Arbor Technology ITX-i87H0 User manual

- 1 -
ITX-i87H0
Mini-ITX Industrial Motherboard
Quick Installation Guide
Version 1.0
CPU
Intel®4th Generation
CoreTM Family
processors
Form Factor
Mini-ITX
I/O
SATA/ USB 2.0/ USB3.0/
Video
HDMI/LVDS/DisplayPort
LAN
RTL8111G Gigabit
Ethernet controller
Audio
Realtek ALC662, Mic-in/
Line-out
Copyright®All Rights Reserved.
4041870001100P
♦ Technical Support
If you have any technical difculties, please consult the user’s manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Contact our customer service at the following addresses if your problem persists.
http://www.arbor.com.tw
E-mail: [e-mail]
♦ Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions : (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

- 2 -
Packing List
Before you begin to install your single board, please make sure that the following
materials have been shipped:
1 x ITX-i87H0 Mini-ITX industrial motherboard
1 x Driver CD
1 x Quick Installation Guide
1 x I/O bracket
1 x DC 2.5 Jack to 7.4 Plug Cable
If any of the above items is damaged or missing, contact your vendor immediately.
Ordering Information
ITX-i87H0 Intel® Embedded Mini-ITX Motherboard
CPF-67Q0-C1 CPU Cooling Fan for LGA1150/ 1155/ 1156 CPU
CBK-07-87H0-00
Cable kit
2 x Two Ports USB2.0 cables
1 x One Port USB2.0 cable
1 x Two Ports USB3.0 cable
1 x Two Ports SATA Power cable
2 x SATA cables
Optional Accessories

- 3 -
The Installation Paths of CD Driver
Windows 8 & 8.1
Driver Path
CHIPSET \ITX-i87H0\Chipset\Win 8.1\32bit
\ITX-i87H0\Chipset\Win 8.1\64bit
GRAPHIC \ITX-i87H0\\Graphic\Win 8.1\win32_1536b
\ITX-i87H0\Graphic\Win 8.1\Win64_153117
ETHERNET \ITX-i87H0\Ethernet\Win 8.1
AUDIO \ITX-i87H0\AUDIO\Win 8.1\32bit
\ITX-i87H0\AUDIO\Win 8.1\64bit
ME \ITX-i87H0\ME\Win 8\32bits_ME9.0_5M_V9.0.2.1345
\ITX-i87H0\ME\Win 8\64bits\MEI_Win8.1_5.0M_9.5.15.1730_PV
CIR \ITX-i87H0\CIR\Win 8
Windows 7
Driver Path
CHIPSET \ITX-i87H0\Chipset\Win 7\32bit
\ITX-i87H0\Chipset\Win 7\64bit
GRAPHIC \ITX-i87H0\Graphic\Win 7\win32_1536b
\ITX-i87H0\Graphic\Win 7\Win64_153117
ETHERNET \ITX-i87H0\Ethernet\Win 7
AUDIO \ITX-i87H0\AUDIO\Win 7\32bit
\ITX-i87H0\AUDIO\Win 7\64bit
ME \ITX-i87H0\ME\Win 7\32bits_ME9.0_5M_V9.0.2.1345
\ITX-i87H0\ME\Win 7\WIN7 64bits
CIR \ITX-i87H0\CIR\Win 7
USB3.0 \ITX-i87H0\USB3.0\32bits_USB3_V2.5.0.19
\ITX-i87H0\USB3.0\64bits_USB_3.0_Win7_2.5.1.28

- 4 -
Specications
Form Factor Mini-ITX industrial motherboard
CPU Intel® 4th Generation CoreTM Family processors in
LGA1150 socket
Chipset Intel® PCH H87
System Memory 2 x 204-pin DDR3 SO-DIMM socket supporting
1600/1333 MHz SDRAM up to 16GB
Graphic Chipset Integrated Intel®Gen 7 Graphics
Graphic Interface
1 x HDMI_OUT port
1 x HDMI_IN port
1 x Displayport
LCD: Daul Channels 24-bit LVDS
Ethernet 1 x Realtek RTL8111G Gigabit Ethernet controllers
BIOS AMI BIOS with 64Mb SPI Flash ROM
Audio Realtek ALC662 + ALC113 HD Audio Codec, Mic-in/
Line-out
Storage 2 x Serial ATA ports with 600MB/s HDD transfer rate
1 x mSATA socket
USB 5 x USB 2.0 ports
6 x USB 3.0/2.0 ports
Expansion Bus 1 x Mini card socket
Power Requirement 19V DC Jack
Operation Temp. 0 ~ 60°C (32 ~ 140°F) w/ cooling fan
Operating Humidity 10 ~ 60% @ 60°C (non-condensing)
Dimension (L xW) 170 x 170 mm (6.7” x 6.7”)
Recommended CPU List:
Intel® Core™ i7-4770S quad-core 3.1GHz / i7-4790S quad-core 3.2GHz
Intel® Core™ i7-4770TE quad-core 2.3GHz
Intel® Core™ i5-4570S quad-core 2.9GHz / i5-4590S quad-core 3.0GHz
Intel® Core™ i5-4570TE dual-core 2.7GHz
Intel® Core™ i3-4330 dual-core 3.6GHz / i3-4350T dual-core 3.1GHz
Intel® Core™ i3-4330TE dual-core 2.4GHz
Intel® Pentium® Processor G3420 dual-core 3.2GHz
Intel® Pentium® Processor G3320TE dual-core 2.3GHz
Intel®Celeron® Processor G1820 dual-core 2.7GHz
Intel®Celeron® Processor G1820TE dual-core 2.2GHz

- 5 -
Board Dimensions
Unit:mm

- 6 -
Jumpers/Connectors Quick Reference
Jumpers
Label Function
❶ LCD_SEL LCD Resolution Selection
❷ CLR_CMOS Clear CMOS Setting
❸ ME_UNLOCK
ME unlock header
Connectors
Label Function
① SATA1,2 Serial ATA connectors
②SYS_FAN
Fan Power Connector
③CPU_FAN
CPU Fan Power Connector
④CIR
Consumer infrared header
⑤ F_PANEL Front panel switch/LED
header
⑥ LVDS LVDS connector
⑦MON_SW
LVDS brightness switch
header
⑧ DISP_BRT LVDS brightness control
header
⑨BZ
Buzzer header
⑩USB_CR_CAM
10-pin USB 2.0 header
⑪F_USB
Front Panel USB 2.0 header
⑫DMIC
Digital Microphone header
⑬SPKR
2 Channel audio speaker
header
⑭F_AUDIO
Front panel audio header
⑮MIC
Microphone connector
⑯LINEOUT
Line out connector
⑰LAN
Ethernet Connector
⑱ PCIE1 mSATA Socket
⑲ PCIE2 Mini-card socket
⑳CASE
Chassis Intrusion detect
header
Label Function
21
USB3R1,2 USB 3.0 Connector
22
DP Displayport
23
HDMI-OUT HDMI Output Connector
24
HDMI-IN HDMI Input Connector
25
DC_IN
DC IN Power Connectors
26
SATA_PWR SATA power connector
27
USB3F
Front USB 3.0 header
28
SO DIMM1,2
204-pin DDR3 SDRAM SO-
DIMMs
29
USB_TP 5-pin USB 2.0 header

- 7 -
Jumpers & Connectors Locations
ITX-i87H0
LGA1150
CASE
ME_UNLOCK
SATA_PWR
USB_TP
F_AUDIO
USB_CR_CAMMON_SW
F_PANEL
F_USB
LCD_SEL
SPKR
DC_IN
LINEOUT
MIC
LAN
BZ
DISP_BRT
PCH
USB3R1/2
CLR_CMOS
DMIC
HDMI_IN DP
SODIMM1/2
PCIE1 PCIE2
2
1
SATA1/2
1
SYS_FAN
2
CPU_FAN
3
CIR
4
7
8
9
6LVDS
5
10
11
15
16
20
19
21
18
17
22
HDMI_OUT
23
24
25
26
28
29
USB3F
27
12
13
14
3

- 8 -
Jumpers
Jumper Settings
The jumper is “short” (closed) when the jumper cap is
placed on pins. If not, that means the jumper is “open.”
Pin open Pin short
(closed)
Pin 2-3 short
(closed)
Pin 1-2 short
(closed)
Connectors
❷ CLR_CMOS: Clear CMOS Setting
Connector type: 2.54mm pitch 1x3-pin headers.
Pin Mode
1-2 Keep CMOS (Default)
23 1
2-3 Clear CMOS
23 1
❸ME_UNLOCK: ME unlock header
Connector Type: 2.54mm pitch 1x2-pin headers.
Pin Description
Short Unlock
1 2
Open Lock
1 2
❶ LCD_SEL: LCD Resolution Selection
When your panel connects to LVDS, please check
LCD Select header setting rst.
Connector type: 2.54mm pitch 2x4-pin headers.
Pin Voltage
None BOE 23.6” HM236WU1-400
1 2
7 8
3-4
7-8 BOE 21.5” B3HT15F01-100
1 2
7 8
7-8 CMO 23.6 M236HGE-L20
1 2
7 8
3-4
5-6 CPT 21.5” CLAA215FA04
1 2
7 8
①SATA1&2: Serial ATA Connectors
The pin assignments
conform to the industry
standard.
②③SYS_FAN&CPU_FAN : Fan Power
Connector
Connector Type: 2.54mm pitch 1x4-pin headers.
Pin Description
1
4
1GND
2 +12V
3 FAN_Detect
4 Control
④CIR: Consumer Infrared Header
Connector Type: 2.54mm pitch 2x4-pin headers.
Pin Desc. Pin Desc.
1
7
2
8
1GND 2 N/C
3N/C 4 N/C
5 PWR +5V 6 PWR +5V
7CIR RX 8 N/C
⑤F_PANEL :Front panel switch/LED
header
A standard set of switch and LED headers for ATX or
Micro ATX cases
Connector Type:
2.54mm pitch 2x5-pin headers.
Pin Description PinDescription
1
9
2
10
1HD LED(+) 2MSG LED (+)
3HD LED(-) 4MSG LED (-)
5Reset Switch (-) 6Power Switch (+)
7Reset Switch (+) 8Power Switch (-)
9Reserved 10 N/C

- 9 -
⑥LVDS :LVDS Connector (40-Pin)
Connector Type: 0.5mm pitch 40-pin coaxial connector
Pin Assignment Pin Assignment
1
40
1ODD Lane3 + 21 NC
2ODD Lane3 - 22 Power +3.3V
3ODD Lane2 + 23 GND
4ODD Lane2 - 24 GND
5ODD Lane1 + 25 GND
6ODD Lane1 - 26 Dual Channels LVDS clock
7ODD Lane0 + 27 Dual Channels LVDS clock
8ODD Lane0 - 28 GND
9EVEN Lane3 + 29 GND
10 EVEN Lane3 - 30 GND
11 EVEN Lane2 + 31 EDlD Signal
12 EVEN Lane2 - 32 LCD backlight ON/OFF
13 EVEN Lane1 + 33 LCD backlight adjustment
14 EVEN Lane1 - 34 Dual Channels LVDS clock
15 EVEN Lane0 + 35 Dual Channels LVDS clock
16 EVEN Lane0 - 36 LCD backlight power +19V
17 GND 37 LCD backlight power +19V
18 Power +5V 38 LCD backlight power +19V
19 Power +5V 39 NC
20 Power +5V 40 EDlD Signal

- 10 -
⑦MON_SW: LVDS brightness switch
header
Connector Type: 2.54mm pitch 1x2-pin headers.
Pin Description
1 2
1LCD Backlight
2 GND
⑧DISP_BRT :Display brightness header
Connector Type: 2.00mm pitch 1x8-pin box headers.
Pin Description
1
8
1LCD BKL ON/OFF
2LCD BKL adjustment
3LCD BKL Power +19V
4LCD BKL Power +19V
5GND
6GND
7LCD BKL Increase
8LCD BKL decrease
⑨BZ:Buzzer header(Optional)
Connector Type: 2.54mm pitch 1x4-pin headers.
Pin Description 1
4
1+5V
2N/C
3N/C
4Signal
⑩USB_CR_CAM :
10-pin USB 2.0 header supports card reader and cam-
era or other USB 2.0 devices
Connector Type:
2.54mm pitch 2x5-pin headers.
Pin Description PinDescription
1
9
2
10
1+5V 2+5V
3USB Port A (-) 4USB Port B (-)
5USB Port A (+) 6USB Port B (+)
7GND 8GND
9N/C 10 N/C
⑪F_USB :
10-pin USB 2.0 header supports card reader and cam-
era or other USB 2.0 devices
Connector Type:
2.54mm pitch 2x5-pin headers.
Pin Description PinDescription
1
9
2
10
1+5V 2+5V
3USB Port A (-) 4USB Port B (-)
5USB Port A (+) 6USB Port B (+)
7GND 8GND
9N/C 10 N/C
⑫ DMIC: Digital MIC Header
Connector Type: 2.54mm pitch 1x5-pin headers.
Pin Description
1
5
1+3.3V
2 DMIC DATA
3 GND
4DMIC Clock
5N/C
⑬SPKR: Internal Speaker Header
Connector Type: 2.00mm pitch 1x4-pin headers.
Pin Description
1
4
1L_Channel-
2 L_Channel+
3 R_Channel+
4R_Channel-
⑭F_AUDIO: Front Panel Audio Header
The front panel audio header allows the user to
install auxiliary front-oriented microphone and line-out
ports for easier access. This header supports HD
audio by default.
Connector Type: 2.54mm pitch 2x5-pin headers.
Pin Desc. Pin Desc.
1
9
2
10
1FP_MIC_in 2 Analog_GND
3 MIC_Power 4 Presence#
5 FP_Right 6 Sense1_Return
7Sense_Send 8 N/C
9 FP_Left 10 Sense2_Return

- 11 -
⑮⑯MIC&LINE OUT: Microphone&Line-out
The pin assignments
conform to the industry
standard.
LINEOUT MIC
⑰LAN: Ethernet Connectors
The pin assignments conform to
the industry standard.
1 8
⑱PCIE1: mSATA socket (Full-size)
Connector type: Onboard 0.8mm-pitch 52-pin edge
card connector
The pin assignments conform to the industry standard.
⑲PCIE2:Mini-card socket (half-size)
Connector type: Onboard 0.8mm-pitch 52-pin edge
card connector
The pin assignments conform to the industry standard.
12
17
15
18
16
51 52
20
CASE: Chassis Intrusion detect header
Connector Type: 2.54mm pitch 1x2-pin headers.
Pin Description
Short Chassis cover is
removed
1 2
Open Chassis cover is
closed
1 2
21
USB3R1,2:USB3.0 port
The pin assignments
conform to the industry
standard.
22
DP:Displayport
Digital Audio/Video connector
The pin assignments
conform to the industry
standard.
23
HDMI_OUT: HDMI Output Connector
Connect the display device to the HDMI_OUT port
The pin assignments
conform to the industry
standard.
18
1
2
19
24
HDMI_IN: HDMI Input Connector
Connect other HDMI source to the HDMI_IN port
The pin assignments
conform to the industry
standard.
18
1
2
19
25
DC_IN: DC jack
Connector type: DC Φ7.4 Male connector
Inner Shell :19V DC
Outer Shell :GND

- 12 -
26
SATA_PWR: Serial ATA Power Connector
The pin assignments
conform to the industry
standard.
27
USB3F: Front USB 3.0 header
Connector Type: 2.00mm pitch 2x10-pin box wafer
connector
Pin Description PinDescription
20 N/C 1Power
19 Power 2USB 3 ICC Port1
SuperSpeed Rx−
18 USB 3 ICC Port2
SuperSpeed Rx+ 3USB 3 ICC Port1 SuperSpeed Rx+
17 USB 3 ICC Port2
SuperSpeed Rx+ 4GND
16 GND 5USB 3 ICC Port1
SuperSpeed Tx−
15 USB 3 ICC Port2
SuperSpeed Tx− 6USB 3 ICC Port1 SuperSpeed Tx+
14 USB 3 ICC Port2
SuperSpeed Tx+ 7GND
13 GND 8USB 3 ICC Port1 D−
12 USB 3 ICC Port2 D− 9USB 3 ICC Port1 D+
11 USB 3 ICC Port2 D+ 10 N/C
28
SO-DIMM1,2: SO-DIMM Connector
The pin assignments conform to the industry standard.
1
11
19
10
1
29
USB_TP: 5-pin USB 2.0 header
Connector Type: 2.54mm pitch 1x5-pin headers.
Pin Description
1
5
1+5V
2 USB-
3 USB+
4GND
5N/C
