Arbor Technology ITX-i9453 User manual

Quick Installation Guide
Version: 1.0
ITX-i9453
FORM FACTOR
Mini-ITX
CPU
μFCPGA 478
MEMORY
DDR2 2GB
LAN
Dual Intel
PCI-Express
Giga LAN
IDE
1 x UDMA 100
2xSATA
AUDIO
AC'97 Codec
Expansion Bus
PCI-Express x 16
Mini PCI
CHIPSET
Intel 945GME /
ICH7M
I/O
USB/Serial/LPT
Core Duo
Processor
Copyright© 2006 All Rights Reserved.
Technical Support
If you have any technical difficulites, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can
not find out the answer.
http://www.arbor.com.tw
E-mail: [e-mail]
PartNumber:4041945300100P
Packing List
Before you begin installing your single board, please make sure that the following
materials have been shipped:
1x ITX-i9453 Mainboard
1x I/O Bracket
1x CPU Cooler
1x CD-ROM (For Driver used)
1x Quick InstallationGuide

1x Warranty Card
Optional
1 x Cable Kit (CBK-07-7453-00) contains the followings:
UltraDMA100 IDE Flat cable x 1
USB cable, L=250 mm x 2
Serial ATA cable x 1
Print cable x 1
LPT to FDDcable x 1
Ordering Information
Note:
1. LAN 1/LAN 2 Support boot from LAN function
2. CompactFlash Card share by IDE1 resources,can not hot swap
ITX-i9453VL2G IntelCoreTM DuoMini-ITX M/BwithCRT/LCD,Audio, SATAII,
DualPCIeGiga LANand16X-PCI Express slot
Cable Kit CBK-07-7435-00
Jumper/Connector Quick Reference
Jumpers
Label Function
JBAT1 Clear CMOS
JPWR1 PS_ON Switch
JRS1 COM2 RS-232/422/485 Select
JV1 COM1 Power Source Special Support
JVLCD1 LVDS Panel Voltage Selects
JP1 Compact Flash Disk Mode Select
Connectors
U13 CPU Socket for Intel CoreTM DuoProcessor
DIMM1,DIMM2 240-pin DDR2 DIMM Socket
PCIE1 PCI Express X16 Interface Slot
MINIPCI1 Mini PCI Interface
KBM1 PS/2 Keyboard and Mouse
VGA1 CRT +DVI Display
INV1 LCD Inverter Connector
LVDS1 LVDS LCD Panel Connector
COM1 COM1+COM2 Serial Port
CON1 RS-422 / 485 Output
IR1 Infrared (IR) Connector
LAN1 Ethernet Connector (include USB1/2 Connector)
LAN2 Ethernet Connector (include USB3/4 Connector)
USB1 USB 7/8 Connector
USB2 USB 5/6 Connector
AUDIO1 Audio Interface Port
PW1 ATX Power Connector
ATX12V1 ATX12V Connector
CPUF1 CPU Fan Connector
SYSF1 System Fan Connector
JFRT1 Front Panel (Switches and Indicators)
DIO1 Digital I/O Connector
LPT1 LPT Share FDD Connector
IDE1 Primary IDE Connector
SATA1,2 Serial ATA 1/2 Connector
CFD1 Compact Flash Socket
12
3 4
Processor Support Socket 478 Intel® Core™ Duo processor
Chipset NB : Intel 945GME SB: Intel ICH7M
System Memory Support Two 240-pin Dual channel DDR2 SDRAM DIMM Socket Up to 2GB
Intel 945GM integrated GMA (Graphic Media Accelerator) 950 Technology
Support Dual Display, CRT, DVI, LVDS
Ethernet Dual Intel 82573V 10/100/1000 Base-T Ethernet LAN
I/O Chips Winbond W83627HF x 1
Phoenix-Award BIOS version 6.0PG
Support 4MB Flash ROM
Realtek ALC655 5.1 CH AC97 Codec
Supports MIC-In / Line-In / Line-out
Serial ATA II x 2 with 300MB/s transfer rate
ATA-100 x 1 channel
Compact Flash Disk X 1 share with IDE1 Slave (Support up to 4GB)
COM 1: RS-232
COM 2: RS232/422/485 Select
Parallel Port Support SPP / EPP / ECP mode
(Floppy only support 1 drive)
K/B and Mouse Support Standard PS/2 K/B and Mouse
Universal Serial Bus 8 x USB 2.0 Ports
Expansion Interface Mini PCI Socket & 16X-PCI Express Slot
Watchdog Timer
Chipset 1~255 Level (sec or min)
Hardware Monitor
Chipset Integrated in W83627HF
RTC Support Real Time Clock
Power Connector ATXPower connector and 4-pin ATX12V connector
Operation Temp. 0ºC ~ 60ºC
Dimension (L x W): 170 x 170 mm (6.7" x 6.7")
FDD / Parallel Port
(Share mode)
Specification
IDE Interface
Two Serial Port
Audio
BIOS
VGA/LCD Controller

01 KBM1: Keyboard and Mouse Connector
Type: 6-pin female x 2
Purple: PS/2 Keyboard
Green: PS/2 Mouse
02 PW1: Power Connector
Type: ATX 20-pin Connector
03 ATX12V1: Power Connector
Type:12V 4-pin (2*2) Power Connector supplies the
CPU operation voltage (Vcore).
If ATX12V1 is not connected, system cannot boot.
Pin Description Pin Description
2 GND 4 +12V
1 GND 3 +12V
04 JPWR1: Power Switch
Type: onboard 2-pin header
JPWR1
Power On Close
Power Off Open
05 06 DIMM1, DIMM2
240-pin DDR II SDRAM, DIMM socket
07 08 CPUF1/SYSF1(System Fan Connector)
Type: onboard 3-pin Wafer Connector
Pin Description
1 GND
2 +12V
3 Fan_Detect
9 10 SATA1/SATA2: Serial ATA
Type: Standard SATA Connector
11 JBAT1:CMOS Jumper Settings
Type: onboard 3-pin header
CMOS JBAT1
Keep CMOS 1-2 ON
Clear CMOS 2-3 ON
12 IDE1: IDE Connector
Type: on board standard 2.54 pitch(2*20) 40-pin holes
13 DIO1: Digital I/O Connector
Type: onboard 2.54 pitch 2*5-pin header
Pin Description Pin Description
1 DIO0 2 DIO1
3 DIO2 4 DIO3
5 DIO4 6 DIO5
7 DIO6 8 DIO7
9 +5V 10 GND
14 JP1: CF Master/Slave Mode Select
JP1
Close Master
Open Slave
15 MINIPCI1: Mini PCI Interface
16 PCIE1: PCI Express X16 Interface Slot
17 JFRT1: Front Panel(Switches and Indicators)
Type: onboard 16-pin (2*8) header
Pin Description Pin Description
1 Power LED+ 2 PWRBTN+
3 GND 4 PWRBTN-
5 GND 6 RESET+
7 HDD LED+ 8 RESET-
9 HDD LED- 10 SPEAKER+
11 SMBCLK 12 SPEAKER+
13 SMBDATA 14 SPEAKER-
15 GND 16 SPEAKER-
18 JV1:COM1 Power Source Special Support
Type: onboard 1*3-pin header
COM1 Power SourceSupport JV1
Standard 2-3
POS:5V on Pin1 1-2
Default setting: Standard
19 INV1: LVDS Panel Inverter Connector
Type: onboard 2.0 pitch 5-pin Wafer
Pin Description Pin Description
1 +12 V 2 GND
3 Backlight on/off 4 Brightness control
5 GND
20 CON1: RS422/485 Output Connector
Type: onboard 2.54 pitch 4-pin header
Pin RS-422 RS-485
1 TX+ DATA+
2 TX- DATA-
3 RX+ N.C
4 RX- N.C
RS-422/RS-485 Select by JRS1, share COM2
resource.
21 LPT1: Parallel Port Connector
Type: onboard 2*13-pin 2.0mm header
Pin Description Pin Description
1 STROBE 14 AFD
2 PTD0 15 ERROR
3 PTD1 16 INIT
4 PTD2 17 SLIN
5 PTD3 18 GND
6 PTD4 19 GND
7 PTD5 20 GND
8 PTD6 21 GND
9 PTD7 22 GND
10 ACK 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SELECT 26 Key(N/C)
LPT1: Floppy Drive Connector
LPT1 can be configured as a connector of floppy disk
drive interface through BIOS setup
Pin Description Pin Description
1 NC 14 RWC-
2 RINDEX- 15 HEAD-
3 TRAK0- 16 DIR-
4 WP- 17 STEP-
5 RDATA- 18 GND
6 DSKCHG- 19 GND
7 NC 20 GND
8 NC 21 GND
9 NC 22 GND
10 DSB- 23 GND
11 MOB- 24 GND
12 WD- 25 GND
13 WE- 26 Key(N/C)
22 IR1: Infrared(IR) Connector
Type: onboard 2.54 pitch 5-pin header
Pin Description
1 +5V
2 N.C
3 IRRX
4 GND
5 IRTX
23 AUDIO1: Audio Interface Port
AC’97 Audio
24 COM1/COM2: RS-232 Serial Port
Pin Description Pin Description
1 DCD1 2 RXD1
3 TXD1 4 DTR1
5 GND 6 DSR1
7 RTS1 8 CTS1
9 RI1
25 26 USB1, USB2: USB Connector
Type: onboard 2.54 pitch 10-pin header for two USB
ports
Pin Description Pin Description
1 +5V 2 +5V
3 USBD- 4 USBD-
5 USBD+ 6 USBD+
7 GND 8 GND
9 GND 10 N.C
27 JRS1: COM2 RS-232 / 422 / 485 Select
Type: onboard 6-pin (2*3) header
JRS1 Select 1-2 3-4 5-6
RS-232 ON OFF OFF
RS-422 OFF ON OFF
RS-485 OFF OFF ON
Default setting: RS-232 mode
5 6
7 8
28 29 LAN1/LAN2: USB/LAN Connector
Supports USB 2.0 x 4 (USB0, 1, 2, 3) & RJ-45
Ethernet Connector(LAN1/LAN2).
30 LVDS1: LVDS LCD Connector
Type : Onboard DF-13 30-pin header
Pin Description Pin Description
1 VDD 2 VDD
3 TX1CLK+ 4 TX2CLK+
5 TX1CLK- 6 TX2CLK-
7 GND 8 GND
9 TX1D0+ 10 TX2D0+
11 TX1D0- 12 TX2D0-
13 GND 14 GND
15 TX1D1+ 16 TX2D1+
17 TX1D1- 18 TX2D1-
19 GND 20 GND
21 TX1D2+ 22 TX2D2+
23 TX1D2- 24 TX2D2-
25 GND 26 GND
27 NC 28 NC
29 NC 30 NC
VDD could be selected by JVLCD1 in +5V or +3.3V
31 JVLCD1: LCD Panel Voltage Selects
Type: onboard 3-pin header
LCD Voltage JVLCD1
5V 1-2
3.3V 2-3
32 VGA1: CRT SVGA
Type: external D-sub female connector for CRT and
DVI
Solder Side
CFD1: Compact Flash Connector
Pin Description Pin Description
1 GND 26 CD1-
2DATA3 27DATA11
3 DATA4 28 DATA12
4 DATA5 29 DATA13
5 DATA6 30 DATA14
6 DATA7 31 DATA15
7 CS#1 32 CS#3
8 GND 33 NC
9 GND 34 IO READ
10 GND 35 IO WRITE
11 GND 36 +5V
12 GND 37 IRQ14
13 +5V 38 +5V
14 GND 39 CSEL
15 GND 40 N/C
16 GND 41 IDE RESET
17 GND 42 IO READY
18 ADDR2 43 IDE-DREQ
19 ADDR1 44 IDE-DACK#
20 ADDR0 45 DASP
21 DATA0 46 DIAG
22 DATA1 47 DATA8
23 DATA2 48 DATA9
24 N/C 49 DATA10
25 CD2- 50 GND
Note: Driver Install
CHIPSET: \DRIVER\CHIPSET\Intel\INF 7.2
IDE: \DRIVER\IDE\Intel\ICH7
VGA: \DRIVER\Graphics\Intel\9X5
USB: \DRIVER\USB2\ICH5
LAN: \DRIVER\Ethernet\Intel
MONITOR: \DRIVER\H-MONITOR\Winbond
AUDIO: \DRIVER\AUDIO\Realtek
1
2
3
4
5
7
910
12 6
13
8
15
16
17
19
20
21
22 23 24 25 26
27
28 29
30
31
32
14
1
11
1
1
18
Audio-In
Audio-Out
MIC-In
LAN1
USB
USB
USB
USB
LAN2
01 KBM1 06 DIMM2 11 JBAT1 16 PCIE1 21 LPT1 26 USB2 31 JVLC
D
02 PW1 07 CPUF1 12 IDE1 17 JFRT1 22 IR1 27 JRS1 32 VGA1
03 ATX12V1 08 SYSF1 13 DIO1 18 JV1 23 Audio1 28 LAN1
04 JPWR1 09 SATA1 14 JP1 19 INV1 24 COM1 29 LAN2
05 DIMM1 10 SATA2 15 MINIPCI1 20 CON1 25 USB1 30 LVDS1
