Filter Unit
FAPC 016
Manual
Safety and operating instructions

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 2 www.argo-hytos.com
Content
Filter Unit FAPC 016
Content.......................................................................................................................................................................... 2
1. About this documentation........................................................................................................................................... 4
1.1 Applicability of this documentation ................................................................................................................................. 4
1.2 Required and supplementary documentation .................................................................................................................. 4
1.3 Presentation of information ............................................................................................................................................ 4
1.3.1 Safety instructions .......................................................................................................................................................... 4
1.3.2 Symbols .......................................................................................................................................................................... 5
1.3.3 Terms ............................................................................................................................................................................. 5
1.3.4 Abbreviations .................................................................................................................................................................. 5
2. Safety instructions........................................................................................................................................................ 6
2.1 About this chapter .......................................................................................................................................................... 6
2.2 Intended use .................................................................................................................................................................. 6
2.3 Improper use .................................................................................................................................................................. 6
2.4 Reasonable foreseeable misuse ....................................................................................................................................... 6
2.5 Qualification of personnel ............................................................................................................................................... 6
2.6 General safety instructions .............................................................................................................................................. 6
2.7 Product and technology related safety instructions .......................................................................................................... 7
3. General instructions ..................................................................................................................................................... 8
4. Scope of delivery.......................................................................................................................................................... 9
5. About this product ..................................................................................................................................................... 10
5.1 Performance description................................................................................................................................................ 10
5.2 Device description ......................................................................................................................................................... 10
5.3 Component overview .................................................................................................................................................... 10
5.4 Identification of the product .......................................................................................................................................... 11
6. Transport and storage................................................................................................................................................ 12
6.1 Transport....................................................................................................................................................................... 12
6.2 Storage ......................................................................................................................................................................... 12
7. Assembly..................................................................................................................................................................... 13
8. Commissioning ........................................................................................................................................................... 14
8.1 Before commissioning ................................................................................................................................................... 14
8.2 After switching on......................................................................................................................................................... 14
8.3 In case of power failure ................................................................................................................................................. 14
9. Operation.................................................................................................................................................................... 15
9.1 Filtering of hydraulic fluids with refilling......................................................................................................................... 15
9.2 Filtering of liquids in the bypass flow ............................................................................................................................. 16
9.3 Data collection .............................................................................................................................................................. 17
9.4 Switching of the measuring type while filling or cleaning............................................................................................... 17
10. Repair and maintenance ............................................................................................................................................ 18
10.1 Maintenance ................................................................................................................................................................. 18
10.2 Maintenance overview................................................................................................................................................... 18
10.2.1 Replacing the suction strainer........................................................................................................................................ 19
10.3 Replacing the filter element .......................................................................................................................................... 19
10.3.1 Removing the filter element .......................................................................................................................................... 20
10.3.2 Removing the filter element from the cover .................................................................................................................. 20
10.3.3 Attaching the filter element .......................................................................................................................................... 20
10.3.4 Installing the filter element ........................................................................................................................................... 21
10.3.5 Bleeding the filter element ............................................................................................................................................ 21
10.4 Replacing the pump ..................................................................................................................................................... 22
10.4.1 Removing the pump ..................................................................................................................................................... 23
10.4.2 Installing the pump........................................................................................................................................................ 23

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 3
www.argo-hytos.com
10.5 Replacing the motor...................................................................................................................................................... 24
10.5.1 Removing the motor...................................................................................................................................................... 24
10.5.2 Installing the motor ....................................................................................................................................................... 24
10.6 Replacing the particle monitor OPCom .......................................................................................................................... 25
10.6.1 Removing the OPCom ................................................................................................................................................... 25
10.6.2 Installing the OPCom..................................................................................................................................................... 25
11. Decommissiong........................................................................................................................................................... 26
12. Disassembly ................................................................................................................................................................ 27
13. Disposal....................................................................................................................................................................... 28
14. Extension..................................................................................................................................................................... 29
14.1 Optional accessories ...................................................................................................................................................... 29
14.1.1 Transport aid / trolley..................................................................................................................................................... 29
14.1.2 Hose extensions............................................................................................................................................................. 29
14.1.3 Suction strainer set........................................................................................................................................................ 29
15. Troubleshooting.......................................................................................................................................................... 30
15.1 How to proceed ............................................................................................................................................................ 30
15.2 Fault table ..................................................................................................................................................................... 30
16. Technical data ............................................................................................................................................................. 31
16.1 Dimensions.................................................................................................................................................................... 31
16.2 Technical data................................................................................................................................................................ 31
16.3 Operating conditions..................................................................................................................................................... 32
16.4 Hydraulic circuit diagram ............................................................................................................................................... 32
17. Appendix..................................................................................................................................................................... 33
17.1 Declaration of conformity.............................................................................................................................................. 33
17.2 Spare parts list............................................................................................................................................................... 34

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 4 www.argo-hytos.com
1. About this documentation
1.1 Applicability of the documentation
This documentation is applicable for the following product:
›Filter Unit FAPC 016
This documentation is written for technicians, operators, service engineers and system operators.
This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing,
dismantling and simple troubleshooting.
›Read this document completely and in particular Chapter 2, “Safety Instructions”, before you work with the product.
Title Document number Document type
Data sheet 8065_EN
Manual OPCom
1.2 Required and supplementary documentation
Do not commission the product until you have received the documentation marked with the book icon and before you have under-
stood and complied with the information therein.
Table 1: Required and supplementary documentation
1.3 Presentation of information
So that this document can help you to work quickly and safely with your product, we use standardized safety instructions, symbols,
terms and abbreviations. For better understanding, these are explained in the following sections.
1.3.1 Safety instructions
In this documentation, safety instructions are faced with a sequence of actions which would result in the danger of personal injury or
damage to equipment. The measures described to avoid theses hazards must be observed.
Safety instructions are as follows:
›Warning signal: draws attention to the danger
›Signal word: indicates the severity of the danger
›Type and source of danger: specifies the type and source of the danger
›Consequences: describes the consequences in the event of non-compliance
›Action: indicates how the danger can be avoided
SIGNAL WORD
Type and source of danger
Consequences of non-compliance
›Measures to avert dangers
›<Enumeration>
Table 2: Hazard classes according to ANSI Z536.6-2006
Warning sign, signal word Meaning
DANGER Indicates a dangerous situation which results in death or serious injury if not avoided.
WARNING Indicates a dangerous situation which may result in death or serious bodily injury if not avoided.
CAUTION Indicates a dangerous situation which may result in light to moderate injury if not avoided.
NOTE Indicates property damage: The product or surrounding could be damaged.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 5
www.argo-hytos.com
Symbol Meaning
If this information is not observed, the product cannot optimally be used or operated.
>Singular, independent action step / instruction
This symbol specifies that protective gloves should be worn.
This symbol specifies that safety shoes should be worn.
This symbol specifies that protective goggles should be worn.
1.3.2 Symbols
The following symbols indicate notes which are not safety-relevant but increase the intelligibility of the documentation.
Table 3: Meaning of symbols
1.3.3 Terms
In this documentation the following terms are used:
Table 4: Terms
1.3.4 Abbreviations
In this documentation the following abbreviations are used:
Table 5: Abbreviations
Term Meaning
Term Meaning
FAPC Filter unit with particle monitor

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 6 www.argo-hytos.com
2. Safety instructions
2.1 About this chapter
This product was manufactured according to the generally recognized standards of engineering. Nevertheless, there is a danger of
injury or damage if you do not observe this chapter and the safety instructions in this documentation.
›Read this document thoroughly and completely before working with the product.
›Retain this document and ensure that it is available for all users at all times.
›Always include the necessary documentation when passing the equipment along to a third party.
2.2 Intended use
This product is a hydraulic component.
You may use the product for the following:
›for filtering lubricants and hydraulic oils while filling machines and plants, taking the technical data into account
›for filtering hydraulic fluids in the bypass flow on machines and plants, taking the technical data into account
›for monitoring the oil cleanliness while filling machines and plants
›for monitoring the oil cleanliness when cleaning in the bypass flow
This product is intended for professional use only and not for private use.
"Intended use" also includes that you have completely read and understood this documentation, in particular Chapter 2
"Safety Instructions".
2.3 Improper use
Any other use than the intended use described, is improper and inadmissible.
If unsuitable products are installed or used in safety-related applications, unintended operating states may occur in the application,
which may cause personal injury and / or property damage.
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documentation,
e.g. in explosion protection areas or in safety-related parts of a control system (functional safety).
ARGO-HYTOS GMBH assumes no liability for damages resulting from improper use. The risks associated with improper use are solely
with the user.
2.4 Reasonable forseeable misuse
The delivery of the following media is forbidden:
›highly flammable liquids such as petrol or thinner (explosion hazard)
The device is not suitable for the extraction of oil sludge and sediment.
The operator alone is liable for damages resulting from improper use.
2.5 Qualification of personnel
The operations described in this document require fundamental knowledge of mechanics and hydraulics as well as knowledge of the
appropriate technical terms. In order to ensure safe use, these operations may therefore only be carried out by a correspondingly
skilled worker or an instructed person under the guidance of a skilled worker.
A skilled worker is someone who can - based on his / her technical education, knowledge and experience as well as knowledge of
the respective regulations of the jobs assigned to him / her - recognize possible dangers and ensure appropriate safety measures.
A skilled worker must observe the relevant technical regulations.
2.6 General safety instructions
›Observe the valid regulations for accident prevention and environmental protection.
›Observe the safety regulations and requirements of the country in which the product is used / applied.
›Only use ARGO-HYTOS products that are in technically perfect condition.
›Observe all instructions on the product.
›People who assemble, operate, disassemble or maintain ARGO-HYTOS products may not do so under the influence of alcohol,
other drugs or medications that affect the responsiveness.
›Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable
spare parts.
›Observe the technical data and ambient specifications specified in the product documentation.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 7
www.argo-hytos.com
›If unsuitable products are used or installed in safety-relevant applications, unintended operating states may occur in the application,
which can cause personal injury and / or material damage. Therefore only use the product in safety-relevant applications if this use
is explicitly specified and permitted in the product documentation.
›You may only put the product into operation, when it has been established that the final product (e.g. a machine or system), into
which the ARGO-HYTOS products have been installed, complies with the country-specific regulations, safety regulations and
standards of the application.
2.7 Product and technology related safety instructions
CAUTION
Leaked hydraulic oil
Environmental hazard / risk of slipping
›In case of spills, cover the oil-covered surface immediately with an oil-binding medium.
›Then immediately dispose of the oil-binding medium according to the national environmental regulations.
Ignition hazard
Risk of electrostatic charge by poorly conducting hydraulic fluid
›If the electrical conductivity of the hydraulic fluid is not known, please contact the manufacturer of the
hydraulic fluid.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation
›Allow the filter unit to cool down before touching it.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 8 www.argo-hytos.com
3. General instructions
For prevention of material damage and product damage
CAUTION
Danger due to improper handling
Property damage
›The filter unit may only be used in accordance with Section 2.2, “Intended use”.
Leakage or spillage of hydraulic fluid
Environmental pollution and ground water contamination
›Use oil binding agents in order to bind leaked hydraulic oil.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation.
›Allow the filter unit to cool down before touching it.
Contamination due to fluids and foreign bodies
Premature wear, malfunction, risk of damage, property damage.
›Ensure cleanliness during installation in order to prevent foreign bodies, such as welding beads or metal chips,
from entering the hydraulic lines, leading to premature wear or malfunction.
›Make sure that connections, hydraulic lines and attachment parts (e.g. gauges) are free from dirt and chips.
›Prior to commissioning, check that all hydraulic and mechanical connections are connected and tight,
and that all gaskets and seals of the plug connectors are correctly assembled and undamaged.
›For removal of lubricants and other contaminants, use residue-free industrial wipes.
›Make sure that all connections, hydraulic lines and attachment parts are clean.
›Ensure that no contaminants enter when closing the connections.
›Make sure that no detergents enter the hydraulic system.
›Do not use cotton waste or faying cleaning rags for cleaning.
›Do not use hemp as sealing agent.
Improper cleaning
Premature wear, malfunction, risk of damage, property damage.
›Close all openings with appropriate protective fittings to prevent penetration of detergents.
›Do not use aggressive cleaning agents for cleaning. Clean the product with a suitable cleaning fluid.
›Do not use a high pressure cleaner.
›Do not use compressed air to clean function interfaces such as seal areas.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 9
www.argo-hytos.com
4. Scope of delivery
This package includes:
›1 Filter Unit FAPC 016
›1 Operating manual

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 10 www.argo-hytos.com
5. About this product
5.1 Performance description
The filter unit FAPC 016 is a mobile filter system for filtering hydraulic fluids and lubricants with a viscosity of 15 mm2/s (min. in
continuous operation) - 150 mm2/s in the bypass flow (300 mm2/s max. during short-term operation).
A separate installation in the bypass flow or cooling circuit for fine filtration and relief of the main flow filter is also possible, as is the
filtration of fresh oil and the cleaning (flushing) of contaminated systems for the wear protection of components and systems.
The volume flow is 16 l/min.
The operating temperature range is from 0 °C to 60 °C.
5.2 Device description
The filter unit FAPC 016 consists of a support frame in which a filter pump unit is integrated. It consists of an electronically operated
filter pump with a replaceable filter element and a pressure gauge as a maintenance indicator. The on-off switch is located on the
control box of the pump motor. The suction hose is connected at the suction side connection of the pump and the pressure hose is
connected at the main filter outlet.
The particle monitor OPCom can be configured and programmed directly on the device.
Measurement data can be transferred to a PC by means of an RS232 interface and then saved for processing on the PC.
5.3 Component overview
Fig.1: Component overview
Power cord
Protective
strainer
Suction strainer
Circuit breaker
Electric motor
Suction hose
Particle monitor
OPCom
Pressure hose
Valve housing
with valve 1 bar
Three-way
stopcock /
switching lever
Discharge pipe
Drip tray
Filter housing
with filter element
Filter cover

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 11
www.argo-hytos.com
Serial number
Filter fineness
Nominal volume flow
Operating pressure
Fig. 2: Nameplate
Filter element
Type designation
Year
Address
5.4 Identification of the product

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 12 www.argo-hytos.com
6. Transport and storage
6.1 Transport
Fig.3: Transport by carrying
The compact design allows for easy transport of the FAPC 016 filter unit – even
to inaccessible parts of hydraulic systems.
Hoses and electrical cables can be attached to the device. The device can be
transported and operated both standing upright and lying flat.
Please note the instructions in Chapter 2 "Safety instructions".
›When using mobile transport aids, ensure a secure position of the unit
(danger of tipping).
›During transport, secure the suction hose and the pressure hose in the brackets
provided for this purpose in order to avoid a possible leakage of residual oil.
6.2 Storage
The filter unit FAPC 016 should be stored in an enclosed area to protect it from humidity and condensation.
DANGER
Risk of injury
Danger of chemical reactions
Chemical substances in the immediate vicinity of the filter unit can react and lead to the destruction of the device
and to injuries to persons in the immediate vicinity of the device.
›Storage in the immediate vicinity of chemically active substances such as acids, alkalis, salts, organic solvents
and rechargeable batteries is prohibited.
The ambient temperature during storage of the filter unit FAPC 016 should be between +5 °C und +50 °C at a maximum humidity
of 80 %.
Before storage over a period of more than 6 months, the device should be filled with oil in order to preserve it against corrosion.
CAUTION
Falling unit by incorrect transport
Injuries! Damage!
›Due to its weight of 22 kg, the device must be carried manually by two persons.
›Wear safety shoes when transporting the filter unit.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 13
www.argo-hytos.com
7. Assembly
Let - prior to commissioning - an electrician check whether:
›the mains voltage matches with the voltage specified on the nameplate of the motor,
›the power source has appropriately been secured,
›the cross-section is of sufficient size,
›cable and connection to the power source are in perfect condition.
With 3-phase AC motors check after connecting that:
›when switching on, the direction of rotation matches with the direction arrow on the motor, if not, have it changed by
an electrician.
The following steps are to be followed in detail:
›connect the 230V voltage plug to the local power supply.
WARNING
Faulty power supply
Risk of death! Risk of injury!
›Always consider the country-specific regulations.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 14 www.argo-hytos.com
8. Commissioning
8.1. Before commissioning
›Be sure to read and understand the operating manual before putting the device into operation.
›The information for intended use, the operating conditions and the technical specifications must be adhered to.
›The unit must be positioned so that there is no danger of tipping and vibrations are largely intercepted.
›Cables and hoses must be outside of the movement range of the operating personnel (tripping hazard).
›If no hydraulic oil is sucked in during commissioning, switch off the unit, open the cover at the filter housing and fill in
approx. 0.3 l hydraulic oil.
›The oil to be filtered must be compatible with the previously filtered hydraulic oil. If this is not the case, the filter unit must be
cleaned and the filter element is to be replaced (see filter element change).
›When using the hoses during unmanned operation, ensure that they might not fall out of the container.
›The suction and discharge pipe must be immersed far enough below the liquid level, so that oil is sucked in.
›The hydraulic fluid must be free of water (no oil turbidity).
›Measurement results are falsified by free water in the oil.
›Properly close the cover of the filter housing.
›Manually turn the cover until it stops; a gap between cover and housing may remain visible (see Figure 3).
Fig. 4: Gap at the filter cover
8.2 After switching on
›With 3-phase AC motors check after connecting if the direction of rotation matches with the direction arrow on the motor.
If not, have it changed by an electrician.
›Check the filter unit for leaks.
›Check that the device is properly vented. To do so, open the hexagon socket screw on the cover slightly until oil emerges.
Then close the hexagon socket screw.
Air bubbles in the oil falsify the measuring result.
8.3 In case of power failure
In order to prevent unintentional starting of the unit, always switch off and unplug the unit.
Gap

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 15
www.argo-hytos.com
9. Operation
CAUTION
Danger resulting from spilled oil
Injury! Risk of slipping!
›If oil leaks, the oil-covered area must be shut of immediately and covered with an oil binding medium
(risk of slipping).
Static charge
Sparking
›There is a risk of static charge when using poorly conducting hydraulic or lubricating oils.
In this case, please consult the manufacturer.
NOTE
Damage to the filter unit by missing or defective suction strainer
Property damage!
›The strainer must be regularly checked according to the maintenance intervals and replaced if necessary.
Inaccuracte measurement results
Incorrect measurements
›The measured values from the first five minutes should not be taken into account, as the particle counter needs
to initialize, and the hydraulic circuit must stabilize (air bubbles, flushing, etc.).
›The filter unit is provided with a protective strainer at the suction side, which has to be serviced regularly.
A missing protective strainer may lead to destruction of the pump. (Order No. see spare parts list)
›If the protective strainer is removed, the manufacturer will resume no liability.
4. Turn the filter unit on at the on/off switch (circuit breaker).
5. Check the oil flow on possibly insufficient immersion depth of the suction pipe in the oil tank.
NOTE
›At the beginning of the filtration, filling of the filter unit may take a few seconds.
6. Using the clogging indicator, check the element for clogging at operating temperature of the medium used.
7. Check the filling level at the machine or system and turn off the filter unit at the circuit breaker, once the desired filling
quantity has been reached.
8. Re-attach the suction strainer and the discharge pipe to the appropriate brackets at the filter unit.
9.1 Filtering of hydraulic fluids with refilling
1. Connect the filter unit to a power source.
2. Place the suction strainer into the oil drum.
3. Place the discharge pipe into a container (e.g. hydraulic tank).
NOTE
Faulty insertion of the discharge pipe
›Make sure that the discharge pipe is below the liquid surface.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 16 www.argo-hytos.com
NOTE
Reaching the maximum cleaning performance
›In order to prevent a short circuit of the oil flow, the distance between the suction and pressure connection
should be kept as large as possible.
Falsification of the measuring results
›Make sure that the device is properly vented.
4. Turn the filter unit on at the on/off switch (circuit breaker).
5. Check the oil flow on possibly insufficient immersion depth of the suction pipe in the oil tank.
NOTE
›At the beginning of the filtration, filling of the filter unit may take a few seconds.
6. Using the clogging indicator, check the element for clogging at operating temperature of the medium used.
7. At the end of filtration, pull the suction strainer out of the container of the machine or system (e.g. hydraulic tank) and draw in
air for max. 30 seconds.
Thus, residual oil from the filter housing and the lines above oil level will be returned via the discharge pipe into the tank of
the machine or unit.
8. Turn off the filter unit by using the circuit breaker.
9. Re-attach the suction strainer and the discharge pipe to the appropriate brackets at the filter unit.
9.2 Filtering of liquids in the bypass flow
1. Connect the filter unit to a power source.
2. Place the suction strainer into the container of the machine or system (e.g. hydraulic tank).
3. Place the discharge pipe in a container of the machine or system (e.g. hydraulic tank).
NOTE
Faulty insertion of the discharge pipe
›Make sure that the discharge pipe is below the liquid surface.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 17
www.argo-hytos.com
9.3 Data collection
The filter unit FAPC 016 is equipped with a data memory that can store up to 3,000 results.
Once the storage capacity is reached, the last measured value is saved, while the oldest measured value is simultaneously overwritten.
The stored results are transferred to the hard disk of the connected PC or laptop and can be stored there.
Fig. 5: Three-way stopcock
NOTE
A description for installation and data transmission is available in the OPCom user manual.
1. Connect a data cable to the RSR232 socket (Fig. 1 Pos. 13).
2. Connect the plug to a PC or laptop on which the corresponding software is installed.
Switch position upstream of filter
›horizontal level position
›the oil cleanliness is monitored during the cleaning process
Switch position downstream of filter
›vertical lever position
›the oil cleanliness is monitored during the filling process
NOTE
The corresponding software can be downloaded from www.argo-hytos.com.
9.4 Switching of the measuring type while filling or cleaning
When monitoring the cleanliness class, a ball valve can be used to switch between "downstream of filter" (e.g. when filling the
equipment) and "upstream of filter" (e.g. when cleaning out oil fillings).
Switch positions are changed using the attached three-way stopcock (Fig. 1 Pos. 6).
downstream of filter
upstream of filter

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 18 www.argo-hytos.com
CAUTION
Leaked hydraulic oil
Environmental hazard / risk of slipping
›Before maintenance and repair work, completely drain the unit.
›In case of spills, cover the oil-covered surface immediately with an oil-binding medium.
›Then immediately dispose of the oil-binding medium according to the national environmental regulations.
Ignition hazard
Risk of electrostatic charge by poorly conducting hydraulic fluid
›If the electrical conductivity of the hydraulic fluid is not known, please contact the manufacturer of the
hydraulic fluid.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation.
›Allow the filter unit to cool down before touching it.
10. Repair and maintenance
DANGER
Danger to life
Risk of electric shock
›During repair work, turn off the unit and pull the mains plug.
NOTE
Impaired function by dirt ingress into the pump
The function of the filter unit is no longer guaranteed.
›During repair work, all parts coming in contact with the hydraulic medium, must be kept free of dirt and chips.
10.1 Maintenance
10.2 Maintenance overview
Except from the filter element and the suction strainer, the filter unit is maintenance-free.
Maintenance work Order No. Maintenance interval
Checking / changing the filter element V7.1220-113 (3 µm) Once the clogging indicator responds with
admissible viscosity
Checking / changing the suction strainer FA 016.0301 Quarterly or with corresponding
problems (lower volume flow with clean filter
element, too loud noise level)

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 19
www.argo-hytos.com
10.2.1 Replacing the suction strainer
NOTE
Damage to the filter unit by missing or defective suction strainer.
Property damage
›The suction strainer must be regularly checked and replaced if necessary, according to the maintenance intervals.
Fig. 6: Replacing the suction strainer
1. Loosen the hose clamp (1).
2. Pull the suction hose (2) from the suction strainer (3).
3. Clean the suction strainer (3) with benzine or diesel fuel.
4. Push the suction hose (2) - as shown above - onto the suction strainer (3).
5. Attach the hose clamp (1).
NOTE
›In case of damage, replace the suction strainer (3) (Order No. FA 016.0100).
10.3 Replacing the filter element
1. Pump the filter element dry (see chapter 9.2 “Filtering liquids in the bypass flow“ Point 7).
2. Turn the filter unit off at the on/off switch (circuit breaker) and pull the mains plug.
CAUTION
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation.
›Allow the filter unit to cool down before touching it.

Subject to change · Filter Unit FAPC 016 · 1020 · EN
Page 20 www.argo-hytos.com
10.3.1 Removing the filter element
Fig. 7: Removing the filter element
1. Turn the housing cover (1) counterclockwise.
2. Carefully remove the cover (1) with the filter element (2)
from the filter tube.
(The filter element is attached to the cover.
Let the draining oil drip off into the housing.)
Fig. 8: Removing the filter element from the cover
1. Push the filter element at the cover in arrow direction 1 and
remove it in arrow direction 2.
2. Dispose of the filter element according to the national
environmental legislation (Waste code: Oil filter 16 01 07).
10.3.2 Removing the filter element from the cover
10.3.3 Attaching the filter element
Fig. 9: Attaching the filter element
1. Check the filter element type number.
Does the laser inscription on the filter element match with
the indications on the type plate or in the operating manual?
2. Attach the filter element in arrow direction 2 and lock it in
arrow direction 1.
1
2
