AREBOS AR-HE-RL42012 User manual

User’s Manual –AREBOS Aluminium Rollator
1
Aluminium Rollator
AR-HE-RL42012
User’s Manual
Please follow all security measures in this user’s manual to ensure a secure use.

User’s Manual –AREBOS Aluminium Rollator
2
Please read and save these instructions. Read through this user’s manual carefully before using
product. Protect yourself and others by observing all safety information, warnings and cautions.
Failure to comply with instructions could result in personal injury and/ or damage to product or
property. Please retain instructions for future reference.
Product specifications
AR-HE-RL42012 Aluminum Rollator is designed to assist the user to walk, rest and carry small items of
shopping for both indoor and outdoor use on flat surfaces by a single individual with limited mobility
with a maximum weight as shown below.
It is important that the user reads and understands the safety advice given within this manual before
attempting to operate the product to avoid possible injury to the user or bystanders and avoid
damage to the rollator or surrounding property.
SUMMARIZATION
1. INTRODUCTION
The rollators are manufactured from high quality materials, aluminum frame, PP and nylon seat,
Polyester bag and locking brake. The handles are adjustable in height and the rollator folds easily for
transport or storage.
2. INDICATIONS
AR-HE-RL42012 is designed to assist the user to walk, rest and carry small items of shopping for both
indoor and outdoor use on flat surfaces by a single individual with limited mobility with a maximum
weight as shown below.
3. EXECUTIVE STANDARD
Type tested according to BS ENISO 11199-2:2005
4. PRODUCT STRUCTURE
Made by hand grips, adjustable parking/running brake, nylon backrest, armrest tube, seat area,
height adjustable tube, nylon shopping bag, front wheel set and rear wheels.

User’s Manual –AREBOS Aluminium Rollator
3
APPEARANCE STRUCTURE DRAWING AS BELOW
1. hand grips
2. adjustable parking/running brake、
3. nylon backrest
4. armrest tube
5. seat area
6. height adjustable tube
7. nylon shopping bag
8. front wheel set
9. rear wheel
5. USE
To assist the user to walk, rest and carry small items of shopping for both indoor and outdoor.
6. WORK ENVIRONMENT
Environment temperature: -20℃～60°C
Relative humidity Range: ≤85%
Atmospheric pressure range: 850hPa≤1050hPa
Key performance specifications
Main parts of product
size
Armrest inner width
45cm
Seat height
54cm
Armrest lowest height
78.5cm
Armrest highest height
92cm
Overall width
64.5cm
Overall length
68.5cm
Seat depth
34cm
Folded width
27cm

User’s Manual –AREBOS Aluminium Rollator
4
Shopping bag weight capacity
5.5KG
Rollator weight capacity
136KG
Unit weight
7.6KG
Master carton size
66.0*29.0*37.0 CM
Fittings List
Product one unit,
Four knob screws,
A manual,
A shopping bag.
Installation & Use
1. Remove all packaging, put all parts out. Insert knob and turn it to adjust the rollator until stable.
Before inserting knob screws in the holes, please make sure all holes are on the same line. Be sure
knob screws can be seen through the holes at the opposite side.
2. To open your rollator, push down on either side of the cross bars as shown below. You should
feel both sides click into position.
To fold the rollator, gently pull the strap in the middle of the seat as shown below.
3. The rollator’s handles can be adjusted in height to suit different users. Simply depress the spring
knob
knob
Open Rollator
Fold Rollator

User’s Manual –AREBOS Aluminium Rollator
5
button and set to the desired height. Repeat for the opposite side and make sure that both
handles are secure and set at the same height before use.
After having depressed the spring button and set to the desired height, it should be located in the
same position on either side.
(Warning: These holes’ diameter is 8-8.2mm, be carefully when using to avoid hurting finger, be
sure to keep children away.)
4. String accessories: Put a stick or umbrella in the holder and fix it with the bandage as shown
below.
Cleaning and Maintenance
1. Do not use strong corrosive action cleaner to clean the product surface.
2. Do not use acid and alkaline solution or polishing agent to wipe the surface.
3. Product cannot be put in the rain outside
4. Pay attention to safety during assembly: To avoid injury, do not put fingers into the spin position.
5. While resting, hold the break to prevent rollator from sliding.
6. Do not hang anything on the left or right side handle to avoid the rollator becoming unstable and
slanted.
7. Please fold before storage.
Transportation and storage
Bandage to fix umbrella or cane

User’s Manual –AREBOS Aluminium Rollator
6
1. AR-HE-RL42012 can be carried by any transport vehicle, make sure to prevent damage by
chemical medicines and the erosion.
2. Storage environment: -40℃～60℃, relative humidity: ≤93%. Atmospheric pressure:
500hPa～1050hPa
3. Storage requirement: No corrosive gases and good ventilation.
After Service
When packing or storing this rollator, please adhere to the conditions described in this manual.
Within 6 months of purchase, exchange remains free of charge. 24 months of warranty are granted.

User’s Manual –AREBOS Aluminium Rollator
7
Disposal Instruction
Disposal of the packaging
Please make reference to the guidelines and standards for appropriate disposal of the packaging
valid in your region. In part, the package may consist of plastic bags - watch this respect, with
special care to ensure that this is not out of the reach of children. There is a risk of suffocation!
Disposal of waste equipment
Equipment must be disposed of in accordance with the rules and regulations of the local waste
disposal.
Meaning of the "dustbin"
Protect our environment; electrical appliances do not belong in household waste.
Use the provided for the disposal of electrical equipment collection points and
enter your electrical and electronic equipment that you no longer use. They help
ensure that the potential effects of incorrect disposal on the environment and
human health to be avoided. So do your part to recycle, recycling and other
forms of recovery of waste electrical and electronic equipment. Information on
where the devices are disposed of, please contact your local authorities or local
Governments.

User’s Manual –AREBOS Aluminium Rollator
8
EU Declaration of Conformity
We,
Canbolat Vertriebs GmbH, Gneisenaustraße 10-11, 97074 Würzburg, Germany,
Hereby declare that the product named below, seen its design and construction as well as according
to our sales, has been complied with the relevant and basic health and safety EU-requirements.
Name of the product: Arebos Aluminium Rollator
Model Nr.: AR-HE-RL42012
Art. Nr.: 4260199756577
If the product has any modification not allowed by us, this declaration loses its validity.
Tested acc. to:
BS ENISO 11199-2:2005
Date/ Manufacturer Signature: / Location: Würzburg, 26.01.2018
Identification of the signatory: Korhan Canbolat, head of the company
Authorised representative for the technical documentation:
Korhan Canbolat
Office address: Warehouse address:
Canbolat Vertriebs GmbH Berenbrinker GmbH
Gneisenaustraße 10 –11 Heiligenhäuschenweg 66
D-97074 Würzburg D-33378 Rheda-Wiedenbrück
Umsatzsteuer-Identifikationsnummer: DE 263752326
Gericht der Handelsregistereintragung ist Würzburg, HRB 10082
WEEE-Reg.-Nr. DE 61617071
