver from the storage device.

- 4 -
Form Factor 3.5" Compact Board
CPU Socket-G rPGA988A supports Intel® i7-620M at 2.66GHz/
i5-520M at 2.40GHz/ Celeron P4500 at 1.86GHz Processor
Chipset Intel® PCH HM55
System Memory 1 x 204-pin SO-DIMM socket supporting up to 4GB DDR3
1066/800MHz SDRAM (Bottom side)
Display
Integrated Intel® HD Graphics Controller fth generation
graphic core supporting 24-bit dual channels LVDS/
DisplayPort/ Analog RGB
Ethernet 1 x Intel® 82583V PCIe Gigabit Ethernet controller
I/O Chips Fintek F71869ED
BIOS AMI PnP Flash BIOS
Audio Realtek ALC662 HD Audio CODEC, Mic-in/ Line-in/ Line-out
Storage 2 x Serial ATA ports with 300MB/s HDD transfer rate
1 x CFast socket
Serial Port 4 x COM ports (COM1, COM3, COM4: RS-232,
COM2: RS-232/422/485 selectable)
Keyboard & Mouse One 6-pin wafer connector (PS/2 interface Keyboard and
Mouse via cable)
Universal Serial Bus 4 x USB 2.0 ports
Expansion Interface LPC interface connector
Operation Temp. -20oC ~ 70oC (-4oF ~ 158oF)
Watchdog Timer 1~255 levels reset
Dimension (L x W) 146 x 102 mm (5.7" x 4.0")
Specications

- 5 -
Board Dimensions
Ø
3.20
146.00
95.20
101.96
3.38
29.40
9.25
8.84
142.77
36.09
Unit: mm

- 6 -
Ø
3.20
146.00
95.20
101.96
3.38
29.40
9.25
8.84
142.77
36.09

- 7 -
Jumpers/ Connectors Quick Reference
Jumpers
Label Function
JPWR1 AT/ATX Power Mode Selection
JBAT1 Clear CMOS Setting
JRS1 COM2 RS-232 / 422 / 485 Selection
JVLCD1 LCD Voltage Selection
JV1 COM1 pin-1 signal setting
Connectors
Label Function
INV1 LCD Inverter Connector
LVDS1 LVDS LCD Connector
DP1 DisplayPort Connector
LPC1 Low Pin Count Connector (bottom side)
12VIN1 Aux. ATX +12V Power Connector
AUDIO1 Audio Connector
JFRT1 Switches and Indicators
CFAST1 CFast socket (bottom side)
DIMM1 DDR3 SO-DIMM Socket (bottom side)
COM1 ~ COM4 Serial Port Connectors
LAN1 Ethernet Connector
JCON1 RS-422/485 Output Connector
KBMS1 Keyboard & Mouse Connector
CPUF1 Fan Power Connector
CRT1 Analog RGB Connector
SATA1~2 Serial ATA Connectors
USB1~2 USB Port Connectors
BAT2 External Battery Connector (Optional)
SMBUS1 External SMBus Connector

- 8 -
Jumpers Location
PC1 S7 S1PC17
1
JPWR1 JVLCD1 JBAT1
Intel PCH
HM55
JV1
rPGA-989
1
1
1
1
1
1
3 42
JRS1
5
12
56

- 9 -
Connectors Location
14
1
DIMM1
PC1 S7 S1PC17
3
2
4
12VIN1
JFRT1
S ATA 2
S ATA 1
2
910
LAN1
1
USB1
USB2
INV1 LVDS1
COM1
COM2
COM3
COM4
AUDIO1
SMBUS1
CPUF1
KBMS1
CRT1
Intel PCH
HM55
JCON1
rPGA-989
11 1
1
1
1
1
1
1
1
1
11
1
2
910
1
20
2
29
20
21
9 10
LPC1
8 9
DP1
21
9 10
21
9 10
21
9 10
2
1
910
2
1
910
6 7
9
1
9
1
2
10
2
10
10 11
12
13
15
16
17
18
19
20
21
27
25
24
23
22
29
26
CFAST1
14
1
BAT2
28

- 10 -
Jumpers Connectors
JBAT1: Clear CMOS Setting (1)
Connector type: 2.54mm pitch 1x3-pin headers.
Pin Mode
1-2 Keep CMOS (Default)
23 1
2-3 Clear CMOS
23 1
JV1: COM1 Pin-1 Signal Selection (2)
The voltage of pin-1 could be selected by JV1 in +5V
or DCD.
Connector type: 2.54mm pitch 1x3-pin headers.
Pin Voltage
1-2 +5V
23 1
2-3 DCD (Default)
23 1
JRS1: COM2 RS-232/422/485 Selection (5)
Connector type: 2.00mm pitch 2x3-pin headers.
Mode RS-232
(Default) RS-422 RS-485
1-2 Short Open Open
3-4 Open Short Open
5-6 Open Open Short
65
21
65
21
65
21
LVDS1: LVDS LCD Connector (7)
Connector type: ACES 1.25mm 87209-304*-06
connector and supports 24-bit dual channels.
Pin Desc. Pin Desc.
1
2930
2
2 VDD 1 VDD
4 TX2CLK+ 3 TX1CLK+
6 TX2CLK- 5 TX1CLK-
8 GND 7 GND
10 TX2D0+ 9 TX1D0+
12 TX2D0- 11 TX1D0-
14 GND 13 GND
16 TX2D1+ 15 TX1D1+
18 TX2D1- 17 TX1D1-
20 GND 19 GND
22 TX2D2+ 21 TX1D2+
24 TX2D2- 23 TX1D2-
26 GND 25 GND
28 TX2D3+ 27 TX1D3+
30 TX2D3- 29 TX1D3-
JPWR1: AT/ATX Power Mode Selection (4)
Connector type: 2.00mm pitch 1x3-pin headers.
Pin 1-2 Power Mode Selection
1-2 ATX Mode (Default)
23 1
2-3 AT Mode
23 1
INV1: LCD Inverter Connector (6)
Connector type: 2.00mm pitch 1x5-pin box wafer
connector.
Pin Description
1
2
3
4
5
1 +12V
2 GND
3 Backlight on/off
4 Brightness control
5 GND
JVLCD1: LCD Panel Voltage Selection (3)
The voltage of LCD panel could be selected by
JVLCD1 in +5V or +3.3V.
Connector type: 2.54mm pitch 1x3-pin headers.
Pin Voltage
1-2 +5V
23 1
2-3 +3.3V (Default)
23 1
DP1: DisplayPort Connector (8)
Connector type: ACES 1.25mm 88266-200X1
Pin Desc. Pin Desc.
1
20
1 LANE_0P 11 LANE_3N
2 LANE_0N 12 GND
3 GND 13 CONF1
4 LANE_1P 14 CONF2
5 LANE_1N 15 AUXP
6 GND 16 AUXN
7 LANE_2P 17 GND
8 LANE_2N 18 HPD
9 GND 19 RTN_PWR
10 LANE_3P 20 PWR(3.3V)

- 11 -
12VIN1: ATX +12V Connector (11)
PWR1 supplies ATX +12V (Vcore).
Pin Description Pin Description
24
13
2 GND 4 +12V
1 GND 3 +12V
CPUF1: Fan Power Connector (10)
CPUF1 is a 3-pin headers for the CPU fan. The fan
must be a +12V fan.
Pin Description
1
2
3
1 GND
2+12V
3 FAN_Detect
AUDIO1: Audio Connector (12)
Connector type: 2.00mm pitch 2x5-pin box headers.
Pin Description Pin Description
9 10
1 2
1Line Left In 2Line Right In
3GND 4 GND
5MIC_L 6MIC_R
7 GND 8 GND
9Line-out Left 10 Line-out Right
JFRT1: Switches and Indicators (13)
It provides connectors for system indicators that
provides light indication of the computer activities
and switches to change the computer status.
Connector type: 2.00mm pitch 2x5-pin headers.
Pin Description Pin Description
109
1 2
1RESET+ 2RESET-
3 POWER_LED+ 4POWER_LED-
5HDD_LED+ 6HDD_LED-
7SPEAKER+ 8SPEAKER-
9PSON+ 10 PSON-
LPC1: Low Pin Count Connector (9)
Connector type: CVILUX 0.5mm CF20141U0*0-LF
connector
Pin Desc. Pin Desc.
14
1
1LPC_D0 8LPC_RST#
2LPC_D1 9 GND
3 LPC_D2 10 LPC_CLK_33Mhz
4LPC_D3 11 GND
5 GND 12 GND
6LPC_FRAME#13 +3.3V
7 SERIRQ 14 +3.3V
COM1~4: Serial Port Connectors (16, 17, 18, 19)
Connector type: 2.00mm pitch 2x5-pin headers.
Pin Desc. Pin Desc.
109
1 2
1DCD# 2RXD
3 TXD 4DTR#
5 GND 6 DSR#
7RTS# 8CTS#
9RI# 10 N/C
DIMM1 : SO-DIMM Socket (15, bottom side)
DIMM1
CFAST1: CFAST Socket (14, bottom side)
Pin Desc.
PC1 S7 S1PC17
S1 SGND1
S2 TXP
S3 TXN
S4 SGND2
S5 RXN
S6 RXP
S7 SGND
PC1 CDI
PC2 GND
PC3 TBD
PC4 TBD
PC5 TBD
PC6 TBD
PC7 GND
PC8 LED1
PC9 LED2
PC10 IO1
PC11 IO2
PC12 IO3
PC13 3.3V
PC14 3.3V
PC15 GND
PC16 GND
PC17 CD0

- 12 -
CRT1: Analog RGB Connector (24)
Connector type: 2.00mm pitch 2x5-pin headers.
Pin Desc. Pin Desc.
109
1 2
1 RED 2 GND
3GREEN 4 GND
5BLUE 6 GND
7H_SYNC 8 GND
9V_SYNC 10 CRT_DET
USB1~2: USB Connectors (22, 23)
Connector type: 2.00mm pitch 2x5-pin headers.
Pin Desc. Pin Desc.
109
1 2
1+5V 2+5V
3 USBD- 4USBD-
5USBD+ 6USBD+
7 GND 8 GND
9 GND 10 N/C (Key)
SATA1~2: Serial ATA Connectors (20, 21)
High speed transfer rates (300MB/s).
Pin Desc.
1
7
1 GND
2TX+
3 TX-
4 GND
5RX-
6RX+
7 GND
KBMS1: Keyboard & Mouse Connector (25)
Connector type: 2.0mm pitch 1x6-pin box wafer
connector.
Pin Description
1
2
3
4
5
6
1KB_DAT
2 GND
3 MS_DAT
4KB_CLK
5 VCC
6MS_CLK
LAN1: GbE Connector (27)
Connector type: 2.00mm pitch 2x5-pin headers.
Pin Desc. Pin Desc.
109
1 2
1TX+/ MDI0+ 2TX/ MDI0-
3 RX+/ MDI1+ 4N/C/ MDI2+
5N/C/ MDI2- 6RX-/ MDI1-
7N/C/ MDI3+ 8N/C/ MDI3-
9N/C 10 N/C (Key)
JCON1: RS-422/485 Output Connector (26)
Connector type: 2.00mm pitch 1x4-pin box wafer
connector.
Pin RS-422 RS-485
1
2
3
4
1TX+ DATA+
2TX- DATA-
3 RX+ N/C
4RX- N/C
SMBUS1: External SMBus Connector (29)
Connector type: 2.54mm pitch 1x3-pin box wafer
connector.
Pin Description
1
2
3
1 Data
2 Clock
3GND
BAT2: External Battery connector (28, Optional)
Connector type: 1.25mm pitch 1x2-pin wafer
connector.
Pin Description
1
1+3.3V
2 GND
