Argo-Hytos FNAPC1 045 User manual

Subject to change · V 0.1 · 02.2020 · EN
Page 1
www.argo-hytos.com
Safety and operating instructions
Read safety and operating instructions before use.
Note:
The indicated data only serve to describe the product.
Specifications regarding the use of this product are only examples and suggestions.
Catalog specifications are no guaranteed features.
The information given does not release the user from his / her own assessments and inspection.
Our products are subject to a process of natural wear and aging.
© All rights are reserved by ARGO-HYTOS Polska, even in the event of industrial property rights.
Any right of disposal such as copying and distribution rights shall remain with us.
The picture on the title page shows a configuration example.
The delivered product may thus differ from the illustration.
The device conforms with the requirements.
Off-line Filter Unit
FNAPC1 045
Manual

Subject to change · V 0.1 · 02.2020 · EN
Page 2 www.argo-hytos.com
Contents
Off-line Filter Unit FNA 045
Contents .............................................................................................................................................................................. 3
1. About this documentation................................................................................................................................................. 4
1.1 Applicability of this documentation........................................................................................................................................ 4
1.2 Required and supplementary documentation ......................................................................................................................... 4
1.3 Presentation of information ................................................................................................................................................... 4
2. Safety instructions.............................................................................................................................................................. 6
2.1 About this chapter................................................................................................................................................................. 6
2.2 Intended use.......................................................................................................................................................................... 6
2.3 Improper use ......................................................................................................................................................................... 6
2.4 Reasonably foreseeable misuse .............................................................................................................................................. 6
2.5 Qualification of personnel...................................................................................................................................................... 6
2.6 General safety instructions..................................................................................................................................................... 7
2.7 Product and technology related safety instructions................................................................................................................. 7
3. General instructions............................................................................................................................................................ 8
4. Scope of delivery ................................................................................................................................................................ 9
5. About this product............................................................................................................................................................ 10
5.1 Performance specification .................................................................................................................................................... 10
5.2 Device description................................................................................................................................................................ 10
5.3 Component overview .......................................................................................................................................................... 10
5.4 Identification of the product ................................................................................................................................................ 11
6. Transport and storage ...................................................................................................................................................... 12
7. Assembly ........................................................................................................................................................................... 13
8. Commissioning.................................................................................................................................................................. 14
8.1 Before commissioning.......................................................................................................................................................... 14
8.2 After switching on ............................................................................................................................................................... 14
8.3 In case of power failure........................................................................................................................................................ 14
9. Operation .......................................................................................................................................................................... 16
10. Repair and maintenance .................................................................................................................................................. 17
10.1 Maintenance ....................................................................................................................................................................... 18
10.2 Maintenance overview......................................................................................................................................................... 18
10.3 Replacing the filter element ................................................................................................................................................. 18
10.4 Replacing the pump and the motor...................................................................................................................................... 19
10.5 Replacing the suction filter element / pump protection filter................................................................................................. 21
10.6 Checking / cleaning OPCom protective filters....................................................................................................................... 22
11. Decommissioning.............................................................................................................................................................. 23
12. Disassembly....................................................................................................................................................................... 24
13. Disposal ............................................................................................................................................................................. 25
14. Troubleshooting................................................................................................................................................................ 26
14.1 How to proceed................................................................................................................................................................... 26
14.2. Fault table............................................................................................................................................................................ 26

Subject to change · V 0.1 · 02.2020 · EN
Page 3
www.argo-hytos.com
15. Technical data.................................................................................................................................................................... 28
15.1 Device dimensions ............................................................................................................................................................... 28
15.2 Technical data...................................................................................................................................................................... 29
15.3 Operating conditions ........................................................................................................................................................... 30
15.4 Hydraulic circuit diagram...................................................................................................................................................... 30
15.5 Connection diagram ............................................................................................................................................................ 31
16. Appendix ........................................................................................................................................................................... 32
16.1 Installation declaration .................................................................................................................................................... 32
16.2 Spare parts list ..................................................................................................................................................................... 33

Subject to change · V 0.1 · 02.2020 · EN
Page 4 www.argo-hytos.com
1. About this documentation
1.1 Applicability of this documentation
This documentation is applicable for the following product:
›Off-line Filter Unit FNAPC1 045
This documentation is written for technicians, operators, service engineers and system operators.
This document contains important information for safe and appropriate assembly, transport, activation, operation, usage, servicing,
dismantling and simple troubleshooting.
›Read this document completely and in particular Chapter 2, “Safety Instructions”, before you work with the product.
1.2 Required and supplementary documentation
Do not commission the product until you have received the documentation marked with the book icon and before you have under-
stood and complied with the information therein.
Title Number of document 1.2.1 Document type
Oil Condition Sensors - LubCos H2O V 3.04.16 Operating manual
Oil Condition Sensors - LubCos H2O +II V 2.01.16 Operating manual
OPCom Particle Monitor V 2.01.16 Operating manual
Table 1: Required and supplementary documentation
1.3 Presentation of information
So that this document can help you to work quickly and safely with your product, we use standardized safety instructions, symbols,
terms and abbreviations. For better understanding, these are explained in the following sections.
1.3.1 Safety instructions
In this documentation, safety instructions are faced with a sequence of actions which would result in the danger of personal injury or
damage to equipment. The measures described to avoid theses hazards must be observed.
Type and source of danger
›Consequences of the danger
›Escaping or averting the danger
›Rescue (optional)
DANGER
›Warning signal: draws attention to the danger
›Signal word: indicates the severity of the danger
›Type and source of danger: specifies the type and source of danger
›Consequences: describes the consequences in the event of non-compliance
›Action: indicates how the danger can be avoided
Warning sign, signal word Meaning
DANGER Indicates a dangerous situation which results in death or serious injury if not avoided.
WARNING Indicates a dangerous situation which may result in death or serious bodily injury if not avoided.
CAUTION Indicates a dangerous situation which may result in light to moderate injury if not avoided.
NOTE Indicates property damage: The product or surrounding could be damaged.
Table 2: Meaning of the warning signs

Subject to change · V 0.1 · 02.2020 · EN
Page 5
www.argo-hytos.com
Symbol Meaning
If this information is not observed, the product cannot optimally be used or operated
> Singular, independent action step / instruction
1.
2.
3.
This symbol indicates danger to equipment, material and environment
This symbol indicates the risk of personal injury (minor injury).
This symbol indicates the risk of personal injury (death, serious bodily injury).
This symbol specifies that protective gloves should be worn.
This symbol specifies that safety shoes should be worn.
This symbol specifies that protective goggles should be worn.
This symbol specifies that the unit should be disconnected from the power supply.
Table 3: Meaning of symbols
1.3.2 Symbols
The following symbols indicate notes which are not safety-relevant but increase the intelligibility of the documentation.
1.3.3 Terms
In this documentation the following terms are used:
Term Meaning
Table 4: Terms
1.3.4 Abbreviations
In this documentation the following abbreviations are used:
Term Meaning
FNAPC Off-line Filter Unit with oil condition monitoring
Table 5: Abbreviations
Numbered instruction
The numbers indicate that the action steps follow one another

Subject to change · V 0.1 · 02.2020 · EN
Page 6 www.argo-hytos.com
2. Safety instructions
2.1 About this chapter
This product was manufactured according to the generally recognized standards of engineering. Nevertheless, there is a danger
of injury or damage if you do not observe this chapter and the safety instructions in this documentation.
›Read this document thoroughly and completely before working with the product.
›Retain this document and ensure that it is available for all users at all times.
›Always include the necessary documentation when passing the equipment along to a third party.
2.2 Intended use
This product is a hydraulic component.
You may use the product for the following:
›for filtration of hydraulic fluids in the bypass flow on machines and systems, taking account of the technical data.
This product is intended for professional use only and not for private use.
"Intended use" also includes that you have completely read and understood this documentation, in particular Chapter 2
"Safety Instructions".
2.3 Improper use
Any other use than the intended use described, is improper and inadmissible.
If unsuitable products are installed or used in safety-related applications, unintended operating states may occur in the application,
which may cause personal injury and / or property damage.
Therefore only use this product in safety-related applications if this use is explicitly specified and permitted in the product documentation,
e.g. in explosion protection areas or in safety-related parts of a control system (functional safety).
ARGO-HYTOS Polska assumes no liability for damages resulting from improper use.
The risks associated with improper use are solely with the user.
2.4 Reasonably foreseeable misuse
The delivery of the following media is forbidden:
›others than listed in Chapter 16 “Technical data“.
Especially
›flammable liquids such as petrol or thinner (explosion hazard)
›foodstuffs
›The device is not suitable for sucking sludge and sediment.
The operator alone is liable for damages resulting from improper use.
2.5 Qualification of personnel
The operations described in this document require fundamental knowledge of mechanics and hydraulics as well as knowledge of the
appropriate technical terms. In order to ensure safe use, these operations may therefore only be carried out by a correspondingly
skilled worker or an instructed person under the guidance of a skilled worker.
A skilled worker is someone who can - based on his / her technical education, knowledge and experience as well as knowledge of
the respective regulations of the jobs assigned to him / her - recognize possible dangers and ensure appropriate safety measures.
A skilled worker must observe the relevant technical regulations.
The device may be operated by the following individuals:
›Persons aged 14 years or older who have read and understood these operating instructions.
›Persons aged 14 years or older who have been instructed by trained staff.
›Qualified / specialized staff with adequate training.
The device may be repaired or maintained by the following individuals:
›Qualified / specialized staff with adequate training.
Work on electrical components:
›Only electrical specialists with adequate training.

Subject to change · V 0.1 · 02.2020 · EN
Page 7
www.argo-hytos.com
2.6 General safety instructions
›Observe the valid regulations for accident prevention and environmental protection.
›Observe the safety regulations and requirements of the country in which the product is used / applied.
›Only use ARGO-HYTOS products that are in technically perfect condition.
›Observe all instructions on the product.
›People who assemble, operate, disassemble or maintain ARGO-HYTOS products may not do so under the influence of alcohol,
other drugs or medications that affect the responsiveness.
›Only use manufacturer-approved accessories and spare parts, in order to prevent personal danger due to unsuitable
spare parts.
›Observe the technical data and ambient specifications specified in the product documentation.
›If unsuitable products are used or installed in safety-relevant applications, unintended operating states may occur in the application,
which can cause personal injury and / or material damage. Therefore only use the product in safety-relevant applications if this use
is explicitly specified and permitted in the product documentation.
›You may only put the product into operation, when it has been established that the final product (e.g. a machine or system), into
which the ARGO-HYTOS products have been installed, complies with the country-specific regulations, safety regulations and
standards of the application.
2.7 Product and technology related safety instructions
Leaked hydraulic oil
Environmental hazard / risk of slipping
›In case of spills, cover the oil-covered surface immediately with an oil-binding medium.
›Then immediately dispose of the oil-binding medium according to the national environmental regulations.
Ignition hazard
Risk of electrostatic charge by poorly conducting hydraulic fluid.
›If the electrical conductivity of the hydraulic fluid is not known, please contact the manufacturer of the
hydraulic fluid.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation.
›Allow the off-line filter unit to cool down before touching it.
CAUTION

Subject to change · V 0.1 · 02.2020 · EN
Page 8 www.argo-hytos.com
3. General instructions
Danger due to improper handling
Property damage
›The filter unit may only be used in accordance with Section 2.2, “Intended use”.
Leakage or spillage of hydraulic fluid
Environmental pollution and ground water contamination
›Use oil binding agents in order to bind leaked hydraulic oil.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation.
›Allow the off-line filter unit to cool down before touching it.
Contamination due to fluids and foreign bodies
Premature wear, malfunction, risk of damage, property damage.
›Ensure cleanliness during installation in order to prevent foreign bodies, such as welding beads or metal chips,
from entering the hydraulic lines, leading to premature wear or malfunction.
›Make sure that connections, hydraulic lines and attachment parts (e.g. gauges) are free from dirt and chips.
›Prior to commissioning, check that all hydraulic and mechanical connections are connected and tight,
and that all gaskets and seals of the plug connectors are correctly assembled and undamaged.
›For removal of lubricants and other contaminants, use residue-free industrial wipes.
›Make sure that all connections, hydraulic lines and attachment parts are clean.
›Ensure that no contaminants enter when closing the connections.
›Make sure that no detergents enter the hydraulic system.
›Do not use cotton waste or faying cleaning rags for cleaning.
›Do not use hemp as sealing agent.
Improper cleaning
Premature wear, malfunction, risk of damage, property damage.
›Close all openings with appropriate protective fittings to prevent penetration of detergents.
›Do not use aggressive cleaning agents for cleaning. Clean the product with a suitable cleaning fluid.
›Do not use a high pressure cleaner.
›Do not use compressed air to clean function interfaces such as seal areas.
CAUTION
3.1 For prevention of material damage and product damage

Subject to change · V 0.1 · 02.2020 · EN
Page 9
www.argo-hytos.com
4. Scope of delivery
The package includes:
›1 Off-line Filter Unit FNAPC1 045
›1 Operating manual

Subject to change · V 0.1 · 02.2020 · EN
Page 10 www.argo-hytos.com
5. About this product
5.1 Performance specification
The off-line filter unit FNAPC 045 is a stationary filter unit for filtration of hydraulic fluids and lubricants with a viscosity of 15 mm2/s
- 250 mm2/s (in continuous operation).
A separate installation in the bypass or cooling circuit for fine filtration and discharge of the full flow filter is just as possible as the
filtration of fresh oil and the cleaning (flushing) of polluted systems for wear protection of components and systems.
The volume flow is 45 l/min (50 Hz) and 54 l/min (60 Hz) respectively.
The operating temperature is in the range of 0 °C to 65 °C.
5.2 Device description
The off-line filter unit FNAPC1 045 consists of an electrically operated filter pump with exchangeable filter element and may be
equipped with an electrical or optical clogging indicator (12). The unit is equipped with a measuring block consisting of two sensors
for monitoring the oil condition:
›OPCom - optical particle monitor (4) for continuous measurement of oil contamination with solid particles and
›LubCos H2O (FNAPC 045 Version H) (5) - sensor for continuous measurement of relative humidity and temperature of oil or
›LubCos H2O+II (FNAPC 045 Version HC) (5) - sensor for continuous determination of oil condition, humidity and temperature
The unit is equipped with a rotary switch (9) which can be used to switch between the basic operating modes: "Filtering" and
"Pump over without filtering".
The control box of the pump motor is used to connect the power supply.
The suction hose can be connected to the suction port (14) of the pump and the pressure hose to the outlet (8) of the main filter.
The unit is equipped with a suction strainer (13) which can be cleaned or replaced if necessary. An additional protective filter (15) is
installed in the line connecting main block and sensor manifold.
5.3 Component overview
1 Pump block 6 Filter cover with ventilating valve 11 Measuring point "before filter"
2 Gerotor pump 7 Filter housing with filter element 12 Filter element clogging indicator
3 Electric motor 8 Outlet port G1" 13 Suction filter
4 OPCom particle monitor 9 Switching valve 14 Inlet port G1 1/4"
5 LubCos sensor 10 Measuring point "after filter" 15 Protective strainer for sensor block
Fig. 1: Component overview

Subject to change · V 0.1 · 02.2020 · EN
Page 11
www.argo-hytos.com
5.4 Identification of the product
1
2
8
3
4
5
1 Address 4 Fineness of filter 7 Serial number
2 Unit order code 5 Flow rate 8 Coded date of production
3 Filter element order code 6 Max pressure
NOTE
Nameplates are documents which must not be changed or removed.
›Damaged or lost nameplates immediately have to be replaced true to the original.
Fig. 2: Nameplate
6
7

Subject to change · V 0.1 · 02.2020 · EN
Page 12 www.argo-hytos.com
6. Transport and storage
Falling unit through incorrect transport
Injury and property damage
›The unit must be carried manually by two persons due to its own weight of 45 kg.
›Wear safety shoes when transporting the filter unit.
6.1 Transport
›When using mobile transport aids, ensure a secure position of the unit (danger of tipping).
›During transport, close the suction and pressure port, in order to avoid a possible leakage of residual oil.
6.2 Storage
Risks related to chemical reactions
Risk of injury
Chemical substances in the immediate vicinity of the off-line filter unit may react and lead to destruction
of the device and to injuries of persons who are in the immediate vicinity of the device.
›Storage in the immediate vicinity of chemically active substances such as acids, alkalis, salts, organic solvents
and rechargeable batteries is prohibited.
The ambient temperature during storage of the off-line filter unit FNAPC1 045 should be between + 5 °C and + 30 °C at a humidity
of 80%. Before storage over a period of more than 6 months, the unit should be filled with oil in order to preserve it against
corrosion.
The off-line filter unit FNAPC1 045 should be stored in a in an enclosed space, to protect it from moisture and condensation.
CAUTION
CAUTION

Subject to change · V 0.1 · 02.2020 · EN
Page 13
www.argo-hytos.com
7. Assembly
Faulty power supply
Risk of death and injury
›Always consider the country-specific regulations.
WARNING
Let - prior to commissioning - an electrician check whether:
›the mains voltage matches with the voltage specified on the type plate of the motor,
›the power source has appropriately been secured,
›the cross-section is of sufficient size,
›cable and connection to the power source are in perfect condition.
With 3-phase AC motors check after connecting that:
›when switching on, the direction of rotation matches with the direction arrow on the motor, if not, have it changed by an
electrician.
Specifically, proceed with the following steps:
›connect the motor to the local power supply.

Subject to change · V 0.1 · 02.2020 · EN
Page 14 www.argo-hytos.com
8. Commissioning
8.1 Before commissioning
›Be sure to read and understand the operating manual before putting the device into operation.
›The information for intended use, the operating conditions and the technical specifications must be adhered to.
›Fasten the unit sufficiently safely and vibration-free only using rubber buffers (Order no. UM 045.0709) (MA 30 +5 Nm).
›Cables and hoses must be outside of the movement range of the operating personnel (tripping hazard).
›If no hydraulic oil is sucked in during commissioning, switch off the unit, open the cover at the filter housing and fill in approx.
0,5 l hydraulic oil.
›The oil to be filtered must be compatible with the previously filtered hydraulic oil. If this is not the case, the filter unit must be
cleaned and the filter element is to be replaced (see filter element change).
›When using the hoses during unmanned operation, ensure that they might not fall out of the container.
›Recommended nominal sizes of the hydraulic connections:
» Suction hose / suction pipe DN 32
» Pressure hose / pressure pipe DN 25
›The suction and discharge pipe must be immersed far enough below the liquid level, so that oil is sucked in.
›The hydraulic fluid must be free of water (no oil turbidity).
›Properly close the cover of the filter housing.
›Manually turn the cover until it stops; a gap between cover and housing may remain visible (see Figure 3).
Fig. 3: Gap at the filter cover
8.2 After switching on
›With 3-phase AC motors check after connecting if the direction of rotation matches with the direction arrow on the motor.
If not, have it changed by an electrician.
›Check the off-line filter unit for leaks.
8.3 In case of power failure
In order to prevent unintentional starting of the unit, always switch off and unplug the unit.
Danger by improper handling
Material damage
›The off-line filter unit should be equipped with a suction strainer on the suction side.
A missing or defective suction strainer (Order No. see below) can lead to pump damage.
In this case the manufacturer assumes no liability.
›With assembly of the off-line filter units, a clogging indicator has to be used.
Without clogging indicator, clogging of the element cannot be observed.
Gap
CAUTION

Subject to change · V 0.1 · 02.2020 · EN
Page 15
www.argo-hytos.com
Installation position vertical
Fixing Fixing only with rubber buffers (Order No. UM 045.0709)
Extension height filter element min. 700 mm
Connection recommendation for
pipeworks
All cut-ring and progressive-ring fittings of series L or LL from ERMETO
EO-standard program according to DIN 2353/ISO 8434-1
Connection recommendation for hoses
Suction connection-ø (inlet)
min. DN 32 only use spiral hose
All cut-ring and progressive-ring fittings of series L or LL from ERMETO
EO-standard program according to DIN 2353/ISO 8434-1
Connection recommendation for hoses
Pressure connection-ø (outlet)
min. DN 25
Suction height max. 2.0 m (unfilled condition)
Pump protection Use of suction strainer mandatory / fineness 280 µm (Order No. S9.0417-13)
Max. cleaning performance Distance between suction and pressure side to be kept as large as possible
(no short-circuit of the oil flow).
Table 6: Installation recommendations

Subject to change · V 0.1 · 02.2020 · EN
Page 16 www.argo-hytos.com
9. Operation
Exposure to spilled oil
Injury - risk of slipping
›If oil leaks, the oil-covered area must be shut off immediately and covered with an oil binding medium
(risk of slipping).
Static charge
Sparking
›There is a risk of static charge when using poorly conducting hydraulic or lubricating oils.
In this case, please consult the manufacturer.
9.1 Filtering hydraulic fluids in the bypass flow
1. Connect the filter unit to a power source.
2. Place the suction line into the container of the machine or system (e.g. hydraulic tank).
3. Place the pressure line of the pressure limiting valve in the container of the machine or system (e.g. hydraulic tank).
4. Turn the switching valve (Fig 1. pos. 9) to Pos. II "Filtering"
NOTE
Faulty insertion of the discharge pipe
›At the beginning of the filtration, filling of the off-line filter unit may take a few seconds.
7. Using the clogging indicator, check the element for clogging at operating temperature of the medium used.
8. At the end of filtration, pull the suction strainer out of the container of the machine or unit (e.g. hydraulic tank) and draw in
air for max. 30 seconds.
Thus, residual oil from the filter housing and the lines above oil level will be returned via the discharge pipe into the tank of
the machine or unit.
9. Turn off the power supply and unplug the mains plug.
NOTE
Reaching the maximum cleaning performance
›In order to prevent a short circuit of the oil flow, the distance between the suction and pressure connection should be kept as
large as possible.
5. Turn on the power supply and plug in the mains plug.
6. Check the oil flow on possibly insufficient immersion depth of the suction pipe in the oil tank.
CAUTION
NOTE
Measurement of oil condition
›Measurement of oil condition is only possible in the "Filtering" mode (switching valve in position II).
Fig. 4: Operating modes
Filtration with oil condition measurement
Pumping without filtration and oil condition measurement

Subject to change · V 0.1 · 02.2020 · EN
Page 17
www.argo-hytos.com
10. Repair and maintenance
Danger to life
Risk of electric shock
During repair work, turn off the unit and pull the mains plug.
DANGER
Risks related to chemical reactions
Risk of injury
›Chemical substances in the immediate vicinity of the filter unit may react and lead to destruction of the device
and to injuries of persons who are in the immediate vicinity of the device
›Storage in the immediate vicinity of chemically active substances such as acids, alkalis, salts, organic solvents
and rechargeable batteries is prohibited.
Hydraulic oil spills
Environmental hazard / risk of slipping
›Before maintenance and repair work, completely drain the unit.
›In case of spills, cover the oil-covered surface immediately with an oil-binding medium.
›Then immediately dispose of the oil-binding medium according to the national environmental regulations.
Ignition hazard
Risk of electrostatic charge by poorly conducting hydraulic fluid
›If the electrical conductivity of the hydraulic fluid is not known, please contact the manufacturer of the
hydraulic fluid.
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded during
operation.
›Allow the filter unit to cool down before touching it.
NOTE
Impaired function by dirt ingress into the pump
The function of the filter unit is no longer guaranteed.
›During repair work, all parts coming in contact with the hydraulic medium, must be kept free of dirt and chips.
CAUTION

Subject to change · V 0.1 · 02.2020 · EN
Page 18 www.argo-hytos.com
10.1 Maintenance
10.2 Maintenance overview
Maintenance work Part No. Maintenance interval
Checking / changing the filter element V7.1560-103(3µm) As soon as the clogging indicator turns
into the red area within the permitted
viscosity range.
V7.1560-03 (5µm)
V7.1560-06 (10µm)
Y7.1560-05 (Aqua Element)
Checking / changing the suction filter
element
S9.0417-13 quarterly or
with corresponding peculiarities
(lower volume rate with clean filter
element, too loud operating noise)
Checking / changing the protective
strainer
15077600 quarterly or
with corresponding peculiarities
(Displayed cleanliness classes are not
plausible e.g. 0/0/0, )
Table 7: Maintenance overview
10.3 Replacing the filter element
1. Pump the filter element empty - (see Chapter 9.1 "Filtering liquids in the bypass flow" Point 7)
2. Disconnect the off-line filter unit from the power supply and unplug the mains plug.
Risk of burns
Contact temperature according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded
during operation.
›Allow the filter unit to cool down before touching it.
10.3.1 Removing the filter element
Fig. 5: Removing the filter element
1. Turn the housing cover (1) counterclockwise.
2. Carefully remove the cover (1) with the filter element (2) from the filter tube.
(The filter element is attached to the cover.
Let the draining oil drip off into the housing.)
10.3.2 Removing the filter element from the cover
Fig. 6: Removing the filter element from the cover
1. Push the filter element at the cover in arrow direction 1 and remove it in
arrow direction 2.
2. Dispose of the filter element according to the national environmental
legislation (Waste code: Oil filter 16 01 07).
CAUTION

Subject to change · V 0.1 · 02.2020 · EN
Page 19
www.argo-hytos.com
10.3.3 Attaching the filter element
Fig. 7: Attaching the filter element
1. Check the filter element type number.
Does the laser inscription on the filter element match with the indications on
the type plate or in the operating manual?
2. Attach the filter element in arrow direction 2 and lock it in arrow direction 1.
10.3.4 Installing the filter element
Fig. 8: Installing the filter element
1. Carefully insert the cover (1) with the filter element (2) into the filter tube.
2. Screw in the cover manually until it stops.
A gap between cover and filter pipe may remain visible
(see Chapter 8.1 "Before commissioning" / Fig. 3)
10.4 Replacing the pump and the motor
Danger to life
Risk of electric shock
›Before uninstalling, disconnect the device from the power supply and pull the mains plug. Uninstalling may
only be carried out by qualified electricians.
›Electrical work on the off-line filter units has strictly to be carried out by qualified electricians. Danger of
electrical shock.
Risk of injury
Risk of injury by incorrect handling
›Uninstalling may only be carried out by instructed persons.
DANGER
Risk of burns
Contact temperatures according to DIN EN563 (3) and DIN EN13202 (4) may be exceeded
during operation.
›Allow the filter unit to cool down before touching it.
Risk of functional impairment
In case of dirt ingress into the pump during maintenance work, optimal functioning of the device is no
longer guaranteed (no manufacturer liability).
›Work with special care when replacing the pump / motor.
›All parts coming into contact with the hydraulic medium must be kept free from dirt and chips.
WARNING
CAUTION

Subject to change · V 0.1 · 02.2020 · EN
Page 20 www.argo-hytos.com
9
8
7
6
5
4
3
2
1
Fig. 9: Replacing the motor and the pump
10.4.1 Removing the pump / motor
1. Unscrew the cylinder screws (Pos. 1 and 2) and release the motor / pump unit (Pos. 4 - 8) from the block (Pos. 3) in upward direction.
2. Unscrew the cylinder screws (Pos. 4) and release the motor (Pos. 8) from the pump (Pos. 7).
NOTE
›When replacing the pump / motor, the O-rings (Pos. 5 and Pos. 7) must always be replaced by new O-rings.
Please take the Order No. from the spare parts list.
10.4.2 Installing the pump / motor
1. Lubricate the O-ring (Pos. 7) and insert it into the provided O-ring groove of the pump (Pos. 6).
2. Place the pump (Pos. 6) onto the motor (Pos. 8) and press it down. Make sure that the O-ring (Pos. 7) remains in the O-ring
groove and that it is not damaged between the pump (Pos. 6) and the motor (Pos. 8).
NOTE
Observe the alignment of the pump
›During the subsequent assembly, the suction and pressure kidneys of the pump (Pos. 6) must coincide with those of the pump
block (Pos. 3) (ensure the correct position by a roll pin (Pos. 9)). Please also pay attention to the later position of the terminal box
(Fig. 1 Pos. 4).
3. Fasten the pump (Pos. 6) using the cylinder screws (Pos. 4) (MA20 +5 Nm).
4. Lubricate the O-ring (Pos. 5) and insert it into the provided O-ring groove of the pump (Pos. 6).
5. Fill the pump (Pos. 6) with oil via the suction and pressure kidneys and check the pump's operability
(turn the shaft end of the motor once by 360° by hand).
6. Place the motor and pump assembly (Pos. 6 with Pos. 8) overhead on the pump block (Pos. 3).
Make sure that the O-ring (Pos. 5) remains in the O-ring groove and that it is not damaged between the pump (Pos. 6) and
the pump block (Pos. 3).
7. Fasten the motor / pump unit with the cylinder screws (Pos. 1 and Pos. 2) to the pump block (Pos. 3) (MA 20 +5 Nm).
8. Fasten the filter pump block to the machine / system, using the rubber buffers (Order No. UM 045.0709) (MA20 +5 Nm).
9. Connect the unit to the power supply according to the electrical connection diagram.
The device can be put into operation (see manual: Commissioning).
If no oil is sucked during commissioning, open the cover at the filter housing and fill in about 0.5 l oil.
