Argo DRY NATURE 17 User manual

15
V 04/20
DEHUMIDIFIER
DRY NATURE 17
DRY NATURE 21
OPERATING INSTRUCTIONS
Read the instructions carefully before operating or servicing the dehumidifier.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Keep
these instructions in a safe place for future reference.
EN

16
V 04/20
The Refrigerant R290
To realize the function of the air conditioner unit, a special refrigerant circulates in the
system. The refrigerant is the fluoride R290 = 3 GWP (Global warming potential). This
refrigerant is flammable and inodorous. It can lead to explosions under certain
conditions, however the flammability of this refrigerant is very low and it can be ignited
only by fire.
Compared to other common refrigerants, R290 is a non-polluting refrigerant with no
harm to the ozonosphere and a no effect upon the greenhouse effect. R290 has very
good thermodynamic features which lead to a really high energy efficiency. The units
therefore need less filling.
Warning:
Do not try to accelerate the defrosting process or to clean the appliance in different ways other
than those recommended by the manufacturer. Should repair be necessary, contact your
nearest authorized Argoclima Service Centre. Any repairs carried out by unqualified personnel
may be dangerous. The appliance has to be stored in a room that doesn’t have any
continuously operating ignition sources. (for example: open flames, an operating gas
appliance or an operating electric heater.) Do not pierce or burn.
Appliance has to be installed, operated and stored in a room with a floor area larger than 4 m2.
For repairs, strictly follow manufacturer’s instructions only for appliances filled with R290
flammable gas. Be aware that refrigerants do not have any odour.
Appliance filled with flammable gas R290.
Before installing and using the appliance, read the owner’s manual.
Before repairing the appliance, read the service manual.

17
V 04/20
GENERAL OPERATING AND SAFETY INSTRUCTIONS
This appliance is a very effective dehumidifier designed only
for domestic use!
Do not place the appliance in humid environments such as
laundries.
Do not place the unit near appliances which can generate heat or
near dangerous/inflammable materials.
Only use this dehumidifier as described in this manual. Any other
use not recommended by the producer could cause fires, electric
shocks or malfunction.
The unit must be placed in vertical position because it contains
refrigerant.
After opening the unit packing for the first time, place the
appliance in vertical position to allow to the refrigerant to stabilize
and wait for two hours before to use it.
Ensure that the required voltage and frequency (220-240 V/50 Hz)
match the available power source.
This appliance can be used by children aged from 8 years and
above and people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
Make sure that the electric plug is secutely inserted. Do not use
multiple adapters. Do not touch the plug with wet hands. Ensure
that the plug is clean.
Children between 3 and 8 years of age must only be able to turn
on/off the appliance, provided that it has been placed in its normal
operating position, and that they have been instructed on how to
safely use the appliance and that they have understood the risks.
Children between 3 and 8 years of age must not be able to
connect the plug, regulate operation or clean the appliance or
carry out maintenance on it.
Disconnect the power plus from the main power supply if it is
not used or during cleaning. An inserted power plug may
cause electric shock or accident.

18
V 04/20
To turn the appliance off, press the button on OFF and remove the
plug from the socket. Pull on the plug only. Do not pull the cord.
Do not bend, drag, twist or pull out the cable with force.
Do not use the appliance if the cord or plug are damaged,
could be fires or electric shock risks. If the power supply cord is
damaged, it must be replaced by the manufacturer, dealer or a
similarly qualified person so as to avoid any safety risks.
Do not place heavy objects on the dehumidifier.
To avoid water spill, empty the water tank before moving the
appliance.
Do not tilt on one side, or do not turn the product upside down as
the leaking water could damage the product.
Do not place the product on unstable or sloping surfaces:
water leakage could cause malfunction or abnormal
vibrations with consequent noise.
The dehumidifier must be positioned at least 50 cm away from the
wall or other obstacles to properly dissipate the heat.
Do not place the operating appliance inside the furnitures or
cabinets, otherwise could cause fires.
Close all open windows to achieve the maximum
dehumidification efficiency.
Do not insert fingers or objects in the air supply grille.
Do not cover the inlet and outlet air grille.
WARNING!
In the event of an anomaly, switch the appliance off and unplug
from the socket. Do not dismantle or attempt to repair or
modify the product. In the event of a malfunction, contact the
after-sales service centre directly.
Do not soak the power cord, the socket or any other part of
dehumidifier into the water or other liquids.
Do not expose the appliance to direct sunlight.
Keep away the appliance from heat sources as this may alter the
colour of the materials.
Do not use insecticides, oils, detergents or spray paints near the
appliance; do not use aggressive chemical detergents to clean the
casing as this may damage the finish and colour.

19
V 04/20
Keep away from the applianced flammable gases or oils!
Do not move the unit during operation: this could cause water
leaks and malfunctions.
Do not pierce or burn the appliance.
The manufacturer shall not be held liable if the relevant safety
and accident prevention rules are not observed.
DESCRIPTION OF PARTS
1. Control panel
2. Handle
3. Air outlet flap
4. Wheels
5. Filter box
6. Water tank
7. Power cord
FRONT VIEW REAR VIEW

20
V 04/20
PRE-OPERATING CHECKS BEFORE THE USE
Make sure the floater and the condensate collection tank are correctly positioned
1. Pull out the tank using both hands and verify the correct position of the floater (1).
2. The following space must be maintained to ensure the operating efficiency of the dehumidifier.
OPERATING INSTRUCTIONS
APPLIANCE START-UP
Place the product on a flat and stable heat-resistant surface, at least 1 metre away from flammable or heat-sensitive
materials and 50 cm away from walls or other obstructions.
Make sure the water tank is in the correct position
.
Connect the power cord to a suitable electric socket (220-240V/50Hz).
Turn the appliance on with POWER on the control panel.
The dehumidifier is designed to operate at ambient temperatures from + 5°C to + 35°C.
If it is operated at low temperatures, ice may form on the evaporator, degrading its operation.
When this happens, the dehumidifier goes into defrost mode. The compressor stops, but the fan continues running.
The defrosting operation may start up and operate for some minutes; during the defrosting operation, the dehumidification
function may intermit: please don’t turn off the switch or pull out the power plug of the dehumidifier.
We recommend not using the dehumidifier in room temperatures lower than 5°C.
50 cm 50 cm
1

21
V 04/20
OPERATING PRECAUTIONS
The dehumidifier will start working only if the humidity level set is lower than the humidity in the surrounding environment
and It will work till reaching the selected humidity level or continuously if the selected humidity level in the room is lower
than the humidity in the environment, with the exception of interruptions caused by a full tank. In this case, empty
and reinstall the tank: the dehumidifier will start running again.
WARNING:
After each interruption of its operation, at least 3 minutes must pass before the dehumidifier starts up again:
this delay prevents the compressor being damaged.
If you follow the start up instructions but the dehumidifier does not start stops for no reason, make sure the plug and
power cord are in good working order. After doing so, wait for 10 minutes and then restart the appliance.
If the dehumidifier still does not start after 10 minutes, or if either the power cord or plug are damaged, switch off the
appliance and contact an after-sales service centre.
WARNING:
When the dehumidifier is running, the compressor produces heat and the appliance emits warm air into the
room. The room temperature will therefore tend to increase. This is completely normal.
AUTOMATIC DEFROST: the dehumidifier is designed to operate at ambient temperatures from + 5°C to + 35°C.
When the unit operates at low environmental temperature the evaporator surface can be covered by ice that can
reduce dehumidifying capacity. When environmental temperature is between 5 and 12°C the unit will stop to
operates quick defrosting cycles every 30 minutes. If the environmental temperature is between 12 and 20°C the
unit will stop to operates quick defrosting cycles every 45 minutes.
When this happens, the dehumidifier goes into defrost mode. The compressor stops, but the fan continues
running.
We recommend not using the dehumidifier in room temperatures lower than 5°C.
MEMORY FUNCTION: the dehumidifier starts up again after a power failure maintaining its settings.
TURNING THE DEHUMIDIFIER OFF
To turn the dehumidifier off press the POWER button. This shuts off power to the unit. Unplug the appliance if you do not
intend to use it for some time.
HOW TO ELIMINATE CONDENSATE
The water extracted from the air can be collected in the provided front tank.
When the tank is full, not inserted or not correctly inserted, the FULL TANK led turns on and the unit beeps for about 15
times, at the end of which the unit turns off.
To switch off the appliance, press the POWER button and wait a few seconds.
1. Carefully remove the tank using both hands and following the direction of the arrow.

22
V 04/20
2. Empty the tank.
3. Reposition the tank following the direction of the arrow.
If the drainage tank is dirty, wash it with cold or lukewarm water. Do not use detergent, scouring pads, chemically
treated dust clothes, gasoline, benzene, thinner or other solvents, as these can scratch and damage the tank and cause
water leakage.
When replacing the drainage tank, press the tank firmly into place with both hands. If the tank is not positioned properly,
the “tank Full” sensor will be active, and the dehumidifier will not operate.
N.B.
Do not use the drain hose when you are collecting condensation in the tank, otherwise water can leak out of the hose.
CONTINUOUS CONDENSATE DRAINAGE
The water can be continuously drained when using the PVC hose of 10 mm diameter, supplied in the package, to insert
in the drain hole placed in the central part of the rear side of dehumidifier.
Turn off the appliance and remove the plug before connecting the hose.

23
V 04/20
Remove the tank and safely connect the hose to the continuous condensate discharge connection, as shown in the
figures below.
The height of the drainage hose must not exceed that of the hole: do not block the drainage hose exit.
CONTROL PANEL
Indications of Display on control panel
The indicator features 3 functions:
1. when the unit is plugged in, it will indicate the room humidity level.
2. when you set the humidity, it will indicate the humidity that you have selected
3. when you program the time for the unit to turn on and off, it will show the hours.
4. When the environment humidity is lower than 35%, it will show “35”
5. When the environment humidity is higher than 95%, it will show “95”
3 2 5 4 1
DISPLAY
Indicator tank FULL

24
V 04/20
TOUCH BUTTONS AND LED INDICATORS
The buzzer will alarm for several times when the unit is powered on, the LED will show the room humidity
for 3 seconds, then it will automatically turn off.
1.Turn on/off button
Touch the button to start the unit when the unit is stop, or touch to shutdown it, when the unit
is operating.
2. Humidity setting button
Touch the button to enter humidity-setting state, then touch or to adjust the humidity
from 40% to 80%, every setting is 5%, the LED flashing display when adjusting. Stop pressing for 5
seconds, it will return to normal display. The default value of humidity is 55%.
3. Fan-speed setting button
Touch the button to set the fan speed to HIGH or LOW, and the corresponding fan speed light will be
lighted.
4.Swing setting button
After the appliance is started, touch the button to start or stop the air-outlet leaf swing
5.Time-setting button
Touch the button to enter boot-time setting state when the unit is stop, then the LED will display the
time, you may touch or button to adjust the automatic boot time from 1 to 24 hours.
Touch to enter shutdown-time setting state when the unit is running, then the LED will display the
time, you may touch or button to adjust the automatic shutdown time from 1 to 24 hours.
Once turned on or off by user or entering water-full state, the unit may loose the timing function.

25
V 04/20
CLEANING AND MAINTENANCE
MAINTENANCE OF THE HUMIDIFIER’S EXTERIOR SURFACE
Warning
Always pull the dehumidifier's plug out of the power socket before cleaning it, to prevent electric
shock and malfunction.
Warning
Do not wet the appliance or immerse it in water, otherwise electric shocks may occur.
Use a damp and soft cloth to clean the exterior surface of the dehumidifier.
Do not use solvents, petrol, xylene, talcum powder or brushes to clean the unit: these may damage
the surface or colour of the casing.
CLEANING THE WATER TANK
We recommend to clean the water tank once every few weeks to prevent mould and bacteria forming on it. Fill the tank
with clean water a small amount of detergent; swill the water around in it, then it out and rinse it thoroughly.
CLEANING THE AIR FILTER
WARNING!
Unplug the unit before start cleaning the air filter.
The filter is designed to remove dust or dirt from the air.
If the filter is clogged by dust, electricity consumption will be higher than normal.
Cleaning instructions:
1. Remove the filter by pulling down the grid to complete extraction. Clean the filter washing it with
warm soapy water.
DO NOT USE ALCOHOL, BENZENE OR OTHER AGGRESSIVE PRODUCTS TO CLEAN THE FILTER.
Do not use the dehumidifier without the filter as dust may affect the efficiency of the evaporator, resulting in higher
energy consumption.

26
V 04/20
2. Clean the air filter
Run a vaacum cleaner lightly over the surface of the air filter to remove dirt. If the air filter is exceptionally dirty wash
it with warm water and mild cleanser and dry thoroughly.
3. Attach the air filter
Insert the filter into the grill smoothly, and place the inlet grill into right place.
Storing the Dehumidifier
When the unit is not being used for a long period of time and you want to store it note the following steps:
1. Empty any water left in the drainage tank.
2. Fold up the power supply cord and put it in the water tank.
3. Clean the air filter
4. Discard in a cool and dry place.

27
V 04/20
TROUBLESHOOTING
Problem Possible Cause Solution
The unit doesn't operate
Has the power cord been
disconnected? Plug the power cord into the outlet.
Is the tank full indication
lamp blinking? (The tank is
full or in a wrong position.)
Empty the water in the drainage
tank and then reposition the tank.
Is the temperature of the
room above 35℃or below
5℃?
The protection device is
activated and the unit
cannot be started.
The dehumidifying
function doesn't work
Is the air filter clogged?
Clean the air filter as
instructed under
"Cleaning the dehumidifier".
Is the intake duct or
discharge duct obstructed?
Remove the obstruction from the
discharge duct or intake duct.
No air is discharged Is the air filter clogged?
Clean the air filter as
instructed under
"Cleaning the dehumidifier".
Operation is noisy
Is the unit tilted or
unsteady?
Move the unit to a stable, sturdy
location.
Is the air filter clogged?
If the units operates with a
temperature between 5 and 15°C the
dehumidifier will stop for the
automatic defrost. The compressor
will stop for short periods. After
defrost the unit will start to norm
Clean the air filter as
instructed under
"Cleaning the dehumidifier".

28
V 04/20
REGULATION (EU) N. 517/2014 - F-GAS
DRYNATURE 17
The unit contains R290, a natural greenhouse gas with global warming potential (GWP) = 3 - Kg. 0,075 = 0,000225
Tons CO2equiv.
Do not release R290 into the atmosphere.
DRYNATURE 21
The unit contains R290, a natural greenhouse gas with global warming potential (GWP) = 3 - Kg. 0,80 = 0,000240 Tons
CO2equiv.
Do not release R290 into the atmosphere.
INFORMATION FOR THE CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EUROPEAN
DIRECTIVE 2012/19/EU
This appliance may not be scrapped with domestic waste at the end of its life cycle. We call your attention to the
crucial role played by the consumer in the re-use, recycling and other forms of recovery of such waste.
The appliance must be scrapped by a sorted waste disposal centre or by returning it to the retailer (no charge is
levied for this service), when you purchase a new equivalent appliance.
Sorted disposal of electric and electronic equipment prevents the negative effects on the environment and human
health resulting from improper scrapping, and also allows the materials from which it is made to be recovered and
recycled, with significant savings in terms of energy and resources.
The sorted disposal requirement is indicated by the crossed waste bin label affixed to the appliance.
www.argoclima.com
