ARGENTO BiMax XL User manual

01
User manual
Contents
Instructions translated from the original Italian
Thank you for choosing this product.
For information, technical support, assistance or to consult the general terms of the warranty, please contact your
dealer or visit www.argentobike.it
This manual is valid for the following electrically power assisted cycles (EPAC)
BiMax XL
BiMax XL +
English
1. Introduction
2. Warnings on use and safety
3. Product overview
4. Technical data sheet
5. Assembly
6. Display
7. Battery
8. First use
9. Storage, maintenance and cleaning
10. Liability and general terms of warranty
11. Information on disposal

02
English 1. Introduction
Overview
This manual is an integral and essential part of the electrically power assisted cycle (EPAC).
Before using the bike for the first time, it is essential that users read, understand and strictly observe the requirements
outlined below.
M.T. Distribution shall not be liable for any damages caused and is in no way responsible for damages caused to property or
persons when:
- the item is used incorrectly or in a manner that does not comply with the instructions of the user guide;
- after the purchase, the item is modified or tampered with in all or some of its components.
In the interest of technological development, the manufacturer reserves the right to modify the product in question without
prior notice and without automatically updating this manual. For further information and to consult any updated versions of the
manual, please visit www.argentobike.it
Support Service
For any problem or request for clarification, please do not hesitate to contact the after-sales service team of your authorised
dealer who has expertise and specialist knowledge and access to specific tools and original spare parts.
CAUTION
Legal note for use
The product, according to the provisions of the Regulations in force regarding the conditions of conformity relating to EPAC
products (EN 15194), cannot be used on public roads, but only for exclusive use in a private area and under the direct respon-
sibility of the end user.
Visual representation of safety warnings
To identify the safety messages in the manual, the following warning symbols will be used which serve to draw the reader’s/
user’s attention in order to ensure that the electrically power assisted cycle is used correctly and safely.
CAUTION
Caution
This highlights the rules which should be observed to avoid damaging the EPAC and/or prevent potentially dangerous
situations from arising.
DANGER
Residual risks
Highlights the presence of hazards that generate residual risks to which the user must pay attention to avoid injury or material
damage.
2. Warnings on use and safety
General safety rules
Even if you are already familiar with the use of an electrically power assisted cycle, the instructions given below must be
followed and the general guidelines for operating a motorised vehicle must also be observed.
It is important to take the time required to learn the basics of using the bike to avoid serious injury which could occur when
first using it. Contact your dealer for advice on how to use the bike correctly or indications on contacting a suitable training
organisation.
The company assumes no direct or indirect responsibility arising from misuse of the bike, failure to comply with both the
highway code and the instructions in the manual, accidents or disputes caused by failure to comply with regulations or illegal
actions.
This product must be used for recreational purposes. It cannot be used by more than one person at a time and must not be
used to transport passengers.
Do not modify the intended use of the vehicle in any way. The item is not suitable for stunts, competitions, transporting
objects, towing other vehicles or trailers.

03
The A-weighted emission sound pressure level at the rider’s ear is less than 70 dB(A).
CAUTION
Using the electrically power assisted cycle
All users must have read and understood the instructions and information outlined in the manual.
If, during assembly, any factory defects are detected, certain steps are unclear or issues with assembly or adjustments occur,
do not ride the vehicle and contact your dealer or visit www.argentobike.it for for technical support.
CAUTION
Risks associated with using the electrically power assisted cycle
Despite the application of safety devices, to ensure safe use of the electrically power assisted cycle, all the safety provisions
reported in this manual must be observed.
Always maintain concentration while riding and do not underestimate the residual risks connected with use of the electrically
power assisted cycle.
CAUTION
Responsibility
The driver is obliged to use the product (pedal-assisted bicycle – EPAC) with the utmost diligence and in full compliance with
all the cycling regulations in force in the country of circulation.
The product, according to the provisions of the Regulations in force regarding the conditions of conformity relating to
EPAC products (EN 15194), cannot be used on public roads, but only for exclusive use in a private area and under the direct
responsibility of the end user.
It is important to note that when using the product, even following this manual to the letter, you are not immune from injury
caused by violations or inappropriate actions taken against other vehicles, obstacles or people. Misuse of the item or non-
compliance with the instructions provided in this manual may cause severe injury.
Riders must also ensure that the electrically power assisted cycle is kept clean, in perfect working order and serviced. They
must diligently carry out the safety checks which are their responsibility, as well as preserve all the documentation about
product maintenance.
Riders must carefully assess any weather conditions which could make it potentially dangerous to use the electrically power
assisted cycle.
This product is a vehicle, therefore, the faster is it goes, the longer the braking distance required. We, therefore, recommend
moderating your speed and maintaining an adequate braking distance if you are riding in adverse weather conditions and/
or heavy trac.
The braking distance increases on wet, slippery, muddy or icy roads and the tyre grip decreases significantly with the risk of
the wheels skidding and loss of balance compared to dry roads.
It is, therefore, essential to ride the bike with greater care, maintain a suitable speed and safety distance from other vehicles
or pedestrians.
Take extra care when riding on unfamiliar roads.
For your safety, we recommend wearing suitable protective equipment (helmet, knee and elbow pads) to protect yourself
from any falls or injuries while riding the bike. When allowing others to use the bike, ensure that the rider wears the safety
equipment and explain how to operate the vehicle. To avoid injury, do not allow other persons to use the item if they do not
know how to use it.
Wear shoes before using the item.
The bike has been designed to allow the load of a maximum overall weight (rider and any load being carried) that does not
exceed the value indicated in the product data sheet.
Avoid using the product, under all circumstances, if the total load transported exceeds the recommended weight to avoid the
risk of damaging the integrity of the structural and electronic components of the bike.
The electrically power assisted cycle is a means of transport used to transport only one person.

04
It is the user’s responsibility to ascertain the suitability of the devices used for passenger transport in terms of construction
characteristics, safety systems, anchoring systems and their installation and assembly on the electrically power assisted cycle
based on its structure and within the permitted load limits (maximum load supported by the bike and by the luggage rack
supplied, if present).
The user is also responsible for the equipment and installation of product equipment devices used for the transport of objects
and animals (e.g.: luggage racks, luggage bags, baskets, etc.) and within the expected load limits (maximum load borne by the
product and the provided luggage rack, if present).
CAUTION
The installation of accessories and equipment on the bike, not only aect the performance of the bike and how it is used, but
can also cause damage if they are unsuitable, thus compromising correct operation and safety conditions during use.
For information on the supply and installation of equipment deemed suitable for the bike, please contact your authorised
dealer or specialised operators.
Warnings for users
• The electrically power assisted cycle can only be used by adults and skilled teenagers.
• Do not take alcohol or drugs before riding the electrically power assisted cycle.
• This model of electrically power assisted cycle is designed and built to be used outdoors and exclusively in private areas.
• Do not attempt to make the electrically power assisted cycle exceed the performance levels for which it was designed;
do not ride on surfaces with a slope greater than 10%, on uneven and rough ground (bumpy road surfaces, with potholes,
depressions, obstacles).
• Never ride the electrically power assisted cycle with any of its parts disassembled.
• Avoid uneven surfaces and obstacles.
• Ride with both hands on the handlebars.
• Before use, replace any worn and/or damaged parts and check that the safety devices are working properly.
• Keep children away from plastic items (including packaging materials) and small parts that may result in suocation.
• Supervise children to make sure they do not play with the product.
• Remove any sharp edges caused by misuse, breakage or damage to the item.
• Pay particular attention when riding the bike near pedestrians and make sure you slow down and signal your presence to
avoid frightening them when arriving from behind.
• Assemble the item correctly.
CAUTION
How to use
The electrically power assisted cycle is a bicycle fitted with an auxiliary electric motor that is activated only when the pedals
are turned.
The motor does not, therefore, replace the work performed by your leg muscles, but assists them so they work less hard by
enabling the electrical and electronic components supplied with the product, i.e. the battery, handlebar controls, sensors and
control electronics (control unit).
More specifically, the electric motor is powered by a battery and operated by a unit that controls the delivery of power and
additional thrust provided to assist the eort made by the rider’s muscles when pedalling based on the real-time reading of
values detected by a series of pedal-assist sensors (PAS). These sensors are positioned on the outside of the frame or inside
the components and are based on the control parameters entered by the user via the handlebar controls (display).
The electric motor supplied with the pedal-assisted bicycle, in addition to being activated exclusively in support of the muscle
pedaling function provided by the user, will deactivate when reaching 25 km/h of speed.
The electrically power assisted cycle has been designed and built to be driven outside, on paved surfaces and/or terrain
suitable for the specific technical and structural characteristics of the product.
Any changes to its construction may compromise the behaviour, safety and stability of the electrically power assisted cycle
and may cause an accident.

05
Any other types of use, or any extensions of use beyond the one intended, do not correspond to the intended use attributed
by the manufacturer and the latter, therefore, disclaims all liability for any resulting damage.
The autonomy of the battery supplied with the electrically power assisted cycle and, therefore, the relevant distance data
estimated in km, may vary significantly depending on the specific mode of use (total load transported, how hard the rider
pedals the bike, level of electric pedal assistance detected, how often the rider departs and restarts), the mechanical and
electrical conditions of the product (tyre pressure and wear, battery eciency level) and external influences (slopes and road
surface, atmospheric conditions).
Before each use, carefully check that the brakes are working correctly and are not worn; check the tyre pressure, the wear of
the wheels and battery charge status.
Regularly check that the tightness of the various elements secured by bolts. The nuts and all the other self-tightening parts
can become loose so, these components need to be periodically checked and tightened.
Like all mechanical components, the item is subject to wear and tear. Dierent materials and components may react to wear
or stress fatigue in a variety of ways. If the useful life of a component is exceeded, it could break suddenly, causing injury
to the user. Any cracks, scratches or changes in colour in areas subject to high levels of stress indicate that the life of the
component has been reached and must be replaced.
CAUTION
Any changes to the control unit which have not been authorised by the manufacturer will exclude the latter from any liability
related to injury caused to persons and/or damage to property, and will invalidate the bike’s warranty terms and conditions.
DANGER
Risk of injury
Maintain a speed and a behaviour appropriate to your abilities to avoid causing serious damage and injury to yourself or to
other people.
CAUTION
Place of use
• The electrically power assisted cycle can be used outdoors providing there are no adverse weather conditions (rain, hail,
snow, strong wind, etc.).
• Maximum permissible temperature: +40°C
• Minimum permissible temperature: +0°C
• Maximum permissible humidity: 80%
• The environment of use must present a flat, compact, smooth asphalted surface, without any holes or dips, free of obstacles
and oil stains.
• The place of use must also be well lit by either natural or artificial light in order to ensure that the route and controls of the
electrically power assisted cycle can be viewed correctly (recommended lighting 300 to 500 lux).
Improper use and contraindications
• The actions described below, which obviously cannot cover the entire range of potential possibilities of “poor use” of the
electrically power assisted cycle, are to be considered strictly prohibited.
DANGER
It is strictly prohibited to:
• Use the electrically power assisted cycle for uses other than the ones for which it has been manufactured.
• Ride the electrically power assisted cycle if the rider’s weight exceeds the permitted limit.
• Use the electrically power assisted cycle under the influence of alcohol or drugs.
• Use the electrically power assisted cycle in areas at a risk of fire, explosions or in places with a corrosive and/or chemically
active atmosphere.

06
• Use the electrically power assisted cycle in adverse weather conditions (heavy rain, hail, snow, strong wind, etc.).
• Use the electrically power assisted cycle in poorly lit areas.
• Ride across or remain on uneven or rough ground (bumpy roads with potholes, depressions, obstacles, etc.) to avoid the
risk of falls and injury to the rider and damage to the bike.
• Charge the battery in an environment that is either too hot or insuciently ventilated.
• Cover the battery while its charging.
• Smoke or use open flames near the charging area.
• Perform any type of maintenance work with the battery connected.
• Insert limbs or fingers between the moving parts of the bike.
• Touch the brakes immediately after use due to high temperatures.
• Allow the electric and electronic components of the electrically power assisted cycle to come into contact with water or
other liquids.
• Modify or change the bike and its mechanical and electronic parts in any way to avoid the risk of structural damage,
compromising eciency and causing damage.
• If any manufacturing defects arise or if any unusual noises or faults are detected, do not use the bike and contact your
dealer or visit the www.argentobike.it website
Safety devices
It is strictly prohibited to modify or remove the safety devices for the battery, chain and other components installed on the
bike, such as the warning and identification plates.

07
Example image of bike structure and components.
1. Saddle
2. Seat post
3. Seat post clamp
4. Li-Ion battery
5. Rear luggage rack
6. Rear LED light
7. Rear mudguard
8. Rear tyre
9. Front wheel rim
10. Rear disc brake
11. Rear wheel
12. Motor
13. 7-Speed cassette
14. Rear gear change - derailleur
15. Stand (opposite side)
16. Motor port
17. Chain
18. Control unit compartment
19. PAS
20. Chainring
21. Crank arm (right side)
22. Pedal (right side)
23. Front tyre
24. Front wheel rim
25. Front wheel
26. Pass-through Pin/ Quick Release front wheel
27. Front disc brake
28. Suspension fork
29. Front mudguard
30. Front LED light
31. Frame serial number
32. Handlebar stem lock/unlock lever
33. Telescopic and folding handlebar stem
34. Handlebars
35. Rear wheel brake lever (right side)
36. Front wheel brake lever (left side)
37. Handlebar attachment
38. Gear change - indexed control
39. Bell
40. Display
41. Frame opening/closing mechanism
42. Rear spring shock absorber
3. Product overview 4. Technical data sheet

08
Product description Product code EAN code
BiMax XL AR-BI-220007 8052679456024
General information
Display LCD - CDC13-BT
Motor Bafang 48V 500W - rear brushless
Battery Li-Ion 48V 12.8Ah 614Wh - external and removable
Brakes Front and rear mechanical disc brakes - brake levers with cut-o sensor
Gear change Shimano 7 gears (1x7) - rear derailleur
Drive chain - 7 speed
Wheels 20” front and rear
Lights Front and rear LEDs
Frame aluminium 6061 - folding
Battery charger Input: AC 100V-240V 2.0A (Max) - Output: DC 54.62V 2.0A (Max)
Maximum load supported by E-bike 100 kg
Maximum load supported by luggage
rack
15 kg
Weight of E-bike 28 kg~
Full speed 25km/h
Product description Product code EAN code
BiMax XL + AR-BI-210030 8052870486905
General information
Display LCD - APT 500S
Motor Bafang 48V 500W - rear brushless
Battery Li-Ion 48V 12.8Ah 614Wh - external and removable
Brakes Front and rear mechanical disc brakes - brake levers with cut-o sensor
Gear change Shimano 7 gears (1x7) - rear derailleur
Drive chain - 7 speed
Wheels 20” front and rear
Lights Front and rear LEDs
Frame aluminium 6061 - folding
Battery charger Input: AC 100V-240V 2.0A (Max) - Output: DC 54.62V 2.0A (Max)
Maximum load supported by E-bike 100 kg
Maximum load supported by luggage
rack
15 kg
Weight of E-bike 29 kg~
Full speed 25km/h
4. Technical data sheet

09
5. Assembly
Carefully remove the bike from the packaging* and remove the protective material taking care not to damage the relevant
aesthetic parts or force the cables and pre-assembled components.
*The bike must be removed from the packaging by two adults to ensure that it is not damaged and avoid the risk of injury
and/or crushing.
Front wheel positioning
Check the correct positioning of the front wheel.
The proper orientation of the front wheel will be confirmed by verifying the correct location of the front light (positioned
frontally) and the front wheel brake disc (positioned on the left side of the front wheel).
Otherwise (fig. A), rotate the front wheel clockwise 180° until it is aligned with the frame, taking care not to force cables and
pre-assembled components (fig.B).
fig. A fig. B
Positioning the handlebar stem
Raise the handlebar stem until it is vertical; tighten the handlebar stem using the locking device indicated by the letter A.
Positioning the handlebars
Position the handlebars on the handlebar attachment taking care to centre and adjust them correctly so they slot onto the
controls, tightening the handlebar attachment lever (tightening device between the handlebars and handlebar attachment).

10
5. Assembly Handlebar stem plate assembly/disassembly instructions for handlebar installation/removal (if necessary)
Remove the handlebar stem from the top end of the
handlebar attachment as follows:
Remove the screw number 1 and then the lever number 2.
Then, remove the metal plate 3 and lastly, remove the
metal plate 4 by sliding it sideways.
Now put the previously removed handlebar stem back in
place, following the steps in reverse order.
Make sure to tighten properly to avoid dangerous
situations while riding.
Installing and positioning the seat post
Insert the seat post into the seat tube of the frame and, after positioning the saddle correctly, secure the seat post firmly using
the special clamping device (seat post clamp) on the frame.
DANGER
Minimum insertion seat post insertion limit
For structural and safety reasons, it is strictly
forbidden, when using the bike, to extract
the seat post from the seat tube of the frame
beyond the limit indicated on the latter to avoid
the risk of causing any structural fractures to the
bike and incurring serious injuries.
The seat post is deemed to be correctly and
safely positioned inside the seat tube of the
frame by inserting it so that no markings and/or
graphic indication of the minimum insertion limit
can be seen; see:
Correct position Incorrect position

11
Maximum insertion seat post insertion limit
For structural reasons, to prevent the risk of damage and
to allow proper operation of the spring-loaded rear shock
absorber that connects the saddle column tube and the
vertical frame sheath, it is strictly not recommended to
insert the seatpost groove beyond the lower limit of the
column tube until any contact, or proximity of contact, with
the shock absorber.
Adjust and verify the presence of a suitable distance
between the aforementioned components to ensure
an adequate operating margin commensurate with the
supported load (see: user weight).
Installing the pedals
Locate the right pedal (marked with the letter R) and left pedal (marked with the letter L).
Fit the right pedal (R) by inserting the threaded pin of the pedal into the corresponding crank arm on the right side of the bike
and screwing it clockwise (turn it towards the front wheel) until it is tightened using a 15mm wrench.
Fit the left pedal (L) by inserting the threaded pin of the pedal into the corresponding crank arm on the left side of the bike
and screwing it anticlockwise (turn it towards the front wheel) until it is tightened using a 15mm wrench.
CAUTION
Verify and regularly check that the various bolted elements, fastening screws, quick releases and pass-through pins are
correctly tightened, and perform an overall check to ensure that all the parts are in order.
The nuts and all the other self-tightening parts can become loose so, these components need to be periodically checked and
tightened.
The recommended tightening torques for fastening the specific parts/components on the bike (e.g. handlebars, handlebar
attachment and stem, saddle, saddle clamp, wheels, etc.) can be identified depending on the relevant elements. An average
torque of 20Nm can be used for all other fastenings.
Verification of the correct tightening of the parts/components through lever systems (quick release, handlebar attachment,
seatpost collar, etc.), in the absence of technically precise indications of the relative values, can be done by testing that the
relative part/component being fixed is not mobile and/or unstable if subjected to a vigorous attempt to remove and/or extract
(handlebar, seatpost channel, wheels, etc.) and by verifying that the tightening lever has adequate resistance during the
closing phase (such as to leave a mark on the palm of the hand used for lever tightening, so-called "imprint on palm") and,
after closing, requires a considerable force to be exerted to allow relative opening.
Rear light
The rear LED light is already installed on the end of the rear luggage rack.
It can be switched on and o manually using the button on the light itself or, at the same time as the front LED light is switched
on/o via the control on the display, if this option is included.

12
CAUTION
Battery key set
The electrically power assisted cycle is exclusively equipped with 2 keys uniquely associated with the key lock located on the
battery installed on the product to allow locking and/or unlocking by extraction.
Identify the keys on the bike, located near the handlebar or attached to another component of the electrically power assisted
cycle (frame or battery), taking care that they do not get mislaid.
CAUTION
Negative check
If, during assembly, you encounter any manufacturing defects, unclear steps or diculties with assembly, do not ride the
electrically power assisted cycle and contact the after-sales service of your authorised dealer or visit the website
www.argentobike.it
CAUTION
In the interest of technological development, the manufacturer reserves the right to modify the item with no prior notice and
this manual will not be automatically updated.
For further information and to consult any new versions of the manual, please visit www.argentobike.it
Folding the electrically power assisted cycle
Fold the pedals by operating the release mechanism
Pedal open Pedal closed

13
Release the handlebar stem closing mechanism by opening the locking device.
Release the handlebar stem closing mechanism by opening the locking device.
Turn the lever locking device (A) in the frame opening/closing mechanism in an anticlockwise direction. Pull the lever (B)
outwards until the locking hook (C) can be extracted from its seat (D).
Fold the entire frame of the electrically power assisted
cycle.
To open the bike frame, carry out the sequence in reverse.

14
6. Display
The electrically power assisted cycle has a control device on the handlebar, LCD display, powered by the battery supplied
with the bike which controls all the bike’s electrical and electronic functions.
• LCD display - CDC13-BT
Overview of controls and symbols
1. Indicator light for light ON
2. Assist: indicator of the assisted pedalling level selected
(number)
3. Error: malfunction warning light
4. Indicator light for walk assist mode ON
5. Digital speedometer: indicator light for speed detected
during use (Km/H or MPH)
6. AVG: display of average speed data recorded during last
use (Km/h or MPH)
7. MAX: display of maximum recorded speed data during
the last use (Km/h or MPH)
8. TRIP: display of partial distance travelled (Km or Miles)
9. ODO: display of total distance travelled (Km or Miles)
10. Travel mode corresponding to the selected assisted
pedalling level (ECO-STD-Turbo)
11. Indicator light for residual battery charge
12. M: mode button (MODE)
13. Button to vary and/or decrease value (-)
14. ON/OFF button
15. Button to vary and/or increase value (+).
Function description
Display on/o
Press the ON/OFF button for at least 3 seconds to switch the display on or o.
Selecting the assisted pedalling level
Press the relevant button to increase or decrease the level of selected assisted pedalling. There are between 1 and 5 assisted
pedalling levels that can be selected (Assist).
Assist level 1 sets minimum electrical support by the motor (minimum power - ECO mode).
Assist levels 2 and 3 set intermediate electrical support by the motor (minimum power - STD mode).
Service levels 4 and 5 determine the setting of the maximum electrical support provided by the motor (maximum power -
Turbo operating mode).
If you select level 0, you exclude electrical assistance from the motor.
Enabling walk assist mode
Set the walk assist level to 0 and then, press and hold the - button to enable the walk assist mode which allows you to
activate electric motor assistance up to a maximum speed of 6 Km/h.
Disable the function by releasing the button.
CAUTION
The assisted walking function must be used in accordance with the regulations in force in the country of circulation and is
allowed exclusively to ride the electrically power assisted cycle by walking next to the bicycle and holding the handlebar
knobs firmly and with both hands. It is allowed exclusively to ride the electrically power assisted cycle by walking next to the
bicycle and holding the handlebar knobs firmly and with both hands.
DANGER
It is strictly prohibited to enable the walk assist mode when you are sitting on the saddle of the electrically power assisted
cycle to avoid the danger of injury and the risk of damaging the electrical components of the bike.

15
Switching the light on/o
Press the ON/OFF button quickly to turn the front light (and rear light, if applicable) on and o.
Viewing data (AVG - MAX - TRIP - ODO)
The data available on speed (AVG and MAX) and distance (TRIP and ODO) will be displayed alternately and automatically in
sequence: AVG - MAX - TRIP - ODO.
The partial usage data (TRIP - AVG - MAX) will automatically reset after the display is turned o.
Indicator light for residual battery charge
The battery charge level is shown on the display screen as a number of dashes between 0 and 5.
If there are 5 dashes, it means that the battery is charged to the maximum percentage defined and detected instantly.
Less dashes are shown to indicate a decrease in the battery charge level available and subsequent autonomy.
The level of the battery charging indicator may fluctuate depending on how the electrically power assisted cycle is being
used, for example, when going up a slope, the level displayed can drop rapidly as there is a much higher battery consumption.
The individual dashes indicate the specific battery charge range detected at the time and do not necessarily indicated a
percentage of the residual autonomy.
Malfunction indicator light
If a malfunction of the bike’s electrical and/or electronic system is detected, the relevant warning light will appear on the
display screen and the relevant identification Error Code will be displayed at the same time
Error Code Malfunction description
2 Malfunction when using the walk assist mode lever
3 Brake sensor malfunction
4 Control unit malfunction
7 Control unit overtemperature
8 High voltage protection (voltage above threshold)
10 Motor malfunction (excessive power consumption)
11 Motor hall sensor malfunction
17 Display-control unit wiring communication malfunction
18 Display-control unit programming communication malfunction
19 Brake sensor malfunction
20 Motor block
Parameter configuration
Press the M button for at least 3 seconds to access the configuration menu and then, quickly press the M button to confirm
the data entered and display the next parameter to be configured.
Select the value for the individual parameter by pressing the + or - buttons and confirming it by pressing the M button (quickly
to access the next parameter).
The sequence of parameters that can be configured is shown below:
P1 - Unit of measurement:
Press the + or – buttons to select the unit of measurement for the speed and travel data displayed on the display: International
metric system (Km/h and Km) or British imperial system (MPH and Mile)
P2 - User password ON/OFF display:
Available options = on / o
OFF = selecting “o”, confirmed by pressing the M button, excludes the user password request (identification code) to allow
the user to access and activate the display and allow full control of all the functions provided for the electrically power
assisted cycle.
The display controls and functions will be immediately accessible after pressing the ON button.
ON = by selecting the data "on", confirmed by pressing the M button, the configuration parameter is enabled which provides
for the activation of the display and access to all the functions provided for the complete management of the pedal-assisted
bicycle exclusively after entering a user password (identification code).
Display controls and functions, after pressing the ON button, will only be accessible after entering the user password previ-
ously set (P3).

16
P3 - User password:
Parameter only displayed after the “ON” option has been selected which allows the user to enable the display access config-
uration exclusively by entering the password (numeric identification code consisting of 4 digits) previously set and confirmed
as follows:
- select the 4 digits which make up the password by pressing the + and - buttons and confirming them individually by
pressing the ON/OFF button
- confirm the numeric identification code consisting of 4 numbers by pressing the M button.
0000 - System parameter setting password:
If incorrect data on the speed (Km/h and Km) and distance (MPH and Mile) are shown on the display, contact the after-sales
technical support service for assistance: www.argentobike.it/assistenza/
• LCD DISPLAY – APT 500S
Overview of controls and symbols
1. AVG: display of average speed data recorded during
last use (Km/h or MPH)
2. MAX: display of maximum speed data recorded during
the last use (Km/h or MPH)
3. Digital speedometer: indicator light for speed detected
during use (Km/H or MPH)
4. Indicator light for lights ON
5. Indicator light for instant motor deactivation by
brake lever operation with cut-o sensor supplied (if
included)
6. Indicator light for residual battery charge
7. Indicator light for the assisted pedalling level selected
(number) or indicator light for walk assist mode ON (P)
8. Indicator light for walk assist mode ON corresponding
to a value of 1 or above
9. Malfunction warning light
10. Time: display of overall usage time (Hours:Minutes)
11. ODO: display of total distance travelled (Km or Miles)
12. TRIP: display of partial distance travelled (Km or Miles)
13. Button to vary and/or decrease value (-)
14. Button to vary and/or increase value (+)
15. M: mode button (MODE)
16. ON/OFF button

17
Function description
Display on/o
Press the ON/OFF button for at least 1 second to switch the display on or o.
Selecting the assisted pedalling level
Press + or - button to increase or decrease the level of selected assisted pedalling.
The display is pre-configured to oer the user 5 dierent assisted pedalling levels (variable values from 1 to 5).
Assistance level 1 provides minimum electrical assistance from the motor.
Assistance level 5 provides maximum electrical support from the motor.
If you select level 0, you exclude electrical assistance from the motor.
When configuring the display, you can modify the parameter for the interval of assisted pedalling that can be selected: 0-3,
0-5 and 0-9.
These options do not change the minimum and maximum value of electrical assistance provided by the motor, but only allow
a dierent distribution of the pedalling assistance levels between the minimum and maximum value as described in the table
below:
Number of assisted pedalling levels
3 (1-3) 5 (1-5) 9 (1-9)
- 1 1
- - 2
1 2 3
- - 4
- 3 5
2 - 6
- 4 7
- - 8
3 5 9
Enabling walk assist mode
Select a walk assist level equal to or greater than 1 and then, press and hold– button to enable the walk assist mode which
allows you to activate electric motor assistance up to a speed of 6Km/h.
Disable the function by releasing the button –.
CAUTION
The walk assist mode must be used in compliance with the regulations in force in the country of use and is only allowed when
pushing the electrically power assisted cycle and walking alongside it holding the handlebar grips firmly with both hands.
DANGER
It is strictly prohibited to enable the walk assist mode when you are sitting on the saddle of the electrically power assisted
cycle to avoid the danger of injury and the risk of damaging the electrical components of the bike.
Switching the light on/o
Press the + button for at least 1 second to light up the display screen and switch the front light and rear on or o.
Viewing data (AVG - MAX - TRIP - ODO - Time)
Press the M button quickly to view the successive usage data available for the speed (AVG and MAX), distance travelled (TRIP
and ODO) and duration (Time).
AVG - MAX: the data is temporarily displayed in line with the digital speedometer followed by automatic reset of the data for
the instant speed.
TRIP - ODO - Time: the selected data remains permanently displayed until the display is turned o.
Press the + and - buttons at the same time for 1 second to reset the AVG, MAX, TRIP and TIME data.

18
Indicator light for residual battery charge
The battery charge level is shown on the display screen as a number of dashes between 0 and 5.
If there are 5 dashes, it means that the battery is charged to the maximum percentage defined and detected instantly.
Less dashes are shown to indicate a decrease in the battery charge level available and subsequent autonomy.
The level of the battery charging indicator may fluctuate depending on how the electrically power assisted cycle is being
used, for example, when going up a slope, the level displayed can drop rapidly as there is a much higher battery consumption.
The individual dashes indicate the specific battery charge range detected at the time and do not necessarily indicated a
percentage of the residual autonomy.
Malfunction indicator light
If a malfunction of the bike’s electrical and/or electronic system is detected, the relevant warning light will appear on the
display screen and the corresponding identification Error Code will be displayed at the same time.
Error Code Malfunction description
04 Accelerator malfunction
06 Low voltage protection (voltage below threshold)
07 High voltage protection (voltage above threshold)
08 Motor hall sensor malfunction
09 Motor phase line malfunction
10 Control unit over temperature
11 Motor over temperature
12 Current sensor malfunction
13 Battery over temperature
14 Motor malfunction
21 Speed sensor malfunction
22 BMS malfunction
30 Communication malfunction
Parameter configuration
Press the M button for at least 2 seconds to access the configuration menu and then, quickly press the M button to confirm
the data entered and display the next parameter to be configured.
Select the desired value for the individual parameter by pressing the + or - buttons and confirm it by pressing the M button
(quickly to access the next parameter or for at least 2 seconds to exit the configuration menu).
The sequence of parameters that can be configured is shown below:
S7 - Unit of measurement:
press the + or - buttons to select the unit of measurement for the speed and distance data shown on the display:
international metric system (Km/h and Km) or British imperial system (MPH and Mile) B1 - Backlight:
press the + or - buttons to change the brightness level of the display screen (from 1 to 5).
0FF - Automatic switch o:
press the + or - buttons to set the minutes before the automatic switch-o of the display (from 1 to 15).
The function can be disabled by selecting 0.
Hd - System parameter:
Pre-defined value = 22
CAUTION
If faulty data for speed and distance are shown on the display, reset the correct value indicated by using the + or - buttons.
Pd - Password:
enter the password “1919” using the + or - buttons and confirming each single digit by pressing the M button to configure the
additional usage parameters.

19
7. Battery
SL - Speed limiter:
press the + or - buttons to increase or decrease the set speed limit (from 10 to 100).
CAUTION
In compliance with the requirements of European Directive 2002/24/EC, the pedal assistance provided by the electric motor
supplied with the product will automatically be cut o when a speed of 25 km/h is reached, even a higher value has been set.
HL - System parameter: Pre-defined value = 6
CAUTION
If faulty data for speed and distance are shown on the display, reset the correct value indicated by using the + or - buttons.
PA - Number of pedal assistance levels available:
press the + or - buttons to set the number of pedal assistance levels that can be selected while using the bike.
Values available:
UbE = test value, do not set
0-3 = 3 pedal assistance levels available (from 1 to 3)
0-5 = 5 pedal assistance levels available (from 1 to 5)
0-9 = 9 pedal assistance levels available (from 1 to 9)
The electrically power assisted cycle starts and powers its electrical and electronic functions through the lithium-ion battery
supplied with the product, correctly recharged and installed, turning the key clockwise to the ON position.
A. Unlock/lock/battery
activation lock
B. Charging socket for
battery charger (lock
side or opposite side
location)
C. Battery residual
charge status
indicator
Battery removal and insertion
The battery can be removed from the bike to prevent theft, for charging or to be stored in optimal conditions.
Removing the battery:
Insert the key supplied in the lock on the battery. Turn the key counter-clockwise to the unlocking position. After folding the
saddle and/or checking that its position does not obstruct the removal of the battery, grab the handle on the battery and pull it
out from its housing fixed to the frame, by pulling upwards.
Inserting the battery:
Insert the key supplied in the lock on the battery. Turn the key counter-clockwise to the unlocking position. After having tilted
the saddle and/or verified that its position does not obstruct the introduction of the battery, insert it in the appropriate seat
fixed to the frame by pushing down until it stops. Turn the key clockwise to the locked position to ensure that the battery is
secured to the frame.
Check that the battery is correctly installed and secured by trying to pull it out and/or making sure that it is securely fastened
to the frame and does not move.

20
7. Battery
Battery charging
Before using the electrically power assisted cycle for the first time, the battery must be fully charged using the battery charger
supplied.
The average time to fully charge the battery, which varies according to the residual charge level of the battery, can be
estimated as shown in the sheet below.
We recommend charging the battery with the specific battery charger after each use of the electrically power assisted cycle.
CAUTION
Only use the battery charger provided or an approved model with the same technical specifications, taking care to observe
the same methods and precautions of use indicated on the charged or in the manual.
EPAC Battery charger INPUT Battery charger OUTPUT Recharge life
BiMax XL AC 100V-240V 2.0A (Max) DC 54.62V 2.0A (Max) 5-7 h
BiMax XL + AC 100V-240V 2.0A (Max) DC 54.62V 2.0A (Max) 5-7 h
Make sure that the electrically power assisted cycle is switched o and the battery is switched o/disabled (if required by the
model of battery supplied with the bike).
Make sure that the battery charger, its jack and the charging port of the battery are dry.
Connect the battery charger jack to the battery charging port and then, the mains power socket (230V/50Hz).
There is a red indicator light when the battery is charging. When the indicator light turns green, it signals that the battery
charging cycle has been completed.
Disconnect the battery charger jack from the battery charging port and then, the mains power socket.
A. Battery charging jack
B. Power supply jack
C. Battery charging LED indicator
light
CAUTION
Using a battery charger that diers from the one supplied, which is not suitable or approved, to charge the e-bike battery may
damage it or involve other potential risks.
Never leave the e-bike unsupervised while it is charging.
Do not switch on or ride the e-bike during charging.
Keep out of the reach of children during charging. Do not place anything on top of the battery charger during use; do not
allow any liquid or metal to get inside the battery charger.
The battery charger heats up during the battery charging cycle.
Do not charge the battery immediately after use. Allow the battery to cool down before charging it.
The item should not be charging for extended periods. Overcharging reduces battery life and poses additional potential
hazards.
Do not allow the battery to completely discharge to avoid damaging it and causing it to lose eciency.
