Original User Manual–AREBOS Aluminium Rollator
1
Aluminium Rollator
AR-HE-RL/42012/G/P/R
Please follow all security measures in this user´s manual to ensure a secure use.
Thank you for trusting in AREBOS.

Original User Manual–AREBOS Aluminium Rollator
2
Table of Contents
1.Safety instructions ..............................3
1.1 Symbols................................................................. 3
1.2 Product specifications........................................... 3
1.3 Introduction .......................................................... 3
2.Use .....................................................3
3.Product structure ................................4
4.Key performance specifications...........5
5.Installation..........................................5
6.Cleaning and Maintenance..................7
6.1 Transportation and storage .................................. 7
7.Environmentally friendly disposal .......8
7.1 Disposal and packaging......................................... 8
7.2 Disposal of old equipment .................................... 8
EU Declaration of Conformity.................9

Original User Manual–AREBOS Aluminium Rollator
3
Thank you for purchasing our product. Please read the operating instructions carefully before using
the product for the first time. If you give the product to a third party, this manual must be handed
over with it. Keep the instruction manual for future reference. The drawings in this manual may
not match the physical objects. Please refer to the physical objects.
1.Safety instructions
1.1 Symbols
1.2 Product specifications
•The Rollator is designed to assist the user to walk, rest and carry small items of shopping for
both indoor and outdoor use on flat surfaces by a single individual with limited mobility with
a maximum weight as shown below.
•It is important that the user reads and understands the safety advice given within this manual
before attempting to operate the product to avoid possible injury to the user or bystanders
and avoid damage to the rollator or surrounding property.
1.3 Introduction
•The Rollator is manufactured from high quality materials, aluminum frame, PP and nylon
seat, Polyester bag and locking brake. The handles are adjustable in height and the rollator
folds easily for transport or storage.
Indicatons:
•The Rollator is designed to assist the user to walk, rest and carry small items of shopping for
both indoor and outdoor use on flat surfaces by a single person with limited mobility with a
maximum weight as shown below.
Executive standard:
•Type tested according to EN ISO 11199-2:2005
2.Use
•To assist the user to walk, rest and carry small items of shopping for both indoor and
outdoor.
Work environment:
•Environment temperature: -20℃～60°C
•Relative humidity Range: ≤85%
•Atmospheric pressure range: 850hPa≤1050hPa
By means of a CE marking, it can be recognized that a product complies with the
legal requirements of European legal standards and therefore may be traded
within the European Community.

Original User Manual–AREBOS Aluminium Rollator
4
3.Product structure
•Made by hand grips, adjustable parking/running brake, nylon backrest, armrest tube, seat
area, height adjustable tube, nylon shopping bag, front wheel set and rear wheels.
Appearance structure drawing as below
1. hand grips
2. adjustable parking/running brake、
3. nylon backrest
4. armrest tube
5. seat area
6. height adjustable tube
7. nylon shopping bag
8. front wheel set
9. rear wheel

Original User Manual–AREBOS Aluminium Rollator
5
4.Key performance specifications
Main parts of product
size
Rollator weight capacity
300 lbs (136 kg)
Armrest inner width
17.72 in (45 cm)
Seat height
21.26 in (54 cm)
Armrest lowest height
30.91 in (78.5 cm)
Armrest highest height
36.22 in (92 cm)
Overall width
25.39 in (64.5 cm)
Overall length
26.97 in (68.5 cm)
Seat depth
13.39 in (34 cm)
Folded width
10.63 in (27 cm)
Shopping bag weight capacity
12.1 lbs (5.5 kg)
Unit weight
15.4 lbs (7.1 kg)
Master carton size
25.98 x 11.42 x 14.57 in (66 x 29 x 37 cm)
Fittings List
•Product one unit,
•Four knob screws,
•A manual,
•A shopping bag.
5.Installation
•Remove all packaging, put all parts out. Insert knob and turn it to adjust the rollator until
stable.
•Before inserting knob screws in the holes, please make sure all holes are on the same line.
Be sure knob screws can be seen through the holes at the opposite side.
•To open your rollator, push down on either side of the cross bars as shown below. You
should feel both sides click into position.
•To fold the rollator, gently pull the strap in the middle of the seat as shown below.
knob
knob

Original User Manual–AREBOS Aluminium Rollator
6
•The rollator’s handles can be adjusted in height to suit different users. Simply depress the
spring button and set to the desired height. Repeat for the opposite side and make sure that
both handles are secure and set at the same height before use.
•After having depressed the spring button and set to the desired height, it should be located
in the same position on either side.
•(Warning: These holes’ diameter is 8-8.2mm, be carefully when using to avoid hurting
finger, be sure to keep children away.)
•String accessories: Put a stick or umbrella in the holder and fix it with the bandage as shown
below.
Bandage to fix umbrella or cane
Open Rollator
Fold Rollator

Original User Manual–AREBOS Aluminium Rollator
7
6.Cleaning and Maintenance
•When packing or storing this rollator, please adhere to the conditions described in this
manual.
•Do not use strong corrosive action cleaner to clean the product surface.
•Do not use acid and alkaline solution or polishing agent to wipe the surface.
•Product cannot be put in the rain outside
•Pay attention to safety during assembly: To avoid injury, do not put fingers into the spin
position.
•While resting, hold the break to prevent rollator from sliding.
•Do not hang anything on the left or right handle to avoid the rollator becoming unstable and
slanted.
•Regularly check the tightness of the screws and wing screws of the folding mechanism.
•Please fold before storage.
6.1 Transportation and storage
•AR-HE-RL42012 can be carried by any transport vehicle, make sure to prevent damage by
chemical medicines and the erosion.
•Storage environment: -40℃～60℃, relative humidity: ≤93%. Atmospheric pressure:
500hPa～1050hPa
•Storage requirement: No corrosive gases and good ventilation.

Original User Manual–AREBOS Aluminium Rollator
8
7.Environmentally friendly disposal
Warning Danger of suffocation! Packaging material is dangerous for children. Never let children play
with packaging material.
7.1 Disposal and packaging
•The packaging of your unit consists of materials that are necessary to guarantee effective
protection during transport. These materials are fully recyclable and therefore reduce the
environmental impact. Dispose of the packaging in a bin for recyclable materials.
7.2 Disposal of old equipment
•Old appliances must be disposed of in accordance with the guidelines and regulations of the
local waste disposal authority. Check with your local administration for the address of the
nearest recycling centre and deliver your appliance there.
The symbol of the crossed-out dustbin on a Waste electrical or electronic
equipment indicates that it must not be disposed of with household waste at
the end of its life. Collection points for waste electrical and electronic
equipment are available free of charge in your area. You can obtain the
addresses from your city or local government. You can find out about other
return options created by us on our website www.arebos.de.
The separate collection of Waste electrical or electronic equipment is intended
to enable the reuse, recycling or other forms of recovery of Waste electrical or
electronic equipment and to avoid the negative consequences of disposal on
the environment and human health.
Our customer service number: Tel. [phone]
Fax: [phone] / E-Mail: [e-mail]
Office address: Canbolat Vertriebs GmbH • Gneisenaustraße 10-11 • 97074 Würzburg
Return address can be found in the imprint: https://www.arebos.de/impressum/

Original User Manual–AREBOS Aluminium Rollator
9
EU Declaration of Conformity
We, the
Canbolat Vertriebs GmbH, Gneisenaustraße 10-11, 97074 Würzburg, Germany,
hereby declare that the equipment described below, by virtue of its design and construction and in
the versions placed on the market by us, complies with the relevant essential health and safety
requirements of the EU directives.
Product name: AREBOS Aluminium Rollator
Model number: AR-HE-RL / 42012 / G / P / R
Article number: 4260199756577 / 4260627424016 / 4260627424023 / 4260627424030
Should the appliance be modified without our consent, this declaration of conformity will lose its
validity.
Relevant EU Regulation:
Medical Device Regulation (EU) 2017/745
Applied harmonised Standards:
EN ISO 11199-2:2005
The product is classified in class I according to annex VIII rule 1 of the Regulation.
Date/Signature Manufacturer/Place: Würzburg, June 23, 2022
Signature:
Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director
Representative of these instructions for use/technical data:
Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director
Office address:
Canbolat Vertriebs GmbH
Gneisenaustraße 10-11
D-97074 Würzburg
Return address can be found in the imprint: https://www.arebos.de/impressum/
VAT identification number: DE 263752326
Court of the Commercial Register is Würzburg, HRB 10082
WEEE Reg.-No. DE 61617071
