Arbor Technology HiCORE-i6320 User manual

Part Number: 4041632000100
Quick Installation Guide
HiCORE-i6320
Full-size PICMG Socket 370 Pentium III /
Celeron PC-133 CPU Card with SCSI,
Triple Fast Ethernet, and DiskOnChip
Version 1.0
All manuals and user guides at all-guides.com
all-guides.com

2 HiCORE-i6320 Quick Installation
Copyright©2002
All Rights Reserved.
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct,
indirect, special, incidental, or consequen-tial damages arising from the use or
inability to use the product or documentation, even if advised of the possibility
of such damages.
This document contains proprietary information protected by copyright. All
rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic, or other means in any form without prior written
permission of the manufacturer.
All manuals and user guides at all-guides.com

3 HiCORE-i6320 Quick Installation
Warning
Single Board Computers and their components contain very delicate
Integrated Circuits (IC). To protect the Single Board Computer and its
components against damage from static electricity, you should
always follow the following precautions when handling it :
1. Disconnect your Single Board Computer from the power source when you
want to work on the inside
2. Hold the board by the edges and try not to touch the IC chips, leads or
circuitry
3. Use a grounded wrist strap when handling computer components.
4. Place components on a grounded antistatic pad or on the bag that came
with the Single Board Computer, whenever components are separated
from the system
Replacing the lithium battery
Incorrect replacement of the lithium battery may lead to a risk of explosion.
The lithium battery must be replaced with an identical battery or a battery
type recommended by teh manufacturer (BR2335).
Do not throw lithium batteries into the trashcan. It must be disposed of in
accordance with local requlations concerning special waste.
Technical Support
If you have any technical difficulites, please consult the user's manual first
at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still
can not find out the answer.
http://www.arbor.com.tw
E-mail:[e-mail]
All manuals and user guides at all-guides.com

4 HiCORE-i6320 Quick Installation
Specifications
General Specifications
CPU : Socket 370 FC-PGA2/FC-PGA Pentium®III, Tualatin, Celeron, VIA
C3TM with 133/100/66MHz FSB
Chipset : Intel 815E (82815 GMCH Northbridge and 82801BA ICH2
Southbridge) integrates Graphics Memory Controller Hub with Dynamic
Viedo Memory Technology and supports PC-133 memory bus, 133MHz FSB
and UltraATA/100 IDE interfaces
BIOS : AWARD®Flash BIOS Green&Soft Off function version 6.0, LS120,
multiple boot function, FWH 4MB
Green Function : power saving supported in BIOS. DOZE /STANDBY /
SUSPEND modes, ACPI & APM
L2 Cache : Integrated on CPU
DRAM Memory : up to 512MB of SDRAM in two168-pin DIMM sockets
(supports PC-133 SDRAM)
Enhanced IDE with UltraDMA : supports 2 ports and up to 4 ATAPI
devices. UltraDMA transfer 33/66 and 100 MB/sec
Watchdog Timer : 127-level timer generates RESET or NMI when your
application loses control over the system.
Real-time Clock : built-in chipset with lithium battery backup for 10 years
of data retention. CMOS data backup of BIOS setup and BIOS default.
High Speed Multi I/O
Chipset : Winbond W83627HF
Serial Ports : one external high speed RS-232C port COM1 (DB9 on
bracket), one internal high speed RS-232C/422/485 port COM2 (jumper
selectable, 10-pin box header). Both with 16C550 compatible UART and 16
byte FIFO.
USB : 4 onboard USB ver 1.1 ports (Dual 2x 5-pin header)
SIR Interface : onboard IrDA TX/RX port (5-pin header)
Floppy Disk Drive Interface : 2 floppy disk drives, 5¼" (360 KB or 1.2
MB) and 3½" (720 KB, 1.44 MB or 2.88 MB).
Bi-directional Parallel Port : SPP, EPP and ECP mode.
Keyboard and Mouse Connectors : external PS/2 KB/Mouse port (2-in-
1 mini DIN) onboard AT Keyboard port (5-pin box header)
All manuals and user guides at all-guides.com

5 HiCORE-i6320 Quick Installation
Network Interface Controller
Chipset : 2x Intel 82559 and 1x internal 82562ET PHY 10/100 Mbps,
autoswitching
Connector : Single RJ-45 on board bracket and Dual RJ-45 on daughter
bracket
Display Controller
Chipset : 4x AGP Intel 82815 2D/3D engines integrated in Intel 815E
Supports 4MB on board SDRAM
Display Type : CRT (VGA, SVGA, XGA, SXGA) and LCD (optional, see
LCD Daughterboard) Type
Connectors : external DB15 for CRT on bracket and DVI Connector for
TMDS daughterboard
LCD Display Daughterboard (optional) : TMDS Panel Link with DVI
interface
Flash Disk DiskOnChip®2000
Package : Single Chip Flash Disk in 32-pin DIP JEDEC
Capacity : up to 288 MByte
Data Reliability : ECC/EDC error correction
Memory Window : 8 KByte
Environmental and Power
Power Requirements : +5 V @ 6.8 A (typical), ±12 V @ 0.08A (typical)
; (FC-PGA Pentium®III 1.0 GHz at 133 FSB and 512 MB PC-133 SDRAM)
CPU Power : onboard PWM switching power supply for autodetects CPU
core voltage
System Monitoring and Alarm : CPU and System temperature, system
voltage and cooling fan RPM.
Board Dimensions : 338 mm x 122 mm
Board Weight : 0.6 Kg.
Operating Temperature : 0 to 60°C (32 to 140°F)
All manuals and user guides at all-guides.com

6 HiCORE-i6320 Quick Installation
Packing list
Before you begin installing your single board computer, please make sure that
the following materials have been shipped:
> 1 x HiCORE-i6320 Full-Size SBC
> 1 x Quick Installation Guide
> 1 x CD-ROM ( for driver used)
> 1 x Cable Kits contains the followings:
Content Part No.
. 2 x USB Port Cable 3431121000000
. 1 x UltraDMA 100 IDE Flat Cable 3432061000030
. 1 x Keyboard / PS2 Mouse Cable 3432102000010
. 1 x MCBK-3 in 1 Cable 6910300000000
(IDE cable, FDD cable, Parallel port cable & Serial port cable)
. 1 x EMD-D1301 (for VL3 & VL3S only) 6716632101010
. 1 x Screw sets (for VL3 & VL3S only) (3525130319600,
3511060306100, 3610124602610)
Ordering Codes
HiCORE-i6320VL3S Full-size PICMG-bus Socket 370 Tualatin,
Pentium-III / Celeron PC-133 CPU Card with
High Drive ISA, LCD/CRT SVGA, Triple Ethernet
and SCSI Interface (includes FEMD-LD1301
Daughterboard) OEM base
HiCORE-i6320VL3 Full-size PICMG-bus Socket 370 Tualatin, Pentium-III /
Celeron PC-133 CPU Card with High Drive ISA, LCD/
CRT SVGA, Triple Ethernet (includes FEMD-LD1301
daughterboard) OEM base
HiCORE-i6320VL Full-size PICMG-bus Socket 370 Tualatin, Pentium-III /
Celeron PC-133 CPU Card with High Drive ISA, CRT
SVGA
FEMD-LD1301 : Daughterboard with Dual Fast Ethernet, one DVI port and
PS/2 mouse port (for VL3 & VL3S )
All manuals and user guides at all-guides.com
all-guides.com

7 HiCORE-i6320 Quick Installation
4P Auxiliary
Power
Two168-pin DIMM
Socket upto 512 MB
SDRAM
VGA
LAN1
DOC
Socket 370 for Intel
Pentium-III / Taulatin
CPUs upto 1.4 GHz at
100/133 MHz of FSB
FDD Port
PS2 K/B Mouse
COM2
PICMG-bus
integrated ISA/
PCI-bus
Interface
ATX1
WOL
SYSF
USB0,1,2,3
Parallel Port
IDE Ports
ATA-100
DIMM1
DIMM2
EKB
Board Layout Front
COM1
CPUF1
PGA 370
DiskOnChip 2000
Socket
Intel
82559
Intel
82559
SCSI
All manuals and user guides at all-guides.com

8 HiCORE-i6320 Quick Installation
Jumpers
Lable Function
J1 Clear CMOS
J2 Watchdog Output
J4 RS-232,422/485 select
J8 H/W Monitor Alarm
Jumper/Connector Quick Reference
All manuals and user guides at all-guides.com

9 HiCORE-i6320 Quick Installation
Jumper/Connector Quick Reference
Connectors
Lable Function
ATX1 ATX Feature Connectorr
COM1 Serial Port: COM1
COM2 Serial Port: COM2
CPUF1 CPU FAN1 Connector
DBC1 Daughter board Connector1
DBC2 Daughter board Connector2
DIMM1 SDRAM bank 1/2 168 pin DIMM
DIMM2 SDRAM bank 3/4 168 pin DIMM
DVI Digital Visual Interface Connector
EKB External Keyboard Connector
ESMI External SMI
ESPK External Speaker
FDD Floppy Disk Driver Connector
HLED HDD LED Connector
IDE1 Primary IDE Connector
IDE2 Secondary IDE Connector
KBM PS/2 Keyboard & Mouse
LAN1 10/100M LAN1 Connector
LAN2 10/100M LAN2 Connector
LAN3 10/100M LAN3 Connector
LPT Parallel Port
PLKL Power LED & Keyboard Lock
PSM PS/2 Mouse
PSON ATX Soft Power Switch
PWR 4P Auxiliary Power Connector
SCSI Ultra-III LVD/SE SCSI 68 pin Connector
SIR Infrared (IR) Connector
SYSF Chassis Auxiliary Fan Connector
RES Reset Connector
USB1 USB Port 0,1
USB2 USB Port 2,3
VGA CRT SVGA Connector
WOL Wake On LAN
All manuals and user guides at all-guides.com

10 HiCORE-i6320 Quick Installation
CMOS Jumper Settings
CMOS Setup (J1)
Type : J1: onboard 3-pin header
CMOS Setup (J1) J1
Keep CMOS 1-2 ON
Clear CMOS 2-3 ON
default setting
123
J 1
Watchdog Timer
Watchdog Output (J2)
The onboard watchdog timer can be disable by jumper setting or enable for
either reboot by system RESET or invoking an NMI (Non-Maskable Interrupt)
Even if enabled by jumper setting upon boot the watchdog timer is always
inactive. To initialize or refresh the watchdog timer writing of port F2 is
sufficient. To disable the watchdog time read port 44h.
Status Action
Enable/refresh the Watchdog Timer I/O Write F2
Disable the Watchdog Timer. I/O Read 044H
After the watchdog timer has been initialized by writing port F2, it has to be
strobed at preconfigured intervals to keep it from issuing a RESET or NMI.
The watchdog timer timeout intervals are set by software programming.
Mode Setting
Watchdog Mode J2
Enabled for Active NMI(I/O Channel Check) 1-2
Enabled for System Reset 2-3
Disable Watchdog Timer None
default setting
Timeout Values
Timout values are programmed. The watchdog timer supports 127 steps.
use the table on the next page to find the hexidecimal value that needs to be
passed on to get the correct timer interval. Look subsequntly at the program
All manuals and user guides at all-guides.com

11 HiCORE-i6320 Quick Installation
Hardware monitor Alarm
Hardware monitor Alarm: J8
Hardware monitor alarm can be selected enable or disable by jumper (J8).
There are three main functins for this item: Voltage/CaseOpen, Fan/Tempera-
ture and CPU/Memory.
All manuals and user guides at all-guides.com
all-guides.com

12 HiCORE-i6320 Quick Installation
Serial Port Selection (RS232C/422/485)
RS-232/422/485 Mode select (J4)
RS-422/485 Mode on COM2
The onboard COM2 port can be configured to operate in RS-422 or RS-485
modes. RS-422 modes differ in the way RX/TX is being handled. Jumper J4
switches between RS-232 or RS-422/485 mode. When J4 is set to RS-422 or
485 mode, there will be only +12V output left while J4 is set. All of the RS-
232/422/485 modes are available on COM2.
COM2
Pin Defined: RS232 RS422 RS485
Pin1 : DCD Tx- RTx-
Pin2 : RXD Tx+ RTx+
Pin3 : TxD Rx+ x
Pin4 : DTR Rx- x
J4 Selection 1-2 3-4 5-6
RS-232 Close Open Open
RS-422 Open Close Open
RS-485 Open Open Close
default setting
All manuals and user guides at all-guides.com

13 HiCORE-i6320 Quick Installation
Triple Fast Ethernet Connectors
LAN Port
Connector : LAN1
Type : external RJ-45 on bracket
Pin 12345678
Desciption TX+ TX- RX+ NC NC RX- NC NC
LAN LED Indicator on RJ-45 connector
Connector : LED
Type : 2 LED
LED ACT (yellow) Speed (green)
Desciption Active Transfer 100 MB mode
Wake On LAN
Connector: WOL1
Type : onboard 3-pin wafer connector
Pin Description
1 5V_SB
2 GND
3 WOL_CTL
WOL
1 2 3
All manuals and user guides at all-guides.com

14 HiCORE-i6320 Quick Installation
Power Connector
ATX Feature Connector
ATX Feature Connector:ATX1
Type : onboard 3-pin Wafer connector
Pin Description
15V
2 GND
3 PS-ON
Connector : PWR
Type : onboard 4-pin Wafer connector
Pin Description
1 5V SB(Standby)
2 GND
3 GND
4 12V
4P Auxilary Power PWR1
+12 V
GND
GND
+5V
CPU Fan Connector
Connector : CPUF1
Type : onboard 3-pin wafer connector
Pin Description
1 GND
2 +12V
3 FAN_CTL
Chassis Auxilary Fan Connector
Connector : SYSF1
Type : onboard 3-pin header
Pin Description
1 GND
2 +12V
3 FAN_CTL
123
CPUF1
321
SYSF1
ATX1 1 2 3
All manuals and user guides at all-guides.com

15 HiCORE-i6320 Quick Installation
Power LED and Keyboard Lock Connector
Connector : PLKL
Power LED can be indicated when the CPU card is on or off. And keyboard
lock can be used to disable the keyboard function so the PC will not respond
by any input.
Pin Description
1 LED power (+5V)
2NC
3 GND
4 Keyboard Lock
5 GND
External Speaker Connector
Connector : ESPK
Pin Description
1 +5V
2 GND
3 Internal buzzer
4 Speak out
Switches and Indicators
Connector : JFRONT1
Type : onboard 20-pin header
Pin Jumper Description
1-2 PSON ATX soft power switch
3-4 RES reset function
5-6 HLED Hard Disk LED
7-8 ESMI external SMI
10,12,14,16 ESPK exteranal speaker
9,11,13,15,17 PLKL power LED & Keyboard Lock
RESHLED ESMI
PLKL
ESPK
PSON
All manuals and user guides at all-guides.com
