Argo-Hytos CFP 03 User manual

Subject to change · 40719700 · 1217 · EN
Page 1
www.argo-hytos.com
Safety and operating instructions
Read safety and operating instructions before use.
Note: The indicated data only serve to describe the product.
Specifications regarding the use of this product are only examples and suggestions.
Catalog specifications are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS GMBH, even in the case of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a configuration example.
The delivered product may thus differ from the illustration.
Compact Filter Pack
CFP 03
Manual

Subject to change · 40719700 · 1217 · EN
Page 2 www.argo-hytos.com
Contents
Compact Filter Pack CFP 03
Contents........................................................................................................................................................................ 2
1. In this documentation.............. ................................................................................................................................... 4
1.1 Applicability of this documentation...................................................................................................................................4
1.2 Required and additional documentation .......................................................................................................................... 4
1.3 Presentation of information............................................................................................................................................. 4
1.3.1 Safety instructions ........................................................................................................................................................... 4
1.3.2 Symbols........................................................................................................................................................................... 5
1.3.3 Terms .............................................................................................................................................................................. 5
1.3.4 Abbreviations .................................................................................................................................................................. 5
2. Safety instructions........................................................................................................................................................ 6
2.1 In this chapter ................................................................................................................................................................. 6
2.2 Intended use ................................................................................................................................................................... 6
2.3 Improper use ................................................................................................................................................................... 6
2.4 Reasonably expectable misapplication.............................................................................................................................. 6
2.5 Qualification of personnel................................................................................................................................................ 6
2.6 General safety instructions............................................................................................................................................... 7
2.7 Product and technology related safety instructions .......................................................................................................... 7
3. General instructions ..................................................................................................................................................... 8
4. Scope of delivery.......................................................................................................................................................... 9
4.1 Scope of components...................................................................................................................................................... 9
4.2 Additional components ................................................................................................................................................... 9
5. About this product ..................................................................................................................................................... 10
5.1 Performance specification.............................................................................................................................................. 10
5.2 Device description ......................................................................................................................................................... 10
5.3 Component overview .................................................................................................................................................... 10
5.4 Identification of the product.......................................................................................................................................... 11
6. Transport and storage................................................................................................................................................ 12
6.1 Transport....................................................................................................................................................................... 12
6.2 Storage ......................................................................................................................................................................... 12
7. Assembly..................................................................................................................................................................... 13
8. Commissioning ........................................................................................................................................................... 14
8.1 Before commissioning ................................................................................................................................................... 14
8.2 Commissioning.............................................................................................................................................................. 14
8.3 After switching on......................................................................................................................................................... 14
8.4 Working with the additional return-suction set .............................................................................................................. 14
8.5 End of operation ........................................................................................................................................................... 14
8.6 Change of oil type......................................................................................................................................................... 14
8.7 In case of power failure ................................................................................................................................................. 14
9. Operation.................................................................................................................................................................... 15
9.1 Filtering hydraulic fluids when refilling........................................................................................................................... 15
9.2 Filtering fluids in the bypass flow................................................................................................................................... 16
9.2.1 Working with the additional return-suction set .............................................................................................................. 16
10. Maintenance / repair.................................................................................................................................................. 17
10.1 Maintenance ................................................................................................................................................................. 18
10.2 Maintenance overview................................................................................................................................................... 18
10.2.1 Cleaning / repairing the suction strainer......................................................................................................................... 18
10.3. Replacing the filter element........................................................................................................................................... 19
10.3.1 Removing the filter element........................................................................................................................................... 19
10.3.2 Installing the filter element ............................................................................................................................................ 19
11. Decommissioning ....................................................................................................................................................... 20
12. Disassembly ................................................................................................................................................................ 21

Subject to change · 40719700 · 1217 · EN
Page 3
www.argo-hytos.com
13. Disposal....................................................................................................................................................................... 22
14. Extension..................................................................................................................................................................... 23
14.1 Optional accessories ...................................................................................................................................................... 23
14.1.1 Suction-return set......................................................................................................................................................... 23
14.1.2 Additional adapter......................................................................................................................................................... 23
15. Troubleshooting.......................................................................................................................................................... 24
15.1 How to proceed ............................................................................................................................................................ 24
15.2 Fault table ..................................................................................................................................................................... 25
16. Technical data ............................................................................................................................................................. 26
16.1 Technical data................................................................................................................................................................ 26
16.2 Device dimensions......................................................................................................................................................... 26
16.3 Operating conditions..................................................................................................................................................... 27
16.4 Hydraulic circuit diagrams.............................................................................................................................................. 27
17. Appendix..................................................................................................................................................................... 28
17.1 Declaration of Conformity ............................................................................................................................................. 28
17.2 Spare parts list............................................................................................................................................................... 29

Subject to change · 40719700 · 1217 · EN
Page 4 www.argo-hytos.com
1. In this documentation
1.1 Applicability of this documentation
This documentation is applicable for the following product:
›Compact Filter Unit CFP 03
This documentation is written for technicians, operators, service engineers and system operators.
This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing,
dismantling and simple troubleshooting.
›Read this document completely and in particular Chapter 2, “Safety Instructions”, before you work with the product.
1.2 Required and additional documentation
Do not commission the product until you have received the documentation marked with the book icon and before you have under-
stood and complied with the information therein.
Title Number of document 1.2.1 Document type
Data sheet 80.62 PDF
Table 1: Required and supplementary documentation
1.3 Presentation of information
So that this document can help you to work quickly and safely with your product, we use standardized safety instructions, symbols,
terms and abbreviations. For better understanding, these are explained in the following sections.
1.3.1 Safety instructions
In this documentation, safety instructions are faced with a sequence of actions which would result in the danger of personal injury or
damage to equipment. The measures described to avoid theses hazards must be observed.
DANGER
Type and source of danger
›Consequences of the danger
›Escaping or averting the danger
›Rescue (optional)
›Warning signal: draws attention to the danger
›Signal word: indicates the severity of the danger
›Type and source of danger: specifies the type and source of danger
›Consequences: describes the consequences in the event of non-compliance
›Action: indicates how the danger can be avoided
Table 2: Danger classes according to ANSI Z536.6-2006
Warning sign, signal word Meaning
DANGER Indicates a dangerous situation which results in death or serious injury if not avoided.
WARNING Indicates a dangerous situation which may result in death or serious bodily injury if not avoided.
CAUTION Indicates a dangerous situation which may result in light to moderate injury if not avoided.
NOTE Indicates property damage: The product or surrounding could be damaged.

Subject to change · 40719700 · 1217 · EN
Page 5
www.argo-hytos.com
1.3.2 Symbols
The following symbols indicate notes which are not safety-relevant but increase the intelligibility of the documentation.
Table 3: Meaning of symbols
1.3.3 Terms
In this documentation the following terms are used:
Table 4: Terms
1.3.4 Abbreviations
In this documentation the following abbreviations are used:
Table 5: Abbreviations
Term Meaning
Term Meaning
CFP Compact Filter Pack
Symbol Meaning
If this information is not observed, the product cannot optimally be used or operated
>Singular, independent action step / instruction
1.
2.
3.
This symbol indicates danger to equipment, material and environment
This symbol indicates the risk of personal injury (minor injury).
This symbol indicates the risk of personal injury (death, serious bodily injury).
This symbol specifies that protective gloves should be worn.
This symbol specifies that safety shoes should be worn.
This symbol specifies that protective goggles should be worn.
This symbol specifies that the unit should be disconnected from the power supply.
Numbered instruction
The numbers indicate that the action steps follow one another

Subject to change · 40719700 · 1217 · EN
Page 6 www.argo-hytos.com
2. Safety instructions
2.1 In this chapter
This product was manufactured according to the generally recognized standards of engineering. Nevertheless, there is a danger of
injury or damage if you do not observe this chapter and the safety instructions in this documentation.
›Read this document thoroughly and completely before working with the product.
›Retain this document and ensure that it is available for all users at all times.
›Always include the necessary documentation when passing the equipment along to a third party.
2.2 Intended use
This product is a compact service device.
You may use the product for the following:
›for filtration of lubricating and hydraulic oils during filling of machines and systems, taking the technical data into account;
›for filtration of hydraulic fluids in the bypass flow on machines and systems, taking the technical data into account.
This product is intended for professional use only, not for private use.
"Intended use" also includes that you have completely read and understood this documentation, in particular chapter 2
"Safety Instructions".
2.3 Improper use
Any other use than the intended use described, is improper and inadmissible.
If unsuitable products are installed or used in safety-related applications, unintended operating states may occur in the application,
which may cause personal injury and / or property damage.
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documen-
tation, e.g. in explosion protection areas or in safety-related parts of a control system (functional safety).
ARGO-HYTOS Polska Sp.z.o.o assumes no liability for damages resulting from an improper use. The risks associated with improper
use are solely with the user.
2.4 Reasonably acceptable misapplication
The delivery of the following media is forbidden:
›flammable liquids such as petrol or thinner (explosion hazard)
›foodstuffs
The device is not suitable for sucking sludge and sediment.
The operator alone is liable for damages resulting from improper use.
2.5 Qualification of personnel
The operations described in this document require fundamental knowledge of mechanics and hydraulics as well as knowledge of the
appropriate technical terms. In order to ensure safe use, these operations may therefore only be carried out by a correspondingly
skilled worker or an instructed person under the guidance of a skilled worker.
A skilled worker is someone who can - based on his / her technical education, knowledge and experience as well as knowledge of
the respective regulations of the jobs assigned to him / her - recognize possible dangers and ensure appropriate safety measures.
A skilled worker must observe the relevant technical regulations.
The device may be repaired or maintained by the following individuals:
›Qualified / specialized staff with adequate training.
Work on electrical components:
›Only electrical specialists with adequate training.

Subject to change · 40719700 · 1217 · EN
Page 7
www.argo-hytos.com
2.6 General safety instructions
›Observe the valid regulations for accident prevention and environmental protection.
›Observe the safety regulations and requirements of the country in which the product is used / applied.
›Only use ARGO-HYTOS products that are in technically perfect condition.
›Observe all instructions on the product.
›People who assemble, operate, disassemble or maintain ARGO-HYTOS products are not to be under the influence of alcohol,
other drugs or medications that affect the responsiveness.
›Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable
spare parts.
›Observe the technical data and ambient specifications specified in the product documentation.
›If unsuitable products are used or installed in safety-relevant applications, unintended operating states may occur in the application,
which can cause personal injury and / or material damage. Therefore only use the product in safety-relevant applications if this use
is explicitly specified and permitted in the product documentation.
›You may only put the product into operation, when it has been established that the final product (e.g. a machine or system), into
which the ARGO-HYTOS products have been installed, complies with the country-specific regulations, safety regulations and
standards of the application.
2.7 Product and technology related safety instructions
CAUTION
Leaked hydraulic oil
Environmental hazard / risk of slipping.
›In case of spills, cover the oil-covered surface immediately with an oil-binding medium.
›Then immediately dispose of the oil-binding medium according to the national environmental regulations.
Ignition hazard
Risk of electrostatic charge by poorly conducting hydraulic fluid.
› If the electrical conductivity of the hydraulic fluid is not known, please contact the manufacturer of the
hydraulic fluid.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation.
›Allow the filter unit to cool down before touching it.
CAUTION

Subject to change · 40719700 · 1217 · EN
Page 8 www.argo-hytos.com
3. General instructions
For prevention of material damage and product damage
CAUTION
Danger due to improper handling
Property damage
›The filter unit may only be used in accordance with Section 2.2, “Intended use”.
Leakage or spillage of hydraulic fluid
Environmental pollution and ground water contamination.
›Use oil binding agents in order to bind leaked hydraulic oil.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceed during
operation.
›Allow the filter unit to cool down before touching it.
Contamination due to fluids and foreign bodies
Premature wear - malfunction - risk of damage - property damage
›Ensure cleanliness during installation in order to prevent foreign bodies, such as welding beads or metal chips,
from entering the hydraulic lines, leading to premature wear or malfunction.
›Make sure that connections, hydraulic lines and attachment parts (e.g. gauges) are free of dirt and chips.
›Prior to commissioning, check that all hydraulic and mechanical connections are connected and tight,
and that all gaskets and seals of the plug connectors are correctly assembled and undamaged.
›For removal of lubricants and other contaminants, use residue-free industrial wipes.
›Make sure that all connections, hydraulic lines and attachment parts are clean.
›Ensure that no contaminants enter when closing the connections.
›Make sure that no detergents enter the hydraulic system.
›Do not use cotton waste or faying cleaning rags for cleaning.
›Do not use hemp as sealing agent.
Improper cleaning
Premature wear - malfunction - risk of damage - property damage
›Close all openings with appropriate protective fittings to prevent penetration of detergents.
›Do not use aggressive cleaning agents for cleaning. Clean the product with a suitable cleaning fluid.
›Do not use a high pressure cleaner.
›Do not use compressed air to clean function interfaces such as seal areas.
CAUTION

Subject to change · 40719700 · 1217 · EN
Page 9
www.argo-hytos.com
4. Scope of delivery
4.1 Scope of components
The unit is supplied with a set of hydraulic hoses. The suction hose DN8 is installed in the suction port of the pump. The oil sucked
from the system / barrel is pumped by the pump into the main filter and then, after being filtered, it is transferred to a DN6,5
discharge hose, connected to the filter output. Both hoses are provided with plugs in order to avoid a possible leakage of residual oil
during storage and transport. The plugs are installed on the free ends of the hoses. The CFP unit is delivered with electric cable and
electric plug.
4.2 Additional components
One additional component for the CFP Compact Filter Pack is a return-suction set (the picture below). The set has to be ordered
separately.
Fig. 1: Additional component: suction-return set
If the suction-return set is installed in plastic tanks, additional adapter has to be ordered (the picture below). The adapter has to be
ordered separately.
Fig. 2: Additional component: adapter for installation in plastic tanks

Subject to change · 40719700 · 1217 · EN
Page 10 www.argo-hytos.com
5. About this product
5.1 Performance specification
The CFP is a portable service unit dedicated to oil pumping, tank filling and off-line filtration of hydraulic fluids and lubricants with a
viscosity of 10 mm2/s - 600 mm2/s (in continuous operation) or 800 mm2/s max. (in short-term operation).
The volume flow is 3 l/min (50 Hz).
The operating temperature is in the range of 0 °C to 60 °C.
5.2 Device description
The Compact Filter Pack CFP consists of a support frame in which the following major units are integrated:
1. A filter pump unit consisting of a gear pump and an electrical 1-phase motor. The pump is equipped with 3.5 bar pressure relief
valve and a suction filter of 700 µm filter fineness. The motor is equipped with an ON/OFF switch and a power cord with a plug.
2. A filter with an exchangeable filter element and a gauge as maintenance indicator. The clogging indicator indicates the need to
replace the filter element. Depending on the needs there are filter elements of a different filter fineness: 5, 10, or 16 µm.
5.3 Component overview
Fig. 3: CFP 03 component overview 1
Electric motor
Pump with
relief pressure
valve
Filter
Filter element
Filter cover gasket
Filter cover
Suction filter
Clogging indicator
Suction hose
Pressure hose
Suction hose
plug
Pressure hose
plug
Plug with
power cord

Subject to change · 40719700 · 1217 · EN
Page 11
www.argo-hytos.com
5.4 Identification of the product
The unit is provided with its own permanent and readable nameplate, located in a prominent position and containing the basic data
of the unit.
Fig. 5: Nameplate
NOTE
Nameplates are documents which must not be changed or removed.
›Damaged or lost nameplates have to be replaced true to the original.
Fig. 4: CFP 03 component overview 2 + 3

Subject to change · 40719700 · 1217 · EN
Page 12 www.argo-hytos.com
6. Transport and storage
6.1 Transport
CAUTION
Falling unit through incorrect transport
Injury and property damage
›Wear safety shoes when transporting the filter unit.
A plastic holder is attached to the unit’s frame to make its transport easier. Due to the fact that the weight does not exceed 10 kg,
the device can be carried manually. When carrying the device, ensure a secure position of the unit and make sure that the handles
are free from residual oil. This will prevent undesirable slipping of the device and falling on the feet of the person carrying the unit.
The bottom part of the frame also serves as the base of the unit and as a collecting tray where the residual oil is collected.
The filter unit CFP should be stored in an enclosed area to protect it from humidity and condensation.
6.2 Storage
The ambient temperature during storage of the filter unit CFP should be between + 5 °C and + 30 °C at a humidity of 80%.
Before storage over a period of more than 6 months, the unit should be filled with oil in order to preserve it against corrosion.
CAUTION
CAUTION
Risks related to chemical reactions
Risk of injury
›Chemical substances in the immediate vicinity of the filter unit may react and lead to destruction of the
device and to injuries of persons who are in the immediate vicinity of the device.
›Storage in the immediate vicinity of chemically active substances such as acids, alkalis, salts, organic solvents
and rechargeable batteries is prohibited.
CAUTION
Fig. 6: Transport

Subject to change · 40719700 · 1217 · EN
Page 13
www.argo-hytos.com
7. Assembly
WARNING
Faulty power supply
Risk of death and injury
›Always consider the country-specific regulations.
Let - prior to commissioning - an electrician check whether:
›the mains voltage matches with the voltage specified on the type plate of the motor,
›the power source has appropriately been secured,
›the cross-section is of sufficient size,
›cable and connection to the power source are in perfect condition.
Specifically, proceed with the following steps:
›connect the 230 V voltage plug to the local power supply.

Subject to change · 40719700 · 1217 · EN
Page 14 www.argo-hytos.com
8. Commissioning
8.1 Before commissioning
›Ensure cleanliness during installation in order to prevent debris such as welding beads or metal shavings from entering the
hydraulic lines and causing wear and malfunctions in the product.
›Make sure the connections, hydraulic lines and fittings are free of dirt and chips
›Prior to commissioning, verify that all hydraulic and mechanical connections are connected and tight, and that all of the
connectors' gaskets and screw connections are correctly installed and undamaged.
›Use residue-free industrial wipes in order to remove lubricants and other contamination.
›Make sure that the connections, hydraulic lines and fittings are clean.
›Make sure that no contaminants penetrate while closing the connections.
›Make sure that no cleaning agents enter the hydraulic system.
›Do not use steel wool or fraying cloths for cleaning.
8.2 Commissioning
1. Remove the plugs from the free ends of suction and pressure hose.
2. Place the suction and discharge hose in the oil container. Make sure that they are immersed far enough below the liquid level.
3. Connect the voltage plug with the 1-phase socket.
4. Turn the filter unit on using the ON/OFF switch (circuit breaker).
8.3 After switching on
1. Check the filter unit for leaks.
8.4 Working with the additional return-suction set
1. Install the return-suction adapter in the oil tank.
2. Remove the plugs from the free ends of the suction and pressure hose.
3. Connect the suction and pressure hose to the appropriate quick couplings of the adapter.
4. Connect the voltage plug of the 1-phase socket.
5. Turn the filter unit on using the ON/OFF switch (circuit breaker).
8.5 End of operation
1. Turn the filter unit off at the ON/OFF switch (circuit breaker).
2. Unplug the power cord.
3. Remove the suction and pressure hose from the oil container.
4. In case of working with a return-suction adapter remove the adapter from the tank.
5. Clean the hoses and attach the hose plugs to free ends of the hoses.
6. When the device ends working, drain off the residual oil into a separate container.
8.6 Change of oil type
Prior to pumping another kind of oil:
1. Remove the filter element.
2. Clean the unit from the residual oil.
3. Install the new filter element in the housing.
4. Pump the oil into the target container.
8.7 In case of power failure
In order to prevent unintentional starting of the unit, always switch off and unplug the unit.

Subject to change · 40719700 · 1217 · EN
Page 15
www.argo-hytos.com
9. Operation
CAUTION
Exposure to spilled oil
Injury / risk of slipping
›If oil leaks, the oil-covered area must be shut of immediately and covered with an oil binding medium
(risk of slipping).
Static charge
Sparking
›There is a risk of static charge when using poorly conducting hydraulic or lubricating oils.
In this case, please consult the manufacturer.
NOTE
Damage to the filter unit by missing or defective suction strainer.
Property damage.
›The strainer must be regularly checked according to the maintenance intervals and replaced if necessary.
›The filter unit is provided with a protective strainer at the suction port of the pump. It has to be serviced regularly.
A missing protective strainer may lead to destruction of the pump. (Order No. see spare parts list)
›If the protective strainer is removed, the manufacturer will resume no liability.
9.1 Filtering hydraulic fluids when refilling
1. Connect the filter unit to a power source.
2. Place the suction hose into the oil drum.
3. Place the discharge hose into a container (e.g. hydraulic tank).
NOTE
Faulty insertion of the discharge hose
›Make sure that the discharge hose is below the liquid surface.
4. Turn the filter unit on at the ON/OFF switch (circuit breaker).
5. Check the oil flow on a possibly insufficient immersion depth of the suction hose in the oil tank.
6. Using the clogging indicator, check the element for clogging at operating temperature of the medium used.
7. Check the filling level at the machine or system and turn off the filter unit at the circuit breaker, once the desired filling
quantity has been reached.
8. Clean the hoses and install plugs to their free ends. Re-attach the suction and the discharge hose at the appropriate brackets at
the filter unit.
CAUTION
Fig. 7: Filling of the small power pack with the use of the CFP

Subject to change · 40719700 · 1217 · EN
Page 16 www.argo-hytos.com
9.2 Filtering fluids in the bypass flow
1. Connect the filter unit to a power source.
2. Place the suction strainer in the tank of the machinery or equipment (e.g. hydraulic tank).
3. Place the discharge pipe in the tank of the machinery or equipment (e.g. hydraulic tank).
4. Turn the filter unit on at the ON/OFF switch (circuit breaker).
5. Check the oil flow on a possibly insufficient immersion depth of the suction hose in the oil tank.
6. Using the clogging indicator, check the element for clogging at operating temperature of the medium used.
7. Once the filtration is completed, pull the discharge hose out of the tank of the machinery or equipment (e.g. hydraulic tank) and
draw in air for a maximum of 15 seconds.
This returns residual oil from the filter housing and the lines above the oil level into the tank of the machinery or equipment via
the discharge hose.
8. Switch off the filter unit using the circuit breaker.
9. Clean the hoses and install plugs to their free ends. Re-attach the suction and the discharge hose at the appropriate brackets at
the filter unit.
9.2.1 Working with the additional return-suction set
1. Connect the filter unit to a power source.
2. Install the suction-return adapter in the oil tank.
3. Remove the plugs from the free ends of the suction and pressure hose.
4. Connect the suction and pressure hose to the appropriate quick couplings of the adapter.
5. Using the clogging indicator, check the element for clogging at operating temperature of the medium used.
6. Once the filtration is completed, pull the suction hose from the quick coupling and draw in air for a maximum of 15 seconds.
This returns residual oil from the filter housing and the lines above the oil level into the tank of the machinery via the discharge
hose.
7. Switch off the filter unit using the circuit breaker.
8. Clean the hoses and install plugs to their free ends. Re-attach the suction and the discharge hose at the appropriate brackets at
the filter unit.
9. Uninstall the suction-return adapter and attach it to the appropriate bracket at the filter unit.
NOTE
Off-line filtration in tank with only one available connection port
›Use the additional suction-return set to allow installation of two hoses (suction and return) in one port.
Fig. 8: Off-line filtration at a small hydraulic power pack with the CFP, connected to the tank via a suction-return set

Subject to change · 40719700 · 1217 · EN
Page 17
www.argo-hytos.com
10. Maintenance / repair
CAUTION
Risks related to chemical reactions
Risk of injury
›Chemical substances in the immediate vicinity of the filter unit may react and lead to destruction of the device
and to injuries of persons who are in the immediate vicinity of the device
›Storage in the immediate vicinity of chemically active substances such as acids, alkalis, salts, organic solvents
and rechargeable batteries is prohibited.
Hydraulic oil spills
Environmental hazard / risk of slipping
›Before maintenance and repair work, completely drain the unit.
›In case of spills, cover the oil-covered surface immediately with an oil-binding medium.
› Then immediately dispose of the oil-binding medium according to the national environmental regulations.
Ignition hazard
›Risk of electrostatic charge by poorly conducting hydraulic fluid.
› If the electrical conductivity of the hydraulic fluid is not known, please contact the manufacturer of the
hydraulic fluid.
Risk of burns
›Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during operation.
›Allow the filter unit to cool down before touching it.
NOTE
Impaired function by dirt ingress into the pump.
The function of the filter unit is no longer guaranteed.
›During repair work, all parts coming in contact with the hydraulic medium, must be kept free of dirt and chips.
DANGER
Danger to life
Risk of electric shock
›During repair work, turn off the unit and pull the mains plug.
DANGER
CAUTION

Subject to change · 40719700 · 1217 · EN
Page 18 www.argo-hytos.com
10.1 Maintenance
10.2 Maintenance overview
Except from the filter element and the suction strainer, the filter unit is maintenance-free.
Maintenance work Order No. Maintenance interval
Checking / changing the filter element V3.0510-53 (5 µm)
V3.0510-56 (10 µm)
V3.0510-58 (16 µm)
Once the clogging indicator changes to the
red range at a permissible viscosity
Checking / changing the suction strainer 40442600 Quarterly or with corresponding
problems (lower volume flow with clean filter
element, too loud noise level).
Table 6: Maintenance overview
10.2.1 Cleaning / replacing the suction strainer
1. Loosen and unscrew the elbow fitting (1).
2. Loosen and unscrew the straight nipple (2).
3. Unscrew the suction strainer set (3) from the inlet port of the pump.
4. Clean the suction strainer using cleaning agent (benzine or diesel fuel).
NOTE
›In case of damage, replace the metal mesh, sealing, and / or O-ring installed inside of the strainer housing - Figure 7.
(Order No. - see spare part list).
5. Screw the suction strainer set (3) into the pump inlet port.
6. Screw the straight nipple (2).
7. Screw the elbow fitting (1)
Fig. 9: Changing the suction strainer Fig. 10: Components of suction strainer:
1
2
3
NOTE
Damage to the filter unit by missing or defective suction strainer.
Property damage
›The suction strainer must be regularly checked, cleaned and replaced if necessary, according to the maintenance intervals.
O-ring
metal mesh
housing
flat sealing
type ED

Subject to change · 40719700 · 1217 · EN
Page 19
www.argo-hytos.com
CAUTION
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded
during operation.
›No fluid may pass through the filter while the filter element is being replaced.
›Allow the filter unit to cool down before touching it.
10.3. Replacing the filter element
Turn the filter unit off at the ON/OFF switch (circuit breaker) and pull the mains plug.
10.3.1 Removing the filter element
1. Unscrew and remove the filter cover (1)
2. Carefully remove the sealing ring (2). Check the sealing.
If necessary replace the sealing by new one.
(Order code. of sealing N 031.0562)
3. Remove the filter element (3) from the housing.
4. Check the filter element type number.
Does the laser inscription on the filter element match with
the indications on the type plate or in the operating
manual?
5. Dispose of the filter element according to the national
environmental legislation (Waste code: Oil filter 16 01 07).
6. Clean the filter housing from residual dirt.
7. Carefully insert the new element into the filter housing.
8. Install the sealing ring. Check the sealing. If necessary
replace the sealing with new one (order no. of sealing N
031.0562).
9. Screw in the filter cover until it stops (use the appropriate
wrench, size 27).
10.3.2 Installing the filter element
Fig. 11: Removing the filter element
Fig. 12: Installing the filter element
CAUTION
3
2
1
7
8
9

Subject to change · 40719700 · 1217 · EN
Page 20 www.argo-hytos.com
11. Decommissioning
DANGER
Danger to life
Risk of electric shock
›Before uninstalling, pull the mains plug. Uninstalling may only be carried out by qualified electricians.
Risk of injury
Risk of injury by incorrect handling
›Uninstalling may only be carried out by instructed persons.
DANGER
The final decommissioning and disposal requires complete uninstallation of the total energy supply, the mechanical components and
the disposal of the hydraulic media remaining in the device.
With disassembly and disposal, all national safety and environmental regulations must be observed.
