AREBOS AR-HE-BN625 User manual

User’s Manual –AREBOS Nibbler machine 625 W
1
Nibbler machine
AR-HE-BN625
Please follow all security measures in this user´s manual to ensure a secure use.
Thank you for trusting in AREBOS.

User’s Manual –AREBOS Nibbler machine 625 W
2
Please read and save these instructions. Read through this user’s manual carefully before using
product. Protect yourself and others by observing all safety information, warnings and cautions.
Failure to comply with instructions could result in personal injury and/or damage to product or
property. Please retain instructions for future reference.
Safety instructions
Explanation oft the symbols
General safety instructions
•Keep work area clean. Cluttered areas can cause injuries.
•Consider work area environment. Don’t expose power tools to rain or wet soil. Don’t use
power tools in damp or wet locations. Work area should be well protected. Don’t use tool in
presence of flammable liquids or gases. Power tools produce sparks during normal operation
or when switching ON/OFF. Never use power tools in dangerous sites containing lacquer,
paint, benzene, thinner, gasoline, gases, adhesive agents, and other materials which are
combustible or explosive.
•Provide sufficient protection against electric shock. Prevent body contact with grounded
This product has been tested and certified by TÜV Süd.
The symbol "GS" stands for tested safety. Products with
marked in accordance with the requirements of the German Product
Safety Act (ProdSG).
By means of a CE marking, it can be recognized that a product complies with the
legal provisions of European legal norms and therefore may be traded within the
European Community.
This product must not be disposed of with household waste!
Warning! Read the safety instructions carefully. The Failure to follow the safety
precautions could result in serious injury or damage. Keep the operating
instructions in a safe place.
Warning! Wear safety glasses!
Protected housing (protection class II)!

User’s Manual –AREBOS Nibbler machine 625 W
3
surfaces. For example: pipes, radiators, ranges, refrigerator enclosures.
•Keep children and third parties away from work area.
•Store unused tools. When not in use, tools should be stored in dry and high or locked-up
place out of reach for children.
•Do not overload the machine! To ensure an optimum in the performance and safety of the
device, only use within the set parameters.
•Use only suitable tools. Don’t use small tools or attachments. Don’t use tool for not intended
purposes. For example: don’t use circular saw for cutting tree limbs or logs.
•Dress properly. Do not wear loose clothing or jewellery. They can get caught in moving parts.
Rubber gloves and non-skid footwear are recommended when working outdoors. Wear
protective hair covering to contain long hair.
•Use safety glasses. Also use face or dust mask if cutting operation is dusty.
•Do not damage the connection cable. Never carry tool by cord or yank it to disconnect from
the plug. Keep cord from heat and oil sources and sharp edges.
•Secure work area. It is recommended to use clamps or a vice for fixation. Please pay special
attention to your hands when operating the device!
•Do not overreach yourself. Keep proper footing and balance at all times.
•Maintain tools with care. Keep tools sharp and clean for better and safer performance.
Follow instructions for lubricating and changing accessories. Inspect extension cords
periodically and replace if damaged. Keep handles dry, clean, and free from oil and grease.
•Switch off the device and disconnect the cable before maintenance or changing accessories
e.g. blades, bits, cutters.
•Remove adjusting keys and wrenches. Always make sure that keys and adjusting wrenches
are removed from tool before turning it on.
•Avoid unintentional starting. Don’t carry plugged-in tool with finger on switch. Be sure switch
is off when plugging in.
•During outdoor work use extension cords intended for outdoor use and marked accordingly.
•Stay alert when operating the device. Do not operate tool when you are tired.
•Check damaged parts. Before further use of the tool, any covers or other parts that are
damaged should be carefully checked to determine that it will operate properly and perform
its intended function. Check for alignment of moving parts, mounting, and any other
conditions that may affect its operation. A cover or other part that is damaged should be
properly repaired or replaced by an authorized service centre unless otherwise indicated
elsewhere in this instruction manual. Defective switches should be replaced by an authorized
service centre. Do not use tool if switch does not turn it on and off.
•Do not use power tools for applications other than those specified in the instruction (other
than that for which it was designed).
•To ensure the designed operational integrity of power tools, do not remove installed covers
or screws.
•Do not touch movable parts or accessories unless the power source has been disconnected.
•Use your tool at lower input load than specified on the nameplate to increase working
efficiency and decrease wear out.
•Do not wipe plastic parts with solvent. Solvents such as gasoline, thinner, benzene, alcohol,
ammonia and oil may damage and crack plastic parts. Do not wipe them with such solvents.
Wipe plastic parts with a soft cloth lightly dampened with soapy water.
•Consult an authorized service agent in the event of power tool failure.
•Use only original replacement parts.
•This tool should only be disassembled for replacement of carbon brushes.

User’s Manual –AREBOS Nibbler machine 625 W
4
Specific safety instructions
•Wear protective glasses to protect your eyes.
•Use earplugs to keep your ears noise-free while working.
•Properly set the bit holder.
•The tool becomes very hot during operation.
•Be sure to use side handle.
•Safe operation depends on one’s work posture.
•When working at a highly elevated location, pay attention to objects and persons below.
•Wear protective shoes to protect your feet. Wear protective gloves.
•To avoid injury from accidental starting, always remove the plug from the electrical socket
before installing or removing a cutting knife.
Device design and construction
1. lower knife guide
2. cutting knife
3. upper knife guide
4. fastening screws
5. piston sleeve
6. piston fastening screw
7. housing
8. additional handles
9. vents
10. switch
11. guide

User’s Manual –AREBOS Nibbler machine 625 W
5
Technical specifications
Model
AR-HE-BN625
Rated power
625 W
Rated voltage/frequency
230 V / 50 Hz
Rotational speed, no load
1000 rpm
Cabe length
2 m
Cutting width
0.236 in (6 mm)
Cutting thickness
Steel metal sheet
0.1575 in (4 mm)
Stainless steel metal sheet
0.0984 in (2,5 mm)
Other metals (aluminium, copper)
0.1575 in (4 mm)
Plastics
0.1575 in (4 mm)
Min cutting diameter
11.81 in (300 mm)
Sound power level LwA
90.9 dB(A)
Uncertainty K
3 db(A)
Sound pressure level LpA
79.9 db(A)
Uncertainty K
3 db(A)
Vibration emission value ah
1.77 m/s²
Uncertainty K
1,5 m/s²
Weight
9.26 lbs (4,2 kg)
Dimensions without handle
11.81 x 3.15 x 13 in (30 x 8 x 33 cm)
Sound level for the operator may exceed 85 dB (A). Wear hearing protection!
Use
Principles of operation
Before first use
•Make sure that the supply voltage is conform with the voltage indicated on the device’s
name plate
•Before each connection of the power supply to the device check the switch position; the
switch must always be in “off” (“0”) position. If the switch is in “on” (“I”) position, the device
will start unintentionally upon energising which may lead to an accident!
•Check the condition of the power cord and plug. If the power cord or plug need replacement,
seek assistance from a qualified service organisation.
Switching On and Off
•Switching on: slide the switch (10) towards the working end of the device, keep sliding until
the switch locks.
•Switching off: press the rear end of the switch to release the lock - the switch will return to
off position.
Operation
•Attach two handles to the device. Properly fix the material to be cut. Hold the device with
both hands when using it. Switch the device on. Never slide the device onto the material
before it is switched on. When cutting keep the device perpendicularly to the material being

User’s Manual –AREBOS Nibbler machine 625 W
6
cut (do not tilt the device sideways, tilting may reduce efficiency of the device and may
damage the cutting knife). Never exert too much pressure when cutting curved areas. To
improve the service life of the cutting knife and the die, use cutting oils which must be
properly selected according to the processed material. Lubricate the cutting knife and the die
with machine oil. Make sure the knife is always sharp to achieve good cutting quality. Blunt /
worn out knifes should be replaced with new ones. Never sharpen worn out knives.
•Never turn the device off before finishing the work - the cutting head must be removed
from the material while the device is still on. The device may be turned off when the
cutting head is removed from the processed material.
Replacing the upper and lower knife guides
•Loosen the fastening screws (4) of the upper (1) and lower (3) guides, then remove the
guides. Clean surfaces. Fasten new guides.
Replacing the cutting knife
•Use the key provided to loosen the screw fastening the piston sleeve (6). Remove the piston
sleeve (5), disassemble worn out knife and assemble a new one. Lubricate the knife and
piston connection point with grease.
Maintenance and inspection
•Inspecting the tool
Since use of a dull tool will cause motor malfunctioning, it should be replaced with a new one
without delay when abrasion is noticed.
•Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that they are properly tightened. Should
any of the screws be loose, retighten them immediately. Failure to do so could result in
serious hazards.
•Maintenance of the motor
The rotor of the motor is the very “heart” of the power tool. Exercise due care to ensure the
rotor does not become damaged and/or wet with oil or water.
Always de-energise the device before inspection or servicing
•Keep the device clean, pay particular attention to making sure that the vents are not clogged.
Clean vents after every operation of the device.
•Service
When servicing, use only identical replacement parts. In such case please contact our service
centre. Use of any other part may create a hazard or cause product damage.
Do not attempt to modify tools or create accessories not recommended. Any such alteration
or modification is misuse and could result in a hazardous condition leading to possible
serious injury. It will also void the warranty.
Regular control of the device
•Regularly control that the device doesn´t present any damage. If there is any damage, please
stop using the device. Please contact your customer service to solve the problem.
•What to do in case of a problem?
Please contact your customer service and prepare following information:
-Invoice number and serial number (the latter is to be found on the technical plate on the
device).
-If relevant, a picture of the damaged, broken or defective part.
-It will be easier for your customer service clerk to determine the source of the problem if
you give a detailed and precise description of the matter. The more detailed your
information, the better the customer service will be able to solve your problem rapidly

User’s Manual –AREBOS Nibbler machine 625 W
7
and efficiently!
•CAUTION: Never open the device without the authorization of your customer service. This
can lead to a loss of warranty!
Disposal instruction
Disposal of the packaging
•Please make reference to the guidelines and standards for appropriate disposal of the packaging
valid in your region. In part, the package may consist of plastic bags - watch this respect, with
special care to ensure that this is not out of the reach of children. There is a risk of suffocation!
Disposal of waste equipment
•Equipment must be disposed of in accordance with the rules and regulations of the local waste
disposal.
Meaning of the "dustbin"
Protect our environment; electrical appliances do not belong in household
waste. Use the provided for the disposal of electrical equipment collection points
and enter your electrical and electronic equipment that you no longer use. They
help ensure that the potential effects of incorrect disposal on the environment
and human health to be avoided. So, do your part to recycle, recycling and other
forms of recovery of waste electrical and electronic equipment. Information on
where the devices are disposed of, please contact your local authorities or local
Governments.
Our customer service number: [phone]
Canbolat Vertriebs GmbH • Gneisenaustraße 10-11 • 97074 Würzburg

User’s Manual –AREBOS Nibbler machine 625 W
8
EU Declaration of Conformity
We,
Canbolat Vertriebs GmbH, Gneisenaustraße 10-11, 97072 Würzburg, Germany,
Hereby declare that the product named below, seen its design and construction as well as according
to our sales, has been complied with the relevant and basic health and safety EU-requirements.
Name of the product: Nibbler machine
Model Nr.: AR-HE-BN625
Art. Nr.: 4260551580536
If the product has any modification not allowed by us, this declaration loses its validity.
Tested acc. to:
EU-Standard:
2006/42/EC EN 55014-1:2006+A1:2009+A2:2011
2014/30/EU EN 55014-2:1997+A1:2001+A2:2008
2011/65/EU EN 50581:2012
EN 60745-1:2009/A11:2010
EN 60745-2-8:2009
EN 61000-3-2:2014
EN 61000-3-3:2013
AfPS GS 2014: 01 PAK
Date/Manufacturer Signature/Location: Würzburg, 20.03.2019
Identification of the signatory:
Korhan Canbolat, head of the company
Authorised representative for the technical documentation:
Korhan Canbolat
Office address:
Canbolat Vertriebs GmbH
Gneisenaustraße 10-11
D-97072 Würzburg
Return address can be found in the imprint: https://www.arebos.de/impressum/
VAT identification number: DE 263752326
Court of the Commercial Register is Würzburg, HRB 10082
WEEE Reg.-No. DE 61617071
