Arbor Technology PBE-1000 User manual

- 1 -
Quick Installation Guide
Version 2.2
PBE-1000
ETX Evaluation Board
Form Factor
ETX Evaluation Board
I/O
PCI/ ISA/ USB/ IDE/
COM/ LPT/ FDD/ CF II
Video
LVDS/ CRT connectors
Ethernet
RJ-45 LAN Connector
Audio
Phone jack for Line-in/
Line-out, MIC-in
Copyright®2011 All Rights Reserved. 4041100001220P
Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
If you have any technical difculties, please consult the user’s manual rst at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
nd out the answer.
http://www.arbor.com.tw
E-mail: [e-mail]
♦ Technical Support

- 2 -
Form Factor ETX evaluation board in ATX form factor
I/O Controller WINBOND W83977
Audio Phone Jack for Line-in/ Line-out, Mic-in
IDE Interface 2 x IDE port connector
Serial Port 4 x Serial port connector
Parallel Port/ Floppy
1 x Parallel port connector
2 x Floppy connector (FDD1 by onboard Super I/O,
LPTFDD1 share with LPT1)
Keyboard / Mouse Standard PS/2 Keyboard and Mouse connector
Universal Serial Bus 4 x USB port connector
LCD LVDS connector
VGA CRT connector
DIO 8-bit Digital Input / 8-bit Digital Output
IrDA 1 x IrDA connector
Expansion Interface 3 x ISA slot, 1 x CF II (share with IDE interface), 4 x PCI slot
Operation Temp. 0ºC - 60ºC (32ºF ~ 140ºF)
Power Connector ATX and AT
Dimension (L x W) 305 x 210 mm (12.0” x 8.3”)
Specification
Ordering Information
PBE-1000 ATX form factor ETX evaluation board with POST,
secondary I/O, audio and ash disk socket
Cable Kit CBK-05-1000-00
Before you begin installing your single board, please make sure that the
following materials have been shipped:
Packing List
1 x PBE-1000 ETX evaluation board
1 x Quick Installation Guide

- 3 -
Jumpers/ Connectors Quick Reference
Label Function
JVLCD1 LCD Voltage Select
JRS1 COM2 RS-232/422/485 Select
JWDT1 Watchdog Timer Mode Select
JBLON1 LCD Panel Backlight Select
JBAT1 Clear CMOS
JDIAG1 IDE 100 or 33 mode Select
JCFD1 CF IDE1 mode Select (Master
or Slave)
JDOC1 DOC Base Address Select
Jumpers
Label Function
KBM1 PS/2 Keyboard and Mouse
Connector
COM1, 2,
3, 4
RS-232 Serial Port
Connector
VGA1 VGA Connector
LPT1 Parallel Port Connector
AUDIO Audio Connector
CON1 RS-422/485 Output
Connector
USB2 USB2~3 Connector
USB1LAN1 USB0~1 Connector
RJ-45 Connector
LVDS1 Dual Channel LVDS
Connector
SIR1 IrDA Connector
TV1 TV-Out Connector
INV1 LCD Inverter Connector
SYSF1 CPU Fan Power Connector
I2C1 I2C Connector
Connectors
JFRT1 Front Panel Connector
PSON1 Power Switch
RES1 Reset Switch
IDE1 Primary IDE Connector
IDE2 Secondary IDE Connector
ATP1 AT Power Connector
ATXP1 ATX Power Connector
FDD1,
LPTFDD1 Floppy Disk Drive Connector
PCI1~4 PCI Bus Slot
ISA1~3 ISA Bus Slot
CFD1 Compact Flash II Socket
DOC1 Disk On Chip Socket
DIO1 Digital I/O Connector
LED1,
LED2
Port 80 POST codes for
debug
ETX1~4 ETX Bus Connector

- 4 -
Board Dimension
305.00
Unit: mm
16.78124.46157.48
10-ø4.01
210.00
33.03 44.90132.07
124.46 16.51157.48
1.60
154.94 44.90
10.17

- 5 -
Jumpers & Connectors
LVDS1
COM2
JVLCD1
ISA3
CON1
JRS1
ISA2
ISA1
PCI3
JFRT1
PCI2
TV1
INV1 JWDT1
JBAT1
PSON1 RES1
CFD1
JCFD1
ATXP1 ATP1
IDE2 FDD1
IDE1
JDIAG1
LPTFDD1
DIO1
DOC1
LED1
LED2
JDOC1
COM3
COM4
LPT1
JBLON1
SYSF1
AUDIO1
ETX1 ETX2
ETX4ETX3
CRT, LVDS
COM1, COM2
LPT1/FDD2,
KB/MS
IDE1, IDE2
LAN1, Misc.
PCI Bus,
Audio, USBFS ISA Bus
VGA1
LAN1
USB1
SIR1
PCI1
COM1
USB2
PCI4
I2C1
KBM1
1
11
1
1
11
1
1
2
1
2
2
1
1
1
1 2
1 2
1
1
1
1
122
1
1
11 2
3 4
1 2
12

- 6 -
JDIAG1: IDE 100/ 33 Mode Select
Connector type: 2.54mm pitch 1x2 pin header.
Pin Setup Mode
1-2 Open Ultra DMA 33
1 2
1-2 Short (Default) Ultra DMA 100
1 2
Jumpers
JVLCD1: LCD Panel Voltage Select
The voltage of LCD panel could be selected by
JVLCD1 in +5V or +3.3V.
Connector type: 2.54mm pitch 1x3 pin header.
Pin Voltage
1-2 +5V
23 1
2-3 +3.3V (Default)
23 1
JBAT1: CMOS Setup
Connector type: 2.54mm pitch 1x3 pin header.
Pin Mode
1-2 Keep CMOS (Default)
23 1
2-3 Clear CMOS
23 1
JDOC1: DOC Base Address Select
Connector type: 2.00mm pitch 2x2 pin header.
Based Address 3-4 1-2
D800 Short Open
2
1
4
3
D000 (Default) Open Short
2
1
4
3
Disabled Open Open
2
1
4
3
JBLON1: LCD Panel Backlight Select
Connector type: 2.54mm pitch 1x3 pin header.
Pin Mode
1-2 Backlight on Hi Active
23 1
2-3 Backlight on Low Active
(Default)
23 1
JRS1: COM2 RS-232/422/485 Select
Connector type: 2.00mm pitch 2x3 pin header.
Mode RS-232
(Default) RS-422 RS-485
1-2 Short Open Open
3-4 Open Short Open
5-6 Open Open Short
65
2
1
65
2
1
65
2
1
JWDT1: WDT Mode Setup
Connector type: 2.54mm pitch 1x3 pin header.
Pin Mode
1-2 RST_SW (Default)
23 1
2-3 NMI
23 1
JCFD1: CF IDE1 mode Select (master or Slave)
Connector type: 2.54mm pitch 1x2 pin header.
Pin Mode
Short Master (Default)
1 2
Open Slave
1 2
Connectors
KBM1: PS/2 Keyboard & Mouse
Standard PS/2 Keyboard & Mouse connector
Connector type: double stack 6-pin mini DIN.
Pin Description
78
9
1112
10
Keyboard
(Purple)
12
3
56
4
Mouse
(Green)
1 KB Data
2 N/C
3 GND
4 +5V
5 KB Clock
6 N/C
7 MS Data
8 N/C
9 GND
10 +5V
11 MS Clock
12 N/C

- 7 -
Pin Desc. Pin Desc.
1
9
2
10
1 +5V 2 +5V
3 USBD- 4 USBD-
5 USBD+ 6 USBD+
7 GND 8 GND
9 GND 10 N/C (Key)
USB2: USB Connector
Connector type: 2.00m pitch 2x5 pin header.
LPT1: Parallel Port
Connector type: D-Sub 25-pin female.
SPP/EPP/ECP mode, shared with LPTFDD1.
COM2~4: RS-232 Connectors
Connector type: 2.00m pitch 2x5 box header.
Pin Desc. Pin Desc.
1 2
9 10
1 DCD# 2 RXD
3 TXD 4 DTR#
5 GND 6 DSR#
7 RTS# 8 CTS#
9 RI# 10 N/C
CON1: RS-422/485 Output Connector
Connector type: 2.00m pitch 1x4 box wafer
connector.
Pin RS-422 RS-485
1
2
3
4
1 TX+ DATA+
2 TX- DATA-
3 RX+ N/C
4 RX- N/C
COM1: RS-232 Connector
Connector type: D-Sub 9-pin male.
Pin Desc. Pin Desc.
1
5
9
6
1 DCD# 6 DSR#
2 RXD 7 RTS#
3 TXD 8 CTS#
4 DTR# 9 RI#
5 GND
VGA1: CRT Connector
Connector type: D-Sub 15-pin female.
Pin Desc. Pin Desc.
1
515
11
1 RED 9 N/C
2 GREEN 10 GND
3 BLUE 11 N/C
4 N/C 12 D-DATA
5 GND 13 H-SYNC
6 GND 14 V-SYNC
7 GND 15 D-DCLK
8 GND
LAN1, USB1: 1 x RJ-45 + 2 x USB
Connector type: RJ-45 + double stack USB type A
connector.
Pin Desc. Pin Desc.
1
13
14
25
1 STROBE 14 AFD
2 PTD0 15 ERROR
3 PTD1 16 INIT
4 PTD2 17 SLIN
5 PTD3 18 GND
6 PTD4 19 GND
7 PTD5 20 GND
8 PTD6 21 GND
9 PTD7 22 GND
10 ACK 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SELECT
AUDIO1: Audio Connector
The AUDIO1 is composed of Line in, Line out and
Microphone jacks.
Line_out Line_in MIC_IN
Pink: MIC
Blue: Line-In
Green: Line-Out
LED LED
LAN
USB
USB
8 7 6 5 4 3 2 1
1 2 3 4
1 2 3 4

- 8 -
SIR1: Infrared Connector
Connector type: 2.54mm pitch 1x5 pin header.
Pin Description
1
2
3
4
5
1 +5V
2 N/C
3 IRRX
4 GND
5 IRTX
INV1: LCD Inverter Connector
Connector type: 2.00m pitch 1x5 box wafer
connector.
Pin Description
1
2
3
4
5
1 +12V
2 GND
3 Backlight on/off
4 Brightness control
5 GND
LVDS1: LVDS LCD Connector
Connector type: DF-13-30DP-1.25V connector.
Pin Desc. Pin Desc.
1
2930
2
2 VDD 1 VDD
4 TX2CLK+ 3 TX1CLK+
6 TX2CLK- 5 TX1CLK-
8 GND 7 GND
10 TX2D0+ 9 TX1D0+
12 TX2D0- 11 TX1D0-
14 GND 13 GND
16 TX2D1+ 15 TX1D1+
18 TX2D1- 17 TX1D1-
20 GND 19 GND
22 TX2D2+ 21 TX1D2+
24 TX2D2- 23 TX1D2-
26 GND 25 GND
28 TX2D3+ 27 TX1D3+
30 TX2D3- 29 TX1D3-
SYSF1: Fan Power Connector
SYSF1 is a 3-pin header for the CPU fan. The fan
must be a +12V fan.
Pin Description
1
2
3
1 GND
2 +12V
3 FAN_CTL
I2C1: I2C Connector
Connector type: 2.54m pitch 1x3 pin header.
Pin Description
1
2
3
1 I2C_Clock
2 I2C_DATA
3 GND
TV1: TV OUT Connector
Connector type: 2.00m pitch 1x6 box wafer
connector.
Pin Description
1
2
3
4
5
6
1 TV_COMP
2 GND
3 TV_Y
4 GND
5 TV_C
6 GND
Pin Description Pin Description
1 Power LED+ 2 PWRBTN-
3 GND 4 PWRBTN+
5 GND 6 RESET+
7 HDD LED+ 8 RESET-
9 HDD LED- 10 SPEAKER+
11 SMB_CLK 12 SPEAKER+
13 SMB_DATA 14 SPEAKER-
15 GND 16 SPEAKER-
JFRT1: Switches and Indicators
It provides connectors for system indicators that
provides light indication of the computer activities
and switches to change the computer status.
Connector type: 2.54m pitch 2x8 pin header.
1
216
15

- 9 -
ATXP1: ATX Power
IDE1/ IDE2: 40-pin IDE Connector
Connector type: 2.54mm pitch 2x20 box header.
Pin Description Pin Description
1 IDE RESET 2 GND
3 DATA7 4 DATA8
5 DATA6 6 DATA9
7 DATA5 8 DATA10
9 DATA4 10 DATA11
11 DATA3 12 DATA12
13 DATA2 14 DATA13
15 DATA1 16 DATA14
17 DATA0 18 DATA15
19 GND 20 N/C (Key)
21 REQ 22 GND
23 IO WRITE 24 GND
25 IO READ 26 GND
27 IO READY 28 IDESEL
29 DACK 30 GND
31 IRQ14 32 N/C
33 ADDR1 34 ATA66 DETECT
35 ADDR0 36 ADDR2
37 CS0# 38 CS1# (HD SELECT1#)
39 IDEACTP 40 GND
1
2
39
40
ATP1: AT Power Connector
Pin Description
1
2
3
4
5
6
7
8
9
10
11
12
1 Power good
2 +5V
3 +12V
4 -12V
5 GND
6 GND
7 GND
8 GND
9 -5V
10 +5V
11 +5V
12 +5V
FDD1/ LPTFDD1: FDD Connector
Floppy connector, LPTFDD1 shared with LPT1.
Connector type: 2.54mm pitch 2x17 box header.
Pin Description Pin Description
1 GND 2 DRVDEN0
3 GND 4 N/C
5 GND 6 DRVDEN1
7 GND 8 INDEX#
9 GND 10 MOA#
11 GND 12 DSB#
13 GND 14 DSA#
15 GND 16 MOB#
17 GND 18 DIR#
19 GND 20 STEP#
21 GND 22 WDATA#
23 GND 24 WGATE#
25 GND 26 TRACK0#
27 GND 28 WP#
29 GND 30 RDATA#
31 GND 32 HEAD#
33 GND 34 DSKCHG#
1
2
33
34
Pin Desc. Pin Desc.
111
1020
11 +3.3V 1 +3.3V
12 -12V 2 +3.3V
13 GND 3 GND
14 PS-ON 4 +5V
15 GND 5 GND
16 GND 6 +5V
17 GND 7 GND
18 -5V 8 PW-OK
19 +5V 9 +5VSB
20 +5V 10 +12V

- 10 -
ISA1, ISA2, ISA3: ISA SlotPCI1, PCI2, PCI3, PCI4: 32 bits PCI Slot
Pin Description Pin Description
B1 -12V A1 TRST
B2 TCK A2 +12V
B3 GND A3 TMS
B4 TDO A4 TDI
B5 +5V A5 +5V
B6 +5V A6 INTA#
B7 INTB# A7 INTC#
B8 INTD# A8 +5V
B9 PRSTN1 A9 RSVD
B10 RSVD A10 +5V
B11 PRSTN2 A11 RSVD
B12 GND A12 GND
B13 GND A13 GND
B14 RSVD A14 3.3V_AUX
B15 GND A15 RST#
B16 CLK A16 +5V
B17 GND A17 GNT#
B18 REQ# A18 GND
B19 +5V A19 PME#
B20 AD31 A20 AD30
B21 AD29 A21 +3.3V
B22 GND A22 AD28
B23 AD27 A23 AD26
B24 AD25 A24 GND
B25 +3.3V A25 AD24
B26 C/BE3# A26 IDSEL
B27 AD23 A27 +3.3V
B28 GND A28 AD22
B29 AD21 A29 AD20
B30 AD19 A30 GND
B31 +3.3V A31 AD18
B32 AD17 A32 AD46
B33 C/BE2# A33 +3.3V
B34 GND A34 FRAME#
B35 IRDY# A35 GND
B36 +3.3V A36 TRDY#
B37 DEVSEL# A37 GND
B38 GND A38 STOP#
B39 LOCK# A39 +3.3V
B40 PERR# A40 SDONE
B41 +3.3V A41 SBO#
B42 SERR# A42 GND
B43 +3.3V A43 PAR
B44 C/BE1# A44 AD15
B45 AD14 A45 +3.3V
B46 GND A46 AD13
B47 AD12 A47 AD11
B48 AD10 A48 GND
B49 GND A49 AD9
B52 AD6 A52 C/BE0#
B53 AD7 A53 +3.3V
B54 +3.3V A54 AD6
B55 AD5 A55 AD4
B56 AD3 A56 GND
B57 GND A57 AD2
B58 AD1 A58 AD0
B59 +5V A59 +5V
B60 ACK64# A60 REQ64#
B61 +5V A61 +5V
B62 +5V A62 +5V
Pin Description Pin Description
B1 GND A1 IOCHK#
B2 RESDRV A2 SD7
B3 +5V A3 SD6
B4 IRQ9 A4 SD5
B5 -5V A5 SD4
B6 DREQ2 A6 SD3
B7 -12V A7 SD2
B8 0WS# A8 SD1
B9 +12V A9 SD0
B10 GND A10 IOCHRDY
B11 SMEMW# A11 AEN
B12 SMEMR# A12 SA19
B13 IOW# A13 SA18
B14 IOR# A14 SA17
B15 DACK3# A15 SA16
B16 DREQ3 A16 SA15
B17 DACK1# A17 SA14
B18 DREQ1 A18 SA13
B19 REFSH# A19 SA12
B20 SYSCLK A20 SA11
B21 IRQ7 A21 SA10
B22 IRQ6 A22 SA9
B23 IRQ5 A23 SA8
B24 IRQ4 A24 SA7
B25 IRQ3 A25 SA6
B26 DACK2# A26 SA5
B27 TC A27 SA4
B28 ALE A28 SA3
B29 +5V A29 SA2
B30 OSC A30 SA1
B31 GND A31 SA0
D1 MEMCS16# C1 BHE#
D2 IOCS16# C2 LA23
D3 IRQ10 C3 LA22
D4 IRQ11 C4 LA21
D5 IRQ12 C5 LA20
D6 IRQ15 C6 LA19
D7 IRQ14 C7 LA18
D8 DACK0# C8 LA17
D9 DREQ0 C9 MEMR#
D10 DACK5# C10 MEMW#
D11 DREQ5 C11 SD8
D12 DACK6# C12 SD9
D13 DREQ6 C13 SD10
D14 DACK7# C14 SD11
D15 DREQ7 C15 SD12
D16 +5V C16 SD13
D17 MASTER# C17 SD14
D18 GND C18 SD15

- 11 -
DIO1: Digital I/O Connector
DIO1 supports 8-bit In/ 8-bit Out.
Connector type: 2.00mm pitch 2x10 pin header
Output Port I/O Based Address: 208h
Input Port I/O Based Address: 200h
Pin Description Pin Description
12
2019
1 DO0 2 DO1
3 DO2 4 DO3
5 DO4 6 DO5
7 DO6 8 DO7
9 GND 10 GND
11 DI0 12 DI1
13 DI2 14 DI3
15 DI4 16 DI5
17 DI6 18 DI7
19 +5V 20 +12V
CFD1: Compact Flash II Socket
Pin Description Pin Description
1 PDD3 26 GND
2 PDD4 27 PDD11
3 PDD5 28 PDD12
4 PDD6 29 PDD13
5 PDD7 30 PDD14
6 PDCS1# 31 PDD15
7 GND 32 PDCS3#
8 GND 33 GND
9 GND 34 PDIOR#
10 GND 35 PDIOW#
11 GND 36 +5V
12 GND 37 PIDEIRQ
13 +5V 38 +5V
14 GND 39 CSEL#
15 GND 40 N/C
16 GND 41 IDERST#
17 GND 42 PIORDY
18 PDA2 43 PDDREQ
19 PDA1 44 PDDACK#
20 PDA0 45 HD_LED1#
21 PDD0 46 PDIAG#
22 PD1 47 PDD8
23 PD2 48 PDD9
24 N/C 49 PDD10
25 GND 50 GND
DOC1: Disk On Chip Socket
Socket type: 2.54mm pitch 32-pin DIP 15.24mm
socket.
Pin Desc. Pin Desc.
1
16 17
32
1 VP 32 +5V
2 A16 31 WE#
3 A15 30 +5V
4 A12 29 A14
5 A7 28 A13
6 A6 27 A8
7 A5 26 A9
8 A4 25 A11
9 A3 24 OE#
10 A2 23 A10
11 A1 22 CE#
12 A0 21 D7
13 D0 20 D6
14 D1 19 D5
15 D2 18 D4
16 GND 17 D3

- 12 -
ETX2 Connector
B1 GND
B3 SD14
B5 SD13
B7 SD12
B9 SD11
B11 SD10
B13 SD9
B15 SD8
B17 MEMW#
B19 MEMR#
B21 LA17
B23 LA18
B25 LA19
B27 LA20
B29 LA21
B31 LA22
B33 LA23
B35 GND
B37 SBHE#
B39 SA0
B41 SA1
B43 SA2
B45 SA3
B47 SA4
B49 SA5
B51 +5V
B53 SA6
B55 SA7
B57 SA8
B59 SA9
B61 SA10
B63 SA11
B65 SA12
B67 GND
B69 SA13
B71 SA14
B73 SA15
B75 SA16
B77 SA18
B79 SA19
B81 IOCHRDY
B83 +5V
B85 SD0
B87 SD2
B89 SD3
B91 DREQ2
B93 SD5
B95 SD9
B97 IOCHK#
B99 GND
GND B2
SD15 B4
MASTER# B6
DREQ7 B8
DACK#7 B10
DREQ6 B12
DACK#6 B14
DREQ5 B16
DACK#5 B18
DREQ0 B20
DACK#5 B22
IRQ14 B24
IRQ15 B26
IRQ12 B28
IRQ11 B30
IRQ10 B32
IO16# B34
GND B36
M16# B38
OSC B40
BALE B42
TC B44
DACK#2 B46
IRQ3 B48
IRQ4 B50
+5V B52
IRQ5 B54
IRQ6 B56
IRQ7 B58
SYSCLK B60
REFCH# B62
DREQ1 B64
DACK#1 B66
GND B68
DREQ3 B70
DACK#3 B72
IOR# B74
IOW# B76
SA17 B78
SMEMR# B80
AEN B82
+5V B84
SMEMW# B86
SD1 B88
NOWS# B90
SD4 B92
IRQ9 B94
SD7 B96
RSTDRV B98
GND B100
ETX1 Connector
A1 GND
A3 PCICLK3
A5 GND
A7 PCICLK1
A9 REQ#3
A11 GNT#2
A13 REQ#2
A15 REQ#1
A17 GNT#0
A19 +5V
A21 SERIRQ
A23 AD0
A25 AD1
A27 AD4
A29 AD6
A31 CBE#0
A33 AD8
A35 GND7
A37 AD10
A39 AD11
A41 AD12
A43 AD13
A45 AD14
A47 AD15
A49 CBE#1
A51 +5V
A53 PAR
A55 PERR#
A57 PME#
A59 LOCK#
A61 TRDY#
A63 IRDY#
A65 FRAME#
A67 GND
A69 AD16
A71 AD17
A73 AD19
A75 AD20
A77 AD22
A79 AD23
A81 AD24
A83 +5V
A85 AD25
A87 AD28
A89 AD27
A91 AD30
A93 PCIRST#
A95 INTR#C
A97 INTR#A
A99 GND
GND10 A2
PCICLK4 A4
GND11 A6
PCICLK2 A8
GNT#3 A10
+3.3V A12
GNT#1 A14
+3.3V A16
N.C A18
+5V A20
REQ#0 A22
+3.3V A24
AD2 A26
AD3 A28
AD5 A30
AD7 A32
AD9 A34
GND A36
AUXAL A38
MIC A40
AUXAR A42
ASVCC A44
SNDL A46
ASGND A48
SNDR A50
+5V A52
SERR# A54
N.C2 A56
USB2- A58
DEVSEL# A60
USB3- A62
STOP# A64
USB2+ A66
GND A68
CBE#2 A70
USB3+ A72
AD18 A74
USB0- A76
AD21 A78
USB1- A80
CBE#3 A82
+5V A84
AD26 A86
USB0+ A88
AD29 A90
USB1+ A92
AD31 A94
INTR#D A96
INTR#B A98
GND A100

- 13 -
C1 GND
C3 R
C5 HSY
C7 VSY
C9 DETECT#
C11 LCD16/B4
C13 LCD17/B5
C15 GND
C17 LCD13/B1
C19 LCD12/B0
C21 GND
C23 LCD8/G2
C25 LCD9/G3
C27 GND
C29 LCD4/R4
C31 LCD5/R5
C33 GND
C35 LCD1/R1
C37 LCD0/R0
C39 +5V
C41 JILI_DAT
C43 JILI_CLK
C45 BIASON/HSYNC
C47 COMP
C49 SYNC
C51 LPT/FLPY#
C53 +5V
C55 STB#/I.C
C57 N.C
C59 IRRX
C61 IRTX
C63 RXD2
C65 GND
C67 RTS#2
C69 DTR#2
C71 DCD#2
C73 DSR#2
C75 CTS#2
C77 TXD#2
C79 RI#2
C81 +5V
C83 RXD1
C85 RTS#1
C87 DTR#1
C89 DCD#1
C91 DSR#1
C93 CTS#1
C95 TXD#1
C97 RI#1
C99 GND
GND C2
BC4
GC6
DDCK C8
DDDA C10
LCD18/SHFCLK C12
LCD19/EN C14
GND C16
LCD15/B3 C18
LCD14/B2 C20
GND C22
LCD11/G5 C24
LCD10/G4 C26
GND C28
LCD7/G1 C30
LCD6/G0 C32
GND C34
LCD3/R3 C36
LCD2/R2 C38
+5V C40
LTGIO0/VSYNC C42
BLON# C44
DIGON C46
YC48
CC50
N.C C52
GND C54
AFD#/DENSEL C56
PD7/N.C C58
ERR#/HDSEL# C60
PD6/N.C C62
INIT#/DIR# C64
GND C66
PD5/N.C C68
SLIN#/STEP# C70
PD4/DSKCHG# C72
PD3/RDATA# C74
PD2/WP# C76
PD1/TRK0# C78
PD0/INDEX# C80
+5V C82
ACK#/DRV C84
BUSY#/MOT C86
PE/WDATA# C88
SLCT#/WGATE# C90
MSCLK C92
MSDAT C94
KBCLK C96
KBDAT C98
GND C100
ETX3 Connector ETX4 Connector
D1 GND
D3 5V_SB
D5 PS_ON
D7 PWERBTN#
D9 KBINH
D11 RSMRST#
D13 ROMKBCS#
D15 EXT_PRG
D17 +5V
D19 OVCR#
D21 EXTSMI#
D23 SMBCLK
D25 SIDE_CS3#
D27 SIDE_CS1#
D29 SIDE_A2
D31 SIDE_A0
D33 GND
D35 PDIAG_S
D37 SIDE_A1
D39 SIDE_INTRQ
D41 BATLOW#
D43 SIDE_ACK#
D45 SIDE_RDY
D47 SIDE_IOR#
D49 +5V
D51 SIDE_IOW#
D53 SIDE_DRQ
D55 SIDE_D15
D57 SIDE_D0
D59 SIDE_D14
D61 SIDE_D1
D63 SIDE_13
D65 GND
D67 SIDE_D2
D69 SIDE_D12
D71 SIDE_D3
D73 SIDE_D11
D75 SIDE_D4
D77 SIDE_D10
D79 SIDE_D5
D81 +5V
D83 SIDE_D9
D85 SIDE_D6
D87 SIDE_D8
D89 GPE2#
D91 RXD-
D93 RXD+
D95 TXD-
D97 TXD+
D99 GND
GND D2
PWGIN D4
SPEAKER D6
BATT D8
LILED D10
ACTLED D12
SPEEDLED D14
I2CLK D16
+5V D18
GPCS# D20
I2DAT D22
SMBDAT D24
SMBALRT# D26
DASP_S D28
PIDE_CS3# D30
PIDE_CS1# D32
GND D34
PIDE_A2 D36
PIDE_A0 D38
PIDE_A1 D40
GPE1# D42
PIDE_INTRQ D44
PIDE_ACK# D46
PIDE_RDY D48
+5V D50
PIDE_IOR# D52
PIDE_IOW# D54
PIDE_DRQ D56
PIDE_D15 D58
PIDE_D0 D60
PIDE_D14 D62
PIDE_D1 D64
GND D66
PIDE_D13 D68
PIDE_D2 D70
PIDE_D12 D72
PIDE_D3 D74
PIDE_D11 D76
PIDE_D4 D78
PIDE_D10 D80
+5V D82
PIDE_D5 D84
PIDE_D9 D86
PIDE_D6 D88
CBLID_P# D90
PIDE_D8 D92
SIDE_D7 D94
PIDE_D7 D96
HDRST# D98
GND D100
