AREBOS AR-HE-AKA10 User manual

User’s Manual –AREBOS Automatic Cable Rewinder
1
Automatic Cable Rewinder
AR-HE-AKA10/15/20
Please follow all security measures in this user´s manual to ensure a secure use.
Thank you for trusting in AREBOS.

User’s Manual –AREBOS Automatic Cable Rewinder
2
Table of Contents
1. Safety Instructions ................................... 3
1.1 Explanation of the symbols................................... 3
1.2 Safety Warnings .................................................... 4
2. Intended Use............................................ 4
3. Assembly.................................................. 4
4. Troubleshooting....................................... 5
5. Technical Data.......................................... 5
6. Environmentally friendly disposal ............ 6
6.1 Disposal and packaging......................................... 6
6.2 Disposal of waste equipment................................ 6
EU Declaration of Conformity ...................... 7

User’s Manual –AREBOS Automatic Cable Rewinder
3
Thank you for purchasing our product. Please read the instruction manual carefully before using
the product for the first time. If you leave the product to third parties, this operating manual must
also be handed over. Keep the instruction manual for later reference. The drawings in this guide
may not match the physical objects. Please refer to the physical objects.
1. Safety Instructions
1.1 Explanation of the symbols
This product must not be disposed of with household waste!
By means of a CE marking, it can be recognized that a product
complies with the legal requirements of European legal standards
and therefore may be traded within the European Community.
Restriction of the use of certain hazardous substances in the field of
heavy metals, brominated flame retardants and plasticisers to
protect human health and the environment.
This product has been tested and certified Intertek.
The symbol "GS" stands for tested safety. Products marked with this
symbol comply with the requirements of the German Product Safety
Act (ProdSG).
Warning of electrical voltage!
Warning! Read the safety instructions carefully. Failure to follow the
safety precautions could result in serious injury or damage. Keep the
operating instructions in a safe place.

User’s Manual –AREBOS Automatic Cable Rewinder
4
1.2 Safety Warnings
•The device must not be used by children under 16 years of age or persons with reduced
physical, sensory or mental abilities or lack of experience and/or knowledge.
•Risk of suffocation - Do not allow children to play with the device.
•Do not operate the device in rooms where there is a risk of explosion.
•Do not operate or handle the unit with wet or damp hands.
•Do not immerse the unit under water.
•Only use the unit under supervision.
•Check the unit for possible damage before each use. Do not use defective units or parts of
the unit. In case of damage, contact a specialist or customer service.
•Never use the device if there is damage to the electrical cables or the mains connection.
•Insert the power plug into a properly fused power outlet.
•Unplug the power cord from the wall outlet by holding the power plug before performing
maintenance, servicing or repair work on the equipment.
2. Intended Use
The device serves as an extension cable for an electrical connection. There is no temperature switch
to prevent overheating! When in use, the drum must be unrolled completely to avoid heating or fire
of the cables (inductive resistance). Unauthorized structural changes, additions or modifications to
the unit are prohibited and will void the warranty. Before using the device, the user must have read
and understood these operating instructions, in particular the safety instructions.
3. Assembly
Install the unit on the wall in accordance with the above safety regulations. Make sure, if necessary,
also with qualified personnel, that the wall is suitable for mounting.
1. Drill 2x M8 holes to match the holes in the
mounting bracket.
2. connect the cable drum with the trunnion to
the mounting bracket.
3. pull the hose, it has 2-3 locking positions
every one meter.
4.please do not pull the cable when it is
completely uncoiled.
5.please hold the connectors when the cable is
pulled back.

User’s Manual –AREBOS Automatic Cable Rewinder
5
4. Troubleshooting
The most common malfunction is: The cable cannot be retracted automatically after the cable is fully
extended.
The reason for this could be that the cable end is locked, as the stop remains in the locking point and
no additional cable can be pulled out to release it.
There are two ways to solve this:
1. hold the cable by the yellow warning mark and pull out with a jerky movement until the
cable retracts.
2. lay the drum with the right side down and pull the cable, until it backs off.
5. Technical Data
Model
Cable Length
Item Number
Voltage
Housing Material
AR-HE-AKA10
10 m
4260627425990
230V AC; 16A
PP
AR-HE-AKA15
15 m
4260627426003
230V AC; 16A
PP
AR-HE-AKA20
20 m
4260627426010
230V AC; 16A
PP

User’s Manual –AREBOS Automatic Cable Rewinder
6
6. Environmentally friendly disposal
Warning Danger of suffocation! Packaging material is dangerous for children. Never let children play
with packaging material.
6.1 Disposal and packaging
•The packaging of your device is made of materials necessary to guarantee effective protection
during transport. These materials are fully recyclable and thus reduce the environmental
impact. Dispose of the packaging in a bin for recyclable materials.
6.2 Disposal of waste equipment
•Waste equipment must be disposed of in accordance with the guidelines and regulations of
local waste disposal. Contact your local administration via the address of the nearest recycling
centre and deliver your device there.
The symbol of the crossed-out waste bin on an OLD electrical or electronic
equipment states that it must not be disposed of in household waste at the end
of its service life. Collection points for WASTE electrical and electronic
equipment are available in your area for free returns. You can obtain the
addresses from your city or local government. You can inform yourself on our
website www.arebos.de about other return options created by us.
The separate collection of WEEE is intended to prevent reuse, recycling or other
forms of recovery of WEEE, as well as the negative consequences of disposal on
the environment and human health.
Our customer service number: Tel. [phone]
fax: [phone] / e-mail: [email protected]
Office address: Canbolat Vertriebs GmbH • Gneisenaustraße 10-11 • 97074 Würzburg
Return address can be found in the imprint: https://www.arebos.de/impressum/

User’s Manual –AREBOS Automatic Cable Rewinder
7
EU Declaration of Conformity
We, the
Canbolat Vertriebs GmbH, Gneisenaustraße 10-11, 97074 Würzburg, Germany,
hereby declare that the equipment described below, by virtue of its design and construction and in
the versions placed on the market by us, complies with the relevant essential health and safety
requirements of the EU directives.
Product name: AREBOS Automatic Cable Rewinder
Model Number: AR-HE-AKA10/15/20
Article Number: 4260627425990 (10m); 4260627426003 (15m); 4260627426010 (20m)
Should the appliance be modified without our consent, this declaration of conformity will lose its
validity.
Tested acc. to:
AfPS GS 2014:01 PAK
EU Standard:
EK1 589-14:2014
EN 61242:1997+A1:08+A2:16+A13:17
Date/Manufacturer Signature/Location: Würzburg, 03.02.2022
Signature:
Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director
Representative of these instructions for use/technical data:
Dipl.-Inform. (Univ.) Korhan Canbolat, Managing Director
